Teac DC-D2700 User manual

The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert
the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure
that may be of sufficient magnitude to constitute a risk of electric shock to persons.
dc-d2700
Û
Thanks for buying a TEAC. Read this manual carefully to get the best performance from this unit.
Digital Compact Hi-Fi System
OWNER’S MANUAL
9A06831900
This appliance has a serial number located
on the rear panel. Please record the model
number and serial number and retain them
for your records.
Model number
Serial number
WARNING: TO PREVENT FIRE OR SHOCK
HAZARD, DO NOT EXPOSE THIS
APPLIANCE TO RAIN OR MOISTURE.
The exclamation point within an equilateral triangle is intended to alert the user to the
presence of important operating and maintenance (servicing) instructions in the
literature accompanying the appliance.
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE
COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.
Ü
ÿ
Ÿ
˛

- 2 -
IMPORTANT SAFETY INSTRUCTIONS
CAUTION:
•Read all of these Instructions.
•Save these Instructions for later use.
•Follow all Warnings and Instructions marked on the audio
equipment.
1) Read Instructions — All the safety and operating instructions
should be read before the product is operated.
2) Retain Instructions — The safety and operating instructions
should be retained for future reference.
3) Heed Warnings — All warnings on the product and in the oper-
ating instructions should be adhered to.
4) Follow Instructions — All operating and use instructions should
be followed.
5) Cleaning — Unplug this product from the wall outlet before
cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp
cloth for cleaning.
6) Attachments — Do not use attachments not recommended by
the product manufacturer as they may cause hazards.
7) Water and Moisture — Do not use this product near water _for
example, near a bath tub, wash bowl, kitchen sink, or laundry tub; in
a wet basement; or near a swimming pool; and the like.
8) Accessories — Do not place this product on an unstable cart,
stand, tripod, bracket, or table. The product may fall, causing serious
injury to a child or adult, and serious damage to the product. Use
only with a cart, stand, tripod, bracket, or table recommended by the
manufacturer, or sold with the product. Any mounting of the product
should follow the manufacturer’s instructions, and should use a
mounting accessory recommended by the manufacturer.
9) Aproduct and cart combination should be moved with care. Quick
stops, excessive force, and uneven surfaces may cause the product
and cart combination to overturn.
"Note to CATV system installer:
This reminder is provided to call the CATV system installer’s atten-
tion to Section 820-40 of the NEC which provides guidelines for
proper grounding and, in particular, specifies that the cable ground
shall be connected to the grounding system of the building, as close
to the point of cable entry as practical."
ANTENNA
LEAD IN
WIRE
ANTENNA
DISCHARGE UNIT
(NEC SECTION 810-20)
GROUNDING CONDUCTORS
(NEC SECTION 810-21)
GROUND CLAMPS
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250. PART H)
NEC - NATIONAL ELECTRICAL CODE
ELECTRIC
SERVICE
EQUIPMENT
Example of Antenna Grounding as per
National Electrical Code, ANSI/NFPA 70
GROUND
CLAMP
15) Lightning — For added protection for this product during a light-
ning storm, or when it is left unattended and unused for long periods
of time, unplug it from the wall outlet and disconnect the antenna or
cable system. This will prevent damage to the product due to light-
ning and power-line surges.
16) Power Lines — An outside antenna system should not be locat-
ed in the vicinity of overhead power lines or other electric light or
power circuits, or where it can fall into such power lines or circuits.
When installing an outside antenna system, extreme care should be
taken to keep from touching such power lines or circuits as contact
with them might be fatal.
17) Overloading — Do not overload wall outlets, extension cords, or
integral convenience receptacles as this can result in risk of fire or
electric shock.
18) Object and Liquid Entry — Never push objects of any kind into
this product through openings as they may touch dangerous voltage
points or short-out parts that could result in a fire or electric shock.
Never spill liquid of any kind on the product.
19) Servicing — Do not attempt to service this product yourself as
opening or removing covers may expose you to dangerous voltage
or other hazards. Refer all servicing to qualified service personnel.
20) Damage Requiring Service — Unplug this product from the
wall outlet and refer servicing to qualified service personnel under
the following conditions:
a) when the power-supply cord or plug is damaged.
b) if liquid has been spilled, or objects have fallen into the product.
c) if the product has been exposed to rain or water.
d) if the product does not operate normally by following the operat-
ing instructions. Adjust only those controls that are covered by the
operating instructions as an improper adjustment of other controls
may result in damage and will often require extensive work by a qual-
ified technician to restore the product to its normal operation.
e) if the product has been dropped or damaged in any way.
f ) when the product exhibits a distinct change in performance _ this
indicates a need for service.
21) Replacement Parts — When replacement parts are required,
be sure the service technician has used replacement parts specified
by the manufacturer or have the same characteristics as the original
part. Unauthorized substitutions may result in fire, electric shock, or
other hazards.
22) Safety Check — Upon completion of any service or repairs to
this product, ask the service technician to perform safety checks to
determine that the product is in proper operating condition.
23) Wall or Ceiling Mounting — The product should be mounted to
a wall or ceiling only as recommended by the manufacturer.
24) Heat — The product should be situated away from heat sources
such as radiators, heat registers, stoves, or other products (includ-
ing amplifiers) that produce heat.
10) Ventilation — Slots and openings in the cabinet are provided for
ventilation and to ensure reliable operation of the product and to pro-
tect it from overheating, and these openings must not be blocked or
covered. The openings should never be blocked by placing the prod-
uct on a bed, sofa, rug, or other similar surface. This product should
not be placed in a built-in installation such as a bookcase or rack
unless proper ventilation is provided or the manufacturer’s instruc-
tions have been adhered to.
11) Power Sources — This product should be operated only from
the type of power source indicated on the marking label. If you are
not sure of the type of power supply to your home, consult your prod-
uct dealer or local power company. For products intended to operate
from battery power, or other sources, refer to the operating instruc-
tions.
12) Grounding or Polarization — This product may be equipped
with a polarized alternating-current line plug (a plug having one
blade wider than the other). This plug will fit into the power outlet
only one way. This is a safety feature. If you are unable to insert the
plug fully into the outlet, try reversing the plug. If the plug should still
fail to fit, contact your electrician to replace your obsolete outlet. Do
not defeat the safety purpose of the polarized plug.
13) Power-Cord Protection — Power-supply cords should be rout-
ed so that they are not likely to be walked on or pinched by items
placed upon or against them, paying particular attention to cords at
plugs, convenience receptacles, and the point where they exit from
the product.
14) Outdoor Antenna Grounding — If an outside antenna or
cable system is connected to the product, be sure the antenna or
cable system is grounded so as to provide some protection against
voltage surges and built-up static charges. Article 810 of the
National Electrical Code, ANSI/NFPA 70, provides information with
regard to proper grounding of the mast and supporting structure,
grounding of the lead-in wire to an antenna discharge unit, size of
grounding conductors, location of antenna-discharge unit,
connection to grounding electrodes, and requirements for the
grounding electrode.

- 3 -
SAFETY INFORMATION
This product has been designed and manufactured according to FDA regulations "title 21, CFR, chapter 1, subchapter J, based on the Radiation
Control for Health and Safety Act of 1968", and is classified as class 1 laser product. There is not hazardous invisible laser radiation during oper-
ation because invisible laser radiation emitted inside of this product is completely confined in the protective housings.
The label required in this reguration is shown 1.
…CAUTION
-DO NOT REMOVE THE PROTECTIVE HOUSING USING SCREWDRIVER.
-USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZ-
ARDOUS RADIATION EXPOSURE.
-IF THIS PRODUCT DEVELOPS TROUBLE, MAKE A CONTACT WITH OUR SERVICEMAN, AND DO NOT USE THE PRODUCT IN A
TROUBLED STATE.
Optical pickup: Type : SF-91P
Manufacturer : SANYO Electric CO., Ltd
Laser output : Less than 0.5 mW on the objective lens
Wavelength : 790 nm
1CERTIFICATION
THIS PRODUCT COMPLES WITH DHHS
RULES 21 CFR SUBCHAPTER J APPLI-
CABLE AT DATE OF MANUFACTURE
TEAC CORPORATION
3-7-3 NAKA-CHO, MUSASHINO-SHI, TOKYO, JAPAN
MANUFACTURED TIF
For U.S.A.

- 4 -
Before Use
ªCassette Tape Handling
Tape Handling:
Do not store tapes in the following places:
…On top of heaters, exposed to direct sunlight or in
any other places with high temperatures.
…Near speakers, on TV sets or amplifiers or where they
would be exposed to strong magnetic fields.
…Where humidity is high and in dirty, dusty places.
…Avoid dropping or subjecting cassettes to excessive
shocks.
…As C-120 tapes are physically weak and could
become entangled in the transport mechanism, do
not use them.
ªLoading a Cassette Tape
1. Use your finger or a pencil to turn the cassette's hub
and take up any slack tape.
Note:
Avoid touching the tape. Fingerprints attract dust and
dirt.
2. Press the STOP/EJECT button to open it.
3. Load the cassette tape with its open edge facing
down.
4. Gently close the compartment door.
ªHandling the Discs
This unit has been designed specifically for sound
reproduction from compact discs bearing the "˛"
mark. No other discs can be used.
…Always place the compact disc in the disc tray with
the label facing upward. (Compact discs can be
played only on one side.)
…To remove a disc from its storage case, press down
on the center of the case and lift the disc out, holding
it carefully by the edges.
How to remove the disc
How to hold the disc
…Fingermarks and dust should be carefully wiped off
the disc's recorded surface with a soft cloth.
Wipe radially
…Never use such chemicals as record sprays, antistatic
sprays or fluid, benzine or thinner to clean compact
discs. Such chemicals will do irreparable damage to
the disc's plastic surface.
…Discs should be returned to their cases after use to
avoid serious scratches that could cause the laser
pickup to "skip."
…Do not expose discs to direct sunlight or high humid-
ity and temperature for extended periods.
Long exposure to high temperatures can warp the
disc.
…Do not stick paper or write anything with a ballpoint
pen on the surface of the label side.
ªMaintenance of Cassette Decks
The heads and tape path should be cleaned and
demagnetized periodically.
Cleaning Tape Path
…Apply head cleaning fluid* to a cotton swab or soft
cloth, and lightly rub the heads, capstan and all metal
parts in the tape path.
…Also clean the pinch roller using rubber cleaning
fluid*.
*Both are available in TEACTape Recorder Cleaning
Kits HC-2 and RC-2 in the U.S.A. orTZ-261 in other
areas.
Demagnetizing Heads
Be sure that the power is off, then demagnetize the
heads using a TEAC E-3 demagnetizer. For details of its
use, read its instructions.
Pinch RollerRecord/Playback Head
Erase Head
Capstan

- 5 -
ªRemoving the transit screw
Unscrew the transit screw with a Phillips head screw-
driver by rotating counterclockwise until the screw is
completely removed.
ªConnecting speakers
Connect each speaker plug to the speaker terminal.
Use speakers with impedance of 4 ohms or more, since
low impedance speakers may damage the unit.
ªConnecting the AC power cord
After connecting the speakers, insert the power plug
into the wall outlet firmly.
The STANDBY indicator on the panel will light.
ªBattery installation for memory backup
Set a new "006P" 9V battery to the terminal inside the
battery compartment on the rear panel. The battery will
keep the preset radio stations in memory.
…Replace the battery with new one approximately
every one year. When replaced, preset stations may
be erased from the memory. In this case, memorize
the station again.
ªBattery installation for Remote
Control Unit
1. Remove the battery compartment cover.
2. Insert three "AAA" (R03, UM-4) dry batteries.
Make sure that the batteries are inserted with their
positive ±and negative —poles positioned correctly.
3. Close the cover until it clicks.
ªBattery Replacement
If the distance required between the remote control unit
and main unit decreases, the batteries are exhausted. In
this case replace the batteries with new ones.
ªPrecautions concerning batteries
…Be sure to insert the batteries with correct positive
"±" and negative "—" polarities.
…Use batteries of the same type. Never use different
types of batteries together.
…Rechargeable and non-rechargeable batteries can be
used. Refer to the precautions on their labels.
…When the remote control unit is not to be used for a
long time (more than a month), remove the batteries
from the remote control unit to prevent them from
leaking. If they leak, wipe away the liquid inside the
battery compartment and replace the batteries with
new ones.
…Do not heat or disassemble batteries and never
dispose of old batteries by throwing them in a fire.
Preparation of Use
Memory Backup Battery
Compartment
Speaker Plugs
To AC Outlet
Transit Screw
This equipment draws nominal nonoperating power
from the AC outlet with its POWER switch in the OFF
position.
Obs! nätströmställaren skiljer ej fela apparaten från
nätet.

- 6 -
Locations of Buttons and Controls
Front Panel
Tu rntable
Rear Panel

- 7 -
1POWER-ON/STANDBY switch
2MEMORY button
3POWER indicator
4FM STEREO indicator
5AUTO SEARCH button (TUNER)
6Tuner display
7STATION MEMORY buttons
8TUNING (Up/Down) buttons
9DUBBING/BEAT CUT switch
0Power STANDBY indicator
qREMOTE SENSOR
wGRAPHIC EQUALIZER control
eBALANCE control
rFUNCTION selector
tVOLUME (UP/DOWN) control
yBAND selector
uPHONES jack
iDeck II Cassette Door
oDeck II Control buttons
pDeck I Cassette Door
aDeck I Control buttons
sDisc tray (CD)
dDisplay (CD)
fINTRO button (CD)
gSEARCH (Ô/) buttons (CD)
hSKIP (Â/¯) buttons (CD)
jSHUFFLE (RANDOM) button (CD)
kREPEAT button (CD)
lPROGRAM button (CD)
;PLAY/PAUSE (Áπ ) button (CD)
zSTOP (ª) button (CD)
xDISC SKIP ( ) button (CD)
cOPEN/CLOSE (ø) button (CD)
vCenter Spindle
bTu rntable Platter
n7" (17 cm) EP Record Adaptor
mTo n earm
,Speed Select switch
.To nearm Rest/Clamp
/Headshell
!FM Antenna
@Tr ansit Screw
#Battery Compartment
$Speaker Terminal
%AC Cord
Remote Control Unit
Certain buttons on the remote control unit and on the
front panel of the DC-D2700 have the same or similar
functions and have the same reference numbers.

- 8 -
Basic Operation
POWER
POWER
indicator
STANDBY
indicator
PHONES
FUNCTION
VOLUME
BALANCE
GRAPHIC
EQUALIZER
ªPower On and Off
To turn the power on, press the POWER (ON/STANDBY)
button.
The STANDBY indicator will turn off and the POWER
indicator will light.
To turn the power off, press the POWER (ON/STANDBY)
button again.
The STANDBY indicator will light and the POWER indi-
cator will turn off.
To switch off the unit completely:
Unplug the AC power cord from the AC outlet.
ªAmplifier operation
1. Select the desired source with the FUNCTION selec-
tor; then the selected source appears in the display.
2. Operate the selected source component for playback.
(See the following pages for the detailed informa-
tion.)
3. Adjust the volume to a comfortable listening level
with VOLUME UP/DOWN (a knob on the panel or but-
tons on the remote control unit).
ªOther functions
ªGraphic equalizer
You can alter the sound character using the 3-band
GRAPHIC EQUALIZER if you want. The "100 Hz" knob
controls boost/cut of low frequency range, the "1 kHz"
knob controls mid range, and the "10 kHz" knob controls
high range.
Note that the graphic equalizer works on the monitor
sound in playback, but does not affect for recording on
cassette tapes.
ªHeadphones monitor
For private listening, connect a pair of headphones
with 3.5 mm diameter stereo plug (stereo mini plug) to
the PHONES jack. When headphones are plugged in, no
sound comes out of the speakers.
Be sure to turn down the volume before connecting or
putting on headphones.
ªBalance control
The BALANCE control knob changes the stereo balance
between left and right.

- 9 -
Listen to Radio
You can enjoy FM and AM radio with the DC-D2700. The
Station Memory function allows the instant recall of up
to 10 stations; 5 for FM and 5 for AM.
ªManual Tuning
1. Set the FUNCTION selector to RADIO position.
The tuner display will be indicated.
2. Set the BAND selector to desired position.
…FM STEREO:
Receives FM program in stereo. The FM STEREO indi-
cator will light when receiving the FM stereo prgram.
…FM:
Receives FM program in mono mode. When the FM
signals received are weak or there is interference on
the airwaves, it is preferable to receive the program
in this position.
…AM:
Receives AM program.
*FM antenna setting
Extend the supplied FM wire antenna on the rear
panel and try to find the best FM antenna position
when selecting FM.
3. Continue pressing theTUNING (Up) or (Down)
button until the desired station is reached.
Note:
If you press either TUNING (Up) or (Down) button
longer than 0.5 second, the fast tuning will be activated.
ªAuto Search
1. Follow steps 1 and 2 above (of "ManualTuning").
2. Press AUTO SEARCH button once.
The unit will search the station automatically and the
search stops at the first strong station being
received. Repeat until your desired station is being
received.
Notes:
…To terminate Auto Search, just press either TUNING
(Up) or (Down) button.
…For weaker stations utilize the manual selection of the
radio station.
…Since Auto search stops if a signal of certain strength
is received, it will not necessarily stop at the exact
frequency of the desired station depending on the
signal strength of the program. If this occurs, press
the TUNING (Up) or (Down) button until the correct
frequency is reached.
ªPreset Tuning
This unit is equipped with five preset stations for both
AM and FM. Once they are preset, you can enjoy broad-
casting corresponding to those preset stations by sim-
ply pressing the STATION MEMORY button.
1. Select the required station manually or automatically
as described above.
2. Press the MEMORY button and then one of the STA-
TION MEMORY buttons. The frequency is memorized
on that STATION MEMORY.
ªRecalling Preset Stations
1. Press the STATION MEMORY button on which the
frequency of the station you want to recall is memo-
rized.
AUTO SEARCH
STATION
MEMORY
FUNCTION
BAND
TUNING
MEMORY
FM STEREO
Display

- 10 -
Listening to CD
The DC-D2700 offers the carrousel type CD changer
which can be loaded up to 3 discs in the independent
disc trays.
1OPEN/CLOSE (ø):
Opens and closes the disc tray.
2PLAY/PAUSE (Áπ):
Starts playback. Pressing it during playback pauses
playback.
3PROGRAM :
Sets the program mode.
4SHUFFLE (RANDOM) :
Plays all tracks of the set discs randomly.
5INTRO :
Plays the first 10 seconds of each track.
6STOP (ª):
Stops playback.
7SKIP (Â/¯) :
Selects tracks. (Backward/forward track selection)
8SEARCH (Ô/) :
Fast backward/fast forward.
9REPEAT:
Sets the repeat mode.
0DISK SKIP ( ) :
Specifies disc skip.
ªBasic CD Playback
1. Set the FUNCTION selector to CD.
2. Press OPEN/CLOSE (ø) to open the disc tray.
3. Place CD(s) with the label side up onto the carousel.
Up to 3 discs can be set.
4. Press OPEN/CLOSE (ø) to close the disc tray.
5. Press PLAY/PAUSE (Áπ) to start playback.
The player starts playback.
To stop playback:
Press STOP (ª).
To pause playback:
Press PLAY/PAUSE (Áπ) .
Pressing it again resumes playback.
To skip forward or backward
Pressing the (SKIP (¯) forward) button causes the
player to jump to the next track.
Pressing the (SKIP (Â) backward) button causes the
player to jump to the beginning of the current track.
Press the either of SKIP (Â/¯) buttons as many
times as required until jumping to the desired track.
To c hange the playback disc:
Press DISC SKIP ( ).
Notes:
…Make sure that the transit screw on the rear panel is
removed before using the first time.
(See "Preparation of Use" on page 5.
…Make sure to push STOP before turning the power off
or changing the FUNCTION switch.
…Do not turn the power off while the CD playing is
playing. Otherwise, the disc and mechanism may be
damaged. Also we recommend that all discs are
removed before turning the power off.
ªProgram Play
You can enjoy CD playback of the tracks in any preferred
sequence using the Program function.
1. While the disc is in stop, press PROGRAM.
The "PROGRAM" indicator will appear, and the DISC
number and TRACK number will become "--" and
flashing.
2. Press DISC SKIP to select the desired disc.
3. Locate the desired track using the SKIP buttons.
6STOP
0DISC SKIP
1OPEN/CLOSE
3PROGRAM
Disc tray Display 8SEARCH
7SKIP
5INTRO
9REPEAT
4SHUFFLE (RANDOM)
2PLAY/PAUSE

- 11 -
4. Press PROGRAM to enter the selection into memory.
5. Repeat steps 2-4 to program.
Up to 32 selections can be programmed.
6. Press PLAY/PAUSE to play the programmed
sequence of tracks.
Notes:
…Press STOP at any time to stop playback without eras-
ing the program.
…To resume programmed playback after pressing
STOP, press PROGRAM and then press PLAY/PAUSE.
…The program memory will be cleared when the
FUNCTION selector deselects CD, CD door is opened,
or the power is turned off.
ªShuffle (Random) Play
The player can play back tracks in random order.
1. Press SHUFFLE (RANDOM).
2. Press PLAY/PAUSE.
The player starts playback in random sequence of
tracks.
(The RANDOM indicator will appear.)
To quit the random playback:
press SHUFFLE (RANDOM) again.
ªRepeat Play - During Normal Playback
Each time REPEAT is pressed, the repeat mode is set
and repeat play is performed in the following sequence.
ªRepeat Play - During Programmed
Playback
Each time REPEAT is pressed during the programmed
playback mode, the repeat mode is set and repeat play
is performed in the following sequence.
ªIntro Check
You can check the first 10 seconds of each track on
discs.
1. Press INTRO.
2. Press PLAY/PAUSE.
The player starts playback of the beginning of each
track for 10 seconds.
To quit the Intro check function:
Press INTRO again.
Cautions:
…Ensure all the disc are removed and the carousel is
stilled before tuning off the unit.
…If a malfunction occurs during operation, reload the
disc.
…Keep all foreign objects out of the CD carousel.
…If TV or radio interference occurs during operation,
move the unit away from the TV and radio.
…Subjecting the unit to mechanical shock or vibration
may cause mistracking.
…Always keep the door closed when not in use.
…Playing some CDs at high volume may cause vibra-
tion leading to mistracking. In this case, lower the
volume or relocate speakers further away from the
unit.
REPEAT
ONE
REPEAT
DISC ALL
(Repeat 1 track) (Repeat all
programed disc)
(Repeat Off)
REPEAT
REPEAT ALL
REPEAT
ONE DISC
REPEAT
DISC
(Repeat 1 track) (Repeat 1 disc) (Repeat all disc)
(Repeat Off)
Beware of condensation
When the player (or a compact disc) is moved from
a cold to a warm place or used after a sudden tem-
perature change, there is the danger of condensa-
tion. Water vapor in the air could condense on the
mechanism or the laser pickup. If droplets of water
form on these parts, correct playback will be impos-
sible because the laser cannot read the information
from the disc correctly. To prevent this, if you are
going to use the player in a condition where con-
densation could occur, you should leave the player
for 1 or 2 hours after plugging it into an AC outlet
depending on the amount of condensation. If this is
done, the player will stabilize at the temperature of
its surroundings.

- 12 -
Listening to Tape
The DC-D2700 has 2 cassette decks; Deck I and Deck II.
Deck I can be used for playback, while Deck II can be
used for recording and playback.
Tape Operation Buttons (PLAYBACK I, REC/PLAY II)
∏:Play Button
:Rewind Button
Ò:Fast Forward Button
STOP/EJECT Button
PAUSE Button
º:Record Button (REC/PLAY II only)
ªLoading a Cassette
1. Press STOP/EJECT on Deck I or Deck II to open the
corresponding cassette holder.
2. Insert a cassette tape with the open surface facing
downward.
3. Close the cassette holder gently.
Never force the holder to close it.
ªBasic Playback
You can choose either Deck I or Deck II for playback as
you like.
1. Set FUNCTION to TAPE position.
2. Load a cassette tape in Deck I or II.
3. Press PLAY (Á).
The playback starts.
To stop playback:
Press STOP/EJECT.
To pause playback:
Press PAUSE.
Pressing PAUSE again resumes playback.
ªContinuous Playback
You can enjoy continuous playback of Deck I and II.
1. Set FUNCTION to TAPE position.
2. Load cassette tapes in Deck I and II.
3. Press PLAY (Á) of Deck I.
The playback starts.
4. Press PAUSE and PLAY (Á) of the Deck II.
When Deck I stops, Deck II will start playback.
Notes:
…The continuous playback can be done only from Deck
I to Deck II.
…When Deck II stops, the continuous playback ends.
Deck #Deck %
Deck # Transport
Control Buttons
Deck % Transport
Control Buttons

ªRecording (Deck II only)
ªRecording from Radio
1. Set FUNCTION to RADIO position.
2. Select the desired radio station.
3. Load a cassette tape in Deck II.
4. Press RECORD (º) to start recording.
5. Press STOP/EJECT to stop recording.
Note:
Sometimes when recording the radio program, you
may hear a whistling noise due to interference between
the radio signal and the built-in AC bias circuitry of the
recorder. If this happens, try to change the BEAT CUT
selector from 1 to 2 or vice versa, which alters the
recording bias frequency and may reduce such interfer-
ence.
ªRecording from a Record (Analog Disc)
1. Set FUNCTION to PHONO position.
2. Set a desired record (analog disc).
3. Load a cassette tape in Deck II.
4. Start playback of the record, then pressing RECORD
(º) to start recording.
5. Press STOP/EJECT to stop recording.
ªRecording from a CD
1. Set FUNCTION to CD position.
2. Set a desired CD.
3. Load a cassette tape in Deck II.
4. Press RECORD (º) of Deck II, then press PLAY/PAUSE
(Áπ) of CD player.
Deck II will start recording the CD.
5. Press STOP/EJECT of Deck II to stop recording.
- 13 -
ªDubbing
(Tape copy from Deck I to Deck II)
The DC-D2700 can duplicate a cassette tape at normal
or high speed.
1. Load the pre-recorded cassette intoTAPE I and a
recordable cassette intoTAPE II.
2. Fully rewind both cassettes so their tapes are taken
up on their left reels.
3. Set FUNCTION to TAPE position.
4. Choose the DUBBING SPEED selector from NORMAL
and HIGH.
5. Press PLAY (Á) of Deck I and RECORD (º) of Deck II
simultaneously.
Dubbing will start.
To stop dubbing:
Press STOP/EJECT on both decks.
CAUTION:
Recording pre-recorded tapes, records, or other pub-
lished or broadcast material may infringe copyright
laws. Check before recording.

- 14 -
Listening to Record
You can enjoy records (analog discs) by the DC-D2700.
1. Set FUNCTION to PHONO position.
2. Open the record player's cover.
3. Release the tonearm clamp and open the needle
guard.
4. Place a record on the platter cover the central
spindle.
*Place the EP adaptor over the central spindle when
playing 7" (17 cm) EP records.
5. Set the Speed selector to the appropriate speed; 33
or 45 rpm.
6. Lift the tonearm, move it to the first track of the
record.
The turntable starts rotating.
7. Place the needle gently on the record.
Playback starts.
8. At the end of the record, the turntable will automati-
cally stop. Lift the tonearm back to the tonearm
clamp and remove the record.
To stop playback on the way:
Lift the tonearm from the record and return it to the
clamp.
Notes:
…Do not turn or attempt to stop the platter by hand.
…Moving the unit without securing the tonearm may
damage the needle.
Tonearm
7" EP Record
adaptor
Speed Select
switch
Tonearm Rest /
Clamp
Headshell
Center Spindle
Turntable Platter
[AMPLIFIER Section]
Output Power: 5 W + 5 W (U.S.A./Canada)
Frequency Response: 60 to 30,000 Hz
[TUNER Section]
FM Section
Frequency Range: 87.50 to 108.00 MHz
AM Section
Frequency Range: 530 to 1710 kHz
(U.S.A./Canada)
[CD PLAYER Section]
Frequency Response: 20 to 20,000 Hz ±3 dB
Signal to Noise Ratio: 65 dB (IEC-A)
[CASSETTE DECK Section]
Tr a c k System: 4 tracks, 2 channel stereo
Tape Speed: 4.8 cm/sec.
Wow and Flutter: 0.4 % (WRMS)
Frequency Response: 125 to 6,300 Hz - 6 dB
[SPEAKER SYSTEM Section]
Type: 2-way
Impedance: 4 ohms
Input Power: Max. 10 W, Nominal 5 W
[GENERAL]
Power Requirements: 120 V AC, 60 Hz
(U.S.A./Canada)
Power Consumption: 30 W
Dimensions (W x H x D): 350 x 430 x 355 mm
Weight (net): 8.5 kg
Standard Accessories:
Remote Control Unit (RC-669) x 1
Owner's Manual x 1
Warranty Card x 1
Specifications

- 15 -
Troubleshooting Guide
Before calling for service, check through the chart below for probable causes of the problems you experience while
using this unit.
Caution:
Since the unit incorporates a microcomputer, it may not operate correctly because of external noise, etc. If this hap-
pens, turn the power switch OFF and disconnect the power cord, then reconnect the power cord, turn it ON again and
restart operations.
Symptom Probable cause(s) Suggested remedy
Low hum or buzz sound. Power line of fluorescent lamps Place this unit as far away from other
is run from the same power electric or electronic devices as possible.
outlet as that of this unit.
No sound from one Speakers are connected wrong. After checking speaker line, connect
speaker. correctly again.
No sound is heard. Volume is set to "minimum". Adjust the volume properly.
RECORD button cannot Erase-prevention tab is Cover the slot with adhesive tape.
be pressed. removed.
Low volume or weak sound Head is dirty. Clean the head.
with mute intervals Pinch roller or capstan is dirty. Refer to "MAINTENANCE" on page 5.
Playing is not possible. …Disc is inserted upside down. …Insert disc with label side up.
…Disc is dirty. …Clean the disc with soft tissue.
…PAUSE button is pressed. …Press play button to release pause.
…Incompatibly-sized disc is …Use compatibly-sized disc.
inserted.
…Lens has dew on it or is wet … Press POWER button and start playing
with moisture. after 20 to 30 minutes.
Poor playing at a particular …Disc is dirty. …Clean the disc with soft cloth.
part. …Disc is scratched. …Scratched part cannot be played.
(Be careful to maintain disc.)
Sound is distorted. …Needle is dirty. …Clean the needle with a soft brush.
…Record is dirty. …Clean the record with soft cloth.
NO SOUND
CASSETTE
TAPE
COMPACT DISC PLAYER
RECORD
PLAYER

TEAC CORPORATION 3-7-3, Nakacho, Musashino-shi, Tokyo 180, Japan Phone: [phone]
TEAC AMERICA, INC. 7733 Telegraph Road, Montebello, California 90640 Phone: [phone]
TEAC CANADA LTD. 5939 Wallace Street, Mississauga, Ontario L4Z 1Z8, Canada Phone: [phone] Facsimile: 905-890-9888
TEAC MEXICO, S.A. De C.V Privada De Corina, No.18, Colonia Del Carmen Coyoacon, Mexico DF 04100 Phone: [phone]
TEAC UK LIMITED 5 Marlin House, Marlins Meadow, The Croxley Centre, Watford, Herts. WD1 8YA, U.K. Phone: [phone]
TEAC DEUTSCHLAND GmbH Bahnstrasse 12, 65205 Wiesbaden-Erbenheim, Germany Phone: [phone]
TEAC FRANCE S. A. 17 Rue Alexis-de-Tocqueville, CE 005 92182 Antony Cedex, France Phone: [phone]
TEAC BELGIUM NV/SA P.A. TEAC Nederland BV, Perkinsbaan 11a, 3439 ND Nieuwegein, Netherlands Phone: [phone]
TEAC NEDERLAND BV Perkinsbaan 11a, 3439 ND Nieuwegein, Netherlands Phone: [phone]
TEAC AUSTRALIA PTY., LTD. 106 Bay Street, Port Melbourne, Victoria 3207, Australia Phone: [phone]
A.C.N. 005 408 462
TEAC ITALIANA S.p.A. Via C. Cantù 5, 20092 Cinisello Balsamo, Milano, Italy Phone: [phone]
0198U.MA-0123A
TO THE USER
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15
of the FCC Rules. These limits are designed to provide reasonable protection against interference in a residential
area. This device generates and uses radio frequency energy and if not installed and used in accordance with the
instructions, it may cause interference to radio or TV reception. If this unit does cause interference with TV or radio
reception you can try to correct the interference by one or more of the following measures:
a) Reorient or relocate the receiving antenna.
b) Increase the separation between the equipment and the receiver.
c) Plug the equipment into a different outlet so that it is not on the same circuit as the receiver.
If necessary, consult the dealer or an experienced radio/TV technician for additional suggestions.
CAUTION:
Changes or modifications to this equipment not expressly approved by TEAC CORPORATION for compliance could
void the user's authority to operate this equipment.
For U.S.A.
AC POWER CORD CONNECTION
CAUTION:
TO PREVENT ELECTRIC SHOCK, MATCH WIDE
BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.
CORDE DE CONNEXION CA
ATTENTION:
POUR ÉVITER LES CHOCS ÉLECTRIQUES, INTRO-
DUIRE LA LAME LA PLUS LARGE DE LA FICHE
DANS LA BORNE CORRESPONDANTE DE LA PRISE
ET POUSSER JUSQU'AU FOND.
For CANADA
