Teac MC-DX22i User manual

9A10509100
Z
Micro Hi-Fi System
OWNER’S MANUAL
MANUEL DU PROPRIÉTAIRE
MANUAL DEL USUARIO
MC-DX22i
ENGLISH FRANÇAIS ESPAÑOL
Includes adapters for:
iPod nano
iPod with video
iPod mini
iPod with Click Wheel
iPod with color display
Adapters sold separately:
iPod with dock connector
Comprend des adaptateurs pour:
iPod nano
iPod avec vidéo
iPod mini
iPod avec molette sensitive Click Wheel
iPod avec écran couleur
Adaptateurs vendus séparément:
iPod avec connecteur pour dock
Incluye adaptadores para:
iPod nano
iPod con vídeo
iPod mini
iPod con rueda de clic
iPod con pantalla en color
Adaptadores no incluidos:
iPod con conector para base

2
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK). NO USER-
SERVICEABLE PARTS INSIDE. REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL.
The lightning flash with arrowhead symbol, within an
equilateral triangle, is intended to alert the user to the
presence of uninsulated “dangerous voltage” within the
product’s enclosure that may be of sufficient magnitude
to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in the
literature accompanying the appliance.
IMPORTANT SAFETY INSTRUCTIONS
CAUTION
• Read all of these Instructions.
• Save these Instructions for later use.
• Follow all Warnings and Instructions marked on the audio equipment.
1) Read Instructions — All the safety and operating instructions should
be read before the product is operated.
2) Retain Instructions — The safety and operating instructions should
be retained for future reference.
3) Heed Warnings — All warnings on the product and in the operating
instructions should be adhered to.
4) Follow Instructions — All operating and use instructions should be
followed.
5) Cleaning — Unplug this product from the wall outlet before cleaning.
Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for
cleaning.
6) Attachments — Do not use attachments not recommended by the
product manufacturer as they may cause hazards.
7) Water and Moisture — Do not use this product near water — for
example, near a bath tub, wash bowl, kitchen sink, or laundry tub; in a
wet basement; or near a swimming pool; and the like.
8) Accessories — Do not place this product on an unstable cart, stand,
tripod, bracket, or table. The product may fall, causing serious injury to a
child or adult, and serious damage to the product. Use only with a cart,
stand, tripod, bracket, or table recommended by the manufacturer, or
sold with the product. Any mounting of the product should follow the
manufacturer’s instructions, and should use a mounting
accessory recommended by the manufacturer.
9) A product and cart combination should be moved with
care. Quick stops, excessive force, and uneven surfaces
may cause the product and cart combination to overturn.
10) Ventilation — Slots and openings in the cabinet are provided for
ventilation and to ensure reliable operation of the product and to protect
it from overheating, and these openings must not be blocked or covered.
The openings should never be blocked by placing the product on a bed,
sofa, rug, or other similar surface. This product should not be placed in a
built-in installation such as a bookcase or rack unless proper ventilation is
provided or the manufacturer’s instructions have been adhered to.
11) Power Sources — This product should be operated only from the
type of power source indicated on the marking label. If you are not sure
of the type of power supply to your home, consult your product dealer or
local power company. For products intended to operate from battery
power, or other sources, refer to the operating instructions.
12) Grounding or Polarization — This product may be equipped with a
polarized alternating-current line plug (a plug having one blade wider
than the other). This plug will fit into the power outlet only one way. This
is a safety feature. If you are unable to insert the plug fully into the outlet,
try reversing the plug. If the plug should still fail to fit, contact your
electrician to replace your obsolete outlet. Do not defeat the safety
purpose of the polarized plug.
13) Power-Cord Protection — Power-supply cords should be routed so
that they are not likely to be walked on or pinched by items placed upon
or against them, paying particular attention to cords at plugs,
convenience receptacles, and the point where they exit from the product.
14) Outdoor Antenna Grounding — If an outside antenna or cable
system is connected to the product, be sure the antenna or cable system
is grounded so as to provide some protection against voltage surges and
built-up static charges. Article 810 of the National Electrical Code,
ANSI/NFPA 70, provides information with regard to proper grounding of
the mast and supporting structure, grounding of the lead-in wire to an
antenna discharge unit, size of grounding conductors, location of
antenna-discharge unit, connection to grounding electrodes, and
requirements for the grounding electrode.
Note to CATV system installer:
This reminder is provided to call the CATV system installer’s attention to
Section 820-40 of the NEC which provides guidelines for proper
grounding and, in particular, specifies that the cable ground shall be
connected to the grounding system of the building, as close to the point
of cable entry as practical."
15) Lightning — For added protection for this product during a lightning
storm, or when it is left unattended and unused for long periods of time,
unplug it from the wall outlet and disconnect the antenna or cable
system. This will prevent damage to the product due to lightning and
power-line surges.
16) Power Lines — An outside antenna system should not be located in
the vicinity of overhead power lines or other electric light or power
circuits, or where it can fall into such power lines or circuits. When
installing an outside antenna system, extreme care should be taken to
keep from touching such power lines or circuits as contact with them
might be fatal.
17) Overloading — Do not overload wall outlets, extension cords, or
integral convenience receptacles as this can result in risk of fire or electric
shock.
18) Object and Liquid Entry — Never push objects of any kind into this
product through openings as they may touch dangerous voltage points or
short-out parts that could result in a fire or electric shock. Never spill
liquid of any kind on the product.
19) Servicing — Do not attempt to service this product yourself as
opening or removing covers may expose you to dangerous voltage or
other hazards. Refer all servicing to qualified service personnel.
20) Damage Requiring Service — Unplug this product from the wall
outlet and refer servicing to qualified service personnel under the
following conditions:
a ) when the power-supply cord or plug is damaged.
b ) if liquid has been spilled, or objects have fallen into the product.
c ) if the product has been exposed to rain or water.
d ) if the product does not operate normally by following the operating
instructions. Adjust only those controls that are covered by the operating
instructions as an improper adjustment of other controls may result in
damage and will often require extensive work by a qualified technician to
restore the product to its normal operation.
e ) if the product has been dropped or damaged in any way.
f ) when the product exhibits a distinct change in performance _ this
indicates a need for service.
21) Replacement Parts — When replacement parts are required, be
sure the service technician has used replacement parts specified by the
manufacturer or have the same characteristics as the original part.
Unauthorized substitutions may result in fire, electric shock, or other
hazards.
22) Safety Check — Upon completion of any service or repairs to this
product, ask the service technician to perform safety checks to determine
that the product is in proper operating condition.
23) Wall or Ceiling Mounting — The product should be mounted to a
wall or ceiling only as recommended by the manufacturer.
24) Heat — The product should be situated away from heat sources such
as radiators, heat registers, stoves, or other products (including
amplifiers) that produce heat.
ANTENNA
LEAD IN
WIRE
ANTENNA
DISCHARGE UNIT
(NEC SECTION 810-20)
GROUNDING CONDUCTORS
(NEC SECTION 810-21)
GROUND CLAMPS
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250. PART H)
NEC - NATIONAL ELECTRICAL CODE
ELECTRIC
SERVICE
EQUIPMENT
Example of Antenna Grounding
as per National Electrical
Code, ANSI/NFPA 70
GROUND
CLAMP

3
ENGLISH
CAUTION
<DO NOT REMOVE THE EXTERNAL CASES OR CABINETS TO
EXPOSE THE ELECTRONICS. NO USER SERVICEABLE PARTS
ARE WITHIN!
<IF YOU ARE EXPERIENCING PROBLEMS WITH THIS PRODUCT,
CONTACT TEAC FOR A SERVICE REFERRAL. DO NOT USE THE
PRODUCT UNTIL IT HAS BEEN REPAIRED.
<USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF
PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY
RESULT IN HAZARDOUS RADIATION EXPOSURE.
WARNING: TO PREVENT FIRE OR SHOCK
HAZARD, DO NOT EXPOSE THIS APPLIANCE
TO RAIN OR MOISTURE.
<Do not expose this apparatus to drips or splashes.
<Do not place any objects filled with liquids, such as vases, on
the apparatus.
<Do not install this apparatus in a confined space such as a
book case or similar unit.
<The apparatus draws nominal non-operating power from the
AC outlet with its POWER switch in the off position.
<The apparatus should be located close enough to the AC
outlet so that you can easily grasp the power cord plug at any
time.
<An apparatus with Class
! construction shall be connected to
an AC outlet with a protective grounding connection.
<Batteries (battery pack or batteries installed) shall not be
exposed to excessive heat such as sunshine, fire or the like.
This product has been designed and manufactured according to
FDA regulations “title 21, CFR, chapter 1, subchapter J, based on
the Radiation Control for Health and Safety Act of 1968“, and is
classified as class 1 laser product. There is not hazardous invisible
laser radiation during operation because invisible laser radiation
emitted inside of this product is completely confined in the
protective housings.
The label required in this regulation is shown ①.
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following
measures:
• Reorient or relocate the equipment and/or the receiving
antenna.
• Increase the separation between the equipment and
receiver.
• Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician
for help.
CAUTION
Changes or modifications to this equipments not expressly
approved by TEAC CORPORATION for compliance will void the
user’s warranty.
For U.S.A.
Optical pickup:
Type : SF-P200Z
Manufacturer : SANYO Electric Co., Ltd
Laser output : Less than 0.5 mW on the objective lens
Wavelength : 765 - 815 nm
For U.S.A.
①
Rear panel of the Subwoofer
AC POWER CORD CONNECTION
CAUTION:
TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG
TO WIDE SLOT, FULLY INSERT.
CORDE DE CONNEXION CA
ATTENTION:
POUR ÉVITER LES CHOCS ÉLECTRIQUES, INTRODUIRE LA LAME
LA PLUS LARGE DE LA FICHE DANS LA BORNE
CORRESPONDANTE DE LA PRISE ET POUSSER JUSQU’AU FOND.
For CANADA
Pour le CANADA

4
Before Using the Unit
Read this before operation
<As the unit may become warm during operation, always leave
sufficient space around the unit for ventilation.
The ventilation holes should not be covered. Make sure there
is at least 5 cm of space on each side of the unit. Do NOT
place anything on top of the unit.
<The voltage supplied to the unit should match the voltage as
printed on the rear panel. If you are in any doubt regarding
this matter, consult an electrician.
<Choose the installation location of your unit carefully. Avoid
placing it in direct sunlight or close to a source of heat. Avoid
locations subject to vibrations and excessive dust, heat, cold
or moisture.
<Do not place the unit on any other electronic components.
<Do not open the cabinet as this might result in damage to the
circuitry or electrical shock. If a foreign object should fall into
the unit, contact your dealer or service company as soon as
possible.
<When removing the power plug from a wall outlet, always
pull directly on the plug. Do not pull on the line cord.
<To keep the laser pickup clean, do not touch it and always
close the CD door after each use.
<Do not attempt to clean the unit with chemical solvents as
this might damage the finish. Use a clean, dry, lint-free cloth.
<Keep this manual in a safe place for future reference.
CAUTION: DO NOT MOVE THE UNIT DURING PLAYBACK
During playback, the disc rotates at high speeds. Do NOT lift
or move the unit during playback. Doing so may damage the
disc or the unit.
WHEN MOVING THIS UNIT
When changing places of installation or packing the unit for
moving, be sure to remove the disc. Moving this unit with the
disc loaded may result in malfunction or other damage.
NXT is a trademark of New Transducers Ltd.
Contents
Thank you for choosing TEAC. Read this manual carefully
to get the best performance from this unit.
Important Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Before Using the Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Discs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Connection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Wall Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Remote Control Unit. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Getting started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Unit Functions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Basic Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
iPod
Listening to iPod . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
CD/MP3
Listening to CD/MP3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Search Mode (MP3 only). . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Shuffle Playback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Programmed Playback. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Repeat Playback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
TUNER
Listening to the Radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Preset Tuning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
AUX
Listening to an External Source . . . . . . . . . . . . . . . . . . . . . . . . 25
Setting the Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Setting the Timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

5
ENGLISH
Discs
Discs which can be played on this unit:
• Conventional audio CDs bearing the COMPACT DISC
DIGITAL AUDIO logo on the label:
• Properly finalized CD-R and CD-RW discs
• MP3 CDs
Note:
<Depending on the quality of the disc and/or the condition of
the recording, some CD-R/CD-RW discs may not be playable.
<Copy-protected discs and other discs that do not conform to
the CD standard may not play back correctly in this player. If
you use such discs in this unit, TEAC Corporation and its
subsidiaries cannot be responsible for any consequences or
guarantee the quality of reproduction. If you experience
problems with such non-standard discs, you should contact
the producers of the disc.
MP3 compatibility
<File names of MP3 should be alphanumeric characters. This
unit cannot display symbols and full-size or 2 bytes-wide
characters (such as Japanese, Chinese, etc.) correctly. Also, be
sure to use the file extension “.mp3”.
<The disc must be finalized in order to play.
<The CD-ROM must be ISO 9660 compatible.
<When more than 200 files or 50 folders are recorded on the
disc, the unit might not be able to play it correctly.
<The file must be mono or stereo MPEG-1 Audio Layer 3
format, 44.1 or 48 kHz, fixed bit-rate.
How to remove the disc How to hold the disc
<Always place the disc on the disc tray with the label side up.
(Compact discs can be played or recorded only on one side.)
<To remove a disc from its storage case, press down on the
center of the case and lift the disc out, holding it carefully by
the edges.
<CD-R and CD-RW discs are more sensitive to the effects of
heat and ultraviolet rays than ordinary CDs. It is important
that they are not stored in a location with direct sunlight and
keep your discs away from sources of heat such as radiators
or heat-generating electrical devices.
<Printable discs aren’t recommended because the label side
might be sticky (or contain glue), which will damage the unit.
<Do not stick papers or protective sheets on the discs and do
not use any protective coating spray.
<Use a soft oil-based felt-tipped pen to write information on
the label side of a disc. Never use a ball-point or hard-tipped
pen, as this may cause damage to the recorded side of the
disc.
<Never use a stabilizer. Using commercially available CD
stabilizers with this unit will damage the mechanisms and
cause them to malfunction.
<Do not use irregular shape CDs (octagonal, heart shaped,
business card size, etc.). CDs of this sort can damage the unit:
<If you are in any doubt as to the care and handling of any
disc, read the precautions supplied with the disc, or contact
the disc manufacturer directly.
<Should the disc become dirty, wipe the surface from the
center hole outward towards the outer edge with a soft, dry,
lint-free cloth:
<Never use chemicals such as record (LP) sprays, antistatic
sprays or fluids, benzine or thinner to clean the discs. Such
chemicals will do irreparable damage to the disc’s plastic
surface.
<Discs should be returned to their cases after each use to avoid
dust and scratches that may eventually cause your disc to
skip.
<Do not expose discs to direct sunlight, high humidity, or high
temperatures for extended periods. Long exposure to high
temperatures will warp the disc.
<Do not play any disc that is warped, scratched, deformed or
damaged. Playing such discs may cause irreparable harm to
the playback mechanism.

6
Connection
CAUTION
<Turn off the power of all the equipment before making connections.
<Read instructions of each component you intend to use with this unit.
<Be sure to insert each plug securely. To prevent hum and noise, do not bundle the connection
cords with the power cord.
B
A
C
E
DD
F
Speaker (R) Speaker (L)
Side panel of the main unit
Subwoofer

7
ENGLISH
Subwoofer
Connect the “TO SUBWOOFER” and the “FROM MAIN”
sockets using the supplied cable.
<Connect the Connectors in the direction as figured.
C
AM loop antenna
Position the antenna for the best sound.
If you want, you can hook the AM antenna on a wall as
shown below:
FM antenna
While in FM mode, tune in an FM station and extend the
lead to find the best position for reception. This antenna
may need to be repositioned if you move your unit to a new
location.
FM Outdoor Antenna
In an area where FM signals are weak, it will be necessary to
use a 75-ohm unbalanced-type outdoor FM antenna using
an optional (not supplied) matching transformer connected
to an external antenna. Generally, a 3-element antenna will
be sufficient; if you live in an area where the FM signals are
particularly weak, it may be necessary to use one with 5 or
more elements.
B
A
Outdoor FM Antenna (75Ω)
SPEAKERS
Connect the left speaker’s plug to L, and the right speaker’s
plug to R.
<If not using the included speakers, make sure the speakers
you use are at least 4 Ωimpedance.
<Do not connect anything other than speakers to these
terminals.
AC Power Cord
Be sure to connect the power cord to an AC outlet which
supplies the correct voltage.
Hold the power plug when plugging or unplugging the
power cord. Never pull or yank on the power cord.
POWER switch of the Subwoofer
Use this switch to turn the system on or off.
<If the power switch of the subwoofer turned off, the
settings kept in memory (clock, preset stations, timer
setting) will be erased.
To avoid loosing your settings, it is advisable to keep this
switch ON when not in use.
AUX IN
You can connect a portable audio player to this jack.
Connect the LINE OUT or PHONES jack (audio output jack)
of the player using the supplied stereo mini plug cable.
When using the PHONES jack of your mini player, you must
adjust the volume of the mini-player or you may hear no
sound from your MC-DX22i.
G
The equipment draws a nominal amount of power from
the AC outlet even with its POWER switch in the OFF
position.
F
E
D

8
Wall Mounting
You can mount the left and right speakers on a wall.
Precautions
<Be aware that the length of the cables are approximately 3 m.
Do not attempt to mount the speakers too far from the
subwoofer.
<Drill holes into solid wall support, such as wooden frame or
concrete wall.
<TEAC supplies these brackets as a convenience to the product
owner. Consult your local building codes and exercise all
necessary caution when mounting these brackets. If you are
unsure how to use the supplied brackets, consult with a local
tradesmen or building supply expert.
To hook on the wall
1. Fix the brackets on the rear panel of the speakers using
the supplied short screws.
2. Use the supplied guide sheet to mark the exact drilling
points on the wall.
3. Drill holes in the wall at the marked points.
4. Screw the supplied long screws into the wall.
Leave about 5 mm space between the screw’s head and the
wall.
<As a convenience, a set of tapered plastic anchors is supplied.
If you chose to use these anchors, drill a pilot hole using a 6
mm drill bit then tap the anchor into the pilot hole.
Only use these anchors if they are appropriate for the
materials onto which the unit is to be mounted. Consult your
local hardware store if you are uncertain.
5.Before going on, connect the speakers and the
subwoofer using the supplied speaker cables (see page
6-7).
6. Carefully hang the speakers onto the screws.
Note:
Ensure that the speaker locks onto the hooks and that the
hooks are strong enough to support the weight before
removing your hands.
Remote Control Unit
Remove the battery compartment cover.
Put in the lithium battery (CR2032, 3V).
Close the cover.
Battery Replacement
If the distance required between the remote control unit and
main unit decreases, the battery is exhausted. In this case,
replace the battery with a new one.
Precautions concerning batteries
Do not heat or disassemble batteries and never dispose of old
batteries by throwing them in a fire.
3
2
1
The provided Remote Control Unit allows the unit to be operated
from a distance.
When operating the remote control unit, point it towards the
remote sensor on the front panel of the unit.
<Even if the remote control unit is operated within the effective
range, remote control operation may be impossible if there
are any obstacles between the unit and the remote control.
<If the remote control unit is operated near other products
which generate infrared rays, or if other remote control
devices using infrared rays are used near the unit, it may
operate incorrectly. Conversely, the other products may also
operate incorrectly.
Battery Installation
1
2
3

9
ENGLISH
The MC-DX22i comes mounted with an adapter for iPod with
color display (40GB, 60GB), “60GB (color) + Photo 40GB/60GB”.
To play your iPod through the MC-DX22i, you have first to check
if the factory mounted adapter fits your model of iPod. If it does
not, you have to replace it with a correct one, as explained
below.
1. Remove the adapter from the Dock of the MC-DX22i.
Hold the left and right sides of the adapter and gently pull it
up.
2. Choose the Dock adapter that fits your iPod mobile
digital device.
“Video 30GB” for iPod with video (30 GB).
“Video 60GB” for iPod with video (60 GB).
“nano” for iPod nano.
“mini” for iPod mini.
“20GB (color) + Photo 30GB” for iPod with color display
(20GB, 30GB, U2 Special Edition).
“60GB (color) + Photo 40GB/60GB” for iPod with color
display (40GB, 60GB).
“20GB + U2” for iPod with Click Wheel (20 GB, U2 Special
Edition).
“40GB” for iPod with Click Wheel (40 GB).
<Use a commercially available adapter to play iPod with dock
connector (with four buttons under the display).
<When you need to remove the adapter, hold the left and
right sides of the adapter and gently pull it up.
<When you don’t use the Dock, use the supplied cover for the
Dock to prevent dust from settling on the Dock.
3. Insert the adapter into the Dock of the MC-DX22i.
Fit the front edge of the adapter into the Dock, and then
press the back edge of the adapter onto the Dock until a
slight “click” is heard indicating the adapter is inserted
correctly.
Compatible iPod Software
In case your iPod will not work with the MC-DX22i or with the
remote control unit, software update may solve the problem.
Visit the Apple website and download the latest iPod Software.
http://www.apple.com/ipod/download/
iPod is a trademark of Apple Computer, Inc., registered in the
U.S. and other countries.
Getting started
1
2

10
Note:
To simplify explanations, instructions in this manual refer to
the names of the buttons and controls on the front panel
only. Associated controls on the remote control will also
operate similarly.
Unit Functions
G
J
K
Q
T
R
H
M
L
G
F
H
I
J
K
U
V
W
X
B
A
S
M
CBA D E
L
N
OP
EC
D

11
ENGLISH
SKIP (.//) / TUNING
In iPod or CD mode, momentarily press this button to skip
tracks. Hold down this button to search for a part of a track.
In TUNER mode, momentarily press this button to tune in
stations.
In Standby mode, these buttons are used to set or adjust the
clock and the timer.
PLAY/PAUSE (y/J)
In iPod or CD mode, use this button to start or pause
playback.
MP3
During playback of a MP3 disc, use this button to search track
name.
REPEAT
In iPod or CD mode, use this button to set the repeat
function.
SHUFFLE/FM MODE
In iPod or CD mode, use this button to turn on and off the
shuffle playback.
In FM TUNER mode, use this button to select STEREO or
MONO.
Display
STANDBY/ON
Use this button to turn the unit on or standby.
The main unit is powered via the subwoofer. You need to first
turn on the subwoofer.
When the main unit is in the standby mode, the power
indicator of the Subwoofer is orange.
When the unit is turned on, the indicator turns blue.
FUNCTION
Use this button to select a source (iPod, CD, TUNER or AUX).
OPEN/CLOSE
In CD mode, use this button to open and close the CD door.
FM/AM
Use this button to select AM or FM.
MEMORY/TIME SET
In CD mode, use this button to program tracks.
In TUNER mode, use this button to preset stations.
This button is also used for clock adjustment.
K
J
I
H
The equipment draws a nominal amount of power from the
AC outlet even with its STANDBY/ON switch in the
STANDBY position.
G
F
E
D
C
B
ASTOP (H)
In CD mode, use this button to stop playback.
<This button doesn’t work in iPod mode.
VOLUME
Press the up “+” or the down “–” button to adjust the
volume.
Dock connector
Before use, insert an appropriate Dock adapter in the Dock
(see page 9).
Insert an iPod mobile digital device into this dock.
CD door
Remote Sensor
When operating the remote control unit, point it towards
here.
PRESET/SCROLL
In TUNER mode, use these buttons to select a preset station.
In iPod mode, use these buttons to scroll up and down the
menu.
During playback of a MP3 disc, use these buttons to select a
folder in the disc.
MENU
This button is equivalent to the MENU button on your iPod.
In iPod mode, use this button to go back to the previous
menu.
TREBLE
Use this button and the VOLUME buttons to adjust the level
of high frequency sound range.
BASS
Use this button and the VOLUME buttons to adjust the level
of low frequency sound range.
SLEEP
Use this button to set sleep timer.
TIMER
Use this button together with the SKIP buttons to set the
timer.
SELECT
This button is equivalent to the Center button on your iPod.
In iPod mode, use this button to confirm selection in menus.
MUTING
Use this button to mute the sound.
X
W
V
U
T
S
R
Q
P
O
N
M
L

12
Basic Operation
Select a source by pressing the FUNCTION button.
3
Play the source and adjust the volume using the
VOLUME buttons.
4
Turn on the subwoofer.
1
Press the STANDBY/ON switch on the main unit.
2
2
3
1
4
(Rear panel of the subwoofer)
<To listen to an external source connected to the AUX IN jack,
select AUX.
<In iPod and AUX modes, the display always shows the clock.
<If you press and hold the TIME SET button for 2 seconds in
CD or TUNER mode, the clock will be displayed for a few
seconds.

13
ENGLISH
Muting
To mute the sound temporarily, press the MUTING button.
Press the MUTING button again to restore the sound.
<While muting is engaged, “MUTING” blinks on the display.
<If you change the volume during the muting, the muting will
be canceled.
Headphones
For private listening, first reduce the volume level to
minimum. Then insert the plug from your headphones into
the PHONES jack, and adjust the volume using the VOLUME
buttons. The sound from the speakers is cut off while the
headphone jack is inserted.
Sleep Timer
Repeatedly pressing the SLEEP button permits setting an
interval (from 90 down to 10 minutes) after which you want
the unit to automatically turn off and shift into Standby
mode.
Each press of the SLEEP button changes the time indication by
10 minutes.
90 80 10
………
CAUTION
Always lower the volume level prior to plugging in your
headphones. TO AVOID DAMAGING YOUR HEARING - Do
not place your headphones on your head until after you have
plugged them in.
Tone Control
1. Press the BASS or TREBLE button.
To adjust the level of low frequency sound range, press the
bass button.
To adjust the level of high frequency sound range, press the
treble button.
2. Within 5 seconds, press the VOLUME buttons to change
the setting.
The level can be adjusted from –4 to +4.
(off)

14
Listening to iPod
Select “iPod” using the FUNCTION button. If an iPod is
already docked, playback will start.
When no iPod is docked, the iPod indicator on the display
blinks.
In iPod mode, press the Play/Pause button (G/J) to start or
pause playback.
Insert the iPod into the Dock of the MC-DX22i.
Then press the Play/Pause button (y/J) on the iPod. The
MC-DX22i will automatically turn on and start playback
from the iPod’s music list.
<If the iPod that is in playback mode is inserted into the Dock,
the MC-DX22i will automatically turn on and start playback of
the iPod.
<Make sure to use an appropriate Dock adapter (see “Getting
started” on page 9).
<The battery of the iPod is recharged to the full whenever the
iPod is docked and the MC-DX22i is connected to the AC
power supply.
<When headphones are plugged into the iPod, sound comes
from both the speakers of the MC-DX22i and the
headphones.
<The Stop button (H) doesn’t work in iPod mode.
To select iPod mode
Press the Play/Pause button (G/J) during playback. Playback
stops at the current position. To resume playback, press the
Play/Pause button (G/J) again.
To skip to the next or a previous track
To suspend playback temporarily
(pause mode)
During playback, hold down the skip button (.or/) for
more than 2 seconds and release it when the part you want
to listen to is found.
During playback, press the skip button (.or/)
repeatedly until the desired track is found. The selected track
will be played from the beginning.
<When the .button is pressed during playback, the track
being played will be played from the beginning. To return to
the beginning of the previous track, press the .button
twice.
Search for a part of a track

15
ENGLISH
To activate the shuffle mode
During playback, press the SHUFFLE button to change the
shuffle mode.
Each time the SHUFFLE button is pressed, the SHUFFLE setting
of iPod is changed as follows:
If iPod is set to shuffle songs or albums, the Shuffle icon ( )
appears in the iPod’s display.
albumssongs off
Select the menu item
Press the PRESET/SCROLL buttons (‡/°) to scroll to the
menu item you want, and then press the SELECT button.
To activate the repeat mode
During playback, press the REPEAT button to change the
repeat mode.
Each time the REPEAT button is pressed, the REPEAT setting
of iPod is changed as follows:
If the iPod is set to repeat one song, the Repeat One icon ()
appears in the iPod’s display.
If the iPod is set to repeat all songs, the Repeat icon ( )
appears in the iPod’s display.
AllOne off
To go back to the previous menu
Press the MENU button to go back to the previous menu.
This button is equivalent to the MENU button on your iPod.

16
Listening to CD/MP3
1
42
35
Press the FUNCTION button to select “CD”.
1
Press the OPEN/CLOSE button.
2
Put a disc onto the center spindle of the player with the
label side facing you.
Press the disc onto the spindle until a slight “click” is heard
indicating the disc is mounted correctly.
3
<Never put more than one disc in the mechanism at a time.
<Ensure that the disc is correctly mounted on the spindle and
locked in place.
Press the OPEN/CLOSE button to close the CD door.
4
<It takes a few seconds for the unit to load the disc. No
buttons will work during loading. Wait until the total number
of the tracks and the total play time of the disc are displayed.
<When no disc is loaded in the CD player, “NO DISC” is
displayed.
When a CD is loaded
Playback starts from the first track of the disc.
<MP3 tracks recorded out of folders are automatically put in
the “ROOT” folder, and playback starts from the first track of
the ROOT folder.
<When the playback of all the tracks has finished, the unit
stops automatically.
When a MP3 disc is loaded
total playing timetotal tracks
total number
of folders
total tracks
Press the Play/Pause button (y/J) to start playback.
5
CD
MP3
elapsed time of current trackcurrent track number
current folder
number
elapsed time of current trackcurrent track number

17
ENGLISH
To suspend playback temporarily
(pause mode)
Press the Play/Pause button (G/J) during playback. Playback
stops at the current position. To resume playback, press the
Play/Pause button (G/J) again.
To stop playback
Press the Stop button (H) to stop playback.
To skip to the next or a previous track
During playback, press the skip button (.or/)
repeatedly until the desired track is found. The selected track
will be played from the beginning.
In the stop mode, press the skip button (.or/)
repeatedly until the track you want to listen to is found. Press
the Play/Pause button (G/J) to start playback from the
selected track.
<When the .button is pressed during playback, the track
being played will be played from the beginning. To return to
the beginning of the previous track, press the .button
twice.
<During programmed playback, the next or previous track in
the program is played.
Search for a part of a track
During playback, hold down the skip button (.or/) and
release it when the part you want to listen to is found.
Select a folder on the MP3 disc
Press the PRESET/SCROLL button to select a folder.
To display MP3 information
During playback of an MP3 disc, press the MP3 button for
more than 1 second. The information about the current track
is displayed as follows:
Filename wTitle wArtist wAlbum
<NONE appears when there is no information.
<UNKNOWN appears when the unit cannot read the
information.
Press the MP3 button for more than 1 second again to cancel
the MP3 information mode.

18
Search Mode (MP3 only)
Initial letter of track name
Track name
Search for a name of track
You can select the track by searching for its name.
Press the MP3 button once.
An alphabet (initial letter of a track name) and a track name
are displayed.
1
Press the PLAY/PAUSE button (G/J).
Playback starts from the selected track.
4
Track number
<To cancel the search mode, press the STOP button (H).
Select the initial letter of the track you want to listen to
by pressing the SKIP button (.or /).
2
Press and hold the SKIP button (.or /).
3
Then you can select the track that has same initial letter by
pressing the SKIP button (.or /).
MP3

19
ENGLISH
Search for a track in a folder
Press the MP3 button twice.
The name of folder is displayed.
<MP3 tracks recorded out of folders are in the “ROOT” folder.
Press the SKIP button (.or /) to find the folder
that the track you want to listen to is included.
Press and hold the SKIP button (.or /).
Then you can select the track in the folder by pressing the
SKIP button (.or /).
Press the PLAY/PAUSE button (G/J) to start playback.
Playback starts from the selected track.
<If you skip step , playback will start from the first track in
the selected folder.
3
4
3
2
1
Shuffle Playback
The tracks can be played randomly. Press the SHUFFLE button
during playback or when in the stop mode. “SHUFFLE” will
then light up in the display.
<If you press the /button during shuffle playback, next
track will be randomly selected and played.
If you press the .button, the currently played track will be
played from the beginning. If you press the .button twice
or more, next track will be randomly selected and played.
A track cannot be replayed during shuffle playback.
<Shuffle playback doesn’t work during programmed playback.
<If one of the following buttons is pressed, shuffle mode will
be cancelled:
SHUFFLE, STOP, FUNCTION, FM/AM
STANDBY/ON, OPEN/CLOSE

20
MEMORY
FUNCTION
Up to 64 tracks can be programmed in the desired order.
Press the FUNCTION button to select “CD”.
1
Press the MEMORY button.
2
“MEMORY” lights up in the display.
<To cancel the program mode, press the Stop button (H).
Press the Skip button (.or/) repeatedly to select a
folder of a MP3 disc, then press the MEMORY button.
<MP3 tracks recorded out of folders are in the “001” (ROOT)
folder.
<Skip this step when playing a CD.
3
The track is programmed, and “P-02” is displayed.
<Repeat steps and to program more tracks.
<You can program up to 64 tracks.
43
CD MP3
Programmed Playback
Press the Skip button (.or/) repeatedly to select a
track, then press the MEMORY button.
4
<When the playback of all the programmed tracks has finished,
or if you press the Stop button (H), the MEMORY indicator
will go off and the program mode will be cancelled. Still the
program is retained in memory.
You can return to the programmed playback by pressing the
MEMORY button and the Play/Pause button (G/J).
<Shuffle function doesn’t work during programmed playback.
MP3
CD MP3
When the selection of track numbers is completed,
press the Play/Pause button (G/J) to start program
playback.
5
