Teac CT-M6855S User manual

TEAC
SERVICE MANUAL
1. Caution……………………………………………………………2
2. Specification………………………………………………………6
3. BOM List ……………………… ………………… ……………9
4. Alignment Procedure………………………………………….…35
5. Block Diagram……………………………………………………39
6. Schematic Diagram………………………………………………40
7. PCB Layout………….……………………………………………41
8. Explode Diagram View………….………………………………42
This manual is the latest at the time of
p
rintin
g
, and does not
include the modification which ma
y
be made after the
p
rintin
g
, b
y
the constant improvement of product.
CT-M6855S

WARNING: TOREDUCE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT
EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
CAUTION: TO REDUCE THE RISK OF
ELECTRICAL SHOCK, DO NOT REMOVE
COVER (OR BACK). NO USER SERVICEABLE
PARTS INSIDE. REFER SER VICING TO
QUALIFIED SERVICE PERSONNEL.
The lighting flash with arrowhead symbol, with an equilateral triangle is intended to
alert the user to the presence of uninsulated voltage within the products
enclosure that may be of sufficient magnitude to constitute a risk of electric shock to
the person.
The exclamation point within an equilateral triangle is intended to alert the user to the
presence of important operating and maintenance (servicing) instructions in the
literature accompanying the appliance.
CAUTION:
Use of controls, adjustments or procedures other than those specified herein may result in
hazardous radiation exposure.
CAUTION
RISKRISK OFOF ELECTRIELECTRICC
SHOCKSHOCK DODO NOTNOT OPEN.OPEN.
2
dangerous

3
FOR YOUR PERSONAL SAFETY
1. When the power cord or plug is damaged or frayed, unplug this television set from the wall outlet and refer servicing to
qualified service personnel.
2. Do not overload wall outlets and extension cords as this can result in fire or electric shock.
3. Do not allow anything to rest on or roll over the power cord, and do not place the TV where power cord is subject to
traffic or abuse. This may result in a shock or fire hazard.
4. Do not attempt to service this television set yourself as opening or removing covers may expose you to dangerous
voltage or other hazards. Refer all servicing to qualified service personnel.
5. Never push objects of any kind into this television set through cabinet slots as they may touch dangerous voltage
points or short out parts that could result in a fire or electric shock. Never spill liquid of any kind on the television set.
6. If the television set has been dropped or the cabinet has been damaged, unplug this television set from the wall outlet
and refer servicing to qualified service personnel.
7. If liquid has been spilled into the television set, unplug this television set from the wall outlet and refer servicing to
qualified service personnel.
8. Do not subject your television set to impact of any kind. Be particularly careful not to damage the picture tube surface.
9. Unplug this television set from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a
damp cloth for cleaning.
10.1. Do not place this television set on an unstable cart, stand, or table. The television set may fall, causing serious injury
to a child or an adult, and serious damage to the appliance.Use only with a cart or stand recommended by the
manufacturer, or sold with the television set. Wall or shelf mounting should follow the manufacturer s instructions, and
should use a mounting kit approved by the manufacturer.
10.2. An appliance and cart combination should be moved with care. Quick stops, excessive force, and uneven surfaces
may cause the appliance and cart combination to overturn.
CAUTION:
Read all of these instructions. Save these instructions for later use.Follow all Warnings and
Instructions marked on the audio equipment.
1. Read Instructions- All the safety and operating instructions should be read before the product is operated.
2. Retain Instructions- The safety and operating instructions should be retained for future reference.
3. Heed Warnings- All warnings on the product and in the operating instructions should be adhered to.
4. Follow Instructions- All operating and use instructions should be followed.
IMPORTANT SAFETY INSTRUCTIONS

4
PROTECTION AND LOCATION OF YOUR SET
11. Do not use this television set near water ... for example, near a bathtub, washbowl, kitchen sink, or laundry tub, in a
wet basement, or near a swimming pool, etc.
Never expose the set to rain or water.If the set has been exposed to rain or water, unplug the set from the wall
outlet and refer servicing to qualified service personnel.
12. Choose a place where light (artificial or sunlight) does not shine directly on the screen.
13. Avoid dusty places, since piling up of dust inside TV chassis may cause failure of the set when high humidity persists.
14. The set has slots, or openings in the cabinet for ventilation purposes, to provide reliable operation of the receiver, to
protect it from overheating. These openings must not be blocked or covered.
Never cover the slots or openings with cloth or other material.
Never block the bottom ventilation slots of the set by placing it on a bed, sofa, rug, etc.
Never place the set near or over a radiator or heat register.
Never place the set in enclosure, unless proper ventilation is provided.
PROTECTION AND LOCATION OF YOUR SET
15.1. If an outside antenna is connected to the television set, be sure the antenna system is grounded so as to provide some
protection against voltage surges and built up static charges, Section 810 of the National Electrical Code, NFPA No.
70-1975, provides information with respect to proper grounding of the mast and supporting structure, grounding of the
lead-in wire to an antenna discharge unit, size of grounding conductors, location of antenna discharge unit, connection
to grounding electrode, and requirements for the grounding electrode.
15.2. Note to CATV system installer : (Only for the television set with CATV reception)
This reminder is provided to call the CATV system attention to Article 820-40 of the NEC that provides
guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding
system of the building, as close to the point of cable entry as practical.
16. An outside antenna system should not be located in the vicinity of overhead power lines or other electric lights or power
circuits, or where it can fall into such power lines or circuits.When installing an outside antenna system, extreme care
should be taken to keep from touching such power lines or circuits as contact with them might be fatal.
17. For added protection for this television set during a lightning storm, or when it is left unattended and unused for long
periods of time, unplug it from the wall outlet and disconnect the antenna. This will prevent damage due to lightning
and power-line surges.
ANTENNA
LEAD- IN WIRE
ANTENNA DISCHARGE
UNIT (NEC SECTION
810-20)
GROUNDING
CONDUCTORS
(NEC SECTION 810-21)
GROUND CLAMPS
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250. PART H)
ELECTRIC SERVICE
EQUIPMENT
GROUND CLAMP
NEC-NATIONAL ELECTRICAL CODE
EXAMPLE OF ANTENNA GROUNDING AS PER
NATIONAL ELECTRICAL CODE
EXAMPLE OF ANTENNA GROUNDING AS PER NATIONAL ELECTRICAL CODE INSTRUCTIONS
a built-in
installer s

OPERATION OF YOUR SET
18. This television set should be operated only from the type of power source indicated on the marking label. If you are not
sure of the type of power supply at your home, consult your television dealer or local power company. For television
sets designed to operate from battery power, refer to the operating instructions.
19. If the television set does not operate normally by following the operating instructions, unplug this television set from the
wall outlet and refer servicing to qualified service personnel. Adjust only those controls that are covered in the operating
instructions as improper adjustment of other controls may result in damage and will often require extensive work by a
qualified technician to restore the television set to normal operation.
20. When going on a holiday : If your television set is to remain unused for a period of time, for instance, when you go on
a holiday, turn the television set and unplug the television set from the wall outlet.
IF THE SET DOES NOT OPERATE PROPERLY
21. If you are unable to restore normal operation by following the detailed procedure in your operating instructions,
do not attempt any further adjustment. Unplug the set and call your dealer or service technician.
22. Whenever the television set is damaged or fails, or a distinct change in performance indicates a need for
service, unplug the set and have it checked by a professional service technician.
23. It is normal for some TV sets to make occasional snapping or popping sounds, particularly when being
turned on or off.If the snapping or popping is continuous or frequent, unplug the set and consult your
dealer or service technician.
FOR SERVICE AND MODIFICATION
24. Do not use attachments not recommended by the television set manufacturer as they may cause hazards.
25.When replacement parts are required, be sure the service technician has used replacement parts specified
by the manufacturer that have the same characteristics as the original part. Unauthorized substitutions
may result in fire, electric shock, or other hazards.
26. Upon completion of any service or repairs to the television set, ask the service technician to perform
routine safety checks to determine that the television is in safe operating condition.
5
off

Item No. Description Quantity Req. Designato
r
Remarks
08-29224E-CR1 ASS'Y - CRT BD 1
10-1N4148-ABX DIODE 1N4148 (SWITCHING) 1 D501
10-1N4148-ABX DIODE 1N4148 (SWITCHING) 1 D502
10-1N4148-ABX DIODE 1N4148 (SWITCHING) 1 L501("1" TO P501"1")
11-A562TM-0BX TRANSISTOR 2SA562TM-0 1 Q507
11-SC1815-YBX TRANSISTOR 2SC1815Y 1 Q502
11-SC1815-YBX TRANSISTOR 2SC1815Y 1 Q504
11-SC1815-YBX TRANSISTOR 2SC1815Y 1 Q506
11-SC4544-0AX TRANSISTOR 2SC4544 1 Q501
11-SC4544-0AX TRANSISTOR 2SC4544 1 Q503
11-SC4544-0AX TRANSISTOR 2SC4544 1 Q505
18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R515
18-CB0272-JNX RES. C.F. 2.7k OHM 1/6W +/-5% 1 R514
18-CB0561-JNX RES. C.F. 560 OHM 1/6W +/-5% 1 R501
18-CB0561-JNX RES. C.F. 560 OHM 1/6W +/-5% 1 R505
18-CB0561-JNX RES. C.F. 560 OHM 1/6W +/-5% 1 R510
18-CB0681-JNX RES. C.F. 680 OHM 1/6W +/-5% 1 R502
18-CB0681-JNX RES. C.F. 680 OHM 1/6W +/-5% 1 R506
18-CB0681-JNX RES. C.F. 680 OHM 1/6W +/-5% 1 R509
18-CB0681-JNX RES. C.F. 680 OHM 1/6W +/-5% 1 R522
18-CB0681-JNX RES. C.F. 680 OHM 1/6W +/-5% 1 R503
18-CB0681-JNX RES. C.F. 680 OHM 1/6W +/-5% 1 R508
18-CB0681-JNX RES. C.F. 680 OHM 1/6W +/-5% 1 R513
18-CB0681-JNX RES. C.F. 680 OHM 1/6W +/-5% 1 R511
18-FE0272-JNX RES. M.O. 2.7K OHM 1/2W +/-5% 1 R519
18-FE0272-JNX RES. M.O. 2.7K OHM 1/2W +/-5% 1 R520
18-FE0272-JNX RES. M.O. 2.7K OHM 1/2W +/-5% 1 R521
18-FG0183-JHX RES. M.O. 18K OHM 2W +/-5% 1 R516
18-FG0183-JHX RES. M.O. 18K OHM 2W +/-5% 1 R517
18-FG0183-JHX RES. M.O. 18K OHM 2W +/-5% 1 R518
25-BLA100-M1X CAP. ELEC 10 UF 250V +/-20% 1 C504
26-AMK102-KRX CAP. CER 1000 pF 2KV +/-10% R 1 C505
26-EBP103-ZFX CAP. CER 0.01UF 50V +80/-20% F 1 C508
26-EBP103-ZFX CAP. CER 0.01UF 50V +80/-20% F 1 C509
26-EBP391-JCX CAP. CER. 390PF 50V +/-5% CH 1 C502
26-EBP391-JCX CAP. CER. 390PF 50V +/-5% CH 1 C501
26-EBP471-JCX CAP. CER 470PF 50V +/-5% CH 1 C503
34-R100K2-1BX COIL CHOKE 10 UH +/-10% 1 L503
9

Item No. Description Quantity Req. Designato
r
Remarks
35-237250-00X FERR. BEAD HF70 4.5X5.0 2 FOR C508 (L505 & L506)
40-02501C-CRG P.C.B. CRT BD 1
41-WJ0050-B00 WIRE BARE JUMPER 5MM 1 L504
41-WJ0050-B00 WIRE BARE JUMPER 5MM 1 L502
41-WJ0060-B00 WIRE BARE JUMPER 6mm 1 R504
41-WJ0060-B00 WIRE BARE JUMPER 6mm 1 R507
41-WJ0060-B00 WIRE BARE JUMPER 6mm 1 R512
41-WJ0075-B00 WIRE BARE JUMPER 7.5MM 1 J503
46-10967W-01X PIN BASE *1 TJC1-1A 1 P501 FOR CRT GROUNDING HOUS.
46-30615H-04X HS 4P24 460 F/W TJC3-4Y/SCN-4 1 P502 FOR M.BD P421
46-37030H-05X HS 5P 2468#24 450 TJC3-5Y/SCN 1 P503 FOR M.BD P201
25-BCB471-M1X CAP. ELEC 470 UF 16V +/-20% 1 C506
47-265540-0U7 SOCKET CRT GZS10-2-4 (C.B.) 1 S501
08-2922XE-FB1 ASS'Y - FRONT CTL BD 1
18-CB0103-JNX RES. C.F. 10K OHM 1/6W +/-5% 1 R087
18-CB0103-JNX RES. C.F. 10K OHM 1/6W +/-5% 1 R081
18-CB0152-JNX RES. C.F. 1.5k OHM 1/6W +/-5% 1 R082
18-CB0182-JNX RES. C.F. 1.8K OHM 1/6W +/-5% 1 R083
18-CB0272-JNX RES. C.F. 2.7k OHM 1/6W +/-5% 1 R084
18-CB0432-JNX RES. C.F. 4.3K OHM 1/6W +/-5% 1 R085
18-CB0622-JNX RES. C.F. 6.2k OHM 1/6W +/-5% 1 R086
40-2922AE-KEA P.C.B. KEY BD 1
48-TAC026-XX0 TACT SWITCH KFC-A06A-12 1 S001
48-TAC026-XX0 TACT SWITCH KFC-A06A-12 1 S002
48-TAC026-XX0 TACT SWITCH KFC-A06A-12 1 S003
48-TAC026-XX0 TACT SWITCH KFC-A06A-12 1 S004
48-TAC026-XX0 TACT SWITCH KFC-A06A-12 1 S005
48-TAC026-XX0 TACT SWITCH KFC-A06A-12 1 S006
48-TAC026-XX0 TACT SWITCH KFC-A06A-12 1 S007
46-39161H-05X HS 5P 2468#24 400mm TJC3-5Y/JC25-5Y 1 P005
46-38570H-04X HS 4P 2468#24 200 TJC3-4Y/JC25-4Y 1 P005B
63-B30080-BT4 S/T SCREW B 3 X 8 BT 5 FOR CONTROL PCB TO F.CAB
08-29224E-FC1 ASS'Y - FRONT CABINET 1
02-GND029-XX0 ASS"Y-CRT GND WIRE & HOUS.(29) 1
42-61308F-GX2 SPEAKER 8 OHM 8W 613 1 SP601
42-61308F-GX2 SPEAKER 8 OHM 8W 613 1 SP602
44-29OFLW-TS4A CRT A68AGA20X99 1 CRT01
46-26514H-04X HS 4P A/B 500/13 RBGW TJC1-4Y 1 P411H
10

Item No. Description Quantity Req. Designato
r
Remarks
48-388070-XX0 DOOR LOCK 1
54-205140-000 SPACER CRT MOUNTING T=2MM 4 FOR CRT MTG.
54-314740-0X0 CRT FIBRE SHEET (22mmX22mmX0.8mm) 4 FOR CRT MTG.
55-2922FC-0UN FRONT CABINET 1
55-2922FD-0HA FRONT DOOR 1
56-2922LE-0HC LIGHT GUIDING POST 1
56-2922PK-0UA POWER KNOB 1
58-2922FI-1UI INLAY FRONT AV 1
62-10654X-00F UNI-TIE (2.5mmX95mm) 7
62-227680-0UA BRACKET ABS-KINGFA 606 (UO) 2
62-388060-0UA POWER CORD NIP 1
63-B30080-AB4 S/T SCREW B 3 X 8 AB 1 FOR WASHER TO AC LINE CORD CLIP MTG
63-H60300-AB4 S/T SCREW H 6 X 30 AB 4 FOR CRT MTG.
65-A60180-20E EXT. TOOTH WASHTER 6 X 18 X 2 4 FOR CRT MTG.
62-216780-00D PLATIC TAPE 12" 1
54-295210-0V0 FIBER WASHER 1 FOR NIP
63-W40150-AB4 S/T SCREW W 4 X 15 AB 8 FOR FIXING MAIN SPEAKER
67-X21679-0E0 SPRING CRT 6mmX50mmX0.6mm 2
67-X25045-0E0 SPRING KNOB 1 FOR POWER KNOB
36-DEG290-XX1 DEGAUSSING COIL 3100MM 1
46-27580H-02X HS 2P22 600/7 TJC3-2Y 1 P602H
46-27580H-02X HS 2P22 600/7 TJC3-2Y 1 P601H
54-113970-0U0 PVC TUBE #5 L=ROLL 0.32 FOR SPK CONNECTORS
08-2922XE-IR1 ASS'Y - RECEIVE BD 1
11-IRR001-1X0 IR RECEIVER MODULE HS0038A2 1 IR001
11-SA1015-YBX TRANSISTOR 2SA1015Y 1 Q081
14-LED05R-XX1 LED RED FB205 1 D080
18-CB0470-JNX RES. C.F. 47 OHM 1/6W +/-5% 1 R089
18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R090
40-2922AE-IRA P.C.B. IR RECEIVE BD 1
41-WJ0060-B00 WIRE BARE JUMPER 6mm 1 J083
41-WJ0075-B00 WIRE BARE JUMPER 7.5MM 1 J085
46-33079W-04X PIN BASE *4 TJC3-4A 1 P005A
62-388160-0HA LED BRACKET 1
62-388170-0HA BRACKET 1
63-B30100-BT4 S/T SCREW B 3 X 10 BT 2 FOR REMOTE CONTROL.PCB
25-BCB470-M1X CAP. ELEC 47 UF 16V +/-20% 1 C080
11-C124ES-0BX TRANSISTOR PDTC124ES (NPN) 1 Q082
11

Item No. Description Quantity Req. Designato
r
Remarks
18-CB0223-JNX RES. C.F. 22k OHM 1/6W +/-5% 1 R091
08-29224E-MA1 ASS'Y - MAIN BD 1
10-0BY228-F0X DIODE BY228 1 D411
10-0FR104-FBX DIODE FR104 (FAST RECTIFIER) 1 D412
10-0FR104-FBX DIODE FR104 (FAST RECTIFIER) 1 D421
10-0FR104-FBX DIODE FR104 (FAST RECTIFIER) 1 D441
10-0FR104-FBX DIODE FR104 (FAST RECTIFIER) 1 D431
10-1N4001-EBX DIODE 1N4001 (RECTIFIER) 1 D301
10-1N4148-ABX DIODE 1N4148 (SWITCHING) 1 D201
10-1N4148-ABX DIODE 1N4148 (SWITCHING) 1 D203
10-1N4148-ABX DIODE 1N4148 (SWITCHING) 1 D601
10-1N4148-ABX DIODE 1N4148 (SWITCHING) 1 D602
10-1N4148-ABX DIODE 1N4148 (SWITCHING) 1 D603
10-1N4148-ABX DIODE 1N4148 (SWITCHING) 1 D202
10-1N4148-ABX DIODE 1N4148 (SWITCHING) 1 D204
10-1N4148-ABX DIODE 1N4148 (SWITCHING) 1 D205
10-79C5V1-DBX DIODE ZENER 5V1 1/2W 5% 1 D001
10-79C8V2-DBX DIODE ZENER 8V2 1/2W 5% 1 D303
11-630MFP-0AX TRANSISTOR IRF630MFP 1 Q414
11-C124ES-0BX TRANSISTOR PDTC124ES (NPN) 1 Q602
11-SA1015-YBX TRANSISTOR 2SA1015Y 1 Q008
11-SA1015-YBX TRANSISTOR 2SA1015Y 1 Q215
11-SA1015-YBX TRANSISTOR 2SA1015Y 1 Q412
11-SA1015-YBX TRANSISTOR 2SA1015Y 1 Q413
11-SA1015-YBX TRANSISTOR 2SA1015Y 1 Q601
11-SA1015-YBX TRANSISTOR 2SA1015Y 1 Q912
11-SA1015-YBX TRANSISTOR 2SA1015Y 1 Q915
11-SA1015-YBX TRANSISTOR 2SA1015Y 1 Q916
11-SC1815-YBX TRANSISTOR 2SC1815Y 1 Q003
11-SC1815-YBX TRANSISTOR 2SC1815Y 1 Q007
11-SC1815-YBX TRANSISTOR 2SC1815Y 1 Q202
11-SC1815-YBX TRANSISTOR 2SC1815Y 1 Q204
11-SC1815-YBX TRANSISTOR 2SC1815Y 1 Q212
11-SC1815-YBX TRANSISTOR 2SC1815Y 1 Q451
11-SC1815-YBX TRANSISTOR 2SC1815Y 1 Q910
11-SC1815-YBX TRANSISTOR 2SC1815Y 1 Q911
11-SC1815-YBX TRANSISTOR 2SC1815Y 1 Q913
11-SC1815-YBX TRANSISTOR 2SC1815Y 1 Q914
12

Item No. Description Quantity Req. Designato
r
Remarks
11-SC1815-YBX TRANSISTOR 2SC1815Y 1 Q909
11-SC2482-0BX TRANSISTOR 2SC2482 1 Q401
11-SC3779-DBX TRANSISTOR 2SC3779D (RF AMPL) 1 Q101
11-SD2539-0AX TRANSISTOR 2SD2539 (HORIZ O/P) 1 Q411
13-000040-52P IC 4052 1 IC901
13-000040-52P IC 4052 1 IC902
13-00M24C-08P IC EEPROM 8K M24C08 1 IC001
13-0TDA81-72S IC TDA8172 1 IC301
13-NJW113-6LP IC NJW1136L 1 IC601
13-TDA894-4JS IC TDA8944J 1 IC602
18-CB0100-JNX RES. C.F. 10 OHM 1/6W +/-5% 1 R204
18-CB0101-JNX RES. C.F. 100 OHM 1/6W +/-5% 1 R213
18-CB0101-JNX RES. C.F. 100 OHM 1/6W +/-5% 1 R930
18-CB0101-JNX RES. C.F. 100 OHM 1/6W +/-5% 1 R203
18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R003
18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R004
18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R023
18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R031
18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R032
18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R106
18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R453
18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R904
18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R906
18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R910
18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R912
18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R923
18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R924
18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R925
18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R926
18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R931
18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R950
18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R950A
18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R951
18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R951A
18-CB0103-JNX RES. C.F. 10K OHM 1/6W +/-5% 1 R006
18-CB0103-JNX RES. C.F. 10K OHM 1/6W +/-5% 1 R025
18-CB0103-JNX RES. C.F. 10K OHM 1/6W +/-5% 1 R026
18-CB0103-JNX RES. C.F. 10K OHM 1/6W +/-5% 1 R033
13

Item No. Description Quantity Req. Designato
r
Remarks
18-CB0103-JNX RES. C.F. 10K OHM 1/6W +/-5% 1 R035
18-CB0103-JNX RES. C.F. 10K OHM 1/6W +/-5% 1 R043
18-CB0103-JNX RES. C.F. 10K OHM 1/6W +/-5% 1 R227
18-CB0103-JNX RES. C.F. 10K OHM 1/6W +/-5% 1 R246
18-CB0103-JNX RES. C.F. 10K OHM 1/6W +/-5% 1 R314
18-CB0103-JNX RES. C.F. 10K OHM 1/6W +/-5% 1 R607
18-CB0103-JNX RES. C.F. 10K OHM 1/6W +/-5% 1 R054
18-CB0103-JNX RES. C.F. 10K OHM 1/6W +/-5% 1 R224
18-CB0103-JNX RES. C.F. 10K OHM 1/6W +/-5% 1 R305
18-CB0104-JNX RES. C.F. 100K OHM 1/6W +/-5% 1 R034
18-CB0104-JNX RES. C.F. 100K OHM 1/6W +/-5% 1 R210
18-CB0104-JNX RES. C.F. 100K OHM 1/6W +/-5% 1 R619
18-CB0104-JNX RES. C.F. 100K OHM 1/6W +/-5% 1 R943
18-CB0104-JNX RES. C.F. 100K OHM 1/6W +/-5% 1 R235
18-CB0104-JNX RES. C.F. 100K OHM 1/6W +/-5% 1 R236
18-CB0104-JNX RES. C.F. 100K OHM 1/6W +/-5% 1 R907
18-CB0121-JNX RES. C.F. 120 OHM 1/6W +/-5% 1 R217
18-CB0123-JNX RES. C.F. 12k OHM 1/6W +/-5% 1 R937
18-CB0123-JNX RES. C.F. 12k OHM 1/6W +/-5% 1 R413
18-CB0151-JNX RES. C.F. 150 OHM 1/6W +/-5% 1 R102
18-CB0151-JNX RES. C.F. 150 OHM 1/6W +/-5% 1 R108
18-CB0151-JNX RES. C.F. 150 OHM 1/6W +/-5% 1 R228
18-CB0153-JNX RES. C.F. 15k OHM 1/6W +/-5% 1 R933
18-CB0153-JNX RES. C.F. 15k OHM 1/6W +/-5% 1 R009
18-CB0153-JNX RES. C.F. 15k OHM 1/6W +/-5% 1 R021
18-CB0183-JNX RES. C.F. 18k OHM 1/6W +/-5% 1 R432
18-CB0202-JNX RES. C.F. 2K OHM 1/6W +/-5% 1 R412
18-CB0220-JNX RES. C.F. 22 OHM 1/6W +/-5% 1 R027
18-CB0220-JNX RES. C.F. 22 OHM 1/6W +/-5% 1 R028
18-CB0221-JNX RES. C.F. 220 OHM 1/6W +/-5% 1 R401
18-CB0221-JNX RES. C.F. 220 OHM 1/6W +/-5% 1 R928
18-CB0221-JNX RES. C.F. 220 OHM 1/6W +/-5% 1 R929
18-CB0221-JNX RES. C.F. 220 OHM 1/6W +/-5% 1 R250
18-CB0222-JNX RES. C.F. 2.2k OHM 1/6W +/-5% 1 R615
18-CB0222-JNX RES. C.F. 2.2k OHM 1/6W +/-5% 1 R903
18-CB0222-JNX RES. C.F. 2.2k OHM 1/6W +/-5% 1 R909
18-CB0222-JNX RES. C.F. 2.2k OHM 1/6W +/-5% 1 R945
18-CB0222-JNX RES. C.F. 2.2k OHM 1/6W +/-5% 1 R946
14

Item No. Description Quantity Req. Designato
r
Remarks
18-CB0222-JNX RES. C.F. 2.2k OHM 1/6W +/-5% 1 R946A
18-CB0222-JNX RES. C.F. 2.2k OHM 1/6W +/-5% 1 R423
18-CB0222-JNX RES. C.F. 2.2k OHM 1/6W +/-5% 1 R417
18-CB0223-JNX RES. C.F. 22k OHM 1/6W +/-5% 1 R005
18-CB0223-JNX RES. C.F. 22k OHM 1/6W +/-5% 1 R022
18-CB0223-JNX RES. C.F. 22k OHM 1/6W +/-5% 1 R616
18-CB0223-JNX RES. C.F. 22k OHM 1/6W +/-5% 1 R905
18-CB0223-JNX RES. C.F. 22k OHM 1/6W +/-5% 1 R911
18-CB0223-JNX RES. C.F. 22k OHM 1/6W +/-5% 1 R913
18-CB0223-JNX RES. C.F. 22k OHM 1/6W +/-5% 1 R932
18-CB0223-JNX RES. C.F. 22k OHM 1/6W +/-5% 1 R938
18-CB0223-JNX RES. C.F. 22k OHM 1/6W +/-5% 1 R939
18-CB0223-JNX RES. C.F. 22k OHM 1/6W +/-5% 1 R942
18-CB0223-JNX RES. C.F. 22k OHM 1/6W +/-5% 1 R940
18-CB0223-JNX RES. C.F. 22k OHM 1/6W +/-5% 1 R941
18-CB0224-JNX RES. C.F. 220k OHM 1/6W +/-5% 1 R240
18-CB0271-JNX RES. C.F. 270 OHM 1/6W +/-5% 1 R243
18-CB0271-JNX RES. C.F. 270 OHM 1/6W +/-5% 1 R244
18-CB0271-JNX RES. C.F. 270 OHM 1/6W +/-5% 1 R245
18-CB0303-JNX RES. C.F. 30K OHM 1/6W +/-5% 1 R241
18-CB0331-JNX RES. C.F. 330 OHM 1/6W +/-5% 1 R201
18-CB0331-JNX RES. C.F. 330 OHM 1/6W +/-5% 1 R214
18-CB0331-JNX RES. C.F. 330 OHM 1/6W +/-5% 1 R608
18-CB0331-JNX RES. C.F. 330 OHM 1/6W +/-5% 1 R609
18-CB0332-JNX RES. C.F. 3.3k OHM 1/6W +/-5% 1 R212
18-CB0681-JNX RES. C.F. 680 OHM 1/6W +/-5% 1 R216
18-CB0332-JNX RES. C.F. 3.3k OHM 1/6W +/-5% 1 R253
18-CB0333-JNX RES. C.F. 33K OHM 1/6W +/-5% 1 R020
18-CB0333-JNX RES. C.F. 33K OHM 1/6W +/-5% 1 R306
18-CB0333-JNX RES. C.F. 33K OHM 1/6W +/-5% 1 R617
18-CB0333-JNX RES. C.F. 33K OHM 1/6W +/-5% 1 R225
18-CB0362-JNX RES. C.F. 3.6K OHM 1/6W +/-5% 1 R302
18-CB0392-JNX RES. C.F. 3.9K OHM 1/6W +/-5% 1 R007
18-CB0392-JNX RES. C.F. 3.9K OHM 1/6W +/-5% 1 R008
18-CB0392-JNX RES. C.F. 3.9K OHM 1/6W +/-5% 1 R203A
18-CB0392-JNX RES. C.F. 3.9K OHM 1/6W +/-5% 1 R303
18-CB0394-JNX RES. C.F. 390K OHM 1/6W +/-5% 1 R935
18-CB0470-JNX RES. C.F. 47 OHM 1/6W +/-5% 1 R024
15

Item No. Description Quantity Req. Designato
r
Remarks
18-CB0470-JNX RES. C.F. 47 OHM 1/6W +/-5% 1 R927
18-CB0471-JNX RES. C.F. 470 OHM 1/6W +/-5% 1 R036
18-CB0471-JNX RES. C.F. 470 OHM 1/6W +/-5% 1 R042
18-CB0471-JNX RES. C.F. 470 OHM 1/6W +/-5% 1 R044
18-CB0471-JNX RES. C.F. 470 OHM 1/6W +/-5% 1 R103
18-CB0471-JNX RES. C.F. 470 OHM 1/6W +/-5% 1 R211
18-CB0472-JNX RES. C.F. 4.7k OHM 1/6W +/-5% 1 R010
18-CB0472-JNX RES. C.F. 4.7k OHM 1/6W +/-5% 1 R315
18-CB0472-JNX RES. C.F. 4.7k OHM 1/6W +/-5% 1 R420
18-CB0472-JNX RES. C.F. 4.7k OHM 1/6W +/-5% 1 R416
18-CB0472-JNX RES. C.F. 4.7k OHM 1/6W +/-5% 1 R602
18-CB0472-JNX RES. C.F. 4.7k OHM 1/6W +/-5% 1 R612
18-CB0473-JNX RES. C.F. 47K OHM 1/6W +/-5% 1 R101
18-CB0473-JNX RES. C.F. 47K OHM 1/6W +/-5% 1 R226
18-CB0473-JNX RES. C.F. 47K OHM 1/6W +/-5% 1 R610
18-CB0473-JNX RES. C.F. 47K OHM 1/6W +/-5% 1 R219
18-CB0513-JNX RES. C.F. 51k OHM 1/6W +/-5% 1 R220
18-CB0560-JNX RES. C.F. 56 OHM 1/6W +/-5% 1 R107
18-CB0563-JNX RES. C.F. 56K OHM 1/6W +/-5% 1 R414
18-CB0681-JNX RES. C.F. 680 OHM 1/6W +/-5% 1 R934
18-CB0683-JNX RES. C.F. 68K OHM 1/6W +/-5% 1 R936
18-CB0683-JNX RES. C.F. 68K OHM 1/6W +/-5% 1 R418
18-CB0750-JNX RES. C.F. 75 OHM 1/6W +/-5% 1 R922
18-CB0820-JNX RES. C.F. 82 OHM 1/6W +/-5% 1 R902
18-CB0820-JNX RES. C.F. 82 OHM 1/6W +/-5% 1 R908
18-CB0222-JNX RES. C.F. 2.2k OHM 1/6W +/-5% 1 R307
18-CB0822-JNX RES. C.F. 8.2K OHM 1/6W +/-5% 1 R202
18-CB0822-JNX RES. C.F. 8.2K OHM 1/6W +/-5% 1 R256
18-CD0479-JNX RES. C.F. 4.7 OHM 1/4W +/-5% 1 R030
18-CD0829-JNX RES. C.F. 8.2 OHM 1/4W +/-5% 1 R620
18-CD0829-JNX RES. C.F. 8.2 OHM 1/4W +/-5% 1 R613
18-CE0109-JNX RES. C.F. 1 OHM 1/2W +/-5% 1 R304
18-CE0271-JNX RES. C.F. 270 OHM 1/2W +/-5% 1 R209
18-EG0109-JHX RES. FUS. 1 OHM 2W +/-5% 1 R301
18-EG0109-JHX RES. FUS. 1 OHM 2W +/-5% 1 R422
18-EG0109-JHX RES. FUS. 1 OHM 2W +/-5% 1 R431
18-EG0229-JHX RES. FUS. 2.2 OHM 2W +/-5% 1 R461
18-FE0121-JNX RES. M.O. 120 OHM 1/2W +/-5% 1 R310
16

Item No. Description Quantity Req. Designato
r
Remarks
18-FE0159-JNX RES. M.O. 1.5 OHM 1/2W +/-5% 1 R309
18-FE0472-JNX RES. M.O. 4.7K OHM 1/2W +/-5% 1 R316
18-FF0221-JGX RES. M.O. 220 OHM 1W +/-5% 1 R311
18-FF0242-JGX RES. M.O. 2.4K OHM 1W +/-5% 1 R402
18-FF0681-JGX RES. M.O. 680 OHM 1W +/-5% 1 R419
18-FG0103-JHX RES. M.O. 10K OHM 2W +/-5% 1 R421
18-FG0399-JHX RES. M.O. 3.9 OHM 2W +/-5% 1 R415
18-GM0302-KTX RES. CEMENT 3K OHM 7W +/-10% 1 R404
25-264610-M1X CAP. ELEC 4.7UF 50V +/-20% NP 1 C415
25-BJB479-M1X CAP. ELEC 4.7 UF 160V +/-20% 1 C401
25-BJG101-M1X CAP. ELEC 100 UF 160V +/-20% 1 C422
26-AIC332-KBX CAP. CER 3300 PF 500V +/-10% B 1 C402
26-AIC391-KBX CAP. CER 390 PF 500V +/-10% B 1 C403
26-EBP100-JCX CAP. CER 10PF 50V +/-5% CH 1 C303
26-EBP102-KBX CAP. CER 1000 PF 50V +/-10% B 1 C226
26-EBP102-KBX CAP. CER 1000 PF 50V +/-10% B 1 C109
26-EBP102-KBX CAP. CER 1000 PF 50V +/-10% B 1 C610
26-EBP102-KBX CAP. CER 1000 PF 50V +/-10% B 1 C651
26-EBP102-KBX CAP. CER 1000 PF 50V +/-10% B 1 C416
26-EBP103-ZFX CAP. CER 0.01UF 50V +80/-20% F 1 C007
26-EBP103-ZFX CAP. CER 0.01UF 50V +80/-20% F 1 C022
26-EBP103-ZFX CAP. CER 0.01UF 50V +80/-20% F 1 C029
26-EBP103-ZFX CAP. CER 0.01UF 50V +80/-20% F 1 C234
26-EBP103-ZFX CAP. CER 0.01UF 50V +80/-20% F 1 C238
26-EBP103-ZFX CAP. CER 0.01UF 50V +80/-20% F 1 C244
26-EBP103-ZFX CAP. CER 0.01UF 50V +80/-20% F 1 C250
26-EBP103-ZFX CAP. CER 0.01UF 50V +80/-20% F 1 C921
26-EBP103-ZFX CAP. CER 0.01UF 50V +80/-20% F 1 C931A
26-EBP103-ZFX CAP. CER 0.01UF 50V +80/-20% F 1 C922
26-EBP103-ZFX CAP. CER 0.01UF 50V +80/-20% F 1 C923
26-EBP103-ZFX CAP. CER 0.01UF 50V +80/-20% F 1 C034
26-EBP103-ZFX CAP. CER 0.01UF 50V +80/-20% F 1 C106
26-EBP103-ZFX CAP. CER 0.01UF 50V +80/-20% F 1 C107
26-EBP103-ZFX CAP. CER 0.01UF 50V +80/-20% F 1 C108
26-EBP103-ZFX CAP. CER 0.01UF 50V +80/-20% F 1 C214
26-EBP103-ZFX CAP. CER 0.01UF 50V +80/-20% F 1 C220
26-EBP103-ZFX CAP. CER 0.01UF 50V +80/-20% F 1 C225
26-EBP103-ZFX CAP. CER 0.01UF 50V +80/-20% F 1 C418
17

Item No. Description Quantity Req. Designato
r
Remarks
26-EBP103-ZFX CAP. CER 0.01UF 50V +80/-20% F 1 C913
26-EBP152-KBX CAP. CER 1500pF 50V +/-10% B 1 C002
26-EBP181-JCX CAP. CER 180PF 50V +/-5% CH 1 C919
26-EBP220-JCX CAP. CER 22PF 50V +/-5% CH 1 C252
26-EBP220-JCX CAP. CER 22PF 50V +/-5% CH 1 C023
26-EBP220-JCX CAP. CER 22PF 50V +/-5% CH 1 C024
26-EBP221-JCX CAP. CER 220PF 50V +/-5% CH 1 C006
26-EBP221-JCX CAP. CER 220PF 50V +/-5% CH 1 C009
26-EBP221-JCX CAP. CER 220PF 50V +/-5% CH 1 C027
26-EBP221-JCX CAP. CER 220PF 50V +/-5% CH 1 C030
26-EBP221-JCX CAP. CER 220PF 50V +/-5% CH 1 C035
26-EBP222-KBX CAP. CER 2200PF 50V +/-10% B 1 C217
26-EBP222-KBX CAP. CER 2200PF 50V +/-10% B 1 C231
26-EBP222-KBX CAP. CER 2200PF 50V +/-10% B 1 C306
26-EBP270-JCX CAP. CER 27PF 50V +/-5% CH 1 C008
26-EBP330-JCX CAP. CER 33PF 50V +/-5% CH 1 C916
26-EBP331-JCX CAP. CER 330PF 50V +/-5% CH 1 C020
26-EBP331-JCX CAP. CER 330PF 50V +/-5% CH 1 C042
26-EBP331-JCX CAP. CER 330PF 50V +/-5% CH 1 C043
26-EBP390-JCX CAP. CER 39PF 50V +/-5% CH 1 C031
26-EBP390-JCX CAP. CER 39PF 50V +/-5% CH 1 C032
27-ALQ432-J0X CAP. M.PP 4300 PF 1.6KV +/-5% 1 C411
27-ALQ562-J0X CAP. M.PP 5600 PF 1.6KV +/-5% 1 C414
27-ALQ762-J0X CAP. M.PP 7600 PF 1.6KV +/-5% 1 C412
27-MBC103-J0X CAP. M.P.E 0.01UF 63V+/-5% 1 C626
27-MBC103-J0X CAP. M.P.E 0.01UF 63V+/-5% 1 C628
27-MBC104-J0X CAP. M.P.E 0.1 UF 63V +/-5% 1 C625
27-MBC104-J0X CAP. M.P.E 0.1 UF 63V +/-5% 1 C633
27-MBC104-J0X CAP. M.P.E 0.1 UF 63V +/-5% 1 C102
27-MBC104-J0X CAP. M.P.E 0.1 UF 63V +/-5% 1 C251
27-MBC104-J0X CAP. M.P.E 0.1 UF 63V +/-5% 1 C602
27-MBC104-J0X CAP. M.P.E 0.1 UF 63V +/-5% 1 C603
27-MBC104-J0X CAP. M.P.E 0.1 UF 63V +/-5% 1 C605
27-MBC104-J0X CAP. M.P.E 0.1 UF 63V +/-5% 1 C652
27-MBC104-J0X CAP. M.P.E 0.1 UF 63V +/-5% 1 C253
27-MBC222-J0X CAP. M.P.E 0.0022UF 63V +/-5% 1 C653
27-MBC222-J0X CAP. M.P.E 0.0022UF 63V +/-5% 1 C604
27-MBC222-J0X CAP. M.P.E 0.0022UF 63V +/-5% 1 C654
18

Item No. Description Quantity Req. Designato
r
Remarks
27-MBC333-J0X CAP. M.P.E 0.033UF 63V +/-5% 1 C656
27-MBC334-J0X CAP. M.P.E 0.33UF 63V +/-5% 1 C608
27-MBC393-J0X CAP. M.P.E 0.039UF 63V +/-5% 1 C309
27-MBC473-J0X CAP. M.P.E 0.047 UF 63V +/-5% 1 C629
27-MBC473-J0X CAP. M.P.E 0.047 UF 63V +/-5% 1 C627
27-MBC473-J0X CAP. M.P.E 0.047 UF 63V +/-5% 1 C655
27-MCB272-J0X CAP. M.P.E 2700 PF 100V +/-5% 1 C311
27-PBC224-J0X CAP. P.E 0.22UF 63V +/-5% 1 C005
27-PBC224-J0X CAP. P.E 0.22UF 63V +/-5% 1 C305
27-PBC822-J0X CAP. P.E 0.0082UF 63V +/-5% 1 C247
27-RHQ223-J0X CAP. PP 0.022 UF 400V +/-5% 1 C413
27-RHQ563-J0X CAP. PP 0.056 UF 400V +/-5% 1 C451
34-A109K0-1IX COIL CHOKE 1 UH +/-10% 1 L102
34-R100J2-0EX COIL PL - 10 UH +/-5% 1 L002
34-R100J2-0EX COIL PL - 10 UH +/-5% 1 L208
34-R220J2-0EX COIL PL - 22 UH +/-5% 1 L202
34-R220J2-0EX COIL PL - 22 UH +/-5% 1 L206
34-R270J2-0EX COIL PL - 27 UH +/-5% 1 L207
34-R470J2-0EX COIL PL - 47 UH +/-5% 1 L101
34-R829J2-0EX COIL PL - 8.2 UH +/-5% 1 L204
36-HDR001-AX1 TRANSFOR HOR. DRIVE (MAGNETIC CORE) 1 T401
36-LIN180-XX1 COIL LINEARITY 18 UH 1 L414
36-WID601-XX1 COIL CHOKE 600 UH 1 L413
37-BSC290-1650X FLYBACK BSC29-0165 1 T461
41-WJ0065-B00 WIRE BARE JUMPER 6.5MM 1 D209
41-WJ0050-B00 WIRE BARE JUMPER 5MM 1 JP903
41-WJ0050-B00 WIRE BARE JUMPER 5MM 1 C215
41-WJ0050-B00 WIRE BARE JUMPER 5MM 1 J610
41-WJ0055-B00 WIRE BARE JUMPER 5.5 MM 1 J915
41-WJ0060-B00 WIRE BARE JUMPER 6mm 1 J004
41-WJ0060-B00 WIRE BARE JUMPER 6mm 1 J005
41-WJ0060-B00 WIRE BARE JUMPER 6mm 1 J218
41-WJ0060-B00 WIRE BARE JUMPER 6mm 1 J229
41-WJ0060-B00 WIRE BARE JUMPER 6mm 1 J301
41-WJ0060-B00 WIRE BARE JUMPER 6mm 1 J302
41-WJ0060-B00 WIRE BARE JUMPER 6mm 1 J306
41-WJ0060-B00 WIRE BARE JUMPER 6mm 1 J307
41-WJ0060-B00 WIRE BARE JUMPER 6mm 1 J614
19

Item No. Description Quantity Req. Designato
r
Remarks
41-WJ0060-B00 WIRE BARE JUMPER 6mm 1 J628
41-WJ0060-B00 WIRE BARE JUMPER 6mm 1 J909
41-WJ0060-B00 WIRE BARE JUMPER 6mm 1 J910
41-WJ0060-B00 WIRE BARE JUMPER 6mm 1 J911
41-WJ0060-B00 WIRE BARE JUMPER 6mm 1 J923
41-WJ0060-B00 WIRE BARE JUMPER 6mm 1 JP901
41-WJ0060-B00 WIRE BARE JUMPER 6mm 1 JP902
41-WJ0060-B00 WIRE BARE JUMPER 6mm 1 J419
41-WJ0065-B00 WIRE BARE JUMPER 6.5MM 1 J008
41-WJ0065-B00 WIRE BARE JUMPER 6.5MM 1 J023
41-WJ0065-B00 WIRE BARE JUMPER 6.5MM 1 J201
41-WJ0065-B00 WIRE BARE JUMPER 6.5MM 1 J202
41-WJ0065-B00 WIRE BARE JUMPER 6.5MM 1 J217
41-WJ0065-B00 WIRE BARE JUMPER 6.5MM 1 J602
41-WJ0065-B00 WIRE BARE JUMPER 6.5MM 1 J606
41-WJ0065-B00 WIRE BARE JUMPER 6.5MM 1 J305
41-WJ0065-B00 WIRE BARE JUMPER 6.5MM 1 JP904
41-WJ0065-B00 WIRE BARE JUMPER 6.5MM 1 D413
41-WJ0065-B00 WIRE BARE JUMPER 6.5MM 1 D414
41-WJ0070-B00 WIRE BARE JUMPER 7MM 1 J919
41-WJ0070-B00 WIRE BARE JUMPER 7MM 1 J922
41-WJ0070-B00 WIRE BARE JUMPER 7MM 1 J926
41-WJ0075-B00 WIRE BARE JUMPER 7.5MM 1 J208
41-WJ0075-B00 WIRE BARE JUMPER 7.5MM 1 J210
41-WJ0075-B00 WIRE BARE JUMPER 7.5MM 1 J221
41-WJ0075-B00 WIRE BARE JUMPER 7.5MM 1 J222
41-WJ0075-B00 WIRE BARE JUMPER 7.5MM 1 J308
41-WJ0075-B00 WIRE BARE JUMPER 7.5MM 1 J413
41-WJ0075-B00 WIRE BARE JUMPER 7.5MM 1 J623
41-WJ0075-B00 WIRE BARE JUMPER 7.5MM 1 J624
41-WJ0075-B00 WIRE BARE JUMPER 7.5MM 1 J917
41-WJ0080-B00 WIRE BARE JUMPER 8 MM 1 J006
41-WJ0080-B00 WIRE BARE JUMPER 8 MM 1 J603
41-WJ0080-B00 WIRE BARE JUMPER 8 MM 1 J604
41-WJ0085-B00 WIRE BARE JUMPER 8.5MM 1 J007
41-WJ0085-B00 WIRE BARE JUMPER 8.5MM 1 J025
41-WJ0085-B00 WIRE BARE JUMPER 8.5MM 1 J223
41-WJ0085-B00 WIRE BARE JUMPER 8.5MM 1 J414
20

Item No. Description Quantity Req. Designato
r
Remarks
41-WJ0085-B00 WIRE BARE JUMPER 8.5MM 1 J627
41-WJ0085-B00 WIRE BARE JUMPER 8.5MM 1 J902
41-WJ0085-B00 WIRE BARE JUMPER 8.5MM 1 J907
41-WJ0090-B00 WIRE BARE JUMPER 9MM 1 J024
41-WJ0090-B00 WIRE BARE JUMPER 9MM 1 J906
41-WJ0100-B00 WIRE BARE JUMPER 10MM 1 J021
41-WJ0100-B00 WIRE BARE JUMPER 10MM 1 J022
41-WJ0100-B00 WIRE BARE JUMPER 10MM 1 J403
41-WJ0100-B00 WIRE BARE JUMPER 10MM 1 J615
41-WJ0100-B00 WIRE BARE JUMPER 10MM 1 J818
41-WJ0100-B00 WIRE BARE JUMPER 10MM 1 J901
41-WJ0100-B00 WIRE BARE JUMPER 10MM 1 J912
41-WJ0100-B00 WIRE BARE JUMPER 10MM 1 J914
41-WJ0100-B00 WIRE BARE JUMPER 10MM 1 J916
41-WJ0100-B00 WIRE BARE JUMPER 10MM 1 J921
41-WJ0115-B00 WIRE BARE JUMPER 11.5MM 1 J607
41-WJ0105-B00 WIRE BARE JUMPER 10.5MM 1 J228
41-WJ0110-B00 WIRE BARE JUMPER 11MM 1 J001
41-WJ0110-B00 WIRE BARE JUMPER 11MM 1 J002
41-WJ0110-B00 WIRE BARE JUMPER 11MM 1 J003
41-WJ0110-B00 WIRE BARE JUMPER 11MM 1 J012
41-WJ0110-B00 WIRE BARE JUMPER 11MM 1 J918
41-WJ0125-B00 WIRE BARE JUMPER 12.5MM 1 J205
41-WJ0125-B00 WIRE BARE JUMPER 12.5MM 1 J206
41-WJ0125-B00 WIRE BARE JUMPER 12.5MM 1 J227
41-WJ0125-B00 WIRE BARE JUMPER 12.5MM 1 J929
41-WJ0125-B00 WIRE BARE JUMPER 12.5MM 1 J930
41-WJ0130-B00 WIRE BARE JUMPER 13MM 1 J220
41-WJ0140-B00 WIRE BARE JUMPER 14MM 1 J224
41-WJ0145-B00 WIRE BARE JUMPER 14.5MM 1 J904
41-WJ0150-B00 WIRE BARE JUMPER 15MM 1 J411
41-WJ0150-B00 WIRE BARE JUMPER 15MM 1 J420
41-WJ0150-B00 WIRE BARE JUMPER 15MM 1 J421
41-WJ0150-B00 WIRE BARE JUMPER 15MM 1 J920
41-WJ0150-B00 WIRE BARE JUMPER 15MM 1 L412
41-WJ0165-B00 WIRE BARE JUMPER 16.5MM 1 J225
41-WJ0165-B00 WIRE BARE JUMPER 16.5MM 1 J611
41-WJ0165-B00 WIRE BARE JUMPER 16.5MM 1 J612
21

Item No. Description Quantity Req. Designato
r
Remarks
41-WJ0175-B00 WIRE BARE JUMPER 17.5MM 1 J212
41-WJ0185-B00 WIRE BARE JUMPER 18.5MM 1 J016
41-WJ0185-B00 WIRE BARE JUMPER 18.5MM 1 J017
41-WJ0185-B00 WIRE BARE JUMPER 18.5MM 1 J226
41-WJ0185-B00 WIRE BARE JUMPER 18.5MM 1 J621
41-WJ0185-B00 WIRE BARE JUMPER 18.5MM 1 J626
41-WJ0190-B00 WIRE BARE JUMPER 19MM 1 J014
41-WJ0190-B00 WIRE BARE JUMPER 19MM 1 J015
41-WJ0190-B00 WIRE BARE JUMPER 19MM 1 J018
41-WJ0190-B00 WIRE BARE JUMPER 19MM 1 J908
41-WJ0195-B00 WIRE BARE JUMPER 19.5MM 1 J601
41-WJ0200-B00 WIRE BARE JUMPER 20MM 1 J013
41-WJ0200-B00 WIRE BARE JUMPER 20MM 1 J905
41-WJ0200-B00 WIRE BARE JUMPER 20MM 1 J913
45-OSC8M0-0Y0 CRYSTAL 8.0MHZ 1 X001
45-TRA5M5-0Y0 CER TRAP TPS 5.5MHZ 1 X203
46-20598W-04X PIN BASE *4 TJC1-4A 1 P411
46-33079W-02X PIN BASE *2 TJC3-2A 1 P601(L)
46-33079W-02X PIN BASE *2 TJC3-2A 1 P602(R)
46-33079W-03X PIN BASE *3 TJC3-3A 1 P002
46-33079W-04X PIN BASE *4 TJC3-4A 1 P421
46-33079W-05X PIN BASE *5 TJC3-5A 1 P001
46-33079W-05X PIN BASE *5 TJC3-5A 1 P201(P1 TO P5)
46-33079W-07X PIN BASE *7 TJC3-7A 1 P920
62-2922MB-0UN MAIN BD BRACKET 1
63-B30100-BT4 S/T SCREW B 3 X 10 BT 2 MTG M.BD & FBT
64-P30080-104 M/C SCREW P 3 X 8 1 FOR IC301
64-P30080-104 M/C SCREW P 3 X 8 1 FOR Q411
64-P30080-104 M/C SCREW P 3 X 8 1 FOR Q414
65-Z30050-23M NUT M 3 1 FOR IC301
65-Z30050-23M NUT M 3 1 FOR Q411
67-H27292-1A0 HEAT SINK 1 FOR Q414
67-H30147-0A0 HEAT SINK FOR HORIZ (2501/2909 1 FOR Q411
67-H34423-4A0 HEAT SINK 1 FOR IC602
25-BCA100-M1X CAP. ELEC 10 UF 16V +/-20% 1 C906
25-BCA100-M1X CAP. ELEC 10 UF 16V +/-20% 1 C911
25-BCA100-M1X CAP. ELEC 10 UF 16V +/-20% 1 C912
25-BCA100-M1X CAP. ELEC 10 UF 16V +/-20% 1 C917
22

Item No. Description Quantity Req. Designato
r
Remarks
25-BCA100-M1X CAP. ELEC 10 UF 16V +/-20% 1 C021
25-BCA100-M1X CAP. ELEC 10 UF 16V +/-20% 1 C033
25-BCA101-M1X CAP. ELEC 100 UF 16V +/-20% 1 C930
25-BCA101-M1X CAP. ELEC 100 UF 16V +/-20% 1 C930A
25-BCA101-M1X CAP. ELEC 100 UF 16V +/-20% 1 C028
25-BCA101-M1X CAP. ELEC 100 UF 16V +/-20% 1 C612
25-BCA101-M1X CAP. ELEC 100 UF 16V +/-20% 1 C210
25-BCA102-M1X CAP. ELEC 1000 UF 16V +/-20% 1 C245
25-BCA470-M1X CAP. ELEC 47 UF 16V +/-20% 1 C920
25-BCB100-M1X CAP. ELEC 10 UF 16V +/-20% 1 C228
25-BCB100-M1X CAP. ELEC 10 UF 16V +/-20% 1 C235
25-BCB221-M1X CAP. ELEC 220 UF 16V +/-20% 1 C910
25-BCB470-M1X CAP. ELEC 47 UF 16V +/-20% 1 C229
25-BCB470-M1X CAP. ELEC 47 UF 16V +/-20% 1 C631
25-BCB479-M1X CAP. ELEC 4.7 UF 16V +/-20% 1 C223
25-BCB479-M1X CAP. ELEC 4.7 UF 16V +/-20% 1 C304
25-BCB479-M1X CAP. ELEC 4.7 UF 16V +/-20% 1 C614
25-BCB479-M1X CAP. ELEC 4.7 UF 16V +/-20% 1 C615
25-BCB479-M1X CAP. ELEC 4.7 UF 16V +/-20% 1 C616
25-BCB479-M1X CAP. ELEC 4.7 UF 16V +/-20% 1 C617
25-BCB479-M1X CAP. ELEC 4.7 UF 16V +/-20% 1 C618
25-BCB479-M1X CAP. ELEC 4.7 UF 16V +/-20% 1 C619
25-BCB479-M1X CAP. ELEC 4.7 UF 16V +/-20% 1 C620
25-BEA221-M1X CAP. ELEC 220 UF 35V +/-20% 1 C302
25-BEA471-M1X CAP. ELEC 470 UF 35V +/-20% 1 C301
25-BEG222-M1X CAP. ELEC 2200 UF 35V +/-20% 1 C308
25-BFB101-M1X CAP. ELEC 100 UF 50V +/-20% 1 C224
25-BFB101-M1X CAP. ELEC 100 UF 50V +/-20% 1 C105
25-BFB101-M1X CAP. ELEC 100 UF 50V +/-20% 1 C237
25-BFB109-M1X CAP. ELEC 1 UF 50V +/-20% 1 C218
25-BFB109-M1X CAP. ELEC 1 UF 50V +/-20% 1 C221
25-BFB109-M1X CAP. ELEC 1 UF 50V +/-20% 1 C307
25-BFB228-M1X CAP. ELEC 0.22 UF 50V +/-20% 1 C216
25-BFB229-M1X CAP. ELEC 2.2 UF 50V +/-20% 1 C601
25-BFB229-M1X CAP. ELEC 2.2 UF 50V +/-20% 1 C607
25-BFB229-M1X CAP. ELEC 2.2 UF 50V +/-20% 1 C650
25-BFB229-M1X CAP. ELEC 2.2 UF 50V +/-20% 1 C657
25-BFB478-M1X CAP. ELEC 0.47 UF 50V +/-20% 1 C227
23
