Teac EU2890ST User manual

PR 106
11
22
33
44556677
88
99
1010
1111
1212
1313
1717
2121
1414
1818
2222
1515
1919
2323
1616
2020
2424
EU2890ST
COLOUR TELEVISION
IMPORTANT!
OWNER'S MANUAL
WARRANTY INFORMATION INSIDE. PLEASE READ
FOR INQUIRIES CALL
TEAC Total Care
1-800-656-700
www.teac.com.au

2

3
WARANTY REGISTRATION
Please read this warranty card.
Keep your purchase receipt to enable you to proceed quickly in the event of a
Warranty Service.
Warranty Terms & Conditions
1. TEAC warrants to the original retail purchaser only, that this product is free from defects in material and
workmanship under normal domestic use and authorises free service during the warranty period at any TEAC
Authorised Centre only. TEAC warranty only applies to products purchased, used and serviced in Australia.
2. Subject to the terms herein, this warranty effectively covers the equipment as specified in the Warranty
Periods Table from the date of purchase.
3. All parts, except the external cabinet, are warranted as specified in Warranty Periods Table, and will be
repaired or replaced at the sole judgement of TEAC.
4. Normal customer maintenance as described in the owner's manual is not covered by this warranty (such as
cleaning VCR heads etc.)
5. This warranty does not apply to equipment showing abuse, damage or that it may have been tampered with,
altered or repaired outside any TEAC Authorised Service Centre. If so, the warranty will be void.
*Your nearest Authorised TEAC Service Centre is listed in your Owners Manual
6. In the event that this unit or any defective parts must be returned to TEAC Service Centres, a copy of this
warranty certificate and of your purchase receipt must be enclosed to be a valid warranty. Such equipment
or parts must be sent to the nearest authorised TEAC Service Centre. After the repair, the unit will be
available for collection by the owner or it will be returned to the owner. The warranty does not cover freight
or insurance. In all cases of in-transit damages or loss, a claim must be filed against the carrier by the
purchaser.
7. In home service will only be provided as part of this warranty if all the following conditions are met;
a) The product is a Colour Television of 59cm screen size or over.
b) The product is within the warranty period.
c) The product is located within the normal service area of the local TEAC Service Provider.
In any other situation or circumstance, where an in home service call is made, a service fee will be charged by
the Service Provider. TEAC Total Care in home service and installation is available at competitive rates.
8. No one is authorised to assume any liability on behalf of TEAC or impose any obligation on it, in connection
with the sale of any equipment other than as stated in this warranty and outlined above.
9. In no event will TEAC be responsible or liable for indirect or consequential damages from interrupted
operations or other causes.
10. Warranty is not transferable to any subsequent purchaser if the product is sold during the warranty period,
TEAC PRODUCT
Televisions
Televisions - Widescreen 16x9
Televisions - 59 cm and above
Digital Set Top Boxes
VCR
DVD
Audio Systems
1 Year
3 Years (In-Home Service Included)
1 Year (In-Home Service Included)
1 Year
1 Year
1 Year
1 Year
WARRANTY PERIOD

4
WARANTY PROCEDURES
Keep this warranty information and your purchase receipt
Your proof of purchase (receipts) will enable fast and efficient service in the event of repair.
Please keep this information for your own records.
Please refer to the owner's manual to ensure that you have followed the correct installation and operating
procedures.
1. Read owner's manual carefully
2. If you require Warranty Service, please contact the TEAC Service Centre
3. Please have your purchase receipt as your proof of purchase and the following details
completed for a valid Warranty.
4. Please ensure that your product is packed appropriately upon return to the service centre.
If you have any other queries regarding service or warranty please contact the TEAC Service below:
TEAC Total Care Ph: 1800 656 700
[email protected]
www.teac.com.au
Owner's Name
Owner's Address
Model Name/No. Serial No.
Dealer's Name
Dealer's Address
Postcode
Postcode

5
•Power supply: • 230/50Hz
•Power consumption: • Stand-by: max. 0,5 W
• Normal operation: 95 W
•Connections: • 2 x Euro AV SCART input
• Antenna 75 Ohm
• Headphones
• Y, Cb, Cr - component input on SCART1
• Mini DIN (SVHS)
• 3xRCA (video and audio)
•Pisture tube: • Diagonal 70 cm - visible screen 66 cm
•Standard: • PAL BG
• NTSC (via SCART)
•Number of programmes: 100
•Displayed functions: OSD - On Screen Display
•Switch-off preset: 0 à 120 min.
•Automatic switch-off after the end of programme transmission
•Frequency synthesis
•Cable and hyperband channels: • VHF-1: 2 - 4
• VHF-3: 2 - 12
• UHF: 21 - 69
• S: S1 - S41
TECHNICAL SPECIFICATIONS................................................................................... 5
POSITIONING.......................................................................................................... 6
IMPORTANT WARNINGS - SAFETY RECOMMENDATIONS............................................. 6
CONNECTION.......................................................................................................... 6
INFRA-RED REMOTE CONTROL................................................................................. 7
CONTROL UNIT PANEL............................................................................................. 8
SWITCHING ON AND OFF......................................................................................... 9
SETTING TV PROGRAMMES...................................................................................... 10
ADJUST PICTURE AND SOUND................................................................................. 13
PICTURE FORMAT 16:9............................................................................................ 15
TELETEXT................................................................................................................16
DEMAGNETISATION OF THE PICTURE TUBE..............................................................18
TROUBLE SHOOTING............................................................................................... 18
TECHNICAL SPECIFICATIONS
CONTENTS:

6
SAFETY AND PRECAUTIONS
To ensure safe and reliable operation of the TV set, please observe the following precautions in installation,
operation and maintenance.
Attention:
1. Pay attention to the power supply cord before installing the TV set. Do not hang anything on the cord and avoid
treading on the cord.
2. The slots on the housing back are designed for ventilation to ensure reliable operation of the TV set and prevent
overheating. They must never be covered or blocked. The TV set must not be placed near a heat source or it
might be damaged.
3. The outdoor antenna must not be erected close to HV lines or other power supply lines. Use extreme care when
erecting the antenna and not to touch living wires or injury may occur.
4. This TV set can only use the supply voltage and frequency indicated on the back of the housing. If your power
supply does not comply with them, please consult with the service personnel.
5. Do not let any object fall into the ventilation opening of the TV set housing, not let any liquid flow into the
machine via the opening.
6. Do not subject the TV set rain or use it in a damp environment. Whwn cleaning dust, be sure to remove the
power supply plug from its socket first. Do not clean the housing with directly liquid detergent, p cloth. Be sure to
remove the power supply plug from its scocket and remove the antanna plug during a thunderstorm or when it
will not be used for long time to avoid components being damaged by lightning.
7. If you use an indoor antenna do not let it touch any electrical appliance or normal reception of TV programs may
be affected.
Safety:
1. Do not remove the back of housing by yourself, as high voltages inside the unit are dangerous. If it is necessary
to open the back, ask a technician with specialized service experience.
2. Remove the power supply plug from its socket in case of the following conditions and consult with service
personnel.
(1) The power cord or plug are damaged or shows crecking.
(2) Any object has fallen into or liquid flown into the TV set.
(3) The performance of TV set has deteriorated significantly or there is damage on the housing.
(4) The TV set will not operate normally according to the instructions.
3. Please remove the power supply plug from its socket when the TV set will not be used for a long period time.
CAUTION:
use of controls, adjustments or procedures other than those specified herein may result in hazardous radiation
exposure.
This appliance has a serial number on the rear
panel. please record the serial number and retain it
for records.
Serial Number:____________________________
WARNING: TO REDUCE THE RISK OF FIRE
OR ELECTRIC SHOCK, DO NOT
EXPOSE THIS APPLIANCE TO
RAIN OR MOISTURE.
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK. DO
NOT REMOVE COVER (OR BACK). NO USER SER
VICEABLE PARTS INSIDE. REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL.
CAUTION
RISK OF ELECTRIC
SHOCK DO NOT OPEN
The exciamation mark within an equileterai triangle is intended to alert the user to the presence
of important operating and maintenance (servicing) instructions in the literature accompanyiing
the appliance.
The lighting flash with arrowhead symbol, with an equileteral triangle is intended to aiert the
user to the presence of Uninsulated "dangerous voltage" Within the product's enclosure that
may be of sufficient magnitude tr constitute a risk of electric shock to the person.

7
ªON/OFF (Stand-by)
1-0 Programme selection /
Page selection (TT)
AV
MENU
PICT
SOUND
ÏMute (Sound off)
pMenu up/down
Programme+ / Page+ (TT)
tMenu up/down
Volume- / Analogue settings-
OK Confirmation key
uMenu up/down
Volume+ / Analogue settings+
qMenu up/down
Programme- / Page- (TT)
Red key
Green key
Yellow key
Blue key
†Teletext on / Mixed picture / Text off (TT)
i
STOP Stoppage of the subpages changing (TT)
¡ZOOM Picture format /
¢›Teletext-
£ˆ
¤N
¥éKey has no function
¦
þThe (TT) mark is for function in teletext mode
Switch over to AV mode
"MENU" menu on
"IMAGE" menu on
"SON Ç"menu on
/ Page- (TT)
/ Page+ (TT)
/ Page+10 (TT)
/ Page+100 (TT)
"INFO" menu on / Index page (TT)
Double height (TT)
Menu switch-TV, AV-TV, TV (TT)
Time display / Subpages on (TT)
Picture and sound normal /
Key ? (TT)
Battery compartment (on the rear side)
25
PR 106
11
22
33
44556677
88
99
1010
1111
1212
1313
1717
2121
1414
1818
2222
1515
1919
2323
1616
2020
2424
INFRA-RED REMOTE CONTROL
Insert two 1,5V batteries, type R6 (RL6) micro. We recommend using alkaline batteries. Be careful to
correctly insert the batteries into the battery compartment (observe the drawing on the compartment
bottom). Check the batteries every now and then to prevent the leakage of worn out batteries.
In order to assure perfect functioning, the remote control handset should be always pointing toward the
TV set. The flashing of the red signal light indicates, that the TV set is receiving the infra-red signals.!

8
!Signal light
"
#P
$
%V
&V
'Analogue select (Video and Audio)
(Mains switch
)Headphone socket (3,5 mm)
*Power suppply cord
+Aerial socket
,SCART 2 socket
-SCART 1 socket
.SVHS input connector
/VIDEO input connector
0AUDIO L input connector
1AUDIO R input connector
Stand-by indicator
Infrared receiver
rogramme- / Switching on the set
from stand-by mode
Programme+ / Switching on the set
from stand-by mode
olume- / Analogue functions-
olume+ / Analogue functions+
CONTROL UNIT PANEL
Using tke keys on the control unit which is located in the lower part on the front side of TV set, it is
possible to set all the important functions of it.
! " # $ % & ' (
*) +
0
.
1
/
, -

SWITCHING ON AND OFF
SWITCHING ON TO
STAND-BY MODE
Switch on the TV set to stand-by mode by
pressing the mains switch (. The red indicator
light !turns on.
SWITCHING ON FROM
STAND-BY MODE
When switching on, the red indicator turns
green.
The time between switching on and picture
appearing on the TV set is 4 to 8 seconds.
If your TV set is in stand-by mode, you can
switch it on with one of the following
procedures:
•press the key ªon the remote control,
•press the Pr- #or Pr+ $key on the control
unit,
•press any of the programme selection keys
1-0 on the remote control.
With the first two procedures the TV set will turn
on and the programme selected will be the
programme stored under 1. With the thirth
procedure, the TV set will turn on to programme
entered by pressing any of the numbers on the
keys 1-0 .
If the programme number has one digit, press
the key with adequate number (e.g. 2) and after
two seconds the displayed number disappears -
the programme displayed is the programme
under number 2.
If the programme number has two digits (e.g.
15), two keys (1 and 5) shall be pressed
consequently, the time elapsed between
pressing both numbers should not exceed 2
seconds - the programme displayed is the
programme under number 15.
If you select programme number which is not
stored, the "EMPTY" sign will be displayed.
In the AV mode (AV1, AV2 or SVHS) you can
switch on your TV set by pressing the AV key.
If AV signal is connected (socket 8 on SCART
connector), the TV set switches over to AV mode
automatically. This is for programmes received
via Euro-AV input (SCART) on the rear side of the
TV set.
To exit AV mode, simply press the key ݢ.
SWITCHING OFF TO
STAND-BY MODE
Switch the TV set from operation mode to stand-
by mode by pressing key ª. The green control
light turns red. The power consumption is
reduced to app. 0,5 W.
If there is no programme on the channel that
your TV set is set to, the TV set will turn off after
5 minutes.
You can also select and set other switch-off time
(see SPECIAL-SLEEP TIMER menu).
In all above stated examples the TV set turns off
to stand-by mode.
9
If you don't intend to watch TV for a longer period of time (e.g. over the night - switch it off
with the mains switch (!

SETTING TV PROGRAMMES
When switching on the TV set for the first time or
if you want to change programme settings, use
the MENU key and move to "MENU". From
this menu you can move to the following menu:
•INSTALLATION
•SPECIAL
•ZOOM (see page 12)
In "MENU" you can select between stated
menus with the pand qkeys. The
selected menu is always illuminated. To switch
on the selected menu use the tor ukeys.
Use the p, t, uand qkeys in the
same way in every menu.
MENU "INSTALLATION"
searching the flashing "..." sign is displayed near
the "AUTOSTORE". If you want to interrupt
searching, press key STOP on the remote
control.
When searching is finished, the TV channels
which were found are automatically sorted and
stored. For identified programmes their name is
displayed, while others are marked wit a letter P
and successive number. When finished, the TV
set returns to "INFO" menu. You can also return
to this menu at any time by interrupting the
automatic search.
To exit the "INFO" menu, press the key ݢ.
Return to "INSTALLATION" menu via
"MENU". In "INSTALLATION" menu the
channels can be manually searched. Use it if you
want to find a channel with very weak signal or
simply if you want to find another programme
without activating automatic search. Use the
por qkeys and illuminate selection
"PROGRAM NR". Use the use the tor u
keys and select the programme location, where
you want to store your programme.
Use the pand qkeys and illumunate
selection "CHANNEL". Channel can be set
using one of the following procedures. Use the
tor ukeys and select the previous or the
next channel or simply enter the number of the
channel. Use the OK key and move to the S
range or back.
If the signal of the selected channel is very weak
you can improve it as follows: use the pand
qkeys and illuminate the "FINE TUNING"
selection and set the optimum value with the
tand ukeys.
If you want to store modifications, move to the
"STORE" selection. Use the tor ukeys
and activate storing procedure. The "STORE"
sign in the menu flashes in red for a second.
To exit the "INSTALLATION" menu, press the
key ݢ.
INSTALLATION
AUTOSTORE >>
PROGRAM NR. 04
CHANNEL C12
FINE TUNE
STORE < >
This menu is used for searching, sorting and
storing of programmes.
Move to selection "AUTOSTORE" with keys
por q.
When "AUTOSTORE" is illuminated use the key
uto start automatic channel searching
through the entire frequency range VHS, UHF
and S. By pressing the same key once again, the
"AUTOSTORE" sign is displayed. Confirm
searching by pressing the key OK . During
10
MENU
INSTALLATION >
SPECIAL >
ZOOM >
