tech21 EVOAQUA Manual

Instruction Guide iPhone 7 Plus
EVOAQUA

2 3
WHAT’S IN THE BOX?
OPENING YOUR EVO AQUA
Evo Aqua case
Dummy phone
Cleaning cloth
Instruction guide
Opening key
Open the SecureClip at the bottom of your
case.
Insert the supplied opening key into the
allocated slot as illustrated and twist to
release the back cover.
Do not pull on the SecureClip. This
could damage your case.
1.
2.
3.
4.
5.
1.
2.
PRE-ASSEMBLY CHECKS
Before assembling your case, check that the
following areas are free from dust, debris and
damage:
ENGLISH
1. 2.

4 5
WATER TEST
1.
2.
Your Evo Aqua was water tested before it
left our factory. To make sure that nothing’s
happened to it in transit, we suggest that you
test it again before using it for the rst time.
Open your case following the instructions
above and carry out the pre-assembly
checks.
Insert the supplied dummy phone into the
front cover of your case, base rst.
ENGLISH
Seals
Acoustic vents
Fingerprint membrane
Using both of your thumbs and index
ngers, squeeze the top left and top
right corners of your case rmly together,
making sure that the clips on either side
of the three SecureHooks are engaged
securely.
On the top of your case’s back-plate, you’ll
notice three SecureHooks. Insert these
hooks into the slots on the back side of the
front cover.
Using your thumbs, press these hooks
rmly up into their slots. You should feel
them shift up into place.
4.
5.
6.
ENGLISH
3.Press the dummy down rmly into your
case as illustrated.

6 7
Moving your way along each side of your
case, use your index ngers to squeeze the
sides of your case inwards towards your
device, whilst using your thumbs to press
the back-plate down into the front cover.
Take your time and make sure that each
individual clip is engaged. Even a slight
gap could cause a leak.
Close the SecureClip.
8.
9.
ENGLISH
Repeat this at the bottom of your case,
making sure that the clips on either side
of the SecureClip, and the clips on each
corner of your case, are engaged securely.
7.
ENGLISH
12.
13.
Remove your case from the water, shake
off any excess water and towel dry
(exterior only).
Open your case following the instructions
above and check inside for any water
ingress. If your case is dry inside, go
ahead and install your phone (instructions
below). If water has entered your case,
please discontinue use and contact our
customer service team (details to follow).
11.Submerge your Evo Aqua, face down,
in a bowl of water for 30min. To keep it
submerged, we suggest using a small
weight.
10.When all the clips are engaged securely,
visually inspect the main seal and ensure
that there’s nothing obstructing it.

8 9
DEVICE INSTALLATION
1.
2.
Remove any screen protectors and/or
cases and clean your phone using the
supplied cleaning cloth.
Make sure that the mute dial is in the
position illustrated below and that your
phone is not switched to silent mode.
ENGLISH
3.Insert your phone into the front cover, base
rst, making sure that the microphone and
speakers are engaged correctly.
4.
5.
6.
Press your phone down rmly into your
case.
Rotate the mute dial on your case to make
sure that it engages correctly with the
mute switch on your phone.
Insert the SecureHooks on the top of your
case’s back-plate into the slots on the back
side of the front cover.
ENGLISH
Using your thumbs, press these hooks
rmly up into their slots. You should feel
them shift up into place.
7.
Using both of your thumbs and index
ngers, squeeze the top left and top
right corners of your case rmly together,
making sure that the clips on either side
of the three SecureHooks are engaged
securely.
8.

10 11
9.
ENGLISH
Moving your way along each side of your
case, use your index ngers to squeeze
the sides of your case inwards towards
your device, whilst using your thumbs to
press the back-plate down into the front
cover. Take your time and make sure that
each individual clip is engaged. Even a
slight gap could cause a leak.
10.
11.
Repeat this at the bottom of your case,
making sure that the clips on either side
of the SecureClip, and the clips on each
corner of your case, are engaged securely.
Visually inspect the main seal to ensure
that there’s nothing obstructing it.
12.
Close the SecureClip.
1.
2.
3.
4.
DEVICE REMOVAL
Never open your Evo Aqua in/or under
water. In order to stop any water getting in
when you’re opening it, rst shake off any
water and then dry it with a towel.
Remove the back of your case by following
the instructions in the section titled
“opening your Evo Aqua”.
Place one of your hands underneath the
open back of your case to catch your
phone.
Using your other hand to hold the front
cover of your case, gently press onto your
phone’s screen. Your phone should fall out
into your hand below.
Follow the handset manufacturer’s
instructions to reprogram the Touch ID
on your phone. This will make sure that
it recognises your ngerprint through the
waterproof membrane.
Your Evo Aqua is now ready to use.
13.
14.
ENGLISH

12 13
1.
2.
3.
4.
5.
6.
CARE & MAINTENANCE
Water test your Evo Aqua every 3 months,
and before any planned deep water
exposure, as per the instructions for the
“water test” detailed above.
If your case comes into contact with soap,
seawater or chlorine, rinse thoroughly with
fresh water. Do not use bleach, alcohol or
proprietary cleaners.
Before every use, inspect the seals and use
a damp cloth to wipe away any matter (e.g.
sand or grit) which could obstruct it.
After any major impact, inspect your case
for damage. If you’re concerned, carry out
a “water test”.
Avoid contact with sharp or abrasive
objects.
We recommend that you remove your
phone from your case on a weekly basis
and check for any moisture build-up from
the environment. This is completely normal
and not a failure of your case. If moisture
has built up inside your case, dry it with a
towel before reassembling it.
IMPORTANT NOTICE
Please read all instructions and warnings
carefully prior to using your Evo Aqua.
Improper use may result in product damage
CUSTOMER SERVICE
To contact our customer service team please
call us on [phone]
Or alternatively visit www.tech21.com/
contact-us
ENGLISH
WARRANTY
The Evo Aqua is warranted for 1 year from the
date of purchase against veried manufacturing
defects, provided the Evo Aqua is used in full
compliance with tech21’s instructions (supplied
with the case and available at tech21.com/
how-to). Following submission of a warranty
claim in accordance with the procedure
described at tech21.com/warranty, tech21 will
at its sole discretion (1) repair the Evo Aqua
at no charge (2) exchange the Evo Aqua for a
replacement or (3) refund the original purchase
price. This warranty does not affect statutory
rights to which you may be entitled. This
warranty excludes damage resulting from wear
and tear, modications, unauthorized repairs,
for which you, the purchaser, will be
responsible.
• Do not store the Evo Aqua in excessively
low or high temperature conditions, including
heat caused by sunlight. Do not place the
Evo Aqua in a re or other excessively hot
environments. Avoid dramatic changes in
temperature or humidity.
• Do not attempt to disassemble, repair,
re-purpose or modify the Evo Aqua in any
way as you risk damaging the product and
such damage isn’t covered by the limited
warranty.
• If you, the purchaser intend for the Evo
Aqua to be used by a minor, you as the
purchasing adult agree to provide detailed
instructions and warnings to any minor prior
to the Evo Aqua being used. Failure to do so
is your sole responsibility as the purchaser,
and you agree to indemnify tech21 for any
unintended use or misuse by a minor.
ENGLISH

14
EXCLUSIONS & LIMITATIONS
Tech21 disclaims liability for any special,
incidental, indirect, punitive, or consequential
damages for breach of any warranty of any
type on any tech21 product. This limited
warranty does not, under any circumstances,
cover the replacement or cost of any electronic
device or personal property or data that may
be damaged or lost inside or outside of the
Evo Aqua case.
accident, abuse or other causes that are not
veried manufacturing defects.
Proof of Purchase as evidence the unit was
purchased from an authorised dealer within
the warranty period is required.
Tech21’s Evo Aqua for iPhone 7 Plus has been
designed for use with an iPhone 7 Plus only. It
is not recommended to use it with any other
device or personal property.
ENGLISH
BEFORE USING YOUR
YOU’LL NEED TO KNOW
HOW TO ASSEMBLE IT
CORRECTLY AND CARRY
OUT A WATER TEST.
TO FIND OUT HOW:
1
READ THE INCLUDED
INSTRUCTION GUIDE
2
VISIT tech21.com/how-to
OR
SCAN THE BELOW QR
CODE
EVO AQUA
IMPORTANT
