Techly IDATA HDMI-KVM67 User manual

P/N: IDATA HDMI-KVM67
(transmitter + receiver)
8059018361629
EN User's Manual
IT Manuale d’istruzione
WWW.TECHLY.COM
HDMI KVM EXTENDER
OVER NETWORK CABLE
Technical features
Technical features
70 M
a/v series

HDMI KVM EXTENDER OVER NETWORK CABLE
Dear Customer
Thank you for purchasing this product. For optimum performance and
safety, please read these instructions carefully before connecting,
operating or adjusting this product. Please keep this manual for future
reference.
IMPORTANT SAFETY INSTRUCTION
INTENDED USE
We do not permit using the device in other ways like
described in this user’s manual. Use the product only
in dry interior rooms. Not attending to these
regulations and safety instruction might cause fatal
accidents, injuries, and damages to persons and property. The
manufacturer/supplier assumes no liability for damages caused by
failure to comply with the intended use.
To reduce risk of electric
shock, this product should
ONLY be opened by an
authorized technician when
service is required. Disconnect the product from mains and other
equipment if a problem should occur. Do not expose the product
to water or moisture.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
• Your product is not a toy and is not meant for children, because it
contains small parts which can be swallowed and can injure when
used inappropriately!
• Please install the system and devices attached to it in a way that
persons cannot be injured, or objects not be damaged for example
by dropping or stumbling.
• Please remove the packing materials, because children may cut
themselves on them while playing. Furthermore, there is a risk of
swallowing and inhalation of incidentals and insulating material.
• Avoid places with high temperatures, or humidity, or places which
might come into contact with water. Do not install the product close
to openings of air conditioners, or at places with an excessive
amount of dust or smoke. Keeps distance from flammable and
explosive devices.
• Do not install the product at places subject to vibration, or
oscillation
• Do not modify and alter the product and any accessories! Do not
use any damaged parts.
• Keep enough space around all devices for a good ventilation and
free motion and to avoid damages.
• Do not mix up HDMI to RJ45 transmitter and RJ45 to HDMI receiver
before installation.
EN - 2
WWW.TECHLY.COM
HDMI KVM EXTENDER
OVER NETWORK CABLE

• Do not hot plug when it is working.
• Use DC5V-12V power supply only. Make sure specification
matched if using 3rd party adapters.
• Static electricity will cause damage of the device, please do ESD
protection when using the device.
INTRODUCTION
This HDMI Extender includes a transmitter unit and a receiver unit,
allows HDMI signal to be transmitted up to 70 meters at 4K resolution
using a CAT6/6A/7 network cable. It is perfect for outdoor advertising,
video clips, monitor system, home entertainment, and conference,
etc.
FEATURES
• Zero latency
• 4K@60Hz HDMI signal can be transmitted 70 meters through a
CAT/6A/7 network cable.
• The receiver can extract the digital audio from the transmitter
through the S/PDIF port.
• Supports audio formats (Dolby True HD 7.1CH, Dolby Digital
5,1CH).
• Supports HDR(YUV4:4:4), EDID passback.
• Transmitter support one HDMI loop-out.
• Support KVM function.
• Lighting protection, surge protection, ESD protection.
PACKAGE CONTENTS
• Transmitter unit x1pc
• Receiver unit x1pc
• DC5V 2A x2pcs
• USB Cable x1pc
• Mounting brackets x8pcs
• Screw x18pcs
• User manual x1pc
INSTALLATION REQUIREMENTS
1. HDMI source device (compute graphics card, DVD, PS3,) HD
monitoring equipment etc.
2. HDMI display device like SDTV, HDTV, projector with HDMI port.
3. UTP/STP CAT6/CAT6A/CAT7 cable. Follow standard IEEE-568B.
It is recommended to select a network cable with less loss and
crosstalk.
EN - 3
WWW.TECHLY.COM
HDMI KVM EXTENDER
OVER NETWORK CABLE

PANEL DESCRIPTION
1. Transmitter (TX)
EN - 4
WWW.TECHLY.COM
HDMI KVM EXTENDER
OVER NETWORK CABLE
1 USB light
a) The mouse and keyboard are connected, the
indicator light is on
b) There is signal connected, the indicator light
flashes
2 Reset button Press to restart the device
3
RJ45 signal
output Connect with network cable
4
Power/Signal
indicator
When there is power and no HDMI signal, the
indicator will flash, when there is HDMI signal, the
indicator will light solid blue
5
DC5V-12V
input Connect with DC5V-12V power adapter
6 HDMI output Connect with HDMI display device
7 HDMI input Connect with the source device
8 USB-A port Connect with computer

2. Receiver (RX)
EN - 5
WWW.TECHLY.COM
HDMI KVM EXTENDER
OVER NETWORK CABLE
1USB light
a) The mouse and keyboard are connected,
the indicator light is on
b) There is signal connected, the indicator
light flashes
2Reset button Press to restart the device
3RJ45 signal
output Connect with network cable
4Power/Signal
indicator
When there is power and no HDMI signal, the
indicator will flash, when there is HDMI signal,
the indicator will light solid blue
5DC5V-12V
input Connect with DC5V-12V power adapter
6S/PDIF out Output digital audio signal
7HDMI output Connect with HDMI display device
8USB-A port Connect with keyboard and mouse

INSTALLATION PROCEDURE
1. Connection
One to one:
HDMI Display
Speaker
RX
USB
Keyboard/Mouse
PC TX HDMI Display
Follow the standard of EIA-568B, It is recommended to select a
network cable with less loss and crosstalk.
1-Orange/white
2-Orange
3-Green/white
4-Blue
5-Blue/white
6-Green
7-Brown/white
8-Brown
2. Connection instruction
1) Connect the source device to the HDMI in port of the transmitter
with an HDMI cable, and connect the HDMI out port of the receiver
to the display device with another HDMI cable.
2) Connect the CAT out port of the transmitter and the CAT in port of
the receiver via a network cable (CAT6/CAT6A/CAT7).
3) If using HDMI loop out, connect the display device to the HDMI
OUT port of the transmitter.
4) Plug the power supply into the device to get started.
Note: It is recommended to use a length range within 2~70m network
cable. If the cable is too short, there may be no display output
because the signal is too strong. If the cable is too long the output
may be with poor quality.
Network
CableHDMI IN HDMI
OUT
EN - 6
WWW.TECHLY.COM
HDMI KVM EXTENDER
OVER NETWORK CABLE

FAQ
Q: There is no output on screen when all connections are correct
A: 1) Please make sure the HDMI cables supports 4K x 2K if the
output signal from the source device is 4K x 2K resolution.
2) Please check and make sure the network cable insert to the
RJ45 port well.
3) Restart the transmitter or receiver by pressing the reset button.
Q: Black screen happened on the display/monitor
A: 1) Check if the length of the cable is within the specified range.
2) Reset the transmitter to re-built the connection.
Q: The display shows unusual color or no sound
A: 1) Reset the transmitter or receiver to re-built the connection.
2) Check if the HDMI cables are connected well.
3) Reconnect the network cable.
SPECIFICATION
Items Specification
Power Supply
Voltage/Current DC5V-12V
Power
consumption TX < 4W RX < 4W
HDMI
Performance
and Interface
HDMI
compliance HDMI 2.0
HDCP
compliance HDCP 2.2
HDMI resolution
480i@60Hz, 480p@60Hz,
576i@50Hz, 576p@50Hz,
720p@50/60Hz, 1080i@50/60Hz,
1080p@50/60Hz,
3840x2160@24/25/30/50/60Hz,
4096x2160@24/25Hz, 1280x960,
1280x800, 1280x768, 1680x1050,
1360x768, 1366x768, 1600x900,
1024x768, 800x600
HDMI
Performance
And Interface
Supports audio
formats
LPCM/DTS-HD/DTS-Audio/Dolby
True HD 7.1CH/Dolby Digital
5,1CH
Input and output
TMDS signal 0.7~1.2Vp-p(TMDS)
Input and output
DDC signal 5Vp-p (TTL)
Input cable
length ≤8m (AWG24)
Output cable
length ≤8m (AWG24)
EN - 7
WWW.TECHLY.COM
HDMI KVM EXTENDER
OVER NETWORK CABLE

Transmission
Distance
CAT6/6A/7 ≤70m
Protection
Level
Electrostatic
protection of the
whole machine
1a Contact discharge level 3
1b Air discharge level 3
Implementation of the
standard: IEC61000-4-2
Operating
Environment
Working
temperature -20~60°C
Storage
temperature -30~70°C
Humidity (no
condensation) 0~90%RH
Body
Properties
Dimension 150.0(L) x 107.0(W) x 28.4(H)mm
Material Aluminium alloy material + crystal
panel
Treatment
process Grit blast
Color Black
Weight TX: 260g RX: 260g
Maintenance: clean only with a dry cloth. Do not use cleaning
solvents or abrasives.
Warranty: no guarantee or liability can be accepted for any changes
and modifications of the product or damage caused due to incorrect
use of this product.
In compliance with EU Directive WEEE this product is marked
with this symbol. It means that used electrical and electronic
products should not be mixed with general household waste.
There is a separate collections system for these products in
compliance with WEEE directive, otherwise contaminative and
hazardous substances can pollute the environment
With the CE sign, Techly®ensures that the product is conformed
to the basic European standards and directives.
EN - 8
WWW.TECHLY.COM
HDMI KVM EXTENDER
OVER NETWORK CABLE

HDMI KVM EXTENDER SU CAVO DI RETE
Gentile Cliente
Grazie per aver acquistato questo prodotto. Per ottenere il massimo
delle prestazioni nella salvaguardia della sua sicurezza, le consigliamo
di leggere con attenzione il presente manuale prima di collegare
e mettere in funzione il prodotto. Tenga sempre a disposizione il
presente manuale per ulteriori esigenze future.
IMPORTANTI INFORMAZIONI SULLA SICUREZZA
USO PREVISTO
Non è consentito l’uso dell’apparecchio in modi diversi
da quello indicato nel presente manuale. Utilizzare il
prodotto solo in luoghi interni asciutti. Non rispettare le
istruzioni e le precauzioni di sicurezza riportate nel
presente manuale potrebbe causare incidenti mortali, lesioni e
danni a persone e cose. Il costruttore/fornitore non risponde dei
danni risultanti da un utilizzo non conforme all’uso previsto.
Per ridurre il rischio di
shock elettrico, questo
prodotto dovrebbe essere
aperto SOLO da un tecnico
autorizzato quando è necessario ripararlo. Scollegare il prodotto
dall’alimentazione e da altri apparecchi se dovesse esserci un
problema. Non esporre il prodotto ad acqua o umidità.
ATTENZIONE
RISCHIO DI SCOSSE ELETTRICHE
NON APRIRE
• Questo prodotto non è un giocattolo e non è pensato per i bambini,
contiene piccole parti che potrebbero venir ingerite o inalate e
provocare danni se non utilizzato correttamente!
• Installare l’apparecchio e le periferiche ad esso collegate in modo
che non possano provocare danni a persone e oggetti come far
inciampare o causare cadute.
• Rimuovere tutti gli imballi che potrebbero causare soffocamento se
manipolati da bambini.
• Evitare di installare l’apparecchio in luoghi con temperature o
umidità eccessive, o luoghi che potrebbero venire a contatto con
l’acqua. Non installare vicino a bocchette dell’aria condizionata
o in luoghi che presentano polvere o fumi eccessivi. Mantenere il
prodotto distante da materiali infiammabili ed esplosivi
• Non installare il prodotto in luoghi soggetti a vibrazioni o oscillazioni.
• Non modificare o alterare il prodotto e i suoi accessori! Non
utilizzare parti danneggiate.
• Mantenere sufficiente spazio attorno alla periferica per garantire
una buona ventilazione, permettere una maggiore libertà di
movimento ed evitare danni.
• Non invertire trasmettitore con ricevitore prima dell'installazione.
• Non collegare altri dispositivi quando il prodotto è in funzione.
IT - 9
WWW.TECHLY.COM
HDMI KVM EXTENDER
SU CAVO DI RETE

• Utilizzare solo l’alimentatore DC5V-12V fornito nella confezione.
Assicurarsi che le specifiche dell’alimentatore sostitutivo
corrispondano a quelle dell’originale.
• L'elettricità statica causerà danni al dispositivo, si prega di
effettuare la protezione ESD quando si utilizza il dispositivo.
INTRODUZIONE
Questo prodotto è un Extender HDMI costituito da un’unità
trasmettitore e da un’unità ricevitore e consente di tramettere il
segnale HDMI fino a 70 metri con una risoluzione 4K utilizzando
un cavo di rete CAT6/6A/7. È perfetto per la pubblicità esterna,
video clip, sistema di monitoraggio, intrattenimento domestico e
conferenze, ecc.
CARATTERISTICHE
• Zero latenza
• Il segnale HDMI 4K a 60Hz può essere trasmesso a 70 metri tramite
un cavo di rete CAT/6A/7.
• Il ricevitore può estrarre l'audio digitale dal trasmettitore attraverso
la porta S/PDIF.
• Supporta i formati audio (Dolby True HD 7.1CH, Dolby Digital
5,1CH).
• Supporta HDR (YUV4: 4: 4), EDID passback.
• Il trasmettitore supporta una porta HDMI in uscita per monitor
locale.
• Supporta la funzione KVM.
• Protezione antifulmine, protezione contro le sovratensioni,
protezione ESD.
CONTENUTO DELLA CONFEZIONE
• Unità trasmettitore x1pz
• Unità ricevitore x1pz
• DC5V-12V x2pz
• Cavo USB x1pz
• Staffe di montaggio x8pcz
• Viti x18pcz
• Manuale d’istruzione x1pz
IT - 10
WWW.TECHLY.COM
HDMI KVM EXTENDER
SU CAVO DI RETE
