Technaxx Sport BT-X28 User manual
MusicMan® * User Manual
Bluetooth In-Ear Headphone LED Sport BT-X28
With this comfortable and good fitting in-ear stereo headphone
you can enjoy music via Bluetooth and the cable lights in the
darkness
The manufacturer Technaxx Deutschlan d GmbH & Co.KG hereby declares
that this device, to which this user manual belongs, complies with the essential
requirements of the standards referred to the Directive RED 2014/53/EU. The
Declaration of Conformity you find here: www.technaxx.de/ (in bar at the
bottom “Konformitätserklärung”). Before using the device the first time, read
the user manual carefully.
This device has a rechargeable battery. It must be fully charged before
first use. NOTE: Charge the battery of the device every 2–3 month if it is
not used! Turn OFF nearby Bluetooth devices to avoid signal
interference! WARNING: DO NOT TURN THE VOLUME TOO HIGH –
HEARING LOSS MIGHT BE THE RESULT!
Service phone No. for technical support: 01805 012643 (14 cent/minute from
German fixed-line and 42 cent/minute from mobile networks).
Keep this user manual for future reference or product sharing carefully. Do the
same with the original accessories for this product. In case of warranty, please
contact the dealer or the store where you bought this product.
Warranty 2 years
Features
Music transfer & hands-free function via Bluetooth V4.2 In-Ear
Bluetooth headphone for Smartphone, Tablet, Notebook, etc. EL
luminous cable shines in the darkness (you can turn it on/off for your
own safety) Easy 4-button handling Built-in microphone Micro
USB connector for charging Redial function Soft & tight ear hook
for comfortable fitting Protection class IPX4 (splash water proofed)
Ideal for outdoor activities in the darkness
Technical specifications
Bluetooth / Transmitting distance BT V4.2 / A2DP / ~8m (open space)
4 Buttons EL luminous cable turn on/off, Play/Pause/On/Off, Decrease
VOL/Last Track, Increase VOL/Next track
Power Built-in rechargable 80mAh lithium polymer battery 3.7V /
charging via Micro USB connector
Charging time ~2 hours (DC 5V/500mApower adapter)
Playing time ~1.5 hours (medium volume, EL light on)
Standby time ~5–6 hours (Bluetooth connection, no music
playing)
SNR / Impedance ≦90dB / 16 Ω
Frequency range 20Hz– 20kHz
Protection class
IPX4 (
(splash water proofed)
Weight / Dimensions 28g / Cable 45cm / (L) 4.0 x (W) 3.2 x (H) 1.6cm
Package Contents
MusicMan® Bluetooth In-Ear Headphone LED
Sport BT-X28, Micro USB charging cable, 3
different plug sizes, User Manual
Hints for Environment Protection: Packages materials are
raw materials and can be recycled. Do not disposal old
devices or batteries into the domestic waste. Cleaning:
Protect the device from contamination and pollution (use a
clean drapery). Avoid using rough, coarse-grained materials
or solvents/aggressive cleaner. Wipe the cleaned device
accurately. Distributor: Technaxx Deutschland GmbH &
Co.KG, Kruppstr. 105, 60388 Frankfurt a.M., Germany
Product Overview
1 EL luminous cable of 45cm length
2 Button for the functions Power ON/OFF, Play/Pause,
Hands-free: Keep pressing the power button for 3 seconds
to turn on the headphone. Meanwhile, BLUE and RED indicator
LED are blinking alternatively.
Under Bluetooth mode: short press to play or pause
music should someone call you, short press to receive or end
phone call double click to redial the last outgoing call.
3 Indicator LED: After turning on the headphone, BLUE and
RED indicator LED are blinking alternatively. BLUE indicator
LED turns solid if headphone is paired via Bluetooth.
Charging mode: RED indicator LED turns solid while charging.
RED indicator LED turns off if headphone is fully charged.
4 Volume up/down, Track back/forth:
Short press to increase or decrease volume.
Long press to move to next track or go back to last track.
5 Soft ear hook
6 Earbud
7 EL luminous cable turn on/off button: Long press to turn on
EL light. Short press to adjust EL light mode.
There are two EL light modes: a) light is on all the time, b)
light flashes with the rhythm of music. (under this mode, if music
stops more than 5 minutes, light turns off automatically.)
8 Microphone 9 Micro USB charging connector
Charging the headphone
Before first use, fully load the battery with the included original Micro
USB charging cable. Connect the Micro USB charging cable to an
USB adapter* (5V/500mA) (*not included) or computer USB port,
and the other end to the Micro USB charging port of the headphone.
The RED LED shines bright while charging in the OFF status. When
the headphone is fully charged, the RED LED turns off. (We
recommend turning off the headphone while charging. Otherwise it
will take a longer time to get it fully charged.)
The device will remind you with a BEEP sound that the battery
has low power.
Attention: The headphone fits only in one direction perfectly
when but on the head! So be sure the right side is on the right
and the left on the left!
Bluetooth
Turn on the headphone by pressing the “POWER” button (2).
Bluetooth works spontaneously, searching for previously paired
Bluetooth devices. The Bluetooth pairing mode is shown by the
quickly flashing BLUE and RED LED. If the headphone fails to
connect turn on your Bluetooth device to search the headphone with
the name ”MusicMan BT-X28”. After pairing successfully, the BLUE
LED indicator lights steady. When the headphone is connected with
your Smartphone and there is an incoming call, you can press the
power button shortly to receive and end calls. By double clicking the
power button you can re-dial the last number you called.
The headphone cannot play music by itself. If you want to hear
music via the headphone, you have to start the music track on your
Bluetooth device (e.g. Smartphone).
Activate the luminous cable
There are two EL light modes. To activate the luminous cable long
press button (7) to turn EL light on. Short press button (7) to adjust
EL light mode:
First: Light is on all the time
Second: Light flashes with the rhythm of music.
Note: Under the second mode, if music stops more than 5 minutes,
light turns off automatically.)
Troubleshooting
The BT-X28 powers Off or does not turn On again could be
either a low battery or a problem with the power supply charge
the BT-X28 and check the connection of the Micro-USB cable. (We
suggest charging the BT-X28 all 2-3 month if it is not used for a long
time.)
Noises are heard from the BT-X28 could be a poor Bluetooth
signal to aviod noise, stay within the Bluetooth range of ~8m.
No Bluetooth connection could be (a) the Bluetooth connection
is not in range, or (b) another mobile device (e.g. Smartphone,
Tablet) is paired with the BT-X28 (a) shorten the range to the
Smartphone, or (b) unpair the other device.
Warnings
Only charge the BT-X28 through the DC 5V Micro USB port by
using the provided original Micro USB charging cable. You also can
use an USB charging adapter but ONLY (!) up to DC 5V/500mA. Do
not (!) charge the BT-X28 with more power!
If the BT-X28 fails to link to your mobile device or if it fails to play
music after being connected, the user shall check if your mobile
device supports A2DP.
Do not attempt to disassemble the BT-X28, it may result in
short-circuit or even damage.
Do not drop or shake the BT-X28, it may break internal circuit
boards or mechanics.
Keep the BT-X28 in dry and ventilated environment. Avoid high
humidity and high temperature. Also batteries should not be
exposed to excessive heat or direct sunlight.
This BT-X28 is not water resistant; therefore keep it away from
moisture.
Keep the BT-X28 away from little children.
