Technaxx MusicMan BT-X57 User manual

MusicMan®* User Manual
Mikro TWS Headphones BT-X57
The manufacturer Technaxx Deutschland GmbH & Co.KG hereby
declares that this device, to which this user manual belongs, complies
with the essential requirements of the standards referred to the Directive
RED 2014/53/EU. The Declaration of Conformity you find here:
www.technaxx.de/ (in bar at the bottom “Konformitätserklärung”).
Before using the device the first time, read the user manual carefully.
Service phone No. for technical support: 01805 012643 (14 cent/minute
from German fixed-line and 42 cent/minute from mobile networks).
Free Email: [e-mail]
This device has a rechargeable battery. It must be fully charged
before first use. NOTE: Charge the battery of the device every 2–3
month if it is not used!
Keep this user manual for future reference or product sharing carefully.
Do the same with the original accessories for this product. In case of
warranty, please contact the dealer or the store where you bought this
product. Warranty 2 years
Enjoy your product. *Share your experience and opinion on one of
the well-known internet portals.
Caution! Choking hazard. Small parts.
Features
•True Wireless Stereo (TWS) in-ear headphone
•Voice assistant function supported
•Automatic on/off function
•Pairing with Bluetooth V5.0
•Built-in microphone for phone calls
•Multi-functional touch buttons on both in-ear headphones;
play/pause, title change, volume, answer and reject phone
calls, voice assistant

Technical specifications
Bluetooth version
V5.0
Bluetooth
Transmitting distance ~10m (open space)
Frequency band 2.4GHz
Radiated transmission power max. 2.5mW
Loudspeaker / frequency /
impedance
5mW*2 / 20Hz-20kHz / 32Ω
Audio codec
AAC/SBC/A2DP
Playtime
Approx. 2h
Charges with charging box
3 times fully charged
Standby time
Approx. 9h
Charging time earbuds
Approx. 1h
Battery earbuds (each)
Built-in rechargeable 30mAh
lithium polymer battery 3.7V /
charging via charging box
Charging time box
Approx. 2h (5V/1A)
Battery charging box
3.7V 150mAh lithium polymer
battery
Operating temperature
0°C up to +40°C
Weight / dimension earbud
10.6g / (L)40 x (W)22 x (H)25mm
Weight / dimension box
35.0g / (L)49 x (W)32 x (H)54mm
Package content
MusicMan® BT-X57, charging
box, USB charging cable, user
manual

Product details
1
Charging box switch
2
LED Charging box
3
Charging port
4
Earbud charging contact
5
Microphone
6
LED Earbud
7
Multi-functional touch button surface
8
Air gate
9
Speaker
First use
Connect the charging box (3) with the attached charging cable
and a USB power adapter* (*not included in the delivery). The
charging box flashes red while charging. The box is fully
charged when the light is stable.
Press the charging switch (1) at the charging box to start the
charging of the earbuds. The LED of the charging box lights up
in blue. The charging stops automatically when the earbuds are
fully charged. The blue light turns off.

Bluetooth connection
Pairing
Take the BT-X57 earbuds out of the charging box. Both
earbuds turn on automatically and start
the pairing mode.
After it prompts “power on” the indicator
LED flashes red and blue in change.
Start the Bluetooth scan function with
your Smartphone / Tablet or any other
Bluetooth enabled device.
Click on “MusicMan BT-X57” in the
Bluetooth settings to pair your device
with the earbuds.
Reset pairing
Take out both BT-X57 earbuds from the charging box and hold
3 seconds the touch-function surface (7) to turn the earbuds off
to clear the pairing settings. The indicator LED will blink red 3
times. Put the earbud into the charging box. Take out both
earbuds to restart the pairing mode.
Single use of BT-X57
Take the right or left earbud out of the charging box. It switches
on automatically. Note: Just the touch button settings of the left
or right earbud are provided. Choose wisely.
Auto reconnection
The BT-X57 headphone will reconnect to the last paired mobile
phone automatically. To change the paired connection to
another mobile phone, reset the pairing.
MusicMan BT-X57

Functions
Power On/Off
Touch the function surface (7) of the earbuds 3 seconds to turn
it off/on. The earbuds turn on/off automatically after put out/in of
the charging box.
Play/Pause music (1x R/L)
Single touch the function surface of one of both earbuds for
play/pause music.
Volume down (2x L)
Double-touch the function surface of the left earbud for
decrease the volume.
Volume up (2x R)
Double-touch the function surface of the right earbud for
increase the volume.
Next song (3x R)
Three touch on the function surface of the right earbud will play
the next song.
Last song (3x L)
Three touch on the function surface of the left earbud will return
to the previous song.
Answer phone calls (R/L)
Incoming calls can be answered by a single touch on one of
both earbuds.
Hang up calls (R/L)
Phones calls can be cancelled by double-touch the function
surface on one of both earbuds.
Reject calls (hold 2 sec. R/L)
To reject calls, hold 2 seconds one of the touch surfaces.
Voice assistant (hold 2 sec. R/L)
2 seconds touch on the left earbuds function surface will
activate the voice assistant of your phone.

Troubleshooting
If you cannot connect the headphone to your phone, do as
follows:
Ensure that the headphone is charged and in on state. Ensure
that the Bluetooth feature is activated on your phone. Check
that the headphone is within 10m of your phone and that there
are no obstructions between the headphone and the phone,
such as walls or other electronic devices. The BT-X57 powers
off or does not turn on again could be either a low battery or a
problem with the power supply. Charge the BT-X57 and check
the battery status of the charging box. (We suggest charging
the BT-X57 all 2–3 month if it is not used for a long time.)
Notes
● Only charge the BT-X57 charging box through the DC 5V
charging port by using the provided charging cable. You also
can use an USB charging adapter but ONLY (!) up to DC
5V/1A. Do not (!) charge the BT-X57 with more power! ●If the
BT-X57 fails to link to your mobile device or if it fails to play
music after being connected, the user shall check if your mobile
device supports SBC / ACC. ●Noises are heard from the BT-
X57 could be a poor Bluetooth signal. To avoid noise, stay
within the Bluetooth range of 10m. ●Avoid prolonged exposure
to excessive volume that may cause noise-induced hearing
impairment. ●Turn the volume down before putting on your
headphones, then adjust it to the right volume.
Warnings
● Do not use the supplied charging cable to charge any other
devcies. This may could cause damage ● Do not disassemble
the BT-X57, it may result in short-circuit or damage. ●Do not
use headphones while driving or riding your bike. ●Stay away
from sharp edges, uneven surfaces, metal parts, and anything
that could damage the headphones. ●Do not modify, repair or
remove headphones without professional guidance. ●Do not
use corrosive or volatile liquid to clean the earphone. ●Do not
use headphones in dangerous environments. ● Battery
warning: Improper use of the battery may cause fire or chemical
burns. The battery may explode in case of damage. ●Do not
drop or shake the BT-X57, it may break internal circuit boards

or mechanics. ●Keep the BT-X57 in dry and ventilated
environment. Avoid high humidity and high temperature. Also,
batteries should not be exposed to excessive heat or direct
sunlight. ●This BT-X57 is not water-resistant; keep it away from
moisture. ●Keep the BT-X57 away from little children and pets
to prevent accidents.
To prevent possible hearing damage, do not listen at high volume
levels for long periods.
Products marked with this symbol meet all applicable
community regulations of the European Economic
Area.
Technaxx Deutschland GmbH & Co KG has issued a
"declaration of conformity" in accordance with the
applicable directives and relevant standards. has
been created. This can be viewed at any time upon
request.
Hints for Environment Protection: Packages
materials are raw materials and can be recycled. Do
not disposal old devices or batteries into the
domestic waste. Cleaning: Protect the device from
contamination and pollution (use a clean drapery).
Avoid using rough, coarse-grained materials or
solvents/aggressive cleaner. Wipe the cleaned
device accurately. Important Notice: Should battery
fluid leak from a battery, wipe the battery case with a
soft cloth dry. Distributor: Technaxx Deutschland
GmbH & Co.KG, Kruppstr. 105, 60388 Frankfurt
a.M., Germany
