Technaxx®* User Manual
Wireless TV Chin Guard Headphone TX-99
With this comfortable and good-fitting headphone you can
enjoy listening to television or music at your preferred volume
without disturbing anyone.
The Declaration of Conformity for this device is under the Internet link:
www.technaxx.de/ (in bottom bar “Konformitätserklärung”). Before using the
device the first time, please read the user manual carefully.
Service phone No. for technical support: 01805 012643 (14 cent/minute from
German fixed-line and 42 cent/minute from mobile networks). Free Email:
[e-mail]
This device has a rechargeable battery. It must be fully charged before first
use. NOTE: Charge the battery of the device every 2–3 month if it is not used!
WARNING: DO NOT TURN THE VOLUME TOO HIGH –HEARING LOSS
MIGHT BE THE RESULT!
Keep this user manual for future reference or product sharing carefully. Do
the same with the original accessories for this product. In case of warranty,
please contact the dealer or the store where you bought this product.
Warranty 2 years
These hearing impaired TV headphone is specially designed to help
people with a hearing impairment to hear sounds from the TV (or
another audio device) clearly and without distortion, which is not
always possible with a normal hearing aid, or with an ordinary
wireless headphone. They can also be used as normal wireless
headphones, when you do not want to disturb others while watching
TV. In order to keep the perfect sound quality, please pay attention
to the following situation: Away from another electronics device, for
example: micro-wave oven, and another communication device e.g.
telephone. Do not activate more electronic equipments in the near
area at the same time. It can happen lost of sound quality &
interference

Features
Wireless transmission between transmitter and receiver up to
15m open areas
Connectable to nearly every device with an audio output via
3.5mm audio cable jack-on-RCA
Hearing aid & adequate volume for television and music
Connection to a mobile phone via AUX cable (receiver must be
plugged in a power source; only hearing –no speaking)
In-Ear headphone for effective environmental noise reduction 
Listen to TV or music clearly without distortions and in a
comfortable volume, without disturbing anybody else
Ideal for hearing impaired persons and seniors
Technical specifications
Transmission distance
~15m (open areas)
Frequency band
(FM channels): 863.5/864/864.5MHz
Frequency response / THD
20Hz–20kHz / < 5% at 1kHz
Radiated transmission power 5mW maximum
Impedance
32Ω ± 15% at 1kHz
Sensitivity
114 ±5dB at 1kHz
Material
Silicone + PP + TPE + ABS plastic
Ports
Microphone 2.5mm & Line-in/out 3.5mm
Power supply
Built- in rechargeable 470mAh lithium
polymer battery 3.7V
Charging time / Playing time
~3 hours / ~8 hours
Receiver
Weight / Dimensions
64g / (L) 16.7 x (W) 1.9 x (H) 20.6cm
Transmitter
Weight / Dimensions
86g / (L) 13.2 x (W) 5.0 x (H) 4.2cm
(without antenna) / (H) 9.9cm (with
antenna)
Package
Contents
Wireless TV Chin Guard Headphone TX-99 (receiver &
transmitter), Power adapter 5V/1A, 2.5mm cable with
microphone, 3.5mm 3-Pin audio cable, 3.5mm audio
cabel to 2 female 3.5mm RCA jack & 2 male 3.5mm
RCA jack, 3 different earplug sizes, User Manual

Charging the headphone
Choose a suitable place near your TV or another audio source (e.g.
computer or HiFi system). Connect the power adapter into the DC
jack of the transmitter. GREEN LED at the front of the transmitter
will turn on. When the receiver is properly placed on the transmitter,
the RED LED at the front of the transmitter will turn ON. To turn
OFF the transmitter, plug out the power adapter at the socket or at
the outlet of the transmitter.
A wrong placement will lead to
charging failure.
Refer to the correct positioning like you
see in the picture. The mark on the top
of the transmitter should be matched with
the mark on the front of the receiver.
Receiver Front Rear
1
Power switch
(on/off button)
4
Charging contacts
2
Scan button
(changing frequency)
5
Indicator light (low battery 
RED LED, signal BLUE LED,
Power GREEN LED)
3
Volume button

Transmitter Front Middle Rear
1
Indicator light (Charging with red LED, signal with blue LED,
power with green LED)
2
2.5mm microphone-in jack
6
Charging contacts
3
3.5mm audio-in jack
7
SCAN button (changing
frequency)
4
3.5mm audio-out jack
5
DC 5V/1A power jack
8
Antenna
How to operate the transmitter
Connect the transmitter to the socket with DC 5V/1A power adapter.
The green LED at the front of the transmitter will turn on.
There are three different ways to connect the TX-99 to a TV or
another sound source (e.g. computer or HiFi system). The ways are
respectively the headphone socket, the Audio out L/R socket or the
microphone.
1. Make sure your TV has an audio output. Not all connections on
the TV are outputs. TVs are playback devices and mainly have
inputs. A headphone jack on the TV is an audio output and can be
connected to the TX-99.
If you do not know which port to use, please refer to the instruction
manual of your TV.
2. Increase the volume of the TV to make sure that the TX-99
transmitter also recognizes the TV as a source. It is only from a
higher volume that the device connected to the TX-99 transmitter is
detected. The LED on the transmitter should then light up blue.

Connecting the transmitter to a headphone socket (AUX–IN
3.5mm jack)
Connect one of the 3.5mm plugs of the AUX–OUT cable with the
connector on your audio source and the other plug into the “IN”jack
on the transmitter. The BLUE LED at the front of the transmitter will
turn on.
Connecting the transmitter to Audio–OUT L/R socket
Connecting the L (White) / R (Red) RCA plug of the 3.5mm RCA
cable into the Audio–out L/R socket on your sound source and the
3.5mm plug to the “IN”jack on the transmitter. The BLUE LED at
the front of the transmitter will turn ON.
Connecting the microphone
This device comprises an external microphone. When connected to
the transmitter, it can be used to amplify sound from an external
source, such as a mobile phone. Connect the microphone cable to
the microphone jack on the transmitter and place the microphone
near the sound source (TV/HiFi system/mobile phone).
Note: The advantage of using the microphone is that it is possible
to also here the ambient noise. The BLUE LED at the front of the
transmitter will turn on. Attention: Audio–IN jack and microphone
cannot be used at the same time.
The transmitter switches to standby mode after 1 minute without
input signal at the Audio-IN. As soon as a signal is applied to the
audio-IN, it takes about 3-5 seconds until the music can be heard
again via the receiver.
How to operate the receiver
Before using the receiver, set the volume on the receiver to a low
level. Press the On/Off button [1] of the receiver, GREEN LED on
the rear side of the receiver [5] will turn on the receiver is working,
When the BLUE LED is lighting the signal was received.
Place the ear buds into your ears and make sure, that the ON/OFF

and SCAN buttons of the receiver face toward the transmitter. The
ear bud tips can be rotated to fit them comfortably in your ears.
Press the ON/OFF button again, the GREEN LED or BLUE LED
turns off. It means the receiver is off.
The BLUE LED is visible during transmitter and receiver active
transmission.
Note: During normal working status, the GREEN LED is off.
Attention: When the transmitter is not in use for more than 3-4
minutes it goes to standby mode. To use it again you must press the
ON/OFF button again.
WARNINGS
Only use the supplied power adapter with this headphone. Do not
use any other type of adapters.
Sometimes, you may not hear the desired audio source due to
the receiver picking up another audio source (e.g. from another
nearby system). To change the transmitting channel, press the
SCAN button on the transmitter. There are 3 preset channels
(863.5MHz, 864MHz, 864.5MHz) on this Wireless Headphone.
If the RED LED of the receiver lights it needs to be charged.
The transmitter will automatically start transmitting when the
audio source is turned on.
It is necessary to place the receiver in the transmitter properly
when charging needed. An opposite placement of the receiver will
lead to charging failure.
Hints for Environment Protection: Packages
materials are raw materials and can be recycled. Do
not disposal old devices or batteries into the domestic
waste. Cleaning: Protect the device from
contamination and pollution (use a clean drapery).
Avoid using rough, coarse-grained materials or
solvents/aggressive cleaner. Wipe the cleaned device
accurately. Distributor: Technaxx Deutschland
GmbH & Co.KG, Kruppstr. 105, 60388 Frankfurt a.M.,
Germany
