Technaxx® * User Manual
Mini-LED HD Beamer TX-127
The Declaration of Conformity for this device is under the Internet
link: www.technaxx.de/ (in bottom bar “Konformitätserklärung”).
Before using the device the first time, please read the user manual
carefully.
Service phone No. for technical support: 01805 012643 (14
cent/minute from German fixed-line and 42 cent/minute from mobile
networks).
Free Email: [e-mail]
Keep this user manual for future reference or product sharing
carefully. Do the same with the original accessories for this product.
In case of warranty, please contact the dealer or the store where you
bought this product. Warranty 2 years
Enjoy your product * Share your experience and opinion on
one of the well-known internet portals.
Features
 Native 720P Mini projector with multimedia player
 Projection size from 27” to 150"
 Integrated 3Watt speaker
 Manual focus adjustment
 Long LED lifetime 40,000 hours
 Connectable with Computer/Notebook, Tablet, Smartphone and
Gaming consoles via AV, VGA, or HDMI
 Playback of Video, Photo and Audio Files from USB, MicroSD or
external hard disk
 Usable with Remote Control

Technical specifications
Projection technic LCD TFT projection system / low noise / low light
leaking
Lens Multichip composite coating optical lens
Power supply AC ~100V-240V 50/60Hz
Projection size / distance 27”–150” / 0.8-3.8m
Projector consumption / brightness
56W / 2000 Lumen
Contrast ration / Display colours 1000:1 / 16.7M
Lamp colour temperature / lifetime 9000K / 40000 hours
Correction Optical ±15°
Using time ~24 hours continuously
Audio frequency 3W
Fan noise Max. 51dB
Signal ports
AV input (1. OVp-p +/–5%)
VGA input (800x600@60Hz, 1024x768@60Hz)
HDMI input (480i, 480p, 576i, 720p, 1080i, 1080p)
Headphone Output
Native resolution 1280x720 pixel
USB / MicroSD card
/ ext. hard disk
format
Video: MPEG1, MPEG2, MPEG4, RM, AVI,
RMVB, MOV, MKV, DIVX, VOB, M-JPEG
Music: WMA, MP3, M4A(AAC)
Photo:
JPEG, BMP, PNG
USB / MicroSD card max. 128GB / max. 128GB
External hard disk max. 500GB
Weight / Dimensions 1250g / (L) 21 x (W) 14.5 x (H) 7.5cm
Packing contents
Technaxx® Native 720P Full HD mini LED
Beamer TX-127, 1x AV signal cable, 1x Remote
control, 1x HDMI cable, 1x Power cable, User
Manual
Compatible devices
Digital camera, TV-Box, PC/Notebook,
Smartphone, Game console, USB-Device /
MicroSD card,
external hard disk, Amplifier.

Product view & Functions
1
Focus adjustment
2
Keystone correction
3
SD
-
Card
4
AUX
-
Port
5
AV
-
Port
6
USB 2x
7
HDMI
-
Port
8
VGA
-
Port
9
Power button
10
V
-
/ Move left
11
Exit / Back
12
Signal source
13
OK / Enter / Menu
14
V+ / Move right
15
Indicator light
16
Air outlet
Power button: Press this button to shut on or off the device. 
Volume plus and minus button: Press the two buttons to increase
or decrease volume. They can also be used in the menu as selection
and parameter adjustment.
Menu: Bring up the main menu or exit system.
Signal source: Select the signal or an external video signal. It is also
usable as “play” button.
Air outlet: Do not cover the air-cooling openings during operation
to avoid burns.
1
2
3 4 5 6 7
8
10
9
11
12
13
14
16
15

Remote control & Functions
1
Power Switch
2
Select Signal Source
3
Menu
4
OK / Play / Pause
5
Move Up
6
Move Left
7
Move Right
8
Move Down
9
Exit / Back
10
Volume down
11
Volume up
12
Mute
 Between the remote control and remote-control receiving host
window, do not put any items, in order to avoid blocking the signal.
 Point the remote control to the right side of the device or the
projection screen, to receive the infrared radiation.
 To prevent battery leakage corrosion in the remote control, take
out the battery when not in use.
 Do not put the remote control in high temperature or damp places,
in order to avoid damage.
1
2 / 3
4 / 5 / 6 / 7 / 8
9
10 / 11
12

 Power on / Power off
After the device gets power through the power cable, it goes into
stand-by status:
 Press the POWER button on the device or on remote control to
turn the on the device.
 Press the POWER button again to turn off the device.
 Pressing the POWER button once again can shut down the engine
power. TX-127 will stay in standby as long as it is connected with the
power socket. If you do not use the device for a long time, take the
power cord from the power socket.
 Select the (Gear) icon on the device interface or press the
MENU button on the remote control to show the MENU screen.
Select with the remote control move buttons or the ◄ ► buttons
on the projector the menu item you need to adjust and confirm with
OK.
 Press the remote control move buttons or the ◄ ► buttons, to
adjust the parameter values for the selected menu item.
 Repeat the steps to regulate other MENU items, or directly
click BACK or EXIT button to EXIT a single interface.
 Multimedia boot screen
When the projector starts working, the screen displays takes about
5 seconds to come into the multimedia screen.
 Image focus
Put the device vertical to the projector screen or white wall. Adjust
the focus with the focus adjustment wheel (1) until the image is clear
enough. Then the focus is finished. During the focusing, you could
display a video or display the menu to check the adjustment.
 Keystone
Sometimes, the image projected on the wall looks like a trapeze
rather than a square, causing distortion that needs to be avoided.
You can adjust it with the keystone correction wheel (2).
The device does not have horizontal keystone correction function.

Multimedia connection
VGA input socket: the port can be connected to a computer or other
VGA video signal output socket. Refer to the following:
NOTE: The device and connection of laptop may not be able to
display images at the same time, if that happens, set the computer
display attributes, select for CRT output mode.
Video input socket: from now on the interface can be connected to
the LD player, DVD players, video cameras and video player
(VIDEO) or audio output socket.
VGA
-
Cable
PC
Laptop

Audio output: Audio signal from the output port of the device, if you
want to high power play music input end connected to external power
amplifier.
HDMI signal input: this interface can be used with HD players. You
have to connect the supplied HDMI cable from your player to the
device.
Video signal cable: yellow
Left channel signal cable: white
Right channel signal cable: red
Left channel
Right
channel
Video signal
cable
Audio
-
Cable


Operation
Input source selection
 Selecting an input signal from the device: (Check that the correct signal
cable is connected).
 Press the S button on the device or the SOURCE button on the remote
control to display the right interface.
 Confirm whether correctly connected to the signal cable press ◄ ►
buttons on the device or on the remote control to select the following input
PC, AV, HDMI, SD and USB. Choose your needed input signal with the OK
button.
Manually operation
Select the menu language
 Select the (Gear) icon on the device interface or press the MENU
button on the remote control to enter the MENU.
 Press the ◄ or ► button to go to OPTIONS.
 Press the OK button on the device or on the remote control to enter the
language option.
 Press the ◄ ► buttons, to select the language you need and then
press the Back button to accept Settings and exit.
Image mode
 Select the (Gear) icon on the device interface or press the
MENU button on the remote control to enter the MENU.
 Press the OK button to enter the PICTURE settings. Now you
can choose with the ◄ ► buttons between STANDARD, SOFT,
HDMI
-
Cable

VIVID and USER mode. Press the BACK button on the device or the
MENU button on the remote control to exit the PICTURE settings.
 After complete the adjustment, press the BACK button on the
device or the MENU button on the remote control to save settings
and exit.
Colour temperature
 Press the ► button to go to the COLOR TEMPERATURE
settings. Now press the OK button to enter the COLOR
TEMPERATURE settings.
 Press the ◄ ► buttons, to choose the settings you need to
adjust and then press the buttons ◄ ► to adjust the values of the
parameters of the options (MediumWarmUserCool).
 Press the BACK button on the device or the MENU button on
the remote control to save settings and exit.
Aspect Ratio
 Press the ► button to go to the ASPECT RATIO settings. Now
press the OK button to enter the ASPECT RATIO settings.
 Press the ◄ ► buttons to choose the parameters. You can
choose between AUTO, 16:9 and 4:3. Now press the OK button to
select the setting you need.
 Press the BACK button on the device or the MENU button on
the remote control to save the settings and exit.
Image projection mode
Image flip  Select the (Gear) icon on the device interface or
press the MENU button on the remote. Press ◄ ► to reach projection
mode. Press the OK button to rotate the image as you need it.
Noise cancel
 Press the ◄ ► buttons, to go to the NOISE REDUCTION settings.
Then press the OK button to enter the NOISE REDUCTION settings.
 Press the ◄ ► buttons, to select the level of noise reduction,
and then press the BACK button on the device or the MENU button
on the remote control to save the settings and exit.

Mute
 Press the mute button on the remote to mute the sound. Press
again mute to reactivate the sound.
Sound
 Select the (Gear) icon on the device interface or press the
MENU button on the remote control to enter the MENU.
 Press the ◄ ► buttons to go to the SOUND settings.
 Press the ◄ ► buttons to choose the items you need to adjust
and then press the ◄ ► buttons to adjust the values of the single
items. Possible options are: Movie / Sports / User / Standard / Music.
Press the BACK button on the device or the MENU button on the
remote control to confirm and exit.
Multimedia supported format from USB or MicroSD
Audio file: MP3 / WMA / ASF / OGG / AAC / WAV
Picture file: JPEG / BMP / PNG
Video file: 3GP (H.263, MPEG4) / AVI (XVID, DIVX, H.264) /
MKV (XVID, H.264, DIVX) / FLV (FLV1) /
MOV (H.264) / MP4 (MPEG4, AVC) /
MEP (MEPG1) VOB (MPEG2) / MPG (MPG-PS) /
RMVB(RV40)/RM
Note: Due to the copyright issue of Dolby, this projector does NOT
support Dolby audio decoding. Dolby audio files can be played via
HDMI connected devices.

Choose the content which you need to display: Video, Music,
Photo, Text.
The projector supports HDMI, MHL, FireTV, Google chromecast
and iPush connection. You can also connect your mobile
devices and tablets with it.
 This product is NOT recommended for PPT, Word, Excel or
business presentation.
 To connect the projector with tablet or smart phone, you need a
HDMI adapter. For Android phone which supports MHL, you need an
MHL to HDMI cable; for iPhone/iPad, you need a lighting (Lightning
Digital AV Adapter) to HDMI adapter cable.
 To connect the projector with PC/Notebook, adjust the
PC/Notebook display resolution to 1280x720, which can provide the
best clarify.
 Note that it only provides clear image in dark room.
MOVIE
MUSIC
TEXT

Hints
 Make sure you lay the cable in a way that the danger of stumbling is avoided.
 Never hold or carry the device by the power cable.  Do not clamp or
damage the power cable.  Ensure that the power adapter do not come into
contact with water, steam or other liquids.  You have to check the complete
construction at regular intervals for functionality, tightness and damage to
prevent the defect of the device.  Install the product due to this user manual
and operate or maintain it in accordance with the manufacturers operating
instructions.  Only use the product for purposes due to its intended function
& only for household use.  Do not damage the product. Following cases may
damage the product: Incorrect voltage, accidents (including liquid or moisture),
misuse or abuse of the product, faulty or improper installation, mains supply
problems including power spikes or lightning damage, infestation by insects,
tampering or modification of the product by persons other than authorized
service personnel, exposure to abnormally corrosive materials, insertion of
foreign objects into the unit, used with accessories not preapproved.  Refer
to and heed all warnings and precautions in the user manual.
Safety instructions
 Use standard power cord with ground wire, to ensure stable power supply
and the same power voltage with the product marked.  Do not disassemble
the product by yourself, otherwise we will not provide free warranty service. 
Do not look into the lens when the projector is working, otherwise it will damage
your eyes easily.  Do not cover the product’s ventilation hole.
 Keep the product away from rain, moisture, water or any other liquid as it is
not waterproof. It may cause an electric shock.  Turn off and cut off the power
supply if not use the product for a long time.  Use the original packing when
moving the product. 
Hints for Environment Protection: Packages
materials are raw materials and can be recycled. Do
not disposal old devices or batteries into the domestic
waste. Cleaning: Protect the device from
contamination and pollution. Avoid using rough,
coarse-grained materials or solvents/aggressive
cleaner. Wipe the cleaned device accurately.
Distributor: Technaxx Deutschland GmbH & Co.KG,
Kruppstr. 105, 60388 Frankfurt a.M., Germany
