Technaxx®* User Manual
Mini DLP Beamer TX-126
The Declaration of Conformity for this device is under the Internet
link: www.technaxx.de/ (in bottom bar “Konformitätserklärung”).
Before using the device the first time, please read the user manual
carefully.
Service phone No. for technical support: 01805 012643 (14
cent/minute from German fixed-line and 42 cent/minute from mobile
networks).
Free Email: [e-mail]
Keep this user manual for future reference or product sharing
carefully. Do the same with the original accessories for this product.
In case of warranty, please contact the dealer or the store where
you bought this product. Warranty 2 years
Enjoy your product * Share your experience and opinion on
one of the well-known internet portals.
Features
Mini projector with multimedia player
Wireless connection for Android devices
Compatible with streaming dongles
Built-in battery and compact design
Integrated 1,5 Watts speaker
Projection size from 7”to 120”
Long LED lifetime
Connectable with Computer/Notebook, Tablet, Smartphone and
Gaming consoles via mini HDMI
Playback of video, photo and audio files from Micro-SD
Remote Control

Product view
1
Power button
On/Off - return
2
◄ Volume -
Previous / Decrease the volume
3
►Volume +
Next / Increase the volume
4
■ Enter
Play/pause - Select in Menu
5
Focus wheel
Adjust the picture focus
6
Audio out
3,5mm Aux-port
7
Mini HDMI
Video in with HDMI to mini HDMI
8
DC in
Micro USB for 5V/2A charging
9
Micro-SD
supports up to 64 GB
10
Indicator light
Blue and red LED
Power button: Press this button 5 seconds to shut on or off the
device. Short press to return under sub-menu. 
Volume plus and minus button: Press the two buttons to
increase or decrease volume. They can also be used in the menu
as selection and for next and previous.
Enter: Play and pause in the playback menu. Bring up the main
menu in HDMI-mode or system.
Lens: Do not touch directly the lens to avoid damage.
Air outlet: Do not cover the air-cooling opening during operation
to avoid burns.
Indicator light chart
LIGHT COLOR
PROJECTOR IS ON
PROJECTOR IS OFF
Red
Charging
Charging
Blue
Working
Full Charged

1
2
3
4
5
6
7
8
9
10

Remote control

1
Volume down
9
Exit
2
Volume up
10
Rewind
3
Enter / Media menu
11
Fast Forward
4
Move Up
12
Previous
5
Move Left
13
Next
6
Move Right
14
Play / Pause
7
Move Down
15
Mute
8
System menu
16
Stop
Power on / Power off
After charging the device fully the first time, it can be powered on
without power cable connection. The built-in battery will now power
the device:
Press the POWER button 5 seconds to turn on the device.
Press the POWER button 5 seconds again to turn off the device.
Hints
Between the remote control and remote-control receiving host,
do not put any items, in order to avoid blocking the signal.
Point the remote control to the back of the device to receive the
infrared radiation.
Such as long-term when not in use take out the battery form the
remote control to prevent battery leakage corrosion.
1
2
3
4
5
8
10
12
14
16
15
13
11
9
7
6

Do not put the remote control in high temperature or damp
places, in order to avoid damage.
Charging
Connect the power cable to the power adapter and a power socket
as shown in the picture below. Plug the micro-USB to the DC port
of the projector to charge the device. Full charging takes about 4
hours. A power bank or a USB charging adapter can also be used
for charging. Please note the max. output of 5V and 2A.
Note: The battery capacity status will be shown on the upper corner
of the projectors main screen.
Icon (red) will appear on the screen when the power adapter
is connected or when the battery is full.
Icon (black) will appear on the screen when the projector is
running low on battery.
Image focus
Put the device vertical to the projector screen or white wall. The
projection screen size is highly related to the distance from the
projector to the projected wall. Adjust the focus with the focus
adjustment wheel (5) until the image is clear enough. Then the
focus is finished. During the focusing, you could display video or
display the menu to check the adjustment.

The device does not have keystone correction function. Adjust
the projector manually to the wall for the best picture quality.
Please refer to the following table for the relationship between
projection distance and screen size:
Screen size (Unit: Inch)
Projection distance (Unit: Meter)
7
0.18
38
1
56
1.5
120
2.5
Connections
Audio output:
AUX-port is for external speakers or headphones connected with
3.5mm jack cable.
MicroSD card
Plug the micro-SD card facing up the chips into the projector and
slide in place until it clicks. A blue memory icon will appear in the
upper right corner of the screen.
HDMI input:
Projecting the display screen from computers, DVs, DSC or other
HDMI source devices like PS4, Xbox or any game consoles via
HDMI cable connection. Please use the attached HDMI to Mini-
HDMI adaptor cable for HDMI connection.
Note: The projector supports streaming sticks like FireTV
and Google Chromecast, MHL and iPush connection.

Multimedia main screen
The screen display takes about 10 seconds to come into the
multimedia screen after power on.
Movie
Accesses the video files on your micro-SD card.
Music
Accesses the music files on your micro-SD card.
Picture
Accesses the image files on your micro-SD card.
Wifi Display
Allows you to connect to a mobile device via Wi-Fi.
HDMI
Connects the projector to an external device via the HDMI cable.
Setup
Opens the settings menu
To use the movie, music or picture mode, a micro-SD card has to
be installed. Face the micro-SD card with the chip up and slide it
into the slot until it clicks into place. Use the keys on the projector
or on the remote control to select movies, pictures or music.

Setup options
Change the language of the projector –multiple languages are
available
Restore to default –restores to factory settings
Do not use the option “Software update”. This is for manufacturer
maintenance only.
Supported multimedia files format for microSD card
Audio file: MP3 / WMA / VLC / OGG / AAC / WAV / FLAC
Video file: AVI /MKV / FLV / MOV / MP4 / MPG / MEP / M4V /
VOB / MTS / WEBM
Picture file: JPEG / BMP / PNG
Note: Due to the copyright issue of Dolby, this projector does NOT
support Dolby audio decoding. Dolby audio files can be played with
HDMI connection.
This product is NOT recommended for PPT, Word, Excel or
business presentation
To connect the mini projector with iPad or iPhone, you need a
wireless HDMI adapter
For Android phone which supports MHL, you need an MHL to
HDMI cable; for iPhone/iPad, you need a lighting to HDMI adapter
cable
To provide the best picture quality for the mini video projector
with PC/Notebook, adjust the PC/Notebook display resolution to
800x600 or 1024x768
It only provides clear images in dark rooms
64GB Micro-SD cards has to be in NTFS format

File explorer functions
Select the file category you want to play in the main menu screen.
Select the file which should be played. Press the play button on the
device or press the play button on the remote control for instant
play the file.
You can also mark the files with pressing “OK”on the remote
control. Multiple selections are possible. The projector will
automatically generate a playlist from the selected files. Press the
play button on the remote to start playing the selected files.
Note: just one file category can be selected.
WiFi Display mode
This mode is for wireless connection with Android only. Apple
devices cannot be used in this mode due to copyright issue.
Select Android for wireless connection with Android devices.
Two options are possible:
Miracast –streaming directly via Android “Smart View”
or
DLNA –wireless connection via built-in Wi-Fi receiver

For the Miracast option:
Choose Miracast and press “OK”or the Enter button on the device.
Follow the instructions on the screen.
For Samsung OS select in the extended panel “Smart View”and
the projector will appear with his serial number “S6-XXXX”.
Note: Different brands may have different wireless connection
names and settings. Please refer to the manual of each device.
After successfully connected, the projector will be mirroring your
Android smartphone or tablet screen.
For the DLNA option:
Choose DLNA and press “OK”or the Enter button on the device.
Now the projector is turned into a Wi-Fi hotspot and you can
connect via Wi-Fi with the projector. Please refer to the manual of
each device.
APPs with this sign “”can be streamed to the projector.

Follow the instructions on the screen. Please refer to the manual of
each device.
Note: In this mode, your smartphone has a Wi-Fi connection with
the projector. If an internet connection is required you have to use
the phone's data plan or set a connection to your home Wi-Fi first.
WiFi
Select this option for an internet connection between home Wi-Fi
and projector.
Scan Choose your Wi-Fi Type in password Connected
Now you will also have an internet connection in the DLNA
function.
Settings
In the settings option you can online update the device, factory
reset the options like Wi-Fi and see the actual firmware version.
FAQ
Q: Why is the projector’s blue indicator on, but the projection
screen has not turned on?
A: Make sure not to press and hold the power key too long.
Release the power key as soon as the blue indicator is on. Please
be patient and not push the power key repeatedly while the
projector system is booting. Otherwise this may cause the projector
to become stuck.
Q: Why it is not playing the files from my micro-SD card?
A: Please check:
1. If the capacity of the micro-SD card is higher than 64GB. The
capacity supported by the projector is only up to 64GB.
2. If the micro-SD card is not standard compliant.
3. The micro-SD card should be formatted in NTFS or FAT32.
Q: Why can some movies not be played?
A: In this case, there are several possibilities:
1. The file size is too large.

2. The video resolution is higher than 1080p. The supported
resolution is only up to 1080p.
3. The file format is not supported. Please refer to the video
format support list in the micro-SD card section.
Q: Why does my movie not playing sound?
A: Due to the copyright issue of Dolby, this projector does not
support Dolby audio decoding. You might not get sound from
videos if they use Dolby audio decoding.
Q: What should I do if the projector system has crashed or is
stuck?
A: In this case, there are several possibilities that may cause the
system to crash.
1. The computing power of the projector cannot catch up the
one of the connected devices.
2. The display resolutions between the projector and the
connected device do not match.
The possible solution is to restart the projector. Then the projector
will work normally.
Hints
Make sure you lay the cable in a way that the danger of stumbling is
avoided. Ensure that the power adapter does not come into contact
with water, steam or other liquids.
You have to check the complete construction at regular intervals for
functionality, tightness and damage to prevent the defect of the device.
Install the product due to this user manual and operate or maintain it
in accordance with the manufacturers operating instructions. Only use
the product for purposes due to its intended function & only for
household use. Do not damage the product. Following cases may
damage the product: Incorrect voltage, accidents (including liquid or
moisture), misuse or abuse of the product, faulty or improper
installation, mains supply problems including power spikes or lightning
damage, infestation by insects, tampering or modification of the product
by persons other than authorized service personnel, exposure to
abnormally corrosive materials, insertion of foreign objects into the unit,

used with accessories not preapproved. Refer to and heed all
warnings and precautions in the user manual.

Technical specifications
Safety instructions
Use standard power cord with ground wire, to ensure stable power
supply and the same power voltage with the product marked. Do not
disassemble the product by yourself, otherwise we will not provide free
warranty service. Do not look into the lens when the projector is
working, otherwise it will damage your eyes easily. Do not cover the
product’s ventilation hole. Keep the product away from rain, moisture,
water or any other liquid as it is not waterproof. It may cause an electric
shock. Turn off and cut off the power supply if not use the product for
a long time. Use the original packing when moving the product.
Projection technic
TI DLP RGB LED
Light source
LED RGB OSRAM
Power supply
Micro-USB DC 5V / 2A
Projection size / distance
7”–120”/ 0,2-2,5m
Projector consumption / brightness
5,8W / 100 Lumen ANSI
Native resolution
854*480 (FWVGA)
Refresh rate
60Hz
Contrast ration
1000:1
LED Lifetime
30000 hours
Working time
~2 hours in battery mode
Built-in speaker
8Ω 1.5W(x1)
Signal ports
Mini HDMI input (480i, 480p, 576i, 720p, 1080i,
1080p)
Headphone Output (3.5mm AUX)
MicroSD card format
Video: AVI /MKV / FLV / MOV / MP4 / MPG /
MEP / M4V / VOB / MTS / WEBM
Music: AAC/FLAC/M4A/OGG/MP3/WAV/WMA
Photo: PNG/BMP/JPEG/JPG
MicroSD card size
max. 64GB
Battery capacity /
power
2500mAh /3.7V
Weight / Dimensions
174g / (L) 55 x (W) 55 x (H) 55mm
Packing contents
Technaxx®Mini DLP Beamer TX-126, 1x
Remote control, 1x HDMI to mini HDMI cable,
1x HDMI to mini HDMI adapter, mini tripod, 1x
power cable, user manual

Hints for Environment Protection: Packages
materials are raw materials and can be recycled. Do
not disposal old devices or batteries into the
domestic waste. Cleaning: Protect the device from
contamination and pollution. Avoid using rough,
coarse-grained materials or solvents/aggressive
cleaner. Wipe the cleaned device accurately.
Distributor: Technaxx Deutschland GmbH & Co.KG,
Kruppstr. 105, 60388 Frankfurt a.M., Germany
