Panasonic Projector RS-232C Control Specifications
PT-DW10000/D10000

2/62
Using the Serial Terminals
Transmission from the computer begins with STX, then the ID, command, parameter, and ETX are sent in this
order. Add parameters according to the details of control.
Basic control command (without parameter)
Start
(STX)
ID Separator
(semicolon) Command End (ETX)
1 byte 4 bytes 1 byte 3 bytes 1 byte
Basic control command (with parameters)
Start
(STX) ID Separator (semicolon) Command Separator (colon) Parameters End (ETX)
1 byte 4 bytes 1 byte 3 bytes 1 byte Undefined length 1 byte
ID of the basic control command
ID 4 bytes
String ID 4 bytes
String ID 4 bytes
String ID 4 bytes
String
ALL ADZZ
ID23 AD23 ID46 AD46 Group E AD0E
ID1 AD01
ID24 AD24 ID47 AD47 Group F AD0F
ID2 AD02
ID25 AD25 ID48 AD48 Group-G AD0G
ID3 AD03
ID26 AD26 ID49 AD49 Group H AD0H
ID4 AD04
ID27 AD27 ID50 AD50 Group I AD0I
ID5 AD05
ID28 AD28 ID51 AD51 Group J AD0J
ID6 AD06
ID29 AD29 ID52 AD52 Group K AD0K
ID7 AD07
ID30 AD30 ID53 AD53 Group L AD0L
ID8 AD08
ID31 AD31 ID54 AD54 Group M AD0M
ID9 AD09
ID32 AD32 ID55 AD55 Group N AD0N
ID10 AD10
ID33 AD33 ID56 AD56 Group O AD0O
ID11 AD11
ID34 AD34 ID57 AD57 Group P AD0P
ID12 AD12
ID35 AD35 ID58 AD58 Group Q AD0Q
ID13 AD13
ID36 AD36 ID59 AD59 Group R AD0R
ID14 AD14
ID37 AD37 ID60 AD60 Group S AD0S
ID15 AD15
ID38 AD38 ID61 AD61 Group T AD0T
ID16 AD16
ID39 AD39 ID62 AD62 Group U AD0U
ID17 AD17
ID40 AD40 ID63 AD63 Group V AD0V
ID18 AD18
ID41 AD41 ID64 AD64 Group W AD0W
ID19 AD19
ID42 AD42 Group A AD0A Group X AD0X
ID20 AD20
ID43 AD43 Group B AD0B Group Y AD0Y
ID21 AD21
ID44 AD44 Group C AD0C Group Z AD0Z
ID22 AD22
ID45 AD45 Group D AD0D
1. Basic Forma
t

3/62
Response (Callback) of the basic control command
In the period when commands can be accepted
Differs according to each command.
In the period when commands cannot be accepted
Hexadecimal 02h 45h 52h 34h 30h 31h 03h
Character E R 4 0 1
In case of the parameter error
Hexadecimal 02h 45h 52h 34h 30h 32h 03h
Character E R 4 0 2
Notes when two or more projectors are used
• Make the communication conditions the same between output/input. IN and OUT can be independently
set respectively. (When you set RS-422 OUT of the first projector to 38 400 bps, set RS-422 IN of the
second projector to 38 400 bps.)
• Make only one in VPS SYSTEM MASTER and make all of the remainder VPS SYSTEM SLAVE.
• Set ID number different in each projector.
• I/O to RS-422 OUT is not done during MAIN POWER OFF. Turn on MAIN POWER of all projectors.
• Make only one of the each group in GROUP MASTER and make all the remainder-GROUP SLAVE.
Attention:
• No command may be sent or received for 10 to 60 seconds after the lamp starts lighting. Try sending
any command after that period has elapsed.
• When sending several commands, be sure to wait for a response from the projector, and send the next
command after 0.5 seconds or more pass.
• It might take time by the time the response returns because the command is processed in the projector.
Set the time-out to ten seconds or more.
Notes:
• This projector will respond to the computer only in the following cases:
If the sent ID coincides with the projector ID,
VPS SYSTEM in RS232C settings of this projector is MASTER and the sent ID is ALL, or
If-Group (A—Z) of the sent ID coincides with GROUP in RS232C settings of this projector and
GROUP in RS232C settings of this projector is MASTER.
• When the command is received during STNDBY, this projector returns the receiving command as it is as
a response (callback) if it is in the period when the concerned command cannot be accepted.
• Each setting/query command concerning P IN P controls to information on the user being set by current
P IN P setting. Therefore, ER401 is returned as a response (callback) when P IN P setting is OFF.

4/62
Explanatory notes
Yes: Enable
No: Disable
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 50h 4Fh 4Eh 03h
Character A D Z Z ; P O N
Response (Callback)
In the period when the command can be accepted (This command in power-on condition is included)
Hexadecimal 02h 50h 4Fh 4Eh 03h
Character P O N
Acceptability
Notes:
• When you confirm whether to have succeeded in power-on, confirm it by QPW (query power condition) command after
receiving the callback of PON command.
• When REMOTE2 is effective, ER401 is returned as a response (callback).
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 50h 4Fh 46h 03h
Character A D Z Z ; P O F
Response (Callback)
In the period when the command can be accepted (This command in power-off condition is included)
Hexadecimal 02h 50h 4Fh 46h 03h
Character P O F
Acceptability
SECURITY STNDBY NO SIGNAL SHUTTER TEST PATTERN REMOTE2
Yes Yes Yes Yes Yes (Yes)
Notes:
• When you confirm whether to have succeeded in power-off, confirm it by QPW (Query Power) command after receiving
the callback of POF command.
• When REMOTE2 is effective, ER401 is returned as a response (callback).
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 4Fh 41h 53h 03h
Character A D Z Z ; O A S
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 4Fh 41h 53h 03h
Character O A S
Acceptability
SECURITY STNDBY NO SIGNAL SHUTTER TEST PATTERN REMOTE2
No No No No No Yes
Note:
• This command is acceptable only when RGB1 or RGB2 is selected and RGB PC signals are input. In other cases, ER401
is returned.
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 4Fh 53h 48h 3Ah *1 03h
Character A D Z Z ; O S H : *2
Parameters (*1, *2)
Shutter OFF Shutter ON
Hexadecimal 30h 31h
Character 0 1
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 4Fh 53h 48h 3Ah *1 03h
Character O S H : *2
Acceptability
SECURITY STNDBY NO SIGNAL SHUTTER TEST PATTERN REMOTE2
Yes No Yes Yes Yes (Yes)
Note:
• The setting by REMOTE2 is given to priority. When a command different from the setting of REMOTE2 is sent, ER402 is
returned.
2. Basic Control Command
2.1. Power ON (Lamp ON)
SECURITY STNDBY NO SIGNAL SHUTTER TEST PATTERN REMOTE2
Yes Yes Yes Yes Yes (Yes)
2.2. Power OFF (Standby)
2.3. AUTO SETUP
2.4. SHUTTER

5/62
Hexadecimal
02h
41h
44h
5Ah
5Ah
3Bh
49h
49h
53h
3Ah
*1 *3 *5 03h
Character A D Z Z ; I I S : *2 *4 *6
Parameters (*1, *2, *3, *4, *5, *6)
RGB1 RGB2
Hexadecimal
52h 47h 31h 52h 47h 32h
Character R G 1 R G 2
VIDEO S-VIDEO
Hexadecimal
56h 49h 44h 53h 56h 44h
Character V I D S V D
DVI AUX
Hexadecimal
44h 56h 49h 41h 55h 58h
Character D V I A U X
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 49h 49h 53h 3Ah *1 *3 *5 03h
Character I I S : *2 *4 *6
Acceptability
SECURITY
STNDBY
NO SIGNAL
SHUTTER
TEST PATTERN
REMOTE2
Yes No Yes Yes Yes (Yes)
Notes:
• REMOTE2 is given to priority. Calls back ER402 if the input select of REMOTE2 is available.
• When AUX is specified for the parameter with incompatible input module installed in the slot, ER401 is returned.
• When AUX is specified for the parameter with no input module installed in the slot, ER402 is returned.
Hexadecimal
02h 41h 44h 5Ah 5Ah 3Bh 4Fh 54h 53h 3Ah *1 *3 03h
Character A D Z Z ; O T S : *2 *4
Parameters (*1, *2, *3, *4)
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 4Fh 54h 53h 3Ah *1 *3 03h
Character O T S : *2 *4
Acceptability
SECURITY
STNDBY
NO SIGNAL
SHUTTER
TEST PATTERN
REMOTE2
Yes No Yes Yes Yes Yes
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 4Fh 4Fh 53h 3Ah *1 03h
Character A D Z Z ; O O S : *2
Parameters (*1, *2)
Shutter OFF Shutter ON
Hexadecimal
30h 31h
Character 0 1
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 4Fh 4Fh 53h 3Ah *1 03h
Character O O S : *2
Acceptability
SECURITY
STNDBY
NO SIGNAL
SHUTTER
TEST PATTERN
REMOTE2
No No Yes No Yes Yes
Note:
• When the display setting of SECURITY is not OFF, ER401 is returned.
2.5. Input Change
2.6. TEST PATTERN
OFF White Black Flag Reversed flag
Hexadecimal 30h 30h 30h 31h 30h
32h 30h 33h 30h 34h
Character 0 0 0 1 0 2 0 3 0 4
Window Reversed
window Focus Color bar Gray 1 (20% brightness)
Hexadecimal 30h 35h 30h 36h 30h
37h 30h 38h 31h 30h
Character 0 5 0 6 0 7 0 8 1 0
Ramp White Red Green Blue
Hexadecimal 31h 31h 32h 31h 32h
32h 32 33 32h 34h
Character 1 1 2 1 2 2 2 3 2 4
10% brightness
(White) 5% brightness (White) Cyan Magenta Yellow
Hexadecimal 32h 35h 32h 36h 32h
38h 32h 39h 33h 30h
Character 2 5 2 6 2 8 2 9 3 0
2.7. ON SCREEN

6/62
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 4Fh 4Dh 4Eh 03h
Character A D Z Z ; O M N
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 4Fh 4Dh 4Eh 03h
Character O M N
Acceptability
SECURITY STNDBY NO SIGNAL SHUTTER TEST PATTERN REMOTE2
Yes No Yes No Yes Yes
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 4Fh 45h 4Eh 03h
Character A D Z Z ; O E N
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 4Fh 45h 4Eh 03h
Character O E N
Acceptability
SECURITY STNDBY NO SIGNAL SHUTTER TEST PATTERN REMOTE2
Yes No Yes No Yes Yes
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 4Fh 43h 55h 03h
Character A D Z Z ; O C U
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 4Fh 43h 55h 03h
Character O C U
Acceptability
SECURITY STNDBY NO SIGNAL SHUTTER TEST PATTERN REMOTE2
Yes No Yes No Yes Yes
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 4Fh 43h 44h 03h
Character A D Z Z ; O C D
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 4Fh 43h 44h 03h
Character O C D
Acceptability
SECURITY STNDBY NO SIGNAL SHUTTER TEST PATTERN REMOTE2
Yes No Yes No Yes Yes
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 4Fh 43h 4Ch 03h
Character A D Z Z ; O C L
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 4Fh 43h 4Ch 03h
Character O C L
Acceptability
SECURITY STNDBY NO SIGNAL SHUTTER TEST PATTERN REMOTE2
Yes No Yes No Yes Yes
2.8. MENU key
2.9. ENTER key
2.10. Up () key
2.11. Down () key
2.12. Left () key

7/62
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 4Fh 43h 52h 03h
Character A D Z Z ; O C R
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 4Fh 43h 52h 03h
Character O C R
Acceptability
SECURITY STNDBY NO SIGNAL SHUTTER TEST PATTERN REMOTE2
Yes No Yes No Yes Yes
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 4Fh 53h 54h 03h
Character A D Z Z ; O S T
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 4Fh 53h 54h 03h
Character O S T
Acceptability
SECURITY STNDBY NO SIGNAL SHUTTER TEST PATTERN REMOTE2
No No No Yes Yes
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 46h 43h 31h 03h
Character A D Z Z ; F C 1
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 46h 43h 31h 03h
Character F C 1
Acceptability
SECURITY STNDBY NO SIGNAL SHUTTER TEST PATTERN REMOTE2
No No (Yes) (Yes) (Yes) (Yes)
Note:
• The acceptability conforms to the function allocated in FUNC1.
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 4Fh 53h 4Ch 03h
Character A D Z Z ; O S L
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 4Fh 53h 4Ch 03h
Character O S L
Acceptability
SECURITY STNDBY NO SIGNAL SHUTTER TEST PATTERN REMOTE2
No No Yes Yes Yes Yes
Note:
• When the input signal is not switchable, ER401 is returned.
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 4Fh 4Eh 4Bh 3Ah *1 03h
Character A D Z Z ; O N K : *2
Parameters (*1, *2)
0 key 1 key 2 key 3 key 4 key 5 key 6 key 7 key 8 key 9 key
Hexadecimal 30h 31h 32h 33h 34h 35h 36h 37h 38h 39h
Character 0 1 2 3 4 5 6 7 8 9
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 4Fh 4Eh 4Bh 3Ah *1 03h
Character O N K : *2
Acceptability
SECURITY STNDBY NO SIGNAL SHUTTER TEST PATTERN REMOTE2
No No Yes No Yes Yes
2.13. Right () key
2.14. DEFAULT key
2.15. FUNC1 key
2.16. SYSTEM SELECTOR
2.17. Numeric key

8/62
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 4Ch 50h 4Dh 3Ah *1 *3 03h
Character A D Z Z ; L P M : *2 *4
Parameters (*1, *2, *3, *4)
QUAD L1/L4 L2/L3 DUAL L1/L2/L3
Hexadecimal 30h 30h 30h 31h 30h 32h 33h 33h 30h 34h
Character 0 0 0 1 0 2 0 3 0 4
L1/L2/L4 L1/L3/L4 L2/L3/L4 TRIPLE L1
Hexadecimal 30h 35h 30h 36h 30h 37h 30h 38h 30h 39h
Character 0 5 0 6 0 7 0 8 0 9
L2 L3 L4 SINGLE
Hexadecimal 31h 30h 31h 31h 31h 32h 31h 33h
Character 1 0 1 1 1 2 1 3
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 4Ch 50h 4Dh 3Ah *1 *3 03h
Character L P M : *2 *4
Acceptability
SECURITY STNDBY NO SIGNAL SHUTTER TEST PATTERN REMOTE2
No Yes Yes Yes Yes Yes
Note:
• During the lamp change processing, ER401 is returned.
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 4Fh 49h 4Ch 3Ah *1 03h
Character A D Z Z ; O I L : *2
Parameters (*1, *2)
FRONT-F REAR-F FRONT-C REAR-C
Hexadecimal 30h 31h 32h 33h
Character 0 1 2 3
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 4Fh 49h 4Ch 3Ah *1 03h
Character O I L : *2
Acceptability
SECURITY STNDBY NO SIGNAL SHUTTER TEST PATTERN REMOTE2
No Yes Yes Yes Yes Yes
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 4Fh 43h 53h 3Ah
Character A D Z Z ; O C S :
Hexadecimal *1 *3 03h
Character *2 *4
Parameters (*1, *2, *3, *4)
*nn of submemory number (mm—nn)
01 02 03 04
Hexadecimal 30h 31h 30h 32h 30h 33h 30h 34h
Character 0 1 0 2 0 3 0 4
93 94 95 96
Hexadecimal 39h 33h 39h 34h 39h 35h 39h 36h
Character 9 3 9 4 9 5 9 6
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 4Fh 43h 53h 3Ah *1 *3 03h
Character O C S : *2 *4
Acceptability
SECURITY STNDBY NO SIGNAL SHUTTER TEST PATTERN REMOTE2
No No No Yes Yes Yes
2.18. LAMP SELECT
2.19. INSTALLATION
2.20. SUB MEMORY CHANGE

9/62
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 4Fh 43h 53h 3Ah
Character A D Z Z ; O C S :
Hexadecimal *1 *3 2Dh *5 *7 03h
Character *2 *4 *6 *8
Parameters
mm of submemory number (mm–nn) (*1,*2,*3,*4)
01 02 03 04
Hexadecimal 30h 31h 30h 32h 30h 33h 30h 34h
Character 0 1 0 2 0 3 0 4
92 93 94 95
Hexadecimal 39h 32h 39h 33h 39h 34h 39h 35h
Character 9 2 9 3 9 4 9 5
nn of submemory number (mm–nn) (*5, *6, *7, *8)
01 02 03 04
Hexadecimal 30h 31h 30h 32h 30h 33h 30h 34h
Character 0 1 0 2 0 3 0 4
93 94 95 96
Hexadecimal 39h 33h 39h 34h 39h 35h 39h 36h
Character 9 3 9 4 9 5 9 6
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 4Fh 43h 53h 3Ah *1 *3 2Dh *5 *7 03h
Character O C S : *2 *4 *6 *8
Acceptability
SECURITY STNDBY NO SIGNAL SHUTTER TEST PATTERN REMOTE2
No No No Yes Yes Yes
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 4Fh 45h 53h 03h
Character A D Z Z ; O E S
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 4Fh 45h 53h 03h
Character O E S
Acceptability
SECURITY STNDBY NO SIGNAL SHUTTER TEST PATTERN REMOTE2
No No No Yes Yes Yes
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 4Fh 44h 53h 3Ah
Character A D Z Z ; O D S :
Hexadecimal *1 *3 2Dh *5 *7 03h
Character *2 *4 *6 *8
Parameters (*1, *2, *3, *4, *5, *6)
mm of submemory number (mm–nn) (*1,*2)
01 02 03 04
Hexadecimal 30h 31h 30h 32h 30h 33h 30h 34h
Character 0 1 0 2 0 3 0 4
92 93 94 95
Hexadecimal 39h 32h 39h 33h 39h 34h 39h 35h
Character 9 2 9 3 9 4 9 5
nn of submemory number (mm–nn) (*3,*4)
01 02 03 04
Hexadecimal 30h 31h 30h 32h 30h 33h 30h 34h
Character 0 1 0 2 0 3 0 4
93 94 95 96
Hexadecimal 39h 33h 39h 34h 39h 35h 39h 36h
Character 9 3 9 4 9 5 9 6
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 4Fh 44h 53h 3Ah *1 *3 2Dh *5 *7 03h
Character O D S : *2 *4 *6 *8
Acceptability
SECURITY STNDBY NO SIGNAL SHUTTER TEST PATTERN REMOTE2
No No Yes Yes Yes Yes
2.21. SUB MEMORY CHANGE (Enhanced)
2.22. SUB MEMORY STORE
2.23. SUB MEMORY DELETE

10/62
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 56h 50h 4Dh 3Ah
Character A D Z Z ; V P M :
Hexadecimal *1 *3 *5 03h
Character *2 *4 *6
Parameters (*1, *2, *3, *4, *5, *6)
DYNAMIC GRAPHIC USER
Hexadecimal 44h 59h 4Eh 47h 52h 41h 55h 53h 52h
Character D Y N G R A U S R
STANDARD CINEMA NATURAL
Hexadecimal 53h 54h 44h 43h 49h 4Eh 4Eh 41h 54h
Character S T D C I N N A T
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 56h 50h 4Dh 3Ah *1 *3 *5 03h
Character V P M : *2 *4 *6
Acceptability
SECURITY STNDBY NO SIGNAL SHUTTER TEST PATTERN REMOTE2
No No Yes Yes Yes Yes
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 56h 43h 4Fh 3Ah
Character A D Z Z ; V C O :
Hexadecimal *1 *3 *5 03h
Character *2 *4 *6
Parameters (*1, *2, *3, *4, *5, *6)
0 1 2
Hexadecimal 30h 30h 30h 30h 30h 31h 30h 30h 32h
Character 0 0 0 0 0 1 0 0 2
98 99 100
Hexadecimal 30h 39h 38h 30h 39h 39h 31h 30h 30h
Character 0 9 8 0 9 9 1 0 0
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 56h 43h 4Fh 3Ah *1 *3 *5 03h
Character V C O : *2 *4 *6
Acceptability
SECURITY STNDBY NO SIGNAL SHUTTER TEST PATTERN REMOTE2
No No No Yes Yes Yes
Note:
• It is displayed in the menu by the value in which 50 is subtracted from the specified value.
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 56h 54h 4Eh 3Ah
Character A D Z Z ; V T N :
Hexadecimal *1 *3 *5 03h
Character *2 *4 *6
Parameters (*1, *2, *3, *4, *5, *6)
0 1 2
Hexadecimal 30h 30h 30h 30h 30h 31h 30h 30h 32h
Character 0 0 0 0 0 1 0 0 2
60 61 62
Hexadecimal 30h 36h 30h 30h 36h 31h 30h 36h 32h
Character 0 6 0 0 6 1 0 6 2
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 56h 54h 4Eh 3Ah *1 *3 *5 03h
Character V T N : *2 *4 *6
Acceptability
SECURITY STNDBY NO SIGNAL SHUTTER TEST PATTERN REMOTE2
No No No Yes Yes Yes
Note:
• It is displayed in the menu by the value in which 31 is subtracted from the specified value.
2.24. PICTURE MODE
2.25. COLOR
2.26. TINT

11/62
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 4Fh 54h 45h 3Ah
Character A D Z Z ; O T E :
Hexadecimal *1 *3 03h
Character *2 *4
Parameters (*1, *2, *3, *4)
LOW MIDDLE HIGH USER1 USER2 DEFAULT
Hexadecimal 30h 31h 32h 34h 39h 31h 30h
Character 0 1 2 4 9 1 0
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 4Fh 54h 45h 3Ah *1 *3 03h
Character O T E : *2 *4
Acceptability
SECURITY STNDBY NO SIGNAL SHUTTER TEST PATTERN REMOTE2
No No Yes Yes Yes Yes
Note:
• If you specify parameters other than USER1 when COLOR MATCHING is not OFF, ER402 is returned.
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 56h 4Fh 52h 3Ah
Character A D Z Z ; V O R :
Hexadecimal *1 *3 *5 03h
Character *2 *4 *6
Parameters (*1, *2, *3, *4, *5, *6)
1 2 3
Hexadecimal 30h 30h 31h 30h 30h 32h 30h 30h 33h
Character 0 0 1 0 0 2 0 0 3
253 254 255
Hexadecimal 32h 35h 33h 32h 35h 34h 32h 35h 35h
Character 2 5 3 2 5 4 2 5 5
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 56h 4Fh 52h 3Ah *1 *3 *5 03h
Character V O R : *2 *4 *6
Acceptability
SECURITY STNDBY NO SIGNAL SHUTTER TEST PATTERN REMOTE2
No No Yes Yes Yes Yes
Notes:
• When a parameter other than USER1 or USER2 is specified for COLOR TEMP., ER401 is returned.
• It is displayed in the menu by the value in which 128 is subtracted from the specified value.
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 56h 4Fh 47h 3Ah
Character A D Z Z ; V O G :
Hexadecimal *1 *3 *5 03h
Character *2 *4 *6
Parameters(*1,*2,*3,*4,*5,*6)
1 2 3
Hexadecimal 30h 30h 31h 30h 30h 32h 30h 30h 33h
Character 0 0 1 0 0 2 0 0 3
253 254 255
Hexadecimal 32h 35h 33h 32h 35h 34h 32h 35h 35h
Character 2 5 3 2 5 4 2 5 5
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 56h 4Fh 47h 3Ah *1 *3 *5 03h
Character V O G : *2 *4 *6
Acceptability
SECURITY STNDBY NO SIGNAL SHUTTER TEST PATTERN REMOTE2
No No Yes Yes Yes Yes
Notes:
•When a parameter other than USER1 or USER2 is specified for COLOR TEMP., ER401 is returned.
• It is displayed in the menu by the value in which 128 is subtracted from the specified value.
2.27. COLOR TEMP.
2.28. WHITE BALANCE LOW — R
2.29. WHITE BALANCE LOW — G

12/62
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 56h 4Fh 42h 3Ah
Character A D Z Z ; V O B :
Hexadecimal *1 *3 *5 03h
Character *2 *4 *6
Parameters (*1, *2, *3, *4, *5, *6)
1 2 3
Hexadecimal 30h 30h 31h 30h 30h 32h 30h 30h 33h
Character 0 0 1 0 0 2 0 0 3
253 254 255
Hexadecimal 32h 35h 33h 32h 35h 34h 32h 35h 35h
Character 2 5 3 2 5 4 2 5 5
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 56h 4Fh 42h 3Ah *1 *3 *5 03h
Character V O B : *2 *4 *6
Acceptability
SECURITY STNDBY NO SIGNAL SHUTTER TEST PATTERN REMOTE2
No No Yes Yes Yes Yes
Notes:
• When a parameter other than USER1 or USER2 is specified for COLOR TEMP., ER401 is returned.
• It is displayed in the menu by the value in which 128 is subtracted from the specified value.
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 56h 48h 52h 3Ah
Character A D Z Z ; V H R :
Hexadecimal *1 *3 *5 03h
Character *2 *4 *6
Parameters (*1, *2, *3, *4, *5, *6)
0 1 2
Hexadecimal 30h 30h 30h 30h 30h 31h 30h 30h 32h
Character 0 0 0 0 0 1 0 0 2
253 254 255
Hexadecimal 32h 35h 33h 32h 35h 34h 32h 35h 35h
Character 2 5 3 2 5 4 2 5 5
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 56h 48h 52h 3Ah *1 *3 *5 03h
Character V H R : *2 *4 *6
Acceptability
SECURITY STNDBY NO SIGNAL SHUTTER TEST PATTERN REMOTE2
No No Yes Yes Yes Yes
Note:
• When a parameter other than USER1 or USER2 is specified for COLOR TEMP., ER401 is returned.
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 56h 48h 47h 3Ah
Character A D Z Z ; V H G :
Hexadecimal *1 *3 *5 03h
Character *2 *4 *6
Parameters (*1, *2, *3, *4, *5, *6)
0 1 2
Hexadecimal 30h 30h 30h 30h 30h 31h 30h 30h 32h
Character 0 0 0 0 0 1 0 0 2
253 254 255
Hexadecimal 32h 35h 33h 32h 35h 34h 32h 35h 35h
Character 2 5 3 2 5 4 2 5 5
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 56h 48h 47h 3Ah *1 *3 *5 03h
Character V H G : *2 *4 *6
Acceptability
SECURITY STNDBY NO SIGNAL SHUTTER TEST PATTERN REMOTE2
No No Yes Yes Yes Yes
Note:
• When a parameter other than USER1 or USER2 is specified for COLOR TEMP., ER401 is returned.
2.30. WHITE BALANCE LOW — B
2.31. WHITE BALANCE HIGH — R
2.32. WHITE BALANCE HIGH — G

13/62
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 56h 48h 42h 3Ah
Character A D Z Z ; V H B :
Hexadecimal *1 *3 *5 03h
Character *2 *4 *6
Parameters (*1, *2, *3, *4, *5, *6)
0 1 2
Hexadecimal 30h 30h 30h 30h 30h 31h 30h 30h 32h
Character 0 0 0 0 0 1 0 0 2
253 254 255
Hexadecimal 32h 35h 33h 32h 35h 34h 32h 35h 35h
Character 2 5 3 2 5 4 2 5 5
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 56h 48h 42h 3Ah *1 *3 *5 03h
Character V H B : *2 *4 *6
Acceptability
SECURITY STNDBY NO SIGNAL SHUTTER TEST PATTERN REMOTE2
No No Yes Yes Yes Yes
Note:
• When a parameter other than USER1 or USER2 is specified for COLOR TEMP., ER401 is returned.
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 56h 43h 4Eh 3Ah
Character A D Z Z ; V C N :
Hexadecimal *1 *3 *5 03h
Character *2 *4 *6
Parameters (*1, *2, *3, *4, *5, *6)
1 2 3
Hexadecimal 30h 30h 31h 30h 30h 32h 30h 30h 33h
Character 0 0 1 0 0 2 0 0 3
61 62 63
Hexadecimal 30h 36h 31h 30h 36h 32h 30h 36h 33h
Character 0 6 1 0 6 2 0 6 3
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 56h 43h 4Eh 3Ah *1 *3 *5 03h
Character V C N : *2 *4 *6
Acceptability
SECURITY STNDBY NO SIGNAL SHUTTER TEST PATTERN REMOTE2
No No No Yes Yes Yes
Note:
• It is displayed in the menu by the value in which 32 is subtracted from the specified value.
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 56h 42h 52h 3Ah
Character A D Z Z ; V B R :
Hexadecimal *1 *3 *5 03h
Character *2 *4 *6
Parameters (*1, *2, *3, *4, *5, *6)
1 2 3
Hexadecimal 30h 30h 31h 30h 30h 31h 30h 30h 33h
Character 0 0 1 0 0 2 0 0 3
61 62 63
Hexadecimal 30h 36h 30h 30h 36h 31h 30h 36h 32h
Character 0 6 1 0 6 2 0 6 3
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 56h 42h 52h 3Ah *1 *3 *5 03h
Character V B R : *2 *4 *6
Acceptability
SECURITY STNDBY NO SIGNAL SHUTTER TEST PATTERN REMOTE2
No No No Yes Yes Yes
Note:
• It is displayed in the menu by the value in which 32 is subtracted from the specified value.
2.33. WHITE BALANCE HIGH — B
2.34. CONTRAST
2.35. BRIGHTNESS

14/62
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 56h 53h 52h 3Ah
Character A D Z Z ; V S R :
Hexadecimal *1 *3 *5 03h
Character *2 *4 *6
Parameters (*1, *2, *3, *4, *5, *6)
0 1 2
Hexadecimal 30h 30h 30h 30h 30h 31h 30h 30h 32h
Character 0 0 0 0 0 1 0 0 2
13 14 15
Hexadecimal 30h 31h 33h 30h 31h 34h 30h 31h 35h
Character 0 1 3 0 1 4 0 1 5
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 56h 53h 52h 3Ah *1 *3 *5 03h
Character V S R : *2 *4 *6
Acceptability
SECURITY STNDBY NO SIGNAL SHUTTER TEST PATTERN REMOTE2
No No No Yes Yes Yes
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 56h 4Eh 53h 3Ah
Character A D Z Z ; V N S :
Hexadecimal *1 03h
Character *2
Parameters (*1, *2)
OFF ON or 1 2 3
Hexadecimal 30h 31h 32h 33h
Character 0 1 2 3
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 56h 4Eh 53h 3Ah *1 03h
Character V N S : *2
Acceptability
SECURITY STNDBY NO SIGNAL SHUTTER TEST PATTERN REMOTE2
No No No Yes Yes Yes
Notes:
• When FRAME DELAY is set to SHORT, ER401 is returned.
• During P IN P, ER401 is returned.
2.36. SHARPNESS
2.37. NOISE REDUCTION

15/62
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 4Fh 41h 49h 3Ah
Character A D Z Z ; O A I :
Hexadecimal *1 *3 *5 03h
Character *2 *4 *6
Parameters (*1, *2)
Mode OFF 1 2 3 USER AUTO
IRIS MANUAL IRIS DYNAMIC-GAMMA
Hexadecimal 30h 31h 32h 33h 34h 41h 4Dh 44h
Character 0 1 2 3 4 A M D
* When Mode is OFF—USER, parameters *3—*6 are not sent.
Example: When you set USER into Mode
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 4Fh 41h 49h 34h 03h
Character A D Z Z ; O A I 4
* When Mode is AUTO IRIS or DYNAMIC GAMMA, parameters *5 and *6 are not sent.
Example: When Mode is AUTO IRIS and you set 3 into AUTO IRIS
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 4Fh 41h 49h 3Ah
Character A D Z Z ; O A I :
Hexadecimal 41h 33h 03h
Character A 3
Example: When Mode is MANUAL IRIS and you set 30 into MANUAL IRIS
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 4Fh 41h 49h 3Ah
Character A D Z Z ; O A I :
Hexadecimal 4Dh 33h 30h 03h
Character M 3 0
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 4Fh 41h 49h 3Ah *1 03h
Character O A I : *2
Acceptability
SECURITY STNDBY NO SIGNAL SHUTTER TEST PATTERN REMOTE2
No No Yes Yes Yes Yes
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 4Fh 41h 49h 3Ah *1 03h
Character A D Z Z ; O A I : *2
Parameters (*1, *2)
OFF 1 2 3 USER
Hexadecimal 30h 31h 32h 33h 34h
Character 0 1 2 3 4
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 4Fh 41h 49h 3Ah *1 03h
Character O A I : *2
Acceptability
SECURITY STNDBY NO SIGNAL SHUTTER TEST PATTERN REMOTE2
No No Yes Yes Yes Yes
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 4Fh 41h 49h 3Ah
Character A D Z Z ; O A I :
Hexadecimal 41h *1 03h
Character A *2
Parameters (*1, *2)
OFF 1 2 3
Hexadecimal 30h 31h 32h 33h
Character 0 1 2 3
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 4Fh 41h 49h 3Ah 41h *1 03h
Character O A I : A *2
Acceptability
SECURITY STNDBY NO SIGNAL SHUTTER TEST PATTERN REMOTE2
No No Yes Yes Yes Yes
2.38. DYNAMIC IRIS
2.39. DYNAMIC IRIS
2.40. DYNAMIC IRIS (AUTO IRIS)

16/62
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 4Fh 41h 49h 3Ah
Character A D Z Z ; O A I :
Hexadecimal 4Dh *1 *3 03h
Character M *2 *4
Parameters (*1, *2, *3, *4)
OFF 1 2 3
Hexadecimal 30h 30h 30h 31h 30h 32h 30h 33h
Character 0 0 0 1 0 2 0 3
60 61 62 63
Hexadecimal 36h 30h 36h 31h 36h 32h 36h 33h
Character 6 0 6 1 6 2 6 3
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 4Fh 41h 49h 3Ah 4Dh *1 03h
Character O A I : M *2
Acceptability
SECURITY STNDBY NO SIGNAL SHUTTER TEST PATTERN REMOTE2
No No Yes Yes Yes Yes
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 4Fh 41h 49h 3Ah
Character A D Z Z ; O A I :
Hexadecimal 44h *1 03h
Character D *2
Parameters (*1, *2)
OFF 1 2 3
Hexadecimal 30h 31h 32h 33h
Character 0 1 2 3
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 4Fh 41h 49h 3Ah 44h *1 03h
Character O A I : D *2
Acceptability
SECURITY STNDBY NO SIGNAL SHUTTER TEST PATTERN REMOTE2
No No Yes Yes Yes Yes
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 56h 53h 47h 3Ah
Character A D Z Z ; V S G :
Hexadecimal *1 *3 *5 03h
Character *2 *4 *6
Parameters (*1, *2, *3, *4, *5, *6)
AUTO 1 AUTO 2 NTSC
Hexadecimal 41h 54h 31h 41h 54h 32h 4Eh 54h 53h
Character A T 1 A T 2 N T S
NTSC4.43 PAL PAL-M
Hexadecimal 4Eh 34h 34h 50h 41h 4Ch 50h 41h 4Dh
Character N 4 4 P A L P A M
PAL-N SECAM PAL60
Hexadecimal 50h 41h 4Eh 53h 45h 43h 50h 36h 30h
Character P A N S E C P 6 0
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 56h 53h 47h 3Ah *1 *3 *5 03h
Character V S G : *2 *4 *6
Acceptability
SECURITY STNDBY NO SIGNAL SHUTTER TEST PATTERN REMOTE2
No No Yes Yes Yes Yes
2.41. DYNAMIC IRIS (MANUAL IRIS)
2.42. DYNAMIC IRIS (DYNAMIC GAMMA)
2.43. TV-SYSTEM

17/62
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 56h 54h 48h 3Ah
Character A D Z Z ; V T H :
Hexadecimal *1 *3 *5 *7 03h
Character *2 *4 *6 *8
Parameters (*1, *2, *3, *4, *5, *6, *7, *8)
0 1 2
Hexadecimal 30h 30h 30h 30h 30h 30h 30h 31h 30h 30h 30h 2
Character 0 0 0 0 0 0 0 1 0 0 0 2
4093 4094 4095
Hexadecimal 34h 30h 39h 33h 34h 30h 39h 34h 34h 30h 39h 35h
Character 4 0 9 3 4 0 9 4 4 0 9 5
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 56h 54h 48h 3Ah *1 *3 *5 03h
Character V T H : *2 *4 *6
Acceptability
SECURITY STNDBY NO SIGNAL SHUTTER TEST PATTERN REMOTE2
No No No Yes No Yes
Note:
• The maximum value that can be actually set changes according to the input signal and the input resolution setting, etc.
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 56h 54h 56h 3Ah
Character A D Z Z ; V T V :
Hexadecimal *1 *3 *5 03h
Character *2 *4 *6
Parameters (*1, *2, *3, *4, *5, *6)
0 1 2
Hexadecimal 30h 30h 30h 30h 30h 30h 30h 31h 30h 30h 30h 32h
Character 0 0 0 0 0 0 0 1 0 0 0 2
4093 4094 4095
Hexadecimal 34h 30h 39h 33h 34h 30h 39h 34h 34h 30h 39h 35h
Character 4 0 9 3 4 0 9 4 4 0 9 5
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 56h 54h 56h 3Ah *1 *3 *5 03h
Character V T V : *2 *4 *6
Acceptability
SECURITY STNDBY NO SIGNAL SHUTTER TEST PATTERN REMOTE2
No No No Yes No Yes
Note:
• The maximum value that can be actually set changes according to the input signal and the input resolution setting, etc.
2.44. SHIFT H
2.45. SHIFT V

18/62
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 56h 53h 45h 3Ah
Character A D Z Z ; V S E :
Hexadecimal *1 *3 03h
Character *2 *4
Parameters (*1, *2, *3, *4)
• Input route: VIDEO
Input signal: NTSC
VID AUTO 4:3 *1 16:9 *2 S4:3 *2 THROUGH
Hexadecimal 30h 31h 32h 33h 35h
Character 0 1 2 3 5
HV FIT H FIT *1
Hexadecimal 36h 39h
Character 6 9
• Input route: VIDEO
Input signal: Except NTSC
DEFAULT 4:3 *1 16:9 *2 S4:3 *2 THROUGH
Hexadecimal 30h 31h 32h 33h 35h
Character 0 1 2 3 5
HV FIT H FIT *1
Hexadecimal 36h 39h
Character 6 9
• Input route: S-VIDEO
Input signal: NTSC
VID AUTO(PRI.) 4:3 *1 16:9 *2 S4:3 *2 THROUGH
Hexadecimal 30h 31h 32h 33h 35h
Character 0 1 2 3 5
HV FIT H FIT *1 S1 AUTO VID AUTO
Hexadecimal 36h 39h 32h 30h 33h 30h
Character 6 9 2 0 3 0
• Input route: S-VIDEO
Input signal: Except NTSC
DEFAULT 4:3 *1 16:9 *2 S4:3 *2 THROUGH
Hexadecimal 30h 31h 32h 33h 35h
Character 0 1 2 3 5
HV FIT H FIT *1
Hexadecimal 36h 39h
Character 6 9
• Input route: Except VIDEO/S-VIDEO
Input signal: SD
DEFAULT 16:9 *2 S4:3 *2 THROUGH
Hexadecimal 30h 32h 33h 35h
Character 0 2 3 5
HV FIT H FIT *1
Hexadecimal 36h 39h
Character 6 9
• Input route: Except VIDEO/S-VIDEO
Input signal: HD
DEFAULT 4:3 *1 S4:3 *2 THROUGH
Hexadecimal 30h 31h 33h 35h
Character 0 1 3 5
HV FIT H FIT *1
Hexadecimal 36h 39h
Character 6 9
*1: Because it is not able to specify it in D10000, ER402 is returned.
*2: Because it is not able to specify it in DW10000, ER402 is returned.
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 56h 53h 45h 3Ah *1 *3 03h
Character V S E : *2 *4
Acceptability
SECURITY STNDBY NO SIGNAL SHUTTER TEST PATTERN REMOTE2
No No No Yes No Yes
Notes:
• When it is not able to set it according to the input signal, ER402 is returned.
• Parameter *3 and *4 are specified only for two digits.
2.46. ASPECT

19/62
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 4Fh 5Ah 48h 3Ah
Character A D Z Z ; O Z H :
Hexadecimal *1 *3 *5 03h
Character *2 *4 *6
Parameters (*1, *2, *3, *4, *5, *6)
50 51 52
Hexadecimal 30h 35h 30h 30h 35h 31h 30h 35h 32h
Character 0 5 0 0 5 1 0 5 2
997 998 999
Hexadecimal 39h 39h 37h 39h 39h 38h 39h 39h 39h
Character 9 9 7 9 9 8 9 9 9
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 4Fh 5Ah 48h 3Ah *1 *3 *5 03h
Character O Z H : *2 *4 *6
Acceptability
SECURITY STNDBY NO SIGNAL SHUTTER TEST PATTERN REMOTE2
No No No Yes No Yes
Notes:
• When ASPECT is THROUGH, ER401 is returned.
• If INTERLOCKED is ON, set it to OFF.
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 4Fh 5Ah 56h 3Ah *1 *3 *5 03h
Character A D Z Z ; O Z V : *2 *4 *6
Parameters (*1, *2, *3, *4, *5, *6)
50 51 52
Hexadecimal 30h 35h 30h 30h 35h 31h 30h 35h 32h
Character 0 5 0 0 5 1 0 5 2
997 998 999
Hexadecimal 39h 39h 37h 39h 39h 38h 39h 39h 39h
Character 9 9 7 9 9 8 9 9 9
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 4Fh 5Ah 56h 3Ah *1 *3 *5 03h
Character O Z V : *2 *4 *6
Acceptability
SECURITY STNDBY NO SIGNAL SHUTTER TEST PATTERN REMOTE2
No No No Yes No Yes
Notes:
• When ASPECT is THROUGH, ER401 is returned.
• If INTERLOCKED is ON, set it to OFF.
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 56h 43h 50h 3Ah *1 *3 *5 03h
Character A D Z Z ; V C P : *2 *4 *6
Parameters (*1, *2, *3, *4, *5, *6)
0 1 2
Hexadecimal 30h 30h 30h 30h 30h 31h 30h 30h 32h
Character 0 0 0 0 0 1 0 0 2
29 30 31
Hexadecimal 30h 32h 39h 30h 33h 30h 30h 33h 31h
Character 0 2 9 0 3 0 0 3 1
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 56h 43h 50h 3Ah *1 *3 *5 03h
Character V C P : *2 *4 *6
Acceptability
SECURITY STNDBY NO SIGNAL SHUTTER TEST PATTERN REMOTE2
No No No Yes No Yes
Note:
• It is able to accept only when the selected slot is RGB1 or RGB2, and ER401 is returned besides.
2.47. ZOOM H
2.48. ZOOM V
2.49. CLOCK PHASE

20/62
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 56h 54h 44h 3Ah
Character A D Z Z ; V T D :
Hexadecimal *1 *3 *5 *7 03h
Character *2 *4 *6 *8
Parameters (*1, *2, *3, *4, *5, *6, *7, *8)
330 331
Hexadecimal 30h 33h 33h 30h 30h 33h 33h 31h
Character 0 3 3 0 0 3 3 1
4093 4094
Hexadecimal 34h 30h 39h 33h 34h 30h 39h 34h
Character 4 0 9 3 4 0 9 4
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 56h 54h 44h 3Ah *1 *3 *5 *7 03h
Character V T D : *2 *4 *6 *8
Acceptability
SECURITY STNDBY NO SIGNAL SHUTTER TEST PATTERN REMOTE2
No No No Yes Yes Yes
Notes:
• This command is acceptable only when RGB1 or RGB2 is selected and RGB signals are input. In other cases, ER401 is
returned.
•
The maximum value that can be actually set changes according to the input signal and the input resolution setting, etc.
• When less than number of display dots is specified, ER402 is returned.
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 56h 44h 44h 3Ah
Character A D Z Z ; V D D :
Hexadecimal *1 *3 *5 *7 03h
Character *2 *4 *6 *8
Parameters (*1, *2, *3, *4, *5, *6, *7, *8)
300 301
Hexadecimal 30h 33h 30h 30h 30h 33h 30h 31h
Character 0 3 0 0 0 3 0 1
2045 2046
Hexadecimal 24h 30h 34h 35h 32h 30h 34h 36h
Character 2 0 4 5 2 0 4 6
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 56h 44h 44h 3Ah *1 *3 *5 *7 03h
Character V D D : *2 *4 *6 *8
Acceptability
SECURITY STNDBY NO SIGNAL SHUTTER TEST PATTERN REMOTE2
No No No Yes Yes Yes
Notes:
• This command is acceptable only when RGB1 or RGB2 is selected and RGB signals are input. In other cases, ER401 is
returned.
• When the value that exceeds the number of total dots is specified, ER402 is returned.
2.50. INPUT RESOLUTION — TOTAL DOTS
2.51. INPUT RESOLUTION — DISPLAY DOTS
