AHIGHLY COMPACT AND AFFORDABLE
3LCD PROJECTOR, DELIVERING
PERFORMANCE, OPTICAL ZOOM AND
EXCELLENT CONNECTIVITY.
This versatile digital projector is the ideal
solution for those looking for performance
at a feel-good price. The Hitachi CP-RS57
can be used for a number of applications
including education, mobile business, home
use and even home theatre. With a
powerful 2000 ANSI Lumens and SVGA
resolution and weighing only 2.3Kg, the
CP-RS57 offers you more. The CP-RS57
uses Hitachi’s proprietary video-processing
circuits and 3LCD technology, which gives
better colour reproduction and higher
brightness than other technologies.
•SVGA Projector (800 x 600)
•Optical Zoom 1.2
•2000 ANSI Lumens
•Full Connectivity – 2 x RGB plus monitor out
• Video and Data Inputs
CP-RS57

Unit: mm
■
SVGA Projector (800 x 600)
■
Optical Zoom 1.2
■
2000 ANSI Lumens
■
Full Connectivity – 2 x RGB plus monitor out
■
Video and Data Inputs
Ahighly compact and affordable 3LCD projector, delivering
performance, optical zoom and excellent connectivity.
73
202
285
OPTICAL
LCD Panel 0.6" P-Si TFT with MLA x 3
Resolution 800 x 600
Brightness (Normal) 2000 ANSI Lumens
(Whisper) 1600 ANSI Lumens
Contrast Ratio 400:1 (typ)
Lens F1.6 x 1.2 Zoom (f=18.6~22.3mm), Manual Focus
Lamp 165W UHB
Focus Distance 1.2m~11.0m
Distance to Width Ratio (:1) 1.6
Diagonal Display Size 40~300" (60"@1.8m)
Colour Saturation x=0.30, y=0.35
Number of Colour 8 Bits/colour, 16.7M colours
COMPATIBILITY
Computer Compatibility IBM Compatible, VGA, SVGA, XGA, SXGA (Smart resizing),
UXGA capability, MAC 16" (Pixelworks Chip PW168A)
Video Compatibility NTSC/PAL(-BGDHI)/SECAM/PAL-M,N/NTSC4.43/PAL 60
SDTV:525i(480i), 525p(480p), 625i(575i)
HDTV: 750p (720p@60Hz), 1125i(1080i@50/60Hz)
Plug & Play DDC2B
Frequency Range Horizontal: 15~91kHz, Vertical: 50~120Hz (video/PC)
FEATURES
Keystone Correction 6:1 upward shift, fixed
Speakers 1 x 1W
Other Mirror reverse image, Up-side down image, R/G/B Color
adjustment, Aspect selection
MENU: 17 Language (English, French, German, Spanish,
Italian, Norwegian, Dutch, Japanese, Portuguese, Simplified
Chinese, Traditional Chinese, Korean, Swedish, Russian,
Finnish, Polish, Turkish) Optical Zoom x 1.2, Freeze Function,
Magnifying, Progressive Scan, Digital Gamma Correction,
My Memory, 2-3 pull down Electrical V Keystone Correction
Auto Configuration (H-Phase, H-Size, Position),
PIN Lock Security
CONNECTORS
Computer Input 2 x 15-pin Mini D-sub
Computer Output 1 x 15-pin Mini D-sub
Video Input 1 x RCA Jack
1xS-Video Jack
Audio Input 1 x Stereo Mini Jack
Audio Output 1 x Stereo Mini Jack
Control 1 x 9-pin D-sub for RS232C Control
POWER
Power Supply 100~120/220~240V
Power Consumption 240W
PHYSICAL
Dimensions (W x H x D) 285 x 73 x 202mm (excluding feet and extrusions)
Weight 2.3Kg
Noise Level 38dB/32dB
MISCELLANEOUS
Lamp Indicator Light, Power Indicator Light, Temp Indicator Light, Ceiling Mount Image,
Rear Projection Image
CERTIFICATION
UL60950-1/c-UL, FCC Part 15, Class B, AS/NZS CISPR22 Class B CE, EN61000-3-2,
EN61000-3-3, EN55022, EN55024, EN60950-1
ACCESSORIES SUPPLIED
RGB Cable, Remote Control, Batteries, Lens Cap, Strap, Filter Cover, Safety Instruction,
Quick Guide, Power Cord, Softcase, User Manual CD-ROM (English, German, French,
Italian, Spanish, Dutch, Norwegian, Portuguese, Korean, Simplified Chinese, Swedish,
Russian, Finnish, Polish)
OPTIONAL ACCESSORIES
Replacement Lamp DT00701
a: Projection Distance
b: Lens centre to the higher edge of the screen
c: Lens centre to the lower edge of the screen
a
b
(Top)
c
(Bottom)
HITACHI DIGITAL MEDIA, Hitachi Europe Ltd, Whitebrook Park, Lower Cookham Road,
Maidenhead, Berkshire SL6 8YA UNITED KINGDOM
Tel: [phone] Fax:[phone] www.hitachidigitalmedia.com
The specification above and photography is for reference only and may be subject to change.
10/06
CP-RS57
SVGA
40" (1.0) 1.2 1.4 52.3 8.7
60" (1.5) 1.8 2.2 78.4 13.1
100" (2.5) 3.0 3.6 130.6 21.8
150" (3.8) 4.5 5.5 195.9 32.7
200" (5.1) 6.1 7.3 261.3 43.5
300" (7.6) 9.1 11.0 391.9 65.3
Screen Size
(Diagonal) min. (m) b(top) c(bottom)
Projection Distance (a)
max. (m)
Screen Height (cm)
40" (1.0) 1.3 1.6 48.6 1.2
60" (1.5) 2.0 2.4 72.9 1.8
100" (2.5) 3.3 4.0 121.6 3.0
150" (3.8) 5.0 6.0 182.3 4.4
200" (5.1) 6.6 8.0 243.1 5.9
300" (7.6) 9.9 12.0 364.7 8.9
Screen Size
(Diagonal) min. (m) b(top) c(bottom)
Projection Distance (a)
max. (m)
Screen Height (cm)
Image Size 4:3 Image Size 16:9
