Technica Engineering USB-100BASE-T1 User manual

USB-100BASE-T1
CONVERTER
Hardware-Version: 2.2
USER MANUAL
Manual-Version: 2.1.2.
March 2019

USB-100BASE-T1 Converter User Manual
2
Content
1GENERAL INFORMATION .................................................................................... 3
1.1 Functionality and Features of the USB-100BASE-T1 Converter .................... 3
1.2 Warranty and Safety Information .................................................................. 4
2HARDWARE INTERFACES ................................................................................... 5
2.1 Connectors.................................................................................................... 5
2.1.1 Black MQS Connector............................................................................. 5
2.1.2 Universal Serial Bus Connector .............................................................. 6
2.2 Other Interfaces ............................................................................................ 6
2.2.1 Status LED .............................................................................................. 6
3INSTALLATION.................................................................................................... 7
3.1 Driver Installation .......................................................................................... 7
4CONFIGURATION .............................................................................................. 14
4.1 NIC settings (information)........................................................................... 16
5ADDITIONAL INFORMATION............................................................................. 20
6LIST OF FIGURES............................................................................................... 21
7CHANGELOG ..................................................................................................... 22
8CONTACT.......................................................................................................... 23

USB-100BASE-T1 Converter User Manual
3
1GENERAL INFORMATION
1.1 Functionality and Features of the USB-100BASE-T1
Converter
Figure 1-1: USB-100BASE-T1 Converter
The Technica Engineering USB-100BASE-T1 Converter transmits data frames from
the physical layer BroadR-Reach (100BASE-T1) to USB 2.0-LAN.
Features:
•1 port 100BASE-T1 with Broadcom BroadR-Reach Technology
•1 port USB 2.0 mini B
•1 Status LED

USB-100BASE-T1 Converter User Manual
4
General Information:
Power requirement:
5V
Power consumption:
2,5 Watt
LINKS:
The User can download the latest firmware and documentation for the USB-100BASE-
T1 Converter here:
https://technica-engineering.de/en/produkt/usb-100base-t1-converter/
1.2 Warranty and Safety Information
Before operating the device, read this manual thoroughly and retain
it for your reference.
The latest documentation for the USB-100BASE-T1 Converter here:
https://technica-engineering.de/en/produkt/usb-100base-t1-
converter/
Use the device only as described in this manual.
Use only in dry conditions.
Do not apply power to a damaged device.
Do not open the device. Otherwise warranty will be lost.
This device is designed for engineering purpose only.
Special care has to be taken for operation.
Do not use this device in a series production car.
As this device is likely to be used under rough conditions, warranty
is limited to 1 year.
Manufacturer liability for damage caused by using the device is
excluded.

USB-100BASE-T1 Converter User Manual
5
2HARDWARE INTERFACES
2.1 Connectors
On the label on top of the device you can see an overview about all HW-Interfaces of
the USB-100BASE-T1 Converter.
2.1.1 Black MQS Connector
The pinning of the ECU connectors is listed on the label on top of the device as well.
(See FIGURE 2-1)
The Connector color is black.
Figure 2-1: Label of USB-100BASE-T1 Converter with pinning information

USB-100BASE-T1 Converter User Manual
6
The Tyco Electronics (TE) Micro Quad Lock System (MQS) is used.
Name
Part Number
Tyco, MQS Buchsengehäuse 3 Pol
4-1718346-1
Tyco crimp contact
928999-1
Table 2-1: Parts of black MQS connector
Note: You can use the official Tyco tool for these crimp contacts. A cheap variant is
the crimp tool for “PSK” contacts.
Pin
Function
1
n.c.
2
100BASE-T1 port, positive
3
100BASE-T1 port, negative
Table 2-2: Pinning of black MQS connector
2.1.2 Universal Serial Bus Connector
There is one USB 2.0 mini B Port for connection to a laptop or PC. Since the chip used
is a USB-LAN chip, your PC will identify a new Ethernet Network Interface Card.
2.2 Other Interfaces
2.2.1 Status LED
The USB-100BASE-T1 Converter has one status LED at the frontside of the case for
the 100BASE-T1 Port.
It is lit when there is linkup. It is toggling when there is communication.
Note: There is a bug in the used BroadR-Reach PHY. When the BR Plus and Minus
lines are swapped, and the 100BASE-T1 port is set to Slave then the Link LED is lit,
but there is no data transmission possible. So please ensure that the 100BASE-T1
lines (positive/positive and negative/negative) are connected correctly.

USB-100BASE-T1 Converter User Manual
7
3INSTALLATION
3.1 Driver Installation
A driver is available for following operating Systems (version 1.4):
•Linux x64
•Windows x32
•Windows x64
Download-link
https://technica-engineering.de/en/produkt/usb-100base-t1-converter/
For Windows, please follow the described steps for installation:
1) Connect your USB-100BASE-T1 Converter device to your computer
2) browse your driver installation data folder and double click on the setup called
“USB-BR_1.4”
Figure 3-1: Driver Installation Data Folder
Accept the prompt to install the application.
3) Follow through the Wizard menus as shown below:

USB-100BASE-T1 Converter User Manual
8
Figure 3-2: Driver Installation Start Up screen

USB-100BASE-T1 Converter User Manual
9
Figure 3-3: Driver Installation Terms and Conditions

USB-100BASE-T1 Converter User Manual
10
Figure 3-4: Driver Installation

USB-100BASE-T1 Converter User Manual
11
Figure 3-5: Driver Installation
4) In case you have an old application running, the installer will prompt to close
automatically:

USB-100BASE-T1 Converter User Manual
12
Figure 3-6: Driver Installation

USB-100BASE-T1 Converter User Manual
13
Figure 3-7: Driver Installation

USB-100BASE-T1 Converter User Manual
14
4CONFIGURATION
The USB-100BASE-T1 Converter is configured by using the Configurator window or
using directly the system try icon.
After successful installation, you will see a new window with a drop-down menu
containing a list of all Technica Engineering USB-100BASE-T1 devices connected to
your PC.
Figure 4-1: Windows Driver window (one device connected and detected)

USB-100BASE-T1 Converter User Manual
15
Configuration Options:
•The “Master” button can be used to configure the BroadR-Reach port to work
in Master mode.
•The “Slave” button can be used to configure the BroadR-Reach port to work in
Slave mode.
When new devices are connected, they are detected automatically and appear on the
drop-down list.
If you connect a new device and it doesn’t appear automatically on the list, please
press the "↻" button.
The Master/Slave settings for each device are kept in memory, so that when you un-
plug and re-plug them, the latest setting will be used.
Note: In a BroadR-Reach Link one device must be set as Master, the other must be set
as Slave.
On version 1.4 the user documentation is not directly linked to the “?” icon, so you will
get the following information:
Figure 4-2: Prompt for Documentation

USB-100BASE-T1 Converter User Manual
16
Please wait for version 1.5 coming soon!!
You can close the window by clicking on the “x”, you can then find it again in the
system tray:
Figure 4-3 Device Settings in Master / Slave
4.1 NIC settings (information)
1) Network Interface Card (NIC) Set Up:
For the USB 100Base T1 device the NIC of the PC the default mode for the
device speed on the USB-LAN side is “Auto Negotiation”.
The 100BASE-T1 phy is always only set to 100 Mbps full duplex.
If desired, the user can follow these steps change USB-LAN NIC from auto
negotiation to 100Mbps Full Duplex.
However, it must be noted, that these might have no influence at all in the
functionality of the device.
i. Go to Control Panel > Hardware and Sound > Device Manager
ii. In the Device Manager Click on Network adapters > Right Click on
LAN9500A USB 2.0 to Ethernet 10/100 Adapter > Properties

USB-100BASE-T1 Converter User Manual
17
Figure 4-4: Device Manager Properties

USB-100BASE-T1 Converter User Manual
18
Figure 4-5: 100Mbps Full Duplex Speed Selection
iii. In Properties > Click on Advanced Tab > Select Speed & Duplex
iv. In the Value drop down menu select 100 Mbps Full Duplex and Click OK

USB-100BASE-T1 Converter User Manual
19
Figure 4-6: Apply Changes
v. Windows will send a prompt to restart the computer after this change.
Click OK to restart the computer for the change to take place.

USB-100BASE-T1 Converter User Manual
20
5ADDITIONAL INFORMATION
•The maximum cable length for BroadR-Reach segments is limited to 15
meters.
•The single unshielded twisted pair cable (UTP) must fulfill the IEEE 100BASE-
T1 specifications
