Technisonic Industries Limited TMS-110 User manual

TMS-110
VHF AM TRANSCEIVER
Installation and Operating
Instructions
TiL Document No. 15RE532
Rev. D
November 2018
Technisonic Industries Limited
240 Traders Boulevard, Mississauga, Ontario L4Z 1W7
Tel: [phone] Fax: [phone]
www.til.ca
Copyright by Technisonic Industries Limited. All rights reserved.

TECHNISONIC INDUSTRIES LIMITED
TMS-110 Installation and Operating Instructions TiL 15RE532 rev. D
ii
This page is intentionally left blank.

TECHNISONIC INDUSTRIES LIMITED
TMS-110 Installation and Operating Instructions TiL 15RE532 rev. D
iii
REVISION HISTORY
[ 15RE532 ]
REV SECTION
- PAGE - DESCRIPTION DATE EDITED BY
N/C
A All
Original Document Release.
Updated to final installation and operation for
production release.
8 Jan 2016
24 May 2018
SM
SM
B All Updated for IC and FCC conformance. 22 June 2018 SM
C All Changed maximum power to 10 watts 24 Sept 2018 SM
D 1, 20 Added -1 and -2 part number information. 14 Nov 2018 SM

TECHNISONIC INDUSTRIES LIMITED
TMS-110 Installation and Operating Instructions TiL 15RE532 rev. D
iv
This page is intentionally left blank.

TECHNISONIC INDUSTRIES LIMITED
TMS-110 Installation and Operating Instructions TiL 15RE532 rev. D
v
ESD CAUTION
This unit contains static sensitive devices. Wear a grounded wrist strap and/or conductive gloves
when handling printed circuit boards.
FCC COMPLIANCE INFORMATION
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference and (2) this device must accept any interference
received, including interference that may cause undesired operation.
WARNING: For compliance with FCC RF Exposure Requirements the mobile transmitter
antenna installation shall comply with the following two conditions:
1. The transmitter antenna gain shall not exceed 3 dBi.
2. The transmitter antenna is required to be located outside of a vehicle and kept at a separation distance of
115 cm or more between the transmitter antenna of this device and persons during operation.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help.
WARNING AND DISCLAIMER
Changes or modifications not expressly approved by Technisonic Industries could void the user’s
authority to operate the equipment.
This manual is designed to provide information about the TDAM-1000. Every effort has been made to
make this manual as complete and accurate as possible.
WARRANTY INFORMATION
The Model TMS-110 is under warranty for one year from date of purchase. Failed units caused by
defective parts or workmanship should be returned to:
Technisonic Industries Limited
240 Traders Boulevard
Mississauga, Ontario L4Z 1W7
Tel: [phone]
Fax: [phone]
NOTES

TECHNISONIC INDUSTRIES LIMITED
TMS-110 Installation and Operating Instructions TiL 15RE532 rev. D
vi
SECTION
TITLE
PAGE
1 GENERAL DESCRIPTION B
1.1 INTRODUCTION ............................................................................................................... 1
1.2 DESCRIPTION .................................................................................................................. 1
1.3 SYSTEM COMPONENTS ................................................................................................. 1
2 INSTALLATION INSTRUCTIONS B
2.1 GENERAL ......................................................................................................................... 3
2.2 EQUIPMENT PACKING LOG ........................................................................................... 3
2.3 TDAM-1000 INSTALLATION ............................................................................................ 3
2.4 INSTALLATION CONNECTIONS ..................................................................................... 5
2.5 INSTALLATION - WIRING INSTRUCTIONS .................................................................... 6
2.6 INSTALLATION - ANTENNA ............................................................................................ 7
2.7 INSTALLATION - BRACKET ............................................................................................ 10
2.8 INSTALLATION - MICROPHONE ..................................................................................... 10
2.9 INSTALLATION - WIRING INSTRUCTIONS .................................................................... 11
3 OPERATING INSTRUCTIONS B
3.1 GENERAL ......................................................................................................................... 12
3.2 FEATURES ....................................................................................................................... 12
3.3 FRONT PANEL ................................................................................................................. 12
3.4 NORMAL OPERATION ..................................................................................................... 13
3.5 FUNCTION MENU ............................................................................................................ 15
3.6 CONFIGURATION MENU ................................................................................................. 16
3.7 25 AND 8.33 kHz CHANNEL SPACING ........................................................................... 17
4 SPECIFICATIONS B
4.0 DIMENSIONS .................................................................................................................... 18
4.1 GENERAL SPECIFICATIONS .......................................................................................... 18
4.2 RECEIVER SPECIFICATIONS ......................................................................................... 19
4.3 TRANSMITTER SPECIFICATIONS .................................................................................. 20
WARRANTY ...................................................................................................................... 21
FIGURE
TITLE
PAGE
1 Outline Drawing for Model TDAM-1000 ............................................................................ 4
2 Wiring Connections and Notes for the TDAM-1000 .......................................................... 5
3 TDAM-1000 Front Panel Controls ..................................................................................... 12
TABLE OF CONTENTS
LIST OF FIGURES

TECHNISONIC INDUSTRIES LIMITED
TMS-110 Installation and Operating Instructions TiL 15RE532 rev. D
vii
TABLE
TITLE
PAGE
1 Power Connections (2 Pin D-Connections – J1) ............................................................... 5
2 Accessory Connections (26 Pin HDD-Connections – J7) ................................................. 5
3 Configuration Menu Commands ....................................................................................... 16
4 ICAO 25 kHz and 8.33 kHz Channel Spacing .................................................................. 17
LIST OF TABLES

TECHNISONIC INDUSTRIES LIMITED
TMS-110 Installation and Operating Instructions TiL 15RE532 rev. D
1
1.1 INTRODUCTION
This publication provides information on the installation and operation of the TMS-110
Transceiver System.
1.2 DESCRIPTION
The TMS-110 (TiL system number 180001) includes the TDAM-1000 VHF AM mobile transceiver
(Product Marketing Name (PMN) TDAM-1000) operates in the aeronautical VHF AM band and is
designed for ground vehicle installation.
1.3 SYSTEM COMPONENTS
The following components make up the system:
Component Part Number
TDAM-1000 VHF AM Transceiver 151286-1
Microphone Assembly 181298-1
Mounting Bracket 169676
Mobile Antenna Assembly 181299-1
Power Cord 183043-1
Installation Kit 189729
SECTION 1: GENERAL DESCRIPTION

TECHNISONIC INDUSTRIES LIMITED
TMS-110 Installation and Operating Instructions TiL 15RE532 rev. D
2
This page is intentionally left blank.

TECHNISONIC INDUSTRIES LIMITED
TMS-110 Installation and Operating Instructions TiL 15RE532 rev. D
3
2.1 GENERAL
This section contains information and instructions for the correct installation of the TMS-110 VHF
AM mobile transceiver system.
2.2 EQUIPMENT PACKING LOG
Unpack the equipment and check for any damage that may have occurred during transit. Save
the original shipping container for returns due to damage or warranty claims. Check that each
item on the packing slip has been shipped in the container.
2.3 INSTALLATION
The TDAM-1000 is designed to be used in land mobile applications. A mounting bracket, hand
microphone, power cable and antenna are supplied. The TDAM-1000 will operate on both
standard 13.8 VDC or 28 VDC special purpose or military vehicle power without modification. The
built in speaker is sufficient for most installations however a 10 watt external speaker output is
supplied for high noise environments.
SECTION 2: INSTALLATION INSTRUCTIONS

TECHNISONIC INDUSTRIES LIMITED
TMS-110 Installation and Operating Instructions TiL 15RE532 rev. D
4
FIGURE 1. Outline Drawing for Model TDAM-1000

TECHNISONIC INDUSTRIES LIMITED
TMS-110 Installation and Operating Instructions TiL 15RE532 rev. D
5
2.4 INSTALLATION – CONNECTIONS
FIGURE 2 – Rear Connector View – TDAM-1000
TABLE 1. Power Plug – J1 (2 Pin D) Connections
Pin # Description
1 Power
2 Ground
TABLE 2. Accessory – J3 (26 Pin HDD) – Use MALE Connector
Pin # Description
1 RS232 Data Out
2 CAN H
3 SPI Clock
4 I2C SCLK
5 I/O 2
6 Remote Mic Audio
7 Cross Mute In
8 External Speaker Out +
9 External Speaker Out -
10 RS232 Data In
11 Ground
12 SPI CS1
13 SPI MISO
14 Ground
15 ADC In
16 Cross Mute Out
17 Ground
18 Remote PTT
19 CAN L
20 SPI CS0
21 SPI MOSI
22 I2C SDA
23 I/O 1
24 Squelch Out
25 Headset Audio
26 Monitor Audio

TECHNISONIC INDUSTRIES LIMITED
TMS-110 Installation and Operating Instructions TiL 15RE532 rev. D
6
2.5 INSTALLATION – WIRING INSTRUCTIONS
For most installations, only the power cable connection and the antenna connection are required.
However an installation of two TDAM-1000 transceivers can take advantage of the ‘Cross Mute’
feature available on the 26 pin HD D connector. The Cross Mute function will mute the other
receiver whenever one of the radios is transmitting. A mating 26 pin HD D connector is supplied
in the installation kit.
2.5.1 J1 PINS 1 AND 2 – MAIN POWER INPUT
Use supplied power cable to connect to vehicle accessory power source.
2.5.2 J3 PINS 8 AND 9 – EXTERNAL SPEAKER OUTPUT + AND –
10 watt speaker output at 8 ohm impedance. The speaker output includes receive audio only. The
Level is set by the volume control. The speaker output is also available on a 1/8” phone jack (J2)
on the back of the radio. The output amplifier is of a ‘bridged‘ type, so both + and – must not be
connected to ground.
2.5.3 J3 PIN 26 – MONITOR AUDIO
Line level audio output receive and sidetone (mic) audio combined. Not affected by the volume
control.
2.5.4 J3 PIN 25 – HEADSET AUDIO
0.5 watt 600 ohm audio output. Includes receive and sidetone (mic) audio. The level is set by
the volume control. Can be used when a remote user position is required, leave unconnected
otherwise.
2.5.5 J3 PIN 7 – CROSS MUTE INPUT
Receive audio will be muted on the speaker, headset and monitor outputs when this input is at 10
volts. Connect to the cross mute output on the second radio.
2.5.6 J3 PIN 16 – CROSS MUTE OUTPUT
10 volt output during transmit and 0 volts during receive. Connect to the cross mute input of the
second radio.
2.5.7 J3 PIN 6 – REMOTE MIC AUDIO
Microphone audio input. Mic DC bias voltage is supplied. Can be used when a remote user
position is required, leave unconnected otherwise.
2.5.8 J3 PIN 18 – REMOTE PTT INPUT
Push to talk input. Radio will transmit when this line is brought to ground. Can be used when a
remote user position is required, leave unconnected otherwise.
2.5.9 J3 PINS 11, 14 AND 17 – GROUND
Ground. Connected to signal and chassis ground.
2.5.10 J3 PIN 24 – SQUELCH OUTPUT
Squelch signal output. Open collector output which goes to ground when squelch is open.
2.5.11 J3 PINS 1 TO 5, 10, 12, 13, 15 AND 19 TO 23 – BASE STATION INTERFACE
For base station applications only. Do not connect.

TECHNISONIC INDUSTRIES LIMITED
TMS-110 Installation and Operating Instructions TiL 15RE532 rev. D
7
2.6 INSTALLATION – ANTENNA
For best results, the antenna should be mounted as high as possible in the center of a flat
metallic surface at least 52” in diameter. Where this may not always be possible, mounting the
antenna in the center of the roof of most cars or trucks should give reasonable performance. The
antenna should be at least 52” from any other antenna. The 181299-1 antenna supplied with the
TMS-110 system can be assembled by the following procedure:
 Drill a 3/8” hole where the antenna is to be installed.
 Unpackage the antenna and disassemble the antenna base:
 Press antenna base through the 3/8” hole and supplied washer:
 Feed coax through the antenna base:
 Slide the locking core over the coax and into the antenna base:

TECHNISONIC INDUSTRIES LIMITED
TMS-110 Installation and Operating Instructions TiL 15RE532 rev. D
8
 Spread the coax shielding over the antenna base:
 Trim the shielding to allow the lock nut to be installed.
 Install and tighten the antenna base lock nut:
 Install and tighten the antenna base grounding cap:
 Place the rubber seal around the antenna base:

TECHNISONIC INDUSTRIES LIMITED
TMS-110 Installation and Operating Instructions TiL 15RE532 rev. D
9
 Screw on antenna base insulator and tighten:
 Bend center conductor over into one of the grooves.
 Cut off excess length:
 Screw on antenna whip:
 Route the coax to the back of the radio position.

TECHNISONIC INDUSTRIES LIMITED
TMS-110 Installation and Operating Instructions TiL 15RE532 rev. D
10
2.7 INSTALLATION – MOUNTING BRACKET
Mount the bracket to the vehicle as required with the two #6 x ¾” self-tapping screws.
The radio may be mounted above or the below the bracket depending on the installation. Use the
four 8-32 x 5/16” black screws to attach the radio to the bracket. The bracket has slots to allow
the angle to be adjusted.
2.8 INSTALLATION – MICROPHONE
Connect the supplied microphone to the radio by plugging in the RJ-45 connector into the front
panel underneath the knob until it clicks.
The mic clip can be installed on the radio or elsewhere in the vehicle. There are holes for vertical
or horizontal mounting on either side of the radio using the two 6-32 x ¼” screws supplied.

TECHNISONIC INDUSTRIES LIMITED
TMS-110 Installation and Operating Instructions TiL 15RE532 rev. D
11
2.9 INSTALLATION – POWER CORD
Plug the supplied power cord into power jack J1 on the back of the radio and tighten both of the
mating screws. Route the red wire to the accessories supply of the vehicle, cutting off any
excess. Connect the black wire to the vehicle chassis ground.

TECHNISONIC INDUSTRIES LIMITED
TMS-110 Installation and Operating Instructions TiL 15RE532 rev. D
12
3.1 GENERAL
This section contains information and instructions for the correct operation of the TDAM-1000
transceiver.
3.2 FEATURES
The TDAM-1000 supports the following features:
 16 character LED alphanumeric display
 Backlit panel and keys
 USB port for loading and saving channel or configuration data.
 Continuous coverage from 117.975 to 138.000 MHz in 25 or 8.33 kHz steps.
 100 programmable channels
 Split frequency pairs
 Transmit DTMF keypad
 Scanning of selected channels
 High and Low power
3.3 FRONT PANEL
Refer to figure 3 below:
FIGURE 3. Front Panel Controls
3.3.1 VOLUME KNOB
The volume knob has a push button built in which is used to turn the radio on and off as well as
select other functions for the knob. To turn on the radio, press and hold the knob until the display
lights up. To turn off the radio, press and hold the knob for approximately 3 seconds until the
display shows ‘OFF’. Quick presses of the knob during normal operation will toggle the knob
function between volume, channel, squelch and brightness modes. The default mode for the knob
is volume when the radio is turned on.
SECTION 3: OPERATING INSTRUCTIONS

TECHNISONIC INDUSTRIES LIMITED
TMS-110 Installation and Operating Instructions TiL 15RE532 rev. D
13
3.3.2 SQUELCH BUTTON
The squelch function mutes the receiver when no signal is present so the operator does not listen
to continuous receiver noise. When the knob is in squelch mode, it adjusts the muting threshold
from fully open to a level where only a strong signal can be heard. Pressing the squelch button
will temporarily open the squelch for as long as the button is pressed. When released, the knob is
put into squelch mode for 3 seconds with the squelch level shown on the bottom line of the
display.
3.3.3 LED DISPLAY
The display is a 2 line 16 character green LED type. During normal operation the frequency,
channel name and/or channel number may be displayed depending on settings in the
configuration menu. The display is also used during programming and menu functions. There are
two LED indicators on the right of the display for transmit and receive (squelch open).
3.3.4 KEYPAD
A numeric keypad is provided to allow quick entry of frequencies or program channels.
3.3.5 CHANNEL UP/DOWN KEYS
These keys are used to select the desired channel.
3.3.6 USB CONNECTOR
The USB connector can be used to upload or download a channel list or program the radio
configuration. See 3.5 FUNCTION MENU for instructions.
3.3.7 MIC AND HEADSET JACKS
The supplied hand mic is plugged into the RJ-45 type jack. Headphones if desired can be
plugged into the headset jack. The internal speaker and external speaker output can be disabled
(default) when the headset jack is used depending on the settings in the configuration menu.
3.4 NORMAL OPERATION
Note: The TDAM-1000 transceiver can be configured to operate in one of two modes:
1. Frequency agile mode – Any frequency from 117.975 to 138.000 MHz can be selected or
programmed into any of the 100 available channels.
2. Fixed mode – Only frequencies programmed into channels can be used.
The operating mode can be set in the configuration menu. The following instructions assume
frequency agile mode. Those marked with an asterisk (*) will not be available in fixed mode.
3.4.1 ENTERING A FREQUENCY*
The TDAM-1000 supports both 25 kHz and 8.33 kHz channel spacing. The channel spacing used
is determined by the frequency entered. See the ICAO frequency chart in section 3.7.
To enter a new frequency, type in the frequency (up to 6 digits) via the keypad and press enter. If
enter is not pressed within 3 seconds or the mic is keyed, the radio will revert back to the
previous frequency. For example, to enter 128.75 press:
The new frequency is ready to use. The new frequency is not saved in a channel but will remain
active until another frequency or channel is selected.
