Page 104 FT-950 OPERATING MANUAL
MENU MODE
The Menu system of the FT-950 provides extensive customization capability, so you can set up your transceiver just the
way you want to operate it. The Menu items are grouped by general utilization category, and are numbered from “001 AGC001 AGC
001 AGC001 AGC
001 AGC
FST DLYFST DLY
FST DLYFST DLY
FST DLY” to “118 TGEN EMRGNCY118 TGEN EMRGNCY
118 TGEN EMRGNCY118 TGEN EMRGNCY
118 TGEN EMRGNCY”.
USING THE MENU
1. Press the [MENU]button momentarily, to engage the
Menu mode.
The display will show the Menu Number, Menu Group
Name, and Menu Item. Press the [SELECT]knob
momentarily to toggle the display between “Menu
Number & Menu Group Name” and “Menu Item”. The
Multi-Display Window shows the current setting of the
currently selected Menu item.
2. Rotate the [SELECT]knob to select the Menu item
you wish to modify.
3. Rotate the [CLAR/VFO-B]knob to change the cur-
rent setting of the selected Menu item.
ADVICE:
Press the [CLEAR]button (located the upper right of
the [SELECT]knob) momentarily to reset the selected
Menu item to the factory default value.
4. When you have finished making your adjustments,
press and hold in the [MENU]button for one second
to save the new setting and exit to normal operation. If
you only momentarily press the [MENU]button, the
new settings will not be retained.
MENU MODE RESET
You may reset all the Menu settings to their origi-
nal factory defaults, if desired.
1. Turn the front panel [POWER]switch off.
2. Press and hold in the [MENU]button, and while
holding it in, press the [POWER]switch to turn
the transceiver back on. Now release the
[MENU]button.
[CLAR/VFO-B]Knob [MENU]Button
Press
Menu Number Menu Group Name
Menu Setting
Menu Item
Menu Setting
[SELECT]Knob
[CLEAR]Button

Page 105FT-950 OPERATING MANUAL
MENU MODE
GROUP NO. MENU FUNCTION AVAILABLE VALUES DEFAULT SETTING
AGC 001 AGC FST DLY 20 ~ 4000 msec (20 msec/step)300 msec
AGC 002 AGC MID DLY 20 ~ 4000 msec (20 msec/step)700 msec
AGC 003 AGC SLW DLY 20 ~ 4000 msec (20 msec/step)3000 msec
DISPLAY 004 DISP COLOR bL1/bL2/bL3/ub1/ub2 bL1Ú1
DISPLAY 005 DISP DIM VFD 0 ~ 15 8
DISPLAY 006 DISP BAR SEL CLAr/C-tn/u-tn C-tn
DISPLAY 007 DISP PKH S OFF/0.5/1.0/2.0 sec OFF
DISPLAY 008 DISP PKH PO OFF/0.5/1.0/2.0 sec OFF
DISPLAY 009 DISP PKH ALC OFF/0.5/1.0/2.0 sec OFF
DISPLAY 010 DISP PKH ID OFF/0.5/1.0/2.0 sec OFF
DISPLAY 011 DISP RTR STU 0/90/180/270° 0°Ú2
DISPLAY 012 DISP RTR ADJ –30 ~ 0° (2°/step) 0°Ú2
DISPLAY 013 DISP QMB MKR On/OFF On
DVS 014 DVS RX LVL 0 ~ 100 50Ú3
DVS 015 DVS TX LVL 0 ~ 100 50Ú3
KEYER 016 KEY BEACON OFF/1 ~ 255 sec OFF
KEYER 017 KEY NUM STL 1290/AunO/Aunt/A2nO/A2nt/12nO/12nt 1290
KEYER 018 KEY CONTEST 0 ~ 9999 1
KEYER 019 KEY CW MEM1 tyP1/tyP2 tyP2
KEYER 020 KEY CW MEM2 tyP1/tyP2 tyP2
KEYER 021 KEY CW MEM3 tyP1/tyP2 tyP2
KEYER 022 KEY CW MEM4 tyP1/tyP2 tyP2
KEYER 023 KEY CW MEM5 tyP1/tyP2 tyP2
GENERAL 024 GENE ANT SEL bAnd/rEG bAnd
GENERAL 025 GENE BEP LVL 0 ~ 100 50
GENERAL 026 GENE CAT BPS 4800/9600/192H (19200)/384H (38400)bps 4800 bps
GENERAL 027 GENE CAT TOT 10/100/1000/3000 msec 10 msec
GENERAL 028 GENE CAT RTS On/OFF On
GENERAL 029 GENE MEM GRP On/OFF OFF
GENERAL 030 GENE Q SPLIT –20 ~ 0 ~ +20 kHz (1 kHz/step)+5 kHz
GENERAL 031 GENE TX TOT OFF/1 ~ 30 min OFF
GENERAL 032 GENE uT DIAL StP1/ StP2 StP1Ú4
GENERAL 033 GENE MIC SCN On/OFF On
GENERAL 034 GENE SCN RSM CAr/5SEc 5SEc
GENERAL 035 GENE FRQ ADJ –25 ~ 0 ~ +25 0
MODE-AM 036 A3E MICGAIN Ur/0 ~ 100 Ur
MODE-CW 037 A1A F-TYPE OFF/buG/ELE/ACS ELE
MODE-CW 038 A1A F-REV nor/rEV (NORNAL/REVERSE)nor (NORNAL)
MODE-CW 039 A1A R-TYPE OFF/buG/ELE/ACS ELE
MODE-CW 040 A1A R-REV nor/rEV (NORNAL/REVERSE)nor (NORNAL)
MODE-CW 041 A1A CW AUTO OFF/50/On OFF
MODE-CW 042 A1A BFO USb/LSb/Auto USb
MODE-CW 043 A1A BK-IN SEni/FuLL SEni
MODE-CW 044 A1A DELAY 30 ~ 3000 msec (10 msec/step)200 msec
MODE-CW 045 A1A PITCH 300 ~ 1050 Hz (50 Hz/step)700 Hz
MODE-CW 046 A1A WEIGHT (1:) 2.5 ~ 4.5 3.0
MODE-CW 047 A1A FRQDISP dir/OFSt OFSt
MODE-CW 048 A1A PC KYNG EnA/diS (ENABLE/DISABLE)diS (Disable)
MODE-CW 049 A1A QSKTIME 15/20/25/30 msec 15 msec
Ú1: Requires optional DMU-2000 Data Management Unit.
Ú2: Requires optional Antenna Rotator.
Ú3: Requires optional DVS-6 Voice Memory Unit.
Ú4: Requires optional RF μTuning Kit.

Page 106 FT-950 OPERATING MANUAL
GROUP NO. MENU FUNCTION AVAILABLE VALUES DEFAULT SETTING
MODE-DATA 050 DATA DT GAIN 0 ~ 100 50
MODE-DATA 051 DATA OUT LVL 0 ~ 100 50
MODE-DATA 052 DATA VOX DLY 30 ~ 3000 msec (10 msec/step)300 msec
MODE-DATA 053 DATA V GAIN 0 ~ 100 50
MODE-DATA 054 DATA PKTDISP –3000 ~ +3000 Hz (10 Hz/step)0 Hz
MODE-DATA 055 DATA PKT SFT –3000 ~ +3000 Hz (10 Hz/step)1000 Hz
MODE-FM 056 F3E MIC Ur/0 ~ 100 50
MODE-FM 057 F3E 28 RPT 0 ~ 1000 kHz (10 kHz/step)100 kHz
MODE-FM 058 F3E 50 RPT 0 ~ 4000 kHz (10 kHz/step)1000 kHz
MODE-RTTY 059 RTTY R PLRTY nor/rEV (NORMAL/REVERSE)nor (NORMAL)
MODE-RTTY 060 RTTY T PLRTY nor/rEV (NORMAL/REVERSE)nor (NORMAL)
MODE-RTTY 061 RTTY OUT LVL 0 ~ 100 50
MODE-RTTY 062 RTTY SHIFT 170/200/425/850 Hz 170 Hz
MODE-RTTY 063 RTTY TONE 1275/2125 Hz 2125 Hz
MODE-SSB 064 J3E TX BPF 1-30/1-29/2-28/3-27/4-26 3-27 (300 ~ 2700 Hz)
MODE-SSB 065 J3E LSB CAR –200 Hz ~ +200 Hz (10 Hz/steps)0 Hz
MODE-SSB 066 J3E USB CAR –200 Hz ~ +200 Hz (10 Hz/steps)0 Hz
RX GENERAL 067 RGEN NB 1 LVL 0 ~ 255 128
RX GENERAL 068 RGEN NB 2 LVL 0 ~ 255 128
RX GENERAL 069 RGEN CNTR LV –40 ~ +20 dB –15 dB
RX GENERAL 070 RGEN CNTR WI 1 ~ 11 10
RX GENERAL 071 RGEN DNF OFF/On OFF
RX GENERAL 072 RGEN DNR OFF/1 ~ 15 OFF
SCOPE 073 SCP 1.8 FIX 1.800 ~ 1.999 MHz (1 kHz/steps)1.800 MHzÚ1
SCOPE 074 SCP 3.5 FIX 3.500 ~ 3.999 MHz (1 kHz/steps)3.500 MHzÚ1
SCOPE 075 SCP 5.2 FIX 5.250 ~ 5.499 MHz (1 kHz/steps)5.250 MHzÚ1
SCOPE 076 SCP 7.0 FIX 7.000 ~ 7.299 MHz (1 kHz/steps)7.000 MHzÚ1
SCOPE 077 SCP 10.1 FIX (1)0.100 ~ (1)0.149 MHz (1 kHz/steps)( 1)0.100 MHzÚ1
SCOPE 078 SCP 14.0 FIX (1)4.000 ~ (1)4.349 MHz (1 kHz/steps)( 1)4.000 MHzÚ1
SCOPE 079 SCP 18.0 FIX (1)8.000 ~ (1)8.199 MHz (1 kHz/steps)( 1)8.068 MHzÚ1
SCOPE 080 SCP 21.0 FIX (2)1.000 ~ (2)1.449 MHz (1 kHz/steps)( 2)1.000 MHzÚ1
SCOPE 081 SCP 24.8 FIX (2)4.800 ~ (2)4.989 MHz (1 kHz/steps)( 2)4.890 MHzÚ1
SCOPE 082 SCP 28.0 FIX (2)8.000 ~ (2)9.699 MHz (1 kHz/steps)( 2)8.000 MHzÚ1
SCOPE 083 SCP 50.0 FIX (5)0.000 ~ (5)3.999 MHz (1 kHz/steps)( 5)0.000 MHzÚ1
TUNING 084 TUN DIALSTP 1/5/10 Hz 10 Hz
TUNING 085 TUN CW FINE EnA/diS (ENABLE/DISABLE)diS (DISABLE)
TUNING 086 TUN MHz SEL 1/0.1 MHz 1 MHz
TUNING 087 TUN AM STEP 2.5/5/9/10/12.5 kHz 5 kHz
TUNING 088 TUN FM STEP 5/6.25/10/12.5/20/25 kHz 5 kHz
TUNING 089 TUN FM DIAL 10/100 Hz 100 Hz
TUNING 090 TUN MY BAND 1.8 ~ 50/GE –
MENU MODE
Ú1: Requires optional DMU-2000 Data Management Unit.

Page 107FT-950 OPERATING MANUAL
GROUP NO. MENU FUNCTION AVAILABLE VALUES DEFAULT SETTING
TX AUDIO 091 TAUD EQ1 FRQ OFF/100 ~ 700 Hz (100 Hz/step)OFF
TX AUDIO 092 TAUD EQ1 LVL –20 ~ +10 +5
TX AUDIO 093 TAUD EQ1 BW 1 ~ 10 10
TX AUDIO 094 TAUD EQ2 FRQ OFF/700 ~ 1500 Hz (100 Hz/step)OFF
TX AUDIO 095 TAUD EQ2 LVL –20 ~ +10 +5
TX AUDIO 096 TAUD EQ2 BW 1 ~ 10 10
TX AUDIO 097 TAUD EQ3 FRQ OFF/1500 ~ 3200 Hz (100 Hz/step)OFF
TX AUDIO 098 TAUD EQ3 LVL –20 ~ +10 +5
TX AUDIO 099 TAUD EQ3 BW 1 ~ 10 10
TX AUDIO 100 TAUD PE1 FRQ OFF/100 ~ 700 Hz (100 Hz/step)200 Hz
TX AUDIO 101 TAUD PE1 LVL –20 ~ +10 0
TX AUDIO 102 TAUD PE1 BW 1 ~ 10 2
TX AUDIO 103 TAUD PE2 FRQ OFF/700 ~ 1500 Hz (100 Hz/step)800 Hz
TX AUDIO 104 TAUD PE2 LVL –20 ~ +10 0
TX AUDIO 105 TAUD PE2 BW 1 ~ 10 1
TX AUDIO 106 TAUD PE3 FRQ OFF/1500 ~ 3200 Hz (100 Hz/step)2100 Hz
TX AUDIO 107 TAUD PE3 LVL –20 ~ +10 0
TX AUDIO 108 TAUD PE3 BW 1 ~ 10 1
TX GENERAL 109 TGEN PROCLVL 0 ~ 100 50
TX GENERAL 110 TGEN EXT TUN itu/Etu (INTERNAL TUNER/EXTERNAL TUNER)itu
(INTERNAL TUNER)
TX GENERAL 111 TGEN TX PWR 5 ~ 100 100
TX GENERAL 112 TGEN AM CAR 0 ~ 100 50
TX GENERAL 113 TGEN PWRCTRL ALL/CAr ALL
TX GENERAL 114 TGEN VOX SEL nic/dAtA nic
TX GENERAL 115 TGEN V GAIN 0 ~ 100 50
TX GENERAL 116 TGEN VOX DLY 30 ~ 3000 msec (10 msec/step)500 msec
TX GENERAL 117 TGEN ANTIVOX 0 ~ 100 50
TX GENERAL 118 TGEN EMRGNCY EnA/diS (ENABLE/DISABLE)diS(DISABLE)
MENU MODE

Page 108 FT-950 OPERATING MANUAL
AGC GROUP
001 AGC FST DLY
Function: Sets the delay time for the AGC FAST mode.
Available Values: 20 ~ 4000 msec (20 msec/step)
Default Setting: 300 msec
002 AGC MID DLY
Function: Sets the delay time for the AGC MID mode.
Available Values: 20 ~ 4000 msec (20 msec/step)
Default Setting: 700 msec
003 AGC SLW DLY
Function: Sets the delay time for the AGC SLOW mode.
Available Values: 20 ~ 4000 msec (20 msec/step)
Default Setting: 3000 msec
DISPLAY GROUP
004 DISP COLOR
Function: Selects the Display color when the optional Data
Management Unit (DMU-2000) is connected.
Available Values: bL1/bL2/bL3/ub1/ub2
Default Setting: bL1 (COOL BLUE)
bL1: COOL BLUE
bL2: CONTRAST BLUE
bL3: FLASH WHITE
ub1: CONTRAST UMBER
ub2: UMBER
ADVICE:
If the optional DMU-2000 Data Management Unit is not
connected, this adjustment has no effect.
005 DISP DIM VFD
Function: Setting of the display brightness level.
Available Values: 0 ~ 15
Default Setting: 8
006 DISP BAR SEL
Function: Selects one of three parameters to be viewed
on the Tuning Offset Indicator.
Available Values: CLAr/C-tn/u-tn
Default Setting: C-tn
CLAr: Displays relative clarifier offset.
C-tu: Displays relative tuning offset between the incom-
ing signal and transmitted frequency while in CW
operation.
u-tn: Displays the peak position of the optional μ-TUNE
filter.
007 DISP PKH S
Function: Selects the peak hold time of the S-meter.
Available Values: OFF/0.5/1.0/2.0 sec
Default Setting: OFF
008 DISP PKH PO
Function: Selects the peak hold time of the PO meter.
Available Values: OFF/0.5/1.0/2.0 sec
Default Setting: OFF
009 DISP PKH ALC
Function: Selects the peak hold time of the ALC meter.
Available Values: OFF/0.5/1.0/2.0 sec
Default Setting: OFF
010 DISP PKH ID
Function: Selects the peak hold time of the ID meter.
Available Values: OFF/0.5/1.0/2.0 sec
Default Setting: OFF
MENU MODE

Page 109FT-950 OPERATING MANUAL
011 DISP RTR STU
Function: Selects the starting point of your rotator
controller’s indicator needle.
Available Values: 0/90/180/270°
Default Setting: 0°
ADVICE:
If the optional Antenna Rotator is not connected, this ad-
justment has no effect.
012 DISP RTR ADJ
Function: Adjusts the indicator needle precisely to the
starting point set in menu item “011 DISP RTR STU011 DISP RTR STU
011 DISP RTR STU011 DISP RTR STU
011 DISP RTR STU”.
Available Values: –30 ~ 0° (2°/step)
Default Setting: 0
ADVICE:
If the optional Antenna Rotator is not connected, this ad-
justment has no effect.
013 DISP QMB MKR
Function: Enables/Disables the QMB Marker (White ar-
row “V”) to display on the Spectrum Band Scope when
the optional DMU-2000 Data Management Unit is con-
nected.
Available Values: On/OFF
Default Setting: On
ADVICE:
If the optional DMU-2000 Data Management Unit is not
connected, this adjustment has no effect.
DISPLAY GROUP DVS GROUP
014 DVS RX LVL
Function: Sets the audio output level from the optional
DVS-6 Voice Memory Unit.
Available Values: 0 ~ 100
Default: 50
ADVICE:
If the optional DVS-6 Voice Memory Unit is not connected,
this adjustment has no effect.
015 DVS TX LVL
Function: Sets the microphone input level to the optional
DVS-6 Voice Memory Unit
Available Values: 0 ~ 100
Default: 50
ADVICE:
If the optional DVS-6 Voice Memory Unit is not connected,
this adjustment has no effect.
KEYER GROUP
016 KEY BEACON
Function: Sets the interval time between repeats of the
beacon message.
Available Values: OFF/1 ~ 255 sec
Default Setting: OFF
017 KEY NUM STL
Function: Selects the Contest Number “Cut” format for
an imbedded contest number.
Available Values: 1290/AunO/Aunt/A2nO/A2nt/12nO/
12nt
Default Setting: 1290
1290: Does not abbreviate the Contest Number
AunO: Abbreviates to “A” for “One”, “U” for “Two”,
“N” for “Nine”, and “O” for “Zero.”
Aunt: Abbreviates to “A” for “One”, “U” for “Two”,
“N” for “Nine”, and “T” for “Zero”.
A2nO: Abbreviates to “A” for “One”, “N” for “Nine”,
and “O” for “Zero”.
A2nt: Abbreviates to “A” for “One”, “N” for “Nine”,
and “T” for “Zero”.
12nO: Abbreviates to “N” for “Nine” and “O” for “Zero”.
12nt: Abbreviates to “N” for “Nine” and “T” for “Zero”.
018 KEY CONTEST
Function: Enters the initial contest number that will in-
crement/decrement after sending during contest QSOs.
Available Values: 0 ~ 9999
Default Setting: 1
ADVICE:
Press the [CLEAR]button to reset the contest number to
“1”.
MENU MODE

Page 110 FT-950 OPERATING MANUAL
019 KEY CW MEM1
Function: Permits entry of the CW message for message
register 1.
Available Values: tyP1/tyP2
Default Setting: tyP2
tyP1: You may enter the CW message from the Main Tun-
ing Dial knob and [CLAR/VFO-B]knob.
tyP2: You may enter the CW message from the CW keyer.
020 KEY CW MEM2
Function: Permits entry of the CW message for message
register 2.
Available Values: tyP1/tyP2
Default Setting: tyP2
tyP1: You may enter the CW message from the Main Tun-
ing Dial knob and [CLAR/VFO-B]knob.
tyP2: You may enter the CW message from the CW keyer.
021 KEY CW MEM3
Function: Permits entry of the CW message for message
register 3.
Available Values: tyP1/tyP2
Default Setting: tyP2
tyP1: You may enter the CW message from the Main Tun-
ing Dial knob and [CLAR/VFO-B]knob.
tyP2: You may enter the CW message from the CW keyer.
022 KEY CW MEM4
Function: Permits entry of the CW message for message
register 4.
Available Values: tyP1/tyP2
Default Setting: tyP2
tyP1: You may enter the CW message from the Main Tun-
ing Dial knob and [CLAR/VFO-B]knob.
tyP2: You may enter the CW message from the CW keyer.
023 KEY CW MEM5
Function: Permits entry of the CW message for message
register 5.
Available Values: tyP1/tyP2
Default Setting: tyP2
tyP1: You may enter the CW message from the Main Tun-
ing Dial knob and [CLAR/VFO-B]knob.
tyP2: You may enter the CW message from the CW keyer.
GENERAL GROUP
024 GENE ANT SEL
Function: Sets the method of antenna selection.
Available Values: bAnd/rEG
Default Setting: bAnd
bAnd: The antenna is selected in accordance with the op-
erating band.
rEG: The antenna is selected in accordance with the band
stack (different antennas may be utilized on the
same band, if so selected in the band stack).
025 GENE BEP LVL
Function: Sets the beep level.
Available Values: 0 ~ 100
Default Setting: 50
026 GENE CAT BPS
Function: Sets the transceiver’s computer-interface cir-
cuitry for the CAT baud rate to be used.
Available Values: 4800/9600/192H (19200)/384H
(38400) bps
Default Setting: 4800 bps
027 GENE CAT TOT
Function: Sets the Time-Out Timer countdown time for a
CAT command input.
Available Values: 10/100/1000/3000 msec
Default Setting: 10 msec
The Time-Out Timer shuts off the CAT data input after the
continuous transmission of the programmed time.
028 GENE CAT RTS
Function: Enables/Disables the RTS port of the CAT jack.
Available Values: On/OFF
Default Setting: On
029 GENE MEM GRP
Function: Enables/Disables Memory Group Operation.
Available Values: On/OFF
Default Setting: OFF
030 GENE Q SPLIT
Function: Selects the tuning offset for the Quick Split fea-
ture.
Available Values: –20 ~ 0 ~ +20 kHz (1 kHz Step)
Default Setting: +5 kHz
031 GENE TX TOT
Function: Sets the Time-Out Timer countdown time.
Available Values: OFF/1 ~ 30 min
Default Setting: OFF
The Time-Out Timer shuts off the transmitter after con-
tinuous transmission of the programmed time.
MENU MODE
KEYER GROUP

Page 111FT-950 OPERATING MANUAL
032 GENE uT DIAL
Function: Selects the μ-TUNE mode.
Available Values: StP1/StP2
Default Setting: StP1
StP1: Activates the μ-TUNE system using “COARSE”
steps of the [SELECT(μ-TUNE)] knob (2 steps/
click) on the 7 MHz and lower amateur bands. On
the 10/14 MHz bands, “FINE” [SELECT(μ-
TUNE)] knob steps will be used (1 step/click).
StP2: Activates the μ-TUNE system using “FINE” steps
of the [SELECT(μ-TUNE)] knob (1 step/click) on
the 14 MHz and lower amateur bands.
ADVICE:
If an optional RF μTuning Kit is not connected, this ad-
justment has no effect.
033 GENE MIC SCN
Function: Enables/disables scanning access via the
microphone’s [UP]/[DWN]keys.
Available Values: On/OFF
Default Setting: On
034 GENE SCN RSM
Function: Selects the Scan Resume mode.
Available Values: CAr/5SEc
Default Setting: 5SEc
CAr: The scanner will hold until the signal disappears,
then will resume after one second.
5SEc: The scanner will hold for five seconds, then resume
whether or not the other station is still transmitting.
035 GENE FRQ ADJ
Function: Adjusts the reference oscillator.
Available Values: –25 ~ 0 ~ +25
Default Setting: 0
Connect a 50-Ohm dummy load and frequency counter to
the antenna jack; adjust the [CLAR/VFO-B]knob so that
the frequency counter reading is same as the VFO fre-
quency while pressing the PTT switch.
ADVICE:
Do not perform this Menu item unless you have a high
performance frequency counter. Perform this Menu item
after aging the transceiver and frequency counter suffi-
ciently (at least 30 minutes).
MODE-AM GROUP
036 A3E MICGAIN
Function: Sets the microphone gain for the AM mode.
Available Values: Ur/0 ~ 100
Default Setting: Ur
When this menu is set to “Ur”, you may adjust the micro-
phone gain using the front panel’s [MIC GAIN]knob.
MODE-CW GROUP
037 A1A F-TYPE
Function: Selects the desired keyer operation mode for
the device connected to the front panel’s KEY jack.
Available Values: OFF/buG/ELE/ACS
Default Setting: ELE
OFF: Disables the front panel’s keyer (“straight key” mode
for use with external keyer or computer-driven key-
ing interface).
buG: Mechanical “bug” keyer emulation. One paddle pro-
duces “dits” automatically, while the other paddle
manually produces “dahs”.
ELE: Iambic keyer with ACS (Automatic Character Spac-
ing) disabled.
ACS: Iambic keyer with ACS (Automatic Character Spac-
ing) enabled.
038 A1A F-REV
Function: Selects the keyer paddle’s wiring configuration
for the KEY jack on the front panel.
Available Values: nor/rEV
Default Setting: nor
nor: Tip = Dot, Ring = Dash, Shaft = Ground
rEV: Tip = Dash, Ring = Dot, Shaft = Ground
039 A1A R-TYPE
Function: Selects the desired keyer operation mode for
the device connected to the rear panel’s KEY jack.
Available Values: OFF/buG/ELE/ACS
Default Setting: ELE
OFF: Disables the front panel’s keyer (“straight key” mode
for use with external keyer or computer-driven key-
ing interface).
buG: Mechanical “bug” keyer emulation. One paddle pro-
duces “dits” automatically, while the other paddle
manually produces “dahs”.
ELE: Iambic keyer with ACS (Automatic Character Spac-
ing) disabled.
ACS: Iambic keyer with ACS (Automatic Character Spac-
ing) enabled.
040 A1A R-REV
Function: Selects the keyer paddle’s wiring configuration
for the KEY jack on the rear panel.
Available Values: nor/rEV
Default Setting: nor
nor: Tip = Dot, Ring = Dash, Shaft = Ground
rEV: Tip = Dash, Ring = Dot, Shaft = Ground
MENU MODE
GENERAL GROUP

Page 112 FT-950 OPERATING MANUAL
041 A1A CW AUTO
Function: Enables/disables CW keying while operating
on SSB.
Available Values: OFF/50/On
Default Setting: OFF
OFF: Disables CW keying while operating on SSB.
50: Enables CW keying only while operating SSB on 50
MHz (but not HF).
On: Enables CW keying while operating on SSB (all TX
bands).
NOTE:
This feature allows you to move someone from SSB to
CW without having to change modes on the front panel.
042 A1A BFO
Function: Sets the CW carrier oscillator injection side for
the CW mode.
Available Values: USb/LSb/Auto
Default Setting: USb
USb: Injects the CW carrier oscillator on the USB side.
LSb: Injects the CW carrier oscillator on the LSB side.
Auto: Injects the CW carrier oscillator on the LSB side
while operating on the 7 MHz band and below, and
the USB side while operating on the 10 MHz band
and up.
043 A1A BK-IN
Function: Sets the CW “break-in” mode.
Available Values: SEni/FuLL
Default Setting: SEni
SEni (SEMI): The transceiver will operate in the semi
break-in mode. The delay (receiver recovery) time is set
via the Menu item “044 A1A DELAY044 A1A DELAY
044 A1A DELAY044 A1A DELAY
044 A1A DELAY”.
FuLL: The transceiver will operate in the full break-in
(QSK) mode.
044 A1A DELAY
Function: Adjusts the Keying Delay (receiver recovery)
time on the CW mode.
Available Values: 30 ~ 3000 msec (10 msec/step)
Default Setting: 200 msec
045 A1A PITCH
Function: Adjusts your preferred CW tone pitch.
Available Values: 300 ~ 1050 Hz (50 Hz/step)
Default Setting: 700 Hz
046 A1A WEIGHT
Function: Sets the Dot:Dash ratio for the built-in elec-
tronic keyer.
Available Values: (1:) 2.5 ~ 4.5
Default Setting: 3.0
047 A1A FRQDISP
Function: Selects the frequency Display Format for the
CW mode.
Available Values: dir/OFSt
Default Setting: OFSt
dir (Direct Frequency):Displays the receiver carrier fre-
quency, without any offset added.
When changing modes between
SSB and CW, the frequency dis-
play remains constant.
OFSt (Pitch Offset): This frequency display reflects the
added BFO offset.
048 A1A PC KYNG
Function: Enables/disables CW keying from the “DATA
PTT” terminal (pin 3) on the rear panel’s RTTY/PKT jack
while operating on the CW mode.
Available Values: EnA (Enable)/diS (Disable)
Default Setting: diS (Disable)
049 A1A QSKTIME
Function: Selects the time delay between when the PTT
is keyed and the carrier is transmitted during QSK opera-
tion when using the internal keyer.
Available Values: 15/20/25/30 msec
Default Setting: 15 msec
MENU MODE
MODE-CW GROUP

Page 113FT-950 OPERATING MANUAL
MODE-FM GROUP
056 F3E MIC
Function: Sets the microphone gain for the FM mode.
Available Values: Ur/0 ~ 100
Default Setting: 50
When this menu is set to “Ur”, you may adjust the micro-
phone gain using the front panel’s [MIC GAIN]knob.
057 F3E 28 RPT
Function: Sets the magnitude of the repeater shift on the
28 MHz band.
Available Values: 0 ~ 1000 kHz (10 kHz/step)
Default Setting: 100 kHz
058 F3E 50 RPT
Function: Sets the magnitude of the repeater shift on the
50 MHz band.
Available Values: 0 ~ 4000 kHz (10 kHz/step)
Default Setting: 1000 kHz
MODE-RTTY GROUP
059 RTTY R PLRTY
Function: Selects normal or reverse Mark/Space polarity
for RTTY receive operation.
Available Values: nor/rEV
Default Setting: nor
060 RTTY T PLRTY
Function: Selects normal or reverse Mark/Space polarity
for RTTY transmit operation.
Available Values: nor/rEV
Default Setting: nor
061 RTTY OUT LVL
Function: Sets the RTTY (AFSK) data output level at the
output port (pin 5) of the RTTY/PKT jack.
Available Values: 0 ~ 100
Default Setting: 50
062 RTTY SHIFT
Function: Selects the frequency shift for RTTY (AFSK)
operation.
Available Values:170/200/425/850 Hz
Default Setting: 170 Hz
063 RTTY TONE
Function: Selects the Mark tone for RTTY operation.
Available Values: 1275/2125 Hz
Default Setting: 2125 Hz
MENU MODE
MODE-DATA GROUP
050 DATA DT GAIN
Function: Sets the data input level from the TNC to the
AFSK modulator.
Available Values: 0 ~ 100
Default Setting: 50
051 DATA OUT LVL
Function: Sets the AFSK data output level at the output
port (pin 5) of the RTTY/PKT jack.
Available Values: 0 ~ 100
Default Setting: 50
052 DATA VOX DLY
Function: Adjusts the “VOX” Delay (receiver recovery)
time in the PACKET mode.
Available Values: 30 ~ 3000 msec (10 msec/step)
Default Setting: 300 msec
053 DATA V GAIN
Function: Adjusts the “VOX” Gain in the PACKET mode.
Available Values: 0 ~ 100
Default Setting: 50
054 DATA PKTDISP
Function: Sets the packet frequency display offset.
Available Values: –3000 ~ +3000 Hz (10 Hz/step)
Default: 0 Hz
055 DATA PKT SFT
Function: Sets the carrier point during the SSB packet
operation.
Available Values: –3000 ~ +3000 Hz (10 Hz/step)
Default: 1000 Hz (typical center frequency for PSK31,
etc.)

Page 114 FT-950 OPERATING MANUAL
MODE-SSB GROUP
064 J3E TX BPF
Function: Selects the audio passband of the DSP modula-
tor on the SSB mode.
Available Values: 1-30/1-29/2-28/3-27/4-26
Default Setting: 3-27: 300 ~ 2700 (Hz)
1-30: 100 ~ 3000 (Hz)
1-29: 100 ~ 2900 (Hz)
2-28: 200 ~ 2800 (Hz)
3-27: 300 ~ 2700 (Hz)
4-26: 400 ~ 2600 (Hz)
NOTE:
The apparent power output, when using the widest band-
widths, may seem lower. This is normal, and it occurs be-
cause the available transmitter power is distributed over a
wider bandwidth. The greatest compression of power out-
put, conversely, occurs when using the “4-26” setting (400
~ 2600 Hz), and this setting is highly recommended for
contest or DX pile-up work.
065 J3E LSB CAR
Function: Adjusts the receiver carrier point for the LSB
mode.
Available Values: –200 Hz ~ +200 Hz (10 Hz steps)
Default Setting: 0 Hz
066 J3E USB CAR
Function: Adjusts the receiver carrier point for the USB
mode.
Available Values: –200 Hz ~ +200 Hz (10 Hz steps)
Default Setting: 0 Hz
RX GENERAL GROUP
067 RGEN NB 1 LVL
Function: Adjusts the noise blanking level of the IF Noise
Blanker for short duration pulse noise.
Available Values: 0 ~ 255
Default Setting: 128
068 RGEN NB 2 LVL
Function: Adjusts the noise blanking level of the IF Noise
Blanker for longer duration pulse noise.
Available Values: 0 ~ 255
Default Setting: 128
069 RGEN CNTR LV
Function: Adjusts the parametric equalizer gain of the
Contour filter.
Available Values: –40 ~ +20 dB
Default Setting: –15 dB
070 RGEN CNTR WI
Function: Adjusts the Q-factor of the Contour filter.
Available Values: 1 ~ 11
Default Setting: 10
071 RGEN DNF
Function: Enables/disables the Digital Notch Filter.
Available Values: OFF/On
Default Setting: OFF
072 RGEN DNR
Function: Set the Digital Noise Reduction response.
Available Values: OFF/1 ~ 15
Default Setting: OFF
MENU MODE
IF
BANDWIDTH
“+” Gain
“Q”
“-- ” Gain
CONTOUR “GAIN” AND “Q”

Page 115FT-950 OPERATING MANUAL
073 SCP 1.8 FIX
Function: Selects the scan start frequency of the FIX mode
Spectrum Scope while monitoring on the 160 m amateur
band.
Available Values: 1.800 ~ 1.999 MHz (1 kHz steps)
Default Setting: 1.800 MHz
074 SCP 3.5 FIX
Function: Selects the scan start frequency of the FIX mode
Spectrum Scope while monitoring on the 80 m amateur
band.
Available Values: 3.500 ~ 3.999 MHz (1 kHz steps)
Default Setting: 3.500 MHz
075 SCP 5.2 FIX
Function: Selects the scan start frequency of the FIX mode
Spectrum Scope while monitoring on the 60 m amateur
band.
Available Values: 5.250 ~ 5.499 MHz (1 kHz steps)
Default Setting: 5.250 MHz
076 SCP 7.0 FIX
Function: Selects the scan start frequency of the FIX mode
Spectrum Scope while monitoring on the 40 m amateur
band.
Available Values: 7.000 ~ 7.299 MHz (1 kHz steps)
Default Setting: 7.000 MHz
077 SCP 10.1 FIX
Function: Selects the scan start frequency of the FIX mode
Spectrum Scope while monitoring on the 30 m amateur
band.
Available Values: (1)0.100 ~ (1)0.149 MHz (1 kHz steps)
Default Setting: (1)0.100 MHz
078 SCP 14.0 FIX
Function: Selects the scan start frequency of the FIX mode
Spectrum Scope while monitoring on the 20 m amateur
band.
Available Values: (1)4.000 ~ (1)4.349 MHz (1 kHz steps)
Default Setting: (1)4.000 MHz
MENU MODE
SCOPE GROUP
ADVICE:
This group’s adjustment has no effect if the optional DMU-2000 Data Management Unit is not connected.
079 SCP 18.0 FIX
Function: Selects the scan start frequency of the FIX mode
Spectrum Scope while monitoring on the 17 m amateur
band.
Available Values: (1)8.000 ~ (1)8.199 MHz (1 kHz steps)
Default Setting: (1)8.068 MHz
080 SCP 21.0 FIX
Function: Selects the scan start frequency of the FIX mode
Spectrum Scope while monitoring on the 15 m amateur
band.
Available Values: (2)1.000 ~ (2)1.449 MHz (1 kHz steps)
Default Setting: (2)1.000 MHz
081 SCP 24.8 FIX
Function: Selects the scan start frequency of the FIX mode
Spectrum Scope while monitoring on the 12 m amateur
band.
Available Values: (2)4.800 - (2)4.989 MHz (1 kHz steps)
Default Setting: (2)4.890 MHz
082 SCP 28.0 FIX
Function: Selects the scan start frequency of the FIX mode
Spectrum Scope while monitoring on the 10 m amateur
band.
Available Values: (2)8.000 ~ (2)9.699 MHz (1 kHz steps)
Default Setting: (2)8.000 MHz
083 SCP 50.0 FIX
Function: Selects the scan start frequency of the FIX mode
Spectrum Scope while monitoring on the 6 m amateur band.
Available Values: (5)0.000 ~ (5)3.999 MHz (1 kHz steps)
Default Setting: (5)0.000 MHz

Page 116 FT-950 OPERATING MANUAL
TUNING GROUP
084 TUN DIALSTP
Function: Setting of the Main Tuning Dial knob’s and the
[CLAR/VFO-B]knob’s tuning speed on the SSB, CW,
and AM modes.
Available Values: 1/5/10 Hz
Default Setting: 10 Hz
085 TUN CW FINE
Function: Enabling/disabling of the “Fine” tuning speed
in the CW mode.
Available Values: EnA/diS (ENABLE/DISABLE)
Default Setting: diS (DISABLE)
EnA (ENABLE): Tuning in 1 Hz steps on the CW mode.
diS (DISABLE): Tuning according to the steps deter-
mined via menu item “084 TUN084 TUN
084 TUN084 TUN
084 TUN
DIALSTPDIALSTP
DIALSTPDIALSTP
DIALSTP”.
086 TUN MHz SEL
Function: Selects the tuning steps for the [CLAR/VFO-
B]knob when the [MHz]button is pressed.
Available Values: 1/0.1 MHz
Default Setting: 1 MHz
087 TUN AM STEP
Function: Selects the tuning steps for the microphone’s
[UP]/[DWN]keys in the AM mode.
Available Values: 2.5/5/9/10/12.5 kHz
Default Setting: 5 kHz
088 TUN FM STEP
Function: Selects the tuning steps for the microphone’s
[UP]/[DWN]keys in the FM mode.
Available Values: 5/6.25/10/12.5/20/25 kHz
Default Setting: 5 kHz
089 TUN FM DIAL
Function: Setting of the Main Tuning Dial knob’s and the
[CLAR/VFO-B]knob’s tuning speed in the FM mode.
Available Values: 10/100 Hz
Default Setting: 100 Hz
090 TUN MY BAND
Function: Programs a band to be skipped while selecting
bands using the [CLAR/VFO-B]knob.
To program the band to be skipped, rotate the [CLAR/
VFO-B]knob to recall the band to be skipped while se-
lecting bands via the [CLAR/VFO-B]knob, then press
the [ENT]button to change this setting to “ON” (a “dd
dd
d”
notation will replace the “EE
EE
E” notation). Repeat the same
procedure to cancel the setting (skipped “Off”: “dd
dd
d” nota-
tion appears).
TX AUDIO GROUP
091 TAUD EQ1 FRQ
Function: Selects the center frequency of the lower range
for the parametric microphone equalizer.
Available Values: OFF/100 ~ 700 Hz (100 Hz/step)
Default Setting: OFF
OFF: The equalizer gain and Q-factor are set to fac-
tory defaults (flat).
100 ~ 700: Center frequencies of 100 Hz ~ 700 Hz.
You may adjust the equalizer gain and Q-factor at this se-
lected audio frequency via menu items “092 TAUD EQ1092 TAUD EQ1
092 TAUD EQ1092 TAUD EQ1
092 TAUD EQ1
LVLLVL
LVLLVL
LVL” and “093 TAUD EQ1 BW093 TAUD EQ1 BW
093 TAUD EQ1 BW093 TAUD EQ1 BW
093 TAUD EQ1 BW”.
092 TAUD EQ1 LVL
Function: Adjusts the equalizer gain of the low range of
the parametric microphone equalizer.
Available Values: –20 ~ +10
Default Setting: +5
093 TAUD EQ1 BW
Function: Adjusts the Q-factor of the low range of the
parametric microphone equalizer.
Available Values: 1 ~ 10
Default Setting: 10
094 TAUD EQ2 FRQ
Function: Selects the center frequency of the middle range
for the parametric microphone equalizer.
Available Values: OFF/700 ~ 1500 Hz (100 Hz/step)
Default Setting: OFF
OFF: The equalizer gain and Q-factor are set to fac-
tory defaults (flat).
700 ~ 1500: Center frequencies of 700 Hz ~ 1500 Hz.
You may adjust the equalizer gain and Q-factor at this se-
lected audio frequency via menu items “095 TAUD EQ2095 TAUD EQ2
095 TAUD EQ2095 TAUD EQ2
095 TAUD EQ2
LVLLVL
LVLLVL
LVL” and “096 TAUD EQ2 BW096 TAUD EQ2 BW
096 TAUD EQ2 BW096 TAUD EQ2 BW
096 TAUD EQ2 BW”.
095 TAUD EQ2 LVL
Function: Adjusts the equalizer gain of the middle range
of the parametric microphone equalizer.
Available Values: –20 ~ +10
Default Setting: +5
096 TAUD EQ2 BW
Function: Adjusts the Q-factor of the middle range of the
parametric microphone equalizer.
Available Values: 1 ~ 10
Default Setting: 10
MENU MODE

Page 117FT-950 OPERATING MANUAL
097 TAUD EQ3 FRQ
Function: Selects the center frequency of the high range
for the parametric microphone equalizer.
Available Values: OFF/1500 ~ 3200 Hz (100 Hz/step)
Default Setting: OFF
OFF: The equalizer gain and Q-factor are set to
factory defaults (flat).
1500 ~ 3200: Center frequencies of 1500 Hz ~ 3200 Hz.
You may adjust the equalizer gain and Q-factor in this se-
lected audio frequency via menu items “098 TAUD EQ3098 TAUD EQ3
098 TAUD EQ3098 TAUD EQ3
098 TAUD EQ3
LVLLVL
LVLLVL
LVL” and “099 TAUD EQ3 BW099 TAUD EQ3 BW
099 TAUD EQ3 BW099 TAUD EQ3 BW
099 TAUD EQ3 BW”.
098 TAUD EQ3 LVL
Function: Adjusts the equalizer gain of the high range of
the parametric microphone equalizer.
Available Values: –20 ~ +10
Default Setting: +5
099 TAUD EQ3 BW
Function: Adjusts the Q-factor of the high range of the
parametric microphone equalizer.
Available Values: 1 ~ 10
Default Setting: 10
100 TAUD PE1 FRQ
Function: Selects the center frequency of the lower range
for the parametric microphone equalizer when the speech
processor is activated.
Available Values: OFF/100 ~ 700 Hz (100 Hz/step)
Default Setting: 200 Hz
OFF: The equalizer gain and Q-factor are set to fac-
tory defaults (flat).
100 ~ 700: Center frequencies of 100 Hz ~ 700 Hz.
You may adjust the equalizer gain and Q-factor at this se-
lected audio frequency via menu items “101 TAUD PE1101 TAUD PE1
101 TAUD PE1101 TAUD PE1
101 TAUD PE1
LVLLVL
LVLLVL
LVL” and “102 TAUD PE1 BW102 TAUD PE1 BW
102 TAUD PE1 BW102 TAUD PE1 BW
102 TAUD PE1 BW”.
101 TAUD PE1 LVL
Function: Adjusts the equalizer gain of the low range of
the parametric microphone equalizer when the speech pro-
cessor is activated.
Available Values: –20 ~ +10
Default Setting: 0
102 TAUD PE1 BW
Function: Adjusts the Q-factor of the low range of the
parametric microphone equalizer when the speech proces-
sor is activated.
Available Values: 1 ~ 10
Default Setting: 2
MENU MODE
103 TAUD PE2 FRQ
Function: Selects the center frequency of the middle range
for the parametric microphone equalizer when the speech
processor is activated.
Available Values: OFF/700 ~ 1500 Hz (100 Hz/step)
Default Setting: 800 Hz
OFF: The equalizer gain and Q-factor are set to fac-
tory defaults (flat).
700 ~ 1500: Center frequencies of 700 Hz ~ 1500 Hz.
You may adjust the equalizer gain and Q-factor at this se-
lected audio frequency via menu items “104 TAUD PE2104 TAUD PE2
104 TAUD PE2104 TAUD PE2
104 TAUD PE2
LVLLVL
LVLLVL
LVL” and “105 TAUD PE2 BW105 TAUD PE2 BW
105 TAUD PE2 BW105 TAUD PE2 BW
105 TAUD PE2 BW”.
104 TAUD PE2 LVL
Function: Adjusts the equalizer gain of the middle range
of the parametric microphone equalizer when the speech
processor is activated.
Available Values: –20 ~ +10
Default Setting: 0
105 TAUD PE2 BW
Function: Adjusts the Q-factor of the middle range of the
parametric microphone equalizer when the speech proces-
sor is activated.
Available Values: 1 ~ 10
Default Setting: 1
106 TAUD PE3 FRQ
Function: Selects the center frequency of the high range
for the parametric microphone equalizer when the speech
processor is activated.
Available Values: OFF/1500 ~ 3200 Hz (100 Hz/step)
Default Setting: 2100 Hz
OFF: The equalizer gain and Q-factor are set to
factory defaults (flat).
1500 ~ 3200: Center frequencies of 1500 Hz ~ 3200 Hz.
You may adjust the equalizer gain and Q-factor in this se-
lected audio frequency via menu items “107 TAUD PE3107 TAUD PE3
107 TAUD PE3107 TAUD PE3
107 TAUD PE3
LVLLVL
LVLLVL
LVL” and “108 TAUD PE3 BW108 TAUD PE3 BW
108 TAUD PE3 BW108 TAUD PE3 BW
108 TAUD PE3 BW”.
107 TAUD PE3 LVL
Function: Adjusts the equalizer gain of the high range of
the parametric microphone equalizer when the speech pro-
cessor is activated.
Available Values: –20 ~ +10
Default Setting: 0
108 TAUD PE3 BW
Function: Adjusts the Q-factor of the high range of the
parametric microphone equalizer when the speech proces-
sor is activated.
Available Values: 1 ~ 10
Default Setting: 1
TX AUDIO GROUP

Page 118 FT-950 OPERATING MANUAL
114 TGEN VOX SEL
Function: Selects the audio input source for triggering TX
during VOX operation.
Available Values: nic/dAtA
Default Setting: nic
nic (MIC): The VOX function will be activated by mi-
crophone audio input.
dAtA (DATA): The VOX function will be activated by
data audio input port (pin 1) of the RTTY/
PKT Jack.
115 TGEN V GAIN
Function: Adjusts the “VOX” Gain on the SSB/AM/FM
modes.
Available Values: 0 ~ 100
Default Setting: 50
116 TGEN VOX DLY
Function: Adjusts the “VOX” Delay (receiver recovery)
time on the SSB/AM/FM modes.
Available Values: 30 ~ 3000 msec (10 msec/step)
Default Setting: 500 msec
117 TGEN ANTIVOX
Function: Adjusts the Anti-VOX Trip Gain, which is the
level of negative AF feedback of receiver audio to the mi-
crophone, to prevent receiver audio from activating the
transmitter (via the microphone) during VOX operation.
Available Values: 0 ~ 100
Default Setting: 50
118 TGEN EMRGNCY
Function: Enables Tx/Rx operation on the Alaska Emer-
gency Channel, 5167.5 kHz.
Available Values: EnA(ENABLE)/diS(DISABLE)
Default Setting: diS(DISABLE)
When this Menu Item is set to “EnA(ENABLE),” the spot
frequency of 5167.5 kHz will be enabled. The Alaska
Emergency Channel will be found between the Memory
channels “P-1” and “01 (or 1-01).”
Important: The use of this frequency is restricted to sta-
tions operating in or near Alaska, and only for emergency
purposes (never for routine operations). See §97.401(c)
of the FCC’s regulations for details.
TX GENERAL GROUP
109 TGEN PROCLVL
Function: Sets a compression level of the Speech Proces-
sor.
Available Values: 1 ~ 100
Default Setting: 50
110 TGEN EXT TUN
Function: Enable/disable the optional FC-40 Antenna
Tuner.
Available Values: itu/Etu (INTERNAL TUNER/EXTER-
NAL TUNER)
Default Setting: itu (INTERNAL)
itu (INTERNAL TUNER): The [TUNE]button will ac-
tivate the internal Antenna
Tuner.
Etu (EXTERNAL TUNER): The [TUNE]button will ac-
tivate the optional FC-40
Antenna Tuner.
111 TGEN TX PWR
Function: Sets a transmitter output level.
Available Values: 5 ~ 100 %
Default Setting: 100 %
112 TGEN AM CAR
Function: Sets a carrier power output level.
Available Values: 0 ~ 100
Default Setting: 50
113 TGEN PWRCTRL
Function: Setting the menu item “111 TGEN TX PWR111 TGEN TX PWR
111 TGEN TX PWR111 TGEN TX PWR
111 TGEN TX PWR”.
Available Values: ALL/CAr
Default Setting: ALL
ALL: The Menu Item “111 TGEN TX PWR111 TGEN TX PWR
111 TGEN TX PWR111 TGEN TX PWR
111 TGEN TX PWR” affects all
modes except AM.
CAr: The Menu Item “111 TGEN TX PWR111 TGEN TX PWR
111 TGEN TX PWR111 TGEN TX PWR
111 TGEN TX PWR” affects all
modes except SSB. In this case, the SSB output
power will be set to maximum, regardless of the
setting of the Menu Item “111 TGEN TX PWR111 TGEN TX PWR
111 TGEN TX PWR111 TGEN TX PWR
111 TGEN TX PWR”.
MENU MODE
