Technolift Sl-9l Instruction manual

IMPORTANT:

Read this manual completely before

installing or operating lift

Installation, Operation & Maintenance Manual

TWO POST LIFT

Showroom - Distribution Centre

8275, 17e Avenue, Montréal, Qc., Canada H1Z 4J9

1-800-361-4095 • 514-328-2300 • Fax 514-328-4684

AUTOMOTIVE EQUIPMENT

ECHNOLIFT

SL-9L 9,000 LBS.

The speciﬁcations stated on this brochure are not binding.

We reserve the right to change the speciﬁcation without notice

Installation, Operation & Maintenance Manual

NOTES

Showroom - Distribution Centre

8275, 17e Avenue, Montréal, Qc., Canada H1Z 4J9

1-800-361-4095 • 514-328-2300 • Fax 514-328-4684

_______________________________________________________________________________

CONTENTS

Products features and specification…………………………………………………………...1

Installation requirement...................................................................3

Steps of installation ........................................................................4

Explosive view..............................................................................17

Test run……………............................................................................19

Operation instruction.....................................................................21

Maintenance.................................................................................21

Trouble shooting……………………………………………………………………………………….22

Part list……………………………………………………………………………………………………..23

1

I. PRODUCT FEATURES AND SPECIFICATIONS

FLOORPLATE CHAIN-DRIVE TWO POST LIFT

Model SL-9L (See Fig. 1)

·Dual hydraulic cylinders, designed and made as standards, utilizing oil seal in

cylinder

· Self- lubricating UHMW Polyethylene sliders and bronze bush

·Floor-plate design, provide unobstructed floor space

· Single-point safety release, and dual safety design

·With 4pcs of 3-stages arms

. Stackable rubber pad with 1.5” and 2.5” extension adaptors

MODEL SL-9L SPECIFICATIONS

Model Style Lifting

Capacity Lifting

Time Lifting Height Overall

Height Overall

Width

Between

Columns

Minimum

Pad Height Gross

Weight Motor

SL-9L Floor-plate

Chain-drived

4000kg

9,000lbs 30S 1940-2169mm

76 3/8”–85 3/8”

2841mm

111 7/8”

3460mm

136 1/4”

2850mm

112 1/4” 83-318mm

3 1/2’’-12 1/2’’

706Kg

1,488 lbs

2.0 HP

Fig. 1

2

Fig. 2

For Model SL-9L

100-3/4”

28”~50-5/8 ”

3

II. INSTALLATION REQUIREMENT

A. TOOLS REQUIRED

Rotary Hammer Drill (Φ19)

Hammer

Level Bar

English Spanner (12")

Ratchet Spanner With Socket (28#)

Wrench set

Carpenter’s Chalk

Screw Sets

Tape Measure (7.5m)

Pliers

Socket Head Wrench (6#)

Lock Wrench

(10#, 13#, 14#, 15#, 17#, 19#, 24#, 27#)

Fig. 3

4

B. SPECIFICATIONS OF CONCRETE (See Fig. 4).

Specifications of concrete must be adhered to the specification as following.

Failure to do so may result in lift and/or vehicle falling.

1. Concrete must be thickness 100mm minimum and without reinforcing steel bars,

and must be dried completely before the installation.

2. Concrete must be in good condition and must be of test strength 3,000psi

(210kg/cm²) minimum.

3. Floors must be level and no cracks.

Fig. 4

C. POWER SUPPLY

The electrical source must be 2HP minimum. The source cable size must be 2.5mm²

and in good condition of contacting with floor.

III.STEPS OF INSTALLATION

A. Location of Installation

Check and insure the installation location (concrete, layout, space size etc.) is

suitable for lift installation.

B. Use a carpenter’s chalk line to establish installation layout of baseplate (See Fig. 5).

Fig. 5

Chalk line

66

Concrete intensity must be

3000psi (210kg/cm²) minimum

136-1/4”

5

C. Check the parts before assembly.

1. Packaged lift and hydraulic power unit (See Fig. 6).

Fig. 6

2. Move the lift aside with fork lift or hoist, and open the outer packing carefully, take off

the parts from upper and inside the column, take out the parts box, check the parts

according to the shipment parts list(See Fig. 7).

Fig. 7

3. Loosen the screws of the upper package stand, take off the upper column and remove

the package stand.

4. Move aside the parts and check the parts according to the shipment parts list.

(See Fig. 8, Fig. 9).

Shipment Parts list

Floor cover

Parts box

42A

Fig. 9

Parts in the parts box (42A)

Fig. 8

6

5. Open the carton of parts and check the parts according to parts box list

(See Fig. 10).

D. Position powerside columns

Lay down two columns on the installation site parallelly, position the powerside

column according to the actual installation site. Usually, it is suggested to install

powerside column on the front-right side from which vehicles are driven to the lift

(See Fig. 11).

Fig. 11

Car in Direction

Powerside column

Offside column

Assemble top-plate

using M10*35 hex

bolt with nut and lock

washer

Fig. 10

7

E. Connecting the cables

1．Put down columns and then push the carriages higher than chain pulley (See Fig. 12).

2．Push the carriages to the bottom of the columns (See Fig. 13).

Fig. 12

Fig. 13

B. Push the carriages higher than chain

pulley, cable pass through from the top

of the carriages to the hole of the

bottom steel plate of the carriages

A. Cable pass in the carriage

C. Pull out cable

8

F. Position columns (See Fig. 14)

Check the columns plumbness with level bar, and adjusting with the shims if the

columns are not vertical.

G. Fix anchor bolts

1. Prepare anchor bolts (See Fig. 15).

Fig. 15

2. Using the prescribed rotary hammer drill, and drill all the anchor holes and install the

anchor bolts. Then tighten the anchor bolts (See Fig. 16).

Note: Torque of Anchors is 150N.m .Minimum embedment of Anchors is 3-1/2”.

Fig. 16

Fig. 14

Lock washer

Washer

Nut

90mm

Check the columns plumbness

with level bar from front and

side

136-1/4”

112-1/4”

9

H. Lift the carriages up by hand and make them be locked at the same level

(See Fig. 17).

Fig. 17

10

I. Install cable (See Fig. 18)

Fig. 18

The fitting of cable pass

through the hole of the

carriages and be screwed

with two cable nuts.

11

J. Assembly oil hose assy.(See Fig. 19).

Fig. 19

71

68

71A

71

69A

70

71

69

71

12

K. Install hydraulic power unit and oil hose assy. (See Fig. 20).

Fig. 20

Using 19#

ratchet spanner to

Lock the nut

75

68

Fix the oil hose by

retainer.

5

13

60

Safety cable

connecting

direction

L. Install safety device and safety cable (See Fig. 21).

NOTE: 1. Assemble safety cable from offside safety assy.

2. Pay attention to the connecting direction of safety cable.

Fig. 21

View A

View B

2

14

Floor Cover

M. Assemble floor cover (See Fig. 22).

N. Install lifting arms and adjust the arm locks

1. Install the lifting arms (See Fig. 23, 24)

Fig. 23

Snap Ring

Use the 8#socket head

wrench to loosen the

socket bolt

Fig. 24

Spanner loose screw

Fig.２２

15

2. Lowing the carriages down to the lowest position, then use the 8# socket head wrench

to loosen the socket bolt (See Fig. 24)

3. Adjust the moon gear as arrow direction (See Fig. 25).

4. Adjust the moon gear and arm lock to make it to be meshed, then tighten bolts of arm

lock (See Fig. 26).

O. Tighten all the hydraulic fittings, and fix the oil hose by retainer.

Note: In consideration of Power Unit’s durability and keep the equipment running in the

perfect condition, please use Hydraulic Oil 46

P.Install Electrical System

Connect the power source on the data plate of Power Unit.

Note: 1. For the safety of operators, the power wiring must contact the floor well.

2. Pay attention to the direction of rotations when using 380V, three phase motors.

Single phase motor (See Fig. 27).

1. Connecting the two power supply lines (active wire Land neutral wire N) to

terminals of AC contactor marked L1, L2 respectively.

2. Connecting the two motor wires to terminals of AC contactor marked T1, T2.

3. Connecting A2 to L2 of AC contactor.

Fig. 25

Adjust moon gear

Locking the bolts after

the moon gear and

arm lock engaged well

Fig. 26

16

4. Terminal 4# of control button is connected with terminals A1of AC contactor;

Terminal 3# of control button is connected with terminals L1of AC contactor.

Fig. 27

Single phase

17

IV. EXPLODED VIEW Model SL-9L

Fig.28

Car-in

direction
