TechVision NS64P8N8 User manual

64 Channel NVR 2U
NS64P8N8

Notes
Please read this user manual carefully to ensure that you can use the device correctly and
safely.
There may be several technically incorrect places or printing errors in this manual. The
updates will be added into the new version of this manual. The contents of this manual are
subject to change without notice.
This device should be operated only from the type of power source indicated on the
marking label. The voltage of the power must be verified before using the same. Kindly
remove the cables from the power source if the device is not to be used for a long period of
time.
Do not install this device near any heat sources such as radiators, heat registers, stoves or
other devices that produce heat.
Do not install this device near water. Clean only with a dry cloth.
Do not block any ventilation openings and ensure proper ventilation around the machine.
Do not power off the device at normal recording condition.
This machine is for indoor use only. Do not expose the machine in rain or moist
environment. In case any solid or liquid get inside the machine’s case, please turn off the
device immediately and get it checked by a qualified technician.
Do not try to repair the device by yourself without technical aid or approval.
When this product is in use, the relevant contents of Microsoft, Apple and Google will be
involved in. The pictures and screenshots in this manual are only used to explain the usage of
our product. The ownerships of trademarks, logos and other intellectual properties related to
Microsoft, Apple and Google shall belong to the above-mentioned companies.
This manual is suitable for many models. All examples and pictures used in the manual are
from one of the models for reference purpose.

Contents
NVR User Manual
Contents
1 Introduction...................................................................................................................1
1.1 Summary.......................................................................................................................1
1.2 Features.........................................................................................................................1
1.3 Front Panel Descriptions...............................................................................................4
1.4 Rear Panel Descriptions................................................................................................5
1.5 Connections...................................................................................................................8
2 Basic Operation Guide................................................................................................11
2.1 Startup & Shutdown....................................................................................................11
2.1.1 Startup..............................................................................................................11
2.1.2 Shutdown..........................................................................................................11
2.2 Remote Controller.......................................................................................................11
2.3 Mouse Control.............................................................................................................13
2.4 Text-input Instruction..................................................................................................13
2.5 Common Button Operation .........................................................................................14
3 Wizard & Main Interface...........................................................................................15
3.1 Startup Wizard.............................................................................................................15
3.2 Main Interface.............................................................................................................21
3.2.1 Main Interface Introduction..............................................................................21
3.2.2 Setup Panel.......................................................................................................23
3.2.3 Main Functions.................................................................................................25
4 Camera Management..................................................................................................27
4.1 Add/Edit Camera.........................................................................................................27
4.1.1 Add Camera......................................................................................................27
4.1.2 Edit Camera......................................................................................................29
4.2 Add/Edit Camera Group..............................................................................................30
4.2.1 Add Camera Group...........................................................................................30
4.2.2 Edit Camera Group...........................................................................................31
4.2.3 IP Planning.......................................................................................................31
5 Live Preview Introduction..........................................................................................33
5.1 Preview Interface Introduction....................................................................................33
5.2 Preview Mode .............................................................................................................34
5.2.1 Preview By Display Mode................................................................................34
5.2.2 Quick Sequence View.......................................................................................36
5.2.3 Camera Group View In Sequence.....................................................................37
5.2.4 Scheme View In Sequence ...............................................................................38
5.3 POS Settings ...............................................................................................................40
5.4 Preview Image Configuration .....................................................................................43
5.4.1 OSD Settings....................................................................................................43
5.4.2 Image Settings..................................................................................................43
5.4.3 Mask Settings...................................................................................................44
5.4.4 Fisheye Settings................................................................................................45

Contents
NVR User Manual
5.4.5 Image Adjustment ............................................................................................45
6 PTZ...............................................................................................................................48
6.1 PTZ Control Interface Introduction.............................................................................48
6.2 Preset Setting...............................................................................................................51
6.3 Cruise Setting..............................................................................................................52
7 Record & Disk Management......................................................................................54
7.1 Record Configuration..................................................................................................54
7.1.1 Mode Configuration.........................................................................................54
7.1.2 Advanced Configuration...................................................................................56
7.2 Encode Parameters Setting..........................................................................................56
7.3 Schedule Setting..........................................................................................................57
7.3.1 Add Schedule....................................................................................................57
7.3.2 Record Schedule Configuration........................................................................59
7.4 Record Mode...............................................................................................................60
7.4.1 Manual Recording............................................................................................60
7.4.2 Timing Recording.............................................................................................60
7.4.3 Motion Based Recording..................................................................................60
7.4.4 Sensor Based Recording...................................................................................60
7.4.5 Intelligence Recording .....................................................................................61
7.5 Disk.............................................................................................................................61
7.5.1 Disk Management ............................................................................................61
7.5.2 Storage Mode Configuration............................................................................62
7.5.3 View Disk and S.M.A.R.T. Information ...........................................................63
8 Playback & Backup.....................................................................................................65
8.1 Instant Playback ..........................................................................................................65
8.2 Playback Interface Introduction ..................................................................................65
8.3 Smart Playback............................................................................................................68
8.4 Record Search, Playback & Backup............................................................................70
8.4.1 Search, Playback & Backup by Time-sliced Image..........................................71
8.4.2 Smart Search ....................................................................................................73
8.4.3 Search, Playback & Backup by Time ...............................................................74
8.4.4 Search, Playback & Backup by Event ..............................................................74
8.4.5 Search & Playback by Tag................................................................................75
8.4.6 Image Management..........................................................................................76
8.4.7 View Backup Status..........................................................................................76
9 Alarm Management ....................................................................................................77
9.1 Sensor Alarm...............................................................................................................77
9.2 Motion Alarm..............................................................................................................78
9.2.1 Motion Configuration.......................................................................................78
9.2.2 Motion Alarm Handling Configuration ............................................................79
9.3 Intelligence Alarm.......................................................................................................79
9.3.1 Object Detection...............................................................................................79
9.3.2 Exception..........................................................................................................81
9.3.3 Tripwire............................................................................................................82
9.3.4 Intrusion Detection...........................................................................................83
9.4 Exception Alarm..........................................................................................................85

Contents
NVR User Manual
9.4.1 IPC Offline Settings .........................................................................................85
9.4.2 Exception Handling Settings............................................................................85
9.5 Alarm Event Notification ............................................................................................86
9.5.1 Alarm-out .........................................................................................................86
9.5.2 E-mail...............................................................................................................86
9.5.3 Display.............................................................................................................86
9.5.4 Buzzer ..............................................................................................................87
9.5.5 Push Message...................................................................................................87
9.6 Manual Alarm .............................................................................................................87
9.7 View Alarm Status.......................................................................................................88
10 Account & Permission Management .........................................................................89
10.1 Account Management................................................................................................89
10.1.1 Add User.........................................................................................................89
10.1.2 Edit User.........................................................................................................90
10.2 User Login & Logout................................................................................................92
10.3 Permission Management ...........................................................................................92
10.3.1 Add Permission Group ...................................................................................92
10.3.2 Edit Permission Group ...................................................................................93
10.4 Black and White List.................................................................................................93
10.5 Preview On Logout ...................................................................................................94
10.6 View Online User......................................................................................................94
11 Device Management....................................................................................................95
11.1 Network Configuration..............................................................................................95
11.1.1 TCP/IP Configuration.....................................................................................95
11.1.2 Port Configuration..........................................................................................98
11.1.3 PPPoE Configuration......................................................................................99
11.1.4 DDNS Configuration......................................................................................99
11.1.5 E-mail Configuration....................................................................................102
11.1.6 UPnP Configuration......................................................................................103
11.1.7 NAT Configuration.......................................................................................104
11.1.8 FTP Configuration........................................................................................104
11.1.9 Platform Access............................................................................................104
11.1.10 SNMP.........................................................................................................105
11.1.11 View Network Status ..................................................................................106
11.2 Basic Configuration.................................................................................................106
11.2.1 Common Configuration................................................................................106
11.2.2 Date and Time Configuration .......................................................................107
11.3 Factory Default........................................................................................................108
11.4 Device Software Upgrade........................................................................................108
11.5 Backup and Restore.................................................................................................109
11.6 Restart Automatically..............................................................................................109
11.7 View Log.................................................................................................................110
11.8 View System Information........................................................................................110
12 Face Detection and Comparison .............................................................................. 111
12.1 Face Detection Settings........................................................................................... 111
12.2 Target Database Settings .........................................................................................112
12.3 Face Comparison.....................................................................................................115

Contents
NVR User Manual
12.3.1 Face Comparison..........................................................................................115
12.3.2 Face Match Alarm Settings ..........................................................................116
12.4 Face Search and Playback.......................................................................................117
12.5 Smart Playback by Face Search ..............................................................................121
13 Remote Surveillance..................................................................................................123
13.1 Mobile Client Surveillance......................................................................................123
13.2 Web LAN Access ....................................................................................................123
13.3 Web WAN Access....................................................................................................124
13.4 Web Remote Control...............................................................................................125
13.4.1 Remote Preview ...........................................................................................126
13.4.2 Remote Playback..........................................................................................129
13.4.3 Remote Backup ............................................................................................130
13.4.4 Remote Configuration..................................................................................130
Appendix A FAQ.................................................................................................................131
Appendix B Calculate Recording Capacity......................................................................137
Appendix C Compatible Device List.................................................................................138

Introduction
NVR User Manual
1
1Introduction
1.1 Summary
Based on the most advanced SOC technology and embedded system in the field, this series of
the NVR adopt the new designed human interface and support the smart management of the IP
camera and the record search of slice. This series of the NVR which are powerful and easy to
use are provided with excellent image quality and stable system. They are centralized
monitoring management products with high performance and high quality specially designed
for network video monitoring field.
This series of the NVR can be widely used to security system of banks at home and abroad,
schools, intelligent mansions, traffic, environmental protection, supermarkets, petrol service
stations, residential quarters and factories and so on.
1.2 Features
Basic Functions
Support network device access including IP camera/dome and the third party IP cameras
Some NVRs support the latest H.265 video coding stream and a mixture input of H.265
and H.264 IP cameras
Support standard ONVIF protocol
Support dual stream recording of each camera
Support IP cameras to be added quickly or manually
Support batch or single configuration of the cameras’OSD, video parameters, mask,
motion and so on
Support a maximum of 8 user permission groups including Administrator, Advanced and
Ordinary which are the default permission groups of the system
Support a maximum of 16 users to be created, multiple web clients login by using one
username at the same time and the user’s permission control to be enabled or disabled
Support a maximum of 10 web clients login at the same time
Live Preview
Support 4K×2K/1920×1080/1280×1024 HDMI and 1920×1080/1280×1024 VGA high
definition synchronous display
Support multi-screen modes such as 1/4/6/8/9/13/16/25/36
Support auto adjustment of the camera’s image display proportion
Support audio monitoring of the camera to be enabled or disabled
Support manual snap of the preview camera
Support the sequence of the preview cameras to be adjusted
Support display mode to be added and saved and the saved modes can be called directly
Support quick tool bar operation of the preview window
Support camera group view and scheme view in sequence, quick sequence view and dwell
time setting
Support motion detection and video mask

Introduction
NVR User Manual
2
Support multiple popular P.T.Z. control protocol and setup of the preset and cruise
Support direct mouse control of the IP dome including rotating, zoom, focusing and so on
Support single camera image to be zoomed by sliding the scroll wheel of the mouse
Support any area of the image to be zoomed in to a maximum of 16 times of the current
size
Support image and lens adjustment (only available for some cameras)
Support quick camera adding in the camera window of the live preview interface
The live camera sequence of the web client will keep consistent with that of the NVR after
adjusting the live camera sequence of the NVR, but the live camera sequence of the NVR will
not be changed if that of the web client is changed
Disk Management
The NVRs with the 3U case can add a maximum of 16 SATA HDDs; a maximum of 8
SATA HDDs with the 2U case, a maximum of 4 SATA HDDs with the 1.5U case, a maximum
of 2 SATA HDDs with the 1U case and a maximum of 1 SATAHDD with the small 1U case
Each SATA interface of the NVR supports the HDDs with max 8TB storage capacity
Some of the NVRs support record to be backed up by e-SATA HDD
Support disk group configuration and management and each camera can be added into
different disk groups with different storage capacity
Support disk information and disk working status viewing
Support batch formatting of the disks
Record Configuration
Support main stream and sub stream recording at the same time and batch or single
configuration of the record stream
Support manual and auto record modes
Support schedule recording, sensor alarm recording and motion detection recording, etc
Support schedule recording and event recording setting with different record streams
Support record schedule setting and recycle recording
Support pre recording and delay recording configuration of the event recording
Record Playback
Support time scale operation in quick playback and the playback date and time can be set
randomly by scrolling the mouse; the time interval of the time scale can be zoomed
Support record searching by time slice/time/event/tag
Support time view and camera view in searching by time slice mode
Support time slice searching by month, by day, by hour and by minute and time slice to be
displayed with camera thumbnail
Support a maximum of 16 cameras to be searched by time
Support event searching by manual/motion/sensor/intelligent events
Support tag searching by the manual added tags
Support instant playback of the selected camera in the live preview interface
Support a maximum of 16 synchronous playback cameras
Support acceleration(maximum 32 times of the normal speed), deceleration (minimum

Introduction
NVR User Manual
3
1/32 times of the normal speed) and 30s’addition or reduction to current playing time
Record Backup
Support record to be backed up through USB (U disk, mobile HDD) or e-SATA interface
Support record to be backed up by time/event/image searching
Support record cutting for backing up when playing back
Support a maximum of 10 backup tasks in background and backup status viewing
Alarm Management
Support alarm schedule setting
Support enabling or disabling of the motion detection, external sensor alarm input,
intelligence alarm and exception alarms including IP address conflict alarm, disk IO error
alarm, disk full alarm, no disk alarm, illegal access alarm, network disconnection alarm, IPC
offline alarm and so on, alarm trigger configuration supportable
Support IPC offline alarm trigger configuration of PTZ, snap, pop-up video, etc.
Support event notification modes of alarm-out, pop-up video, pop-up message box, buzzer,
e-mail and so on
The snapped images can be attached into the e-mail when alarm linkage is triggered
Support alarm status view of alarm-in, alarm-out, motion detection and exception alarm
Support alarm to be triggered and cleared manually
Support system auto reboot when exception happens
Network Functions
Support TCP/IP and PPPoE, DHCP, DNS, DDNS, UPnP, NTP, SMTP protocol and so on
Support black and white list function and the IP address/IP segment/MAC address can be
allowed or blocked.
Support multiple browsers including IE8/9/10/11, Firefox, Opera, Chrome (available only
for the versions lower than 45) and Safari in MAC system
Support remote achievement, configuration, import and export of the NVR parameters and
other system maintenance operations including remote upgrading and system restart
Support remote camera configuration of the NVR including video parameters, image
quality and so on
Support remote searching, playback and backup of the NVR
Support manual alarm to be triggered and cleared remotely
The auto-focusing camera can be adjusted through web client (support zoom in/out, but
one key focus is not currently supported)
Support NVMS or other platform management software to access the NVR and manage it
Support NAT function and QRCode scanning by mobile phone and PAD
Support mobile surveillance by phones or PADs with iOS or Android OS
Support NVR to be accessed remotely through telnet and the telnet function can be
enabled or disabled
If one camera recording is enabled or disabled manually through web client, it will be
simultaneously enabled or disabled in the NVR
Other Functions

Introduction
NVR User Manual
4
The NVR can be controlled and operated by the buttons on the front panel, the remote
controller and the mouse
Setting interfaces can be switched to one another conveniently by clicking the main menus
on the top of the setting interfaces
Support NVR information viewing including basic, camera status, alarm status, record
status, network status, disk and backup status
Support factory restoring, import and export of the system configuration, log view and
export and local upgrading by USB mobile device
Support auto recognition of the displayer’s resolution
You can click the right mouse button at any interface to go back to the upper interface
You can click the middle mouse button at any interface to go to the live view interface
The display language and video format of the NVR will not be changed and the system
logs will be reserved if you reset the NVR to factory default
Press and hold the right mouse button for 5 seconds in any interface to switch the output to
VGAand the NVR will display the video at the lowest resolution which the NVR supports
1.3 Front Panel Descriptions
The following descriptions are for reference only.
Type I:
Name
Descriptions
REC
When recording, the light is blue
Net
When access to network , the light is blue
Power
Power indicator, when connection , the light is blue
Fn
No function temporarily
Type II:
Name
Descriptions
Power
Power Indicator, when connected, the light is blue
HDD
The light turns blue when reading/writing HDD
Net
The light turns blue when it is able to access the network
Backup
The light turns blue when backing up files and data
Play
The light turns blue when playing video
REC
Power Indicator, when connected, the light is blue
AUDIO /+
1. Adjust audio 2. Increase the value in setup
P.T.Z / -
1. Enter PTZ mode 2. Decrease the value in setup
MENU
Enter Menu in live
INFO
Check the information of the device
BACKUP
Enter backup mode in live
SEARCH
Enter search mode in live
Exit
Exit the current interface

Introduction
NVR User Manual
5
Name
Descriptions
Manually record
Play/Pause
Speed down
Speed up
1-9
Input digital number and select camera
0/--
Input number 0, the number above 10
Direction Key
Change direction
Multi-Screen Switch
Change the screen mode
Enter
Confirm selection
USB
To connect external USB device like USB mouse or USB
flash
1.4 Rear Panel Descriptions
Here we only take a part of real panels for example to introduce their interfaces and
connections. The interfaces and locations of the interfaces are only for references. Please take
the real object as the standard.
No.
Name
Descriptions
1
ALARM OUT
Relay output; connect to external alarm
2
GND
Grounding
3
AUDIO IN
Audio input; connect to audio input device, like microphone,
pickup, etc
4
DC12V
DC12V power input
5
LAN
Network port
6
VGA
Connect to monitor
7
ALARM IN
Alarm inputs for connecting sensors
8
HDMI
Connect to high definition display device
9
USB
Connect USB storage device or USB mouse
10
AUDIO OUT
Audio output; connect to sound box
11
RS485
Connect to keyboard.A is TX+; B is TX-

Introduction
NVR User Manual
6
No.
Name
Descriptions
1
VGA
Connect to monitor
2
e-SATA
Connect to HDD with e-SATA interface
3
RS485 Y/Z interface
Connectors for speed dome. Y is TX+, Z is TX-
(This interface of some models is unavailable.)
4
RS485 A/B interface
Connect to a keyboard. Ais TX+; B is TX-
5
AUDIO OUT
Audio output; connect to sound box
6
LAN
Network port
7
HDMI
Connect to high definition display device
8
USB
Connect USB storage device or USB mouse
9
GND
Grounding
10
ALARM OUT
Relay output; connect to external alarm
11
ALARM IN
Alarm inputs for connecting sensors
12
AUDIO IN
Audio input; connect to audio input device, like
microphone, pickup, etc
13
Power Switch
Press the switch to turn on/off the NVR
14
Power Supply
Power supply interface

Introduction
NVR User Manual
7
No.
Name
Descriptions
1
VGA
Connect to monitor
2
RS485 Y/Z interface
Connect to speed dome. Y is TX+, Z is TX-
(This interface of some models is unavailable.)
3
ALARM OUT
Relay output; connect to external alarm
4
GND
Grounding
5
AUDIO OUT
Audio output
6
e-SATA1/ e-SATA2
Connect to HDD with e-SATA interface
7
LAN1/LAN2
Network port
8
HDMI1
Connect to 4K×2K high definition display device
9
USB3.0/USB
USB3.0 and USB 2.0 interface, connect USB storage
device or USB mouse
10
HDMI2
Connect to 1920×1080 high definition display device.
Connect to monitor as anAUX output channel by
channel. Only video display, no menu show
11
RS485 A/B interface
Connect to a keyboard. A is TX+; B is TX-
12
ALARM IN
Alarm inputs for connecting sensors
13
AUDIO IN
Audio input
14
Power Switch
Press the switch to turn on/off the NVR
15
Power Supply
Power supply interface
No.
Name
Descriptions
1
Power Supply
DC48V power supply interface
2
PoE port
8 PoE network ports; connect to 8 PoE IP cameras
3
LAN
Network port
4
VGA
Connect to monitor
5
HDMI
Connect to 1920×1080 high definition display device
6
USB3.0
USB3.0 interface, connect USB storage device or
USB mouse
7
AUDIO IN
Audio input; connect to audio input device, like
microphone, pickup, etc
8
AUDIO OUT
Audio output; connect to sound box
9
Power Supply
DC12V power supply interface

Introduction
NVR User Manual
8
No.
Name
Descriptions
1
e-SATA
Connect to HDD with e-SATA interface
2
LAN1/LAN2
Network port
3
HDMI2
Connect to 1920×1080 high definition display device.
Connect to monitor as anAUX output channel by
channel. Only video display, no menu show
4
USB
USB interface, connect USB storage device or USB
mouse
5
HDMI1
Connect to 4K×2K high definition display device
6
VGA
Connect to monitor
7
RS485 Y/Z interface
Connect to speed dome. Y is TX+, Z is TX-
(This interface of some models is unavailable.)
8
RS485 A/B interface
Connect to keyboard.A is TX+; B is TX-
9
ALARM OUT
Relay output; connect to external alarm
10
GND
Grounding
11
ALARM IN
Alarm inputs for connecting sensors
12
AUDIO IN
Audio input; connect to audio input device, like
microphone, pickup, etc
13
AUDIO OUT
Audio output; connect to sound box
14
Power Switch
Press the switch to turn on/off the NVR
15
Power Supply
Power supply interface
1.5 Connections
Video Connections
Video Output: Supports VGA/HDMI video output. You can connect to monitor through these
video output interfaces simultaneously or independently.
Audio Connections
Audio Input: Connect to microphone, pickup, etc.

Introduction
NVR User Manual
9
Audio Output: Connect to headphone, sound box or other audio output devices.
Alarm Connections
Some models may not support this function. Take 16 CH alarm inputs and 1 CH alarm output
for example.
Alarm Input:
Alarm IN 1~16 are 16 CH alarm input interfaces. There are no type requirements for sensors.
NO type and NC type are both available.
The way to connect sensor and the device is as shown below:
The alarm input is an open/closed relay. If the input is not an open/closed relay, please refer to
the following connection diagram:
Alarm Output:
The way to connect alarm output device:
Pull out the green terminal blocks and loosen the screws in the alarm-out port. Then insert the
signal wires of the alarm output devices into the port of NO and COM separately. Finally,
tighten the screws. Provided that the external alarm output devices need power supply, you can

Introduction
NVR User Manual
10
connect the power supply as per the following figures.
RS485 Connection
There are two types of RS485 interfaces:
（Type 1）（Type 2）
Type 1: The P/Z interfaces are unavailable temporarily. K/B interfaces are used to connect
keyboard.
Type 2: The RS485 interfaces are used to connect keyboard. A is TX+; B is TX-.

Basic Operation Guide
NVR User Manual
11
2Basic Operation Guide
2.1 Startup & Shutdown
Please make sure all the connections are done properly before you power on the unit. Proper
startup and shutdown are crucial to expending the life of your device.
2.1.1 Startup
①Connect the output display device to the VGA/HDMI interface of the NVR.
②Connect with the mouse and power. The device will boot and the power LED would turn
blue.
③A WIZARD window will pop up (you should select the display language the first time you
use the NVR). Refer to 3.1 Startup Wizard for details.
2.1.2 Shutdown
You can power off the device by using remote controller or mouse.
By remote controller:
①Press the Power button. This will take you to a shutdown window. The unit will power off
after a while by clicking the “OK”button.
②Disconnect the power.
By mouse:
①Click StartShutdown to pop up the Shutdown window. Select “Shutdown”in the
window. The unit will power off after a while by clicking the “OK”button.
②Disconnect the power.
2.2 Remote Controller
①It uses two AAA size batteries.
②Open the battery cover of the remote controller.
③Place batteries. Please take care the polarity (+ and -).
④Replace the battery cover.
Key points to check in case the remote doesn’t work.
1. Check batteries polarity.
2. Check the remaining charge in the batteries.
3. Check IR controller sensor for any masking.
If it still doesn’t work, please change a new remote controller to try, or contact your dealers.
You can just turn the IR sensor of the remote controller towards the IR receiver of the NVR to
control it when you are controlling multiple devices by remote controller.
There are two kinds of remote controller. The interface of remote controller is shown as below.

Basic Operation Guide
NVR User Manual
12
Button
Function
Power Button
Switch off—to stop the device
Record Button
To start recording
-/-- /0-9
Input number or choose camera
Fn1 Button
Unavailable temporarily
Multi Button
To choose multi screen display mode
Next Button
To switch the live image
SEQ
To go to sequence view mode
Audio
To enable audio output in live mode
Switch
No function temporarily
Direction button
To move cursor in setup or pan/title PTZ
Enter Button
To confirm the choice or setup
Menu Button
To go to menu
Exit Button
To exit the current interface
Focus/IRIS/Zoom/PTZ
To control PTZ camera
Preset Button
To enter into preset setting in PTZ mode
Cruise Button
To go to cruise setting in PTZ mode
Track Button
No track function temporarily
Wiper Button
No function temporarily
Light Button
No function temporarily
Clear Button
No function temporarily
Fn2 Button
No function temporarily
Info Button
Get information about the device
To control playback. Play(Pause)/Stop/Previous
Frame/Next Frame/Speed Down/Speed Up
Snap Button
To take snapshots manually
Search Button
To go to search mode
Cut Button
No function temporarily
Backup Button
To go to backup mode
Zoom Button
To zoom in the images
PIP Button
No function temporarily
Note:
You shall press P.T.Z button to enter PTZ setting mode, choose a channel and press P.T.Z button again to
hide the P.T.Z control panel. Then you can press preset, cruise, track, wiper or light button to enable the
relevant function.

Basic Operation Guide
NVR User Manual
13
2.3 Mouse Control
Mouse control in Live Display & Playback interface
In the live display & playback interface, double click on any camera window to show the
window in single screen mode; double click the window again to restore it to the previous size.
In the live display & playback interface, if the interfaces display in full screen, move the mouse
to the bottom of the interface to pop up a tool bar. The tool bar will disappear automatically
after you move the mouse away from it for some time; move the mouse to the right side of the
interface to pop up a panel and the panel will disappear automatically after you move the
mouse away from it.
Mouse control in text-input
Move the mouse to the text-input box and then click the box. The input keyboard will pop up
automatically.
2.4 Text-input Instruction
Button
Function
REC
Record manually
Search
To enter search mode
MEUN
To enter menu
Exit
To exit the current interface
ENTER
To confirm the choice or setup
Direction button
To move cursor in setup
ZOOM
To zoom in
PIP
No function temporarily
To control playback. Play(Pause)/Next Frame/Speed
Up/Stop/Previous Frame/Speed Down
Multi
To choose multi screen display mode
Next
To switch the live image
SEQ
To go to sequence view mode
INFO
Get information about the device
Note: Mouse is the default tool for all operations unless an exception as indicated.

Basic Operation Guide
NVR User Manual
14
The system includes two input boxes. Refer to the above pictures. The left box is the number
input box and the right box is the input box which provides inputs of numbers, letters and
punctuation characters. The introductions of keys on the input boxes are shown below.
Button
Meaning
Button
Meaning
Backspace key
Switch key of punctuation character
Delete Key
Enter key
Switch key between upper
and lower letter
Space key
Switch key of language
2.5 Common Button Operation
Button
Meaning
Click it to show the menu list.
Click it to change the sequence of the list.
Click it to change the camera displaying mode.
Click it to close the current interface.
Click it to go to the earliest date of camera recording.
Click it to go to the latest date of camera recording.
