Luxon Video HYB32-Pro User manual

Digital Video Recorder
HYB32-PRO
User Manual
UD.6L0202D1568A02

User Manual of Digital Video Recorder
1
Thank you for purchasing our product. If there is any question or request, please do not hesitate to contact dealer.
This manual is applicable to following embedded network DVR series.
Series
Model
Type
HYB32-PRO
HYB32-PRO-3TB/6TB/9TB/12TB
Network HDVR

User Manual of Digital Video Recorder
2
Regulatory information
FCC information
FCC compliance: This equipment has been tested and found to comply with the limits for a digital device, pursuant to
part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when
the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case
the user will be required to correct the interference at his own expense.
FCC conditions
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that may cause undesired operation.
EU Conformity Statement
This product and - if applicable - the supplied accessories too are marked with "CE" and comply therefore with the
applicable harmonized European standards listed under the Low Voltage Directive 2006/95/EC, the EMC Directive
2004/108/EC, the RoHS Directive 2011/65/EU.
2012/19/EU (WEEE directive): Products marked with this symbol cannot be disposed of as unsorted municipal waste in
the European Union. For proper recycling, return this product to your local supplier upon the purchase of equivalent new
equipment, or dispose of it at designated collection points. For more information see: www.recyclethis.info.
2006/66/EC (battery directive): This product contains a battery that cannot be disposed of as unsorted municipal waste in
the European Union. See the product documentation for specific battery information. The battery is marked with this
symbol, which may include lettering to indicate cadmium (Cd), lead (Pb), or mercury (Hg). For proper recycling, return
the battery to your supplier or to a designated collection point. For more information see: www.recyclethis.info.

User Manual of Digital Video Recorder
3
Trademarks and Registered Trademarks
•Windows and Windows mark are trademarks or registered trademarks of Microsoft Corporation in the United States
and/or other countries.
•HDMI, HDMI mark and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI
Licensing LLC.
•The products contained in this manual are authorized by HDMI Licensing LLC with the use right of the HDMI
technology.
•VGA is the trademark of IBM.
•UPnPTM is a certification mark of the UPnPTM Implementers Corporation.
•Other names of companies and product contained in this manual may be trademarks or registered trademarks of their
respective owners.

User Manual of Digital Video Recorder
4
Preventive and Cautionary Tips
Before connecting and operating your device, please be advised of the following tips:
•Ensure unit is installed in a well-ventilated, dust-free environment.
•Unit is designed for indoor use only.
•Keep all liquids away from the device.
•Ensure environmental conditions meet factory specifications.
•Ensure unit is properly secured to a rack or shelf. Major shocks or jolts to the unit as a result of dropping it
may cause damage to the sensitive electronics within the unit.
•Use the device in conjunction with an UPS if possible.
•Power down the unit before connecting and disconnecting accessories and peripherals.
•A factory recommended HDD should be used for this device.
•Improper use or replacement of the battery may result in hazard of explosion. Replace with the same or
equivalent type only. Dispose of used batteries according to the instructions provided by the battery
manufacturer.

User Manual of Digital Video Recorder
5
Product Key Features
General
Connectable to the network cameras, network dome and encoders (this feature is supported by
HDVR series).
Connectable to the third-party network cameras like ACTI, Arecont, AXIS, Brickcom, Bosch, Canon,
PANASONIC, Pelco, SAMSUNG, SANYO, SONY, Vivotek and ZAVIO (this feature is supported by
HDVR series).
Connectable to the third-party network cameras that support ONVIF or PSIA protocol (this feature is
supported by HDVR series).
Connectable to smart IP cameras.
PAL/NTSC adaptive video inputs.
H.264 video compression with high reliability and superior definition.
Each channel supports dual-stream.
Up to 32 network cameras can be added (this feature is supported by HDVR series).
Independent configuration for each channel, including resolution, frame rate, bitrate, image quality,
etc.
The quality of the input and output video is configurable.
Each channel supports two kinds of compression parameters, the normal continuous and event.
Sub-stream can be configured locally.
Encoding for both audio/video composite stream and video stream; audio and video synchronization
during composite stream encoding.
Support CABAC (this feature is supported by analog cameras only).
Watermark technology.
Local Monitoring
Simultaneous HDMI, VGA and CVBS outputs.
HDMI output and VGA output at up to 1920×1080P resolution.
Multi-screen display in live view is supported, and the display sequence of screens is adjustable.
Live view screen can be switched in group. Manual switch and auto-switch are selectable and the
auto-switch dwell time is configurable.
Quick setting menu is provided for live view.
The selected live view channel can be shielded.
Motion detection, video tampering detection, video exception alarm and video loss alarm functions.
VCA alarm function
Privacy mask.
Several PTZ protocols supported; PTZ preset, patrol and pattern.
Zooming in by clicking the mouse and PTZ tracing by dragging mouse.
HDD Management
8 network disks (8 NAS disks, or 7 NAS disks+1 IP SAN disk) can be connected.
Support eSATA disk for recording or backup.
HDD group management.
Support HDD standby function.
HDD property: redundancy, read-only, read/write (R/W).
HDD quota management; different capacity can be assigned to different channel.

User Manual of Digital Video Recorder
6
HDD frame-extracting management to extend the record time.
Support S.M.A.R.T. and bad sector detection
Disk clone function
Recording, Capture and Playback
Provide new playback interface with easy and flexible operation.
Holiday recording schedule configuration.
Normal and event video encoding parameters.
Multiple recording types: manual, normal, alarm, motion, motion | alarm, motion & alarm, VCA.
8 recording time periods with separated recording types.
Pre-record and post-record for alarm, motion detection recording, and pre-record time for schedule
and manual recording.
Searching record files and captured pictures by events (alarm input/motion detection/VCA).
Customization of tags, searching and playing back by tags.
Locking and unlocking record files.
Local redundant recording and capture.
Searching and playing back record files by camera No., recording type, start time, end time, etc.
Smart search for the selected area in the video.
Smart playback to go through less effective information;
Zooming in when playback.
Reverse playback for multi-channel.
Supports pause, fast forward, slow forward, skip forward, and skip backward when playback,
locating by dragging the mouse.
Up to 16-ch synchronous playback at WD1 real time; for other models, up to 16-ch synchronous
playback at 4CIF real time.
Manual capture, continuous capture of video images and playback of captured pictures.
Backup
Export video data by USB, SATA or eSATA device.
Export video clips when playback.
Management and maintenance of backup devices.
Support NTFS and FAT32 formatted backup devices.
Alarm and Exception
Configurable arming time of alarm input/output.
Alarm for video loss, motion detection, tampering, abnormal signal, video input/output standard
mismatch, illegal login, network disconnected, IP confliction, abnormal record/capture, HDD error,
and HDD full, etc.
Alarm triggers full screen monitoring, audio alarm, notifying surveillance center, sending email and
alarm output.
Automatic restore when system is abnormal.
Other Local Functions
Users can operate by front panel, mouse, remote control, and control keyboard.
Three-level user management; admin user is allowed to create many operating accounts and define
their operating permission, which includes the limit to access any camera.
Operation, alarm, exceptions and log recording and searching.
Manually triggering and clearing alarms.
Importing and exporting of device configuration file.

User Manual of Digital Video Recorder
7
Manual video quality diagnostics for analog channels.
Either normal or hot spare working mode is configurable to constitute an N+1 hot spare system (this
function is supported by HDVR series only).
Network Functions
2 self-adaptive 10M/100M/1000M network interfaces, and three working modes are configurable:
multi-address, load balance and network fault tolerance.
IPv6 is supported.
TCP/IP protocol, PPPoE, DHCP, DNS, DDNS, NTP, SADP, SMTP, SNMP, NFS, and iSCSI are
supported.
TCP, UDP and RTP for unicast.
Auto/Manual port mapping and automatically discovered by NAT.
Remote web browser access by HTTPS ensures high security.
Remote reverse playback by RTSP.
Support accessing by the platform by ONVIF.
Remote search, playback, download, locking and unlocking the record files, and downloading files
broken transfer resume.
Remote parameters setup; remote import/export of device parameters.
Remote viewing of the device status, system logs and alarm status.
Remote keyboard operation.
Remote locking and unlocking of control panel and mouse.
Remote HDD formatting and program upgrading.
Remote system restart.
RS-232, RS-485 transparent channel transmission.
Alarm and exception information can be sent to the remote host
Remotely start/stop recording.
Remotely start/stop alarm output.
Captured pictures can be sent to the FTP server which supports FTP and SFTP protocol, and two FTP
servers can be configured (this feature is supported by DVR series).
Upgraded by remote FTP server is supported.
Remote PTZ control.
Remote JPEG capture.
Two-way voice talk and voice broadcasting.
Embedded WEB server.

User Manual of Digital Video Recorder
8
TABLE OF CONTENTS
Product Key Features ............................................................................................................................5
Chapter 1 Introduction ......................................................................................................................13
1.1 Front Panel..............................................................................................................................14
1.2 IR Remote Control Operations ...............................................................................................17
1.3 USB Mouse Operation............................................................................................................20
1.4 Input Method Description.......................................................................................................21
1.5 Rear Panel............................................................................................................................... 22
1.6 Starting Up and Shutting Down the Device............................................................................24
Chapter 2 Getting Started.................................................................................................................. 26
2.1 Using the Wizard for Basic Configuration..............................................................................27
2.2 Adding and Connecting the IP Cameras .................................................................................30
2.2.1 Adding the IP Cameras................................................................................................... 30
2.2.2 Configuring the Connected IP Cameras.........................................................................34
Chapter 3 Live View...........................................................................................................................37
3.1 Introduction of Live View.......................................................................................................38
3.2 Operations in Live View Mode............................................................................................... 39
3.2.1 Front Panel Operation .................................................................................................... 39
3.2.2 Using the Mouse in Live View.......................................................................................40
3.2.3 Using an Auxiliary Monitor ...........................................................................................41
3.2.4 Quick Setting Toolbar in Live View Mode .................................................................... 41
3.3 Adjusting Live View Settings ................................................................................................. 45
3.4 Channel-zero Encoding...........................................................................................................47
3.5 Manual Video Quality Diagnostics......................................................................................... 48
3.6 User Logout ............................................................................................................................49
Chapter 4 PTZ Control......................................................................................................................50
4.1 Configuring PTZ Settings.......................................................................................................51
4.2 Setting PTZ Presets, Patrols & Patterns..................................................................................53
4.2.1 Customizing Presets.......................................................................................................53
4.2.2 Calling Presets................................................................................................................54
4.2.3 Customizing Patrols .......................................................................................................54
4.2.4 Calling Patrols................................................................................................................55
4.2.5 Customizing Patterns ..................................................................................................... 55

User Manual of Digital Video Recorder
9
4.2.6 Calling Patterns..............................................................................................................56
4.2.7 Customizing Linear Scan ............................................................................................... 56
4.2.8 Calling Linear Scan........................................................................................................ 57
4.2.9 One-touch Park............................................................................................................... 57
4.3 PTZ Control Panel ..................................................................................................................58
Chapter 5 Record and Capture Settings........................................................................................... 60
5.1 Configuring Encoding Parameters..........................................................................................61
5.2 Configuring Record/Capture Schedule ...................................................................................65
5.3 Configuring Motion Detection Recording and Capture..........................................................68
5.4 Configuring Alarm Triggered Recording and Capture............................................................ 70
5.5 Configuring VCA Recording and Capture..............................................................................72
5.6 Configuring Manual Recording and Continuous Capture....................................................... 74
5.7 Configuring Holiday Recording and Capture .........................................................................76
5.8 Configuring Redundant Recording and Capture.....................................................................78
5.9 Configuring HDD Group for Recording and Capture.............................................................80
5.10 Files Protection....................................................................................................................... 82
5.10.1 Locking the Record Files ...............................................................................................82
5.10.2 Setting HDD property to Read-only............................................................................... 84
Chapter 6 Playback ............................................................................................................................86
6.1 Playing Back Record Files......................................................................................................87
6.1.1 Playing Back by Time....................................................................................................87
6.1.2 Playing Back by Event...................................................................................................90
6.1.3 Playing Back by Tag ......................................................................................................92
6.1.4 Playing Back by Smart Search....................................................................................... 94
6.1.5 Playing Back by Searching System Log ........................................................................96
6.1.6 Playing Back External Files ...........................................................................................98
6.1.7 Playing Back Frame Extracting Record .........................................................................99
6.2 Auxiliary Functions of Playback .......................................................................................... 101
6.2.1 Playing Back Frame by Frame.....................................................................................101
6.2.2 Digital Zoom................................................................................................................101
6.2.3 Reverse Playback of Multi-channel ............................................................................. 102
6.3 Picture Playback ...................................................................................................................103
Chapter 7 Backup.............................................................................................................................105
7.1 Backing up Record Files....................................................................................................... 106
7.1.1 Quick Export................................................................................................................ 106
7.1.2 Backing up by Normal Video Search...........................................................................107
