TEFAL Everyday Slim IH2108 User manual

Everyday Slim
www.tefal.com
INDUCTION COOKER
EN
KO

A
D
B
B
C
FM NOP
GH IJKLE
C

A
D
B
B
C
FM NOP
GH IJKLE
C
1
x1
x2
x3
x4
6
7 8 9
수동 모드
전원 켜기
수동 모드
전원 끄기
10
1 2 3
4 5

2
3
15
5초
18 19
종료
20
16 17
12 13 14

4
전원 끄기
21
최대 30분
22 23 24

6
IMPORTANT SAFETY INSTRUCTIONS
• Read these instructions for use carefully before
using your appliance for the first time and keep
them to hand for future reference.
• This appliance is not intended to function using
an external time-switch or a separate remote
control system.
• This appliance is not intended for use by persons
(including children) with reduced physical, sensory
or mental capabilities, or lack of experience
and knowledge, unless they have been given
supervision or instruction concerning use of the
appliance by a person responsible for their safety.
• Chidren must be supervised to ensure that they
do not play with the appliance.
• This appliance can be used by children aged from
8 years and above and persons with reduced
physical, sensory or mental capabilities or lack
of experience and knowledge if they have been
given supervision or instruction concerning use of
the appliance in a safe way and understand the
hazards involved. Cleaning and user maintenance
shall not be made by children unless they are
older than 8 years and supervised.

7
EN
• Keep the appliance and its cord out of the reach
of children less than 8 years.
• As this appliance is for household use only, it is
not intended for use in, and the guarantee will
not apply for :
– Staff kitchen areas in shops, offices and other
working environments ;
– Farm houses ;
– By clients in hotels, motels and other residential
type environments ;
– Bed and breakfast type environments.
• If the power cord is damaged, it must be replaced
by either the manufacturer, its approved service
centre or similary qualified persons to avoid any
danger.
• Please handle the ceramic plate with care to
avoid breakage. In case of any crack on the
surface, please immediately turn off the power,
risk of electric shock. Do not use the appliance
and contact an approved service centre.
• Do not place any metal objects, such a knife,
fork, spoon, lid and aluminum foil etc … on the
ceramic plate (as they may conduct heat and
cause injury).
• Never immerse the appliance or its power cord in
water or any other liquid.

8
• Do not use your appliance if it does not operate
correctly, if it has been damaged or if the power
cord or plug is damaged. To maintain safety,
these parts must be replaced by an Approved
Service Centre.
• Any intervention other than normal cleaning and
maintenance by the customer must be performed
by an Approved Service Centre.
• Never touch the hot surfaces of the appliance,
they will remain so for a while after use.
• People fitted with cardiac pacemakers or similar
medical devices should be kept away from the
induction cooker when it is connected to the
power supply. If in any doubt consult a medical
practitioner before using this product to avoid
any danger.
• Warning: If the surface is cracked, switch off the
appliance to avoid the possibility of electric shock.
• Notice: the ceramic plate is hot after cooking,
please do not touch
• This appliance is designed for indoor domestic household use only. In
case of professional use, inappropriate use or failure to comply with
the instructions, the manufacturer accepts no responsibility and the
guarantee will not apply.
• For your safety, this appliance meets applicable standards and
regulations (Directives on Low Voltage, Electromagnetic Compatibility,
Materials in contact with food articles, Environment, etc.).
• This appliance is designed to function on AC current only. Before using

9
EN
it for the first time, check that your mains supply voltage matches that
indicated on the appliance data plate.
• Any connection error will invalidate your guarantee.
• Always plug the appliance into a dedicated socket outlet with an earth
connection. Do not use a socket adaptor or connect any other appliance
into the same socket simultaneously, to avoid electrical overloading and
risk of fire.
• Given the diverse standards in effect, if the appliance is used in a country
other than that in which it is purchased, have it checked by an Approved
Service Centre.
• Remove all packaging materials, stickers and accessories from inside
and outside of the appliance.
• The appliance must be placed and used on a flat, stable, heat-resistant
work surface, away from water splashes.
• Do not place or use this appliance in high humidity environments.
• Do not place or use the induction plate on steel or aluminium surfaces.
• Maintain a gap of at least 10cm (4 inches) on all sides of the appliance
to ensure adequate ventilation.
• Never place or use the appliance close to a wall or below a wall cupboard.
• Never place or use the appliance below or close to easily inflammable
objects (e.g. curtains, etc.).
• Never place or use the appliance on or close to a cooking hob or other
sources of heat.
• Unwind the power cord fully before use.
• Do not use an extension lead. If you accept liability for doing so, only
use an extension lead which is in good condition, has a plug with an
earth connection and is suited to the power rating of the appliance.
• Never leave the appliance unattended whilst connected to the power
supply, even if for a few moments, especially where children are present.
• Do not let the power cord hang where children may reach it.
• The power cord must never be close to or in contact with hot parts of the
appliance, close to sources of heat or resting on sharp edges.
• Take all necessary precautions to prevent anyone tripping over an
extension cord.
• Switch off and disconnect the appliance from the power supply when
not in use.
• Never disconnect the plug by pulling on the power cord.

10
• Inspect the appliance and power cord for signs of wear or damage prior
to connecting to the power supply.
• Never move the appliance when it is hot.
• Allow the appliance to cool down completely before you clean and store it.
• Always keep the induction cooker clean to avoid dust entering the fan
motor and causing a malfunction.
• If parts of the appliance should catch fire, never try to extinguish flames
with water. Disconnect the appliance and smother the flames with a
damp cloth.
• Place the pan at the centre of the cooking circle.
• Do not overheat pan or preheat while empty for long periods.
• Do not heat the foodstuffs in tins or other airtight containers to avoid
explosions caused by air expansion.
• This appliance can be used up to an altitude of 4000 meters.
KEEP THESE INSTRUCTIONS
IN A SAFE PLACE
Environmental protection first!
Your appliance contains valuable materials that can be
recovered or recycled.
Leave it at a local civic waste collection point.
This product has been designed for domestic use only. Any commercial
use, inappropriate use or failure to comply with the instructions, the
manufacturer accepts no responsibility and the guarantee will not apply.

11
EN
SPECIFICATION
PRODUCT STRUCTURE
PRINCIPLE AND CHARACTERISTICS
A Ceramic glass
B Air entry
C Air exit
D Control panel
E Digital Display Screen
F G/H/I programs selection
button
G Slow program
H Stew program
I Boil program
J Boost program
K Stir Fry program
L Fry program
M Timer button
N «+/-» button / Slider
O Pause Button
P On/Off button
Working Principle
An induction hotplate works by heating
a receptacle using the currents induced
by a magnetic field. When an electric
current passes through a coil, it generates
a magnetic field. On an induction hotplate,
this magnetic field is then induced into the
base of the receptacle. Foucault currents of very low intensity pass through
the base of the receptacle. Despite their low intensity, these currents generate
heat in the receptacle as they pass through it. The principle behind the
induction hotplate is to multiply these Foucault currents while changing the
direction of the very high frequency field in order to heat the bottom of the
receptacle. The heating process is instantaneous, because as soon as the
coil power supply is activated, the receptacle is heated. Food is then heated
through contact with the base of the pan.
For the induction method to function properly, the cooking utensil must be
ferromagnetic. (See details in the section Cooking utensils).
Model Maximum
Input Power
Power Adjustment
Range
Display
Type
Applicable Power
Supply
IH2108 2100W 300W-2100W Digital
Display
220V-240V/
50Hz-60Hz
Eddy
current
Ferromagnetic
receptacle
Cooker surface
Magnetic
field
Magnetic
field
Coil
see product view page 2

12
Characteristics
Multiple Safety Protections
• Protection against voltage drops/surges.
• The induction cooker is only suitable for induction pots with a diameter
between 10 and 26 cm (part in contact with the ceramic plate).
• Protection against appliance overheating.
• Detection of the risk of heating an empty cooking utensil and the risk of
damaging the non-stick coating or igniting oil.
Environmental Protection
• This induction hob complies with ErP Directive 2009/25/EC and its EU
implementing regulation no. 66/2014.
• Induction is the most efficient method in terms of energy, with an energy
yield of more than 90%.
• To reduce energy consumption, place a lid on the pan whilst cooking.
• Induction does not generate any flames.
• Induction does not need any fuel and reduces the risk of domestic accidents
linked to gas leaks or fire due to its numerous controls.
• The cooking area on this induction hob has a working diameter of 230mm,
and its energy consumption is EC (Wh/kg) = 195.
Intelligent Control
• Multiple cooking functions: multiple cooking modes from low to high power
to meet various cooking needs.
• Wide range of cooking temperatures: maintains and regulates the cooking
temperature intelligently.
• Flexible timer function: allows you to programme the hotplate to stop
cooking after between 1 minute and 3 hours (depending on the mode).
• Detection of the presence of induction receptacles: if no receptacle or an
unsuitable receptacle is detected on the induction hotplate, the alarm is
triggered.
• If the temperature of the ceramic glass plate exceeds 50° C at the end of
cooking, the LCD screen flashes and displays “H”. The fan continues to run
to cool the plate.
Convenient Cleaning
• The ceramic glass plate is wear-resistant and does not easily tarnish. It is also
easy to clean and maintain.
Caution: the ceramic glass may be hot after being in contact with the
receptacle.

13
EN
USER INSTRUCTIONS
MANUAL Mode
• Manual mode enables you to cook all types of food by manually
adjusting your heating power.
• Below are the power levels that correspond to each program:
P1 P2 P3 P4 P5 P6 P7
300 W 600 W 1200 W 1400 W 1600 W 1800 W 2100 W
• The timer is available in Manual Mode:
Default time Maximum time
15 min 180 min
PROGRAM SELECTION: Slow, Stew, Boil
SLOW Mode
• Slow Cook Mode cooks food at a low temperature, without the need
to add water or fats. This method of cooking helps food maintain its
quality and flavour.
• Below are the power levels that correspond to each program:
P1 P2 P3
300 W 600 W 1200 W
• The timer is available in Slow Cook Mode:
Default time Maximum time
30 min 180 min
STEW Mode
• This mode allows to make the food tender owing to a long cooking, just
below the boiling point.
• Below are the power levels that correspond to each program:
P1 P2 P3 P4 P5 P6
300 W 600 W 1200 W 1400 W 1800 W 2100 W
• The timer is available in Stew Mode:
Default time Maximum time
45 min 45 min

14
BOIL Mode
• This mode will boil between 0.4 L and 2.5 L of water in a pot. (Do not use
this function for heating milk as it may burn).
• Below are the power levels that correspond to each program:
P1 P2 P3 P4 P5 P6 P7
300 W 600 W 1200 W 1400 W 1600 W 1800 W 2100 W
• The timer is available in Boil Mode:
Default time Maximum time
10 min 15 min
BOOST Mode
• Boost raises the ring temperature very quickly. It can be used for cooking
food, such as meat, very quickly at a high temperature.
• Below are the power levels that correspond to each program:
P1 P2 P3 P4 P5 P6 P7
300 W 600 W 1200 W 1400 W 1600 W 1800 W 2100 W
• The timer is available in Boost Mode:
Default time Maximum time
15 min 120 min
STIR FRY Mode
• Stir Fry Mode cooks food in a little fat at a high temperature so as to
brown the surface.
• Below are the power levels and oil temperatures that correspond to
each program:
P1 P2 P3 P4 P5 P6 P7
600 W 1200 W 1200 W 1400 W 1400 W 1800 W 2100 W
110 °C 125 °C 140 °C 155 °C 170 °C 185 °C 200 °C
• The timer is available in Stir Fry Mode:
Default time Maximum time
15 min 180 min

15
EN
FRY Mode
• This mode fries food in a large quantity of oil - maximum 2 L.
• Below are the power levels and oil temperatures that correspond to
each program:
P1 P2 P3 P4 P5 P6 P7
1200 W 1200 W 1400 W 1400 W 1600 W 1800 W 2100 W
100 °C 120 °C 140 °C 160 °C 180 °C 200 °C 220 °C
• The timer is available in Fry Mode:
Default time Maximum time
15 min 180 min
CLEANING
ERROR CODES
You must disconnect the power lead, wait until the ceramic glass plate
has cooled, then follow the instructions below to clean the appliance:
1. Ceramic glass plate: if the ceramic glass plate is very dirty, clean
using a damp non-abrasive sponge or for more stubborn stains use an
appropriate cleaning product which is designed for use on ceramic hobs.
2. Cooker body and control panel: Use a damp soft cloth to clean. In case
of any oil stains that are not easily removed, wipe away the stains with
a soft cloth rinsed in warm water and a little washing-up liquid and then
clean using a damp soft cloth.
3. Air entry/air exit surface: remove any dust with a cotton bud.
• Receptacle missing or not the correct type:
If the pot base diameter is less than 10 cm or if the pot material is
unsuitable, the buzzer will sound and the digital display shows “E1”.
Change the cookware.
• Protection of the power source against overheating:
If the power source overheats, the induction cooking appliance cuts
off the incoming power supply and the screen displays “E2”. Allow the
hotplate to cool: if the defect persists, please contact the customer service.
• Over or under- voltage protection:
If the voltage is greater than 265 V - 285 V, the incoming power supply for

16
the induction cooking appliance is cut off and the digital screen displays
“E3”; if the voltage is between 150 V and 170 V, the incoming power
supply for the induction cooking appliance is cut off and the digital screen
displays “E4”. Check that your device’s specifications are compatible with
your electric network.
• Temperature sensor:
If the sensor is in an open circuit, the induction cooking appliance will
continue to operate for one minute and the digital screen will display
“E5”; if the sensor detects a short circuit, the induction cooking appliance
will immediately display “E6”. Contact the customer service.

17
KO
중요 안전 지침
• 제품을 처음 사용하기 전에 본 사용 설명서를
주의 깊게 읽고 나중에 참고할 수 있도록 잘
보관하시기 바랍니다.
• 본 제품은 외부 타이머나 별도의 원격 조정
시스템에 의해 작동되지 않습니다.
• 안전에 대한 책임을 질 수 있는 사람이 제품
사용을 감독하거나 지시하지 않는 한 신체적,
감각적, 정신적 능력이 제한되었거나 경험 및
지식이 부족한 사람(어린이 포함)은 이 제품을
사용할 수 없습니다.
• 어린이가 제품을 가지고 장난치지 않도록 주의
깊게 지켜봐 주십시오.
• 8세 이상의 어린이 및 제한된 신체적, 감각적,
정신적 능력을 지녔거나 경험이나 지식이 부족한
사람일지라도 감독하는 사람이 있거나 안전하게
기기를 사용하는 방법과 발생할 수 있는 위험을
인식하고 있을 경우 이 기기를 사용할 수
있습니다. 세척 및 유지관리는 주위에 감독하는
사람이 있는 경우에 한하여 8세 이상의 어린이가
행할 수 있습니다.
• 제품과 전선은 8세 미만 어린이의 손이 닿지
않는 곳에 보관하십시오.
• 이 제품은 가정용으로만 사용하도록 제조되었습니다.
다음과 같은 용도로 사용할 경우 품질 보증 혜택을

18
받으실 수 없습니다.
– 가게, 사무실 및 기타 영업장소 내 직원용 주방
– 농가
– 호텔, 모텔 및 기타 숙박시설 내에서 고객 접대용
– 아침 식사를 제공하는 숙박시설.
• 전선이 손상된 경우, 위험을 방지하기 위해 반드시
제조사, 공인 서비스 센터 또는 유사 자격을 갖춘
전문인을 통해 교체하시기 바랍니다.
• 세라믹 상판이 깨지지 않도록 주의하여 다루시기
바랍니다. 표면에 금이 간 경우, 감전의 위험이
있으므로 즉시 전원을 끄고 제품의 사용을 중단한
후 공인 서비스 센터에 연락하시기 바랍니다.
• 나이프, 포크, 숟가락, 뚜껑, 알루미늄 포일과
같은 금속성 물체를 세라믹 상판에 올려놓지
마십시오(뜨거워져 부상을 유발할 수 있습니다).
• 제품 또는 전선을 물이나 기타 액체에 담그지
마십시오.
• 제품이 올바로 작동하지 않거나 손상된 경우, 또는
전선이나 플러그가 손상된 경우 제품을 사용하지
마십시오. 안전을 위해 본 부품은 반드시 공인
서비스 센터에서 교체되어야 합니다.
• 사용자가 할 수 있는 일반적인 세척 및 유지관리를
제외한 모든 관리는 공인 서비스 센터에서
수행되어야 합니다.
• 사용 후 한동안 열기가 남아 있으므로 제품의
열판을 절대 만지지 마십시오.

19
KO
• 심박조율기 또는 유사한 의료기기를 착용한
사람은 인덕션 레인지가 전원에 연결되어 있는
경우 레인지로부터 멀리 떨어지시기 바랍니다.
위험을 방지하기 위해 제품 사용 전 자세한
사항은 전문의와 상담하시기 바랍니다.
• 경고: 표면에 금이 간 경우, 감전의 위험을
방지하기 위해 제품의 전원을 끄십시오.
• 주의: 조리가 끝난 후 세라믹 상판은 뜨거우니
만지지 마십시오.
•이 제품은 실내 가정용으로만 사용하도록 제조되었습니다. 상업적 용도,
부적절한 사용 또는 사용 설명을 준수하지 않아 발생한 문제에 대해
제조사는 그 어떤 책임도 지지 않으며 품질 보증 혜택을 받으실 수 없습니다.
•안전을 위하여 본 제품은 적용되는 표준 법규 및 규정(저전압, 전자파
적합성, 식품 접촉 물질 규정, 환경 등)을 준수합니다.
•본 제품은 오직 AC(교류) 전류에만 연결하여 사용하도록
제조되었습니다. 제품을 처음 사용하기 전, 제품의 정격 표기 부분에
기재된 공급 전압이 가정 내 전압 시스템과 일치하는지 확인하십시오.
•전압이 맞지 않아 발생한 문제의 경우, 품질 보증 혜택이 적용되지
않습니다.
•제품의 전원은 반드시 접지 콘센트에 연결하시기 바랍니다. 전기
과부하 및 화재의 위험을 방지하기 위해 콘센트 어댑터를 사용하거나
같은 콘센트에 다른 제품을 동시에 연결하지 마십시오.
•나라마다 서로 다른 전기기준이 시행되고 있으므로, 이 제품을 구입한
곳이 아닌 다른 국가에서 사용할 때에는 반드시 공인된 서비스 센터에서
확인을 받으십시오.
•포장재, 스티커, 제품 내부 및 외부에 장착된 액세서리를 모두
제거하십시오.
•제품은 반드시 물이 튀기지 않으며 흔들림 없는 평평한 내열 바닥 위에
올려놓고 사용합니다.
•제품을 습도가 높은 공간에 보관하거나 사용하지 마십시오.
•스틸 또는 알루미늄 표면에 인덕션 레인지를 놓거나 사용하지 마십시오.
•통풍이 원활하게 이뤄질 수 있도록 제품 사방으로 최소 10cm(4인치)의
여유 공간을 확보하십시오.

20
•절대 제품을 벽 근처 또는 찬장 아래에 설치하거나 사용하지 마십시오.
•불이 쉽게 붙는 인화성 물체(예: 커튼 등) 아래 또는 근처에 절대 제품을
설치하거나 사용하지 마십시오.
•가스 또는 전기레인지나 기타 열원 위 또는 근처에 절대 제품을
설치하거나 사용하지 마십시오.
•사용하기 전에 전선을 완전히 푸십시오.
•연장선을 사용하지 마십시오. 연장선 사용에 대한 책임을 사용자가
진다는 전제 하에 상태가 양호하고 접지 단자가 포함되어 있으며 제품의
전압 정격에 적합한 연장선만을 사용하십시오.
•제품이 전원에 연결되어 있을 경우, 특히 주변에 어린이가 있다면 단 몇
분이라도 제품을 절대 방치하지 마십시오.
•어린이 손이 닿을 수 있는 곳에 전선을 걸어 놓지 마십시오.
•전선이 제품의 뜨거운 부분에 직접 닿거나 그 근처에 놓이지 않도록
하십시오. 또한 전선을 열원 근처에 두거나 날카로운 모서리에 걸쳐놓지
마십시오.
•사람이 연장선에 걸려 넘어지지 않도록 필요한 모든 조치를 취하시기
바랍니다.
•제품을 사용하지 않을 경우 전원을 끄고 플러그를 빼십시오.
•전선을 힘껏 당겨서 빼지 마십시오.
•전원에 연결하기 전에 제품 및 전선에 마모 또는 손상의 흔적이 없는지
확인하십시오.
•제품에 열기가 남아 있을 때 제품을 움직이지 마십시오.
•세척 및 보관하기 전에 제품의 열기를 완전히 식히십시오.
•냉각팬 모터에 먼지가 유입되는 것을 막고 제품 오작동을 방지하기 위해
인덕션 레인지를 항상 청결하게 유지하십시오.
•제품의 일부분에 불이 붙은 경우, 절대 물을 사용하여 끄지 마십시오.
전원을 분리하고 젖은 천으로 화재를 진화하시기 바랍니다.
•조리 용기를 화구 중앙에 놓으십시오.
•조리 용기를 과열하거나 안에 내용물이 없는 상태에서 조리 용기를
오랫동안 예열하지 마십시오.
•통조림 또는 밀폐 용기 안에 들어 있는 음식을 데우지 마십시오. 공기가
팽창하여 폭발의 위험이 있습니다.
•본 제품은 최고 4,000미터의 고도에서 사용할 수 있습니다.
이 사용 설명서를
안전한 장소에 보관하십시오
