TEFAL FR7009 SEMI PRO OLEOCLEAN DEEP FRYER User manual

S.A. SEB SELONGEY CEDEX • RC. DIJON B 302 412 226 • REF. 5068181
Design: Espace Graphique
GB-IE Environment protection first !
Your appliance contains valuable materials which can be
recovered or recycled.
Leave it at a local civic waste collection point.

Instructions for use

Summuary
Safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Use of the Oil box button . . . . . . . . . . . . . . . . . . . . . 6
Before first use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Preparing the fryer . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Frying process . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Cleaning and Maintenance . . . . . . . . . . . . . . . . . . . . 11
If your deep fryer does not work properly . . . . . . . . 13
1

PROTECTION OF THE ENVIRONMENT
Your appliance has been designed to work for many years. However, when finally you decide to
replace your deep fryer, do not forget to think of what you can do to help to protect the environment
by disposing of it at your local civic waste disposal centre.
Read and follow the instructions for use carefully.
SAFETY INSTRUCTIONS
This appliance complies with the safety regulations and directives in effect at the time of manufacture.
Check that the power supply voltage corresponds to that shown on the appliance (alternating current).
Given the diverse standards in effect, if the appliance is used in a country other than that in which it is
purchased, have it checked by an approved Service Centre.
This appliance is designed for domestic use only. In case of professional use, inappropriate use or failure
to comply with the instructions, the manufacturer accepts no responsibility and the guarantee does not
apply.
Read and follow the instructions for use. Keep them safe.
Connecting to the power supply
• Do not use the appliance if the appliance or the cord is damaged, if the appliance has fallen or
shows visible damage or does not work properly. In the event of the above, the appliance must
be sent to an approved Service Centre. Do not take the appliance apart yourself.
• Always plug the appliance into an earthed socket.
• Do not use an extension lead. If you accept liability for doing so, only use an extension lead which
is in good condition, has an earthed plug and is suited to the power of the appliance.
• If the power supply cord is damaged, it must be replaced by the manufacturer, an authorised
service centre or a similarly qualified person in order to avoid any danger.
• Do not leave the cord hanging.
• Do not unplug the appliance by pulling on the cord.
• Always unplug the appliance: immediately after use, when moving it, prior to any cleaning or
maintenance.
Using
• Use a flat, stable, heat-resistant surface, away from any water splashes and other heat sources.
• Do not place on an oven hob/cooker top.
• Never leave the appliance within reach of children without supervision.
• This electrical equipment operates at high temperatures which may cause burns. Do not touch
the apparent metal parts, filter or window….
• Do not switch on the appliance near to flammable materials (blinds, curtains….) or close to an
external heat source (gas stove, hot plate etc.).
• In the event of fire, never try to extinguish the flames with water. Close the lid. Smother the flames
with a damp cloth.
• Do not move the appliance when it is full of liquids or hot food.
• If you have a removable bowl, never take it out when the fryer is switched on.
• Never immerse the appliance or the electrical control unit in water!
!
2

• Store your fryer in a cool and dry place.
Cooking
• Never plug in the deep fat fryer without oil or fat inside. The oil level must always be between the
min and max markers.
• If you use solid vegetable fat, cut it into pieces and melt it over a low heat in a separate pan
beforehand, then slowly pour it into the deep fryer bowl. Never put solid fat directly into the deep
fryer bowl or fryer basket as this will lead to deterioration of the appliance.
• Do not mix different types of oil.
• Do not over fill the basket, never exceed the maximum capacity.
Recommendations
• Limit the cooking temperature to 190°C, especially for potatoes.
• Use the basket for chips.
• Control the cooking: Do not eat burnt food.
• Filter your oil after every use to avoid burnt crumbs and change to avoid burnt crumbs and
change it regularly.
• Eat a balanced and varied diet which includes plenty of fruits and vegetables.
• Store your fresh potatoes in a room above 8°C.
• For crisp results and fast cooking, we recommend that you limit the quantity of chips to 1/2
basket per frying.
• For a larger quantity of food or potatoes, the temperature drops very fast just after having lowered
the basket. While cooking, the temperature never reaches above 175°C even if the thermostat is
set at the 190°C (Stabilized Temperature before lowering).
3

MAX
MIN
MAX
4
1.
3.
4.
6.
7.
9.
11.
11.a
11.b
3.a
3.b
2.
1.a1.b1.c1.d
5.
8.
10.
12.

Description
1. Lid
a. Permanent filter
b. Filter cover
c. handle
d. viewing window
2. Removable control unit
3. Frying basket
a. handle
b. MAX. food level marking
4. Removable bowl
5. Min. and Max. oil level markers
6. Basket high position
7. Fixed oil filter grid
8. Safety carrying handles
9. Oil box control button
10. Body
11. Oil box
a. lid
b. Oil box cap
12. Feet
13. Electronic panel
a. Change oil indicator light
b. Digital timer
c. Temperature light
d. Power light
e. Change oil Reset
f. Temperature touchpad
g. Timer touchpad
14. Safety cut-out reset button
5
13. 13.a13.b13.c13.d
13.e13.f13.g
RESET function: Your appliance is equipped with safety features.
If the safety cut-out is activated, the appliance will shut off automatically and an
error code will appear on the display (from 81 to 85).
Unplug the appliance, let it cool and follow the instructions for use.
If the error code still appears, push the safety cut-out RESET
button (found on the back of the control unit) with a toothpick
or similar non-metallic object. If the problem with the safety
cut-out persists, please contact our Helpline see details on
Page 3.
14

Filtration, drainage and automatic storage of oil/fat
Your fryer is fitted with an exclusive and patented system for filtration and
automatic drainage, suitable for most types of oils and fats used for cooking.
GThe drainage of oil is completely automatic and safe.
GThe automatic patented filtration system ensures your oil/fat stays clean and
lasts longer for healthier frying. No crumbs guarantees less odours.
GThe OIL BOX container enables you to store your oil or fat and keep it until you
next want to use it and avoid any transfer of flavours.
Ultra easy cleaning
Your fryer is easy to handle and to dismantle.
GAll the parts (except the electrical control unit) are dishwasher safe.
GThanks to the patented automatic filtration and oil storage system, some parts
of your fryer can go into the dishwasher after each use.
Clean as new after each use.
6
Using the Oil Box control button
• The Oil Box control button has 3 positions.
Fry Position: to fry.
Automatic Oil Filtration Position: to drain and filter the oil
into the oil box.
Oil Box Position: to push back or pull out the oil box.

Before first use
• The fryer can be completely dismantled.
Remove the lid. Remove the frying basket, the control unit
and the bowl. Remove the oil box by positioning the Oil
Box control button on the Oil box position.
• Clean the lid, the bowl, the body, the frying basket and the
Oil Box with a damp cloth and washing-up liquid or put
them in the dishwasher.
Clean the control unit and the heating element with a
damp cloth.
Dry thoroughly.
• After cleaning, press on the red button under the fryer to
release any water in the bowl.
• Place the bowl and the electronic control unit in position.
• Place the Oil Box control knob on the Oil box position
and insert the empty Oil Box in to the fryer.
• Completely unfold the basket handle; a “click” indicates
that it is correctly positioned.
7
Do not immerse
the control unit
with the heating
element in water.
!
Check that the red
button has gone
back to its original
position.
!
CLICK
Make sure that the
control unit is
correctly positioned
otherwise the fryer
cannot function.
!
OK

8
Preparing the fryer
• Fill the bowl with oil.
The oil level should always be between the Min. and Max.
level of the bowl.
Do not exceed the maximum fill line as boiling oil may
overflow during frying and can cause severe burnings.
• For best results we recommend blended vegetable oil.
• For sunflower oil, groundnut oil, or soya oil, ensure the oil
is changed after every 5 uses.
Follow the manufacturer's cooking recommendations.
• If you use solid vegetable fat: cut it into small pieces, melt
it in a separate pan then pour the melted fat into the fryer
bowl.
Be sure that the
oil level is
between the Min.
and Max. level of
the bowl
otherwise the
safety cut-out will
activate
(see page 5).
!
Never use
different types of
oil at the same
time as this may
cause the oil to
overflow.
!
Never melt the fat
on the heating
element or in the
frying basket.
If you melt the fat
on the heating
element or in the
frying basket, the
safety cut-out
would be
activated
(see page 5).
!
Maxi 3,3 L
Mini 2,8 L
Maxi 2888 g
Mini 2450 g
