TEFAL DR80XX User manual

www.tefal.com
Access’Steam DR80XX
1800135875-02DR8080G1.qxp_110x15401/10/1514:04Page1

2
3
4
6
7
5
1
9 10* 11*
8
* EN Depending on model
1800135875-02DR8080G1.qxp_110x15401/10/1514:04Page2

* EN Depending on model
PROD CT DESCRIPTION
1. On/Off button
2. Steam head
3. Hanging hook
4. Lock position
for continuous steam
5. Steam trigger
6. Standing base
7. Removable water tank
8. Cord exit
9. Fabric brush
10*. Steam cover
11*. Door hook
1800135875-02DR8080G1.qxp_110x15401/10/1514:04Page3

4
IMPORTANT SAFETY
INSTR CTIONS
When using your appliance, basic precautions
should always be followed, including the following:
• Read all instructions before using this product.
• This product has been designed for indoor,
domestic use only. Any commercial use,
inappropriate use or failure to comply with the
instructions, the manufacturer accepts no
responsibility and the guarantee will not apply.
• Always plug your appliance:
- into a mains circuit with voltage between 220 V
and 240 V.
- into an earthed electrical socket.
Connecting to the wrong voltage may cause
irreparable damage to the appliance and will
invalidate your guarantee.
If using a mains extension lead, ensure that it is
correctly rated (16A) with an earth, and is fully
extended.
• Completely unwind the power cord before
plugging into an earthed socket.
• Use appliance for its intended use only.
• To reduce the risk of contact with hot water
emitting from steam vents, check appliance
1800135875-02DR8080G1.qxp_110x15401/10/1514:04Page4

5
before each use by holding it away from body and
operating steam button.
• ever pull on the cord to disconnect the
appliance from electrical outlet; instead, grasp
plug and pull to disconnect on the plug to
disconnect the appliance.
• Do not allow cord to touch hot surfaces or come
into contact with rough or sharp edges. Let the
appliance cool completely down before putting
away. Loop cord loosely around appliance when
storing.
• Always disconnect appliance from the electrical
supply when filling with water or emptying when
cleaning, when removing or refitting accessories
and when not in use.
• Care should be taken when using the appliance
due to the emission of steam.
• Do not operate appliance with a damaged cord
or if appliance has been dropped or damaged. To
avoid the risk of electric shock, do not
disassemble or attempt to repair the appliance.
Take it to the nearest Tefal approved service
centre for examination and repair. Incorrect
reassembly or repair could cause a risk of fire,
electrical shock or injury to persons when the
appliance is used.
• Close supervision is necessary for any appliance
being used by or near children.
1800135875-02DR8080G1.qxp_110x15401/10/1514:04Page5

6
• Do not leave the appliance unattended while
plugged in or while it is still hot.
• Burns could occur from touching hot metal or
plastic parts, hot water or steam. Use care when
you empty a steam appliance. There may be hot
water in the reservoir.
• If an extension cord is absolutely necessary, a
cord with a 16A ampere rating shall be used. A
cord rated for less amperage can result in a risk of
fire or electric shock due to overheating. Care
shall be taken to arrange the cord so that it
cannot be pulled or be tripped over.
• To protect against a risk of electric shock, do not
immerse the appliance in water or other liquids.
• Do not direct steam at people, animals or clothes
while they are being worn.
• This appliance is not intended for use by persons
(including children) with reduced physical, sensory
or mental capabilities, or lack of experience and
knowledge, unless they have been given
supervision or instruction concerning use of the
appliance by a person responsible for their safety.
Children should be supervised to ensure that they
do not play with the appliance.
• This appliance can be used by children aged from
8 years and above and persons with reduced
physical, sensory or mental capabilities or lack of
experience and knowledge if they have been
given supervision or instruction concerning use of
the appliance in a safe way and understand the
1800135875-02DR8080G1.qxp_110x15401/10/1514:04Page6

7
hazards involved. Children shall not play with the
appliance. Cleaning and user maintenance shall
not be made by children without supervision.
• The use of accessory attachments other than
those provided by *Tefal is not recommended and
may result in fire, electric shock or personal injury.
• The appliance must be rested on a stable surface.
When placing the appliance on its base, ensure
that the surface on which the base is placed is
stable.
• The appliance must not be used if it has been
dropped, if there are visible signs of damage or if
it is leaking.
• Check the electrical power cord for sign and wear
or damage prior to use. If the electrical power
cord is damaged, it must be replaced at an
approved service centre to avoid any danger.
SAVE THESE INSTR CTIONS
1800135875-02DR8080G1.qxp_110x15401/10/1514:04Page7

BEFORE SE
Remove the water tank.
Remove the water inlet stopper.
8
During the first few uses, the appliance may produce
smoke, a harmless odour and a light emission of
particles. These are simply the engineering residues
from the manufacturing process burning off. These
are harmless and will quickly disappear.
WHICH WATER SHO LD I SE?
Filling the water tank
• Your appliance was designed to operate using
untreated tap water.
However, it is necessary to periodically clean the
appliance to remove any mineral deposits.
• Do not use pure demineralised or pure distilled
water, water containing additives, water from clothes
dryers, scented or softened water, rain water, filtered,
bottled or boiled water, water from refrigerators,
batteries or air conditioners as these may damage
the appliance. These types of water contain organic
waste, mineral elements that become concentrated
when heated and cause spitting, brown staining,
leaking or premature wear on your appliance. If your
water is very hard, mix 50% untreated tap water
with 50% distilled water (available in hardware
stores).
1
1800135875-02DR8080G1.qxp_110x15401/10/1514:04Page8

Return the water tank to its place on the appliance
then plug it in. Make sure that the water tank is fully
set in place.
Hang your garment on a clothes hanger.
9
MAX
200 ml
Fill the water tank with a maximum of 200 ml of
untreated tap water.
Close the water inlet stopper.
Tips: Check the fabric’s label for recommendations.
We recommende that you test acrylic, nylon or other
synthetic fabrics in an inconspicuous area to ensure
these fabrics are not damaged by hot steam.
As steam is very hot: never attempt to remove
creases from a garment while it is being worn, always
hang garments on a clothes hanger.
1800135875-02DR8080G1.qxp_110x15401/10/1514:04Page9

10
The fabric brush opens the weaves of the fabrics for
better steam penetration.
Before removing or attaching the steam brush, unplug
your appliance and allow it to cool down, for one hour.
The steam cover filters water impurities and protects
fabrics from water drips.
Before removong or attaching the steam cover, unplug
your appliance and alow it to cool down for one hour.
SE
*
*
*
* EN Depending on model
ACCESSORIES
The door hook allows to hang your garment for
steaming.
During use or while unit is heating or cooling, do not
rest appliance on its head. Place the product on a
stable, heat resistant, flat surface, as the head will be
hot. As the appliance heats, the housing becomes
warm. This is normal.
2
3
1800135875-02DR8080G1.qxp_110x15401/10/1514:04Page10

11
Switch on the appliance.
ON
OK
45s
Wait until the light stops flashing (approximately 45
seconds). When the light is steady the appliance is
ready to use.
Press the steam button with the steam brush facing
away from you holding it in a vertical position.
For optimal use, pass the steam jets over your garment
from top to bottom.
1800135875-02DR8080G1.qxp_110x15401/10/1514:04Page11

3 sec.
Press and hold the On/Off button for 3 seconds to
switch the appliance off.
Unplug the appliance.
1h
Wait for an hour for your appliance to cool before
storing.
12
OFF
For continous steam, lock the steam trigger by pushing
the switch down.
if you need to refill the water tank during use, please
refer to 'Before Use' Section.
1800135875-02DR8080G1.qxp_110x15401/10/1514:04Page12

Remove the water tank.
Empty the water tank completely.
13
AFTER SE
Return the water tank to its place on the appliance.
After use or while unit is cooling down, place the
product on a flat, stable, heat resistant surface.
4
1800135875-02DR8080G1.qxp_110x15401/10/1514:04Page13

14
EASY DESCALING
Remove the water tank.
Remove the water inlet stopper.
50%
WhiteWhite
VinegarVinegar
White
Vinegar
50%
WaterWaterWater
Fill the water tank with 50% water and 50% white
vinegar.
Do not use other descaling products.
Return the water tank to its place on the appliance.
Make sure the water tank is fully set in place.
5
We advise you to do this operation in a vented room
1800135875-02DR8080G1.qxp_110x15401/10/1514:04Page14

15
Plug-in the appliance.
Switch on the appliance.
OK
45s
Wait until the light stops flashing (approximately 45
seconds). When the light is steady the appliance is
ready to use.
Put the steam trigger in the locked position.
Place the product on a flat, stable, horizontal and heat
resistant surface.
ON
1800135875-02DR8080G1.qxp_110x15401/10/1514:04Page15

OK
Allow the appliance to run until the water tank has
completely emptied.
3 sec.
Press and hold the On/Off button for 3 seconds to
switch the appliance off.
16
OFF
Unplug the appliance and pull the water tank out.
MAX
200 ml
Remove the water inlet stopper and fill the water tank
with a maximum of 200 ml of untreated tap water.
1800135875-02DR8080G1.qxp_110x15401/10/1514:04Page16

17
Plug in the appliance.
Switch on the appliance.
ON
OK
45s
Wait until the light stops flashing (approximately 45
seconds). When the light is steady the appliance is
ready.
Return the water tank to its place on the appliance.
Make sure the water tank is fully set in place.
1800135875-02DR8080G1.qxp_110x15401/10/1514:04Page17

18
Put the steam trigger in the locked position.
place the product on a flat, stable, horizontal and heat
resistant surface.
OK
1800135875-02DR8080G1.qxp_110x15401/10/1514:04Page18

STANDBYE MODE
1) For your safety, the steambrush is fitted with a standby monitoring system, which is
activated automatically after approximately 8 minutes without use.
2) Only the ‘On-Off ’button flashes slowly to indicate that the appliance is on standby
3) To reactivate the steambrush :
a. Press the ‘ On-Off ’ button and wait that the button light stops flashing
b. You can start steaming again
1800135875-02DR8080G1.qxp_110x15401/10/1514:04Page19

1800135875-02 - 40/15
www.tefal.com
PROBLEMS POSSIBLE CA SES SOL TIONS
There is no steam. The app iance is not p ugged in, or
not switched on.
The water eve is too ow.
The steam pump has not been
primed.
You are using the app iance for the
first time.
The water tank is not fu y in p ace.
The app iance is on standby mode.
Check that your app iance is
correct y p ugged in and switched
on.
Unp ug your app iance and refi it.
Press the steam trigger continuous y
for a few seconds to begin steaming.
Press the steam trigger continuous y
for a few seconds to begin steaming.
Ensure that stopper is c osed and
that the water tank snaps when put
into p ace.
PLEASE REFER TO THE ‘STANDBY’
section.
The app iance
does not heat.
It is not p ugged in, or not switched
on.
The app iance is on standby mode.
P ug in your app iance and switch
on.
PLEASE REFER TO THE ‘STANDBY’
section.
Water eaks. The water tank is not fu y in p ace
or the stopper is not c osed
proper y.
Ensure that stopper is c osed and
that the water tank snaps when put
into p ace.
Steam rate
decreases.
Ca c Sea ing. Refer to ‘ANTI CALC section in
instructions for use.
The steam eaves
stains on the fabric
or the app iance
spits.
You are using water with additives.
The app iance has not been
c eaned enough after the desca ing
operation.
You are using other iquids than
white vinegar to desca e the
product.
Never add any additive in the water
tank.
Read carefu y the ‘ANTI CALC’
section in instructions for use.
Use on y white vinegar during ‘ANTI
CALC’ procedure.
App iance steams
continuous y.
The steam trigger is on the ock
position.
Un ock the steam trigger.
IS THERE A PROBLEM ?
1800135875-02DR8080G1.qxp_110x15401/10/1514:04Page20
