Tefi Vintage Lab GainOver User manual

Te Vintage Lab is pleased to welcome you to our family. We hope you
enjoy using our new GainOver dual preset overdrive. Feel free to get
in touch for any suggestions or clarications as to how you might best
use the effect. Play music and enjoy using our products!
GainOver - Dual preset overdrive
GainOver is a two-preset overdrive with switchable channels and in-
dependent Gain and Volume controls. The “Low Gain” section ranges
from a quasi-clean boost to a creamy full dynamic crunch with clear
attack, while the “High Gain” section maintains these properties whi-
le producing more drive saturation. The GainOver design is based on
the PCN (Progressive Clipping Network) proprietary circuit, a com-
plex analog net designed to obtain a dynamic and progressive appro-
ach to distortion, reproducing the incoming saturation of an EL84
Class-A nal stage of a tube amplier.
Thanks to the PCN circuit every note is well dened, whether you are
playing a melodic phrasing, a rhythmic pattern or a sustained Solo.
We have created GainOver to allow the musician to maintain the same
sound during playing, from light crunch to hard overdrive Soloing in
one pedal. Moreover, GainOver can be used in a single channel ampli-
er to obtain a typical three channel conguration (Clean, Crunch,
Drive), thanks to two independent Gain-Volume settable presets that
allow limitless versatility.
GainOver Operating Manualwww.tevintagelab.it
Dimensions
Output impedance
Power supply/
Power consumption
9Vdc/ca. 165mW (I-max
consumption=18mA @9Vcc)
Chassis
Max Gain “HI Gain” section
Weight
Max Gain “LO Gain” section
Input impedance
Signal switching
127x95x52 mm
Battery type +9V (6LF22)
Power connection/ground Negative tip/negative ground
470 Ohm
Alluminio, die-cast
+65 dB
360gr. (senza batteria)
+46 dB
700 kOhm
True-bypass
TECHNICAL SPECIFICATIONS

CONNECTION AND USE
• Connectingtoinstrumentandamplier/gear: connect your instrument
(or gear effects chain) to the Input jack on the pedal’s right side with a
6.3mm Jack instrument cable. Connect the output jack on the pedal’s left
side to an amplier (or to the next effects in your chain) with a 6.3mm Jack
instrument cable.
• Battery: to access the battery compartment, remove the four screws on
the bottom cover. Connect the 9V battery (6LF22 type) to the battery clip
connector. Do not reverse the polarity! Insert the battery into the battery
compartment located between the two footswitches. Be careful not to da-
mage the wires and/or the battery clip. To preserve battery life disconnect
the instrument cable from the pedal Input jack when the pedal is not in
use.
• Powersupply: connect a 9V stabilized external power supply adapter to
the pedal’s power connector located on the right side (5.5mm connector
with 2.1mm pole type). Do not reverse polarity! (external positive, inter-
nal negative). In the presence of reversed polarity the pedal will not power
up; no damage will be caused below 25V reversed polarity.
CONTROLS AND FUNCTIONS
GainOver has two independent Gain-Volume presets, LO-Gain and HI-Gain, se-
lectable by pressing the footswitch on the right side of the pedal faceplate.
“LO Gain” PRESET: the reduced max gain provides a quasi-clean boost
through to a light overdrive crunch. Thanks to a wideband response, simply
by turning down the guitar’s volume it will return from crunch to its own cle-
an response. You can control Gain and Volume by setting the knobs “LO Gain”
and “LO Vol”. Activation of this preset is indicated by the cyan LED.
“HIGain”PRESET: this preset has a wide range gain setting (about 40dBv
range from minimum to maximum) and offers about 25dBv more gain than
the “LO Gain” preset, to the sustain needed during a Solo or for power chords.
At high gain, midrange frequencies are emphasized to add more presence. You
can control Gain and Volume by setting the knobs “HI Gain” and “HI Vol”. Ac-
tivation of this preset is indicated by the red LED.
CONTOUR: the Contour knob is common to both presets and regulates the ge-
neral tonal balance in a wide frequency range. Turning fully CCW gives a war-
mer sound, to balance the response on bright sounding ampliers. Rotating
CW gives more presence and lows without affecting the bass responce.
TEFI Vintage Lab invites you to activate the warranty within 10 days of the purchase of the product. It is necessary to connect to our website www.tevintagelab.it and, on the page describing your product, ll in the required form in the “register product” section.
TEFI Vintage Lab products are covered by a 5-year warranty. If the user nds an anomaly due to component defects and erroneous assembly, please contact us by sending an e-mail to info@tevintagelab.it, describing the problem encountered in detail and the
circumstances in which it was veried.
In compliance with the regulations dened in the following clauses, TEFI Vintage Lab undertakes to repair the instrument with no additional costs.
Warrantly is valid for 5 years. Does not include parts subject to wear such as jacks, switches, potentiometers, dip-switches, 9V battery clip or 9V battery holder, nor does it include aesthetic parts such as knobs.1.
Warrantly does not extend to damage caused by inexperience or negligence in the use of the effects pedal, or bad/neglected maintenance.2.
TEFI Vintage Lab undertakes to replace at its own discretion the malfunctioning or incorrect manufacturing parts, only after a careful check and verication of bad construction.3.
In the presence of incorrect use of the warranty, shipping costs will be charged to the user.4.
During the warranty period, the replaced parts/products become the property of the manufacturer.5.
This warranty is only valid for the original purchaser who has followed the normal maintenance instructions described in this manual. Our warranty liability expires at the moment the original owner surrenders ownership of the product, or modications are 6.
made to it.
Warranty does not include damage caused by excessive stress, such as the use of the product after the detection of an anomaly, the use of inappropriate methods of operation, as well as the failure to observe use and maintenance instructions. 7.
The manufacturer assumes no responsibility for any difculties that may arise in resale or use abroad due to the provisions in force in the country where the product was sold.8.
The product part of the defective unit must be delivered to TEFI Vintage Lab for replacement, otherwise the replaced part will be charged to the buyer.9.
Any product repair or modication by the user or by companies not authorized by TEFI Vintage Lab will invalidate the warranty10.
EU DIRECTIVE AND DISPOSAL
TEFI Vintage Lab products are designed to comply with the standards laid down by EU directives regarding safety and the environment. Pursuant to Legislative Decree No. 49 of March 14, 2004 “Implementation of Directive 2012/19/EU on
waste electrical and electronic equipment (RAEE)”.
The crossed-bin symbol indicates that the product, at the end of its useful life, must be separately collected from other waste.
The user must therefore confer the equipment with the essential components at the end of their life to the appropriate collection centers for electrical and electronic waste.
