Tek Nek Toys International ROCK'N RIDE LUCKY 1-80046 User manual

Á
!$5,4350%26)3)/.2%15)2%$4HISRIDEONTOYISNOTTOBEUSEDNEAR
SWIMMINGPOOLSONORNEARHILLSROADWAYSSLOPEDDRIVEWAYSORSTAIRWAYS3HOES
MUSTBEWORNATALLTIMESWHILERIDINGTHISTOY$ESIGNEDFORONLYONERIDERATATIME
i*NBMJUUMFQPOZ
DMJQJUZDMPQ
DMJQJUZDMPQyw
#1-80046
%&-69&413*/()034&%&-69&413*/()034&
"(&4


!NYCONTACTWITHMOISTUREORLIQUIDWILLDAMAGETHEELECTRONICS
#OLORSANDDECORATIONSMAYVARY
4HISPACKAGECONTAINSSMALLPARTSANDSCREWSWHICHHASHAZARDOUS 
SHARPPOINTSINTHEUNASSEMBLEDSTATE&OR!DULTASSEMBLYONLY
#ARESHOULDBETAKENINTHEUNPACKINGANDASSEMBLYOFTHETOY

OWNER’S MANUAL
WARNING
1
• PARENTS: MONITOR YOUR CHILD’S PLAY ACTIVITY TO ENSURE
PROPER AND SAFE USE OF THIS PRODUCT.
• REMOVE ALL PACKAGING, CLIPS, STAPLES, TIES AND SIMILAR
ATTACHMENTS BEFORE GIVING THIS TOY TO A CHILD,AS THESE
ATTACHENTS POSE A POTENTIAL CHOKING HAZARD AND ARE NOT
PART OF THE TOY.
• ADULT ASSEMBLY IS REQUIRED.
• PARENTAL SUPERVISION IS REQUIRED.
• This product is designed for a child at least 2 year’s old and weight
not exceeding 65 lbs (29.5 kgs).
• Allow only one child on the product at a time.
• Never allow the child to play with the product near roadways,
streets, swimming pools, hills, sloped driveways, ramps,steep
inclines, or stairs. use only on a level surface.
• Always wear shoes while riding.
• Do not allow another child to push the product when a
child is sitting on it.
• Do not allow the child to stand on the product.
• The child should always sit in the forward facing position.
• Do not allow the child to ride the product on steep inclines.
• Feet should remain in the stirrups at all times while riding the toy.
• Inspect toy periodically for loose or damaged components.
“LUCKY”, THE DELUXE TALKING PLUSH SPRING HORSE

Parts List
1. Body
X 1 pcs 2. Frame End X 2 pcs 3.
Frame Side
X 2 pcs 4. Wood Dowel X 2 pcs
5. Spring
X 4 pcs 6. Safety Hook X 8 pcs 7. Eye Bolt X 4 pcs 8. Dowel Cap X 4 pcs
15. Spring Boot
X 4 pcs
11. Frame Nut
X 8 pcs 12. Frame Washer X 8 pcs
14. Stirrup
X 2 pcs
9. Dowel Screw
X 4 pcs 10. Frame Bolt X 8 pcs
2

Insert the two wood dowels (4) through the body (1), and secure
them to the body with the four dowel screws (9).
Insert the flat end of a safety hook (6) into one side of a spring
(5), and turn the safety hook until the curved end is aligned with
the hook on the spring. Repeat this step with the other three
springs.
Insert a spring boot (15) over a frame attachment point. Please
note that the white plastic anchor at the attachment point has a
thicker section at the top of it. While compressing the spring boot,
insert the spring/safety hook assembly into the anchor so that the
open ends of the two hooks go into the hole and over the thicker
section of the anchor. The attached spring/safety hook assembly
should be facing towards the center of the frame. Repeat this
step at the other three frame attachment points.
Assembly Instructions
Step 1:
Step 2:
3
Step
1 Step
2
2
3
11
10 12
9
4
1
Connect the two frame ends (2) to the two frame sides (3) using
the frame bolts (10), frame nuts (11) and frame washers (12).
Ensure that each corner of the frame is secured with two sets of
bolts/nuts/washers.
Step 3:
Step 4:
15
5
Step
4
Step
3
6
5

Step 6:
Step 7:
4
7
Step
6 Step
7
Insert the flat end of a safety hook (6) into the other side of a
spring (5), and turn the safety hook until the curved end is aligned
with the hook on the spring. Attach the spring/safety hook
assembly to the closest eye bolt (7) on the horse. Repeat this
step with the other three springs.
Slide the four spring boots (15) over the spring/safety hook
assemblies until they are flush with the body and stirrups.
Ensure all spring assemblies are completely covered by the
boots to minimize pinching or chaffing during use.
Step 5:
CD
AB
114
7
8
Step
5
Slide a stirrup (14) over one side of the forward wood dowel.
Place a dowel cap (8) over the end of the dowel. Secure the
woven safety strap, located at the frame attachment point, to the
dowel with an eye bolt (7). Ensure that the eye bolt is tightened
completely and that the hole in the eye bolt is parallel to the floor.
Failure to completely tighten and properly align the eye bolt can
result in damage to the toy and possible injury to the rider. Please
refer to close-ups A and C in the Step 5 diagram for correct
installation. Repeat this step at the other three ends of the wood
dowels, noting that the second stirrup is only used on the other
side of the forward dowel.
Step 8: Re-tighten all frame fasteners.

Buttons and Sounds
Operation and Features
Lucky can make several sounds and move his mouth, while allowing
his rider to enjoy an exciting gallop on the open range!
Note:
“ Hi friend, it's a beautiful day for a ride. Let's go! ” OR
“ I love riding with you because we have so much fun
together. ” OR “ I'm your talking, singing pony friend! ” OR
“ I like hugs! When you hug me, you can feel my soft coat. ”
Various horse sounds, including galloping,
whinnying and snorting
Song “ I’m a little pony, clippity-clop, clippity-clop.
Such a pretty pony, clippity-clop, clippity-clop.
I love to have my coat brushed underneath the old
oak tree. Let’s jump and run, we'll have lots of fun.
Can you come and play with me?”
5
By pressing the following buttons located on Lucky’s ears, his mouth will
move, and you will hear:
You must slide the switch on the battery compartment to “ON” to
activate the motion sensor, which will make galloping sounds when
Lucky is rocked.
Lucky’s battery compartment is located on the left side of his mane, along
his neck. There is a Velcro strip underneath the hair, and the battery
compartment is located inside it. You will need a small Phillips screwdriver
to open it. It uses three AA batteries.
Battery Replacement
Volume Control
You can adjust Lucky’s sound volume by sliding the volume switch on his
battery compartment to either soft or loud. Refer below to the Battery
Replacement section for the location of the battery compartment.

WARNING
WHEN CHANGING THE BATTERIES, THE SCREW THAT SECURES THE
BATTERY COMPARTMENT SHOULD BE KEPT AWAY FROM
CHILDREN AS IT POSES A POTENTIAL CHOKING OR INHALATION
HAZARD.
1) An adult should handle battery installation.
2) Remove exhausted batteries and dispose of properly.
3) Install 3 AA (1.5V) batteries correctly observing the polarity (+, -)
signs to avoid leakage.
4) Replace battery cover and screw.
5) Do not mix old and new batteries.
6) Do not mix alkaline, standard (Carbon-Zinc), and rechargeable
(Ni-Cad) batteries. Only batteries of the same or equivalent type as
recommended are to be used.
7) Remove the batteries if the toy will not be in use for an extended period of time.
8) Do not dispose of batteries in a fire.
9) Do not attempt to recharge standard batteries.
10) The supply terminals are not to be short-circuited.
11) Rechargeable batteries are to be removed from the toy before being
charged (if removable). Rechargeable batteries are only to be charged
under adult supervision (if removable).
Care and Maintenance
• Check all nuts and bolts prior to use and periodically thereafter. Tighten
or replace as necessary.
• Product may be cleaned with a mild household detergent and warm water.
• Scratches on metal parts may be touched up with a non-lead based paint.
• Do not place unit near stairways, wall heaters, fireplace or any source
of extreme heat.
• Check all plastic and metal parts for cracks, cuts and/or excessive wear.
Replace as necessary.
• Any contact with moisture or liquid may damage the electronics.
• Occasionally check to see that all nuts and bolts are on tight and secure.
• If the sound is not operating correctly, replace the batteries.
• Make sure all hardware is tightened and springs covers are
securely in place before the child rides the toy.
• Please note: all springs, stirrups, screws and spring covers are
contained inside the small box within the package for shipping purposes.
6

PLEASE KEEP THIS MANUAL FOR FUTURE REFERENCE.
This product conforms to ASTM-F963. Standard
Consumer Safety Specifications on Toy Safety.
This instruction manual contains assembly instructions,
safety and maintenance tips.
©Tek Nek Toys International, L.P.
2834 Market Loop, Suite 106
Southlake, TX 76092
Pat. No. US 6,524,156/6,780,076
www.teknektoys.com
Made in China.
