TEKA ILLUMINATION TOWER BOLLARD User manual

THIS DOCUMENT CONTAINS PROPRIETARY INFORMATION OF TEKA ILLUMINATION AND ITS RECEIPT OR POSSESSION DOES NOT CONVEY ANY RIGHTS TO REPRODUCE, DISCLOSE ITS CONTENTS, OR TO MANUFACTURE, USE OR SELL ANYTHING IT MAY
DESCRIBE. REPRODUCTION, DISCLOSURE OR USE WITHOUT SPECIFIC WRITTEN AUTHORIZATION OF TEKA ILLUMINATION IS STRICTLY FORBIDDEN.
THIS DOCUMENT CONTAINS PROPRIETARY INFORMATION OF TEKA ILLUMINATION AND ITS RECEIPT OR POSSESSION DOES NOT CONVEY ANY RIGHTS TO REPRODUCE, DISCLOSE ITS CONTENTS, OR TO MANUFACTURE, USE OR SELL ANYTHING IT MAY
DESCRIBE. REPRODUCTION, DISCLOSURE OR USE WITHOUT SPECIFIC WRITTEN AUTHORIZATION OF TEKA ILLUMINATION IS STRICTLY FORBIDDEN.
Warning Hot Surface
NEEDED
FOR
INSTALLATION:
By Others
Wear Gloves
DATE
12-18-17
REFERENCE NUMBER
INS-2572-00
40429 Brickyard Drive • Madera, CA 93636 • USA
559.438.5800 • FAX [phone]
www.tekaillumination.com • [email protected]
High Voltage
Mounting Plate
IMPORTANT - WEAR GLOVES TO AVOID GETTING FINGERPRINTS ON THIS PRODUCT. MANY TEKA ILLUMINATION PRODUCTS ARE DESIGNED TO NATURALLY PATINA.
OILS FROM YOUR SKIN WILL ACCELERATE THIS PROCESS WHERE TOUCHED AND ARE NEARLY IMPOSSIBLE TO REMOVE. THIS PROCESS OCCURS OVER TIME AND IS
DETERMINED BY THE INSTALLATION ENVIRONMENT.
· Suitable for wet locations
IMPORTANT LISTINGS AND CERTIFICATIONS
IMPORTANT SAFETY INFORMATION - READ, FOLLOW, AND SAVE THESE INSTALLATION INSTRUCTIONS
• Product must be installed by a qualified person in a manner
consistent with its intended use and in compliance with the
National Electrical Code, Canadian Electrical Code, and all Local and
Provincial Codes.
• Follow product label information and instructions.
• Qualified Personnel with appropriate personal protective
equipment must perform all servicing of this product.
• Before wiring to power supply and during servicing, turn off and
lock out power at fuse or circuit breaker before service.
• The use of accessory equipment not recommended by the
manufacturer or installed contrary to instructions may cause an
unsafe condition. The use of damaged components may cause an
unsafe condition and void product warranty.
IMPORTANT SAFETY INFORMATION - READ, FOLLOW, AND SAVE ALL SAFETY
AND INSTALLATION INSTRUCTIONS
• Do not block light emanating from product in whole or part, as
this may cause an unsafe condition.
• Never operate the fixture with missing or damaged lens.
Lens must be cleaned on regular basis.
• Entire fixture may become extremely hot. Do not touch hot
lens or fixture body.
• Replace LED assembly only with correct wattage and type of
power supply appropriate for LED assembly.
• All gaskets, o-rings and sealing surfaces must be kept clean
during installation and service; failure to do this may cause an
unsafe condition and void product warranty.
INSTRUCTIONS PERTAINING TO
A RISK OF FIRE, OR INJURY TO
PERSONS IMPORTANT SAFETY
INSTRUCTIONS
Lighted fixture is HOT!
WARNING - To reduce the risk of
FIRE OR INJURY TO PERSONS:
Turn off/unplug and allow to cool before replacing LED.
Fixture gets HOT quickly! Contact only switch/plug when
turning on. Do not touch hot lens, guard, or enclosure.
Keep fixture away from materials that may burn.
Do not operate the luminaire fitting with a missing or
damaged shield. Do not touch the source at any time. Use
a soft cloth or gloves. Oil from skin may cause damage.
SAVE THESE INSTRUCTIONS
TOWER BOLLARD™ (TWB)
IMPORTANT SAFETY INFORMATION - READ, FOLLOW, AND SAVE THESE INSTALLATION INSTRUCTIONS
Lens
Rings
Cap
#36
Anchor
Kit Option
1/8”, 0.050” & 9/64” Allen Wrench
Waterproof Wire Connectors
Mounting Hardware
Gloves
Adjustable Crescent Wrench
Silicone Sealant

IMPORTANT SAFETY INFORMATION LISTED ON REVERSE
READ, FOLLOW, AND SAVE ALL SAFETY AND INSTALLATION INSTRUCTIONS
DATE
12-18-17
40429 Brickyard Drive • Madera, CA 93636 • USA
559.438.5800 • FAX [phone]
www.tekaillumination.com • [email protected]
REFERENCE NUMBER
INS-2572-00
TOWER BOLLARD™ (TWB)
Max. 3/4”
1. Adjusted anchor bolts to project no more than
3/4” above the anchor plate after installation. The
three (3) 1/4-20 nuts on top of the plate may be
left in place while concrete is poured.
Finished grade Finished grade
Finished grade
3. With the conduits in place and the anchor
plate properly positioned, secured and leveled,
concrete may be poured.
Finished grade
Finished grade
Finished grade
2. Install anchor plate and bolt assembly flush
with the finished grade. Run conduit inside
of the anchor plate center hole prior to
pouring concrete. The conduit may project
above the finished surface of the concrete
by 3/4” maximum. Max of four (4) 3/4” trade
size conduits may be positioned inside anchor
plate center hole prior to concrete pour.
Anchor #36 Installation
4. The fixture may be installed by removing the
three (3) 1/4-20 nuts and re-using them with
wrench to secure the fixture mounting base
assembly. See fixture installation sheet(s) for
additional information.
Soil Prep
Conduit
trench
B. Dig hole 10” wide and 24” deep.
Conduit
Trench
Excavated
for Anchor Kit
C. Prep soil according to DIG-IT Guide.A. Determine Soil Type by referencing DIG-IT Guide.
Prep soil according to DIG-IT Guide.

2. Place wiring connections inside of fixture
and mounting plate and engage fixture with
mounting plate. Tighten four (4) 1/4-20 set
screws with 1/8” Allen wrench to secure. Make
sure the fixture is completely seated.
WIRING DIAGRAM
Phase 2 - Fixture Installation
1. Make connections from primary branch circuit
to driver primary leads using watertight wire
connectors (By Others). Connect incoming
dimming controls to driver side dimming
controls. Connect green fixture ground wire to
green primary ground wire. Secondary side is
factory wired. See wiring diagram.
TOWER BOLLARD™ (TWB)
IMPORTANT SAFETY INFORMATION LISTED ON REVERSE
READ, FOLLOW, AND SAVE ALL SAFETY AND INSTALLATION INSTRUCTIONS
DATE
12-18-17
40429 Brickyard Drive • Madera, CA 93636 • USA
559.438.5800 • FAX [phone]
www.tekaillumination.com • [email protected]
REFERENCE NUMBER
INS-2572-00
2. Remove mounting plate assembly from the
fixture base by loosening four (4) 1/4-20 x
1/2” set screws with 1/8” Allen wrench.
Phase 1 - Install Mounting Plate
4. Seal as per NEC with waterproof silicone sealant
(By Others).
1. Remove 1/4-20 nuts from installed #36 anchor
kit with adjustable crescent wrench.
5. Pull primary branch circuit wiring necessary for
installation (By Others). Pull incoming dimming
controls for installation (By Others).
3. Attach mounting plate to anchor bolts with
the 1/4-20 nuts and lock washers provided
with the #36 Anchor kit using adjustable
crescent wrench.
LINE
Red
FIXTURE
COM
Hydrolock
Plate
Black
GROUND
Driver
White
Black
Green
DIM +
DIM -
Black
White
Hydrolock
Plate
Green
Driver
White
Black
White
Blue
Green
LINE
COM
GROUND
Orange
Orange
Brown
Blue
Black
Gray
FIXTURE
FIXTURE
Green
Green
LINE
Red
FIXTURE
COM
Driver
Black
GROUND
DIM +
DIM -
GROUND IN HOUSING
LINE
Red
FIXTURE
COM
Driver
Black
DIM +
DIM -
GROUND ON PLATE
LINE
Red
FIXTURE
COM
Driver
Black
DIM +
DIM -
HP2RM
HP2 TR
TMB
PCIII
Generic TR
GROUND IN HOUSING
LINE
Quick
Connect
COM
Driver FIXTURE
DIM +
DIM -
PM3
GROUND IN HOUSING
LINE
Quick
Connect
COM
Driver FIXTURE
DIM +
DIM -
Quick
Connect
Driver FIXTURE
DIM +
DIM -
PM3D
GROUND IN HOUSING
LINE
COM
Remote
Driver
DIM +
DIM -
Fixture
Fixture
PM3RM
GROUND ON PLATE
LINE
COM
Driver
DIM +
DIM -
PCIII
Quick
Connect
FIXTURE
LINE
Red
FIXTURE
COM
Remote
Driver
Black
DIM +
DIM -
MA/AP
GROUND
GROUND IN HOUSING
LINE
COM
Remote
Driver
DIM +
DIM -
DIM +
DIM -
PM3DRM
Fixture
Fixture
Remote
Driver
Fixture
Fixture

TOWER BOLLARD™ (TWB)
IMPORTANT SAFETY INFORMATION LISTED ON REVERSE
READ, FOLLOW, AND SAVE ALL SAFETY AND INSTALLATION INSTRUCTIONS
DATE
12-18-17
40429 Brickyard Drive • Madera, CA 93636 • USA
559.438.5800 • FAX [phone]
www.tekaillumination.com • [email protected]
REFERENCE NUMBER
INS-2572-00
1. Loosen three (3) #10-24 set screws on cap using
9/64” Allen wrench.
Replacing LED Assembly
2. Disconnect quick disconnects at top of
heatsink.
9. Place cap back on fixture body. Tighten three
(3) #10-24 set screws on cap using 9/64” Allen
wrench.
3. Loosen, then remove two (2) #4-40 screws from
LED module using .050” Allen wrench.
4. Carefully remove LED module from heatsink.
Do not pull on connector or wiring. Handle
with care.
Fragile! Do not pull on connector or wiring.
Handle with care.
5. Use small pick tool to push connector off
LED board through two small slots behind
connector. Once loose, lift connector upwards
and off board.
6. Spread thin, even layer of thermal paste on back
of new LED module. Place new LED module
onto heatsink, lining up module with holes for
screws. Tighten two (2) #4-40 screws using .050”
Allen wrench to secure LED module to heatsink.
7. Press connector straight downwards into slot on
module to snap into place.
Connector will only fit in one direction.
8. Reconnect quick disconnects at top of
heatsink.










ĺ
ĺ
Current
350mA
500mA
550mA
700mA
750mA
900mA
12 3

ĺ
ĺ
Current
350mA
500mA
550mA
700mA
750mA
900mA
12 3

