Teka RSR 10138 EU User manual

EN ES PT PL
User Manual
RSR 10138 EU
www.teka.com

1 1 Warning 1-2
2 1 Placement 6
2 2 Level ing feet 7l
Door Right-Left Change
(optional
3 1 Key components 11
4 1 Cleaning 13
Stop using
14
4 Maintenance of refrigerator
5 Trouble shooting
CONTENTS

1
1 Safety warnings
1
1.1 Warning
:
This appliance is intended to be used in household and similar applications such as staff kitchen
areas in shops, offices and other working environments; farm houses and by clients in hotels, motels
and other residential type environments; bed and breakfast type environments; catering and similar non-
retail applications.
This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance.
If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly
qualified persons in order to avoid a hazard.
Do not store explosive substances such as aerosol cans with a flammable propellant in this
appliance.
The appliance has to be unplugged after use and before carrying out user maintenance on the
appliance.
Warning: Keep ventilation openings, in the appliance enclosure or in the built-in structure,
clear of obstruction.
Warning: Do not use mechanical devices or other means to accelerate the defrosting
process, other than those recommended by the manufacturer.
Warning: Do not damage the refrigerant circuit.
Warning: Do not use electrical appliances inside the food storage compartments of the
appliance, unless they are of the type recommended by the manufacturer.
Warning: Please abandon the refrigerator according to local regulators for it use flammable
blowing gas and refrigerant.
Warning: When positioning the appliance, ensure the supply cord is not trapped or
damaged.
Warning: Do not locate multiple portable socket-outlets or portable power supplies at the
rear of the appliance.
Do not use extension cords or ungrounded two prong adapters
Take off the doors
Leave the shelves in place so that children may not easily climb inside
installation of accessory

Refrigerant and cyclopentane foaming material used for the appliance are
flammable. Therefore, when the appliance is scrapped, it shall be kept away from any fire source and
be recovered by a special recovering company with corresponding qualification other than be disposed
by combustion, so as to prevent damage to the environment or any other harm.
The necessity that, for doors or lids fitted with locks and keys, the keys be kept out of the reach
of children and not in the vicinity of the refrigerating appliance, in order to prevent children from being
locked inside .
For EN standard: This appliance can be used by children aged from 8 years and above and
persons with reduce physical sensory or mental capabilities or lack of experience and knowledge if they
have been given supervision or instruction concerning use of the appliance in a safe way and
understand the hazards involved. Children shall not play with the appliance. Cleaning and user
maintenance shall not be made by children without supervision. Children aged from 3 to 8 years are
allowed to load and unload refrigerating appliances.
To avoid contamination of food, please respect the following instructions:
– Opening the door for long periods can cause a significant increase of the temperature in the
compartments of the appliance.
– Clean regularly surfaces that can come in contact with food and accessible drainage systems.
– Clean water tanks if they have not been used for 48 h; flush the water system connected to a water
supply if water has not been drawn for 5 days.（note 1）
– Store raw meat and fish in suitable containers in the refrigerator, so that it is not in contact with or
drip onto other food.
– Two-star frozen-food compartments are suitable for storing pre-frozen food, storing or making
ice-cream and making ice cubes.（note 2）
– One-, two- and three-star compartments are not suitable for the freezing of fresh food.（note 3）
– For appliances without a 4-star compartment: this refrigerating appliance is not suitable for freezing
foodstuffs.（note 4）
– If the refrigerating appliance is left empty for long periods, switch off, defrost, clean, dry, and leave
the door open to prevent mould developing within the appliance.
Note 1,2,3,4: Please confirm whether it is applicable according to your product compartment type.
For a freestanding appliance: this refrigerating appliance is not intended to be used as a built-in
appliance
its service agent or similar qualified person. (See chapter 2.4 for lamp replacement)
Warning:
with the instructions.
Warning:Connect to potable water supply only. (Suitable for ice making machine)
To Prevent A Child From Being Entrapped, Keep Out Of Reach Of Children And Not In The Vicinity
Of Freezer (Or Refrigerator). Suitable for products with locks

This manual contains lots of important safety information
which shall be observed by the users.
1 2
Prohibition symbol
Warning symbol
Note symbol
This is a prohibition symbol.
Any incompliance with instructions marked with
this symbol may result in damage to the product
or endanger the personal safety of the user.
This is a warning symbol.
It is required to operate in strict observance of
instructions marked with this symbol; or otherwise
damage to the product or personal injury may be caused.
This is a cautioning symbol.
Instructions marked with this symbol require special caution.
Insufficient caution may result in slight or moderate injury,
or damage to the product.
1 3 Electricity related warnings
Do not pull the power cord when pulling the power plug of the
refrigerator. Please firmly grasp the plug and pull out it from
the socket directly.
To ensure safe use, do not damage the power cord or use the power cord
Please use a dedicated power socket and the power socket shall
not be shared with other electrical appliances.
The ower plug should be firmly contacted with the socket or else
fires might be caused.
Please ensure that the grounding electrode of the power socket is
equipped with a reliable grounding line.
Please turn off the valve of the leaking gas and then open the doors
and windows in case of leakage of gas and other flammable gases.
Do not unplug the refrigerator and other electrical appliances
considering that spark may cause a fire.
Do not use electrical appliances on the top of the appliance,
33

1.5 Warnings for placement
1 4 Warnings for using
Do not put flammable, explosive, volatile and highly corrosive items
in the refrigerator to prevent damages to the product or fire accidents.
Do not place flammable items near the refrigerator to avoid fires.
The refrigerator is intended for household use, such as storage of foods;
it shall not be used for other purposes, such as storage of blood,
drugs or biological products, etc.
Do not arbitrarily disassemble or reconstruct the refrigerator,
nor damage the refrigerant circuit; maintenance of the appliance
must be conducted by a specialist
Damaged power cord must be replaced by the manufacturer, its
maintenance department or related professionals in order to avoid
danger.
Do not allow any child to get into or climb the refrigerator; otherwise
suffocation or falling injury of the child may be caused.
Do not place he~vy objects on the top of the refrigerator considering
that objectives may fall when close or open the door, and accidental
injuries might be caused.
Please pull out the plug in case of power failure or cleaning. Do not
connect the refrigerator to power supply within five minutes to prevent
damages to the compressor due to successive starts.
The gaps between refrigerator doors and between doors and refrigerator
body are small, be noted not to put your hand in these areas to prevent from
squeezing the finger. Please be gentle when close the refrigerator door to
avoid falling articles.
Do not pick foods or containers with wet hands in the freezing chamber when
the refrigerator is running, especially metal containers in order to avoid frostbite.
44

1.7
Do not store beer, beverage or other fluid contained in bottles or
enclosed containers in the freezing chamber of the refrigerator;
otherwise the bottles or enclosed containers may crack due to
freezing to cause damages.
1.6 Warnings for energy
1)Refrigerating appliances might not operate consistently (possibility of defrosting of contents or
temperature becoming too warm in the frozen food compartment) when sited for an extended period of
time below the cold end of the range of temperatures for which the refrigerating appliance is designed.
2)The fact that effervescent drinks should not be stored in food freezer compartments or cabinets or
in low-temperature compartments or cabinets, and that some products such as water ices should not be
consumed too cold;
3)The need to not exceed the storage time(s) recommended by the food manufacturers for any kind of
food and particularly for commercially quick-frozen food in food-freezer and frozen-food storage
compartments or cabinets;
4)The precautions necessary to prevent an undue rise in the temperature of the frozen food while
defrosting the refrigerating appliance, such as wrapping the frozen food in several layers of newspaper.
5)The fact that a rise in temperature of the frozen food during manual defrosting, maintenance or
cleaning could shorten the storage life.
1.7 Warnings for disposal
Refrigerant and cyclopentane foaming material used for the refrigerator are flammable.
Therefore, when the refrigerator is scraped, it shall be kept away from any fire source and
be recovered by a special recovering company with corresponding qualification other than
be disposed by combustion, so as to prevent damage to the environment or any other harm.
When the refrigerator is scraped, disassemble the doors, and remove gasket of door and
shelves; put the doors and shelves in a proper place, so as to prevent trapping of any child.
Correct Disposal of this product
This marking indicates that this product should not be disposed with other household
wastes throughout the EU. To prevent possible harm to the environment or human health
from uncontrolled waste disposal, recycle it responsibly to promote the sustainable reuse
of material resources. To return your used device, please use the return and collection
systems or contact the retailer where the product was purchased. They can take this
product for environmental safe recycling.
55

2 1 Placement
2 Proper use of refrigerators
Precautions before installation:
Information in the Instruction Manual is only for reference. The physical product may differ.
Before installation and adjusting of accessories, it shall be ensured that the refrigerator is
disconnected from power.
Precautions shall be taken to prevent fall of the handle from causing any personal injury.
Before use, remove all packing materials, including bottom cushions,
foam pads and tapes inside of the refrigerator;
tear off the protective film on the doors and the refrigerator body.
Keep away from heat and avoid direct sunlight. Do not
place the freezer in moist or watery places to prevent rust
or reduction of insulating effect.
The refrigerator is placed in a well-ventilated indoor place;
the ground shall be flat, and sturdy (rotate left or right to
adjust the wheel for levelling if unstable).
The top space of the refrigerator shall be greater than 30cm, and
The refrigerator should be placed against a wall with a free distance
more than10cm to facilitate heat dissipation.
Do not spray or wash the refrigerator; do not put the refrigerator in
moist places easy to be splashed with water so as not to affect the
electrical insulation properties of the refrigerator.
66

2 2 2.2 Levelling feet
Schematic diagram of the levelling feet
Adjusting procedures:
a. Turn the feet clockwise to raise the refrigerator;
b. Turn the feet counterclockwise to lower the refrigerator;
c. Adjust the right and left feet based on the procedures above to a horizontal level.
77

2.3 Door Right-Left Change
1 Power off the refrigerator, and remove all objects from the door trays.
2 Dismantle the hinge cover, screws and upper hinge, and remove the hole cap and pins
from the other side
3 Remove the door first, then remove the lower hinge assembly and levelling foot, interchange
the positions of the lower hinge assembly and levelling foot and install them.
Hinge cover
Upper hinge
Levelling foot
8
8
Cross screwdriver
5/16 Masking tape
Putty knife
Lower hinge assembly
Hinge cover
Upper hinge
Levelling foot Lower hinge assembly
Cross screwdriver
5/16 Masking tape
Putty knife
Parts to be used for door reverse
Number Name Number
1
2
3
4
5
6
7
8
Upper hinge
Hinge cover
Hole cap
Stopper
Lower hinge
assembly
Levelling foot
Pre-installed on the refrigerator, still used when door
Note
Pre-installed on the refrigerator, still used when door
Pre-installed on the refrigerator, still used when door
Pre-installed on the refrigerator, still used when door
Tapping screw
Tapping locking
screw
Pre-installed on the refrigerator, still used when door
Pre-installed on the refrigerator, still used when door
Pre-installed on door end caps, still used when door
Pre-installed on door end caps, still used when door
Pre-installed on door end caps, still used when door

99
5 Install the door on the lower hinge assembly, and then install the upper hinge, hinge cover, pins and
hole cap in sequence.
4 Dismantle the stopper under the door stopper .
Hinge cover
Upper hinge
Hinge cover
Upper hinge

Before initial start, keep the refrigerator still for half an hour
Spare enough space for convenient opening of the doors and drawers or
statement by the distributor.
2.5 Starting to use
2.6 Energy saving tips
The appliance should be located in the coolest area of the room, away from heat
producing appliances or heating ducts, and out of the direct sunlight.
Let hot foods cool to room temperature before placing in the appliance. Overloading
the appliance forces the compressor to run longer. Foods that freeze too slowly may
lose quality, or spoil.
Be sure to wrap foods properly, and wipe containers dry before placing them in the
appliance. This cuts down on frost build-up inside the appliance.
Appliance storage bin should not be lined with aluminum foil, wax paper, or paper
toweling. Liners interfere with cold air circulation, making the appliance less efficient.
Organize and label food to reduce door openings and extended searches. Remove as many
items as needed at one time, and close the door as soon as possible.
1010
2.4 Changing the Light(optional)
product or statement by the distributor
( )
Any replacement or maintenance of the LED lamps is intended to be made by the manufacturer,
its service agent or similar qualified person. Replacement must first cut off the power supply.
Any replacement or maintenance of the LED lamps is intended to be made by the manufacturer,
its service agent or similar qualified person. Replacement must first cut off the power supply.
541mm
390mm
541mm
390mm

3 1 Key components
3 Structure and functions
Refrigerating chamber
The Refrigerating Chamber is suitable for storage of a variety of fruits, vegetables, beverages and
other food consume in the short term. Cooking foods shall not be put in the refrigerating chamber
until cooled to room temperature. Suggested storage time 3days to 5days.
It is the most energy efficient to place food in the position shown in the picture above.
Foods are recommended to be sealed up before putting into the refrigerator.
It is recommended to put bottled or canned drinks and other items on the door;
Note: Storage of too much food during operation after the initial connection to power may adversely
Shelf
Temperature-
control knob
Lamp
11
11
CE-BC80CM
Small tray
Little door
Large tray
Small tray
Shelf
Fruits and
CE-BC80CM

Recommended gear: 3 gears
3 2 Functions
(1) (1)
(2)
(2)
Turn the temperature control knob to MAX, the internal temperature
of the refrigerator becomes lower.
Turn the temperature control knob to MIN, the internal temperature
of the refrigerator becomes higher.
The letter on the knob only represents the level, but does not mean the specific temperature,
the "OFF" means stop working.
Recommended gear: “MED”.
If there is no special needs, please avoid setting the gear at MAX all the time so as to make sure
you can prevent the tank bladder from frosting.
1212
MIN
MED
OFF
MIN
MED
OFF
OFF
1
Gear1 Gear2 Gear3 Gear4
OFF
The figures do not mean specific set temperature, but temperature level.
"1" means the warmest setting
"4"means the coldest setting
The higher the figure is, the lower the actual temperature inside refrigerator shall be.
"OFF" means stop running.
OFF
1

4 2 Defrost
The appliance shall run continuously once it is started. Generally, the operation of the appliance
shall not be interrupted; or otherwise the service life may be impaired
4 3 Stop using
Power failure: In case of power failure, even if it is in summer, foods inside the appliance can be kept for
Long-time nonuse: The appliance shall be unplugged and then cleaned; then the doors are left open
Moving: Before the refrigerator is moved, take all objects inside out, fix the glass partitions, vegetable holder,
Remove the food from the and place it properly to prevent food from melting.refrigerator
Clear the drain pipe (to use soft materials to prevent damage to the liner), Prepare the water containers for
(pay attention to clean the compressor compartment water tray,Avoding overflow to the ground).
You can use the natural temperature the natural defrost, you can also use the ice shovel to eliminate the
You can also use the appropriate amount of hot water to speed up the defrost, with a dry towel to dry
After defrosting, put back the foods in cabinet , and power on the refrigerator
4.1 Cleaning
4 Maintenance of refrigerator
Please unplug the refrigerator for defrost and cleaning.
Dusts behind the refrigerator and on the ground shall be timely
cleaned to improve the cooling effect and energy saving.
Clean the door gasket with a soft cloth dampened with soapy water
or diluted detergent.
Please turn off the power before cleaning interior, remove all foods,
two tablespoons of baking soda and a quart of warm water. Then
rinse with water and wipe clean. After cleaning, open the door and
let it dry naturally before turning on the power.
For areas that are difficult to clean in the refrigerator (such as narrow sandwiches, gaps or
corners), it is recommended to wipe them regularly with a soft rag, softbrush, etc. and
when necessary,combined with some auxiliary tools (such as thin sticks) to ensure no
contaminants or bacterials accumulation in these areas.
Clean the bottle frame, shelves and drawers with a soft cloth dampened with soapy water
Wipe the outer surface of the refrigerator with a soft cloth dampened with soapy water,
detergen t
4
1313

Loud noise
Check whether the floor is level and whether the refrigerator is placed stably
Check whether accessories are placed at proper locations
Water tray overflows
There is too much food in the chamber or food stored contains
The doors are not closed properly, resulting in frosting due to entry
5Trouble shooting
You may try to solve the following simple problems by yourself.
Not work
Check whether the appliance is connected to power or
Check whether the voltage is too low
Check whether there is a power failure or partial circuits have tripped
Odor
Odorous foods shall be tightly wrapped
Check whether there is any rotten food
Clean the inside of the refrigerator
Light not work
Check whether the refrigerator is connected to power supply and
Have the light replaced by a specialist
Gasket gap
Remove foreign matters on the door seal
Heat the door seal and then cool it for restoration
Over heat on sidewall
Heat dissipation of the built-in condenser via the housing, which is normal
When housing becomes hot due to high ambient temperature,
Noise
Long operation of the refrigerator is normal in summer
It is not suggestible having too much food in the appliance at the same time
Food shall get cool before being put into the appliance
The doors are opened too frequently
Long-time operation
The door is stuck by food packages Too much food is placed
The refrigerator is tilted
Doors cannot be
Surface condensation
Condensation on the exterior surface and door seals of the refrigerator
Buzz: The compressor may produce buzzes during operation, and the buzzes
Creak: Refrigerant flowing inside of the appliance may produce creak,
1414

16
Table 1 Climate classes
SN + 10 to + 32
N
ST
T
Extended temperate
Temperate
Subtropical
Tropical
Class Symbol Ambient temperature range
+ 16 to + 32
+ 16 to + 38
+ 16 to + 43
SN + 10 to + 32
N
ST
T
Extended temperate
Temperate
Subtropical
Tropical
Class Symbol Ambient temperature range
+ 16 to + 32
+ 16 to + 38
+ 16 to + 43
Extended temperate: ‘this refrigerating appliance is intended to be used at ambient temperatures
ranging from 10 °C to 32 °C’;
temperate: ‘this refrigerating appliance is intended to be used at ambient temperatures ranging
from 16 °C to 32 °C’;
Subtropical: ‘this refrigerating appliance is intended to be used at ambient temperatures ranging
from 16 °C to 38 °C’;
Tropical: ‘this refrigerating appliance is intended to be used at ambient temperatures ranging
from 16 °C to 43 °C’;
If the wine cooler operates outside the climate class(ambient temperature range)for which it is
rated then it may not be able to maintain satisfactory ieternal temperatures.
Extended temperate: ‘this refrigerating appliance is intended to be used at ambient temperatures
ranging from 10 °C to 32 °C’;
temperate: ‘this refrigerating appliance is intended to be used at ambient temperatures ranging
from 16 °C to 32 °C’;
Subtropical: ‘this refrigerating appliance is intended to be used at ambient temperatures ranging
from 16 °C to 38 °C’;
Tropical: ‘this refrigerating appliance is intended to be used at ambient temperatures ranging
from 16 °C to 43 °C’;
If the wine cooler operates outside the climate class(ambient temperature range)for which it is
rated then it may not be able to maintain satisfactory ieternal temperatures.
Ordered Part
thermostats
temperature sensors
printed circuit boards
light sources
door handles
trays
baskets
door gaskets
door hinges
Provided by
Professional maintenance personnel
Professional repairers and final users
Minimum Time Required for
Provision
At least 7 years after the last model is
launched on the market
Professional maintenance personnel
Professional maintenance personnel
Professional maintenance personnel
Professional repairers and final users
Professional repairers and final users
Professional repairers and final users
Professional repairers and final users
At least 7 years after the last model is
launched on the market
At least 7 years after the last model is
launched on the market
At least 7 years after the last model is
launched on the market
At least 7 years after the last model is
launched on the market
At least 7 years after the last model is
launched on the market
At least 7 years after the last model is
launched on the market
At least 7 years after the last model is
launched on the market
At least 10 years after the last model is
launched on the market
The ordered parts in the following table can be acquired from channel _:
Ordered Part
thermostats
temperature sensors
printed circuit boards
light sources
door handles
trays
baskets
door gaskets
door hinges
Provided by
Professional maintenance personnel
Professional repairers and final users
Minimum Time Required for
Provision
At least 7 years after the last model is
launched on the market
Professional maintenance personnel
Professional maintenance personnel
Professional maintenance personnel
Professional repairers and final users
Professional repairers and final users
Professional repairers and final users
Professional repairers and final users
At least 7 years after the last model is
launched on the market
At least 7 years after the last model is
launched on the market
At least 7 years after the last model is
launched on the market
At least 7 years after the last model is
launched on the market
At least 7 years after the last model is
launched on the market
At least 7 years after the last model is
launched on the market
At least 7 years after the last model is
launched on the market
At least 10 years after the last model is
launched on the market
Special for new European standard
The shortest period for providing after-sales spare parts is 15 working days.
The model information and model identification in the product database can be obtained
by scanning the web link on the QR code (if any) on the product energy efficiency label.
