Teka Mistral Plus User manual

Register here please the specific data to the Mistral acquired by you, in order
to have available immediately all necessary data with telephone consultation
with the Trotec GmbH:
Equipment designation - type: Mistral
Year of construction:
Machine-No.:
Commission-No.: AU-
Start-up date:
OPERATINGINSTRUCTIONS
Mistral (Plus), Mistral Eco (Plus)
Mistral Super Plus
110 and 230 V
Vers.: 4.10

Contents
1. General information 5
1.1. Referring to author and patent rights 5
1.2. Notes for the operator 5
1.3. Service and warranty 6
1.4. Instruction- and training course topics 6
1.5. Examples of training course topics 7
2. Safety 9
2.1. General information 9
2.2. Duty of information 9
2.3. Intended use 10
2.4. Referring of signs and symbols 11
2.5. Residual risk 11
2.6. Safety references for the operating personnel 12
2.7. Safety references for the operation of the Mistral 13
2.8. Safety references to the maintenance 13
2.9. Referring to special danger kinds 14
2.9.1. Electricity 14
2.9.2. Types of dust and other chemical substances 14
2.9.3. Noise 15
3. Product description 15
3.1. Overview Mistral (Eco) 15
3.2. Overview Mistral (Eco) (Super) Plus 16
3.3. Description of function 17
3.4. Connection to external control 17
3.5. Protective device 17
3.6. Technical data 18
3.6.1. Mistral and Mistral Eco 18
3.6.2. Mistral Plus, Mistral Eco Plus and Mistral Super Plus 19
3.7. Differential pressure 19
4. Transport, storage and start-up 20
4.1. Transport on wooden palette 20
4.2. Scope of supply 20
4.3. Storage 21
5. Start-up of the Mistral 21
5.1. Connection of an external control 21

5.2. Connecting the Mistral 22
6. Operation of the Mistral 22
6.1. Qualification of the operating personnel 22
6.2. Operating conditions 22
6.3. Operation 23
6.4. Program 24
6.4.1. Keypad 24
6.4.2. Display 24
6.4.3. Turn the Mistral ON OFF 25
6.4.4. Turning-speed control 25
6.4.5. Volume-flow control 25
6.4.6. Operating message 25
6.4.7. Collective error message “filter full” 25
6.4.8. Collective error message “change coal“ 26
6.4.9. Collective error message „change brushes“ 26
6.5. Indicating and adjusting the system-parameter 26
6.6. Remote Control 27
6.7. Test operation 28
7. Filter pollution 29
7.1. Pre-filter 29
7.2. Filter unit 29
7.3. Activated carbon 29
8. Maintenance 30
8.1. General information 30
8.2. Operating conditions 31
8.3. Care and visual inspection 31
8.3.1. Visual inspections 32
8.4. Service 32
8.4.1. General information 32
8.4.2. Exchange of the filter-unit 32
8.4.3. Exchange of the activated carbon 34
8.4.4. Exchange of the brushes 36
9. Error tracing and break down search 37
10. Disposal 39
10.1. Environmental protection 39
10.2. Filter and types of filter dust 39
10.3. Final putting out of operation 39

11. Appendix 40
11.1. Spare and wearing parts 40
11.2. Circuit diagram 41
11.2.1. Circuit diagram Mistral Eco (Plus) 1,2kW, 230V 41
11.2.2. Circuit diagram Mistral Eco (Plus) 1,2kW, 110V 42
11.2.3. Circuit diagram Mistral (Plus) 1,1kW, 230V 43
11.2.4. Circuit diagram Mistral (Plus) 1,1kW, 110V 44
11.2.5. Circuit diagram Mistral Super Plus 230, 2,4 kW, 230 V 45
11.2.6. Circuit diagram Mistral Super Plus 110, 2,4 kW, 110 V 46
12. Declaration of conformity of the Mistral 47

1. General information
This operating instructions are a substantial assistance for the successful and safe operation of the Mistral,
Mistal Eco, Mistral Plus, Mistral Eco Plus and the Mistral Super Plus in the following briefly mentioned as
Mistral.
The operating instructions contains important notes, in order to operate the Mistral safely, properly and
economically. Their attention helps to avoid dangers to decrease repair costs and down-times and to
increase the reliability and the life span of the Mistral.
The operating instruction must be available constantly at the Mistral and has to be read and used from each
person, who is assigned to work with and on the Mistral e.g.:
–Operation, disturbance recovery in the work routine, disposal of operating and auxiliary materials,
–Maintenance (maintenance, care, repair) and or
–Transport
1.1. Referring to author and patent rights
This operating instructions are to be treated confidentially. It is to be made accessible only to authorised
persons. A hiring to third may take place only with express, written agreement of the manufacturing firm.
All documents are protected in the sense of the copyright law. The passing on as well as the duplication of
documents, also in part, as well as an utilisation and a report of their contents are not entitled so far not
expressly in writing permitted.
Offences are punishable and obligate to compensation. We reserve all rights for the practice of commercial
patent rights to ourselves.
1.2. Notes for the operator
The operating instructions are a substantial component of the Mistral. The operator ensures that the
operating personnel takes these guidelines to the knowledge.
Since the operating instruction is presumably exposed to a strong demand at the place of work of the Mistral,
it is incumbent on the operator:
–to keep the original surely,
–to concern for the fact that a copy of the operating instruction is constantly available at the Mistral,
–that each user reads the operating instruction attentively and considers and keeps all data.
The operating instructions are to be supplemented around operating instructions due to the existing national
regulations for accident prevention (BGV D27) and to the environmental protection, including the information
of the duty to supervision and obligations to register, the consideration of operational characteristics e.g.
regarding working particularity relating to the work sequences and assigned personnel by the operator.
Beside the operating instructions and the in the user country and at the employment place valid obligatory
regulations for accident prevention are to be considered also the recognised specialised technical rules for
security and professional working.
After one year at the latest the examination of the Mistral is to be made by experts. The test report is to be
documented in a test book in writing.
The operator user may not make changes at the Mistral, which could impair security, without permission of
the manufacturing firm! This applies in particular to the installation and the attitude of safety devices.
Operating Instructions Mistral (Plus), Mistral Eco (Plus), Mistral Super Plus 110 and 230V vers. 4.10 Page 5 of 47

Spare parts must correspond to the technical requirements specified by the manufacturing firm. This is
always ensured with original spare parts.
Use trained or instructed personnel only. Specify the competencies of the personnel for serving, controlling
and repairing clearly!
The maintenance of the Mistral may take place only via particularly trained personnel of the Trotec
Produktions- u. Vertriebs GmbH and or a service company authorised in addition.
1.3. Service and warranty
The Trotec Produktions - Vertriebs GmbH is endeavoured to work on your questions and order as fast as
possible. We ask you to indicate your names as acknowledging address as well as the identifications data of
your Mistral before each inquiry. They are registered behind the first page of this operating instructions.
The warranty of the manufacturing firm for the Mistral extends within the implied warranty period to damage,
which can be proved on construction – to lead back material or production defects.
The time of warranty is 24 month, exception: turbine with brushes: 6 month. It begins with the delivery e.g.
start-up time of the Mistral.
A warranty is transferred only in its entirety if:
–the distribution inspection, the delivery and the instructions are implemented correctly,
–the Mistral is for intended use only,
–the maintenance and servicing instructions are to be strictly obeyed (With dirty turbine no warranty
claim exists).
In the case of a warranty the manufacturing firm transfers the material- and repair costs, which result directly
from the remedy at the Mistral.
Only the spare part prices and the fee of the manufacturing firm are valid.
We refer to the regulations as well as the general trading conditions of the Trotec Produktions- u. Vertriebs
GmbH.
1.4. nstruction- and training course topics
As operator of the Mistral you are obligated to inform and or to instruct the operating maintenance staff about
existing rules for the prevention of accidents and on the rights as well as about existing safety devices to and
around the Mistral. Different technical qualifications of the personnel are to be considered.
The operating maintenance staff must have understood the instruction and it must be guaranteed that the
instruction is considered.
Only in such a way you can achieve security and the danger-conscious working of your staff. Each co-worker
should confirm the participation in the training course and instruction in writing.
On the following pages you will find examples of instruction topics, for copying as well a list for the
confirmation.
Operating Instructions Mistral (Plus), Mistral Eco (Plus), Mistral Super Plus 110 and 230V vers. 4.10 Page 6 of 47

1.5. Examples of training course topics
1.) For the safety
Rules for the prevention of accidents
General legal regulations
General safety references
Measures in an emergency
Disposal of the filter
The personal protection equipment
Safety references for the operation of the Mistral
Handling the safety devices at the Mistral
Safety devices in the surrounding field of the Mistral
Meaning of symbols and signs
2.) To the operating of the Mistral
Handling the controls of the Mistral
Explanation of the operating instruction for the operating personnel
Special experiences of the operator in handling the Mistral
The use of used materials, aids and auxiliary facilities
Experiences regarding the employment of the Mistral
Removal of operating disturbances
3.) To the maintenance
Correct handling agents, lubricants
Special experiences of the operator within the ranges servicing, maintenance,
cleaning servicing of the Mistral
Operating Instructions Mistral (Plus), Mistral Eco (Plus), Mistral Super Plus 110 and 230V vers. 4.10 Page 7 of 47

Confirmation of the instruction
Topic of the instruction:
Date: Training course leader: Signature of the training
participant:
No. Name, Pre-name Signature
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
Operating Instructions Mistral (Plus), Mistral Eco (Plus), Mistral Super Plus 110 and 230V vers. 4.10 Page 8 of 47

2. Safety
2.1. General information
The Mistral is built according to the state of technology and the recognised safety-relevant rules.
Nevertheless dangers for the user or third and or impairments of the Mistral and other real values can
develop with its use, if:
–it is operated by not trained or not instructed personnel,
–it is not intended used,
–it is inappropriately held or waited.
2.2. Duty of information
For your security!
As operator of the filter system please, consider absolutely the data given in the CE manufacturer
explanation, CE - declaration of conformity, the data and information in the user manual and in particular the
operating and safety instructions.
Residual risk
Filter systems and suction units contain inflammable construction parts (filter material, seals, plastic parts,
etc.). Consider in your work place evaluation after the law for employee protection (AschG the residual risk of
a case of fire. It is important to have the approval of us with changes in the use of the filter system in
writing.
CE – Declaration of conformity
As a rule we deliver the filter system with a CE - declaration of conformity. When assembled with other parts
it becomes a higher - ranking filter system for which you, as operator, have the duty to make a danger
analysis and you must provide a CE - declaration of conformity for the whole filter system.
Duty of information
Sparks, cigarette stubs or similar may not be sucked into the filtering device.
Our plants may be used only as described in the operating manual and as intended. Changes in the use
require our express written permission.
Each use going beyond it is not considered as intended, the manufacturer supplier can not be made liable
for developing damages which result from it. The risks carries the operator.
ntended use of the filter system(s) / plant
t is not allowed sucking off dust, smoke, gases and media which do not correspond with the chapter
2.3 in this operating instruction. The media exhausted may be classified in no dust explosion class
(St-Class).
Start-up maintenance work and service
Refer to maintenance and safety instructions in the operating manual.
All repair and maintenance work may only be carried out with complete stand still of the machine plant
(separate all poles by switching off from the mains, pull the plug out of the socket). Only trained and
authorised personnel may operate, make maintenance work service at the machine plant. Work within the
electrical range may be implemented by authorised specialists only!
The plant must at least 1x annually be examined per AAV §16 Abs. 8.
Operating Instructions Mistral (Plus), Mistral Eco (Plus), Mistral Super Plus 110 and 230V vers. 4.10 Page 9 of 47

2.3. ntended use
The Mistral and Mistral Eco of the Trotec Produktions- u. Vertriebs GmbH exclusively serve for sucking off
gases and smoke with pollutants, which is developed with:
–Stamp production
–Marker sign production, and engraving procedure
No statements can be made for other fields of activity than in this operating instruction specified regarding the
endangerment of humans and environment. No overall statement can be made to the suitability of the Mistral,
if loaded gases and smoke with pollutants in another than here mentioned purposes are sucked off.
In this case the Trotec Produktions- u. Vertriebs GmbH is to be addressed, otherwise any warranty claim is
void.
Consider also while handling dangerous materials the rules for the prevention of accidents and here in
particular the safety rules for extractor equipment for air pollution control on the job, ZH 1 140.
The Mistral may be operated only with accessory with the equipment which are intended and approved from
the Trotec Produktions- u. Vertriebs GmbH.
The data in chapter 3.6 technical data are to be considered and kept.
Valid as not intended is the extraction of:
–damp, liquid or vapourous materials,
–explosive or inflammable gas material material air mixtures,
–in air-impermeable layers crystallising materials,
–sticky or statically responsible materials or
–incandescent or burning substances.
Another or beyond it going use, e.g. industrial extractor is considered as not intended.
If gases and smoke on production conditions are to be extracted, in the course of which carcinogenic
materials after BIA TRGS 900 are developed and or be contained, you may not use the Mistral!
Alone the operator of the Mistral is responsible for those from not intended use resulting damage. This
implies arbitrarily accomplished changes on the Mistral.
Imperfect construction unit spare parts are to be exchanged immediately. Use only original spare parts. In
particular with non original filter devices it is not ensured that they filter the pollutants from the extracted
gas smoke completely!
To the intended use also belongs keeping the references:
–for safety,
–to the operation,
–to maintenance and servicing
which are described in this operating instruction.
Operating Instructions Mistral (Plus), Mistral Eco (Plus), Mistral Super Plus 110 and 230V vers. 4.10 Page 10 of 47

2.4. Referring of signs and symbols
In this operating instruction following designations and or indications are used for safety references and
particularly important data:
Danger!
Powers on a directly threatening danger attentively which will lead to heaviest injuries of persons or to death,
if not accurately responded to the designated instructions.
Warning!
Powers on a directly threatening danger attentively which will lead to heaviest injuries of persons or to death,
if not accurately responded to the designated instructions.
Caution!
Powers on a directly threatening danger attentively which will lead to heaviest injuries of persons or to death,
if not accurately responded to the designated instructions.
All these WARNINGS must be kept in every detail!
Information!
This refers to special circumstances whose attention ensures safe, adequate and efficient handling of the
Mistral.
All references should be fulfilled in the interest of an intended use of the Mistral. Pass all references on to
other users!
●With this point work or control steps are marked. The steps are to be implemented in the sequence
from above downwards!
–By the mirror line enumeratings are marked.
References and symbols attached direct on the Mistral like warnings, warning sticker, construction unit
markings etc. must absolutely be considered.
On the Mistral attached references and symbols may not be removed and are to be kept completely
readable!
2.5. Residual risk
Also with attention to all safety regulations a residual risk remains with the operating of the Mistral.
All persons, who work on and with the Mistral, must know these residual risks and must obey the instructions,
which prevent, that these residual risks lead to accidents or damage.
Caution!
By the inhalation of poisonous gases and types of dust poisoning damage can occur. Likewise long-term
damage can occur to internal organs by repeated inhalation, sips and contact with gases and dust contained
in the filter-unit and suction hose itself.
Before all work on the inside of the Mistral, in particular at the filter devices as well as on the dust extraction
hose the personal protect equipment is to put on.
Operating Instructions Mistral (Plus), Mistral Eco (Plus), Mistral Super Plus 110 and 230V vers. 4.10 Page 11 of 47

In addition belongs:
1. Protection gloves (one-way gloves from polyethylene, long version),
2. Protection mask (purifying dust respirator with examination of the protection stage 3),
3. Eye protector.
2.6. Safety references for the operating personnel
The Mistral may be used only in technically perfect condition and as intended. Safety and danger-consciously
considering of this operating instruction is supposed! All disturbances in particular such, which can impair
security, are immediately to be eliminated!
Each person, who is assigned to the assemble, start-up, maintenance or repair at the Mistral, must have
completely read and understood this operating instruction, in particular the chapter security before beginning
with the operation.
During the work it is too late.
This applies in particular to personnel used only occasionally at the Mistral.
Each person, who is assigned to work on the Mistral, must confirm by signature that he she read and
understood the operating instructions before first handling the Mistral.
The operating instructions must be at hand constantly at the Mistral.
For damage and accident by neglecting the instructions no responsibility will be taken over.
The relevant rules for the prevention of accidents as well as the other general recognised safety-relevant
rules according to industrial medicine are to be kept.
The competencies for the different activities in the context of the operation, the maintenance of the Mistral
must be clearly fixed and kept. Only then miss-actions in particular danger situations can be avoided.
The operator has to obligate the serving and maintenance staff to carry personal protection equipment. In
addition protection gloves, purifying dust respirator mask.
Are there safety-relevant changes at the operational behaviour or disturbances at the Mistral so it has to be
stopped immediately and announced to the competent authority!
Keep first aid facilities (first aid box, eye rinsing bottles etc.) within reach!
Make known the location and operation of fire extinguishers and the possibilities of fire reporting and fire
fighting.
Absolutely consider the notes for maintenance, service and safety equipment!
Work on the Mistral may be accomplished only by reliable personnel. The legal permissible minimum age
must be considered!
Use only trained or instructed personnel!
Training, or in the context of general training personnel who is to be trained may become active at the Mistral
only under constant supervision of an experienced person!
Operating Instructions Mistral (Plus), Mistral Eco (Plus), Mistral Super Plus 110 and 230V vers. 4.10 Page 12 of 47

2.7. Safety references for the operation of the Mistral
With all work which concern:
–the operating,
–the re-equipment or the adjustment of the Mistrals and its safety devices,
–the inspection,
–the maintenance and
–the repairing
consider the turn on and turn off processes in accordance with the operating instruction and the references to
the maintenance!
The Mistral only may be operated, if all protection and safety devices e.g. solvable protection devices,
housing bolts etc. are on its place and functional!
Before starting up the personnel has to make itself familiar around the Mistral.
The Mistral may never remain unsupervised during the operation!
At least once per shift the Mistral must be examined for outwardly recognisable damage. Changes (including
that of the operational behaviour) have to be announced immediately to the responsible shift leader and or
the plant manager.
Stop and secure immediately with malfunctions at the Mistral. Disturbances are to be eliminated immediately
through trained specialists.
2.8. Safety references to the maintenance
Before beginning inform the operating personnel about the execution of special- and maintenance work.
Keep the periods for tests inspections prescribed in this operating instructions.
For the execution of maintenance work appropriate workshop equipment is absolutely necessary.
Illuminate maintenance ranges, to the extent necessary, additionally with hand or stand lamps.
For Maintenance or repair the Mistral must be switched off and secured against unexpected restarting, by:
–switching off at the circuit breaker and afterwards
–disconnecting the device from the mains by pulling out the plug of the mains cable.
With prepare-, assembly or maintenance work do not reach into the covering grid plate of the turbine or the
filter chambers in the filter-unit.
After switching off stopping the Mistral wait for the stop of the turbine.
To avoid current impacts do not open electrical construction units as well as housings and covers.
Do not touch damaged, torn life (voltage) parts.
Make no program modifications at programmable control systems.
Work on electrical equipment may be made only by trained specialists!
Check regularly for damage on cable and hose connections, particularly such at mobile construction units
and if necessary exchange.
Exchange the filter-unit in the indicated and or in appropriate time intervals, even if no safety relevant lack is
recognisable!
Tighten always again solved screwed joints with maintenance and repairs!
Operating Instructions Mistral (Plus), Mistral Eco (Plus), Mistral Super Plus 110 and 230V vers. 4.10 Page 13 of 47

If the disassembly of safety devices is necessary with servicing or repairing, the assembly and examination of
safety devices must take place immediately after conclusion of maintenance and repair work!
At the beginning of maintenance repair care the Mistral, and here in particular connections and screw
connections are to be cleaned of all contamination and residues, e.g. dust, fuels or preservative agents.
Do not use aggressive cleaning agents containing solvent Use a lint free cleaning cloths.
Use only mild cleaning agents on water basis. Consider the data of the manufacturers.
Do not use organic solvents, since fire and danger of explosion exists!
Provide for safe and environmental careful disposal of operating and auxiliary materials as well as
replacement parts!
2.9. Referring to special danger kinds
2.9.1. Electricity
The work on the electrical equipment of the Mistral may be made only by an electrical specialist or personnel
instructed by under line and supervision of an electrical specialist, in accordance with the electrical rules!
It must be waited always five minutes after switching off, so that the inserted condenser in the control board
can unload themselves. Opening of the housing is only permissible at the end of this time.
Use only original safety devices with prescribed amperages!
Never accomplish work on live parts!
With repairs pay attention to the fact that constructional characteristics are not to be safety reducing changed
in particular: allowed air creeping and air clearance as well as distances are not to be made smaller by
isolations.
The perfect grounding of the electrical system must be ensured by a protective grounding system.
Program modifications at the control system may be made only in consultation with Trotec Produktions- u.
Vertriebs GmbH or directly with the manufacturing firm.
With disturbances at the electrical power supply separate immediately the Mistral from the net, by:
–switching off the Mistral at the transparency keyboard and thereafter
–disconnecting the plug from the mains.
2.9.2. Types of dust and other chemical substances
With the Mistral partial toxic types of dust from contaminated air are filtered. Depending upon the kind of the
assigned materials these types of dust can be health-endangering and or carcinogenic.
While handling toxic types of dust special caution is required.
Consider and keep valid regulations and safety data sheets of the manufacturers concerning storage,
handling, employment and disposal, while handling chemical substances.
With eye or skin contact with the types of dust in the filters or the suction hose the part concerned must be
flushed immediately with much water. Suitable mechanisms (eye wash bottle, wash basin, shower) must be
available at hand!
By cleaning and disinfectants loaded skin should be maintained after washing. Irritation can be avoided by
the preventing use of skin protection means and a suitable skin care. The preservative agent which can be
used is to be selected as a function of the pollution impact and the individual condition of the skin. Containing
fat preservative agents are predominantly applicable.
Operating Instructions Mistral (Plus), Mistral Eco (Plus), Mistral Super Plus 110 and 230V vers. 4.10 Page 14 of 47

Eating, drinking, smoking and keeping food in areas, in which chemicals are, is forbidden!
Keep dangerous materials never in bottles or containers for food. Mark always clearly for the respective
material use certified containers.
Depending upon pollution impact particle and gas filters are subjects to the special hazardous waste
regulation and are to dispose accordingly.
The inappropriate exchange of the pollutant-loaded filter-units represents a health risk for the implementing
persons and their environment. Consider therefore with the exchange of the filter parts absolutely the section
7,4,2, exchange of the filter-unit in this operating instructions.
2.9.3. Noise
The A-weighted one equivalent continuous sound pressure level on the operation job of the Mistral lies during
normal operation below 68 dB(A), depending upon type of device.
Dependent on the local conditions a higher sound pressure level in the surrounding field of the Mistral can
prevail. This increased sound pressure level can be caused by neighbouring machines and may cause a
deafness.
3. Product description
3.1. Overview Mistral (Eco)
Operating Instructions Mistral (Plus), Mistral Eco (Plus), Mistral Super Plus 110 and 230V vers. 4.10 Page 15 of 47

3.2. Overview Mistral (Eco) (Super) Plus
Illustration 1: Total view
Pos.1 Transparent announcement, transparency keyboard Pos.10 Filter unit
Pos.2 Covering Pos.11 Activated carbon
Pos.3 Filter casing Pos.12 Tension close device
Pos.4 Activated carbon casing Pos.13 2x Extraction tube NW50
Pos.5 Turbine casing Pos.14 Extraction tube NW71
Pos.6 Guiding roller Pos.15 Exit grille
Pos.7 Guiding roller with brake Pos.16 Sub-D9 connection
Pos.8 Handle Pos.17 Mains connection
Pos.9 Frame (empty)
Operating Instructions Mistral (Plus), Mistral Eco (Plus), Mistral Super Plus 110 and 230V vers. 4.10 Page 16 of 47

Illustration 2: Transparent announcement, transparency keyboard
3.3. Description of function
The Mistral serves for extraction of gases and smoke loaded with pollutants. With a connected suction hose
between the machine which can be exhausted and the Mistral.
The Mistral is switched on and or headed for either at its transparency keyboard or by the controlling of the
machine which can be exhausted (remote switching mechanism).
The gas smoke are sucked in by the suction hose into the filter housing with the assigned filter-unit.
The Mistral consists of the following filter stages:
–Filter-unit and
–Activated carbon filter.
Through the turbine underneath the activated carbon filter the clean gas is sucked in and blown out through
the exit grille (Pos.15) attached in the back, to the ambient air.
3.4. Connection to external control
For the operation of the Mistral with a remote switching mechanism a control cable with a Sub-D9-plug is
needed. The pin allocation of the Sub-D9-plug (see in section 5,1) is to be considered!
3.5. Protective device
The Mistral is equipped with protection device, that with intended use of the Mistral no dangers for security
and health of the operator and or third exist.
The entire Mistral is designed and manufactured according to the current state of the art and the recognised
safety-relevant rules. In order to ensure the safe operation for personnel and environment, the
precautions safety devices described in the following were taken and or installed.
Unauthorised removing or bridging (go around) of protection device represents a punishable action. In the
case of loss each liability claim expires.
The turbine is secured by a shield and or a grille, which can be removed only with tool.
All elements of the control systems place themselves with power failure or announced disturbances into a
safe condition for operators, Mistral and environment.
All live construction units are secured against contact (isolated) and with sufficient estimate distance installed.
Live building groups are built in the turbine case, and can be opened only with tool.
Operating Instructions Mistral (Plus), Mistral Eco (Plus), Mistral Super Plus 110 and 230V vers. 4.10 Page 17 of 47
1 Transparent announcement
2 Key EIN AUS
3 LED-announcement „filter full“
4 Key +
5 Key -
6 Announcement: „Run“
7 Key ENTER
R u n
E rro r

All electrical construction units carry the CE characteristic for low-voltage and or EMV.
For the grounding of the Mistral a potential equalisation (Ø > 1.5 mm²) of all leading components is installed.
The Mistral is implemented according to the type of protection IP 54.
All connections of the control and the gas-prominent hoses are clearly characterised. Electrical connection
diagrams with associated parts lists are to be found in the appendix.
3.6. Technical data
3.6.1. Mistral and Mistral Eco
Filtering device: Mistral and Mistral ECO
Housing: Breadth 365 mm
Width 1089 mm
Dept 681 mm
Surrounding: Surrounding temperature, perm.+ 5 °C bis + 35 °C
Relative air humidity max. 65 %
Data
Mistral 230: Maximum air flow 280 m3h
Power of the motor 1,1 kW
Connection voltage 230 V 50 60 Hz
Maximum negative pressure 14.000 Pa
Mistral Eco 230: Maximum air flow 330 m3h
Power of the motor 1,2 kW
Connection voltage 230 V 50 60 Hz
Maximum negative pressure 14.000 Pa
Mistral 110: Maximum air flow 280 m3h
Power of the motor 1,2 kW
Connection voltage 110 V 50 60 Hz
Maximum negative pressure 21.000 Pa
Mistral Eco 110: Maximum air flow 330 m3h
Power of the motor 1,2 kW
Connection voltage 110 V 50 60 Hz
Maximum negative pressure 14.000 Pa
Filter material
Filter-unit:
Activated carbon:
Pre-filter mat for activated carbon:
Filter classification F 9
13,5 kg
Filter classification G4

3.6.2. Mistral Plus, Mistral Eco Plus and Mistral Super Plus
Filtering device: Mistral Plus, Mistral ECO Plus, Mistral Super Plus
Housing: Breadth 365 mm
Width 1240 mm
Dept 681 mm
Surrounding: Surrounding temperature, perm. + 5 °C bis + 35 °C
Relative air humidity max. 65 %
Data
Mistral Plus 230: Maximum air flow 280 m3h
Power of the motor 1,1 kW
Connection voltage 230 V 50 60Hz
Maximum negative pressure 21000 Pa
Mistral Eco Plus 230: Maximum air flow 330 m3h
Power of the motor 1,2 kW
Connection voltage 230 V 50 60 Hz
Maximum negative pressure 14.000 Pa
Mistral Plus 110: Maximum air flow 280 m3h
Power of the motor 1,2 kW
Connection voltage 110 V 50 60 Hz
Maximum negative pressure 21.000 Pa
Mistral Eco Plus 110: Maximum air flow 330 m3h
Power of the motor 1,2 kW
Connection voltage 110 V 50 60 Hz
Maximum negative pressure 14.000 Pa
Mistral Eco Super Plus 230: Maximum air flow 640 m3h
Power of the motor 2,4 kW
Connection voltage 230 V 50 60 Hz
Maximum negative pressure 14.000 Pa
Mistral Eco Super Plus 110: Maximum air flow 640 m3h
Power of the motor 2,4 kW
Connection voltage 110 V 50 60 Hz
Maximum negative pressure 14.000 Pa
Filter material
Filter-unit:
Activated carbon:
Pre-filter mat for activated carbon:
Filter classification F 9
27 kg
Filter classification G4
3.7. Differential pressure
Unit Pa
Mistral with 1 turbine
Mistral with 1 turbine and the PreFilter
Mistral with two turbines
Mistral with two turbines and the PreFilter
2500
3500
3200
5000
Operating Instructions Mistral (Plus), Mistral Eco (Plus), Mistral Super Plus 110 and 230V vers. 4.10 Page 19 of 47

4. Transport, storage and start-up
4.1. Transport on wooden palette
The Mistral is transported on a wooden pallet. The following corridor promotion vehicles are permissible for
the transport of the wood pallet:
–Fork lift and
–Fork truck.
Hard impacts of the Mistral (e.g. on the loading area of a transport vehicle) must be avoided when setting off.
Secure the wood pallets with the Mistral in the case of transport against tilting.
Imprinted arrows on the transportation crates must show upward.
Consider the valid accident prevention and industrial safety regulations.
Consider absolutely danger warnings and information on the packing!
The Mistral and or the wood pallet with the Mistral is to be secured on the transport vehicle against slipping
and tilting.
Information!
Unpack the Mistral only at the place of assembly.
Do not set up the Mistral in direct proximity of heating heating elements.
Consider sufficient area for the exchange of the filter-unit when setting up.
Proceed when unpacking and setting up the Mistral as follows:
●Lift the Mistral off the wood pallet and or from the transportation packing only at the place of
assembly. Remove the packing carefully.
●Examine the completeness of the supply on the basis of the packing list. If parts should be missing
or supplied wrongly, contact immediately the Trotec Produktions- u. Vertriebs GmbH. The same
applies to transport damages.
●In addition do examine the complete supply for outside damage, which may have developed e.g. in
the case of transport.
●Transport the Mistral afterwards attentively and prudently on its guiding rollers up to the place of
assembly.
●Set up the Mistral to even, firm underground.
●Always check that the Mistral stands secured and that the guiding roller’s brakes are set.
●Set up the Mistral in such a way, that the attached suction hoses between the Mistral and machine
which can be exhausted do not lie in through ways and or generally do not have to be exceeded.
4.2. Scope of supply
Examine with the delivery of the Mistral the scope of supply in every detail and announce immediately if parts
are missing or should be damaged. Later complaints are not accepted.
To the regular scope of supply belong:
–Mistral, completely (with inserted filter-unit); mains cable (cold equipment cable);
–Blind cover (inserted in the extraction inlets).
Please note that the scope of supply can deviate in individual cases from this list. In this case the list in the
delivery document is binding.
Operating Instructions Mistral (Plus), Mistral Eco (Plus), Mistral Super Plus 110 and 230V vers. 4.10 Page 20 of 47
