Teka TR60-120 User manual

RELEASED
02-06-18
REFERENCE NUMBER
INS-2454-00
40429 Brickyard Drive • Madera, CA 93636 • USA
559.438.5800 • FAX [phone]
www.tekaillumination.com • [email protected]
THIS DOCUMENT CONTAINS PROPRIETARY INFORMATION OF TEKA ILLUMINATION AND ITS RECEIPT OR POSSESSION DOES NOT CONVEY ANY RIGHTS TO REPRODUCE, DISCLOSE ITS CONTENTS, OR TO MANUFACTURE, USE OR SELL ANYTHING IT MAY
DESCRIBE. REPRODUCTION, DISCLOSURE OR USE WITHOUT SPECIFIC WRITTEN AUTHORIZATION OF TEKA ILLUMINATIONIS STRICTLY FORBIDDEN.
IMPORTANT SAFETY INFORMATION - READ, FOLLOW, AND SAVE THESE INSTALLATION INSTRUCTIONS
TOOLS
NEEDED:
By Others
• Product must be installed by a qualified person in a manner
consistent with its intended use and in compliance with the
National Electrical Code, Canadian Electrical Code, and all Local
and Provincial Codes.
• Follow product label information and instructions.
• Qualified Personnel must perform all servicing or relamping of
this product.
• Before wiring to power supply and during servicing or relamping,
turn off power at fuse or circuit breaker before service.
• The use of accessory equipment not recommended by the
manufacturer or installed contrary to instructions may cause an
unsafe condition. The use of damaged components may cause
an unsafe condition and void product warranty.
IMPORTANT SAFETY INFORMATION - READ, FOLLOW, AND SAVE ALL SAFETY
AND INSTALLATION INSTRUCTIONS
• Do not block light emanating from product in whole or part,
as this may cause an unsafe condition.
• Never operate the fixture with missing or damaged lens.
Lens must be cleaned on regular basis.
• Entire fixture may become extremely hot. Do not touch hot
lens or fixture body. Do not touch the lamp at any time. Use
a clean, dry, soft cloth to handle the lamp. Oil from skin may
damage the lamp and cause it to rupture.
• Replace lamp only with correct wattage and type of lamp
marked on fixture label.
• All gaskets, o-rings and sealing surfaces must be kept clean
during installation and service; failure to do this may cause an
unsafe condition and void product warranty.
INSTRUCTIONS PERTAINING TO
A RISK OF FIRE, OR INJURY TO
PERSONS IMPORTANT SAFETY
INSTRUCTIONS
Lighted lamp is HOT!
WARNING - To reduce the risk of FIRE OR INJURY TO PERSONS:
Turn off/unplug and allow to cool before replacing lamp.
Lamp gets HOT quickly! Contact only switch/plug when
turning on.
Do not touch hot lens, guard, or enclosure (see diagram/
picture).
Keep lamp away from materials that may burn.
Do no touch the lamp at any time. Use a soft cloth. Oil
from skin may damage lamp.
Do not operate the luminaire fitting with a missing or
damaged shield.
SAVE THESE INSTRUCTIONS
· Suitable for wet locations
IMPORTANT LISTINGS AND CERTIFICATIONS
Warning Hot Surface
Installation Instructions
Waterproof Wire Connectors
Mounting Hardware
High Voltage
Please refer to the low voltage design
guide at www.tekaillumination.com/
lvguide before installation for proper
wire selection.
Mounting Bracket
(Mounting Hardware By Others)
NEMA 3R Rated
Stainless Steel Housing
Two (2) 7/8” Dia. Knockouts
(Not Shown)
TR60 SERIES™
120V Magnetic Transformer
TR60-120
For LED sourced products, do
not exceed more than 80% of the
maximum load of the transformer.

Installation Instructions
IMPORTANT SAFETY INFORMATION LISTED ON REVERSE
READ, FOLLOW, AND SAVE ALL SAFETY AND INSTALLATION INSTRUCTIONS
RELEASED
02-06-18
REFERENCE NUMBER
INS-2454-00
2. Stainless steel housing has two (2) 7/8” diameter
knockouts located on bottom of housing.
1. Mount transformer stainless steel housing
with proper hardware for surface (Hardware
By Others). Clearance holes are 1-2/2” apart on
center.
1-1/2”
(2) 7/8" Dia.
Knockouts
(TR60)
WIRING DIAGRAM - 12V Output
LINE (Black)
Fixture
COM (White)
GROUND (Green)
12VAC Secondary (Blue)
COM Secondary (Blue)
13V BOOST
(Orange - Capped)
TRANSFORMER
(in Housing)
LINE (Black)
COM (White)
GROUND (Green)
13VAC Secondary (Blue)
COM Secondary (Blue)
13V BOOST
(Orange)
(Black - Capped)
Fixture
LINE (Black)
Fixture
COM (White)
GROUND (Green)
Secondary (Red)
Secondary (Yellow)
120v
277v
TRANSFORMER
(in Housing)
TRANSFORMER
(in Housing)
60
LINE (Black)
Fixture
COM (White)
GROUND (Green)
12VAC Secondary (Red)
COM Secondary (Red)
TRANSFORMER
(in Housing)
LINE (Black)
COM (White)
GROUND (Green)
12VAC Secondary (Red)
12VAC Secondary (Red)
TRANSFORMER
(in Housing)
Fixture
Fixture
LINE (Black)
COM (White)
GROUND (Green)
13V BOOST
(Orange)
(Black - Capped)
TRANSFORMER
(in Housing)
Secondary (White)
Secondary (White)
Fixture
Fixture
LINE (Black)
COM (White)
GROUND (Green)
13V BOOST
(Orange - Capped)
TRANSFORMER
(in Housing)
12VAC Secondary (White)
12VAC Secondary (White)
Fixture
Fixture
LINE (Black)
Fixture
COM (White)
GROUND (Green)
12VAC Secondary (White)
COM Secondary (White)
13V BOOST
(Orange - Capped)
TRANSFORMER
(in Housing)
LINE (Black)
COM (White)
GROUND (Green)
13VAC Secondary (White)
COM Secondary (White)
13V BOOST
(Orange)
(Black - Capped)
Fixture
TRANSFORMER
(in Housing)
WIRING DIAGRAM - 13V Output
LINE (Black)
Fixture
COM (White)
GROUND (Green)
12VAC Secondary (Blue)
COM Secondary (Blue)
13V BOOST
(Orange - Capped)
TRANSFORMER
(in Housing)
LINE (Black)
COM (White)
GROUND (Green)
13VAC Secondary (Blue)
COM Secondary (Blue)
13V BOOST
(Orange)
(Black - Capped)
Fixture
LINE (Black)
Fixture
COM (White)
GROUND (Green)
Secondary (Red)
Secondary (Yellow)
120v
277v
TRANSFORMER
(in Housing)
TRANSFORMER
(in Housing)
60
LINE (Black)
Fixture
COM (White)
GROUND (Green)
12VAC Secondary (Red)
COM Secondary (Red)
TRANSFORMER
(in Housing)
LINE (Black)
COM (White)
GROUND (Green)
12VAC Secondary (Red)
12VAC Secondary (Red)
TRANSFORMER
(in Housing)
Fixture
Fixture
LINE (Black)
COM (White)
GROUND (Green)
13V BOOST
(Orange)
(Black - Capped)
TRANSFORMER
(in Housing)
Secondary (White)
Secondary (White)
Fixture
Fixture
LINE (Black)
COM (White)
GROUND (Green)
13V BOOST
(Orange - Capped)
TRANSFORMER
(in Housing)
12VAC Secondary (White)
12VAC Secondary (White)
Fixture
Fixture
LINE (Black)
Fixture
COM (White)
GROUND (Green)
12VAC Secondary (White)
COM Secondary (White)
13V BOOST
(Orange - Capped)
TRANSFORMER
(in Housing)
LINE (Black)
COM (White)
GROUND (Green)
13VAC Secondary (White)
COM Secondary (White)
13V BOOST
(Orange)
(Black - Capped)
Fixture
TRANSFORMER
(in Housing)
3A. For 12V output wiring: Ground incoming primary ground wire to green wire from TR60 housing. Make
watertight connections from incoming primary line voltage (black) to black primary side of transformer.
Connect incoming primary common (white) to white primary side of transformer. Orange boost wire from
primary side of transformer must be capped for 12V wiring. Connect secondary side of transformer (blue
wires) to fixture leads. See wiring diagram.
3B. For 13V output wiring: Ground incoming primary ground wire to green wire from TR60 housing. Make
watertight connections from incoming primary line voltage (black) to orange boost wire from primary side
of transformer. Connect incoming primary common (white) to white primary side of transformer. Black wire
from transformer primary side must be capped for 13V wiring. Connect secondary side of transformer (blue
wires) to fixture leads. See wiring diagram.
TR60 SERIES™
120V Magnetic Transformer
1-1/2”
(2) 7/8" Dia.
Knockouts
(TR60)
40429 Brickyard Drive • Madera, CA 93636 • USA
559.438.5800 • FAX [phone]
www.tekaillumination.com • [email protected]

RELEASED
02-06-18
REFERENCE NUMBER
INS-2458-00
THIS DOCUMENT CONTAINS PROPRIETARY INFORMATION OF TEKA ILLUMINATION AND ITS RECEIPT OR POSSESSION DOES NOT CONVEY ANY RIGHTS TO REPRODUCE, DISCLOSE ITS CONTENTS, OR TO MANUFACTURE, USE OR SELL ANYTHING IT MAY
DESCRIBE. REPRODUCTION, DISCLOSURE OR USE WITHOUT SPECIFIC WRITTEN AUTHORIZATION OF TEKA ILLUMINATIONIS STRICTLY FORBIDDEN.
IMPORTANT SAFETY INFORMATION - READ, FOLLOW, AND SAVE THESE INSTALLATION INSTRUCTIONS
TOOLS
NEEDED:
By Others
• Product must be installed by a qualified person in a manner
consistent with its intended use and in compliance with the
National Electrical Code, Canadian Electrical Code, and all Local
and Provincial Codes.
• Follow product label information and instructions.
• Qualified Personnel must perform all servicing or relamping of
this product.
• Before wiring to power supply and during servicing or relamping,
turn off power at fuse or circuit breaker before service.
• The use of accessory equipment not recommended by the
manufacturer or installed contrary to instructions may cause an
unsafe condition. The use of damaged components may cause
an unsafe condition and void product warranty.
IMPORTANT SAFETY INFORMATION - READ, FOLLOW, AND SAVE ALL SAFETY
AND INSTALLATION INSTRUCTIONS
• Do not block light emanating from product in whole or part,
as this may cause an unsafe condition.
• Never operate the fixture with missing or damaged lens.
Lens must be cleaned on regular basis.
• Entire fixture may become extremely hot. Do not touch hot
lens or fixture body. Do not touch the lamp at any time. Use
a clean, dry, soft cloth to handle the lamp. Oil from skin may
damage the lamp and cause it to rupture.
• Replace lamp only with correct wattage and type of lamp
marked on fixture label.
• All gaskets, o-rings and sealing surfaces must be kept clean
during installation and service; failure to do this may cause an
unsafe condition and void product warranty.
INSTRUCTIONS PERTAINING TO
A RISK OF FIRE, OR INJURY TO
PERSONS IMPORTANT SAFETY
INSTRUCTIONS
Lighted lamp is HOT!
WARNING - To reduce the risk of FIRE OR INJURY TO PERSONS:
Turn off/unplug and allow to cool before replacing lamp.
Lamp gets HOT quickly! Contact only switch/plug when
turning on.
Do not touch hot lens, guard, or enclosure (see diagram/
picture).
Keep lamp away from materials that may burn.
Do no touch the lamp at any time. Use a soft cloth. Oil
from skin may damage lamp.
Do not operate the luminaire fitting with a missing or
damaged shield.
SAVE THESE INSTRUCTIONS
· Suitable for wet locations
IMPORTANT LISTINGS AND CERTIFICATIONS
Warning Hot Surface
Installation Instructions
Waterproof Wire Connectors
Mounting Hardware
High Voltage
Mounting Bracket
(Mounting Hardware By Others)
NEMA 3R Rated
Stainless Steel Housing
Two (2) 7/8” Dia. Knockouts
(Not Shown)
TR60 SERIES™
277V Magnetic Transformer
TR60-277
For LED sourced products, do
not exceed more than 80% of the
maximum load of the transformer.
40429 Brickyard Drive • Madera, CA 93636 • USA
559.438.5800 • FAX [phone]
www.tekaillumination.com • [email protected]
Please refer to the low voltage design
guide at www.tekaillumination.com/
lvguide before installation for proper
wire selection.

Installation Instructions
IMPORTANT SAFETY INFORMATION LISTED ON REVERSE
READ, FOLLOW, AND SAVE ALL SAFETY AND INSTALLATION INSTRUCTIONS
RELEASED
02-06-18
REFERENCE NUMBER
INS-2458-00
2. Stainless steel housing has two (2) 7/8” diameter
knockouts located on bottom of housing.
1. Mount transformer stainless steel housing
with proper hardware for surface (Hardware
By Others). Clearance holes are 1-1/2” apart on
center.
1-1/2”
(2) 7/8" Dia.
Knockouts
(TR60)
WIRING DIAGRAM - 12V Output
LINE (Black)
Fixture
COM (White)
GROUND (Green)
12VAC Secondary (Blue)
COM Secondary (Blue)
13V BOOST
(Orange - Capped)
TRANSFORMER
(in Housing)
LINE (Black)
COM (White)
GROUND (Green)
13VAC Secondary (Blue)
COM Secondary (Blue)
13V BOOST
(Orange)
(Black - Capped)
Fixture
LINE (Black)
Fixture
COM (White)
GROUND (Green)
Secondary (Red)
Secondary (Yellow)
120v
277v
TRANSFORMER
(in Housing)
TRANSFORMER
(in Housing)
60
LINE (Black)
Fixture
COM (White)
GROUND (Green)
12VAC Secondary (Red)
COM Secondary (Red)
TRANSFORMER
(in Housing)
LINE (Black)
COM (White)
GROUND (Green)
12VAC Secondary (Red)
12VAC Secondary (Red)
TRANSFORMER
(in Housing)
Fixture
Fixture
LINE (Black)
COM (White)
GROUND (Green)
13V BOOST
(Orange)
(Black - Capped)
TRANSFORMER
(in Housing)
Secondary (White)
Secondary (White)
Fixture
Fixture
LINE (Black)
COM (White)
GROUND (Green)
13V BOOST
(Orange - Capped)
TRANSFORMER
(in Housing)
12VAC Secondary (White)
12VAC Secondary (White)
Fixture
Fixture
LINE (Black)
Fixture
COM (White)
GROUND (Green)
12VAC Secondary (White)
COM Secondary (White)
13V BOOST
(Orange - Capped)
TRANSFORMER
(in Housing)
LINE (Black)
COM (White)
GROUND (Green)
13VAC Secondary (White)
COM Secondary (White)
13V BOOST
(Orange)
(Black - Capped)
Fixture
TRANSFORMER
(in Housing)
3A. Ground incoming primary ground wire to green wire from TR60 housing. Make watertight connections
from incoming primary line voltage (black) to black primary side of transformer. Connect incoming primary
common (white) to white primary side of transformer. Connect secondary side of transformer (red wires) to
fixture leads. See wiring diagram.
TR60 SERIES™
277V Magnetic Transformer
1-1/2”
(2) 7/8" Dia.
Knockouts
(TR60)
40429 Brickyard Drive • Madera, CA 93636 • USA
559.438.5800 • FAX [phone]
www.tekaillumination.com • [email protected]
