TEKNIX FF1860W User manual

INTION MANUAL
FROST FREE FRIDGE - FREEZER
FF1860W/FF1860S/FF1860B

Contents
I. SAFETY ............................................................................................................................................................3
II. Product features...............................................................................................................................................5
III. Preparations for use .......................................................................................................................................5
IV. Functions..........................................................................................................................................................6
V. Instructionsfor food storage...........................................................................................................................8
VI. Tipsfor specialneeds.....................................................................................................................................9
VII. Maintenance andcleaning.............................................................................................................................9
VIII. Simplefault analysisand elimination(varying withdifferent products).................................................10
IX. Certifications (tobe provided byCertificationEngineer).........................................................................11
X. Saferecoveryinstructions............................................................................................................................11

I.SAFETY
WARNING!
It is hazardous for anyone other than authorized service personnel to carry out servicing or repairs which involves the
removal of covers. To avoid the risk of an electric shock do not attempt to repair this appliance yourself.
WARNING!
Risk of fire / flammable materials.
Safety tips
Do not use electrical appliances such as a hair dryer or heater to defrost your Fridge/Freezer.
Containers with flammable gases or liquids can leak at low temperatures.
Do not store any containers with flammable materials, such as spray cans, fire extinguisher refill cartridges etc. in the
Fridge/Freezer.
Do not place carbonated or fizzy drinks in the Freezer compartment. Ice lollies can cause Frost/Freeze burns”. If
consumed straight from the Fridge/Freezer.
Do not remove items from the Fridge/Freezer compartment if your hands are damp/wet, as this could cause skin
abrasions or Frost/Freezer burns”. Bottles and cans must not be placed in the Freezer compartment as they can burst
when the contents freeze.
Manufacturer’s recommended storage times should be adhered to. Refer to relevant instructions.
Do not allow children to tamper with the controls or play with the Fridge/Freezer. The Fridge/Freezer is heavy. Care
should be taken when moving it. It is dangerous to alter the specification or attempt to modify this product in any way.
Do not store inflammable gases or liquids inside your Fridge/Freezer.
If the power cable is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in
order to avoid a hazard.
This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use
of the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning
and user maintenance shall not be made by children without supervision.
This refrigerating appliance is not intended to be used as a built-in appliance.
Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction.
Do not use mechanical devices or other means to accelerate the defrosting process, other than those recommended by
the manufacturer.
Do not damage the refrigerant circuit.
Do not use electrical appliances inside the food storage compartments of the appliance, unless they are of type
recommended by the manufacturer.
Do not store explosive substances such as aerosol cans with a flammable propellant inthis appliance.
This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use
of the appliance by a person responsible for their safety. Children should be supervised to ensure that they do not play
with the appliance.

–WARNING: Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of
obstruction.
–WARNING: Do not use mechanical devices or other means to accelerate the defrosting process, other than
those recommended by the manufacturer.
–WARNING: Do not damage the refrigerant circuit.
–WARNING: Do not use electrical appliances inside the food storage compartments of the appliance, unless
they are of the type recommended by the manufacturer.
–WARNING: Refrigerating appliances –in particular a refrigerator-freezer Type I –might not operate
consistently (possibility of defrosting of contents or temperature becoming too warm in the frozen food compartment)
when sited for an extended period of time below the cold end of the range of temperatures for which the refrigerating
appliance is designed;
–WARNING: The necessity that, for doors or lids fitted with locks and keys, the keys be kept out of the reach
of children and not in the vicinity of the refrigerating appliance, in order to prevent children from being locked inside.
–WARNING: The refrigerant used in your appliance and insulation materials requires special disposal
procedures.
–WARNING: When positioning the appliance, ensure the supply cord is not trapped or damaged.
–WARNING: Do not locate multiple portable socket-outlets or portable power supplies at the rear of the
appliance
Children aged from 3 to 8 years are allowed to load and unload refrigerating appliances.
To avoid contamination of food, please respect the following instructions:
–Opening the door for long periods can cause a significant increase of the temperature in the
compartments of the appliance.
–Clean regularly surfaces that can come in contact with food and accessible drainage systems.
–Clean water tanks if they have not been used for 48 h; flush the water system connected to a water supply if water has
not been drawn for 5 days.
–Store raw meat and fish in suitable containers in the refrigerator, so that it is not in contact with or
drip onto other food.
–Two-star frozen-food compartments are suitable for storing pre-frozen food, storing or making ice-
cream and making ice cubes.
–One-, two- and three-star compartments are not suitable for the freezing of fresh food.
–If the refrigerating appliance is left empty for long periods, switch off, defrost, clean, dry, and leave the door open to
prevent mould developing within the appliance.
Electrical Connection
~WARNING~
This appliance should be properly grounded for your safety. The power cord of this appliance is equipped with a
three-prong plug which mates with the standard three prong wall outlets to minimize the possibility of electrical shock.
Do not, under any circumstances, cut or remove the third ground prong from the power cord supplied.
This refrigerator appliance requires a standard 220-240VAC 50Hz
electrical outlet with three-prong ground.
This refrigerator appliance is not designed to be used with an inverter.
The cord should be secured behind the appliance and not left exposed or dangling to prevent accidental injury.
Never unplug the refrigerator by pulling the power cord. Always grip the plug firmly and pull straight out from the
receptacle.
Do not use an extension cord with this appliance. If the power cord is too short, have a qualified electrician or service
technician install an outlet near the appliance. Use of an extension cord can negatively affect the performance of the unit.
Improper use of the grounded plug can result in the risk of electrical shock. If the power cord is damaged, have it
replaced by an authorized service center.
Climate Range
The information about the climate range of the appliance is provided on the rating plate. It indicates at which ambient
temperature (that is, room temperature, in which the appliance is working) the operation of the appliance is optimal
(proper).
Climate range Permissible ambient temperature
SN from +10°C to +32°C
Nfrom +16°C to +32°C
ST from +16°C to +38°C
Tfrom +16°C to +43°C
Note Given the limit values of the ambient temperature range for the climate classes for which the refrigerating appliance
is designed and the fact that the internal temperatures could be affected by such factors as location of the refrigerating
appliance, ambient temperature and the frequency of door opening, the setting of any temperature control device might

havetobevariedtoallowfor thesefactors, ifappropriate.
If the powercable is damaged,itmustbe replaced bythe manufacturer,itsserviceagent orsimilarlyqualifiedpersonsin
order toavoidahazard.
Note:When operating in an environment other than the specified climate type (i.e., beyond the rated ambient temperature
range), the appliance may not be able to maintain the desirable compartment temperatures.
Locks
If your Refrigerator is fitted with a lock, keep the key out of reach and not in the vicinity of the appliance to prevent children
being entrapped. When disposing of an old Refrigerator, break off any old locks or latches as a safeguard.
Freon-free
The freon-free refrigerant (R600a) and the foaming insulation material (cyclopentane) that is environmentally friendly are
used for the refrigerator, causing no damage to the ozone layer and having a very small impact on the global warming.
R600a is flammable, and sealed in a refrigeration system, without leakage during normal use. But, in case of refrigerant
leakage due to the refrigerant circuit being damaged, be sure to keep the appliance away from open flames and open the
windows for ventilation as quickly as possible.
II. Product features
•Total no frost design
•Multi air flow cooling system •Electronictemperaturecontrol
•Interior LED lighting
Partsname
Due totechnologicalinnovation, thedescriptionsoftheproductinthis manualmaynotbe completelyconsistentwithyour
refrigerator.Detailsarein accordancewiththe materialitem.
III.Preparationsfor use
Installation location
1.Ventilation condition
The position you selectfortherefrigeratorinstallationshouldbe well-ventilated and haslesshotair. Donotlocatethe
refrigeratornearaheatsourcesuchascooker,boiler, and avoiditfromdirectsunlight, thusguaranteeingthe
refrigerationeffectwhilesavingenergyconsumption.Donotlocatetherefrigerator in thedampplace,soastoprevent
the refrigeratorfromrusting andleaking electricity.Theresultofthe totalspaceofthe roomin whichthe refrigeratoris
installed beingdivided bytherefrigerantcharge amount of therefrigerator shallnotbe lessthan 8g/ M3.
Note:The amount of refrigerant chargedforthe refrigerator can be found on the nameplate.
2. Heat dissipationspace
When working, the refrigerator givesoff heattosurroundings. Therefore, at least 30mm of free spaceshould be spared
at the top side,morethan100mm onbothsides,and above50mmatthe backsideof the refrigerator.
Dimensionsin mm:
W D H A B C(°) E F
595 635 1855 966 1192 130 50 100 BCD-308W
No
Description
1
Control panel
2 Fridgeshelves
3 Crisper Cover
4 Crisper
5 Freezer drawers
6 Adjustable Feet
7 Refrigerator door racks

Note Figure1, Figure2onlyasaproductspacedemandsizeschematic diagram.
3.Level ground
Placethe refrigerator on the solid and flatground (floor) tokeep it stable, orelse, it will giverisetovibration and noise.
Whenthe refrigeratorisplaced on suchflooring materialsascarpet, strawmat, polyvinylchloride,the solid backing plates
should beapplied underneaththe refrigerator,soastoprevent colorchange due toheat dissipation.
Unobstructedventilationshall be maintainedaroundtheappliance orinanembeddedstructure.
Preparationsforuse
1.Standingtime
Afterthe refrigeratoris properlyinstalledand well cleaned,do notswitchitonimmediately.Makesuretoenergizethe
refrigeratoraftermorethan1hour ofstanding,soastoensureitsnormaloperation.
2. Cleaning
Confirmthe accessorypartsinsidethe refrigerator andwipe the insidewithasoftcloth.
3. Power-on
Insert the plug intothe solid sockettostart thecompressor.After1hour,openthe freezerdoor,ifthe temperatureinside
the freezer compartment dropsobviously, it indicatesthe refrigeration systemisworking normally.
4.Storage offood
Afterthe refrigeratorrunsforaperiodoftime,theinternaltemperatureoftherefrigeratorwill beautomaticallycontrolled
accordingtothe user’stemperaturesetting.Afterthe refrigeratorisfullycooled,putinfoods,whichusuallyneed2~3
hourstobe fullycooled.Insummer,when thetemperatureis high,ittakesmorethan4hoursforthefoodstobe fully
cooled (Trytoopentherefrigerator door aslessaspossible beforethe internaltemperaturecoolsdown).
If therefrigeratorisinstalledin themoistureplace,makesuretocheckwhetherthegroundwireandleakagecircuit
breakerarenormal.If vibration noisesareproduced duetotherefrigeratorcontacting the wall orifthe wall getsblackened
byairconvectionaroundthecompressor,movetherefrigeratorawayfromthe wall.Settingup therefrigerator maycause
jammingnoiseorimagechaostothemobile phone,fixed-line telephone,radioreceiver,televisionsetsurrounding it, so
trytokeep therefrigerator asfar awayaspossible in suchcase.
IV.Functions
Whentherefrigeratorsystemispowered on forthe firsttime, all iconson the displaypanel getsilluminatedfor2s,and the
systemrunsat4 bydefault.
1.Functions
1.1Temperaturesetting
Temperature can be adjusted by pressing the ‘SET’key, and if no key operation within 3s after temperature setting, the
said setting will be validated, with the temperature immediately controlled as per the setting; and the mode indicator
light will go off after 3 seconds.
The temperature modes cycle as following:“1→2→3→4→FAST COOL→1”
ØWhen the temperature mode keeps unchanged, adjust the airregulating rod fromleft to right,the
COLDEST
COLD
1
When the user needs a colder temperature.
2
When in normal use.
3
When the user does not need a colder temperature.
4

fridge temperature gets decreased while the freezer temperature increased.
ØWhen the temperature mode keeps unchanged, adjust the airregulating rod fromright to left, the
fridge temperature gets increased while the freezer temperature decreased.
ØIt is recommended to adjust the airregulating rod in the middle position. When the user needs a
lower freezer temperature, adjust the airregulating rod to the left properly,then the freezer
temperature decreases while the fridge temperature rises. When the temperature meets the
requirement, adjust the air regulating rod backto the middle position again in atimelymanner.
The fridge thermostat andthe air regulatingrod shouldbeusedincombination.
ØWhen the ambient temperature around the refrigerator is higher than 35 ℃, do not set the
thermostat at Mode 1 and adjust the air regulating rod to the leftmost position, so as not to affect the
normal refrigeration of the refrigerator.
ØDo not set the thermostat at Mode 1 and adjust the air regulating rod to the rightmost position, in
order to avoid the fridge compartment undercooling.
ØIf the fridge temperature is not cool or undercooled, set the thermostat at the middle mode and
adjust the air regulating rod in the middle position.
ØIn case the ‘Fastcool’function is enabled, adjust the air regulating rod to the middle position.
1.2 Fast Cool
Cooling down the temperature in a rapid manner is beneficial to the prevention of food nutrition against lost and the
preservation of freshness.
After a cumulative running period of17 hours, the fast cooling function will exit automatically.
1.3 Power cut memory
In case of power failure, the refrigerator will maintain the operating state before power failure when power supply is
restored.
1.4 Power-on delay
In order to protect the refrigerator compressor from being damaged in the case of short-time power failure (i.e., less
than 5 minutes), the compressor will not be started immediately after it is powered on.
1.5 Fault alarm
When the indicator light of Fast Cool or Mode 4 keeps flashing, it indicates fault with the refrigerator. Please contact the
aftersales person for visiting service in such case.
Temperature adjustment
Use
environment
Recommended mode setting
on the display panel
Recommended air regulating
rod position
Notes
Higher
than 35℃
1) It is recommended to
set at the middle mode.
2) The temperature
modes can be adjusted
as recommended in the
left table in case of
change to the ambient
temperature around the
refrigerator
16℃-35℃
Lower than
16℃

V. Instructions for food storage
Precautions for use
lThe appliance might not operate consistently (there is possibility of defrosting or temperature becoming too warm in
the frozen food compartment) when sited for an extended period of time below the cold limit of the temperature range
for which the refrigerating appliance is designed
lThe information of climate type of the appliance is provided on the rating plate.
lThe internal temperature could be affected by such factors as the location of refrigerating appliance, ambient
temperature, and frequency of door open, etc., and if appropriate, a warning that setting of any temperature control
device might have to be varied to allow for these factors should be made.
lEffervescent drinks should not be stored in the freezer compartment or the low-temperature compartment, and some
products such as water ices should not be consumed too cold.
Food storage location
Due to the cold air circulation in the refrigerator, the temperature of each area in the refrigerator is different, so different
kinds of food should be placed in different areas.
The fresh food compartment is suitable for the storage of such foods as need not to be frozen, the cooked food, beer,
eggs, some condiments that need cold preservation, milk, fruit juice, etc. The crisper box is suitable for the preservation of
vegetables, fruits, etc.
The freezer compartment is suitable for the storage of ice cream, frozen food and the foods to be preserved for a long
time.
Use of the fresh food compartment
Fridge shelf: When removing the shelf, lift it up first, and then pull it out; and when installing the shelf, place it into position
before putting it down. Keep the shelf rear flange upward, to prevent foods from contact the liner wall. When taking out or
putting in the shelf, hold it firmly, and handle with care to avoid damage.
Crisper box: Pull out the crisper box for access to food. After using or cleaning the cover plate of the crisper box, be sure
to put it back onto the crisper, so that the internal temperature of the crisper box will not be affected.
How to use the ice-making box
Place the ice-making box in the upper position of the freezer compartment, so that it ices up as soon as possible.
Cautions forfood storage
You’dbetter cleanthefoodsand wipe themdry before storingtheminside therefrigerator. Before foodsare put in the
refrigerator, it isadvisable to seal themup, soastoprevent water evaporationto keep freshfruitsand vegetables on one
hand, and prevent taint of odorontheother hand.
Do notput too manyor tooweightfoodsinsidethe refrigerator. Keep enoughspacebetween foods; if tooclose, the cold
air flowwill beblocked,thusaffectingtherefrigerationeffect. Do not store excessiveoroverweight foods,to avoidthe
shelf frombeing crushed. When storingthefoods, keep adistanceawayfromtheinner wall; and do not placethe
water-rich foodstoocloseto thefridge rear wall, lest theyget frozen ontheinner wall.
Categorizedstorage of foods Foodsshould bestored bycategory, with thefoodsyou eat every dayplaced in front of the
shelf, sothat thedoor open durationcanbeshortened and food spoilage dueto expiration can beavoid.
Energy-savingtips: Allowthehot foodcool downto theroomtemperaturebeforeputting it in the refrigerator. Put the
frozen foodin thefreshfood compartment tothaw, using the lowtemperatureof thefrozen foodto cool the freshfood,
thussavingenergy.
Storage of fruitsandvegetables
In thecaseof refrigeratingapplianceswith chill compartment, astatementto theeffectthatsometypesof fresh
vegetablesandfruits are sensitiveto coldand therefore are not suitablefor storage in thiskind ofcompartment shouldbe
made.
Useof thefrozenfood storage compartment
The freezer temperatureis controlled below-18 ℃, and it is advisable to store thefood forlong-term preservation inthe
freezer compartment, but the storage durationindicatedonthefoodpackagingshould beadheredto.
The freezer drawers areused to store food that needsto befrozen. Fishand meatof large blocksizeshould becut into
small piecesand packedinto fresh-keepingbagsbefore theyare evenlydistributedinsidethe freezer drawers.
Fast freezing
(1) Refer tothe descriptionaboutfast freezingfunction inthe Function”section.
(2) Compared withthe normal freezing,fastfreezing enablesfood topassthroughthemaximumicecrystal formation
zone atthefastestspeed. Fastfreezing canfreezethe food watercontentintofine icecrystals,withoutdamaging the
cellmembrane,socell juicewill notbelostwhen thawing,and the originalfreshnessandnutritionoffoodcan be
maintained.
(3)The fast-freezingfunction isdesignedtopreservenutrition ofthe frozen food,withthe foodthoroughlyfrozen inthe
shortesttime. Fast freezingconsumesmoreenergythanthenormalfreezing does.
★Allowthe hot foodstocool downtothe roomtemperaturebeforeputtingtheminthefreezer compartment.
★Donotputaglasscontainerwithliquidorthecanned liquid thatissealed inthefreezercompartment, soastoavoid
burstdue tovolumeexpansionafter the liquid getsfrozen up.
★Divide the food intoappropriatelysmall portions
★You’dbetterpackthe foodup beforefreezingit,andthepacking bag used should be dry,in casethe packingbagsare
frozen together. Foodsshould be packed orcovered bysuchsuitable materialsasarefirm,tasteless,impervioustoair

and water, non-toxic andpollution-free, toavoid cross-contaminationandtransferof odor.
Tips forshopping thefrozenfoods
1.Whenyou arebuying frozenfood,lookat theStorage Guidelinesonthepackaging. You will be able tostoreeachitem
of frozenfoodfortheperiodshownagainstthe starrating.Thisisusuallytheperiodstatedas Besttousethembefore×”,
found on the front of thepackaging.
2. Check the temperatureofthefrozen food cabinetin the shop whereyou buythe frozenfoods.
3.Makesurethe frozen food package is in perfect condition.
4. Alwaysbuyfrozen productslaston yourshopping trip orvisit tothesupermarket.
5.Trytokeepfrozen food together whilstshopping and on thejourneyhome,asthiswill helptokeepthe foodcooler.
6. Don’t buyfrozenfoodunlessyou can freezeitstraight away. Special insulated bagscan be boughtfrommost
supermarketsandhardwareshops. Thesekeepthefrozen foodscold longer.
7.Forsomefoods,thawing beforecooking is unnecessary.Vegetablesandpastacan be added directlytoboiling wateror
steamcooked.Frozen saucesand soupscan be put intoasaucepan and heatedgentlyuntilthawed.
8. Usequalityfoodandhandle it aslittleaspossible.Whenfoodsarefrozen insmallquantities,it will takeless thanfor
themtofreezeup and thaw.
9. Estimatetheamount offoodstobe frozenup.Whenfreezing large amountsof freshfood, adjust the temperature
control knobtothe lowmode,withthe freezertemperaturelowered. So, foodscanbe frozen up in fastmanner, withthe
food freshnesswell kept.
VI.Tipsfor specialneeds
Moving the refrigerator/freezer
•Location
Donotplaceyourrefrigerator/freezernearaheatsource,e.g.cooker,boilerorradiator.Avoid itfromdirectsunlightin
out-buildingsorsunlounges.
•Leveling
Makesuretolevelyourrefrigerator/freezerusing thefrontlevelingfeet. Ifnotlevel,therefrigerator/freezerdoorgasket
sealing performancewill be affected, oreven itmaylead tothe operating failureofyour refrigerator/freezer.
After locating the refrigerator/freezer in position, wait for4hoursbeforeusing it, soastoallowthe refrigeranttosettle.
Installation
Donotcover orblock the ventsor grillesof yourappliance.
Whenyou areout for alongtime
•If the appliancewill notbe used for several months,turnitoff first,andthenunplugtheplug fromthewall outlet.
•Takeoutallfoods.
•Clean anddrythe interiorthoroughly.Topreventodorandmold growth,leavethedoorajar: blockitopenorhavethe
door removed if necessary.
•Keep the cleaned appliancein adry,ventilatedplaceandawayfromthe heatsource,placethe appliancesmoothly,and
do notplaceheavy objectsontop ofit.
•The unitshouldnot be accessibletochild’splay.
VII. Maintenance and cleaning
Beforecleaning,unplug the powerplug first; Donotpluginorplugoutthe plug withwethand,becausethereis a
risk ofelectricshockandinjury. Donotspill waterdirectly on the refrigerator,toavoidrust, electricityleakageand
accidents.Donotstretchyourhandsintothebottomoftherefrigerator,sinceyou mightbe scratchedbysharpmetal
corners.
Internalcleaning and external cleaning
The food residualsinthe refrigeratorareliable toproducebad odor,sothe refrigeratormustbe cleanedregularly.The
freshfoodcompartment isusuallycleaned onceamonth.
Removeall shelves,crisperbox,bottle racks,coverboard,and drawersetc., andcleanthemwithasofttowel orsponge
dippedinwarmwater or neutral detergent.
Clear off thedustsaccumulatedon the rear panelandside platesof therefrigeratoroften.
After usingdetergent, besuretorinseit withclean water,andthenwipe it dry.
Donot usebristle brush, steelwirebrush, detergent, soappowder, alkaline detergent, benzene, gasoline,acid,hot
waterand othercorrosiveorsoluble itemstocleansethecabinetsurface,doorgasket, plasticdecorativeparts,etc., soas
toavoid damage.
Carefullywipe drythedoorgasket, cleanthegrooveusingawoodenchopstickwrappedwithcottonstring.Afterthe
cleaning, fixthe four cornersof the doorgasketfirst, andthenembed it segmentbysegment intothedoor groove.
Interruptionofpower supplyorfailureoftherefrigerating system
•Takecareof the frozen foodsin theevent ofan extended non-running of the refrigerating appliance(suchasinterruption
of power supplyor failureof therefrigerating system).
•Trytoopen the refrigeratordooraslessaspossible,in thiswaycan food safelyandfreshlykeptforhourseven in hot
summer.

•If you getthepower outage noticeinadvance
1) Adjustthethermostatknob tothehigh mode an hourinadvance,sothatfoodsgetfullyfrozen (Donotstorenew
food duringthis time!). Restorethe temperaturemode totheoriginal setting when powersupplybecomesnormal ina
timelymanner.
2)You can alsomakeicewitha watertightcontainer,andput it in the upperpart of thefreezer,soastoextend thetime
for freshfood tobestored.
Note:Oncethe refrigeratorisused,you’dbetteruseitcontinuously;and undernormalcircumstance,donotstop its
use, soasnot toaffect theservice life.
Defrosting
Thisapplianceisdesigned withautomatic defrosting function, thusnoneedto defrost it manually.
Changingthe lamp
The LED lampisused bythe refrigerator for lighting, which features lowenergy consumptionand long servicelife. In case
of anyabnormality, pleasecontact theafter-sales service provider.The lampscanonlybe replaced bythe manufacturer,
together with a part of theappliance.
Lamptype LED light.
Energyefficiencylevel F
Safety-check aftermaintenance
Is thepower cordbrokenor damaged?
Is thepower plugfirmlyinsertedintothesocket?
Is thepower plugabnormallyoverheat?
Note: Electricshockandfireaccident maybecaused in casethepower cord and plug is damaged or stained by
dust. If anyabnormality, pleaseunplug thepower plug andget incontact with thevendor.
Howto disassemble theparts.
Fridgedoorbottle rack:
Hold thebottlerackwith bothhands, and then pushit up.
Fridgeshelf:
Hold oneendofthe shelf, and lift it upwhile pulling it outwards.
VIII. Simplefaultanalysisandelimination
Withregardtothe following small faults,noteveryfailureneedstobefixed bythe technicalservicepersonnel;you can try
tosolvetheproblem.
Case Inspection Solutions
●Completely
non-refrigeration •Ispower plug off?
•Arebreakersandfusesabroken?
•Noelectricityorlinetrip?
•Re-plug.
•Opening the doorand checking whetherthe
lampislit.
•Abnormal noise•Isrefrigeratorstable?
•Doesrefrigerator reachthewall?•Adjustingrefrigerator'sadjustable feet. •Off the wall.。
•Poor
refrigerating
efficiency
•Doyou puthot food or toomuchfood?
•Doyou openthedoor frequently?
•Doyou clip food bag totheseal ofdoor?
•Directsunlightor nearafurnaceorstove?
•Isit well-ventilated?
•Temperaturesetting in toohigh?
•Puttingfoodintorefrigeratorwhen hotfood
becomescool.
•Checking and closing the door.
•Removingtherefrigeratorfromtheheat
source.
•Emptyingthedistancetomaintaingood
ventilation.
•Settingtothe appropriatetemperature.
•Peculiarsmell in
refrigerator•Anyspoiled food?
•Doyou needtoclean refrigerator?
•Doyou pack food ofstrongflavors?
•Throwing awayspoiled food.
•Cleaning refrigerator.
•Packing food ofstrongflavors.
•LED lamp
alwaysflashing•Isthe dooropen formorethan 10 minutes?•Close the fridge door,openitagainin 2s, checking whetherthe LED lamprestorestonormal.
Note:If the abovedescriptionsareinapplicable totroubleshooting,do notdisassemble andrepairityourself. Repairs
carriedoutbyinexperiencedpersonsmaycauseinjuryorseriousmalfunctioning.Contactthelocalstorewhereyour
purchasewasmade.Thisproduct should be serviced byan authorized engineerand onlygenuine sparepartsshould be
used.

Whentheapplianceisnotin useforlongperiods,disconnectfromtheelectricitysupply,emptyallfoodsandclean the
appliance,leavingthedoorajar toprevent unpleasant smells.
IX.Certifications
Electricalinformation
Thiselectricalappliancemustbe grounded.
Thisproductisequipped withaplug,whichissuitableforallhousesequippedwithsocketsmeetingthecurrent
specifications
If the fittedplug is notsuitable foryoursocketoutlets,itshould becutoffand carefullydisposedof.Toavoid apossible
shock hazard, donot insertthediscarded plugintoasocket.
ThisproductcompliestheEEC directives.
X.Safe recoveryinstructions
Disposal
Old appliancesstillhavesome surplusvalue.An environmentallyfriendlyapproachwill ensurethatvaluablerawmaterials
arerecycled.
The refrigerantsused in your equipment andinsulationmaterialsrequirespecialhandlingprocedures.Makesurethereis
no pipe damage onthebackof the equipment beforehandling.
Up-to-dateinformation ontheoptionsfordisposingofold equipmentandpackagingfromold equipmentcan be obtained
fromthe localmunicipal office.
Correct Disposalofthisproduct
Thismarkingindicatesthatthisproductshouldnotbedisposedwithotherhouseholdwastes
throughouttheEU. Topreventpossible harmtotheenvironmentorhumanhealthfrom
uncontrolled wastedisposal, recycleit responsiblytopromotethe sustainable reuseof material
resources.Toreturnyourused device,pleaseusethereturnandcollection systemsorcontact
the retailerwheretheproductwaspurchased.Theycan takethisproductforenvironmentally
saferecycling.
Warnings for disposal
※Refrigerant and cyclopentane foaming material used for the refrigerator are
flammable. Therefore, when the refrigerator is scrapped, it shall be kept away
from any fire source and be recovered by a special recovering company with
corresponding qualification other than be disposed by combustion, so as to
prevent damage to the environment or any other harm.
※When the refrigerator is scrapped, disassemble the doors, and remove gasket
of door and shelves; put the doors and shelves in a proper place, so as to
prevent trapping of any child.
* Instructions on how to find in the model information in the product database, as definded in
regulation () 2019/2019 by means of a weblink that links to the model information as stored in the
product database or a link to the product database and information on how to find the model
identifier on the product.
※Refrigerantandcyclopentane foamingmaterialusedforthe refrigeratorare
flammable.Therefore,whenthe refrigeratoris scrapped,itshallbe keptaway
fromanyfiresource andbe recoveredbyaspecialrecoveringcompanywith
correspondingqualificationotherthanbe disposedbycombustion,soas to
prevent damage tothe environment oranyotherharm.
※Whenthe refrigeratoris scrapped,disassemble the doors,andremove gasket
ofdoorandshelves;putthe doors andshelves ina properplace,soas to
prevent trappingof anychild.







 

  

 



  


 


  

  


 

n

=1-
J


 
 
 

  



Guarantee
We, Teknix, undertake that if within 24 months of the date of purchase this appliance or any part thereof is proven to be defective by reason of mechanical
or electrical failure we will at our discretion repair or replace the same free of any charge for labour, materials or carriage on condition that:
• The appliance has been correctly installed in accordance to manufacturers’ instructions.
•The appliance has been used for normal domestic purposes only and in accordance with our operating instructions.
• The appliance has not been repaired, taken apart or tampered with by any person not authorised by us.
• All repair work under this guarantee must be undertaken by the organisation or its authorised agents
• Proof of purchase is available on request
• If we decide your appliance cannot be repaired, or is uneconomical to repair, we'll replace it with the same model. If that model is no longer
available, we'll discuss an alternative settlement with you.
• We reserve the right to charge for the expense of a service call if no fault has been found with the appliance after we have inspected it.
• All claims must be arranged via a call to us on 01759 487893. Without pre-authorisation it may result in the cost of claim not being reimbursed.
This guarantee is in addition to your statutory and other legal rights
Exclusions
- Damage resulting from transportation, improper use, or neglect.
- Appliance outside the United Kingdom.
- Consumer replaceable items including, but not limited to, batteries, light bulbs and other consumables.
- Cosmetic damage and/or non-functional parts, which do not affect the normal use of the product including for example cabinet, scratches and rust.
- Any loss suffered as a result of not being able to use the appliance or any loss other than the repair or the replacement cost of the product.
- Accidental or physical damage
