P6700 Series
Serial Analyzer Probes
ZZZ
Instruction Manual
*P077011502*
077-0115-02

P6700 Series
Serial Analyzer Probes
ZZZ
Instruction Manual
xx
Revision A
www.tektronix.com
077-0115-02

Copyright © Tektronix. All rights reserved. Licensed software products are owned by Tektronix or its subsidiaries
or suppliers, and are protected by national copyright laws and international treaty provisions.
Tektronix products are covered by U.S. and foreign patents, issued and pending. Information in this publication
supersedes that in all previously published material. Specifications and price change privileges reserved.
TEKTRONIX and TEK are registered trademarks of Tektronix, Inc.
RT-Eye is a registered trademark of Tektronix, Inc.
PCI Express is a registered trademark of PCI-SIG®.
G3PO is a trademark of Corning Gilbert Inc.
Contacting Tektronix
Tektronix, Inc.
14150 SW Karl Braun Drive
P.O. Box 500
Beaverton, OR 97077
USA
For product information, sales, service, and technical support:
In North America, call 1-800-833-9200.
Worldwide, visit www.tektronix.com to find contacts in your area.

Warranty
Tektronix warrants that this product will be free from defects in materials and workmanship for a period of one (1)
year from the date of shipment. If any such product proves defective during this warranty period, Tektronix, at its
option, either will repair the defective product without charge for parts and labor, or will provide a replacement
in exchange for the defective product. Parts, modules and replacement products used by Tektronix for warranty
work may be new or reconditioned to like new performance. All replaced parts, modules and products become
the property of Tektronix.
In order to obtain service under this warranty, Customer must notify Tektronix of the defect before the expiration of
the warranty period and make suitable arrangements for the performance of service. Customer shall be responsible
for packaging and shipping the defective product to the service center designated by Tektronix, with shipping
charges prepaid. Tektronix shall pay for the return of the product to Customer if the shipment is to a location within
the country in which the Tektronix service center is located. Customer shall be responsible for paying all shipping
charges, duties, taxes, and any other charges for products returned to any other locations.
This warranty shall not apply to any defect, failure or damage caused by improper use or improper or inadequate
maintenance and care. Tektronix shall not be obligated to furnish service under this warranty a) to repair damage
resulting from attempts by personnel other than Tektronix representatives to install, repair or service the product;
b) to repair damage resulting from improper use or connection to incompatible equipment; c) to repair any damage
or malfunction caused by the use of non-Tektronix supplies; or d) to service a product that has been modified or
integrated with other products when the effect of such modification or integration increases the time or difficulty
of servicing the product.
THIS WARRANTY IS GIVEN BY TEKTRONIX WITH RESPECT TO THE PRODUCT IN LIEU OF ANY
OTHER WARRANTIES, EXPRESS OR IMPLIED. TEKTRONIX AND ITS VENDORS DISCLAIM ANY
IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.
TEKTRONIX' RESPONSIBILITY TO REPAIR OR REPLACE DEFECTIVE PRODUCTS IS THE SOLE
AND EXCLUSIVE REMEDY PROVIDED TO THE CUSTOMER FOR BREACH OF THIS WARRANTY.
TEKTRONIX AND ITS VENDORS WILL NOT BE LIABLE FOR ANY INDIRECT, SPECIAL, INCIDENTAL,
OR CONSEQUENTIAL DAMAGES IRRESPECTIVE OF WHETHER TEKTRONIX OR THE VENDOR HAS
ADVANCE NOTICE OF THE POSSIBILITY OF SUCH DAMAGES.
[W2 – 15AUG04]

Table of Contents
General Safety Summary .......................................................................................... v
Service Safety Summary......................................................................................... vii
Environmental Considerations .................................................................................. viii
Preface.............................................................................................................. ix
Related Documentation ...................................................................................... ix
List of Terms ................................................................................................... x
Getting Started ............................................. .............. .............. ............................. 1
Product Description............................................................................................ 1
Serial Analyzer Configurations............................................................................... 4
Operating Basics.................................................................................................... 5
Preparing for Installation of the Midbus Retention Mechanism.......................................... 5
Installing the Midbus Retention Mechanism ............ ................................................... 5
Connecting the Midbus Probe................................................................................ 7
Arranging the Midbus Probe Cables......................................................................... 9
Connecting a Slot Interposer Probe......................................................................... 10
Connecting the Solder-Down Probe ........................................................................ 14
Reference........................................................................................................... 19
Probe Dimensions ............................................................................................ 19
Circuit Board Design......................................................................................... 23
Midbus Footprint Pin and Probe Channel Assignments.................................................. 41
Rearranging Wires in the Probe Connector................................................................ 58
Adding Probes to the P6701SD Probe Connector......................................................... 61
Specifications ...................................................................................................... 63
Environmental................................................................................................. 63
Maintenance........................................................................................................ 65
Inspection and Cleaning...................................................................................... 69
Storing the Probe.............................................................................................. 69
Repackaging Instructions .................................................................................... 69
Appendix A: PCI Express System Design Review Checklist ................................................ 71
General Considerations ...................................................................................... 71
Midbus Probe Configuration ................................................................................ 71
Mechanical Considerations.................................................................................. 71
Electrical Considerations .................................................................................... 73
Appendix B: File Attachments................................................................................... 75
Index
P6700 Series Serial Analyzer Probes Instruction Manual i

Table of Contents
List of Figures
Figure 1: P6716 16-Channel Midbus probe ..................................................................... 1
Figure 2: P6708S Slot interposer probe.......................................................................... 2
Figure 3: P6701SD Solder-Down probe ......................................................................... 3
Figure 4: 16-Channel footprint.................................................................................... 5
Figure 5: Installing the retention mechanism............................. ....................................... 6
Figure 6: Soldering the anchoring posts to the PCB............................................................ 6
Figure 7: Connecting a probe to the retention mechanism..................................................... 8
Figure 8: Arranging the midbus probe cables................................................................... 9
Figure 9: Connecting a slot interposer probe................................................................... 11
Figure 10: Installing the P6701SD probe ..................................... ................ .................. 14
Figure 11: Connecting the P75TLRST tip to the probe head................................................. 15
Figure 12: Connecting wires to the circuit...................................................................... 16
Figure 13: Connecting the tip to the circuit..................................................................... 17
Figure 14: P6716S dimensions................................................................................... 19
Figure 15: P6716 cable length dimensions ..................................................................... 20
Figure 16: P6716S cable length dimensions.................................................................... 20
Figure 17: P6701S, P6704S, and P6708S dimensions ........................................................ 21
Figure 18: P6701SD dimensions ................................................................................ 22
Figure 19: P75TLRST Solder Tip dimensions................................................................. 22
Figure 20: 8-Channel midbus footprint dimensions and keep-out area ..................................... 24
Figure 21: 16-Channel midbus footprint dimensions and keep-out area.................................... 25
Figure 22: Recommended trace routing on primary surface layer........................................... 26
Figure 23: Via and trace keep-out areas for the P6708 8-Channel probe ................................... 27
Figure 24: Via and trace keep-out areas for the P6716 16-Channel probe.................................. 27
Figure 25: Recommended trace routing on inner or secondary surface layer (primary layer pads
shown) ......................................................................................................... 27
Figure 26: Recommended trace routing on inner or secondary surface layer (primary layer pads not
shown) ......................................................................................................... 28
Figure 27: Clock cable connector dimensions ................................................................. 29
Figure 28: P75TLRST TriMode Long Reach Solder Tip..................................................... 30
Figure 29: Typical wire length from probe tip to circuit...................................................... 31
Figure 30: P75TLRST solder tip with 0.010 inch of tip wire ................................................ 32
Figure 31: P75TLRST solder tip with 0.050 inch of tip wire ................................................ 32
Figure 32: P75TLRST solder tip with 0.100 inch of tip wire ................................................ 33
Figure 33: P75TLRST solder tip with 0.200 inch of tip wire ................................................ 33
Figure 34: P75TLRST TriMode Long Reach Solder Tip dimensions....................................... 34
Figure 35: Signal eye measurements (time versus voltage) .................................................. 34
Figure 36: Periodic jitter gain function ................................... ...................................... 36
ii P6700 Series Serial Analyzer Probes Instruction Manual

Table of Contents
Figure 37: S-parameter data of retention mechanism only ................................................... 37
Figure 38: S-parameter data of retention mechanism plus P6700 Series midbus probe................... 37
Figure 39: S-parameter data of P6701SD Solder-Down probe............................................... 38
Figure 40: Slot Interposer probe with a clock cable connected .............................................. 39
Figure 41: P6708 8-Channel probe footprint pin assignments ............................................... 41
Figure 42: P6716 16-Channel probe footprint pin assignments.............................................. 41
Figure 43: 8-Channel midbus footprint connection module connector...................................... 41
Figure 44: 16-Channel midbus footprint connection module connector .................................... 42
Figure 45: Opening the probe connector........................................................................ 59
Figure 46: Removing the probe sleeve.......................................................................... 59
Figure 47: Probe labels ........................................................................................... 60
Figure 48: Removing individual wires.......................................................................... 60
Figure 49: Inserting additional probe wires .................................... ............ .................... 61
Figure 50: Replaceable bullets and tool......................................................................... 65
Figure 51: Removing the bullet contacts ....................................................................... 66
Figure 52: Inspect the bullet contacts ........................................................................... 67
Figure 53: Installing the bullet contacts..................... .......................... .......................... 68
P6700 Series Serial Analyzer Probes Instruction Manual iii

Table of Contents
List of Tables
Table i: Terms used in this document ............................................................................ x
Table 1: Serial analyzer configuration............................................................................ 4
Table 2: Recommended circuit board design criteria.......................................................... 23
Table 3: Via and trace characteristics ........................................................................... 26
Table 4: Clock cable three-pin connector pin assignments ................................................... 29
Table 5: Probe Eye Requirements ............................................................................... 35
Table 6: Reference clock electrical requirements.............................................................. 39
Table 7: X16 unidirectional link................................................................................. 44
Table 8: X8 bidirectional link.................................................................................... 45
Table 9: X8 (2) unidirectional links ............................................................................. 46
Table 10: X4 bidirectional link .................................................................................. 47
Table 11: X4 (2) unidirectional links............................................................................ 48
Table 12: X2 bidirectional link .................................................................................. 49
Table 13: X2 (2) unidirectional links............................................................................ 50
Table 14: X1 bidirectional link .................................................................................. 51
Table 15: X1 (2) unidirectional links............................................................................ 52
Table 16: X8 unidirectional link................................................................................. 53
Table 17: X4 bidirectional link .................................................................................. 53
Table 18: X4 (2) unidirectional links............................................................................ 54
Table 19: X4 unidirectional link and a X2 unidirectional link ............................................... 54
Table 20: X4 unidirectional link and a X1 unidirectional link ............................................... 55
Table 21: X2 bidirectional link .................................................................................. 55
Table 22: X2 (2) unidirectional links............................................................................ 56
Table 23: X1 bidirectional link .................................................................................. 56
Table 24: X1 (2) unidirectional links............................................................................ 57
Table 25: Atmospheric characteristics .......................................................................... 63
Table 26: Midbus Probe Configuration ......................................................................... 71
Table 27: Midbus Probe .......................................................................................... 71
Table 28: Slot Interposer Probe.................................................................................. 72
Table 29: Reference Clock Connector .......................................................................... 72
Table 30: Midbus Probe .......................................................................................... 73
Table 31: Slot Interposer Probe.................................................................................. 73
Table 32: Reference Clock Connector .......................................................................... 74
Table 33: Serial analyzer probes and related simulation models............................................. 75
iv P6700 Series Serial Analyzer Probes Instruction Manual

General Safety Summary
General SafetySummary
Review the following safety precautions to avoid injury and prevent damage to
this product or any products connected to it.
To avoid potential hazards, use this product only as specified.
Only qualified personnel should perform service procedures.
While using this product, you may need to access other parts of a larger system.
Read the safety sections of the other component manuals for warnings and
cautions related to operating the system.
To Avoid Fire or Personal
Injury
Connect and disconnect properly. Connect the probe output to the measurement
instrument before connecting the probe to the circuit under test. Connect the
probe reference lead to the circuit under test before connecting the probe input.
Disconnect the probe input and the probe reference lead from the circuit under test
before disconnecting the probe from the measurement instrument.
Ground the product. This product is indirectly grounded through the grounding
conductor of the mainframe power cord. To avoid electric shock, the grounding
conductor must be connected to earth ground. Before making connections to
the input or output terminals of the product, ensure that the product is properly
grounded.
Observe all terminal ratings. To avoid fire or shock hazard, observe all ratings
and markings on the product. Consult the product manual for further ratings
information before making connections to the product.
The inputs are not rated for connection to mains or Category II, III, or IV circuits.
Do not apply a potential to any terminal, including the common terminal, that
exceeds the maximum rating of that terminal.
Power disconnect. The power cord disconnects the product from the power source.
Do not block the power cord; it must remain accessible to the user at all times.
Do not operate without covers. Do not operate this product with covers or panels
removed.
Do not operate with suspected failures. If you suspect that there is damage to this
product, have it inspected by qualified service personnel.
Avoid exposed circuitry. Do not touch exposed connections and components when
power is present.
P6700 Series Serial Analyzer Probes Instruction Manual v

General Safety Summary
Do not operate in wet/damp conditions.
Do not operate in an explosive atmosphere.
Keep product surfaces clean and dry.
Provide proper ventilation. Refer to the manual's installation instructions for details
on installing the product so it has proper ventilation.
TermsinThisManual These terms may appear in this manual:
WARNING. Warning statements identify conditions or practices that could result
in injury or loss of life.
CAUTION.Caution statements identify conditions or practices that could result in
damage to this product or other property.
Symbols and Terms on the
Product
These terms may appear on the product:
DANGER indicates an injury hazard immediately accessible as you read
the marking.
WARNING indicates an injury hazard not immediately accessible as you
read the marking.
CAUTION indicates a hazard to property including the product.
The following symbol(s) may appear on the product:
vi P6700 Series Serial Analyzer Probes Instruction Manual

Service Safety Summary
Service Safety Summary
Only qualified personnel should perform service procedures. Read this Service
Safety Summary and the General Safety Summary before performing any service
procedures.
Do Not Service Alone. Do not perform internal service or adjustments of this
product unless another person capable of rendering first aid and resuscitation is
present.
Disconnect Power. To avoid electric shock, switch off the instrument power, then
disconnect the power cord from the mains power.
UseCareWhenServicingWithPowerOn. Dangerousvoltagesorcurrentsmay
exist in this product. Disconnect power, remove battery (if applicable), and
disconnect test leads before removing protective panels, soldering, or replacing
components.
To avoid electric shock, do not touch exposed connections.
P6700 Series Serial Analyzer Probes Instruction Manual vii

Environmental Considerations
Environmental Considerations
This section provides information about the environmental impact of the product.
Product End-of-Life
Handling
Observe the following guidelines when recycling an instrument or component:
Equipment Recycling. Production of this equipment required the extraction and
use of natural resources. The equipment may contain substances that could be
harmful to the environment or human health if improperly handled at the product’s
end of life. In order to avoid release of such substances into the environment and
to reduce the use of natural resources, we encourage you to recycle this product
in an appropriate system that will ensure that most of the materials are reused or
recycled appropriately.
This symbol indicates that this product complies with the European Union’s
requirements according to Directive 2002/96/EC on waste electrical and
electronic equipment (WEEE). For information about recycling options, check
the Support/Service section of the Tektronix Web site (www.tektronix.com).
Restriction of Hazardous
Substances
This product has been classified as Monitoring and Control equipment, and is
outside the scope of the 2002/95/EC RoHS Directive.
viii P6700 Series Serial Analyzer Probes Instruction Manual

Preface
Preface
This manual contains information needed to install and use a P6700 Series probe
with a TLA7S08 or TLA7S16 Serial Analyzer module to debug, validate, and
verify computer and embedded systems.
Related Documentation
The following table lists related documentation available for your instrument. The
documentation is available on the TLA Documentation CD and on the Tektronix
Web site (www.Tektronix.com/manuals).
For documentation not specified in the table, contact your local Tektronix
representative.
Related Documentation
Item Purpose Location
TLA Quick Start User Manuals High-level operational overview
OnlineHelp In-depth operation and UI help
Installation Quick Reference Cards High-level installation information
Installation Manuals Detailed first-time installation information
XYZs of Logic Analyzers Logic analyzer basics
Declassification and Securities
instructions
Data security concerns specificto
sanitizing or removing memory devices
from Tektronix products
Application notes Collection of logic analyzer application
specific notes
Product Specifications & Performance
Verification Procedures
TLA Product specifications and
performance verification procedures
TPI.NET Documentation Detailed information for controlling the
logic analyzer using .NET
P6700 Series Serial Analyzer Probes Instruction Manual ix

Preface
Related Documentation (cont.)
Item Purpose Location
Field upgrade kits Upgrade information for your logic
analyzer
Optional Service Manuals Self-service documentation for modules
and mainframes
List of Terms
The following is a list of terms that appear in this manual. You may want to
review this list if you are unfamiliar with some of the terms. For a list of PCI
Express®-specific terms, refer to the PCI Express Base Specification.
Table i: Terms used in this document
Term Description
Footprint An arrangement of pads built into the board as specified in the
PCI Express Base Specification. It is the contact point for the
retention mechanism.
Retention Mechanism The mechanism that connects the probe head to the PCB. It fits
on the footprint and must be soldered to the PCB.
Probe Head The end of the probe that connects to the retention mechanism.
Full-width 16-Channel
Half-width 8-Channel
Link A connection between two PCI Express devices. A link consists
of a number of lanes. A link described as by-N (or xN) consists
of a number (N) lanes.
Differential Pair A set of two signals, positive and negative, transmitting data
from one device to another.
Lane A single differential pair (two signals) that transmit data in one
direction of a PCI Express Link. A unidirectional lane.
PCB Printed circuit board
SUT System under test. This is the system/circuit board(s) you intend
to test with the serial analyzer.
x P6700 Series Serial Analyzer Probes Instruction Manual

Getting Started
Product Description
Tektronix offers three types of probes for the TLA7S08 and TLA7S16 Serial
Analyzer modules:
Midbus probes
Slot interposer probes
Solder-down probes
Midbus Probes A midbus probe connects to a retention mechanism installed on your circuit board.
You must install the retention mechanism to either a PCI Express Gen1 or Gen2
footprint on your circuit board.
Tektronix offers the following midbus probes:
P6708 8-Channel Midbus probe
P6716 16-Channel Midbus probe
Figure 1: P6716 16-Channel Midbus probe
P6700 Series Serial Analyzer Probes Instruction Manual 1

Getting Started
Slot Interposer Probes A slot interposer probe connects to a PCI Express slot on your SUT. Each probe
has a x16 connector for a PCI Express card device.
Tektronix offers the following (bidirectional) slot interposer probes:
P6701S PCI Express x1 Slot Interposer probe
P6704S PCI Express x4 Slot Interposer probe
P6708S PCI Express x8 Slot Interposer probe
P6716S PCI Express x16 Slot Interposer probe
Figure 2: P6708S Slot interposer probe
2 P6700 Series Serial Analyzer Probes Instruction Manual

Getting Started
P6701SD Solder-Down
Probe
The P6701SD probe connects to your SUT through the differential solder-down
tip (P75TLRST). Up to four probes (one differential pair each) can be installed in
each signal connector to the serial module. (See page 61, Adding Probes to the
P6701SD Probe Connector.)
Figure 3: P6701SD Solder-Down probe
P6700 Series Serial Analyzer Probes Instruction Manual 3
