Tektronix P5210 User manual

Instructions
P5210
High Voltage Differential Probe
070-9841-01
1of4
www.tektronix.com
*P070984101*
070984101

Copyright ©Tektronix, Inc. All rights reserved.
Tektronix products are covered by U.S. and foreign patents, issued and
pending. Information in this publication supercedes that in all previously
published material. Specifications and price change privileges reserved.
Tektronix, Inc., P.O. Box 500, Beaverton, OR 97077
TEKTRONIX, TEK, and TEKPROBE are registered trademarks of
Tektronix, Inc.

WARRANTY
Tektronix warrants that the products that it manufactures and sells will be free from defects
in materials and workmanship for a period of one (1) year from the date of purchase from
an authorized Tektronix distributor. If any such product proves defective during this
warranty period, Tektronix, at its option, either will repair the defective product without
charge for parts and labor, or will provide a replacement in exchange for the defective
product. Batteries are excluded from this warranty.
In order to obtain service under this warranty, Customer must notify Tektronix of the defect
before the expiration of the warranty period and make suitable arrangements for the
performance of service. Customer shall be responsible for packaging and shipping the
defective product to the service center designated by Tektronix, shipping charges prepaid,
and with a copy of customer proof of purchase. Tektronix shall pay for the return of the
product to Customer if the shipment is to a location within the country in which the
Tektronix service center is located. Customer shall be responsible for paying all shipping
charges, duties, taxes, and any other charges for products returned to any other locations.
This warranty shall not apply to any defect, failure or damage caused by improper use or
improper or inadequate maintenance and care. Tektronix shall not be obligated to furnish
service under this warranty a) to repair damage resulting from attempts by personnel other
than Tektronix representatives to install, repair or service the product; b) to repair damage
resulting from improper use or connection to incompatible equipment; c) to repair any
damage or malfunction caused by the use of non-Tektronix supplies; or d) to service a
product that has been modified or integrated with other products when the effect of such
modification or integration increases the time or difficulty of servicing the product.
THIS WARRANTY IS GIVEN BY TEKTRONIX WITH RESPECT TO THE
LISTED PRODUCTS IN LIEU OF ANY OTHER WARRANTIES, EXPRESS OR
IMPLIED. TEKTRONIX AND ITS VENDORS DISCLAIM ANY IMPLIED
WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR
PURPOSE. TEKTRONIX’ RESPONSIBILITY TO REPAIR OR REPLACE
DEFECTIVE PRODUCTS IS THE SOLE AND EXCLUSIVE REMEDY
PROVIDED TO THE CUSTOMER FOR BREACH OF THIS WARRANTY.
TEKTRONIX AND ITS VENDORS WILL NOT BE LIABLE FOR ANY
INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES
IRRESPECTIVE OF WHETHER TEKTRONIX OR THE VENDOR HAS
ADVANCE NOTICE OF THE POSSIBILITY OF SUCH DAMAGES.

P5210 Instructions i
Table of Contents
Contacting Tektronix ii...............................
General Safety Summary iii..........................
Getting Started 1....................................
Features and Accessories 1.............................
Installation 9........................................
Functional Check 10..................................
Operating Basics 11.................................
Operating the Probe Safely 11..........................
Minimizing Risk of RF Burn (probe leads) 11...........
Maximum Input Limits 12..........................
Operating Characteristics and Probing Techniques 14.......
Operating Limits 14...............................
Overrange Detection 14............................
Common-Mode Rejection 15........................
Twisting the Input Leads 16.........................
Probe Loading 16.................................
Cleaning 17.........................................
Specifications 19....................................
Warranted Characteristics 20...........................
Typical Characteristics 24.............................
Nominal Characteristics 28............................

ii P5210 Instructions
Contacting Tektronix
Phone [phone]*
Address Tektronix, Inc.
Department or name (if known)
14200 SW Karl Braun Drive
P.O. Box 500
Beaverton, OR 97077
USA
Web site www.tektronix.com
Sales support 1-800-833-9200, select option 1*
Service support 1-800-833-9200, select option 2*
Technical support Email: [e-mail]
1-800-833-9200, select option 3*
6:00 a.m. -- 5:00 p.m. Pacific time
*This phone number is toll free in North America. After office
hours, please leave a voice mail message.
Outside North America, contact a Tektronix sales office or
distributor; see the Tektronix web site for a list of offices.

P5210 Instructions iii
General Safety Summary
Review the following safety precautions to avoid injury and prevent
damage to this product or any products connected to it. To avoid
potential hazards, use this product only as specified.
Only qualified personnel should perform service procedures.
Observe Maximum Working Voltage
Do not use the P5210 High Voltage Differential Probe above
1,000 VRMS CAT II from ground on either input or ±1,300 V
(DC + peak AC) between the leads.
To Avoid Fire or Personal Injury
Avoid RF Burns While Handling Probe. To avoid RF burns, do not handle
the probe while the input leads are connected to circuits above the
voltage and frequency limits specified in Figure 2 on page 13. Use
only probe accessories that are rated for the application.
Connect and Disconnect Properly. Connect the probe output to the
measurement instrument before connecting the probe to the circuit
under test. Disconnect the probe input and the probe ground from the
circuit under test before disconnecting the probe from the measure-
ment instrument.

General Safety Summary
iv P5210 Instructions
Ground the Product. This product is indirectly grounded through the
grounding conductor of the mainframe power cord. To avoid electric
shock, the grounding conductor must be connected to earth ground.
Before making connections to the input or output terminals of the
product, ensure that the product is properly grounded.
Observe All Terminal Ratings. To avoid fire or shock hazard, observe all
ratings and markings on the product. Consult the product manual for
further ratings information before making connections to the product.
Use Proper AC Adapter. Use only the AC adapter specified for this
product.
Do Not Operate Without Covers. Do not operate this product with
covers or panels removed.
Avoid Exposed Circuitry. Do not touch exposed connections and
components when power is present.
Do Not Operate With Suspected Failures. If you suspect there is damage
to this product, have it inspected by qualified service personnel.
Do Not Operate in Wet/Damp Conditions.
Do Not Operate in an Explosive Atmosphere.
Keep Product Surfaces Clean and Dry.

General Safety Summary
P5210 Instructions v
Safety Terms and Symbols
Terms in This Manual. These terms may appear in this manual:
WARNING. Warning statements identify conditions or practices that
could result in injury or loss of life.
CAUTION. Caution statements identify conditions or practices that
could result in damage to this product or other property.
Terms on the Product. These terms may appear on the product:
DANGER indicates an injury hazard immediately accessible as you
read the marking.
WARNING indicates an injury hazard not immediately accessible as
you read the marking.
CAUTION indicates a hazard to property including the product.
Symbols on the Product. These symbols may appear on the product:
CAUTION
Refer to Manual
WARNING
High Voltage
Double
Insulated
Protective Ground
(Earth) Terminal

General Safety Summary
vi P5210 Instructions

P5210 Instructions 1
Getting Started
This section describes the P5210 High Voltage Differential Probe and
gives instructions on how to install and functionally test the probe.
Features and Accessories
The P5210 High Voltage Differential Probe shown in Figure 1
provides a safe means of measuring circuits with floating high
voltages. The probe outputs a low-voltage, ground-referenced signal
for display on instruments with the TEKPROBE interface (or any
oscilloscope or other measurement instrument when used with the
Tektronix 1103 TekProbe power supply).
The P5210 High Voltage Differential Probe probe allows clear and
accurate measurements of high-speed transitions and provides
excellent rejection of common-mode signals. Both inputs have high
impedance and low capacitance. Because of these features, the probe
can safely and accurately measure the fast voltage transients in
switching power devices without risk of damage.
Other applications for the P5210 High Voltage Differential Probe
include testing high-voltage motor control circuits and line
connected circuits in switch-mode power supplies.

Getting Started
2P5210 Instructions
The probe has a number of design features to protect you from high
voltage. This protection extends up to the full input rating of the
probe.
HThe probe head and input cables are double insulated.
HThe control buttons and probe housing are non conductive and
isolated.
HThe probe housing is internally shielded with a connection from
the shield to earth ground through the output cable.

Getting Started
P5210 Instructions 3
ON
Figure 1: P5210 High Voltage Differential Probe

Getting Started
4P5210 Instructions
WARNING. To avoid shock or burn hazard, use only the standard
accessories or accessories that are rated for the application. Use the
P5210 High Voltage Differential Probe accessories with this product
only.
Keep your fingers behind the finger guard on the probe body
whenever possible to reduce the risk of a shock from the circuit under
test.
Differential Inputs. The inputs are CAT II rated to a
maximum of 2,200 VRMS between either input and
earth ground. They are also rated for a maximum
difference of 4,400 VRMS CAT II between the inputs
with less than 5,600 V (DC + peak AC) between the
inputs.
Attenuation Range. In the raised position the range
button sets the attenuation to 1,000X. In the lowered
position the range button sets the attenuation to 100X.
Use the 1,000X position for measurements up to a
maximum of 4,400 VRMS CAT II. Use the 100X
position for better signal resolution on connections
below 440 VRMS CAT II.
Overrange Indicator. The overrange indicator lights red
if the voltage of the input signal exceeds the linear
operating range of the probe. When this happens, the
signal on the probe output does not accurately represent
the signal on the probe input.

Getting Started
P5210 Instructions 5
ON Overrange Beeper. In the raised position the overrange
button sets the overrange beeper to sound whenever the
overrange indicator lights.
Bandwidth Select. In the raised position the bandwidth
button sets the full bandwidth (50 MHz). In the
lowered position the bandwidth is restricted to
approximately 5 MHz.
Input Leads. The input leads of the differential probe
connect to the probe tips. The connectors are 4 mm
insulated banana plugs and are double insulated for
safety.
NOTE. Use only accessories that are rated to the
maximum input voltage under test.
TEKPROBE Interface. The TEKPROBE interface
provides power, signal, and probe characteristic data
transfer.
If your oscilloscope does not support the TEKPROBE
interface, you can use the optional 1103 probe power
supply as an effective interface. Contact your local
Tektronix representative for more information.

Getting Started
6P5210 Instructions
Zero Adjust. Use the zero adjust to set the probe output
to the zero reference point prior to making measure-
ments. Use the adjustment tool provided.
6-32 Probe Tip
Finger
Guard Probe Body. The probe body is designed for personal
safety, ergonomic comfort, and signal fidelity. The
body is rated for the maximum input voltage of the
P5210 High Voltage Differential Probe.
The probe tip is a 6--32 threaded post that accepts the
hook tips provided with the probe.
The finger guard provides protection when the hook
tips are not being used. Keep your fingers behind the
finger guard whenever possible to reduce the risk of a
shock from the circuit under test.
Use only accessories that are rated for the application.
Substitution of other accessories may create a shock or
burn hazard.
Keep the probe body and accessories clean to reduce
the risk of shock due to surface conduction. Refer to
page 17 for cleaning instructions.

Getting Started
P5210 Instructions 7
Small Hook Tip. Use the small hook tip for making con-
nections to small conductors such as component leads.
The hook tip is rated for the maximum input voltage of
the P5210 High Voltage Differential Probe.
Install the small hook tip by sliding it over the body of
the probe and screwing it onto the threaded probe tip.
To use the tip, hold the probe body and pull the tip
shield back. Hook the tip onto the circuit and release
the shield.
Large Hook Tip. Use the large hook tip when working
with larger components such as the bolt terminals and
bus bars typically found in power distribution equip-
ment. The hook tip is rated for the maximum input
voltage of the P5210 High Voltage Differential Probe.
Install the large hook tip by sliding it over the body of
the probe and screwing it onto the threaded probe tip.

Getting Started
8P5210 Instructions
To use the tip, hold the probe body and pull the tip shield
back. Hook the tip onto the circuit and release the shield.
Soft Case. The soft case protects the probe and allows
you to hang the probe near the point of measurement.
Install or remove the case by opening the access flaps
on the back.
When not in use, coil the leads and secure them with
the strap on the back. Use one of the loops to hang the
probe on a storage hook or utility belt.
Color Marker Bands. When you are using more than one
probe, the bands enable you to quickly distinguish
between probes and the channels they are connected to.
To use the marker bands, attach one band near the
probe head and the matching band near the compensa-
tion box.
For a complete list of replaceable accessories and part ordering
information, refer to the service manual that accompanies this
product.

Getting Started
P5210 Instructions 9
Installation
Install the P5210 High Voltage Differential Probe as follows:
1. Connect the output of the probe to the TEKPROBE input of the
oscilloscope or other measurement instrument. Make sure the
measurement instrument is properly grounded.
NOTE. Use the 1103 TEKPROBE Power supply if the instrument does
not have the TEKPROBE interface.
2. Select the proper range setting. For higher resolution and less
noise when measuring signals below 440 VRMS, switch the
attenuation to 100X. If the overrange indicator lights or flashes,
use the 1,000X setting or the output signal may not be accurate.
3. The probe output is adjusted to zero at the factory. Adjust the
probe output to zero only if you need to measure small differen-
tial voltages. Follow steps a through c to make the adjustment.
a. Let the probe warm up for at least 20 minutes.
b. Set the probe to the desired attenuation (100X or 1,000X).
c. Connect the input leads of the probe together. Insert the
adjustment tool in the access hole of the compensation
box and adjust the probe to the zero reference point.
If you are using this probe for the first time, read the General Safety
Summary on page iii, and Operating Basics on page 11 for important
safety information.

Getting Started
10 P5210 Instructions
Functional Check
To make a simple functional check of the P5210 High Voltage
Differential Probe, select a source that supplies AC line voltage and
use the following procedure. This procedure verifies a majority of
the circuitry within the probe. (For a complete performance
verification, refer to the service manual that accompanies this
product.)
1. Use the installation procedure starting on page 9 to connect the
output of the P5210 High Voltage Differential Probe to a
measurement instrument.
2. Connect the inputs, set the range, and perform the check as each
line of Table 1 indicates.
Table 1: Functional check
Mode
Range
setting
Input 1
(+ or –)
Input 2
(– or +) Check
Differential 100X or
1,000X
Hot Ground or
Neutral
Measurement instrument
displays or indicates the line
voltage
Common
Mode
100X or
1,000X
Hot (same
connection)
No signal
This completes the functional check procedure.
