Preface
This document helps customers with data security concerns to sanitize or remove
memory devices from the Tektronix TTR503A and TTR506A vector network
analyzers (VNAs) and the TCAL500 electrical calibration kits.
The VNAs have a data storage (memory) device. The instructions in this manual
describe how to clear or sanitize the memory device.
The VNA and the TCAL500 do not contain any media or export devices that
require declassification instructions.
Reference The procedure in this document is written to meet the requirements specifiedin:
NISPOM, DoD 5220.22–M, Chapter 8
ISFO Process Manual for Certification & Accreditation of Classified Systems
under NISPOM
Products The security instructions apply to these Tektronix products:
TTR503A
TTR506A
TCAL500-35F, TCAL500-35MF, TCAL500-35M
TCAL500-NF, TCAL500-NMF, TCAL500-NM
Required documents No external documents are required to perform the procedures in this document.
Terms used in this
document
Clear. This removes data on media/memory before reusing it in a secured
area. All reusable memory is cleared to deny access to previously stored
information by standard means of access.
Erase. This is equivalent to clear.
Instrument Declassification. A term that refers to procedures that must be
undertaken before an instrument can be removed from a secure environment.
Declassification procedures include memory sanitization and memory
removal, and sometimes both.
Media storage/data export device. Any of several devices that can be used
to store or export data from the instrument, such as a USB port.
Nonvolatile memory. Data is retained when the instrument is powered off.
Power off. Some instruments have a “Standby” mode, in which power is
still supplied to the instrument. For the purpose of clearing data, puttingthe
instrument in Standby mode does not qualify as powering off. For these
TTR500 Series and TCAL500 Declassification and Security Instructions iii

Preface
products, you will need to either press a rear-panel OFF switch or remove the
power source from the instrument.
Remove. This isaphysicalmeanstoclearthedatabyremovingthememory
device from the instrument. Instructions are available in the product Service
Manual.
Sanitize. This eradicates the data from media/memory so that the data cannot
be recovered by other means or technology. This is typically used when the
device will be moved (temporarily or permanently) from a secured area to a
non-secured area.
Scrub. This is equivalent to sanitize.
User Accessible. User is able to directly retrieve the memory device contents.
User-modifiable. The user can write to the memory device during normal
instrument operation, using the instrument interface or remote control.
User-modifiable. The user can write to the memory device during normal
instrument operation, using the instrument interface or remote control.
Volatile memory. Data is lost when the instrument is powered off.
Device terms User data. Describes the type of information stored in the device. Refers to
waveforms or other measurement data representing signals connected to the
instrument by users.
User settings. Describes the type of information stored in the device. Refers
to instrument settings that can be changed by the user.
Both. Describes the type of information stored in the device. It means that
both user data and user settings are stored in the device.
None. Describes the type of information stored in the device. It means that
neither user data nor user settings are stored in the device.
Directly. Describes how data is modified. It means that the user can modify
the data.
Indirectly. Describes how data is modified. It means that the instrument
system resources modify the data and that the user cannot modify the data.
iv TTR500 Series and TCAL500 Declassification and Security Instructions

Memory devices
Volatile memory devices
Table 1: TTR500 volatile memory devices
Type and
min. size Function
Type
of user
info
stored
Backed
up by
battery
Method
of
modification
Data
Input
method Location
User
accessible To clear To sanitize
SRAM 1MB Holds
active
acquisition
data
User
data
No Indirectly Written by
RFIC
RFIC No Disconnect
power for
at least 20
seconds.
Disconnect
power for
at least 20
seconds.
SRAM 128KB Holds
RFIC
firmware
User
settings
No Indirectly Written by
VectorVu-PC
application
RFIC No Disconnect
power for
at least 20
seconds.
Disconnect
power for
at least 20
seconds.
SRAM 32KB Not
applicable
Not
applicable
No Not
applicable
Not
applicable
RFIC No Disconnect
power for
at least 20
seconds.
Disconnect
power for
at least 20
seconds.
SRAM 128KB Not
applicable
Not
applicable
No Not
applicable
Not
applicable
RFIC No Disconnect
power for
at least 20
seconds.
Disconnect
power for
at least 20
seconds.
SRAM 512 KB Micro-controller
memory
User
data,
user
settings
No Indirectly Firmware
operation
Micro-controllerYes Disconnect
power for
at least 20
seconds.
Disconnect
power for
at least 20
seconds.
Table 2: TCAL500 volatile memory device
Type and
min. size Function
Type
of user
info
stored
Backed
up by
battery
Method
of
modification
Data
Input
methodLocation
User
accessible To clear To sanitize
SRAM 512 KB Controller
program
memory,
registers
Device
switch
command,
transfer
of
calibration
memory
No VectorVu-PC
application
commands
to
TCAL500
VectorVu-PC
application
commands
U16 on
internal
PCB
No Remove USB
cable
Remove USB
cable
TTR500 Series and TCAL500 Declassification and Security Instructions 1

Memory devices
Non-volatile memory
devices
Table 3: TTR500 non-volatile memory devices
Type and
min. size Function
Type
of user
info
stored
Method of
modification
Data
Input
method Location
User
accessible To clear To sanitize
I2C-32KB Bootloader None Programming
in factory
Factory
dedicated
software
Micro-controller
system
No Not applicable.
Does not contain
user data
or settings.
Clearing
can disable
instrument
functionality.
Not applicable.
Does not
contain user
data or settings.
Clearing
can disable
instrument
functionality.
SPI-16MB Firmware None Programming
in factory
Factory
dedicated
SW
Micro-controller
system
No Not applicable.
Does not contain
user data
or settings.
Clearing
can disable
instrument
functionality.
Not applicable.
Does not
contain user
data or settings.
Clearing
candisable
instrument
functionality.
Embedded
USB drive —
2GB
Software
installer,
documentation.
None,
unless
written by
user.
Host OS
contains
option to
write files
to disk.
Standard
Windows
file copy.
Embedded
USB
memory
module
Yes Disable USB
storage in
VectorVu-PC
application.
Use standard
Windows
applications
in your
organization to
declassify the
disk drive.
Disable USB
storage in
VectorVu-PC
application.
Use standard
Windows
applications
in your
organization
to declassify the
disk drive.
Table 4: TCAL500 non-volatile memory devices
Type and
min. size Function
Type
of user
info
stored
Method of
modification
Data
Input
method Location
User
accessible To clear To sanitize
Flash
memory
128MB
Factory
calibration
data
No user
data.
Only
Factory
calibration
table.
Factory
calibration,
not user
modifiable
Calibration
at Factory
U21 on
internal
PCB
Read only Factory software
command
Factory
software
command
Data export devices There are no media or export devices that require declassification or security
procedures with this product.
2 TTR500 Series and TCAL500 Declassification and Security Instructions

Clear or sanitize a non-functioning instrument
Clear or sanitize a non-functioning instrument
If your instrument is not functioning, return the instrument to Tektronix for
repair. A Tektronix service professional can reprogram the USB device embedded
in the VNA. No user data is stored on the instrument when it is disconnected
from a power supply.
To clear or sanitize the instrument:
1. Enable USB storage in activation manager in VectorVu-PC.
2. Use a secure erase tool to erase the USB drive.
Charges Replacement of any missing hardware will be charged according to the rate at
the time of replacement.
TTR500 Series and TCAL500 Declassification and Security Instructions 3
