Teleco Motostat digimatic 65 Assembly instructions

UK
INSTALLATION GUIDE
AND USER MANUAL

Information
Congratulations on your purchase! MotoSat is among the most technologically advanced
products in the field of satellite TV reception. This handbook has been prepared to provide
information on how to install, use, maintain and technical specifications your MotoSat.
For additional information, please contact your local dealer or directly the manufacturers:
TELECO s.p.a.
Via E. Majorana 49
48022 LUGO (RA)
Web site: www.telecogroup.com
Technical attendance: 899.899.856
TELECO .p.a. declines all responsibility for any errors contained in this manual. All the
contained information are up to the dates of printing and of the above-mentioned software
revisions. TELECO .p.a. reserves the right to introduce any modification made necessary by
the development of its products.
TELECO WARRANTY
Teleco guarantees its satellite dishes and terrestrial antennas against any
material and/or construction fault and defect. The warranty offered by
TELECO is limited to the free-of-charge replacement or repairing of any
parts that are deemed faulty by TELECO. The warranty is applicable for a
period of 3 YEARS starting from the product purchase date; however, it will
only be considered valid if the Customer is able to produce a written document
(invoice or tax receipt) showing the purchase date.
The following is excluded from the TELECO warranty:
a. Damages caused by incorrect installation and/or use and/or maintenance
b. Damages resulting from product alterations not authorised by Teleco
c. Damages resulting from the use of spare parts different from original
Teleco parts
d. Damages resulting from repairs carried out by personnel not
authorised by Teleco
e. Normal part wear;
f. Expenses incurred for spare parts transport between the Customer's
and the service centre
g. Damages that may occur during transport:
the Customer shall always be responsible for transport risks.
1

…and then drill the outside wall.
Set the drilling jig in place. Drill in the
middle of the jig (page 22)
Using a dia. 42 cutter, drill the inside
wall first…
Caution:
Mount the antenna away from the vehicle
roof edge to avoid overhanding the roof
line when travelling.
The MotoSat antenna must be installed
near a vertical wall where the wall outlet
can be fitted
Installation instructions
2

Insert the mast roof mounting bracket in
the dia. 42 hole bored in the roof, making
sure you apply a layer of silicone under
the ring nut.
Fasten the ring nut using self-tapping
screws. Place the rubber gasket over the
ring nut. ( Screws not supplied )
Secure the pipe lead to the roof using
the ring nut and its wedge-shaped spacer.
Caution: the antenna must be in horizontal
position. The wedge-shaped spacer is
used to set the antenna in the horizontal
position even if the roof is inclined.
Lock the collar on the wedge spacer
by applying the 2 screws (not supplied).
3

3,5 x 32
Introduce the
nut in its seat
on the back of
the wall outlet
Tight the locking ring nut
This mast locking device must be
screwed tight every time you wish to
secure the antenna in the desired position.
To turn or lift the mast, loosen this ring
nut.
Spread a thin film of Vaseline inside the
seal and introduce the mast
Fit the upper part of the wall outlet without
tightening all the way
Fix the outlet unit to the wall
4

Cut the antenna cable to the proper length and
apply the connector as shown on Figure. Make
sure no wire of the braiding touches the core of
the cable
Introduce the coaxial cable in the special
slot (A) and lead it out of rear bottom side
of Motosat (B)
Engage Motosat in the antenna support
tube until the tube holes are aligned with
the Motosat holes.
Fix Motosat to the antenna support tube
with the special screws.
Connect the cables as
shown in figure
Verify that the
coaxial cable
does not
obstruct the
screw hole.
Green
WhiteBrown
Coax
Receiver Sat
5

Press the UP button until a sequence of
beep sounds is obtained.
The antenna becomes automatically
positioned to facilitate installation (the
display reading is 37°).
Press the DOWN button until the
display reads OF.
Press the
DOWN button
until the display
reads OF.
Fasten the
antenna to the
arm as shown
in the figure.
6

Check that the antenna has been
lowered to the required travelling
position (fig.24) and glue the steel
plate below the LNB shim to the
roof with jointing compound or
double-sided adhesive tape.
Make sure that
the antenna is
exactly in its
stowed
position. Place
the sticker on
the mast in
such a way
that you can
quickly lock the
antenna in the
right position
before every
start.
The antenna must be absolutely installed according to fig. 24, i.e.,
the disc must be bent to the rear of the vehicle.
7

DSF80E is a device designed to quickly find required DIGITAL satellites according
to a manual dish pointing system. The 8 most popular satellites used in Europe are
stored in the system memory:Astra 28E,Astra23E,Astra19E, Hotbird 13E, Eurobird
9E, Thor 1W,Atlantic Bird 5W and Hispsat 30W. The Digital Finder is equipped with
visual and sound indicators to achieve received signal optimisation. If used in
conjunction with the Electronic Angle Detector available in the Voyager Digimatic
systems, DSF80E will also show the dish elevation figure, thus further simplifying
pointing operations. The device display unit will show the dish angle actual ‘absolute’
value even if the vehicle is not levelled.
1) ON/OFF switch
2) Satellite selection button
3) Pointed satellite indicator
4) Signal level indicator
5) Pointing completed indicator
6) Dish angle display unit
7) Angle adjustment buttons
(upon first installation only)
CONNECTIONS DSF80E
8

1) Connect the coaxial cable coming from the mast handle to the ANT connector
of the DSF80E device
2) Plug the REC connector of the DSF80 in the LNB connector of your satellite
receiver via the supplied coaxial cable.
3) Connect the 12Vdc input cable to the 12Vdc connector of the DSF80E device.
Plug the other end of the cable into the vehicle battery or a 12Vdc power outlet.
(stabilised)
SATELLITE RECEIVER
Note: The USB port can
only be used by
technical personnel to
carry out software
updates.
12Vdc
9

Country Town HOT BIRD ASTRA ATLANTIC
13° EST 19° EST BIRD 3 5° WEST
ALBANIA Tirana 42 42 36
ALGERIA Algiers 46 44 47
Costantine 47 45 45
Oran 46 43 48
AUSTRIA Innsbruck 36 35 33
Salzburg 35 35 32
Vienna 35 35 31
BALEARICS Palma 44 42 44
BELGIUM Antwerp 31 30 31
Brussels 31 30 31
Gand 31 30 31
Liege 31 30 31
BULGARIA Burgas 39 40 31
Sofia 40 41 33
CZECH
REPUBLIC Brno 33 34 30
Prague 33 32 30
DENMARK Copenhagen 27 27 25
EGYPT Alexandria 49 52 38
Cairo 50 53 38
FINLAND Helsinki 21 22 17
FRANCE Lyon 36 35 36
Marsille 39 37 38
Paris 36 35 36
Toulouse 38 37 39
GERMANY Berlin 30 30 28
Cologne 31 31 31
Hamburg 30 28 28
Munich 35 34 33
Stuttgart 34 34 33
Table of Elevation values for initial DSF80E setting up with MotoSat systems
Instructions for DSF80E initial set-up with Voyager systems
Set-up operations should only be carried out once upon system installation.After completing
all the required connections, perform inclinometer "ADJUSTMENT" to the vehicle on which
it is installed.
1) Check the Adjustment Table to identify the correct dish angle for the selected satellite
pointing (e.g. HOT BIRD 13E) from the installation area (e.g. HOT BIRD from Florence =
39°).
2) Switch on the DSF80E device by setting the power switch to ON and then select the
satellite to point (e.g. HOT BIRD ) by pressing the SAT button. Adjust the MotoSat elevation
and rotation settings to point the satellite as required and optimise pointing until the LEVEL
indicator shows the maximum number of burning LEDs and the SAT OK LED lights up.
3) The ELEVATION display unit of DSF80E will show a figure describing your dish angle.
This figure must match the figure shown in the Adjustment Table (for instance, in Florence,
the angle value that can be found in the table is 39°). If the display unit reading does not
match the adjustment table value, the device must be reset.
4) To reset the device, insert a small hard tip (e.g. the end of a metal staple) in one of
the 2 holes next to "Adj" then press repeatedly until the display unit reads the correct
angle value (39°). The button inside the left-hand hole will decrease the value, while the
button inside the right-hand hole will increase the value.
5) The DSF80E device is now ready to function and the display unit will always show the
dish angle actual ‘absolute’ value even if the vehicle is not levelled.
10

Country Town HOT BIRD ASTRA ATLANTIC
13° EST 19° EST BIRD 3 5° WEST
GIBRALTAR 44 41 48
GREECE Athens 45 46 37
Iraklion 47 49 38
Patras 45 46 38
Thessalonica 42 43 35
HUNGARY Budapest 35 35 31
Pecs 37 37 32
ICELAND Reykjavik 12 11 16
ITALY Brindisi 43 43 37
Cagliari 44 43 42
Firenze 39 39 37
Milano 37 37 36
Napoli 43 43 39
Palermo 46 45 42
Roma 42 41 38
Venezia 38 37 35
LYBIA Tripoli 52 51 47
MAROCCO Casablanca 45 41 51
Fes 46 43 50
Marrakech 46 42 53
Tangiers 44 41 48
NETHERLANDS Amsterdam 30 29 29
Eindhoven 31 30 30
Rotterdam 30 29 30
NORWAY Oslo 22 22 21
trondheim 19 19 18
POLAND Cracow 32 33 28
Gdansk 28 28 24
Warsaw 29 30 25
Wroclaw 31 32 28
PORTUGAL Lisbon 40 36 45
Porto 37 35 42
ROMANIA Bucarest 37 38 30
Timisoara 37 37 31
RUSSIA St. Petersburg 20 21 16
Moscow 23 25 16
SLOVAKIA Bratislava 35 35 31
Kosice 33 34 29
SPAIN Barcelona 41 39 42
Bilbao 40 37 42
Carthagene 44 42 46
Madrid 40 38 43
Seville 42 39 47
SWEDEN Goteborg 25 24 23
Stockholm 23 23 20
SWITZERLAND Berne 36 35 35
Geneve 36 35 36
Zurich 35 35 34
TUNISIA Tunis 47 46 44
TURKEY Ankara 39 42 29
Istanbul 40 42 31
Izmir 44 45 35
UNITED
KINDOM Belfast 28 27 27
Cardiff 31 29 31
Dublin 29 28 29
Glasgow 26 25 26
Inverness 24 23 24
Limerick 30 29 29
London 30 29 31
Manchester 27 26 29
Newcastel 26 25 27
Plymouth 32 31 32
York 27 26 28
11

Check that the elevation shown on
the DSF80E display coincides exactly
with that obtained at point 3. If not, use
the UP and DOWN buttons in order to
reach it.
Hold down the
“UP” button until 3
beep sounds are
emitted by
MotoSat. The
antenna will go up
to the latest stored
position setting
MotoSat will
automatically store
the latest antenna
elevation value to
facilitate pointing
operations.
Switch DSF80E on by
setting its power
switch to "ON"
Select a satellite to point
(e.g. ASTRA 19E )
by pressing the
button SAT
1) Switch on and prepare the SAT receiver and the TV set for reception following
the instructions of their respective manufacturers.
2) It is critical to make sure that there are no obstacles (e.g. houses, trees etc.) between the
antenna and the satellite southwards.
3) Check in the table supplied the elevation relative to the town closest to the place where
you are located.
INSTRUCTIONS FOR USE
12

Turn the dish
SOUTHWARDS until
DSF80E emits a
continuous "BEEP"
sound.
Wait for the SAT OK LED to light up,
confirming that the pointed satellite is
the required one.
If a satellite different from the required
one has been pointed, the SAT NOT
OK LED will light up and the dish must
be rotated again until the "BEEP"
sound is heard again and the SAT OK
LED lights up.
Optimise pointing by
slowly adjusting both
dish elevation and
dish rotation until the
maximum number of
burning LEDs is
obtained on the
LEVEL indicator.
13

Important information for proper antenna tracking
Before performing antenna tracking operation, make sure you have positioned your vehicle
so that the view towards the South (where Satellite signals come from) is free from any nearby
obstacle (trees, houses, etc.). This way, the antenna will be free to receive signals coming
from the satellite.
1) It is also important to know that satellites do not transmit with the same intensity throughout
Europe, so if you are outside the reception area, your Motosat search might be unsuccessful.
2) The reception areas for each Satellite can be found on the main magazines dealing in this
line of business. Also remember that the larger the dish, the more reception area is available
3) Make sure that the vehicle battery is sufficiently charged, if the voltage drops below 11.5
volts the electronic circuit protection prevents MotoSat antenna to move.
Switch DSF80E off by setting its
switch to the position "OFF"
If the power switch is not set to
OFF, no signal will reach the
satellite receiver and not TV
picture can be viewed.
RIGHT
POSITION
WRONG
POSITION
14

DISPLAY “Er”
The antenna has become locked. This
message is accompanied by 3 beep
sounds.
Remove any possible obstacle
which may block the antenna
(such as branches etc.)
DISPLAY “AL”
The vehicle has been started with an
unfolded antenna. This message is
accompanied by a long sequence of beep
sounds.
Lower the antenna pushing the
DOWN button.
DISPLAY “OF”
The antenna is folded. This message is
accompanied by a prolonged beep sound.
DISPLAY MESSAGES
With the antenna up, the display will show
the corresponding antenna elevation. The
elevation reading may be not accurate
because of poor levelling of the parked
vehicle.
15

ANTENNA FOLDING
To lower the antenna, hold down the
“DOWN” button until the display reads
“OF” followed by a prolonged beep sound.
If the green safety cable is connected to
the vehicle starter key (fig. XX) and the
vehicle is started with the antenna still
up, MotoSat will warn the user of the
impending danger with a long sequence
of beep sounds.
Before starting the
vehicle, make sure you
have brought down the
antenna to its standby
position and tightened
the knob hard
Failure to comply with these conditions may result in product
degradation which the manufacturer cannot be held responsible
for.
1) It is recommended not to use the antenna under strong wind
conditions (80 km/h). Failure to comply with this condition may result
in product degradation which the manufacturer cannot be held
responsible for.
2) The manufacturer declines any liability for all degradations suffered
by the product owing to misuse.
16

LNB rotation for ideal reception in Europe’s extreme
(South-West or South-East) areas
Remember that the outside converter (a.k.a. LNB) has its own assembly position which must
be complied with. Otherwise you will not receive any signal. The pre-set mounting position
for the LNB is along the centre line of the disk (fig. A). With this configuration, the Voyager
system works correctly in most European countries. However, if you are in areas very far
from the satellite orbital position, it might be necessary to adjust the converter angle. In
particular, if you wish to receive transmissions from the satellites Astra 19E, Astra 28E or
HotBird 13E, while you find yourself in Portugal or Morocco, your converter angle should be
adjusted as shown in (fig. B), while if you are in Turkey, to receive the same satellites you
should set your converter to the position (fig. C).
Place Position HotBird 13E Astra 19E Astra 28E
Lisbona B 25° 28° 37°
Casablanca B 27° 34° 41°
Ankara C 22° 15° 5°
1) Loosen the screws on the LNB locking U-bolt
2) Turn in the Clockwise (West) or Anti-clockwise (South-East) direction
3) Lock the LNB again by screwing down the screw
17

Dish elevation maps
To correctly point the dish towards your required satellite, it is very important to tilt
the dish to the exact angle.
Check your position on the map, then set the dish elevation figure in degrees
according to the figure on the required satellite map.
The grey sections in the various maps identify the geographical areas in which LNB
adjustment may be necessary.
18

19
