Teletekno Finnflash 1000 User manual

INSTALLATION INSTRUCTION
1
OPTICAL DISTRIBUTION SYSTEM
FINNFLASH 1000

FINNFLASH 1000
2
OPTICAL DISTRIBUTION SYSTEM
FINNFLASH 1000
INSTALLATION INSTRUCTION
© ONNINEN TELETEKNO OY 2007

INSTALLATION INSTRUCTION
3
Sisällysluettelo
1 General ........................................................................................................................ 5
2 Components of the system.......................................................................................... 6
3 Unpacking ................................................................................................................... 7
4 Locating and fastening ............................................................................................... 8
4.1 Planning the location....................................................................................................... 8
4.2 Fastening to oor ............................................................................................................. 8
4.3 Fastening to other frame................................................................................................. 9
4.4 Fastening to the wall........................................................................................................ 9
4.5 Earthing........................................................................................................................... 10
5 Termination of outdoor cables ................................................................................. 11
5.1 Termination of cables when outdoor cables are spliced to pigtail cables within
the FINNFLASH 1000 frame...................................................................................... 11
5.1.1 Bringing cables to the frame ............................................................................. 11
5.1.1.1 Cable entry from top................................................................ 11
5.1.1.2 Cable entry from bottom ........................................................12
5.1.2 Preparation and earthing of cables.................................................................. 12
5.1.2.1 Stranded loose tube cable ....................................................... 12
5.1.2.2 Slotted core cable ..................................................................... 13
5.1.2.3 Central tube cable.................................................................... 14
5.1.3 Fibre entry to the splice tray ............................................................................. 14
5.1.4 Installation of the splice module ..................................................................... 15
5.1.5 Installation of the splice trays to the splice module ...................................... 16
5.1.6 Installation of the patch panel .......................................................................... 16
5.1.7 Bringing of pigtail cables for splicing ............................................................. 18
5.1.8 Construction, colour coding and the main properties of the pigtail cable . 19
5.1.9 Preparing pigtail cables for splicing ............................................................... 20
5.1.10 Splicing of bres ................................................................................................ 22
5.1.11 Fastening and earthing of cables .................................................................... 23
5.1.12 Fastening of bre tubes .................................................................................... 24
5.1.13 Finishing the termination ............................................................................... 24
5.2 Termination of cables, when outdoor cables are spliced to pigtail cables outside
the FINNFLASH 1000 frame...................................................................................... 25
5.2.1 Bringing the outdoor cables to the splicing point ......................................... 25
5.2.2 Installation of the patch panel.......................................................................... 25
5.2.3 Installation of several patch panels simultaneously ..................................... 26
5.2.4 Bringing the pigtail cables from the FINNFLASH 1000 frame.................. 28
5.2.5 Finishing the termination in the FINNFLASH 1000 frame ....................... 29
5.2.6 Bringing the pigtail cables to the splicing point............................................ 29
5.2.7 Construction, colour coding and the main properties of the pigtail cable . 30
5.2.8 Preparing pigtail cables for splicing ...............................................................30
5.2.9 Splicing of bres ................................................................................................. 32
6 Side and back covers ................................................................................................. 33
7 Patch cords ................................................................................................................ 34
7.1 Patch cord installations into the FINNFLASH 1000 patch panels ......................... 35
7.2 Patch cords inside the FINNFLASH 1000 frame ...................................................... 36
7.3 Patch cords between the FINNFLASH 1000 frame and equipment racks............ 37
7.4 Patch cords between the FINNFLASH 1000 frames................................................. 39
8 FINNFLASH 1000 Storage Rack for patch cords .................................................... 40
9 ADC FibreGuide® system.......................................................................................... 42
9.1 Preparation ...................................................................................................................... 42
9.2 Installing supports ......................................................................................................... 43
9.3 Installing horizontal components ............................................................................... 43
9.4 Installing vertical components..................................................................................... 43
9.5 Installing covers, end caps, and accessories............................................................... 43
9.6 Completing and checking the system .........................................................................44
9.7 Examples of the installed FiberGuide® systems......................................................... 45

FINNFLASH 1000
4

INSTALLATION INSTRUCTION
5
1 General
In distributors the cables are terminated and connected to other cables or to equipment. e number of cables
coming to and leaving from a distributor may be up to hundreds of cables depending on the type and purpose
of the distributor. It is very important that the distributor including all cable installations has been designed,
planned and installed with appropriate skill and knowledge.
FINNFLASH 1000 Optical Distribution System has been designed to meet all the critical requirements of
a well functioning and reliable distributor. It is a result of the long and profound product development and
experience of Teletekno and its customers. All substantial aspects of initial build-up, use and maintenance
have been carefully taken into account. Modular design, pre-assembled and pre-terminated patch panels and
a smart cable management system guarantee easy installation, changes, expansions and other maintenance
practices during the whole life time.
e main features of FINNFLASH 1000 are the following:
• high bre capacity
• superior cable management
• access from the front side
• pre-assembled patch panels
• modular and clear construction
• easy to install, maintain and expand
• dimensions according to the ETSI standards

FINNFLASH 1000
6
2 Components of the system
e FINNFLASH 1000 system consists of the components shown in the table below. With these components
the network builder can construct appropriate distributor systems for his needs and purposes.
No. Component Short description Product
code
1FINNFLASH 1000 Optical Distribution
Frame, 2200 m
ODF frame with a turnable inner frame and fibre guides, height
2200 m 692600
FINNFLASH 1000 Optical Distribution
Frame, 2000 m
ODF frame with a hinged inner frame and fibre guides, height
2000 m 692601
2FINNFLASH 1000 Patch panel 24 with
4 m cable
Pre-assembled patch panel with:
• 12 x SC-D connectors
• pre-terminated MiniXtend cable, length 4 m
• 24 SM fibres
693701
FINNFLASH 1000 Patch panel 48 with
4 m cable
Pre-assembled patch panel with:
• 24 x SC-D connectors
• pre-terminated MiniXtend cable, length 4 m
• 48 SM fibres
693711
3FINNFLASH 1000 Patch panel 24 with
customer specified length of cable
Pre-assembled patch panel with:
• 12 x SC-D connectors
• pre-terminated MiniXtend cable of a customer specified
length
• 24 SM fibres
693700
FINNFLASH 1000 Patch panel 48 with
customer specified length of cable
Pre-assembled patch panel with:
• 24 x SC-D connectors
• pre-terminated MiniXtend cable of a customer specified length
• 48 SM fibres
693710
4MiniXtend cable, 24 SM Corning MiniXtend cable with 24 SM fibres, outer diameter 7
mm, fibre colour code according to ANSI/TIA-598-C.
(Same cable type is used in 693700 and 693701)
641110
MiniXtend cable, 48 SM Corning MiniXtend cable with 48 SM fibres, outer diameter 7
mm, fibre colour code according to ANSI/TIA-598-C.
(Same cable type is used in 693710 and 693711)
641111
5FINNFLASH 1000 Splice module Splice module for 18 FINNFLASH 1000 splice trays with a
capacity of 48 fibres each 692602
6FINNFLASH 1000 Splice tray Splice tray for FINNFLASH 1000 splice module, capacity of 48
fibres 692324
7FINNFLASH 1000 Storage rack for
patch cords, 2200 m
Storage rack for managing and storage of patch cords, height
2200 m 692602
FINNFLASH 1000 Storage rack for
patch cords, 2000 m
Storage rack for managing and storage of patch cords, height
2000 m 692603
8FINNFLASH 1000 Side cover, 2200 m Side cover for ODF frame, height 2200 mm 692605
FINNFLASH 1000 Side cover, 2000 m Side cover for ODF frame, height 2000 mm 692606
9FINNFLASH 1000 Back cover, 2200 m Back cover for ODF frame, height 2200 mm 692607
FINNFLASH 1000 Back cover, 2000 m Back cover for ODF frame, height 2000 mm 692608
10 FINNFLASH 1000
Wall Mounting Kit
With this kit FINNFLAH 1000 frame can be fastened to the wall
from the top 692640
Special modules with splitters or WDMs are available for the system.

INSTALLATION INSTRUCTION
7
3 Unpacking
Unpack the delivery package as follows:
• Remove the binding straps.
• Remove the covering cardboard and the wrapping cardboard.
• Remove the cellular plastic surrounding the frame.
• Unfasten the frame from the pallet by opening the fastening bolts.
• Check and assure that no damages have been caused during the transportation.
• Inform the supplier of possible damages.
• Li the frame and move it to its location, which has been planned before. Caution: e weight of the
frame is approx. 100 kg.

FINNFLASH 1000
8
4 Locating and fastening
4.1 Planning the location
Plan and prepare carefully the location of the frame before fastening. e following aspects should be consi-
dered when choosing the location:
• Accessibility to pathways, such as trays and shelves
• Floor loading: the weight of the equipped frame can exceed 300 kg
4.2 Fastening to floor
Fasten the frame to the oor with 4 screws at each corner of the bottom.
Required components: 4 pcs of M8 screw with washers (not included in the delivery)

INSTALLATION INSTRUCTION
9
4.3 Fastening to other frame
e frame can be fastened also to another frame. e fastening points are in front and back columns both on
the right and le.
Required components: 4 pcs of M6 screw with nuts and washers (not included in the delivery)
4.4 Fastening to the wall
e frame can be fastened to the wall from the top with FINNFLASH 1000 Wall Mounting Kit, see picture.
Required products and components:
• FINNFLASH 1000 Wall Mounting Kit, 692640
• 6 pcs of M6 screw with nuts
• 2 pcs of M5 screws and nuts

FINNFLASH 1000
10
4.5 Earthing
Connect the frame to the equipotential or earthing terminal of the telecommunications room. e earthing
conductor shall be min. 16 mm2copper wire.

INSTALLATION INSTRUCTION
11
5 Termination of outdoor cables
ere are two principle ways of outdoor cable termination:
1. Outdoor cables are spliced to pigtail cables within the FINNFLASH 1000 frame
2. Outdoor cables are spliced to pigtails outside the FINNFLASH 1000 frame
5.1 Termination of cables when outdoor cables are spliced to pigtail cables within
the FINNFLASH 1000 frame
5.1.1 Bringing cables to the frame
Either the top entry or the bottom entry can be used. Cables are brought to the frame outside of the back side
and they are xed only aer they have been spliced. Excess lengths of cables should be le to enable an easy
installation. Preparation and xing of cables depend on the entry direction. e top entry is described in 5.1.1.1
and the bottom entry is described in 5.1.1.2.
5.1.1.1 Cable entry from top
• Bring the cables down to the frame along the le side of the frame back (as seen from the front).
• Draw the ends of the cables inside the frame below the lowest xing plate.
• Draw the ends of the cables out of the frame as much as the cables will be in the frame aer the
termination work. As specifying the cable lengths note the 200 – 250 cm stripping length of the
cables starting from the earthing bar.
• Make the marks of the sheath removal point at the distance of 20 mm above the earthing bar.
• Draw the cables out of the frame as much as the marks of the sheath removal points are outside of
the frame and so much that the cables can be handled for the termination.
• Measure the 200 – 250 cm stripping lengths of the cables starting from the sheath removal points
and cut away the extra lengths from the cables.

FINNFLASH 1000
12
5.1.1.2 Cable entry from bottom
• Change the place of the earthing bar to the place above the lowest xing plate.
• Li the cables to the frame along the right side of the frame back (as seen from the front).
• Draw the ends of the cables inside the frame below the lowest xing plate.
• Draw the ends of the cables out of the frame as much as the cables will be in the frame aer the ter-
mination work. As specifying the cable lengths note the 200 – 250 cm stripping length of the cables
starting from the xing plate.
• Make the marks of the sheath removal point just above the lowest xing plate..
• Draw the cables out of the frame as much as the marks of the sheath removal points are outside of
the frame and so much that the cables can be handled for the termination.
• Measure the 200 – 250 cm stripping lengths of the cables starting from the sheath removal points
and cut away the extra lengths from the cables.
5.1.2 Preparation and earthing of cables
• Remove the cable sheaths starting from their sheath removal marks.
• Prepare and earth the cables according to the instructions of the cable supplier. ree examples are
described in 5.1.2.1 – 5.1.2.3. It should be noted that these are only examples. In every case instruc-
tions of the cable supplier shall be carefully followed.
5.1.2.1 Stranded loose tube cable
• Remove the cable sheath and other protective layers up to the sheath removal point marked before.
• Separate the loose tubes from each other.
• Remove the possible lling compound from the bre tubes by using the methods of the cable
supplier.
• Strip the possible metallic central element and cut it to the length of 20 cm.
• Cut the possible non-metallic central element and all llers at the point where the sheath has been
cut.

INSTALLATION INSTRUCTION
13
• Connect the connector of the earthing conductor to the possible aluminium laminate or corrugated
steel tape armouring of the cable.
5.1.2.2 Slotted core cable
• Remove the cable sheath and other protective layers up to the sheath removal point marked before.
• Connect the connector of the earthing conductor to the possible aluminium laminate or corrugated
steel tape armouring of the cable.
• Separate the bres or bre bundles from the slots. Take care that the bres don’t get mixed with each
other.
• If the cable is supplied with a metallic central element, cut the slotted core with the central element
to the length of 20 cm. Strip the central element to the length of 15 cm.
• If the cable is supplied with a non-metallic central element, cut the slotted core with the central ele-
ment to the length of 50 mm.
• Clean the bres from the lling compound.
• Bring the bundled bres into the tubes of the installation kit (accessory). e minimum length of the
installation kit is 110 cm.
• Push the installation kit around the slotted core in such a way that the bres in the slots are guided
directly into the protective tubes of the installation kit.
• Fasten the installation kit to the slotted core with the clamp included in the installation kit. If the
fastening is not tight, use the small adjusting parts of kit under the clamp.
• Mark the ends of the protection tubes by numbers 1, 2, …

FINNFLASH 1000
14
5.1.2.3 Central tube cable
• Expose the strength elements on both sides of the cable and turn them up to sheath removal point
marked before, cut them to the length of 200 mm and bend them on two sides.
• In the case of a cable with aluminium laminate or corrugated steel tape remove the sheath and other
protective layers up to the distance of 50 cm from the sheath removal point. Remove the cable sheath
in several parts.
• In the case of non-metallic cable remove the sheath and protective layers up to the to sheath removal
point. Remove the cable sheath in several parts.
• Remove the sheath from the possible aluminium laminate or corrugated steel tape by heating it e.g.
with a warm-air heater.
• Use e.g. a steel brush to remove also the possible plastic coating from the laminate or steel tape in
order to ensure the electrical contact for earthing.
• Cut the central tube at the distance of 30 mm from the aluminium laminate or the corrugated steel
tape and in a case of non-metallic cable at the distance of 30 mm from the cable sheath. Cut the
central tube by making rst a scratch around the tube and then bending the tube carefully at the both
sides of the scratch as long as it breaks.
• Take a hold from the bres with ngers and pull the central tube away.
• Clean the bres from the lling compound.
• Push the fan-out part of the installation kit (accessory) over the central tube and fasten it with the
clamp. If the fastening is not tight, use the small adjusting parts of kit under the clamp.
• Draw the bundled bres into the protection tubes of the installation kit by using the pulling wire
included into the kit. e minimum length of the tubes is 110 cm.
• Push the protection tubes to the slots of the fan-out part and guide the bres at the same time directly
from the central tube to the tubes.
• Mark the ends of the protection tubes by numbers 1, 2, …
5.1.3 Fibre entry to the splice tray
• Remove the covers of the splice trays.
• Bring the ends of the bre tubes to the le sides of splice trays (seen from the top) and put them
parallel so that the outermost tube is tube 1 and the innermost tube is the last tube.
• Fix the tubes with binders.
• Loop the bres on the splice trays.
• Make the appropriate markings on the splice tray.
• Reattach the covers to the splice trays.

INSTALLATION INSTRUCTION
15
5.1.4 Installation of the splice module
• Take the splice module from its package and turn it in the right way for mounting to the inner frame
so that the narrower mounting holes for the splice trays are below.
• Adjust the upper corner of the splice module to about 44 cm distance from the bottom of the inner
frame.
• Mount the splice module into the inner frame by 4 screws included to the splice tray module.

FINNFLASH 1000
16
5.1.5 Installation of the splice trays to the splice module
• Install the splice trays into their appropriate positions in the splice module
• Guide the bre tubes from the splice trays below the trays on the hinge side of the inner frame to the
back of the frame.
• e bre tubes shall be positioned considering the following:
o Bending radius of bres
o Movement of the inner frame
o Possibility to remove each splice tray individually from the splice module
5.1.6 Installation of the patch panel
• Open the panel package and remove protective materials from the package.
• Fasten the panel frame from its lower xing holes to the inner frame of FINNFLASH 1000 with two
screws included in the package. Install the rst panel of the frame into the highest place of the inner
frame.

INSTALLATION INSTRUCTION
17
• Cut the binders with which the panel is xed in the package.
• Open the pigtail cable loop of the panel.
• Mark the end of the cable by the identication number of the patch panel.
• Push the pigtail cable through the panel frame and guide it to the management hooks in the right
side of the inner frame. Do not x the cable to the hooks – leave it as loose as possible.

FINNFLASH 1000
18
• Mount and lock the panel to the panel frame with two nger screws.
5.1.7 Bringing of pigtail cables for splicing
• Bring the pigtail cable to its splice tray loosely from below the splice tray and from the front side (seen
from the front).
• Make the cutting marks on the cable to such lengths that the cable length on the splice tray is about
30 mm and the bre length on the splice tray is approx. 100 cm, and at least 70 cm.
• Cut away the extra length from the pigtail cable.
• Remove the splice tray from the frame and set it on the splicing table.

INSTALLATION INSTRUCTION
19
5.1.8 Construction, colour coding and the main properties of the pigtail cable
• e construction of the pigtail cable is in the picture below.
Rip cord
Loose buffer tube with up to
12 fibers E9/125, filled with
athixotropicgel
Central member, metal free
Swellable tape
Outer jacket, FRNC
• e colour coding system of the pigtail cable is as follows:
o Tubes:
24 bre cable: blue, orange
48 bre cable: blue, orange, green, brown
o Fibres:
No. 1 blue No. 7 red
No. 2 orange No. 8 black
No. 3 green No. 9 yellow
No. 4 brown No. 10 violet
No. 5 slate No. 11 pink
No. 6 white No. 12 turquoise
• e main installation properties of the pigtail cable are as follows:
o Bending radius:
During installation min. 120 mm
Installed min. 80 mm
o Pulling force: 900 N
◆
◆
◆
◆

FINNFLASH 1000
20
5.1.9 Preparing pigtail cables for splicing
• Remove the pigtail cable from management hooks of the inner frame.
• Cut the sheath at the point of the cutting mark.
• Remove the sheath at the length of 10 cm from the pigtail end and nd the rip cord.
• Remove the sheath by using the rip cord.
Table of contents
