1. Introduction
1.1. Scope
This document describes hardware solutions you can use to develop a product
containing the Telit CC864-Dual module, as follows:
•Describing the basic functions of the module
•Suggesting a proper hardware solution for each function
•Describing the wrong solutions and most common errors to be avoided
This document is not intended to provide an overall description of all hardware
solutions and all the products that may be designed.
The solutions suggested serve as a guide or starting point for you to be able to
correctly develop a product with the Telit CC864-Dual module.
However, avoiding the wrong solutions and most common errors described here
should be regarded as mandatory.
1.2. Audience
This manual is intended for hardware developers who design products that integrate
the CC864-DUAL module.
1.3. Contact Information, Support
For detailed information about where you can buy the Telit modules or for
recommendations on accessories and components visit http://www.telit.com
To register for product news and announcements or for product questions contact
Telit's Technical Support Center (TTSC).
1.4. Product Overview
The CC864-Dual module is a CDMA-1XRTT wireless module designed to have the
same form, fit and function as its GSM/GPRS counterpart product family, the GC864-
Dual.
This enables integrators and developers to design their applications once and take
advantage of the global coverage and service flexibility allowed by the combination of
the most prevalent cellular technologies worldwide.
With its ultra-compact design and extended operating temperature range, the Telit
CC864-Dual module is the perfect platform for m2m applications, mobile data and
computing devices. It also incorporates gpsOne capability for applications in mobile
environments such as telematics, personal and asset tracking.
1.4.1. General Specifications
Parameter Description
External access Code division multiple access

CC864-DUAL Hardware User Guide
80pppSTzzzzza Rev. 0.4 - dd/mm/yy
Reproduction forbidden without Telit Communications S.p.A’s. written authorization - All Rights Reserved. Page 7 of 49
CDMA protocol CDMA2000 1x Rel A and Rel B
Data Rate 153.6 Kb/s (full-duplex)
GPS SGPS / standalone
Vocoder EVRC, 13kQCELP, 4GV
Operating temperature -30° ~ +80°
1.4.2. Receiver Specifications
Parameters Descriptions
Frequency range Cellular: 869~894 MHz
PCS: 1930~1990 MHz
Channel number Cellular: 832
PCS: 1200
Sensitivity Better than -104 dBm
Input dynamic range -25dBm ~ -104 dBm
1.4.3. Transmitter Specifications
Parameters Descriptions
Frequency range Cellular: 824~849 MHz
PCS: 1850~1910 MHz
Channel number Cellular: 832
PCS: 1200
Power class Cellular: Class III
PCS: Class II
Power range 0.2 W (23 dBm) ~ 0.63 W (28 dBm)
Nominal power 0.27 W (24.31 dBm)
1.4.4. gpsOne Receiver Specifications
Parameters Descriptions
Frequency range L1, 1575.42 MHz
Receiver sensitivity -151 dBm
1.5. Safety Recommendations
1.5.1. Local regulations
Make sure that the use of this product is allowed in the country and in the
environment required.
The use of this product may be dangerous and thus must be avoided where:

CC864-DUAL Hardware User Guide
80pppSTzzzzza Rev. 0.4 - dd/mm/yy
Reproduction forbidden without Telit Communications S.p.A’s. written authorization - All Rights Reserved. Page 8 of 49
•It can interface with other electronic devices in environments such as
hospitals, airports, and so on.
•There is risk of explosion such as in the proximity of gasoline, oil refineries,
and so on.
You are responsible to enforce country and specific environment regulations on the
product. For further details refer to Chapter 1.7 for related documents.
1.5.2. Wiring and Installation
Always follow the instructions of this guide when wiring the product.
The product must be supplied with a stabilized voltage source, and the wiring must
conform to security and fire prevention regulations.
The installation of the external components of the module must be handled with care
in order to ensure the proper functioning of the product.
1.5.3. Electrostatic Discharge
The product must be handled with care, avoiding any contact with the pins because
electrostatic discharge can damage the product.
1.5.4. R-UIM Card
The R-UIM card must also be handled with care, always following the instructions for
its use.
Do not insert or remove the R-UIM when the product is in power saving mode.
1.5.5. Antennas
Every module must be equipped with a proper antenna with specific characteristics.
The antenna must be installed with care in order to avoid any interference with other
electronic devices, and it must also have a minimum distance of 20 cm from the body.
In case this requirement cannot be satisfied, the system integrator must assess the
final product against the applicable SAR regulations.
1.5.6. Disassembly
Do not disassemble the product.
Any evidence of tampering will void the warranty.
1.6. Document Organization
This manual contains the following chapters:
“Chapter 1: Introduction” provides a scope for this manual, target audience, contact
and support information, and text conventions.

CC864-DUAL Hardware User Guide
80pppSTzzzzza Rev. 0.4 - dd/mm/yy
Reproduction forbidden without Telit Communications S.p.A’s. written authorization - All Rights Reserved. Page 9 of 49
“Chapter 2: Mechanical Specifications” contains information on the dimensions of the
module, the interface connector and the RF connector, and on how to include the
module into external applications.
“Chapter 3: Hardware Interface Description” describes the hardware interfaces of the
product and provides guidelines for using the module in various applications.
“Chapter 4: Development and Testing” provides information on how to connect the
module to the Telit Evaluation Kit (EVK).
“Chapter 5: Acronyms and Abbreviations” provides definition for all the acronyms and
abbreviations used in this guide.
“Appendix: Pin Allocation” specifies the allocation of the pins on the connector that is
used for connecting the unit with external applications.
1.7. Text Conventions
Danger – This information MUST be followed or catastrophic equipment failure or
bodily injury may occur.
Caution or Warning – Alerts the user to important points about integrating the module,
if these points are not followed, the module and end user equipment may fail or
malfunction.
Tip or Information – Provides advice and suggestions that may be useful when
integrating the module.
1.8. Related Documents
The following documents are related to this user guide:
•CC864-DUAL Product Description – (Doc No)
•CC864-DUAL Software Description – (Doc No)
1.9. Document History
Doc rev # Date Changes Location in
Guide
0.3 01.03.2008 First version for Peer review
0.4 04.03.2008 Updates after review

CC864-DUAL Hardware User Guide
80pppSTzzzzza Rev. 0.4 - dd/mm/yy
Reproduction forbidden without Telit Communications S.p.A’s. written authorization - All Rights Reserved. Page 10 of 49
2. Mechanical Specifications
2.1. Module Dimensions
The CC864-DUAL overall dimensions are:
Length: 36.25 mm
Width: 30.00 mm*
Thickness: 4.65 mm*
*) Excluding solder pads.

CC864-DUAL Hardware User Guide
80pppSTzzzzza Rev. 0.4 - dd/mm/yy
Reproduction forbidden without Telit Communications S.p.A’s. written authorization - All Rights Reserved. Page 11 of 49
2.2. Interface Connector Specifications
The CC864-Dual module is equipped with a Molex 80-pin board-to-board connector
and P/N 0539490878 (male).
The mating part is Molex P/N 0541500878 (female).

CC864-DUAL Hardware User Guide
80pppSTzzzzza Rev. 0.4 - dd/mm/yy
Reproduction forbidden without Telit Communications S.p.A’s. written authorization - All Rights Reserved. Page 12 of 49
2.3. RF Connector Specifications
The CC864-Dual module is equipped with a Murata GSC type 50 Ohm RF connector,
and P/N MM9329-2700.
The suitable counterpart is Murata MXTK92 type or MXTK88 type connector.

CC864-DUAL Hardware User Guide
80pppSTzzzzza Rev. 0.4 - dd/mm/yy
Reproduction forbidden without Telit Communications S.p.A’s. written authorization - All Rights Reserved. Page 13 of 49
Mounting
The figure below shows the position of the Molex board-to-board connector and pin 1.
Tip: It is highly recommended to maintain a 1.5mm clearance from all wireless
modems to any components, including around the solder tabs.

CC864-DUAL Hardware User Guide
80pppSTzzzzza Rev. 0.4 - dd/mm/yy
Reproduction forbidden without Telit Communications S.p.A’s. written authorization - All Rights Reserved. Page 14 of 49
3. Hardware Interface Description
3.1. Overview
The CC864-Dual module has the following main interface function blocks:
•UART1 (used for AT commands)
•USB (used for diagnostic monitoring)
•R-UIM (UART2)
•GPIOs
•Audio (includes Analog I/O audio codecs and PCM interface)
•JTAG
•Miscellaneous pins (including I2C)
To
Antenna
QSC 6055
80 Pin Modem Interface Connector
RF Interface
US-PCS
Duplexer
RX
Filter
US
PCS
LNA
PAM TX
Filter
Cellular
Duplexer
RX
Filter
Cellular
LNA
PAM TX
Filter
Triplexer
USB
UART1
RUIM
GPIOs
CODEC
JTAG
Misc
To GPS
Dedicated
Antenna
ROM
RAM
CDMA Rx GPS
CDMA Tx
IIC
GPS
filter
LNA
GPS
Switch

CC864-DUAL Hardware User Guide
80pppSTzzzzza Rev. 0.4 - dd/mm/yy
Reproduction forbidden without Telit Communications S.p.A’s. written authorization - All Rights Reserved. Page 15 of 49
3.2. Functions for Turning On and Off the Module
3.2.1. Turning On the CC864-Dual Module
To turn on the module the ON/OFF Pin must be tied for at least one second, and
then released.
A Few Examples
1) Let's assume you need to drive the ON_OFF pin with a totem pole output of a +3/5
V microcontroller (uP_OUT1):
1s

CC864-DUAL Hardware User Guide
80pppSTzzzzza Rev. 0.4 - dd/mm/yy
Reproduction forbidden without Telit Communications S.p.A’s. written authorization - All Rights Reserved. Page 16 of 49
2) Let's assume you need to drive the ON_OFF pin directly with an ON/OFF
button:
3.2.2. Turning Off the CC864-Dual Module
You can turn off the device with either a software command or a hardware shutdown
circuit.
When the device is shut down either way, it issues to the network a detach request
with the information that the device is not reachable any more.
Warning: Never disconnect power before the power off procedure is completed. If
you do, this may cause severe damage the module primarily due to the possibility of
memory corruption that renders the module inoperable.
3.2.2.1. Hardware Shutdown
To turn off the CC864-Dual module the ON/OFF Pin must be tied for at least one
second, and then released.
The same circuitry and timing as for power on must be used for be used for powering
off the module.
The device shuts down after you release the ON_OFF Pin.
3.2.2.2. Software Shutdown
Please refer the “Software User Guide” for information on how to shut down the
module using AT-commands.
3.2.3. Hardware Reset
To perform hardware reset and reboot the module, the RESET pin must be tied low
for at least 200 milliseconds, and then released.

CC864-DUAL Hardware User Guide
80pppSTzzzzza Rev. 0.4 - dd/mm/yy
Reproduction forbidden without Telit Communications S.p.A’s. written authorization - All Rights Reserved. Page 17 of 49
The following figure shows a sample circuit to accomplish this operation:
TIP: A hardware reset circuit should be always implemented on the host board but
the host should use it as an emergency reset procedure only.
Example
Let's assume you need to drive the RESET# pad with a totem pole output of a +3/5 V
microcontroller (uP_OUT2):
3.3. Power Supply
The electrical design of the power supply strongly depends on the power source from
which the power is drained. We will discuss the following three common categories:
•+5V input source supply (typically PC internal regulator output)
•+12V input source supply (typically automotive)
•Battery source supply

CC864-DUAL Hardware User Guide
80pppSTzzzzza Rev. 0.4 - dd/mm/yy
Reproduction forbidden without Telit Communications S.p.A’s. written authorization - All Rights Reserved. Page 18 of 49
3.3.1. +5V Input Source Power Supply Design Guidelines
The desired output for the power supply is 3.8V, hence there’s not a big difference
between the input source and the desired output and a linear regulator can be used. .
When using a linear regulator, a proper heat sink may be required in order to
dissipate the heat.
A bypass low ESR capacitor of adequate capacity must be provided in order to cut
the current absorption peaks close to the CC864-Dual module, a 100µF tantalum (or
equivalent) capacitor is suited for this purpose.
Make sure the low ESR capacitor on the power supply output (usually a tantalum) is
rated at least 10V.
A protection diode should be inserted close to the power input, in order to protect the
module from power polarity inversion.
A typical example of a linear regulator with 5V input is:
3.3.2. +12V Input Source Power Supply Design Guidelines
The desired output for the power supply is 3.8V, and due to the large difference
between the input voltage and the desired output, a linear regulator is not well suited
and should not be used. A switching power supply is preferred because of its better
efficiency with the 2A peak current load drawn by the CC864-Dual module.
When using a switching regulator, a 500 KHz or more switching frequency regulator
is preferable because of its smaller inductor size and faster transient response. This
allows the regulator to respond quickly to current peaks.

CC864-DUAL Hardware User Guide
80pppSTzzzzza Rev. 0.4 - dd/mm/yy
Reproduction forbidden without Telit Communications S.p.A’s. written authorization - All Rights Reserved. Page 19 of 49
In any case the frequency and switching design selection is related to the application
to be developed due to the fact the switching frequency could also generate EMC
interferences and the application must also take this into account.
For a car PB battery the input voltage can rise up to about 16V and when choosing
components, all components in the power supply must withstand this voltage.
Power supplies for automotive use are complicated and have to take a number of
issues into account, such as: over voltage, reverse polarity, cranking, load dump
booster batteries, forced charging etc
A bypass low ESR capacitor of adequate capacity must be provided in order to cut
the current absorption peaks; a 100µF tantalum (or equivalent) capacitor is suitable
for this purpose.
Make sure the low ESR capacitor on the power supply output (usually a tantalum) is
rated at least 10V.
For car applications a spike protection diode must be inserted close to the power
input, in order to clean the supply from spikes and a specific automotive grade
regulator is recommended.
A protection diode (which can be the same diode as in spike protection) must be
inserted close to the power input in order to save the CC864-Dual module from
power polarity inversion.
A typical example of a switching regulator with 12V input is:
3.3.3. Battery Source Power Supply Design Guidelines
The desired nominal output for the power supply is 3.8V and the maximum voltage
allowed is 4.2V, so that a single 3.7V lithium-ion cell battery type is ideal to supply
the power to the module.
Three regular battery cells (Ni/Cd or Ni/MH 3.6V nom. battery types or 4V PB types)
must not be used directly because their maximum voltage can rise over the absolute
maximum voltage for the CC864-Dual module and damage it.
