1. INTRODUCTION
1.1. Scope
Scope of this document is to provide an overview of the technical aspects to consider
while implementing WiFi functionalities onto applications integrating Telit modules
specified in the aforementioned Applicability Table.
1.2. Audience
This document is intended for Telit customers who are about to implement WiFi
functionalities into their projects.
1.3. Contact Information, Support
For general contact, technical support services, technical questions and report
documentation errors contact Telit Technical Support at:
•[e-mail]
•[e-mail]
•[e-mail]
Alternatively, use:
http://www.telit.com/support
For detailed information about where you can buy the Telit modules or for recommendations
on accessories and components visit:
http://www.telit.com
Our aim is to make this guide as helpful as possible. Keep us informed of your comments
and suggestions for improvements.
Telit appreciates feedback from the users of our information.

80490NT11511A Rev. 3 Page 7of 17 2018-07-24
1.4. Text Conventions
Danger –This information MUST be followed or catastrophic equipment
failure or bodily injury may occur.
Caution or Warning –Alerts the user to important points about integrating the
module, if these points are not followed, the module and end user equipment
may fail or malfunction.
Tip or Information –Provides advice and suggestions that may be useful
when integrating the module.
All dates are in ISO 8601 format, i.e. YYYY-MM-DD.

80490NT11511A Rev. 3 Page 8of 17 2018-07-24
1.5. Related Documents
•LE910Cx HW user Guide, 1VV0301298
•AT Commands Reference Guide, 80407ST10116A
•Telit EVB User Guide, 1VV0301249
•Telit WE866C3 HW Design Guide, 1VV0301495
•M.2 Adapter for WE866C3-P HW User Guide, 1VV0301533
•LE910Cx Multi Technology Interface Board TLB - HW User Guide, 1VV0301508

80490NT11511A Rev. 3 Page 9of 17 2018-07-24
2. WIFI INTERFACE
2.1. Introduction
The WiFi Interface is part of the Baseband System of the cellular module.
Its main application described in this document is to connect the WIFI interface to
WE866C3 module.
2.2. Functional Overview
The WiFi Interface is a dedicated SDIO interface that is used as a communication channel
to the Modem chipset.
The tables below describe the WIFI interface for the various cellular modules.
2.2.1. WiFi interface of LE910Cx
PIN
SIGNAL
I/O
FUNCTION
TYPE
COMMENT
L12
WIFI_SDRST_TGPIO13
O
WLAN RESET
CMOS
1.8V
N13
WIFI_SDCMD_TGPIO14
I/O
SDIO CMD
CMOS
1.8V
J13
WIFI_SD0_TGPIO15
I/O
SDIO DATA 0
CMOS
1.8V
M13
WIFI_SD1_TGPIO16
I/O
SDIO DATA 1
CMOS
1.8V
K13
WIFI_SD2_TGPIO17
I/O
SDIO DATA 2
CMOS
1.8V
H13
WIFI_SD3_TGPIO18
I/O
SDIO DATA 3
CMOS
1.8V
L13
WIFI_SDCLK_TGPIO19
O
SDIO CLOCK
CMOS
1.8V

80490NT11511A Rev. 3 Page 10 of 17 2018-07-24
2.3. Basic Block Diagram
The following diagram shows a basic connection of LE910Cx with WE866C3 module over
the WiFi interface.
Figure 1 Basic Block Diagram
LE910Cx
WE866C3
Wi-Fi SDIO
Interface
VBATT (3.6V –4.2V)
1.8V
Reg.
Reg.
3.3V

80490NT11511A Rev. 3 Page 11 of 17 2018-07-24
2.4. EVB Connection
The WiFi interface connection which is forming the system of LE910Cx and the WE866C3
module is made using the MTB card. The figure below shows the EVB and the MTB card
connected. The WE866C3 module, mounted on an M.2 form factor mini card, is mounted
on the MTB.
Figure 2 EVB Connection

80490NT11511A Rev. 3 Page 12 of 17 2018-07-24
2.4.1. Detailed EVB Connection Diagram
The figure below shows the detailed signals connection between Telit LE910Cx and the
WE866C3 module.
V. Reg
1.8V
V. Reg
3.3V
VBATT
VDDIO VDD_3.3VVBATT/VBATT_PA
Telit Module WE866C3
WIFI_SDCLK
WIFI_SDCMD
WIFI_SD0
WIFI_SD1
WIFI_SD2
WIFI_SD3
WIFI_SDRST
WCI_RX
WCI_TX
WLAN_SLEEP_CLK
SDIO_CLK
SDIO_CMD
SDIO_DATA0
SDIO_DATA1
SDIO_DATA2
SDIO_DATA3
WL_EN
LTE_PRI/LTE_TXD
LTE_SYNC/LTE_RXD
LF_CLK_IN
WOW
TGPIOx
Figure 3 Detailed WiFi Connectivity Diagram
•SDIO bus of 4 bit is supported by the Modem.
•The system is using the 2-wire WCI interface for LTE coexistence.

80490NT11511A Rev. 3 Page 13 of 17 2018-07-24
2.4.2. Detailed EVB Connection Signal description
TELIT
SIGNAL NAME
WIFI
WE866C3
SIGNAL NAME
I/O
FUNCTION
TYPE
COMMENT
SDIO BUS
WIFI_SDCLK
SDIO_CLK
O
SDIO CLOCK
CMOS 1.8V
WIFI_SDCMD
SDIO_CMD
I/O
SDIO CMD
CMOS 1.8V
WIFI_SD0
SDIO_DATA0
I/O
SDIO DATA 0
CMOS 1.8V
WIFI_SD1
SDIO_DATA1
I/O
SDIO DATA 1
CMOS 1.8V
WIFI_SD2
SDIO_DATA2
I/O
SDIO DATA 2
CMOS 1.8V
WIFI_SD3_TGPIO18
SDIO_DATA3
I/O
SDIO DATA 3
CMOS 1.8V
CONTROLS
WIFI_SDRST
WL_EN
O
WLAN Power
Down
CMOS 1.8V
WLAN ENABLE.
ACTIVE HIGH.
WLAN_SLEEP_CLK
LF_CLK_IN
O
SLEEP CLOCK
FOR WIFI
(32.768KHZ)
CMOS 1.8V
EXTERNAL LOW-
POWER 32.768
KHZ CLOCK
INPUT
MODEM COEXISTANCE
WCI_RX
LTE_PRI/LTE_TXD
I
SERIAL DATA
INPUT
CMOS 1.8V
LTE CO-
EXISTENCE
SIGNAL.
LTE_UART_TXD
OR LTE_PRI.
WCI_TX
LTE_SYNC/LTE_R
XD
O
SERIAL DATA
OUTPUT
CMOS 1.8V
LTE
COEXISTENCE
SIGNAL.
LTE_UART_RXD
OR LTE_FS.

80490NT11511A Rev. 3 Page 14 of 17 2018-07-24
3. WIFI SETUP QUICK START GUIDE
3.1. Software/Set-up Requirements
The following Drivers must be installed:
- Android SDK platform on a Windows machine:
•Go to: http://developer.android.com/sdk/win-usb.html
Follow the instructions for installing the SDK (Select SDK only, no need for ADT
bundles).
•Right-click “My Computer”, select Properties→Advanced→Environment Variables,
and set the path to include the c:\android-sdk-windows\tools directory.
The path must point to directory with fastboot.exe file in it.
For example -> C:\Program Files\Android\android-sdk\platform-tools
•Navigate to the %USERPROFILE%\.android directory (simply copy this line into the
file browser: %USERPROFILE%\.android).
•In the %USERPROFILE%\.android directory, create/edit the adb_usb.ini file. If the file
already exists, it will contain a DO NOT EDIT message. Disregard this message and
edit the file anyway. To edit, add a line containing 0x1bc7 to the end of the file.
The file contents should look like the below:
# ANDROID 3RD PARTY USB VENDOR ID LIST -- DO NOT EDIT.
# USE 'android update adb' TO GENERATE.
# 1 USB VENDOR ID PER LINE: 0x1bc7
- USB drivers on a Windows machine can be downloaded from:
http://www.telit.com/evkevb-drivers/
3.2. Commands example
1) Open Command prompt (cmd.exe), and execute ‘adb shell’ command.
2) Line marking will change to / # , You can proceed to next step
The following steps are run from within this shell, as is.
1) Type QCMAP_CLI, select the following options:
a. type 30 (Enable/Disable Mobile AP) –1: Enable
b. type 31 (Enable/Disable WLAN) –1: Enable
c. type 32 (Connect/Disconnect Backhaul)
I. Backhaul State(1-Connect/0-Disconnect): 1
II. Call Type (1-IPV4; 2-IPV6): 1
3.3. WLAN - User guide
Please see Telit AT Commands reference manual (document number 80407ST10116A) for details
on WLAN available commands.

80490NT11511A Rev. 3 Page 15 of 17 2018-07-24
4. GLOSSARY AND ACRONYMS
Description
TTSC
Telit Technical Support Center
USB
Universal Serial Bus
HS
High Speed
DTE
Data Terminal Equipment
UMTS
Universal Mobile Telecommunication System
WCDMA
Wideband Code Division Multiple Access
WCI
Wireless Coexistence Interface
HSDPA
High Speed Downlink Packet Access
HSUPA
High Speed Uplink Packet Access
UART
Universal Asynchronous Receiver Transmitter
SIM
Subscriber Identification Module
SPI
Serial Peripheral Interface
I/O
Input Output
GPIO
General Purpose Input Output
CMOS
Complementary Metal –Oxide Semiconductor
CLK
Clock
CS
Chip Select
RTC
Real Time Clock
PCB
Printed Circuit Board

80490NT11511A Rev. 3 Page 16 of 17 2018-07-24
5. DOCUMENT HISTORY
Revision
Date
Changes
0
2016-11-14
First issue
1
2016-11-21
LE920A4 and LE910Cx adaptation of document
2
2018-02-26
Global updated related to WE866C3
3
2018-07-24
Remove reference to LE920A4

[04.2016]
Mod. 80490NT11511A 2018-07-24
Rev.3
