Tellabs 8860 User guide

Revision A
Copyright © 2004 Tellabs. All rights reserved.
®
System Installation
76.8860IM31-A
Tellabs®8860 Multi-service Switch Router

FCC Notification
Statement Federal Communications Commission (FCC) Rules require that you be notified of the following:
This equipment has been tested and found to comply with the limits for a Class
A digital device, pursuant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to
cause harmful interference in which case the user will be required to correct the
interference at his own expense.
Changes or modifications not expressly approved by Tellabs Operations, Inc., in
writing can void the user’s authority to operate the equipment.
Industry Canada
Notification Statement Industry Canada interference-causing equipment regulations require that you be notified of the following:
This Class A digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe A est conforme à la norme NMB-003 du
Canada.
Copyright Statement This Tellabs manual is owned by Tellabs or its licensors and protected by U.S.
and international copyright laws, conventions, and treaties. Your right to use this
manual is subject to limitations and restrictions imposed by applicable licenses
and copyright laws. Unauthorized reproduction, modification, distribution, display
or other use of this manual may result in criminal and civil penalties.
Trademark Notice The following trademarks and service marks are owned by Tellabs Operations,
Inc., or its affiliates in the United States and/or other countries: AUDIO PLUS®,
CABLESPAN®, CEC-128™, DYNAMIC SIGNAL TRANSFER™, DXX®,
DXX logo®, EC DUO®, ENHANCED AUDIO PLUS®, EXPRESS/PATH®,
FOCUS™, MARTIS®, MARTISDXX®, MARTIS logo®, MARTISDXX logo®,
METROVANTAGE™,METROWATCH™, NETREACH®, NETWISE®,
SCULPTURED SOUND™, TELLABS®, TELLABS and T symbol®, T symbol,
TELLABS PROPARTNER™, TEL/MAP™, TEL/MOR®, THE WORLD
COMMUNICATES THROUGH TELLABS™, TITAN®, VERITY™, YOUR
NETWORKING PARTNER®.
Any other company or product names may be trademarks of their respective
companies.
Contact Information In an effort to improve the quality of this document, please notify Tellabs
Technical Assistance at 1.800.443.5555 in North America or 1.630.378.1192
outside North America if any anomalous conditions are observed.

Tellabs 8860 Multi-service Switch Router System Installation iii
Table of Contents
CHAPTER 1 Installation Overview
Overall Installation Sequence. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
1. Unpack and Inspect the 8860 MSR and Components . . . . . . . . . . . . 1-2
2. Prepare Power Source. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
3. Position, Load, and Cable the 8860 MSR . . . . . . . . . . . . . . . . . . . . . . . 1-2
4. Initialize the 8860 MSR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
Installation Checklist. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
CHAPTER 2 Unpacking and Site Preparation
Safety Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
Unpacking the 8860 MSR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
Uncrate and Inspect. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
8860 MSR Crate Inspection and Disassembly . . . . . . . . . . . . . . . . . 2-3
Accessory Box Inspection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-5
Circuit Pack Crate Inspection and Disassembly . . . . . . . . . . . . . . . 2-5
Verify Receipt. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-6
Contacting Technical Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-6

PN 76.8860IM31-A Tellabs 8860 Multi-service Switch Router System Installation
iv
Returning Products to Tellabs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-6
Site Preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-7
Tools and Supplies Requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-7
Rack Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-8
Environmental Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-9
Power Requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-10
Optical Network PLM Description and Cable Connection. . . . . . . . . . . . . 2-11
Fast Ethernet PLM Details . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-13
DS3 Clear Channel and Channelized PLM Details. . . . . . . . . . . . . . . . . . . . 2-14
CHAPTER 3 Equipment Overview
8860 MSR Chassis . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2
Card Cage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-3
System Panel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-3
Environmental Status LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4
Alarm LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-5
Craft Display Panel and Keypad. . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-5
ACO Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-6
Card Status LEDs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-8
Fan Tray Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-9
Air Filter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-10
Cable Management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-11
8860 MSR Rear Connector Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-12
Intershelf Cabling Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-13
Serial Connector. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-13
Ethernet Management Connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-13
External Alarm Connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-13
T1 BITS External Timing Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-14
DC Power Blocks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-14
Switch and Control Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-15
Using the Shutdown Button on the SCC . . . . . . . . . . . . . . . . . . . . . . . . 3-17
Universal Line Cards. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-18
Physical Line Modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-20
Blank Panels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-20
CHAPTER 4 Installation
Rack-Mount the 8860 MSR. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2
Adjusting Mounting Brackets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-3
Positioning and Securing 8860 MSR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-4

PN 76.8860IM31-A Tellabs 8860 Multi-service Switch Router System InstallationTel-
v
Connect Power and Ground. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-5
Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-5
Ground the 8860 MSR Chassis. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-7
Tri-Power Grounding and Connection. . . . . . . . . . . . . . . . . . . . . . . . . . . 4-7
Load the Chassis . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-9
SCC and ULC Installation Sequence. . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-10
Install the Switch and Control Cards . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-10
SCC Slot Rules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-10
Loading SCCs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-11
Install the Universal Line Cards. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-13
ULC Slot Rules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-13
Loading ULCs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-13
Install an OC-192c/STM-64c PLM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-16
Install a 10 Gigabit Ethernet PLM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-17
Install PLMs into the ULCs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-17
Inserting a PLM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-17
Install Blank Panels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-18
Install Card Slot Blank Panels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-18
Install PLM Blank Panels into ULCs. . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-20
Connect PLMs to the Optical Network. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-21
Connect T1 BITS Clocks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-22
Connect 8860 MSR Alarm Outputs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-23
Connect a Local Console to the 8860 MSR. . . . . . . . . . . . . . . . . . . . . . . . . . . 4-24
Apply and Verify Power. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-25
Let the System Boot Up. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-26
Log Into the 8860 MSR Console Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-27
If you need to log out . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-27
Change the Default Password . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-28
Set a Static Route . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-29
Connect the Ethernet Management Port . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-29
Connect to the IP Management Network. . . . . . . . . . . . . . . . . . . . . . . . 4-30
APPENDIX A 8860 MSR Specifications
8860 MSR Physical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-2
8860 MSR System Management and Alarm Specifications. . . . . . . . . . . . . . A-3
8860 MSR System Power Requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-4
Optical PLMs and Power Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-5
OC-3 PLMs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-6
OC-12 PLMs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-7
OC-48 PLMs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-8
OC-192 PLMs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-9

PN 76.8860IM31-A Tellabs 8860 Multi-service Switch Router System Installation
vi
Other PLMs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-10
10 GigE PLM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-11
GigE PLM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-12
Fast Ethernet PLM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-13
DS3/E3 Clear Channel PLM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-14
DS3 Channelized PLM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-15
Environmental Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-16
Safety and Compliance Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-17
Connector and Adapter Pinouts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-18
Console Serial Connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-19
RJ45-to-DB9 Connector Adapters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-20
Ethernet (IP Management) Connector . . . . . . . . . . . . . . . . . . . . . . . . . . A-21
External Alarm Connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-22
External BITS Timing Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-23
Port Densities . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-24
APPENDIX B Setting Boot Parameters
Viewing and Modifying Boot Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-2

Tellabs 8860 Multi-service Switch Router System Installation vii
PREFACE About This Manual
The Tellabs 8860 Multi-service Switch Router System Installation
provides instructions for safely unpacking, installing, powering-
up, testing and servicing the Tellabs 8860 Multi-service Switch
Router (MSR). After completing the procedures in this
installation guide, you can start managing and configuring the
8860 MSR equipment with the Tellabs® Multi-service Operating
System.
This preface contains information about this manual, in the
following sections:
❑ Audience
❑ Organization
❑ Symbols
❑ General Safety Precautions

PN 76.8860IM31-A Tellabs 8860 Multi-service Switch Router System Installation
viii
Audience
The Tellabs 8860 Multi-service Switch Router System Installation manual is intended for
use by equipment administrators and NOC operators who are responsible for ensuring
integrity of received product, and performing equipment setup and initialization.
Organization
The Tellabs 8860 Multi-service Switch Router System Installation manual is organized as
follows:
❑ Chapter 1—Installation Overview —Provides a quick glance of the task sequence typically
required for installing a 8860 MSR after all components have been removed from the
shipping crate, site preparation is completed, and all components have been inspected.
❑ Chapter 2—Unpacking and Site Preparation —provides procedures and relevant information
for unpacking and mounting the 8860 MSR, and for connecting it to external facilities.
❑ Chapter 3—Equipment Overview —describes the 8860 MSR chassis and all replaceable
components. This chapter also introduces the software tools used to control and
monitor the 8860 MSR.
❑ Chapter 4—Installation —provides the procedures and relevant information for installing,
cabling, and connecting the 8860 MSR line cards and physical line modules.
❑ Appendix A— 8860 MSR Specifications —lists physical, environmental, electrical, and
mechanical characteristics of the 8860 MSR switch components and physical line
modules (PLMs).
❑ Appendix B— Setting Boot Parameters —provides guidelines for modifying boot parameters,
if absolutely necessary.

ix
PN 76.8860IM31-A Tellabs 8860 Multi-service Switch Router System Installation
Symbols
This section presents the conventions used in this documentation to identify important
notes and various warnings.
NOTE
The pencil icon highlights important, noteworthy information. Be sure to
read information alongside this symbol to obtain guidelines for performing
tasks more efficiently.
ARNING
The warning symbol alerts you about action(s) or inaction(s) that could
lead to personal injury or damage to the 8860 MSR equipment.
The laser radiation symbol alerts you about actions that, if performed
incorrectly, can result in exposure to hazardous invisible radiation.
ESD W ARNING
The electro-static discharge (ESD) warning symbol reminds you to observe
precautions to prevent electrostatic damage to static-sensitive assemblies
and circuits.
CAUTION
The caution symbol alerts you about any hazard that may result in physical
injury.

PN 76.8860IM31-A Tellabs 8860 Multi-service Switch Router System Installation
x
General Safety Precautions
This section presents the safety precautions that you must observe while working with
Viva equipment, in the following topics:
❑ Observe Warnings in Product Documentation
❑ Ground the 8860 MSR
❑ Do Not Substitute Parts or Modify Equipment
The safety precautions listed in this section represent warnings associated with certain
dangers of which Tellabs is aware. You, as the user of this product, must observe these
warnings and all other safety precautions necessary to ensure your personal safety as well
as the continued safe operation of the 8820 MSR in your operating environment.
Observe Warnings in Product Documentation
Warning symbols and advisory text are positioned at potentially hazardous procedures in
this manual. When you see these warnings, follow the instructions as well as any other
safety precautions that you deem necessary for installing, operating, and servicing Viva
equipment in your operating environment.
ARNING
Danger! Shock Hazard
Use extreme caution when working around power sources during
installation, operation, testing, and equipment adjustments.
Remove the power at its point of distribution before you connect or
disconnect power leads to the equipment.
Class 1 Laser Product
Class 2 LED Product
Using controls or adjustments, or performing procedures, other than as
specified herein, may result in exposure to hazardous invisible radiation.
CAUTION
Use of controls or adjustments of performance or procedures other than
those specified herein may result in hazardous radiation exposure.

xi
PN 76.8860IM31-A Tellabs 8860 Multi-service Switch Router System Installation
Ground the 8860 MSR
To meet safety and EMI requirements and to ensure proper operation, the 8860 MSR must
be adequately grounded before power is connected. Two threaded 5/16-18 UNC studs are
provided on the rear of the chassis for a connection to earth ground. A standard two-hole,
2 AWG lug (Panduit LCD series), and two 5/16-18 UNC nuts are furnished with the
chassis.
To properly ground the 8860 MSR, use a 2 AWG copper grounding cable that is long
enough to connect the nearest earth ground point at the site to the 8860 MSR chassis
ground lug. Crimp the cable to this lug, using the hardware provided with the chassis. The
grounding cable must be able to handle 120 amps of current.
ESD W ARNING
The 8860 MSR circuit cards can be damaged by static electricity that builds up on
work surfaces and on your body. Static is produced by the everyday movement of
your body, and is released as an Electro-Static Discharge (ESD) when you touch an
object. Observe the following precautions whenever you are working with the 8860
MSR.
•Always wear a grounded wrist strap to prevent ESD damage to the 8860
MSR system components
•Be sure to attach the wrist strap to the ESD ground jack located on the
front panel of the equipment.
CAUTION
The 8860 MSR chassis is heavy. When shipped with module packs and
packing materials, the weight increases substantially. Use safe work
practices whenever unpacking, lifting, or moving a 8860 MSR shelf. Use
guidelines in the manual to determine how many people you need to assist
in positioning and securing a 8860 MSR shelf.
CAUTION
Do not apply power to 8860 MSR equipment until you have completed all
installation procedures provided in this manual.

PN 76.8860IM31-A Tellabs 8860 Multi-service Switch Router System Installation
xii
Do Not Substitute Parts or Modify Equipment
Do not install substitute parts or perform any unauthorized modification of the 8860 MSR
system. Contact your local Tellabs representative for service and repair.
Lithium Battery
Contact Tellabs Advanced Data Products Technical Support to determine if the Lithium
battery is the source of any defective operations on the 8820 MSR, and do not attempt to
change the battery without the assistance of authorized, Tellabs service personnel. Please
see
Table 2-2 on page 6 for contact information.
CAUTION
For centralized DC power connection install only in a restricted access area.
ARNING
Danger! Shock Hazard
Never dismantle a 8860 MSR chassis, or attempt to service 8860 MSR
chassis sub-assemblies without the assistance of Tellabs factory-
authorized service personnel or other qualified maintenance personnel.
CAUTION
Danger! Possible Explosive
An incorrectly replaced Lithium battery may result in explosion. Replace
only with the same or equivalent type recommended by the manufacturer.
Dispose of used batteries according to the manufacturer’s instructions.

Tellabs 8860 Multi-service Switch Router System Installation 1-1
CHAPTER 1 Installation Overview
This chapter introduces the task sequence typically required for
installing a Tellabs® 8860 Multi-service Switch Router after all
components have been removed from the shipping crate, site
preparation is complete, and all components have been
inspected. Installation overviews are provided in the following
sections of this chapter:
❑ Overall Installation Sequence, on page 1-2
❑ Installation Checklist, on page 1-3

PN 76.8860IM31-A Tellabs 8860 Multi-service Switch Router System Installation
1-2 Installation Overview Overall Installation Sequence
1. Unpack and Inspect the 8860 MSR and Components
Overall Installation Sequence
This section provides an overall 8860 MSR installation sequence as follows:
1. Unpack and Inspect the 8860 MSR and Components, on page 1-2
2. Prepare Power Source, on page 1-2
3. Position, Load, and Cable the 8860 MSR, on page 1-2
4. Initialize the 8860 MSR, on page 1-3
1. Unpack and Inspect the 8860 MSR and Components
See Unpacking the 8860 MSR, on page 2-2 for detailed instructions.
2. Prepare Power Source
Power feed cabling must be prepared to enable connection to the 8860 MSR DC block, and
the earth ground must be prepared for connection to the rear of the 8860 MSR. See
Connect
Power and Ground, on page 4-5
for details.
3. Position, Load, and Cable the 8860 MSR
Prior to installing the 8860 MSR in a rack you may need to install the mounting brackets
provided with the equipment as shown by the following steps:
Step 1 Rack-Mount the 8860 MSR, on page 4-2
Step 2 Connect Power and Ground, on page 4-5
Step 3 Load the Chassis, on page 4-9
Step 4 Install Blank Panels, on page 4-18
Step 5 Connect PLMs to the Optical Network, on page 4-21

Installation Checklist 4. Initialize the 8860 MSR Installation Overview 1-3
PN 76.8860IM31-A Tellabs 8860 Multi-service Switch Router System Installation
4. Initialize the 8860 MSR
This section provides guidelines for attaching the 8860 MSR to a network and performing
an initialization sequence. Detailed information is provided in the following sections:
❑ Connect a Local Console to the 8860 MSR, on page 4-24
❑ Connect to the IP Management Network, on page 4-30
❑ Apply and Verify Power, on page 4-25
❑ Let the System Boot Up, on page 4-26
Installation Checklist
Use the links in Table 1-1 under the Guidelines column to find details for completing each
step of the installation and initial system configuration.
NOTE
If you need to troubleshoot the bootup, refer to guidelines provided in
Setting Boot Parameters, on page B-1 .
Table 1-1 First-Time Installation Checklist and Documentation Reference
Task Checklist Guidelines
Mount the 8860 MSR chassis on a
rack. •
Rack-Mount the 8860 MSR, on page 4-2
Connect the chassis to earth
ground. •
Connect Power and Ground, on page 4-5
Connect the 8860 MSR to a UPS-
protected power source.
Install the first switch and control
card (SCC) in slot S1. •
SCC and ULC Installation Sequence, on page 4-10
• Install the Switch and Control Cards, on page 4-10
Install universal line cards (ULCs)
in slot 8. •
SCC and ULC Installation Sequence, on page 4-10
• Install the Universal Line Cards, on page 4-13
Install physical line modules
(PLMs). •
Install an OC-192c/STM-64c PLM, on page 4-16
• Install a 10 Gigabit Ethernet PLM, on page 4-17
• Install PLMs into the ULCs, on page 4-17

PN 76.8860IM31-A Tellabs 8860 Multi-service Switch Router System Installation
1-4 Installation Overview Installation Checklist
4. Initialize the 8860 MSR
Connect the PLMs to the SONET/
SDH optical network. •
Connect PLMs to the Optical Network, on page 4-21
Connect the 8860 MSR to the
external alarm equipment. •
Connect 8860 MSR Alarm Outputs, on page 4-23
Connect the 8860 MSR to the T1
BITS external timing clocks (if you
are using BITS timing).
Connect T1 BITS Clocks, on page 4-22
Obtain the following information
for 8860 MSR management
interfacing:
❑System IP Address
❑IP mask
❑Gateway IP Address
Connect the Ethernet Management Port, on page 4-29
Connect the local console
(computer or terminal server) to
the SCC serial port.
Connect a Local Console to the 8860 MSR, on page 4-24
Power up and perform initial
configuration of the system.
Apply and Verify Power, on page 4-25
Table 1-1 First-Time Installation Checklist and Documentation Reference (Continued)
Task Checklist Guidelines

Tellabs 8860 Multi-service Switch Router System Installation 2-1
CHAPTER 2 Unpacking and Site
Preparation
This chapter describes the 8860 Multi-service Switch Router
shipping contents and site preparation requirements, and
provides guidelines for preparing the 8860 MSR for installation,
in the following sections:
❑ Safety Information, on page 2-2
❑ Unpacking the 8860 MSR, on page 2-2
❑ Site Preparation, on page 2-7
❑ Optical Network PLM Description and Cable Connection, on page 2-11
❑ Fast Ethernet PLM Details, on page 2-13
❑ DS3 Clear Channel and Channelized PLM Details, on page 2-14

PN 76.8860IM31-A Tellabs 8860 Multi-service Switch Router System Installation
2-2 Unpacking and Site Preparation Safety Information
Safety Information
To ensure that you install the 8860 MSR safely, observe the following guidelines:
❑Review the safety information in the Preface of this installation guide, and observe
safety admonishments provided in the notes, cautions, and warnings throughout this
manual.
❑Comply with all applicable industrial safety requirements, practices, and standards.
❑After installing the 8860 MSR, protect your equipment by using an ESD grounding
strap whenever handling system components. Follow proper grounding procedure by
first establishing an earth ground for the 8860 MSR, then attaching a wrist strap to the
ESD jack located on the
System Panel of the 8860 MSR.
Unpacking the 8860 MSR
The 8860 MSR arrives in at least two crates, one of which contains the 8860 MSR chassis,
and other(s) that contain the Switch Control Card(s) (SCCs), Universal Line Card(s)
(ULCs), and the Physical Line Modules (PLMs).
The section guides you through the unpacking process, in the following topics:
❑ Uncrate and Inspect, on page 2-3
❑ Verify Receipt, on page 2-6
❑ Returning Products to Tellabs, on page 2-6
NOTE
Begin inspecting for damage as soon as your shipment arrives. If you see
damage (such as punctures, damp spots, and crushed corners) at any
point when unpacking and inspecting, do not proceed with the unpacking
instructions in this chapter. Immediately notify the transfer company
about the damage, and record the damage on the bill of lading. Have the
transfer company’s agent acknowledge the damage by signing the bill of
lading under the damage notation.

Unpacking the 8860 MSR Uncrate and Inspect Unpacking and Site Preparation 2-3
PN 76.8860IM31-A Tellabs 8860 Multi-service Switch Router System Installation
Uncrate and Inspect
This section describes how to remove the 8860 MSR equipment from the shipping
container, and determine that you have received all expected equipment in the following
sections:
❑ 8860 MSR Crate Inspection and Disassembly, on page 2-3
❑ Accessory Box Inspection, on page 2-4
❑ Circuit Pack Crate Inspection and Disassembly, on page 2-5
8860 MSR Crate Inspection and Disassembly
When unpacking the 8860 MSR, you will first disassemble the wood crate, then remove the
chassis from its internal cardboard carton and plastic wrap as shown by the following
steps:
Step 1 Remove the packing list from the plastic envelope mounted on the outside of the
shipping crate. Use this paperwork to validate the contents after the shipping
containers are removed.
Step 2 Disassemble the wood crate.
a. Unlock each of the nine cam locks located around the perimeter of the front
panel and pull the front panel away from the crate.
b. Unlock each of the three cam locks located at the bottom rim of the rear panel,
and pull the entire crate away from the pallet and 8860 MSR cardboard carton.
Step 3 Disassemble the cardboard carton.
a. Remove the top lid and set it aside. You can now see the 8860 MSR accessory
box surrounded by protective foam pads.
b. Remove the accessory box and foam pads, and set them aside.
NOTE
Do not discard packing materials until you have completed the unpacking
procedures and verified the integrity of your 8860 MSR shipment. You
may need to reuse the packing materials if returning the product to
Tellabs.

PN 76.8860IM31-A Tellabs 8860 Multi-service Switch Router System Installation
2-4 Unpacking and Site Preparation Unpacking the 8860 MSR
Uncrate and Inspect
c. Place your hands at opposite sides of the cardboard around the 8860 MSR, and
lift the cardboard sleeve up and away from the 8860 MSR chassis. Set the sleeve
aside. You now see that the 8860 MSR is shrouded in plastic wrap.
d. Remove the plastic wrap and set it aside.
Step 4 Use standard operating procedures (per your site safety guidelines) to carefully lift
the 8860 MSR away from the shipping pallet, and place it on the ground or on a
cart for transport to the installation site.
Accessory Box Inspection
Open the 8860 MSR accessory box to ensure that you have received all items shown in Table
2-1
.
Use
Figure 2-1 to help you assemble the DC power terminal block on the rear of the 8860
MSR chassis using the items listed in
Table 2-1 . See Connector and Adapter Pinouts, on page A-18
for more information on connection and adapter pinouts needed to install the 8860 MSR.
Table 2-1 8860 MSR Accessory Box Contents
Item Description Part Number
Universal Chassis Kit ❑6-ft Ethernet
❑6-ft Null Modem
❑Two 9-pin adapters for console cable
❑Anti-static (ESD) wrist-band
grounding strap with 170 plug
termination (standard banana plug)
❑Reversible screwdriver
❑108.0007
Assembly Kit ❑10-32 and 12-24 mounting screws for
8860 MSR rack mount
❑Unterminated power cable—loose
connector, pins and in-line splice
components
❑Adapters, lugs, washer and nuts
❑108.0009
