Tema Telecomunicazioni AC-16R User manual

Revision
Date
Revision reason
Prepared
Checked/Approved
3 09/05/2020 Update GBC FL
MAS-AC-16-REV03EN Page 1 of 10
AC-16R / AC-16Q
Analog telephone line alarm
TECHNICAL MANUAL – INSTALLATION
AC-16Q / AC-16R System manual Version HW 1.1 - FW 6
PRELIMINARY DOCUMENTATION
Recommendations
1. Use only original spare parts and consumables supplied by Tema Telecomunicazioni Srl for this equipment. The company shall
not be held responsible for any damage caused by the use of materials that they have not supplied.
2. The device has been carefully manufactured and tested. In any case, the product is not recommended for use in situations in
which incorrect operating may result in damage to persons and/or property.
3. We recommend that you carefully read all this manual before starting to use the device.
4. Do not expose the device to sunlight and protect it from sources of heat, dust, humidity and chemical agents.
5. This manual is the property of Tema Telecomunicazioni Srl and any duplication and reproduction, even partial, as well as
storage on any type of media is forbidden without written permission from Tema Telecomunicazioni Srl.
TEMA TELECOMUNICAZIONI S.r.l.
Telecommunications - Electronics
Product entirely developed and manufactured in Italy

TEMA TELECOMUNICAZIONI SRL AC-16Q / AC-16R Analog telephone line alarm
MAS-AC-16-REV03EN Page 2 of 10
La sottoscritta società TEMA TELECOMUNICAZIONI SRL
con sede in Via C. Girardengo, 1/4 - 20161 MILANO
dichiara che il prodotto Teleallarme per linea di derivato interno analogico di PBX
Analog telephone line alarm
Codici AC-16Q, AC-16R
è stato costruito in conformità alle seguenti normative:
SICUREZZA EN 60950
EMC EN 55022
EN 55024
EN 61000-6-1
EN 61000-6-3
TERMINALE DI TBR 21 (1998) – Terminal Equipment (TE); Attachment
TELECOMUNICAZIONE requirements for pan-European approval for connection
to the analogue Public Switched Telephone Networks (PSTNs)
of TE (excluding TE supporting the voice telephony service) in
which network addressing, if provided, is by means of Dual
Tone Multi Frequency (DTMF) signalling.
Inoltre il prodotto sopra menzionato soddisfa i requisiti essenziali delle seguenti direttive:
• Direttiva LVD 73/23/EEC (Low Voltage Directive)
• Direttiva EMC 89/336/EEC – 92/31/ECC
• Direttiva 99/05/EC per apparati di Radio e Telecomunicazioni
MILANO, 08 Marzo 2011 TEMA TELECOMUNICAZIONI SRL
D. Pontillo
DICHIARAZIONE DI CONFORMITÀ CE
DECLARATION OF CONFORMITY CE

TEMA TELECOMUNICAZIONI SRL AC-16Q / AC-16R Analog telephone line alarm
MAS-AC-16-REV03EN Page 3 of 10
I. IMPORTANT INFORMATIONS REGARDING THE RECOVERY AND RECYCLING OF
THIS ELECTRONIC DEVICE
The crossed-out wheeled bin symbol below indicates that this electronic equipment is intended to be
disposed in a separate collection and not in an unsorted municipal waste, in order to provide for the
treatment of WEEE (Waste Electrical and Electronic Equipment) using best available recovery and recycling
techniques.
Specific treatment for WEEE is indispensable in order to avoid the dispersion of pollutants and other
hazardous substances into the waste stream, while recycling leads to reduction of disposal of waste and the
negative impacts on environment and human health. That is, priority is given to reuse of WEEE in its
components, subassemblies and consumables.
As the final holder, the user has an important role in contributing to reuse, recycling and other forms of
recovery of WEEE and is responsible to return this waste in the collection facilities set up by EC Member
Stases and to fulfill other duties in compliance with Directive 2002/96/EC and local laws.

TEMA TELECOMUNICAZIONI SRL AC-16Q / AC-16R Analog telephone line alarm
MAS-AC-16-REV03EN Page 4 of 10
1. OVERVIEW....................................................................................................................................... 5
2. CHARACTERISTICS ....................................................................................................................... 5
3. PARTS COMPRISING THE SYSTEM (PACKING LIST).............................................................. 6
4. TECHNICAL SPECIFICATIONS..................................................................................................... 6
5. DEVICE INSTALLATION ................................................................................................................ 6
5.1. W ALL INSTALLATION ...................................................................................................................... 6
5.2. C ONNECTION ................................................................................................................................ 7
6. OPERATION..................................................................................................................................... 8
6.1. I DLE CONDITION ............................................................................................................................ 8
6.2. A LARM CONDITION ........................................................................................................................ 8
7. PROGRAMMING.............................................................................................................................. 9
7.1. P ROGRAMMING THE NUMBER TO CONTACT FOR NOTICE ..................................................................... 9
Index Pag.

TEMA TELECOMUNICAZIONI SRL AC-16Q / AC-16R Analog telephone line alarm
MAS-AC-16-REV03EN Page 5 of 10
1. OVERVIEW
The AC-16 device is a small remote alarm system for analog extension of PBX (with DTMF dial
tones) that doesn’t require an external power supply since it is self-powered from the telephone
line. It can be used to signal states of emergency in hospital rooms, hotel rooms, or service centers
with people who can get help by pressing a button available to them. AC-16 can also be used in
alarm/signalling systems in industrial/corporate environments. The device, which must be
connected in series to the internal telephone extension, is responsible to inform the staff that
identifies the source of the call from the internal phone number of origin (even in the case of
multiple devices installed in the same department). The cyclical report of the alarm status can be
done with a simple tone or with a standard voice message that can be customizable in factory to
customer specifications. The maximum length of the message is 16 seconds. During
customization, it is possible to split the message into two sections of a maximum of 8 seconds
each, playable separately or linked together. This feature is useful for example to play a message
in two different languages choosing during device programming the voice message in the desired
language.
2. CHARACTERISTICS
The main characteristics of AC-16 are:
• Built into a standard telephone RJ11 socket (2 models)
• Compatible with all models of PBX on the market
• Wall mounting, replaces the normal telephone jack point for the downstream phone
• Extreme ease of installation / use
• Self-powered from the telephone line, no external power source needed
• Connection of the telephone line and alarm button on standard screw terminals
• Possibility of connecting an additional alarm silence button
• Phone call for cyclic alarm alert configurable: tone or voice message of up to 16 seconds of
duration
• Possibility of alarm stopping also from DTMF phone during an alert call
• Programming of the number to be alerted by a telephone call using DTMF tones
• Permanent data program memory (even without power)
• Internal led for signaling main device functions
• Memory of the generated alarm for detachment / temporary unavailability of the line
• Operation independent of whether or not the phone is connected downstream
AC-16R AC-16Q
AC-16
PBX
PO
Analog
Extensions
Analog
Trunk
PSTN
Generic extension or telephone wit
h
display for alarm monitoring
Alarm
button
Analog
extension

TEMA TELECOMUNICAZIONI SRL AC-16Q / AC-16R Analog telephone line alarm
MAS-AC-16-REV03EN Page 6 of 10
3. PARTS COMPRISING THE SYSTEM (PACKING LIST)
AC-16 is provided with a set of rawplugs and the user manual.
4. TECHNICAL SPECIFICATIONS
5. DEVICE INSTALLATION
5.1. Wall installation
AC-16R
• Open the case of AC-16R raising the two screws (a) and perform the wall drill in order to
secure the base of the device to the wall using normal rawplugs and screws (b).
• Secure the base of the device to the wall and set a slot for the cables doing a hole in the plastic
case of AC-16R for the arrival of the necessary cables (for connecting please refer to the
following paragraph).
• Close the case with the cover after connecting the cables and tighten the two screws (a).
AC-16Q
• Gently pull the plastic cover (c) of the AC-16Q case and remove it.
• Unscrew the two screws (a) that attach the board to the case and make the drilling of the wall
to secure the base of the device using standard rawplugs (b).
• Secure the base of the device to the wall and prepare the arrival of the cables at the slot of the
case (for connecting please refer to the following paragraph).
• After the cables are wired, screw without forcing the board in his place using the two screws (a)
• Close with the cover (c) on the wired case.
Power supply Self-powered from the telephone line
Mounting type Wall
Connections Screw terminals for line and button cable connection.
RJ11 socket for series downstream phone connection
Operative temperature -25˚C / +55˚C
Relative humidity 95% not condensing
Dimensions and weight AC-16Q (rectangular version) L51 x H57 x D21 mm, 40 gr
AC-16R (round version) L64 x H64 x D28 mm, 45 gr
a
a
b
b
a
a
Programming/alarm silencing button
a
a
a
a
b
b
Programming/alarm silencing button
c
c

TEMA TELECOMUNICAZIONI SRL AC-16Q / AC-16R Analog telephone line alarm
MAS-AC-16-REV03EN Page 7 of 10
5.2. Connection
Connect the cables as described. Connect the two pair of wires of the telephone line. Provide two
extra wires to connect external alarm button. If desired, provide two extra wires to connect an
external reset button.
•Connect the telephone line from the PBX to the LINE terminal
•Connect the two wires from the external alarm button to the ALARM terminal
•Connect the optional external reset button to the PROGRAM terminal
•The phone must be connected later on the plug outlet of AC-16 (AC-16 will be connected in
series between the existing line and the analog telephone, PHONE terminal is already
connected by the factory at the RJ11 outlet of AC-16)
•WARNING: Do not connect the telephone line to the ALARM or PROGRAM terminals. The
device can be irreversible damaged. The device is designed to operate with only one
analog phone connected downstream. It is possible to connect only dry contacts to the
ALARM and PROGRAM terminals (i.e. free from tension and references to other electrical
equipment)
AC-16R The screw terminals are accessible by removing the cover of the case
AC-16Q The screw terminals are accessible after removing the cover
and having unscrewed the two screws that attach the board to the socket
Connect here the
two wires for
PROGRAM button
LINE terminal for
the two-wire
PBX’s telephone
line
Connect here the
two wires for
ALARM button
Connect here the
two wires for
ALARM button
LINE terminal for
the two-wire
PBX’s telephone
line
Connect here the
two wires for
PROGRAM button
Internal button
for PROGRAM
and alarm silence
Internal button
for PROGRAM
and alarm silence
(on the other side of
the board)
PHONE terminal
(already
connected)
PHONE terminal
(already
connected)

TEMA TELECOMUNICAZIONI SRL AC-16Q / AC-16R Analog telephone line alarm
MAS-AC-16-REV03EN Page 8 of 10
6. OPERATION
6.1. Idle condition
When the device is in idle condition, the connected phone appears to be operating on the
dedicated telephone line. The telephone can make and receive calls in transparent mode.
6.2. Alarm condition
When the alarm button is pressed, AC-16 provides to disconnect the downstream phone, to
terminate an existing call and to dial the preset number to handle the warning. This behavior
occurs only if AC-16 has been correctly connected in series between the line and the telephone.
AC-16 will play continuous short tones or the vocal message to be recognized by the called. AC-16
waits that the called closes the cycle of warnings with the programmed sequence of DTMF digits
(this means that the emergency alert has been received and the called don’t want to be further
informed by AC-16).
If warnings are not silenced after an emergency call, AC-16 will continue the attempts to notice.
The notice can be stopped only: introducing the code of silence (the code is 32), by pressing the
silencing button if properly connected, by pressing the reset button inside the device.
The duration of each warning that by default is set at 30 sec., is programmable between 30, 60, 90
or 120 seconds at the end of which, in the absence of an occurred silencing, AC-16 will generate a
new warning.
After silencing, AC-16 returns to idle condition.
In case of disconnection or unavailability of the telephone line for some occasional reason, AC-16
remembers the alarm condition and at the return of the availability or reconnection of telephone
line, the warning call will continue.

TEMA TELECOMUNICAZIONI SRL AC-16Q / AC-16R Analog telephone line alarm
MAS-AC-16-REV03EN Page 9 of 10
7. PROGRAMMING
7.1. Programming the number to contact for notice
To access to the AC-16 programming, from the idle state, press the external silencing button (if
connected) for a while or press the PROGRAM button inside the plastic case of the device. The
condition of the system ready for programming is signaled by the unique led on the card placed
inside the case. For all the time that the led stays on (15 seconds) the device can be called to his
number and AC-16 will answer to allow its programming.
The call must be made from another extension number, using a standard DTMF telephone. At the
response of AC-16 and after a beep is heard, introduce the code of the programming password
(pwd = *1235), wait for the confirmation beep and insert the phone number that must be
programmed. Once the number was inserted, press # to confirm and wait for another confirmation
beep. At this point it is possible to select the alarm notification mode by choosing: the digit "0" for
alarm notification with simple tone, the digit "1" for alarm notification with voice message 1, the digit
"2" for alarm notification with voice message 2, the digit "3" for alarm notification with voice
message 1+2 (concatenated). Wait for the confirmation beep. The memory space for voice
messages of 16 seconds is logically divided into two sections of 8 seconds each, where the first
section contains the message 1 and the second one contains the message 2.
Choose between the digits 0-1-2-3 the value for the desired time of alarm notification, 0=30”,
1=60”, 2=90”, 3=120” and hang up.
Example: - press the internal reset button (or external if connected), the led will light
- call the extension number where AC-16 is connected within 15 seconds
- heard a beep, enter * 1235 to access to the number programming
- heard the beep for confirm of entering programming, enter the number phone to
alert, press #to confirm and wait for the confirmation beep
- introduce now the digit "0" or "1" or "2" or "3" to program the desired alarm
notification mode (0=tone, 1=message 1, 2=message 2; 3=Message 1 +2, wait for
the confirmation beep
-introduce now the digit "0" or "1" or "2" or "3" to program
how long AC-16 will notify the alarm before hanging for time out
(0=30 seconds, 1=60 seconds, 2=90 seconds, 3=120 seconds).
- wait for the confirmation beep, AC-16 will close the call and will retain the
introduced parameters
It is possible to input the character * (star) in the number to call to get a dialing pause of 500
milliseconds for each * digit introduced.
The maximum field length of the number to call is fixed at 20 digits (including * digits).
If you get into programming and you do not make the introduction of a new number to call or do not
end with #the number introduced, it is like not having done any programming, and the old number
will remain in memory.
If, however, after confirming the entered number with the #character and heard the beep of
confirmation will not be introduced additional characters, there will be no change to the previous
programmed mode of how AC-16 will notify the alarm (tone or voice message).
Finally, if you also confirms how AC-16 will notify the alarm will not be introduced additional
characters, there will be no change to the previous programmed time alarm notification.
During programming, AC-16 waits 15 seconds from the last command received, then close the
communication breaking down the programming state.

TEMA TELECOMUNICAZIONI SRL AC-16Q / AC-16R Analog telephone line alarm
MAS-AC-16-REV03EN Page 10 of 10
REMARKS:
