HY603-WIFI Digital Heating Thermostat User Manual
Search for "Smart RM" “Smart Heating
“Download the Wi-Fi App with the following
icon
Turn on the thermostat press and hold the
key combination “ ” and “ ” Activate
WIFI distribution network icon
The App advanced password is 123456
Features
Appearance
1. Standard total Size is 86*86mm 6. Touch buttons to make simple
2. Display size: 64*64mm operation
3. The visible thickness above the wall is only 15mm
4. 86mm hidden box and 60mm European box
5. Color: white& black
Functions
(A) Including built-in sensor and external sensor
(B) 0.5°C accuracy keeps temperature within the level you set
(C) Children lock to prevent misoperation by children
(D) Data memory when power is off
(E) Holiday mode make you change the temperature in holiday
(F) Floor or external temperature can be measure through external NTC sensor
Product Specifications
☆ Power:200-240Vac 50/60HZ ☆ Range of temperature display:：0~40°C
☆ Display accuracy:：0.5°C ☆ Insulating condition: Normal environment
☆ Probe sensor:：NTC(10k)1% ☆ Running program: Set per 1 week as a cycle
☆ Contact capacity:：5A/250V(WH);16A/250V(EH) ☆ Output: Switch relay
☆ Working environment temperature:：0~90°C ☆ Installation: Wall mounted or on battery seat
☆ Range of temperature adjustment:：5~35°C ☆ Size(mm)：86*86*27
Before wiring and installing
1. Read these instructions carefully. Failure to follow them could damage the product or cause a
hazardous condition.
2. Check the ratings given in the instructions and on the product to make sure the produce is suitable
for your application.
3. Installer must be a trained experienced service technician.
4. After installation is complete. Check and follow the operation sequence as provided as per
instructions
CAUTIO
Electrical shock or equipment Damage Hazard. or short equipment circuitry.
Disconnect power supply before installation
Wiring Diagram
Electric heating wiring diagram Water heating wiring diagram
(do not connect terminal "close 4" of electric valve)
Water heating and gas wall-hung boiler heating
no contact wiring diagram (disconnection when electric valve close)
ote:3 & 4 connect with power, 5 & 6 connect with gas boiler,1& 2
connect with thermal actuator, please do not connect 1&2 to gas boiler,
this may cause boiler board damaged.
Displays
Description of icon
Auto mode; run preset program Manual mode
Temporary manual mode Clock
Holiday mode Holiday days and temperature can be set to run in countdown mode
Heating icon disappears to stop heating External NTC sensor
WIFI connection flashing EZ distribution mode Child lock
Wi-Fi status: Disconnection Cloud icon: flashing AP distribution network mode
=
=

Operation key
O symbols represent
A
Turn ON/OFF: Short press to turn on/ turn off
B
1 Short press
to switch automatic mode and manual mode
2 Turn on thermostat long press for 3-5 seconds to enter into programmable
setting
3. Turn off thermostat long press for 3-5 seconds to enter into advanced setting
C
1 Confirm key: use it with
key
2 Only short press it to set time
3 Turn on thermostat long press it for 3-5seconds to holiday mode setting. Appear
OFF press or change to ON then press to confirm opening holiday mode
B
1 Decrease key
2 Long press to lock /unlock
D
1 Increase key :
2 Long press to inquire external sensor temperature
3 In the Auto model press or enter to temporary manual mode
Programmable
5+2 (factory default) 6+1 and 7 models 6 times period setting for user choose. In the advanced options
choose model of you need under power on state long press for 3-5 seconds enter into programming
mode setting then short press choose: hour minute time period and press and to adjust
data finished setting about 10 seconds will automatic save and exist.
Wake up
Outdoor Back home Outdoor Back home Sleep
6：00 20℃ 8：00 15℃ 11：30 15℃ 13：30 15℃ 17：00 15℃ 22：00 15℃
The optimum comfort temperature is 18℃-22℃.
Advanced options
Under turn off state long press for 3-5 seconds to access advanced setting.
From A1 to AD short press to choose the option and adjust data by short press to switch
next option. Remain about 5 seconds after finish setting will quit setting.
NO Setting Options Data Setting Function Factory Default
A1 Measure Temperature
Calibration -9-+9℃ 0.5℃ Accuracy Calibration
A2 Temperature control
return difference setting
0.5-2.5℃ 1℃
A3
External sensors limit
temperature control
return difference
1-9℃
2℃
A4 Options of sensor control N1:Built-in sensor (high temperature protection NI
close)
N2:External sensor (high temperature protection
close)
N3:Built-in sensor control temperature external
sensor limit temperature (external sensor detect
the temperature is higher than highest
temperature of external sensor thermostat will
disconnect relay turn off load)
A5 Children lock setting 0:half lock 1:full lock 0
A6
Limit value of high
temperature for external
sensor
1. 35℃-70℃
2. Under 35℃ screen display【--】, high
temperature protection was canceled
45℃
A7
Limit value of low
temperature for external
sensor(anti-freeze
protection)
1. 1-10℃
2. Exceed 10℃ screen display【--】, Low
temperature protection was canceled. 5℃
A8 Setting temp lowest limit 1-10℃ 5℃
A9 Setting temp highest
Limit
20-70℃ 35℃
AA Descaling function
0:Close descaling function
1:Open descaling function（valve is continuously
closed over 100 hours，it will be opened for 3
minutes automatically）
0:Close
descaling
function
AB
Power with memory
function
0:Power with memory function
1:Shutdown power after power off
2:Shutdown power after power on
0:Power with
memory
function
AC
Weekly programming
selection
0: 5+2
1: 6+1
2: 7
0: 5+2
AD Restore factory defaults Display A o press key whole show
AE Time setting of turn on
night light (HY311 model)
1: 00:00-23:30 & 2: 00: 00 press” and
display-- it means cancel night light function 18:00
AF Time setting of turn off
night light (HY311 model)
1: 00:00-23:30
6:00
Return difference : Max limit value of external sensor is 45℃ for factory default (A6) value of external
sensor control return difference (A3) is 2. when temperature rise to 45℃ the relay stop working and
trigger high temperature alarm. If temperature drop to 43℃ then relay continue to work and heating
alarm will go off. (on that event the operation of heating resume only when indoor temperature is lower
than setting temperature i-e heat demand)
Sensor fault display : Please ensure to have correct way of working for built-in and external sensor if
connect wrongly or sensor fault (breakdown) “E1” or “E2” will be displayed on the screen. Thermostat
will stop heating until the fault is eliminated.
Warranty：We offer operation warranty of 18 months from date of sales to cover any issue due to quality
and workmanship defect. service.
