Tempur-Pedic Sleeptracker-AI TEMPUR ERGO SMART User manual

OWNER’S MANUAL
MANUEL DU PROPRIÉTAIRE
Tempur-Pedic Customer Service U.S. : 1-844-309-3597 | Canada : 1-800-887-4321 | México: 01-722-273-1810
Service à la clientèle Tempur-Pedic É-U. : 1-844-309-3597 | Canada : 1-800-887-4321 | México: 01-722-273-1810
Servicio al Cliente Tempur-Pedic É-U. : 1-844-309-3597 | Canada : 1-800-887-4321 | México: 01-722-273-1810
MANUAL DEL PROPIETARIO
TEMPUR ERGO®SMART

table of contents
Safety Precautions and Usage Statements ......................................................1-4
Parts List ...................................................................................... 5
Base Overview ................................................................................ 6
Quick Reference Guide ..........................................................................7
Installation Guide ............................................................................8-10
Remote Control .............................................................................11-13
USB Charging .................................................................................14
Connecting Strap ..............................................................................15
Syncing Two Bases (Optional)...................................................................16
Headboard Brackets (Optional) .................................................................17
Emergency Battery Backup Strap ...............................................................18
Troubleshooting ...............................................................................19
Warranty ...................................................................................20-21

table des matières
Consignes de sécurité et directives d’utilisation ................................................. 22-25
Liste des pièces .................................................................................. 26
Aperçu de la base ............................................................................... 27
Guide de référence rapide ........................................................................ 28
Guide d’installation ............................................................................29-31
Télécommande ............................................................................... 32-34
Recharge USB ....................................................................................35
Attaches de raccordement ....................................................................... 36
Synchronisation de deux bases (facultative) ........................................................ 37
Fixations de tête de lit (facultatives) ............................................................... 38
Sangle des piles de secours ....................................................................... 39
Dépannage .......................................................................................30
Garantie...................................................................................... 40-41

tabla de contenidos
Precauciones de Seguridad. ..............................................................................42-46
Lista de las Partes...........................................................................................47
Diagrama de la Base .......................................................................................48
Diagrama de Conexiones. ...................................................................................49
Instalación de la Base ...................................................................................50-52
Control Remoto .........................................................................................53-55
Carga USB .................................................................................................56
Correas de Conexión ........................................................................................57
Sincronización de Dos Bases. ................................................................................58
Guía de Instalación de Soportes de la Cabecera (Opcional) .....................................................59
Correa de Respaldo de la Batería ............................................................................60
Solución de Problemas. ......................................................................................61
Garantía.................................................................................................62-63

1
safety precautions and usage statements
Attention: Important Safety Disclaimers
Read all instructions before using your TEMPUR ERGO®SMART POWERED BY SLEEPTRACKER-AI®adjustable base.
SAVE THESE INSTRUCTIONS.
WARNING
To reduce the risk of shock, burns, fire or injury:
Always unplug the base from the electrical outlet before servicing any
part of the base. To reduce risk of electric shock, unplug the base before
cleaning. To safely disconnect, ensure the base is in a flat position with all
motors o, and unplug from power source.
Keep the power cord away from heated surfaces. Never operate the base
when the air openings are blocked. Keep air openings free of lint, hair and
the like. Do not drop or insert any object into any opening.
Discontinue use of the bed base and contact a qualified service center if: it
has a damaged cord or plug, is not working properly, or has been dropped
into water.
Only use this bed base for its intended use as described in this manual.
Do not use accessories/attachments that are not recommended by the
manufacturer.
Close supervision is required when the bed base is used by or near children,
convalescents or disabled persons.
Outlet Safety:
For optimal safety and operation, plug bed base into a
surge protector (not included).
The bed base should only be plugged directly into a wall outlet or surge
protector (recommended). Improper connection of the equipment can result
in the risk of electrical shock, electrical fire or faulty operation of this bed
base. If the plug does not fit your outlet, contact a qualified electrician to
install a suitable outlet. Unauthorized modification or failure to use a wall
outlet or surge protector could void the electrical portion of your warranty.
Warranty Warning:
Do not open or tamper with control box, motors, or remote (with the
exception of battery compartments). The warranty will be void if the internal
workings of these components are tampered with. For complete warranty
information refer to the warranty information section on pages 20-21.
In-Home Use and Hospital Disclaimer:
The Tempur Ergo bed base is designed solely for in-home use. This base
was not designed as a hospital bed and is not designed to meet hospital
standards.
Do not use this base with TENT TYPE oxygen therapy equipment or
near explosive gases.
Children and Pets:
Children and pets can be crushed or killed if they become entrapped in
moving parts of the bed. Before you reposition the base, check to be sure
children and pets are not near or under the base. Do not teach children to
operate the remote. Engage child lockout on the remote before leaving the
room. (See p. 13) Store the remote where children can't find it. Children
should not operate this product without adult supervision. To avoid injury,
children and pets should not be allowed to play on or under the bed.
Immediately dispose of all packaging materials as they may pose a
smothering risk to children and pets.
Safety Features:
Manual operation – If something gets caught in the platform when flattened,
you can manually raise the platform up by lifting at both the head and foot
to relieve pressure and allow for release.
Child-lockout – This remote control is programmed with a child-lock safety
feature. Information on activation and deactivation of this feature can be
found on the Remote Control page(s) and on the back of your remote
control.
Emergency stop – Stop the motion of the platform by pressing any button
on the remote control or by pushing the button on the Battery Backup Box
located underneath the base.
Power outage – Use the “Emergency Battery Backup Box” as a temporary
power source to get the base to a desired position. Instructions on how
to operate the Battery Backup Box are on the Emergency Battery Backup
page(s).

2
Power Ratings:
INPUT: AC 100–240V 50/60 HZ 2.0A
OUTPUT: DC 29V 2.0A
WATTS: 58W
Product Ratings:
The lift motors are not designed to operate continuously for more than two
[2] minutes in an eighteen [18] minute time period or approximately 10% duty
cycle. Attempting to circumvent or exceed this rating will shorten the life
expectancy of the product and may void the warranty.
The massage motors are not designed to operate continuously for more
that 30 minutes at a time. Please allow the massaging system to rest for 30
minutes after automatic massage shut o before restarting.
Weight Limits:
The recommended weight limits on theTEMPUR ERGO®SMART POWERED
BY SLEEPTRACKER-AI®are: Twin Long / Full / Queen / King / Split CA King /
CA King: 750 pounds.
Maximum weight the bed can support per person is 275 pounds with the
weight evenly distributed across the head and foot sections. This product
is not designed to support or lift this amount of weight in the head or foot
sections alone.
NOTE: Exceeding the recommended weight restrictions could damage your
TEMPUR ERGO®SMART POWERED BY SLEEPTRACKER-AI® and void your
warranty. For best performance, you should enter and exit the TEMPUR
ERGO®SMART POWERED BY SLEEPTRACKER-AI®while it is in the flat or
fully lowered position.
TEMPUR ERGO®SMART POWERED BY SLEEPTRACKER-AI®fits easily inside
bed frames, furniture beds and platform beds that are certified to hold a
minimum of 900 pounds. If using this adjustable base without the legs and
placing directly on a bed frame or platform bed, cross-bed supports (slats)
are strongly recommended to ensure TEMPUR ERGO®SMART POWERED BY
SLEEPTRACKER-AI®maintains stability during operation.
Exceeding this weight restriction could damage the bed
and/or cause injury and will void the warranty.
Acoustics:
In normal base operation the wheels, which allow the bed to maintain its
distance from the wall, will make contact with the steel platform supports of
the base creating a contact noise. When entering, exiting or shifting weight
on the base, this contact noise may be audible as the wheels make contact.
This is normal.
Fabric Care:
To prolong the life of your fabric, protect from direct sunlight whenever
possible. For spot cleaning, wipe area with a light damp sponge or vacuum
with a soft brush attachment to remove particles. Keep at a minimum of
30cm (12 inches) away from direct heat sources.
For deeper cleaning, blot liquid spills with a clean dry cloth. Wipe with a clean
cloth dampened with warm water. Do not wet excessively. A soft bristle brush
may be used to remove ingrained soil. Avoid scratching by gentle brushing.
Wipe with a clean cloth dampened with warm water to remove residues after
brushing. Dry in shade away from direct heat.
If persistent marks remain visible after cleaning, seek professional advice.
FCC Compliance:
NOTE: This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to part
15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which
can be determined by turning the equipment o and on, the user
is encouraged to try to correct the interference by one or more of
the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from
that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for
help.
CAN ICES-3 (B)/NMB-3(B)
safety precautions and usage statements

3
Tempur®Sleeptracker-AI®System
For TEMPUR ERGO® SMART
System Components
Sleeptracker-AI®Sleep Monitoring System Model STS-60 / STS-60A :
- One Sleeptracker-AI®Processor Units
- One or two Sleeptracker-AI®Sensors*
Quick Start Card with QR code
Safety and Warranty Information
*Note: the number of sensor units included depends on the particular
TEMPUR ERGO®SMART POWERED BY SLEEPTRACKER-AI®size purchased.
Specifications
Sleeptracker-AI®Sleep Monitoring System Model STS-60 / STS-60A:
- Input Power: 5V DC, 1.5A
WLAN:
IEEE802.11a/b/g/n/ac
Wi-Fi frequency range:
2.4 GHz ISM Bands 2.412-2.472 GHz
5.15-5.25 GHz (FCC UNII-low band) for US/Canada and Europe
5.25-5.35 GHz (FCC UNII-middle band) for US/Canada and Europe
5.47-5.725 GHz for Europe 5.725-5.825 GHz (FCC UNII-high band) for US/
Canada
Wi-Fi AP channel:
802.11b:
USA, Canada and Taiwan – 1 ~ 11
Most European Countries – 1 ~ 13
802.11g:
USA and Canada – 1 ~ 11
Most European Countries – 1 ~ 13
802.11n:
USA and Canada – 1 ~ 11
Most European Countries – 1 ~ 13 802.11a:
USA – 36, 40, 44, 48, 52, 56, 60, 64, 100, 104, 108, 112, 116, 120, 124, 128, 132, 136,
140, 149, 153, 157, 161, 165
Output Power (Board Level Limit):
2.4G
Min Typ Max Unit
11b (11Mbps) @EVM<35% 14 16 18 dBM
11g (54Mbps) @EVM≦-27 dB 12 14 16 dBM
11n (HT20 MCS7) @EVM≦-28 dB 11 13 15 dBM
11n (HT40 MCS7) @EVM≦-28 dB 10 12 14 dBM
5G
Min Typ Max Unit
11a (54Mbps) @EVM≦-27 dB 11 13 15 dBm
11n (HT20 MCS7) @EVM≦-28 dB 8 10 15 dBm
11n (HT40 MCS7) @EVM≦-28 dB 8 10 12 dBm
11ac (VHT20 MCS8) @EVM≦-30 dB 8 10 12 dBm
11ac (VHT40 MCS9) @EVM≦-32 dB 7 9 11 dBm
11ac (VHT80 MCS9) @EVM≦-32 dB 6 8 10 dBm
Bluetooth Standard:
BT4.2+Enhanced Data Rate (EDR)
Bluetooth 5 support
Bluetooth frequency range:
2402MHz~2483MHz
Output Power:
Min Typ Max Unit
BDR 0 2 4 dBm
EDR -4 -1 1 dBm
Low Energy 0 2 4 dBm
Certifications:
- FCC Part 15B, FCC Part 15C
- ISED ICES-3(B)/NMB-3(B), RSS-Gen, RSS-102, RSS-210
© 2023 Tempur Sealy International, Inc.
All rights reserved. Tempur-Pedic®is a registered trademark of Tempur Sealy
International, Inc. TEMPUR ERGO®SMART is a trademark of Tempur Sealy
International, Inc.
© 2005–2023 Fullpower Technologies, Inc.
All rights reserved. U.S. and international patents granted and pending.
Sleeptracker-AI®is a trademark of Fullpower Technologies, Inc., registered in
the U.S. and other countries.
For assistance visit our web site: www.sleeptracker.com
Services and app availability are subject to change at any time, may not be
available in all areas and may require separate subscriptions.
This product is not a medical device and should not be used to diagnose or
treat any medical condition.
Designed in Santa Cruz, California
Made in China
safety precautions and usage statements

4
safety precautions and usage statements
System Requirements:
• Mobile device running iOS or Android
• Existing Wi-Fi network
Requires Tempur®Sleeptracker-AI®app from Fullpower Technologies, available
on the Apple App Store or on Google Play. Requires Wi-Fi connection to your
home network, and Internet access via a router or modem.
Apple and the Apple logo are trademarks of Apple Inc., registered in the U.S.
and other countries. App Store is a service mark of Apple Inc., registered in
the U.S. and other countries. iOS is a trademark or registered trademark of
Cisco in the U.S. and other countries and is used under license.
Google Play, Android and the Google Play logo are trademarks of Google Inc.
100–240 V AC 50/60 Hz
FCC ID: 2AF2O-STS60
IC: 20700-STS60
Tempur-Pedic North America, Inc.
1000 Tempur Way
Lexington, KY 40511
Tempur-Pedic Canada
145 Milner Ave.
Scarborough, Ontario M1S 3R1
FCC Certification Statement
This equipment complies with Part 15 of the FCC Rules. Operation of this
equipment is subject to the following two conditions: (1) the equipment may
not cause harmful interference, and (2) the equipment must accept any
interference that might cause undesired operation.
Important: Any changes or modifications not expressly approved by Tempur
Sealy International (”Tempur”) could void the electromagnetic compatibility
compliance and negate your authority to operate this equipment.
This equipment was tested for FCC compliance under conditions that
included the use of Tempur peripheral devices and Tempur cables and
connectors between system components. It is important that you use Tempur
cables and connectors between system components to reduce the possibility
of causing interference to radios, television sets, and other electronic devices.
You can obtain proper Tempur cables and connectors through an Tempur-
authorized dealer.
Responsible party (contact for FCC matters only):
Tempur-Pedic North America, Inc.
1000 Tempur Way
Lexington, KY 40511
Sleeptracker-AI®Sleep Monitoring System model STS-60 / STS-60A FCC ID:
2AF2O-STS60
Industry Canada Statement of Compliance
This device complies with Industry Canada license-exempt RSS standard(s).
Operation is subject to the following two conditions: (1) this device may not
cause interference, and (2) this device must accept any interference, including
interference that may cause undesired operation of the device. This device
complies with ICES-003 Class B specifications of Industry Canada.
Responsible party (contact for Industry Canada matters only):
1390658 Ontario Inc (Tempur Canada)
145 Milner Ave.
Scarborough, Ontario
M1S 3R1
Sleeptracker-AI®Sleep Monitoring System model STS-60 / STS-60A
IC: 20700-STS60.
Exposure to Radio Frequency Energy
This equipment complies with radiation exposure limits set forth in the FCC’s
KDB 447498 and ISED RSS-102 standard for an uncontrolled environment.
This equipment should be installed and operated with minimum distance of
20cm (about 8 inches) between the radiator and your body. This equipment
must not be co-located or operating in conjunction with any other antenna or
transmitter.
Pacemaker Notice
If you use a medical device such as a pacemaker or implantable cardioverter-
defibrillator (ICD), please consult your physician before using this product.

5
A) B)* C)
D) E) **
)‡* )
parts list
All electronics and components that need to be installed are
located in boxes under the base or attached to the frame.
A) Wireless Remote Control (1)
AAA Batteries (2)
B) Mattress Retainer Bar (1)*
C) Legs (6)
D) Power Cord (1)
E) Power Supply (1)
F) Battery Backup Strap (1) **
(9 Volt alkaline batteries not included)
G) Connecting Strap ‡*
Miscellaneous Parts (not included):
H) Surge Protector (1)
I) 9 Volt alkaline batteries (2)
Before discarding the packing materials, ensure all the parts are accounted for.
A
D
G
B
E
C
F
* These items are attached to the base for shipping purposes.
Carefully remove from base and set aside.
** Leave connected to the Power Supply.
‡ Only included in Twin Long and Cal King Split
*

6
base overview
Foot Motor
Head Motor
Control
Box
USB
Ports
Sleeptracker-AI®
Sensor
Sleeptracker-AI®
Sensor
USB Ports
Massage Motor
Massage Motor
Lumbar Motor Under Bed
Light
Under Bed
Light
Under Bed Light
Sleeptracker-AI®
Processor
To access all the features of your smart base, please download the TEMPUR®SLEEPTRACKER-AI®App and setup using the
QR code found on the back of the remote control.

7
Not to scale. For illustration purposes only. Read all instructions before beginning installation.
quick reference guide
USB Charging
Ports
Remote Control Battery
Backup Strap
Sleeptracker-AI®
Sensors
LED Brand
Badge
Control Box
Sleeptracker-AI®
Processor
Under Bed
Lighting
Massage Motors
Power Supply Power Cord
Foot Motor
Head Motor
Lumbar Motor
Input Cord
POWER
FOOT LUMBARHEAD
MULTIFUNCTION
21HEAD VIBRATIONFOOT VIBRATION 3

8
installation guide
STEP 1
STEP 4
STEP 2
Always use two people when setting up the base.
Place the bed base box in a desired location with the bottom
of the box facing up.
Remove the binding straps and packing materials, making sure
not to puncture the box with any sharp objects.
Remove the bed base from the box. Unfold the bed making
sure to keep the bottom of the bed facing upwards.
STEP 3
To sync two bases see detailed installation
instructions on pages 15-16.
To install Headboard Brackets (sold separately)
see instructions on page 17.
It is recommended to leave the
battery backup strap attached to the
power supply for use when needed.
Two 9V batteries (not included) will
be required for its use.
Legs are shipped fully assembled. To install the legs, check
to make sure all segments are assembled together tightly.
Alternative heights in 3" increments can be achieved by removing
leg segments from the top of the leg accessory. Thread the leg
into the frame, and tighten by hand. Do not over tighten.

9
installation guide
STEP 7
STEP 8
STEP 9
STEP 10
Carefully flip the base over on to its legs. Important: Two
people are required to move the bed base. Do not drag
across the floor. Do not rest frame on its side, excessive
pressure may damage the legs.
Plug the Power Cord into a power source. A surge protector is
recommended.
Ensure that batteries are correctly installed in the remote.
Quickly test remote functions to verify proper setup before
placing mattress on base. Return the base to a FLAT position
before placing the mattress on top.
To install the mattress retainer bar, insert each end of the bar
into the holes at the foot of the platform.
STEP 5
STEP 6
Uncoil Input Cable (connected to Control
Box’s power port) and plug into Power
Supply.
Uncoil the Power Cord and connect to
the Power Supply. Place Power Supply
on the ground and extend from the base.
Ensure that the Power Supply and all
attached cords are directed toward the
desired surge protector.

10
installation guide
STEP 11
STEP 12
STEP 13
Using the remote, move the head of
the base to its full upright position.
Confirm that the LED on the black
Sleeptracker processor is blinking
green. This may take up to 90
seconds after connecting power to
the Smart Base. This indicates that
the processor is powered up and
ready to connect to a WiFi network.
The customer should scan
the QR code on the remote
control packaging (A) or
on the rear side label of the
remote control (B) to set up
the Sleeptracker App. or
(A) (B)
To complete the Smart Base setup, download the TEMPUR®
SLEEPTRACKER-AI®App and follow the in-app prompts.
Once the app is connected, it will allow access to the full
functionality of your new TEMPUR ERGO®SMART POWERED
BY SLEEPTRACKER-AI®.
Setup is now complete! Test all functions on remote.

11
Remote control arrives paired to the adjustable base.
Two (2) AAA batteries are required to operate the remote.
remote control
IMPORTANT!: For your safety, read the owner’s manual
carefully and completely before operating this product.
Electric shock may occur if electrical components are not
installed or operated according to these guidelines.
ADJUST
Head Position Adjustments
Use to raise and lower the head section of your
adjustable base.
Foot Position Adjustments
Use to raise and lower the foot section of your
adjustable base.
Lumbar Adjustments
Use to increase or decrease lumbar support.

12
MASSAGE
Head Zone Massage Control
Activates simple steady-state massage and toggles
through 2 intensity levels. Low, high and o.
Foot Zone Massage Control
Activates simple steady-state massage and toggles
through 2 intensity levels. Low, high and o.
Massage Wave Mode Control
Turns on and activates programmed massage
mode. Toggles wave modes 1, 2 ,3 and o. Intensity
default to low.
Press the Massage Wave Mode Control button to choose the desired
mode (1,2,or 3), then use the Head Zone Massage Control and/or the
Foot Zone Massage Control buttons to cycle through the available
intensity levels. Once the massage wave mode is chosen, it will run
for 30 minutes unless it is cancelled by pressing the Massage Wave
Mode Control button repeatedly until massage stops.
If one of the wave massage modes is not needed, pressing Head
and/or Foot Zone Massage buttons will initiate massage for those
zones and cycle through 2 different intensity levels as well as "OFF".
remote control
Remote control arrives paired to the adjustable base.
Two (2) AAA batteries are required to operate the remote.
PRESET
Zero-G®‡
Adjusts your legs to relieve pressure o the lower
back.
Flat *
One-Touch Flat lowers head and foot to flat position
and turns o massage (if running).
TV in Bed Preset Position ‡
Brings head and foot into position for viewing TV.
QuietMode™ Preset Position ‡
Help relieve snoring for you or your partner with the
push of a button, gently tilting the mattress position
to help reduce snoring.
Favorite 1 & 2 Preset Positions‡
Reprogrammable Preset Positions.
Underbed LED lighting *
Press to turn on/o underbed LED lighting. Press
and hold for three (3) seconds to turn o LED brand
badge.
* Not user programmable.
‡ Can be reprogrammed to user desired position.
The ZERO-G®, TV in Bed, Anti-Snore, and Favorite 1 in bed presets
can be re-programmed to any position chosen by the user. Simply
adjust the bed to the desired position, then press and hold any of
the 4 buttons down until the remote backlight flashes twice. The
button is now re-programmed.
To restore the buttons to their original positions, press and hold the
One-touch Flat and Zero-G®buttons simultaneously for 5 seconds.
The remote backlight will flash twice to indicate the original
positions have been restored.

13
Child Lock Feature
Remote Pairing
Activate Child Lock
Deactivate Child Lock
remote control
Test all remote functions. If the remote buttons do not impact
the adjustable base movements, please repeat the process
again or call customer service: U.S. 1-800-499-1965 | Canada
1-800-268-4414
STEP 1
STEP 2
The original remote that comes in the box is already paired to
the adjustable base. No further action is required. In the event
that the remote is not paired with the base, follow the steps
below.
Children and pets can be crushed or killed in moving parts
of the bed! For safety purposes, the child lock function locks
the remote control to prevent any accidental button presses
and bed movements. Engage child lock on the remote control
before leaving the room.
STEP 3
Remove rear cover of the remote control by sliding it down
to expose the PAIR button. Unplug the Power Cord from
your power outlet. Wait 1 minute, then plug it back in to your
power outlet. Perform Step 2 within 10 seconds, while the
control box light is flashing.
Power Cord
Control Box LED
Power Supply
Press and hold the PAIR button on the
back of the remote. The PAIR button will
illuminate and start to flash. When the
PAIR button stops flashing, the LED light
on the control box will stop flashing.
Release the PAIR button.
Press and hold dedicated Child Lock button for
three (3) seconds.
The remote LED will flash twice to confirm
activation. When any button is pressed on
the remote while in child lock mode, the LED
illuminates for two (2) seconds or while button
is pressed.
*Child Lock feature will be deactivated when
batteries are removed.
Press and hold dedicated Child Lock button
and the Underbed Lighting button together for
three (3) seconds.
The remote LED will flash once to indicate the
remote is no longer in Child Lock. The remote
and adjustable base will work normally.
+
WARNING

14
USB Charging
The Type-A USB connector is a
standard USB port, used for standard
cable connection interface for personal
computers and consumer electronics
devices.
The Type-C USB connector is a smaller
USB port.
TYPE-A CONNECTOR (STANDARD USB) TYPE-C CONNECTOR
The USB charger is configured with 2 connectors, Type-A and Type-C connector.

15
connecting strap
With the bases in their desired
location, slightly loosen both
legs to allow the strap to fit on
the leg bolt, between the leg
washer and frame.
Slide side (a) of the Connecting Strap onto leg bolt. Swing the
strap and connect side (b) to the leg bolt. Secure the strap by
shifting to the left.
Re-tighten legs. Do not over tighten. Use the remaining strap
and repeat on other end of the base.
STEP 2
STEP 1
STEP 3
a b
If any split setup is being installed, plastic Connecting Straps are provided (one per base) to secure the
bases together.

16
To sync two bases wirelessly, please refer to the below instructions. The remote controls must be paired
to their respective control boxes prior to completing this step. Refer to page 13 for specific instructions.
syncing two bases (optional)
• If bases become mismatched, pressing the FLAT button
will re-sync the mechanical positions.
1. Press and hold the Remote A Sync button until the
button light blinks and then release the button.
2. At this time, Remote A will return to the single
communication with Base A. The bases are no longer
synced.
3. When users operate Remote B, Remote B will wake up
from hibernation and find that Base A has resumed the
single communication, and thus Remote B will return to
single communication with Base B.
PERFORMANCE NOTES
To un-sync two bases:
Unplug bases from power outlet. Wait 1 minute, then plug it
back into your power outlet.
Press and hold the SYNC button on the
back of both remotes simultaneously.
The SYNC buttons will illuminate and
start to flash. When the SYNC buttons
stop flashing, release the SYNC
buttons. Bases are now synced.
Sync
Button
Test all remote functions. If the remote buttons do not impact
both adjustable base movements, please repeat the process
again or call customer service: U.S. 1-800-499-1965 | Canada
1-800- 268-4414
STEP 1
STEP 2
STEP 3
