Tenergy 58062 User manual

INFRARED
THERMOMETER
USER MANUAL
PN 58062

Please read these instructions carefully before
using this product and keep these instructions
in a safe place
WHAT’S IN THE BOX
2x AAA Battery User Manual Storage PouchThermometer

TABLE OF CONTENTS
WARNING AND PRECAUTIONS
APPEARANCE OF THE PRODUCT
MEASUREMENT STANDARDS
USING THE PRODUCT
ADDITIONAL FUNCTIONS
CARE AND STORE
SPECIFICATIONS
FAQS
EMC INFORMATION
1
3
4
5
8
10
10
11
12

Use of this thermometer is not intended as a substitute for
consultation with your physician.
Keep out of reach of children under 12 years old.
Never use the thermometer for purposes other than those it
has been intended for. Please follow the general safety
precautions when using on children.
Never immerse the thermometer into water or other liquids (this
thermometer is not waterproof).
Do not store this thermometer in temperature extremes below
-13°F or over 140°F(below-25°C or over 60°C) or in excessive
humidity (above 95% non-condensing relative humidity).
If thermometer is stored in a location that is cooler or warmer
than where it is being used, let it reach room temperature for
10 minutes before taking a measurement.
Do not use the thermometer if there are signs of damage on
the sensor or on the thermometer itself. If damaged, do not
attempt to repair the product.
Never insert a sharp object into the sensor or any other open
surface on the thermometer.
This thermometer consists of highprecision parts. Do not drop
the instrument. Protect it from severe impact and shock.
This thermometer is intended for household use only.
Temperature elevation may signal a serious illness, especially
in neonates and infants, or in adults who are old, frail, or have a
weakened immune system. Please seek professional advice
immediately when there is a temperature elevation and if you
are taking temperature on:
Neonates and infants under 3 months (Consult your
physician immediately if the temperature exceeds 99.4 °F
[37.4 °C]).
Patients over 60 years of age (Fever may be blunted or
absent in older patients).
Patients with Diabetes Mellitus or a weakened immune
system (e.g., HIV positive, cancer chemotherapy, chronic
steroid treatment, splenectomy).
Patients who are bedridden (e.g., nursing home patient,
stroke, chronic illness, recovering from surgery).
A transplant patient (e.g., liver, heart, lung, kidney).
This thermometer is not intended for pre-term babies or
small-for-gestational age babies.
This thermometer is not intended to interpret hypothermic
temperatures.
Do not allow children to take their temperatures unattended.
Please consult your doctor if you see symptoms such as
unexplained irritability, vomiting, diarrhea, dehydration,
changes in appetite or activity, seizure, muscle pain, shivering,
stiff neck, pain when urinating, etc., even in the absence of
fever.
Even in the absence of fever, those who exhibit a normal
temperature may still need to receive medical attention. People
who are on antibiotics, analgesics, or antipyretics should not
be assessed solely on temperature readings to determine the
severity of their illness.
Do not modify this equipment without the authorization of the
manufacturer.
WARNING AND PRECAUTIONS
1

Use of this thermometer is not intended as a substitute for
consultation with your physician.
Keep out of reach of children under 12 years old.
Never use the thermometer for purposes other than those it
has been intended for. Please follow the general safety
precautions when using on children.
Never immerse the thermometer into water or other liquids (this
thermometer is not waterproof).
Do not store this thermometer in temperature extremes below
-13°F or over 140°F(below-25°C or over 60°C) or in excessive
humidity (above 95% non-condensing relative humidity).
If thermometer is stored in a location that is cooler or warmer
than where it is being used, let it reach room temperature for
10 minutes before taking a measurement.
Do not use the thermometer if there are signs of damage on
the sensor or on the thermometer itself. If damaged, do not
attempt to repair the product.
Never insert a sharp object into the sensor or any other open
surface on the thermometer.
This thermometer consists of highprecision parts. Do not drop
the instrument. Protect it from severe impact and shock.
This thermometer is intended for household use only.
Temperature elevation may signal a serious illness, especially
in neonates and infants, or in adults who are old, frail, or have a
weakened immune system. Please seek professional advice
immediately when there is a temperature elevation and if you
are taking temperature on:
Neonates and infants under 3 months (Consult your
physician immediately if the temperature exceeds 99.4 °F
[37.4 °C]).
Patients over 60 years of age (Fever may be blunted or
absent in older patients).
Patients with Diabetes Mellitus or a weakened immune
system (e.g., HIV positive, cancer chemotherapy, chronic
steroid treatment, splenectomy).
Patients who are bedridden (e.g., nursing home patient,
stroke, chronic illness, recovering from surgery).
A transplant patient (e.g., liver, heart, lung, kidney).
This thermometer is not intended for pre-term babies or
small-for-gestational age babies.
This thermometer is not intended to interpret hypothermic
temperatures.
Do not allow children to take their temperatures unattended.
Please consult your doctor if you see symptoms such as
unexplained irritability, vomiting, diarrhea, dehydration,
changes in appetite or activity, seizure, muscle pain, shivering,
stiff neck, pain when urinating, etc., even in the absence of
fever.
Even in the absence of fever, those who exhibit a normal
temperature may still need to receive medical attention. People
who are on antibiotics, analgesics, or antipyretics should not
be assessed solely on temperature readings to determine the
severity of their illness.
Do not modify this equipment without the authorization of the
manufacturer.
WARNING AND PRECAUTIONS
2

APPEARANCE OF THE PRODUCT
LCD
Thermometer
Sensor
Battery
Chamber
Measure
Button
Memory/Mode
Button
Mute/Unit
Switch Button
LCD DISPLAY
Room Temperature Mode
Forehead Temperature Mode
Measured Temperature
Temperature Unit
Mute / Un-Mute Alarm
Memory Recall
Low Battery
3

MEASUREMENT STANDARDS
Typical normal body temperature
Each individual’s normal temperature is different, and our body
temperature variance depends on many factors such as age, time of
day, exertion level, health status, measuring method and other factors.
Please use the following temperature reading only as a quick reference
guide to typical body temperature ranges. It is important to know each
individual’s normal temperature when they are well. This is the best way
to accurately diagnose a fever. Take multiple readings to establish a
healthy normal baseline temperature.
Oral
Rectal
Axillary
Ear
Forehead (this product)
Method Range (°F)
0 - 2 years
Oral
Rectal
Axillary
Ear
Forehead (this product)
3-10 years
Oral
Rectal
Axillary
Ear
Forehead (this product)
11 - 65 years
Oral
Rectal
Axillary
Ear
Forehead (this product)
65+ years
N/A
97.9
94.5 99.1
94.5
95.9
97.9
96.6
96.6 99.7
98.0
96.6 98.0
97.0 100.0
100.4
99.5
99.1
97.5
97.6
98.6
95.3 98.4
95.3
96.4
96.4 99.5
97.1
96.0 97.4
96.0 97.4
99.2
98.5
98.4
100.6
99.6
100.4
100.4
Note: This device is not intended as a substitute for regular check-ups by your doctor,
please consult your doctor if you have any doubt about the temperature.
4

5
USING THE PRODUCT
Step 1. Power the Thermometer - Insert the battery
Insert two AAA batteries, using the plus (+) and minus (-) guides
inside the battery chamber to insert the batteries in the proper
direction.
Locate and slide open the battery chamber cover
1
2
3Close the battery chamber cover
Step 2. Aim the thermometer
Position the thermometer 1 inch away from the center of the forehead,
just between the eyebrows. If the eyebrow area is covered with hair,
sweat or dirt, please clear up the area before taking a measurement. It
is important to hold the thermometer steady at the right angle and
distance during measurement. Movement will impact the temperature
reading.
Note: When the battery is low, the icon will show up on the screen to remind you to
replace the battery. Do not confuse it with the out of temperature range indicator “Lo”.
Note: For best consistent results, measure your body temperature at the time of day
when there is least factor that may affect the results, such as early in the morning after
getting out of bed, before the rst meal.
1” away

USING THE PRODUCT
Step 3. Take temperature measurement
Step 4. Understanding the results
In approx 1 second, the thermometer will make a beep sound
to indicate measuring complete; LCD will show the temperature
reading.
The LCD color code helps you to quickly understand the temperature
ranges with the color indicated on the display. The screen displays
green if the recorded temperature is in the normal range, yellow when
the temperature is elevated, and red for a potential fever.
Properly position the thermometer away from forehead (refer to
last section).
Remove the thermometer from forehead and read the temperature
from the screen.
1
2
3
4
Press the button.
Green: 89.6°F to 99.2°F
Yellow: 99.3°F to 100.3°F
Red: 100.4°F to 109.2°F
6

7
USING THE PRODUCT
Power Off
This device will shut off automatically after 20seconds of inactivity.
Or you can shut down the device by pressing and holding the
button for 6 seconds.
If the temperature is outside of measuring range in this mode, a red
screen with “Lo” or “Hi” will be displayed to indicate out of range.
Note: This unit can only measure a temperature range within 89.6 °F to 109.2 °F in
forehead thermometer mode.

8
ADDITIONAL FUNCTIONS
Recall pervious temperature reading memories
How to change the temperature unit
Press the button again to read older temperature records,
these records will be displayed in order of latest -> oldest.
Press the button once to use the memory recall function.
When the icon displays on screen, press the button
again to see recently recorded temperatures.
1
2
3
Most recent memory: Second memory: So on:
Repeating the above steps again will switch the units again.
Taking a temperature reading (while the screen is still on):
Press and hold the button for 5 seconds.
The displayed unit on the upper corner will switch from °F to °C.
1
2
3

9
ADDITIONAL FUNCTIONS
How to silence the thermometer
To un-mute, simply repeat the above
steps again.
After taking a temperature reading (while the screen is still on):
Press the button once.
The icon will be displayed on screen,
to indicate mute mode is now enabled.
1
2
3
Room temperature thermometer mode
Press and hold the button for 5 seconds until the icon
show up at the upper corner, release the button.
Make sure the unit is powered off (screen is off).
Point the thermometer sensor toward the room.
You can use this unit to measure the indoor room thermometer using
the following steps:
1
2
3
The thermometer is now enabled in room temperature mode,
which enables the thermometer to measure from a wider range of
temperatures 32°F to 212°F.
4
Press the button to measure the ambient room temperature.
5
The thermometer will reset to forehead thermometer mode after
being powered off.
6
Note: Upon replacing the battery, memory records will be removed and temperature
units/mute settings will be reset to default.
Note: For better results using the room temperature mode. It is suggested to point the
thermometer toward walls without a source of heat, a few feet to get the best scan of
the environmental average temperature. Avoid pointing the thermometer at sources of
heat, such as a replaces, lamps, hot spots, and or direct sunlight.

10
CARE AND STORE
SPECIFICATIONS
Always keep the sensors clean and free of obstacles.
Never immerse the thermometer into water or other liquids.
Never use abrasive cleaning agents, thinners or benzene for cleaning.
Store the unit in dry and cool location between uses.
Use an alcohol swab or cotton swab moistened with 70% alcohol to
clean the thermometer.
Measurement Range:
Forehead thermometer mode: 89.6 °F to 109.2 °F
Room temperature thermometer mode: 32 °F to 212 °F
Error Tolerance:
Measuring Distance (Forehead mode):
Display Units: °F / °C
Operating Conditions:
Dimension: 1.4 x 1.7 x 6 inches
Weight: 2.4 oz
Display: LCD with backlit
Measurement Reading Memory: 35
Power: 2x AAA (included)
Forehead thermometer mode: ±0.4 °F
Room temperature thermometer mode: ±1.8 °F
Ambient temperature:
Humidity:
1 inch
50 °F to 104 °F
15% to 95% RH

11
FAQS
Q: Why am I getting a different temperature from this forehead thermometer than my
other digital thermometer?
A: This is normal. Different body parts will have different temperatures, digital thermometers
orally or through the ears will have different temperature readings than forehead thermome-
ter readings.
Q: I am keep getting “Lo” on the screen without temperature, what do I fix it?
A: “Lo” on the screen means the thermometer is getting a temperature reading outside of its
measuring range in forehead mode. Please refer to page 5 and properly positioned in front of
your forehead before measurement.
Q: Can I change the unit from Fahrenheit to Celsius?
A: Yes, please refer to page 8 of this manual.
Q: Can I take temperature measurements by other part of my body using this
thermometer?
A: Forehead between theeyebrows is the only recommended area to measure using this
thermometer.
Q: How can I ensure an accurate reading of my own temperature?
A: We recommend using a mirror to better position the thermometer on the forehead. In
addition,for a better reading, we suggest measuring your temperature right out of bed in the
morning (before a shower and your rst meal, will give results that reduce common factors
that changes your temperature).
Q: How to I fix an error code “ER1” showing up on thermometer?
A: ER1 means the ambient temperature is too hot or too cold to use this thermometer, please
let the thermometer reach room temperature before attempting to take a temperature
reading again.
Q: How long can the battery last?
A: The set of AAA battery can last about 2,000 scans before needing to be replace.
Q: What if I still have questions?
A: Please do not hesitate to contact us at [e-mail] for any questions or
concerns, we are more than happy to help resolve any concerns.
MORE QUESTION?
Feel free to contact our customer service specialist:
510-979-9969 [e-mail]

12
Model: FC-IR202
Symbol Description
Type B applied part.
Information about a manufacturer
Please read the instructions carefully.
Waste electrical materials should be sent to a dedicated collection
point for recycling.
Serial number
Batch number
IMPORTANT
Importer:
Fremont, CA 94539
Importer Part Number: 58062
Manufacturer:
Shenzhen Finicare Co., Ltd
201, Dehe Building, No.81, Haoyong No.2
Industrial Park, Hongxing Community Songgang
Street, Bao’an District
Shenzhen, Guangdong
518103 CHINA
Tenergy Corporation
Share Info Consultant Service
Dimdi Code: DE/0000047946
Inaccurate reading or thermometer damage may occur if the
thermometer is not correctly used.
2 Protected against solid foreign objects of 12,5 mm Ø and greater:
2 If keep the thermometer in 15 degree angle, it still can prevent the
water drop.

13
Guidance and manufacturer's declaration-electromagnetic emissions
The infrared thermometer is intended for using in the electromagnetic environment
specied below. The customer or the user of the infrared thermometer should assure
that it is used in such an environment.
Emissions test Compliance Electromagnetic environment-guidance
RF emissions
CI S PR11
The infrared thermometer uses RF energy
only for its internal function. Therefore, its
RF emissions are very low and are not
likely to cause and interference in nearby
electronic equipment.
rhe infrared thermometer uses RF energy
only for its internal function. Therefore, its
RF emissions are very low and are not
likely to cause and interference in nearby
electronic equipment.
network that supplies buildings used for
domestic purposes.
RF emissions
CI S PR11
Harmonic
emissions IEC
61000-3-2
Voltage
uctuations/icker
emissions IEC
Group 1
Class B
N/A
N/A

14
Guidance and manufacturer's declaration-electromagnetic immunity
The infrared thermometer is intended for use in the electromagnetic environment
specied below. The customer or the user of the infrared thermometer should assure
that it is used in such an environment.
Immunity test IEC60601 test level Compliance level Electromagnetic environment -guidance
Electrostatic
discharge
(ESD) IEC
61000-4-2
±2, ±4, ±6, ±8kV for
Contact discharge
±2, ±4, ±8, ±15kV
air discharge
±2 kV for a.c. power
lines ±1 kV for d.c.
power lines
±1 kV line(s) to
line(s) ±2 kV line(s)
to earth
3A/m
NOTES' is the a.c. mains voltage prior to application of the test level.
3A/m
<5%UT
(>95 dip in UT) for
0.5 cycle
40%UT
(60% dip in UT) for
5 cycles
70% UT
(30% dip in UT) for
25 cycles
<5%UT
(>95% dip in UT) for
5 s
t2, ±4, ±6, t8kV for
Contact discharge
t2, ±4, ±8kV t15kV
air discharge
Floors should be wood, concrete or ceramic
tile. If oors are covered with synthetic
material, the relative humidity should be at
least 30%
Mains power quality should be that of a
typical commercial or hospital environment.
Mains power quality should be that of a
typical commercial or hospital environment.
Mains power quality should be that of a
typical commercial or hospital environment.
If the user of the infrared thermometer
requires continued operation during power
mains interruptions, it is recommended that
the infrared thermometer be powered from
an uninterrupted power supply or a battery
Power frequency magnetic elds should be
at levels characteristic of a typical location in
a typical commercial or hospital environment
Electrical fast
transient/burst
IEC 61000-4-4
Surge
IEC 61000-4-5
Voltage dips,
short
interruptions
and voltage
variations in
power supply
input lines
IEC 61000-4-11
Power
frequency
(50/60Hz)
magnetic eld
IEC 61000-4-8
N/A
N/A
N/A

15
Radiated RF
IEC 6100043
3V/m 80kHz
to 2.5GHz
3V/m d=1.2P80MHz to 800MHz
d=2.3P 800MHz to2.5MHz
Here P is the maximum output power rating of the transmitter
in watts (W) according to the transmitter manufacturer and dis
the recommended separation distance in meters (m). Field
strengths form xed RF transmitters, as determined by an
electromagnetic site survey, should be less than the
compliance b level in each frequency range. Interference may
occur in the vicinity of equipment marked with the following
symbol:
NOTE 1 At90MHz and 800MHz, the higher frequency range applies.
NOTE 2 These guidelines may not apply in all situations. Electromagnetic propagation is affected by
absorption and reection from structures, objects and people.
a
Field strengths from xed transmitters, such as base stations for radio (cellular/cordless) telephones and
land mobile radios, amateur radio, AM and FM radio broadcast and TV broadcast cannot be predicted
theoreticallywith accuracy. To assess the electromagnetic environment due to xed RF transmitters, an
electromagnetic site survey should be considered. If the measured eld strength in the location in which the
thermometer is used exceeds the applicable RF compliance level above, the thermometershould be
observed to verify normal operation. If abnormal performance is observed, additional measures may be
necessary, such as reorienting or relocating the thermometer.
b
Over the frequency range 150kHz to 80MHz, eld strengths should be less than 3V/m.

16
Recommended separation distances between portable and mobile RF communications equipment
and the infrared thermometer
The infrared thermometer is intended for use in an electromagnetic environment in which radiated RF
disturbances are controlled.
The customer or the user of the infrared thermometer can help prevent electromagnetic interference by
maintaining aminimum distance between portable and mobile RF communications equipment (transmitters)
and the infrared thermometer as recommended below, according to the maximum output power of the
communications equipment.
For transmitters rated at a maximum output power not listed above, the recommended separation distance
d in meters (m) can be estimated using the equation applicable to the frequency of the transmitter, where P
is the maximum output power rating of the transmitter in watts (W) according to the transmitter
manufacturer.
NOTE 1 At 80MHz and 800MHz, the separation distance for the higher frequency range applies.
NOTE 2 These guidelines may not apply in all situations. Electromagnetic propagation is affected by
absorption and reection from structures, objects and people.
Rated maximum output
power of transmitter W
Rated maximum output
power of transmitter W
Separation distance according to frequency of transmitter m
80MHz to 800MHz
d=1.2P
800MHz to 2.5GHz
d=2.3P
150kHz to 80MHz
d=1.2P
0.01 0.01 0.12 0.23
0.1 0.1 0.38 0.73
1 1 1.2 2.3
10 10 3.8 7.3
100 100 12 23
