Tepex PLFM 100 Series User manual

CONTENT
1.
Manufacturer
1
2.
General safety information’s
1
3.
Purpose
2
4.
Product compliance
2
5.
Degree of protection and technical data
2
6.
Type
3
7.
Mounting and installation
4
8.
Dimension
5
9.
Inspection, maintenance, repair and overhaul
5
10.
Spare part and accessories
6
11.
Responsibility and authorization
7
12.
Storage and transport
7
13.
Manufacturer's warranty
7
14.
Marking
7
1. MANUFACTURER
TEP Ex d.o.o.
Prilaz dr. Franje Tuđmana 6 HR-49210 ZABOK
Tel: [phone]
Web: www.tepex.hr
2. GENERAL SAFETY INFORMATIONS
W A R N I N G !
The user manual contains basic information about the product. Mounting, installation, usage and maintenance
should be carried out under this user manual to provide and ensure safe operation within the nominal
characteristics. This user manual complement national Regulation and Standards. The responsible person shall
ensure their implementation. Failure off implement this user manual can reduce explosion protection and
endanger people, property and the environment. Any improper and illegal actions as well as non-compliance with
the provisions of this user manual excludes all responsibility by manufacturer side.
Before installation/commissioning:
- Carefully read all instructions,
- Execute proper training of responsible personnel,
- Check that the contents of these instructions is fully understandable by the responsible personnel,
- Make sure that all the requirements and national Regulations as well as all special security measures are applied.
In lack of understanding:
-Contact the manufacturer.
During operation:
- Ensure that this user manual and other work instructions are available to the responsible staff at all times,
- Check the implementation of these instructions and all other safety user’s instruction
d.o.o.
Medarska 69, Zagreb, Croatia
tel. [phone], fax [phone]
e-mail: [e-mail]
www.tepex.hr
USER MANUAL FOR EXPLOSION PROTECTED
PENDANT LIGHTING FITTING / LIGHT SWITCH,
TYPE PLFM …-.
Doc. No: TEPEx.RS.0
Ver : 0
Date: 01.2020.

3. PURPOSE
Explosion proof pendant lighting fitting / light switch, typePLFM ...-. is intended for general lighting in industrial with potentially
explosive atmosphere of gases, vapors and dust in zones 1, 2, 21, 22 in accordance with EN 60079-10-1 and EN 60079-10-2.
4. PRODUCT COMPLIANCE
Design of lighting fitting is accordance with the standard EN 60598-1 and all related standards.
The product is in compliance with Regulations concerning equipment and protective systems for use in potentially explosive
atmosphere.
The product complies with the ATEX Directive 2014/34/EU and standards:
-EN IEC 60079-0:2018,
-EN 60079-1:2014,
-EN IEC 60079-7:2015/A1:2018,
-EN 60079-31:2014.
The product has been developed, manufactured and tested according to the existing state of technique accordance with the
standards EN 9001, EN ISO 80079-34 and EN ISO 14001.
The product is in compliance with the LV Directive 2014/35/EU.
The product is in compliance with the RoHS Directive 2011/65/EU.
The product is in compliance with EMC Directive 2014/30/EU.
5. DEGREE OF PROTECTION AND DATA
Certificate:
FIDI 19 ATEX 0047
Category and
explosion protection:
II 2G Ex db eb IIC T6-T3 Gb ili II 2G Ex db IIC T6-T3 Gb
II 2D Ex tb IIIC T85°C –T155°C Db
Ambient temperature:
-20ºC ≤ Ta ≤ +40°C
Mechanical protection:
IP66, category 1
Resistance to shock:
IK 08
Class of protection:
I (PE - protective earthing)
Rated voltage:
-230 V (-10% / +6%) / 50 Hz
- PLFM FLASH, PLFM LUXOMAT- . see Table of light sources
Rated power:
- see Table of light sources
Luminous flux
- see Table of light sources
Wiring:
- Radox 155 or Betatherm 155, IEC 60228:2005 IEC 60228:2005 class 5,
1,5mm2
Connection terminals inside housing / light
switch:
- tree-pole plug and socket terminals for connection L + N + PE; 2,5mm2
max, solid, stranded
- four-pole plug and socket terminals for connection L + L’ + N + PE;
2,5mm2max, solid, stranded
Connection terminals inside Ex eb / tb
junction box / light switch:
- conductor terminals for connection of phase, neutral and protective
conductor L + L '+ N + PE; 2.5mm2 single-wire, multi-wire
- true wiring is also possible by connecting two conductors to the same
terminal inside the Ex eb connection chamber, 2.5mm2 max.
Ex eb / tb cable glands and plugs
- two Ex eb / tb SPU 25 cable glands ISO 25 II 2G Ex eb IIC Gb
II 2D Ex tb IIIC Db for diameter cable Ø7-15 mm in accordance EN 62444
Certificate: FIDI 19 ATEX 0003X
- two Ex eb / tb TEPEx plugs, II 2G Ex eb IIC Gb II 2D Ex tb IIIC Db in
accordance EN 62444
Certificate: FIDI 19 ATEX 0003
Connection terminals inside Ex db eb/tb
adapter ADP 23/1:
- terminals for connection L + N + PE; 2,5 mm2,
- solid, stranded
Connection terminals inside Ex db eb/tb
adapter ADP 24/1:
- terminals for connection L + N + PE; 2,5 mm2,
- solid, stranded
Adapter ADP:
- type ADP 23/1, ADP 24/1, II 2G Ex db eb IIC Gb II 2D Ex tb IIIC Db,
for cable v7-15 mm
Certificate: FIDI 19 ATEX 0014X
Connection cable for direct entry via
Ex db / tb cable entries:
- connection on tree-pole / four-pole plug inside housing for connection
L + N + PE; 2,5mm2solid, stranded
Ex db / tb cable gland:
- ATEX certified II 2G / D Ex db / tb IP66 M20 cable gland
0722

Tightening torque:
- screws of Ex eb terminal 0,8 Nm
- screws of Ex e cover of junction box 0,8 Nm
-pressure nut of cable gland 2,5 Nm
Ballast:
- 230V/50Hz 70/50W 1,00/0,76A λ=0,37 tw=130°C ΔT=70/50K in
accordance EN 61347, Vossloh Schwabe, GmbH
Light switch:
-Dasy 010-2 12V AC/DC
-Dasy 010-2 24V AC/DC
-Dasy 010-2 230V AC
-Dasy 016-2 230V AC
Manufacturer: Doepke GmbH, Germany
All capacitors inside the light switch will be discharged within 5 min. below
0.02 mJ according to p. 6.3. EN IEC 60079-0: 2018
Lamp holder:
- E27, 250V, 4A, according to EN 60238:2004, Vossloh Schwabe, GmbH
Dimension:
- 339 x 208 x 130 mm –PLFM 100-. , PLFM 100/1-. , PLFM 100/2-. , PLFM
100/3-. , PLFM 20 LED-. , PLFM FLASH-.
- 380 x 208 x 130 mm –PLFM 70 HSE-.
Weight:
- 3,5 kg - PLFM 100-. , PLFM 100/1-. , PLFM 100/2-. , PLFM 100-3-. , PLFM
FLASH-.
- 4,5 kg - PLFM 20 LED-. , PLFM 70 HSE-.
Mounting:
- allowed only vertical mounting –PLFM 100/1-.
- allowed deviation from the vertical max. 30 °- PLFM 100-. , PLFM 100/2-. ,
PLFM 100/3-. , PLFM 20 LED-. , PLFM FLASH-.
For versions with mounted Ex db eb adapter (PLFM ...- 2) there are specific conditions of use:
- the user must ensure adequate fastening of the cable outside the cable gland because the cable gland of the multi-core
conductor insulator with a connection chamber has been tested with a lower pulling force in accordance with p. A.3.1.1 of
EN IEC 60079-0,
- the device must be installed in places with a lower risk of impact because the multi-core conductive insulator with a
connection chamber has been tested with a lower impact energy in accordance with EN IEC 60079-0.
Threaded joints:
- M125x1,5 - 6H / 6g, medium tolerance according to ISO 965-3, thread DIN 13 T.24, 11 full threads,
- M20x1,5 - 6H / 6g, medium tolerance according to ISO 965-3, thread DIN 13 T.24, 7 full threads.
For luminaires type PLFM 100 / 1-3 (versions with direct entry) it is necessary to use a cable with a temperature resistance not
less than 90 ° C. For luminaires type PLFM 70 HSE-3 (version with direct introduction) it is necessary to use a cable with a
temperature resistance not less than 140 ° C.
6. TYPE
PLFM ... - .
basic type code
maximal wattage and type of sources:
-100 - A incandescent lamp 100W max,
-A ECO halogen lamp 105W max,
-QT halogen lamp 100W max.
-100/1 - LME mixed discharge lamp 100W max.
-100/2 - TC-SB compact fluorescent lamp 23W max.
-100/3 - LED BULB lamp 15W max.
-20 LED - LED MODUL special 20W max.
-FLASH - XENON MODUL special 5W max.
-70 HSE - HSE-I high pressure sodium discharge lamp 70W,
-HSE-I high pressure sodium discharge lamp 50W.
-LUXOMAT 10 –light switch 10A,
-LUXOMAT 16 –light switch 16A.
Type of entries:
-1 –indirect entry –type with Ex eb junction box,
-2 –indirect entry –type with Ex db adapter ADP 23/1,
-3 –direct entry –type with Ex db cable gland.

Table of light sources:
Model code
Max. wattage
LBT
marking
Nominal
voltage
Luminous flux
Lamp
holder
Temp.
class
(gas)
T0 MAX
(dust)
OSRAM type
PHILIPS type
Another
supplier
Ta=40°C
Ta=40°C
PLFM
100 - .
100 W
A
230V
1340 lm
E27
T4
130°C
-
GE Lighting -
Rough Service
GLS - Clear
116 W Osram
105 W Philips
A ECO
230 V
2135 lm Osram
1980 lm Philips
E27
T4
130°C
Halogen Classic
A ECO
EcoClassic A -
shape
-
100 W
QT
230 V
1800 lm Osram
E27
T4
130°C
Halolux Ceram
Eco
-
-
PLFM
100/1 - .
100 W
LME
230 V,
50 Hz
1100 lm
E27
T3
155°C
-
ML Mixed Light
lamps
-
PLFM
100/2 - .
22 W Osram
23 W Philips
TC-SB
230 V,
50 Hz
1440 lm
E27
T6
80°C
Osram Deluxe-
Intelligent
Longlife
Master PL -
Electronic
-
PLFM
100/3 - .
12 W Osram
13 W Philips
LED
230 V,
50 Hz
810 lm Osram
1055 lm Philips
E27
T6
80°C
Parathorm Ledotron
Classic A
Master LED bulb
-
PLFM
20 LED - .
20 W
LED
modul
230 V,
50 Hz
1300 lm
-
T6
80°C
-
-
Vossloh LED
LR 42
PLFM
FLASH - .
5 W
XENON
10–100 V DC
4J/90Hz
-
T6
80°C
-
-
RS Components
–Miniature
Xenon beacons
110 V AC
230 V AC
PLFM
70 HSE - .
70 W
HSE
230 V,
50 Hz
5900 lm Osram
5600 lm Philips
E27
T4
130°C
Vialox NAV-E
70W/I
SON 70W I E27
CO 1CT
-
50W
HSE
230 V, 50 Hz
3600 lm Osram
3500 lm Osram
E27
T4
130°C
Vialox NAV-E
50W/I
SON 50W I E27
CO 1CT
-
PLFM
LUXOMAT 10
- .
-
-
12 V AC/DC
-
-
T6
85°C
-
-
Doepke DASY
010
24 V AC/DC
230 V AC
PLFM
LUXOMAT 16
- .
-
-
230 V AC
-
-
T6
85°C
-
-
Doepke DASY
016
7. MOUNTING AND INSTALLATION
Mounting of the lamp:
- With vertical suspension on the bolt with ring bolt
head M8 witch is twisted in the housing and further
blocked from self-loosening
- Mounting on the tube 2” and blocking it with two M10
screws
Before opening the housing, unscrewing the assembly of the protective glass, mechanical release should be carried
out by unscrewing the blocking screws M4x14 ISO 4027 in the framework of the glass. Removing the lamps is only
allowed in the not energized state. Not energized state must be ensured by switching of the master switch. It is
recommended only to install light sources listed in the table of light sources.
Electrical connection is made by connecting the power cable to the terminal connection terminals L - phase
conductor, N - neutral, PE - protective earth. For direct entry of cable, electrical connection is made by connecting
the power cable to the plug.

Type PLFM 70 HSE is factory wired for High pressure sodium source of 70W and connection diagram is shown in
the following figure:
If the user wants to install High pressure sodium source of 50W, it is necessary that the brown phase conductor which
is connected to the lampholder E27 is reconnected to the two-pole terminal from 70W to 50W.
After each opening lamp protective fitting must be protected with "Baplex" protective agents (manufacturer's
recommendation).
Wiring diagram PLFM LUXOMAT:
8. DIMENSIONS
9. INSPECTION, MAINTENANCE, REPAIR AND OVERHAUL
Inspections are carried out in accordance with IEC 60079-17:2014, general and special conditions of manufacturer
and users Regulations and includes supervision of parts on which the explosion protection depends, especially:
that the housing, all part of housing, replacement glass and gaskets without rupture and damage,
that the housing completely closed with replacement glass compound and that mechanical blockage against
self opening is done,
that the cable gland, plug, adapter, pressure nut of cable gland, screws cover of junction box and connection
terminal are fastened with nominal torque.
N
N
L
L
plava 1 mm
ž.z. 1 mm
smeða 1 mm
plava 1 mm
ž.z. 1 mm
smeða 1 mm
2
2
2
plava 1 mm2
ž.z. 1 mm2
smeða 1 mm2
smeða 1 mm2
2
2
2
230V/50Hz
L70W
50W
70W
50W 70W
PE
Ex e Ex d Svjetlosna sklopka
Adapter
ADP 24/1
Žuto-zelena
Crna
Plava
Smeða
N
PE
L1
L2
PE
Ex d
Ex db
Cable gland
PE
L
N
L'
N
PE
L1
L2
Žuto-zelena
Crna
Plava
Smeða
N
L'
L
N
L'
L
Svjetlosna sklopka
175
320
345
175
361
386

All the repairs are performed by the manufacturer or the manufacturer's authorized personal and the original parts must be
provided according to the product documentation, all in accordance with EN 60079-19.
If repair or any other procedure are performed on the product by unauthorized person, all producer responsibility for the
product and the warranty and the manufacturer's declaration of conformity becomes invalid.
10. SPARE PART AND ACCESSORIES
SKETCH
DESCRIPTION
CODE
SKETCH
DESCRIPTION
CODE
Replacement
glass PLFM
PLFM 10 - 120
plug and socket
terminals
PLFM 10-180
Gasket PLFM
PLFM 10 - 140
Adapter
ADP 23-1
PLFM 20 - 110
Heat sink SET
PLFM
PLFM 10-180
Ex e cable gland
SPU 25
SPU 25
Lamp holder
PLFM
PLFM 10 - 150
Ex eb plug SPC
25
SPC 25
Ballast SET
PLFM
PLFM 10-170
Ex db cable
gland
-
Light switch
10/16A
Doepke Dasy 10
Doepke Dasy 16
PLFM 100-.
PLFM 100/1-.
PLFM 100/2-.
PLFM 100/3-.
PLFM FLASH-.
PLFM 70 HSE-. PLFM 20 LED-.
Ex e prikljuèna komora
Ex d e adapter ADP 23/1
Ex d uvodnica

11. RESPONSIBILITY AND AUTHORIZATION
This instruction is the basic information about the product. It is completed by the corresponding national laws and
regulations.
Production, use, certification and supervision are determined at the national level:
a) Regulations concerning equipment and protective systems intended for use in potentially explosive atmospheres
EU directive ATEX 2014/34/EU
b) Regulations on minimum requirements for safety and health protection of workers and technical inspection of
facilities, equipment, installations and equipment in hazardous areas EU directive 1999/92/EC (ATEX 137).
The responsible person shall ensure their implementation at the working facility.
12. STORAGE AND TRANSPORT
Transportation and warehousing of the lamps is only allowed in the original packaging, as outlined in a cardboard
box.
13. MANUFACTURER'S WARRANTY
The manufacturer provides a warranty on the product for a period of one year under the provisions of this user manual
and the law on obligations. This statement has the force of Warranty sheet.
14. MARKING
Explosion-protected pendant lighting fitting , type PLFM ... - . - . is labeled with:
- warning plate on housing, type PLFM 100-., PLFM 100/2-., PLFM 100/3-., PLFM 20 LED-., PLFM
FLASH-., PLFM 70 HSE-1, PLFM 70 HSE-2, PLFM LUXOMAT ..-.:
- warning plate on housing, type PLFM 100/1-1, PLFM 100/1-2:
- warning plate on housing, type PLFM 100/1-3:

-natpisnom pločicom na kućištu, tip PLFM 70 HSE-3:
- marking plate with technical data on housing and inside housing:
