dun-bri GROUP DBG M35 Series Manual

www.dun-bri.com [phone] [email protected]
Dun-Bri Group, Watermill Industrial Estate, Aspenden Road, Buntingford, Hertfordshire, SG9 9JS, United Kingdom
DBG M35 SERIES R65 LED
WARNING MODULE
INSTALLATION + OPERATING INSTRUCTIONS
! IMPORTANT ! - Read all instructions before installing and operating the module. This module
must be installed by a qualified automotive technician. Failure to do so may void your warranty.
v1.1
M35 Series
Voltage Range 10-30V
LED Colour Amber
Mounting Surface Mount (2 Screws)
Connection Fly Lead
Flash Patterns 19
Syncable? Yes (with alternating sync)
Dimmer Function HPF307VV version only
IP Rating IP69K
MODELS AVAILABLE
SKU LEDs Approvals Watts Dimensions (l) x (h) x (d)
308.HPF306VV 6ECE R65 (Class I), ECE R10 18W 100mm x 28mm x 12mm
308.HPF307VV 6 ECE R65 (Class II), ECE R10 18W 100mm x 28mm x 12mm

www.dun-bri.com [phone] [email protected]
Dun-Bri Group, Watermill Industrial Estate, Aspenden Road, Buntingford, Hertfordshire, SG9 9JS, United Kingdom
DBG M35 SERIES R65 LED
WARNING MODULE
! WARNING ! - Do NOT look directly at the LEDs when in operation to prevent damage to your eyes.
19 STANDARD FLASH PATTERNS
01 Single Flash (ECE R65 Approved) 11 Double Flash (Left / Right)
02 Double Flash 12 Quad Flash (Left / Right)
03 Quad Flash 13 Five Flash (Left / Right)
04 Five Flash 14 Strobe (Left / Right)
05 Strobe 15 Single Flash + Quad Flash (Left / Right)
06 Single Flash + Quad Flash 16 Single Flash + Strobe (Left / Right)
07 Single Flash + Strobe 17 Random
08 Single Flash (Slow) 18 Combination
09 Single Flash + Single Flash (Slow) 19 Constantly Bright
10 Single Flash (Left / Right)
WIRING DIAGRAM
Latching Switch (On/Off)
+VDC
(RED WIRE)
Ground
Battery
ALT SYNC (GROUP 1)
WHITE WIRES (+)
Fuse (Required)
Supplied with 210mm length of cable
Fuse and switches NOT supplied
Momentary Switch (Change Flash Pattern)
(Not Connected)
ALT SYNC (GROUP 2)
WHITE WIRES (+)
SYNC
YELLOW WIRE (+)
- VDC
(BLACK WIRE)
DIMMER
BLUE WIRE (+)
Latching Switch (On/Off)
(If Applicable)

www.dun-bri.com [phone] [email protected]
Dun-Bri Group, Watermill Industrial Estate, Aspenden Road, Buntingford, Hertfordshire, SG9 9JS, United Kingdom
MODULE LENS CLEANING
Occasional cleaning is recommended to ensure optimal
light output. Although tough, polycarbonate scratches
easily, so take care when cleaning. Clean lens with soap
and water or a lens polish using a soft cloth.
! WARNING ! - Do NOT use
solvents as they may damage
the lens.
WIRING INSTRUCTIONS
TO CHANGE FLASH PATTERNS
Momentarily apply yellow wire to the +VDC. A simple momentary switch will be sufficient.
SYNCHRONISATION INSTRUCTIONS
Ensure all modules are set to the same flash pattern. Connect yellow wires of all modules together.
ALTERNATE SYNC INSTRUCTIONS
Ensure all modules are set to the same flash pattern.
Connect yellow wires of all modules together.
For GROUP 1: Connect all white wires to the +VDC.
For GROUP 2: Do not connect white wires.
DIMMER FUNCTION INSTRUCTIONS (HPF307VV VERSION ONLY)
Apply blue wire to the +VDC. A simple latching switch will be sufficient.
! WARNING ! - Unconnected
wires MUST be sealed to
prevent any water ingress.
MOUNTING + FITTING INSTRUCTIONS
Carefully unpack and inspect the module and all
accessories before installing to ensure there are no
damaged or missing parts.
Use foam gasket and screws provided. Do NOT
overtighten screws.
Plan all cable routing before attempting installation and
ensure voltage compatibility.
Ensure there are no obstructions limiting visibility to
traffic when mounting.
If the module slides or moves easily, a proper installation
has NOT been attained.
! CAUTION ! - Disconnect the
battery before wiring up the
module to prevent accidental
shorting and/or electrical shock.
! CAUTION ! - When drilling into
the vehicle surface, make sure
the area is free from anything
that could be damaged,
including any electrical wires,
fuel lines, upholstery, etc.
! WARNING ! - Do NOT
overtighten screws.

www.dun-bri.com [phone] [email protected]
Dun-Bri Group, Watermill Industrial Estate, Aspenden Road, Buntingford, Hertfordshire, SG9 9JS, United Kingdom
DBG M35 SERIES R65 LED
WARNING MODULE
MANUFACTURER’S WARRANTY
Dun-Bri Services Ltd warrants that on the date of purchase this product conforms to the specifications
(available on request). Dun-Bri Services Ltd further warrants that this product is free from defects in materials
and workmanship for 24 months from the date of purchase. Dun-Bri Services Ltd will at its discretion, repair or
replace any product found to be defective, subject to the Limited Warranty.
Damage to parts or products resulting from tampering, accident, abuse, misuse, negligence, unapproved
modifications, fire or other hazard, improper installation/operation or failure to maintain in accordance with the
reasonable maintenance procedures set forth in Dun-Bri Services Ltd’s installation and operating instructions
shall void the Limited Warranty.
Verbal statements or representation about this product made by salespersons, dealers, agents or other
representatives do not constitute part of the warranty agreement. This Limited Warranty may not be amended
or extended except by written agreement, signed by an authorised official of Dun-Bri Services Ltd, which
expressly refers to this Limited Warranty.
EXCLUSION OF OTHER WARRANTIES
Dun-Bri Services Ltd offers no further warranties, express or implied. The implied warranties for merchantability
or fitness for a particular purpose are hereby excluded and shall not apply to the product. The buyer’s sole and
exclusive option in contract, tort, or any other practice against Dun-Bri Services Ltd regarding the product and
its use shall be the replacement or repair of the product as described.
LIMITATION OF LIABILITY
In the event of liability for damages arising from this Limited Warranty or any other claim related to Dun-Bri
Services Ltd’s products, the liability for damages shall be limited to the amount paid for the product at the time
of purchase. Under no circumstances shall Dun-Bri Services Ltd be liable for lost profits, the cost of substitute
equipment or labour, property damage, or other special, consequential, or incidental damages based upon
any claim for breach of contract, improper installation or negligence. Dun-Bri Services Ltd shall not be liable for
any claim even if Dun-Bri Services Ltd or its representatives has been advised that damages of this nature are
sought. Dun-Bri Services Ltd shall have no further obligation or liability with respect to the product or its sale,
operation and use. Dun-Bri Services Ltd neither assumes nor authorises the assumption of any obligation or
liability in connection with this product.
Problem Probable Cause Solution
Module does not function
Wiring error Ensure module wiring is correct and all wire
connections are secure
Blown fuse Check wiring and fuse. Replace fuse
Incorrect flash pattern Wrong flash configuration Re-progam the flash pattern
TROUBLESHOOTING
All modules are performance tested prior to shipment. However, should you encounter a problem at any
time, please refer to the below table for repair solutions. Additional information may be obtained from the
manufacturer if required.
