Tertium NFC SCANNER User manual

NFC SCANNER | USER GUIDE
Step 1 Step 2
Switch on the NFC Scanner by press and hold the
nger on the button until you hear a beep.
Make sure the battery of the NFC Scanner is charged
suciently. If the blue LED is blinking once per
second, you need to charge it.
Step 3
Position the NFC Scanner antenna correctly respect
to the NFC area* of the LED driver for an optimal
connection (see explanation in the next page).
Step 4
To start the reading or writing data to or from the
LED driver you do not need to push the button,
just follow the App instruction and wait the ashing
of the yellow LED.
*NFC area is located over or sideway the LED
driver. It is indicated with the NFC logo.
TERTIUM Technology S.r.l. - Via Emilia, 323 - 56121 Pisa - Italy - Tel. [phone] - www.tertiumtechnology.com

As regards the optimal reading of the LED drivers, NFC Scanner must be positioned
in “edge reading” over the NFC area of LED driver or sideways as shown in
gure 3.
3. 4.
HOW DO YOU READ LED DRIVER CORRECTLY?
1. 2.
As regards the optimal reading of the LED drivers, NFC Scanner must be positioned
in “edge reading” over the NFC area of LED driver or sideways as shown in
gure 1.
TERTIUM Technology S.r.l. - Via Emilia, 323 - 56121 Pisa - Italy - Tel. [phone] - www.tertiumtechnology.com

TERTIUM Technology S.r.l. - Via Emilia, 323 - 56121 Pisa - Italy - Tel. [phone] - www.tertiumtechnology.com
As regards the optimal reading of the LED drivers, NFC Scanner must be positioned
sideways the NFC area of LED driver as shown in gure 5.
HOW DO YOU READ LED DRIVER CORRECTLY?
6.5.
