TESmart HMA0404A70 User manual

www.tesmart.com
1
4x4 HDMI Seamless Matrix
# HMA0404A70
Products Description
The 4 x 4 HDMI Matrix Switch can route any of 4 HDMI video sources to any of 4 HDMI
displays, with a quick view of all port connections via the front panel LCD. The matrix
supports multiple control methods, front-panel push buttons, IR, RS232 and TCP/IP.
It supports seamless switching of HDMI sources with same resolution, ensures no switching
delay and no blank video delay. And supports 2X2 video wall mode, provide you an ideal
solution for applications that require multiple HDMI displays with multiple HDMI sources to
be conveniently setup in multiple locations.
Features
Compliant with HDCP 1.4
Support resolution up to 3840x2160@30Hz
Connect any of 4 HDMI sources to any of 4 HDMI displays
No latency, support seamless switching
Support 2X2 video wall mode
Smart EDID management, make it compatible with most display devices
Matrix status could be memorized after power down, automatically restore previous mat
rix status after next power on
Easy to control matrix via IR remote control, front keypad and PC(via RS232 port or LAN
port)
Easy to view real-time inputs and outputs status via LED display
Support DVI-D single link sources and displays with the use of HDMI-to-DVI adapters
Packing List
1 * 4x4 HDMI Matrix
1 * Remote control
1 * DC 12V Power Adapter
1 * User manual

www.tesmart.com
2
Panel description
1. DC 12V
2. USB port for system upgrade
3. HDMI output
4. HDMI input
5. LAN port
6. RS232 console port
7. 16X2 LCD display
8. Input selection button
9. Output selection button
10. Function keys
11. Output status
12. Input status
13. IR receiver
14. Power status
15. Power switch

www.tesmart.com
3
Connection diagram

www.tesmart.com
4
Specification
HMA0404A70
4x4 HDMI Seamless Matrix
Functionality
Port selection
Front panel buttons
Yes
Console commands
RS232/TCP/IP
IR remote control
Yes
OSD
No
Smart EDID
Yes
Technical
Max. Resolution
3840x2160@30Hz
HDCP version
1.4
Data rate
10.2 Gbps
Input
4*HDMI Type A, 24/26 AWG HDMI cable up to 8M
Output
4*HDMI Type A, 24/26 AWG HDMI cable up to 10M
ESD protection
Human body model - ±8kV (Air-gap discharge)
Mechanical
Chasing material
Metal
Power supply
DC 12V 2A
Operating/Storage
temperature
0 to 70 degree/-40 to 85 degree
Operating Humidity
10 to 90% RH
Product
Dimension
440(L) x 139 (W) x 44.5 (H) mm
Weight
1541g
Item
Dimension
476 (L) x 90 (W) x 232 (H) mm
Weight
2185g
Carton
Dimension
515 (L) x 285 (W) x 470 (H) mm
Quantity
5pcs
Total Weight
11.775kg
