Important: user should make this setting before following operations.
B. In “Common Calibration” interface, short press “▲” or “▼” to select gas, long press
“OK” button, the background of selected gas will turn red, connect calibration gas
and after the value is stable, long press “OK” button to complete this operation with
display of “Set OK”. Short press “ ” to exit.
Notice:
a. Before calibration, activate this device for at least 6 minutes to allow it run stably
b. When the device is alarming for low power, stop calibration and charge it right away
c. Calibration gas must be standard gas used for calibration purpose
d. Zero sensors firstly before calibration
e. Make sure gas flow is stable before connecting calibration gas, calibration gas flow for CH4,
CO, O2 is 200ml/min, 300ml/min for H2S.
f. Suggested calibration gases are as following:
CH4 1.00%vol, CO 500ppm, H2S 50ppm, oxygen can be calibrated in fresh air
11. In setting interface, short press “ ▲” or “ ▼” to select among “CH4”, “LEL”, “PPM”,
“MG/m³”, “Allow Calibration”, “ √” means item is selected. Long press “OK” button to
select and confirm. Short press “ ” to exit.
Important: User can’t enter calibration interface without choosing “Allow Calibration”
4. Technical Parameter:
Technical
Specification
Parameter
Measured gas
Methane(CH4), Oxygen(O2),
Carbon Monoxide(CO), Hydrogen Sulfide(H2S)
Methane (CH4)
Measurement range
(0.00~5.00)%vol
Measurement error
(0.00~1.00)%vol: ±0.10%CH4
(1.00~3.00)%vol: True value±10%
(3.00-5.00)%vol: ±0.30%CH4
Respond time
≤20s (T90)
Resolution
0.01%vol
Alarm point
1.00%vol (Adjustable for full
range)
Oxygen (O2)
Measurement range
(0.0~30.0)%vol
Measurement error
(0.0~5.0)%vol: O2:±0.5%vol
(＞5.0~30.0)%vol: O2:0.9%vol
Respond time
≤35s (T90)
Resolution
0.1%vol
Alarm point
18.0%vol(Adjustable for full range)
25.0%vol(Adjustable for full range)
Carbon Monoxide (CO)
Measurement range
(0~1000)ppm
Measurement error
(0~20)ppm:±2ppm
(＞20~100)ppm: ±4ppm

(＞100~500)ppm: True Value±5%
(＞500~1000)ppm:True value±6%
Respond time ≤45s (T90)
Resolution 1ppm Alarm point 24%vol(Adjustable for full range)
Hydrogen Sulfide (H2S)
Measurement range (0~100)ppm
Measurement error (0~50)ppm:±3ppm
(＞50~100)ppm: ±10%
Respond time ≤45s (T90)
Resolution 1ppm Alarm point 10ppm(Adjustable for full range)
Sensor lifetime CH4: ≥1 year
CO,H2S,O2: ≥2 years
Alarms Audible--buzzer with ≥85dB @1m audible
Visible--flashing red LED, ≥20m visible
Vibration
Charging time 4-5hours
Continuous operating
hours
13 hours
Battery model PL123450, 3.7V/1500mA
Protect Grade IP66
Working temperature -25℃
~
50℃
Size(mm) 130*70*37
Data logging for
MG08 only
Continuously data logging
(100000 records with 1-10 minutes interval)
Enclosure PC+ABS with resistance ≤10-9Ω
Display Color Screen LCD
≥
