TEUCER LR-8RGBW User manual

Teucer`s RGBW controller enables control of up to 8 zones.
As well as dimming this product this product can be used in
conjuncon with the LR-WTC receiver and paired with the
LR-WIFI trans and the Easy lighng app therefore allowing
any Android or Apple smartphone/ tablet to simultaneous
control the lighng wirelessly whilst maintaining synchro-
nous operaons.
Product Descripon
Technical Specicaon
Brighter for longer
CONTROLLER AND RECEIVER
www.teucerled.co.uk
Controller
Order Code LR-8RGBW
Type RF remote controller
Input Voltage 5VDC
Operaon Frequency 434MHz / 868MHz / 915Mhz
Dimension 115.4x58.8x12mm (WxLxH)
Power 3.7V (Lithium Baery), USB charge
Receiver
Order Code LRR-WTC
Type RF receiver
Input Voltage 12-36VDC
Current 4X5A
Output 4X(60-180)W
Note Constant voltage
Dimension 46x178x22mm (WxLxH)
• Control up to 8 zones independently or simultaneously
• Adjust colour and brightness
• Smartphone / tablet compable via Easy Lighng app
• Wireless RF range of 8-15 meters (depending on signal
obstacles within the installaon area)
• Save light funcons and preferences to each zone
• 5%-100% smooth dimming
Features
RF technology allows for greater exibility when it comes to
controlling simple or complex lighng installaons without
the need of addional cabling.
There are some limitaons where installaons have the
receivers enclosed in electrical boxes or hidden away in a
ceiling, reducing the RF signal strength and therefore the
communicaon range.
In order to overcome these RF Signal restricons we sug-
gest the following when synchronising our RF controllers
and receivers:
• Keep the distance within 10 meters from the controller
to the receiver
• When expanding your lighng, always try and use a
signal repeater (PR-RGB), where possible.
• If your installaon requires several RF receivers, ensure
the “master” receiver is posioned in the middle.
Recommendaon
LR-8RGBW and LRR-WTC
8 zone RF & WIFI controller and receiver for RGBW LED strip

Receiver wiring diagram
Controller layout
Brighter for longer
CONTROLLER AND RECEIVER
www.teucerled.co.uk
When wiring the receivers, it s mportant to make sure the total waage of the LED strips does not exceed the maximum
rated waage per channel of the receiver. Each chanel is rated at 5A, so the maximum waage per channel is 24x5A=120w.
The power supply has to match the rated voltage and be superior to the total LED strip waage by a remcommended 10%.
5
6
7
8
1
2
3
4
Click to switch ON/OFF
Red channel:Click to turn off/on, Press and
hold down to increase/decrease light intensity
Green channel:Click to turn off/on, Press and
hold down to increase/decrease light intensity
Blue channel:Click to turn off/on, Press and
hold down to increase/decrease light intensity
White channel:Click to turn off/on, Press and
hold down to increase/decrease light intensity
Play & pause mode, click to play or pause
running mode
Save color, press and hold down to save,
click to recall the saved
Return to previous status
Speed up, press and hold down
to speed up the running mode
Speed down, press and hold down
to speed down the running mode
Brightness up, press and hold down to
increase light intensity
Brightness down, press and hold down
to decrease light intensity
5
6
7
8
1
2
3
4
8 zones, click to select a zone,
press and hold down to turn on/off
corresponding zone
USB port
Off
On
Indicator will be on while remote is charging.
Indicator will be off while it's full charged.
Power Switch
LED indicator
Note: If remote control is not used for
a long time, please charge it every two months.
1
23
LRR-WTC
Learning Key
4
MASTER SLAVE
L
N
110V-230VACPower Supply
W
1
23
LRR-WTC
Learning Key
4
MASTER SLAVE
L
N
110V-230VACPower Supply
W
LR-8RGBW and LRR-WTC
8 zone RF & WIFI controller and receiver for RGBW LED strip

Synchronising the controller to receiver
Brighter for longer
CONTROLLER AND RECEIVER
www.teucerled.co.uk
1) Turn the controller ON. Red LED indicator will be light up.
3) Ensure the receiver has power. Press the learning key on the receiver.
4) Ensure the controller is turned ON (red light
indicator ON) and press the zone you which to
allocate to the receiver, than touch the colour
wheel. The LED strips will blink to conrm syn-
chronisaon has been successful.
6) To clear the receiver from a selected zone, simply press and hold the learning key for 5 or
more seconds. The receiver will be reset to the default factory sengs.
Learning key
1
23
LRR-WTC
Learning Key
4
MASTER SLAVE
W
2) Set the receiver LRR-WTC as a MASTER OR SLAVE.
Allocang the receiver as a master or slave is important to ensure your LED strip and receiv-
er are fully synchronised. There can be only 1 master receiver per zone.
close circuit for MASTER
open circtuit for SLAVE
1
23
LRR-WTC
Learning Key
4
MASTER SLAVE
W
1. Select your zone
2. Touch the colour wheel
The LED strip will flash
to confirm synchronisa�on.
5
6
7
8
1
2
3
4
5) Just repeat the learning process to synchronise several receivers to the same controller.
LR-8RGBW and LRR-WTC
8 zone RF & WIFI controller and receiver for RGBW LED strip

Teucer (UK) Ltd
Head oce
Bedford House, Fulham Green, Fulham High Street,
London, SW6 3JW, UK
Tel: [phone]
Fax: [phone]
www.teucerled.co.uk
[e-mail]
Logiscs Centre
Trident Court,
1 Oakcro Road,
Chessington,
Surrey, KT9 1BD, London, UK
Tel: [phone], extension: 401
[e-mail]
Controlling your LED strip
Brighter for longer
CONTROLLER AND RECEIVER
www.teucerled.co.uk
With LR-8RGBW one can adjust the brightness and colour temperature of the RGBW LED strip.
• Choose the zone(s) you wish to control.
Select as many zones as you wish.
• Touch the colour wheel to change colours.
• Press and hold R/G/B/W to individually
dim them up or down.
• Choose one of 10 pre-set play modes.
• Speed up or slow down the play modes.
5
6
7
8
1
2
3
4
Click to switch ON/OFF
Red channel:Click to turn off/on, Press and
hold down to increase/decrease light intensity
Green channel:Click to turn off/on, Press and
hold down to increase/decrease light intensity
Blue channel:Click to turn off/on, Press and
hold down to increase/decrease light intensity
White channel:Click to turn off/on, Press and
hold down to increase/decrease light intensity
Play & pause mode, click to play or pause
running mode
Save color, press and hold down to save,
click to recall the saved
Return to previous status
Speed up, press and hold down
to speed up the running mode
Speed down, press and hold down
to speed down the running mode
Brightness up, press and hold down to
increase light intensity
Brightness down, press and hold down
to decrease light intensity
5
6
7
8
1
2
3
4
8 zones, click to select a zone,
press and hold down to turn on/off
corresponding zone
Warranty
• Products must be installed and serviced by qualied
electrician.
• Please ensure the receiver is mounted in a water proof
enclosure if installed in an outdoor environment,
avoiding metallic enclosures.
• Always ensure products are mounted in areas with
adequate venlaon to avoid overheang.
• Please ensure outputs of any power suppliers used in
conjucon with this product comply with its working
voltage.
• Never install product whilst connected to power and
double check connecons before switching on to
avoid short circuits.
Safety
Should this product fail during the 3 year warranty
period it will be replaced free of charge, subject to the
correct installaon of the original product in accordance
with applicable and appropriate electrical codes and
instrucons provided by Teucer, as well as subsequent
return of the faulty unit. Teucer does not accept
responsibility for any installaon costs associated with
the replacement of this product and Teucer reserves the
right to alter specicaons without prior noce. Teucer
can oer 5 year warranty upon request. For further
informaon, please see our Terms and Condions.
www.teucerled.co.uk/terms-and-condions/
LR-8RGBW and LRR-WTC
8 zone RF & WIFI controller and receiver for RGBW LED strip
