TEUCER LR-W User manual

This controller is used to control and dim single colour LED
strip. It enables the user to access 3 pre-set lighng levels
from the touch of a buon or adjust your lighng with
smooth dimming (5%-100%) via the touch sensive wheel.
Product Descripon
Technical Specicaon
Brighter for longer
CONTROLLER AND RECEIVER
www.teucerled.co.uk
Controller
Order Code LR-W
Type RF remote controller
Input Voltage 3.6VDC
Operaon Frequency 2.46GHz
Dimension 56x113x22mm (WxLxH)
Power Baeries 2xAAA
Receiver
Order Code LRR-W
Type RF receiver
Input Voltage 12-24VDC
Current 2x6A
Output 2x(72-144)W
Note Constant voltage
Dimension 45x85x23mm (WxLxH)
Features
RF technology allows for greater exibility when it
comes to controlling simple or complex lighng instal-
laons without the need of addional cabling.
There are some limitaons where installaons have
the receivers enclosed in electrical boxes or hidden
away in a ceiling, reducing the RF signal strength and
therefore the communicaon range.
In order to overcome these RF Signal restricons we
suggest the following when synchronising our RF con-
trollers and receivers:
• Keep the distance within 10 meters from the con-
troller to the receiver
• When expanding your lighng, always try and use
a signal repeater (PR-RGB), where possible
• It is not recommended to use more than 4 receiv-
ers with a single zone controller.
• This controller / receiver does not have a master/
slave funcon, meaning if you connect several
receivers to the same controller, the LED strip will
become unsynchronised when put into a colour
changing programme (play mode), however it will
not aect the performance in the stac mode.
Recommendaon
• 5%-100% smooth dimming capacity
• Touch sensive brightness wheel
• Wireless RF (Radio Frequency) range of 8-15m (de-
pending on signal obstacles within the installaon area)
LR-W and LRR-W
1 zone RF controller and receiver for single colour LED strip

Receiver wiring diagram
Remote controller layout
Brighter for longer
CONTROLLER AND RECEIVER
www.teucerled.co.uk
• Do not connect power before wires are connected to the receiver and the driver.
• Please check weather the input voltage of the constant voltage driver is in accordance with the controller, and check
connecon of both posive (+) and negave(-) of the LED strip.
• Please do not use the controller in an area saturated with wireless products (interference) nearby, otherwise, the re-
mote’s transmission distance will be seriously aected.
• It is important to ensure your ngers are not making contact with the colour wheel when installing the baeries.
• It is not recommended to use CAT5 cable to connect any Teucer product.
LR-W and LRR-W
1 zone RF controller and receiver for single colour LED strip
ON
bu�on
OFF
bu�on
Highest brightness
Brightness wheel
Lowest brightness Medium brightness
ON OFF

Synchronising the controller to receiver
Brighter for longer
CONTROLLER AND RECEIVER
www.teucerled.co.uk
2) Turn ON the remote.
1) Conrm that receiver is correctly connected with power supply and LED strip. The strip should light up when
turned on. Turn it o.
All controllers and receivers sold in a pack are pre-sychronised. There is no need to sync the remote to the re-
ceiver. Only follow instrucons below if you are adding another receiver with the same remote.
4) Sync the remote controller to the addional receiver by pressing the highest brightness buon within 3 sec-
onds of powering the receiver. (Do not press and hold.)
3) Turn ON the second receiver.
5) Repeat the above instrucons to synchronise addional receivers.
Press to
turn ON
ON OFF
Press highest
brightness
bu�on
ON OFF
LR-W and LRR-W
1 zone RF controller and receiver for single colour LED strip

Teucer (UK) Ltd
Head oce
Bedford House, Fulham Green, Fulham High Street,
London, SW6 3JW, UK
Tel: [phone]
Fax: [phone]
www.teucerled.co.uk
[e-mail]
Logiscs Centre
Trident Court,
1 Oakcro Road,
Chessington,
Surrey, KT9 1BD, London, UK
Tel: [phone], extension: 401
[e-mail]
Controlling your LED strip
Brighter for longer
CONTROLLER AND RECEIVER
www.teucerled.co.uk
With LR-W you can adjust the brightnes of single colour LED strip.
LR-W and LRR-W
1 zone RF controller and receiver for single colour LED strip
ON OFF
Press to turn ON Press to turn OFF
Press for highest
brightness
Adjust the
brightness level
by dimming up
or down
Press for lowest
brightness
Press for medium
brightness
Warranty
• Products must be installed and serviced by qualied
electrician.
• Please ensure the receiver is mounted in a water proof
enclosure if installed in an outdoor environment,
avoiding metallic enclosures.
• Always ensure products are mounted in areas with
adequate venlaon to avoid overheang.
• Please ensure outputs of any power suppliers used in
conjucon with this product comply with its working
voltage.
• Never install product whilst connected to power and
double check connecons before switching on to
avoid short circuits.
Safety
Should this product fail during the 3 year warranty
period it will be replaced free of charge, subject to the
correct installaon of the original product in accordance
with applicable and appropriate electrical codes and
instrucons provided by Teucer, as well as subsequent
return of the faulty unit. Teucer does not accept
responsibility for any installaon costs associated with
the replacement of this product and Teucer reserves the
right to alter specicaons without prior noce. Teucer
can oer 5 year warranty upon request. For further
informaon, please see our Terms and Condions.
