Texas Instruments DS90UB95x-Q1EVM Series User manual

User’s Guide
DS90UB95x-Q1 Serializer Evaluation Module
ABSTRACT
The Texas Instruments DS90UB95x-Q1EVM evaluation module (EVM) is a functional board design for
evaluating the DS90UB953-Q1 FPD-Link III serializer, the DS90UB635-Q1 low-cost FPD-Link III serializer,
and the TSER953 V3Link serializer. This document provides necessary details for the evaluation, such as a
brief product overview, quick-start guide, troubleshooting section, schematics, printed-circuit board (PCB) layout
details, and bill of materials (BOM).
The DS90UB953-Q1, DS90UB635-Q1, and TSER953 serializers represent the next generation in FPD-Link
III and V3Link serializers and are designed to support high-speed raw data sensors including 2-MP imagers
at 60 fps, as well as 4-MP, 30-fps cameras, satellite RADAR, LIDAR, and time-of-flight (ToF) sensors. The
chip delivers a 4-Gbps+ forward channel and an ultra-low latency, 50-Mbps bidirectional control channel. The
chip also supports power over a single coax (PoC) or shielded twisted-pair (STP) cable and connector. The
DS90UB953-Q1, DS90UB635-Q1, and TSER953 feature advanced data protection and diagnostic features to
support ADAS, autonomous driving, and industrial and medical imaging applications. Together with a companion
deserializer, the chip delivers precise multi-camera sensor clock and sensor synchronization. For a full list of
device characteristics, refer to the datasheet for each device.
Table of Contents
1 Introduction.............................................................................................................................................................................3
2 Quick Start Guide....................................................................................................................................................................4
3 Troubleshooting......................................................................................................................................................................7
4 Bill of Materials..................................................................................................................................................................... 39
5 PCB Schematics................................................................................................................................................................... 43
6 Board Layout.........................................................................................................................................................................47
7 Related Documentation........................................................................................................................................................53
8 Revision History................................................................................................................................................................... 53
List of Figures
Figure 1-1. DS90UB95x-Q1EVM Top View................................................................................................................................. 3
Figure 2-1. Typical Application Block Diagram Using DS90UB953-Q1 and DS90UB954-Q1 (or variant)...................................4
Figure 2-2. DS90UB95x-Q1EVM Major Components................................................................................................................. 5
Figure 2-3. DS90UB95x-Q1EVM With Installed Jumpers........................................................................................................... 5
Figure 2-4. DS90UB954-Q1EVM (or variant) With Jumpers Highlighted.................................................................................... 6
Figure 3-1. USB2ANY..................................................................................................................................................................7
Figure 3-2. I2C Pinout of USB2ANY Connector.......................................................................................................................... 8
Figure 3-3. Launching ALP........................................................................................................................................................ 10
Figure 3-4. Initial ALP Screen....................................................................................................................................................10
Figure 3-5. Follow-Up Screen.................................................................................................................................................... 11
Figure 3-6. ALP Information Tab................................................................................................................................................12
Figure 3-7. ALP Registers Tab...................................................................................................................................................13
Figure 3-8. ALP Device ID Selected.......................................................................................................................................... 14
Figure 3-9. ALP Device ID Expanded........................................................................................................................................15
Figure 3-10. Writing to Register 0x00 by Checking Bits in ALP.................................................................................................15
Figure 3-11. ALP Scripting Tab.................................................................................................................................................. 16
Figure 3-12. Pre-Defined Scripts............................................................................................................................................... 17
Figure 3-13. Custom Button Creation Step 1.............................................................................................................................18
Figure 3-14. Custom Button Creation Step 2.............................................................................................................................18
Figure 3-15. ALP Scripting Tab..................................................................................................................................................21
Figure 3-16. USB2ANY Setup................................................................................................................................................... 22
www.ti.com Table of Contents
SNLU224D – SEPTEMBER 2017 – REVISED FEBRUARY 2023
Submit Document Feedback
DS90UB95x-Q1 Serializer Evaluation Module 1
Copyright © 2023 Texas Instruments Incorporated

Figure 3-17. Remove Incorrect Profile.......................................................................................................................................22
Figure 3-18. Add Correct Profile................................................................................................................................................ 23
Figure 3-19. Finish Setup.......................................................................................................................................................... 23
Figure 3-20. ALP No Devices Error........................................................................................................................................... 24
Figure 3-21. Windows 7, ALP USB2ANY Driver........................................................................................................................24
Figure 3-22. ALP in Demo Mode............................................................................................................................................... 25
Figure 3-23. ALP Preferences Menu......................................................................................................................................... 25
Figure 3-24. Error that States One Instance of This Application Can Be Active in ALP............................................................ 26
Figure 3-25. Ending MainGUI.exe in Task Manager..................................................................................................................26
Figure 3-26. Error That States That USB2ANY Firmware Must be Updated.............................................................................27
Figure 3-27. USB2ANY Firmware Loader Program Dialog....................................................................................................... 28
Figure 3-28. USB2ANY Without Enclosure............................................................................................................................... 29
Figure 3-29. USB2ANY With Enclosure.................................................................................................................................... 29
Figure 3-30. Verifying DS90UB95x Register............................................................................................................................. 30
Figure 3-31. Window for Setting up Scripts in ALP....................................................................................................................30
Figure 3-32. DS90UB954-Q1EVM (or variant) With Highlighted Jumpers................................................................................ 33
Figure 3-33. DS90UB95x-Q1EVM With Installed Jumpers....................................................................................................... 34
Figure 3-34. Test Setup............................................................................................................................................................. 35
Figure 3-35. Setting up Device Profiles in ALP..........................................................................................................................36
Figure 3-36. Navigating to DS90UB954 (or variant) Scripting Tab in ALP.................................................................................36
Figure 3-37. Reading I2C Device ID Within the Register Tab....................................................................................................37
Figure 3-38. Verifying Pass and Lock for DS90UB954 (or variant) in ALP................................................................................37
Figure 3-39. Verifying Camera Initialization in ALP................................................................................................................... 38
Figure 5-1. DS90UB95x-Q1EVM Schematic 1.......................................................................................................................... 43
Figure 5-2. DS90UB95x-Q1EVM Schematic 2.......................................................................................................................... 44
Figure 5-3. DS90UB95x-Q1EVM Schematic 3.......................................................................................................................... 45
Figure 5-4. DS90UB95x-Q1EVM Schematic 4.......................................................................................................................... 46
Figure 6-1. Top Layer PCB Layout............................................................................................................................................ 47
Figure 6-2. Top Overlay............................................................................................................................................................. 47
Figure 6-3. Top Paste................................................................................................................................................................ 48
Figure 6-4. Top Solder............................................................................................................................................................... 48
Figure 6-5. Signal Layer 1......................................................................................................................................................... 49
Figure 6-6. Signal Layer 2......................................................................................................................................................... 49
Figure 6-7. Signal Layer 3......................................................................................................................................................... 50
Figure 6-8. Signal Layer 4......................................................................................................................................................... 50
Figure 6-9. Bottom Layer PCB Layout.......................................................................................................................................51
Figure 6-10. Bottom Overlay......................................................................................................................................................51
Figure 6-11. Bottom Paste......................................................................................................................................................... 52
Figure 6-12. Bottom Solder........................................................................................................................................................52
List of Tables
Table 3-1. Equipment.................................................................................................................................................................31
Table 4-1. Bill of Materials..........................................................................................................................................................39
Trademarks
All trademarks are the property of their respective owners.
Trademarks www.ti.com
2DS90UB95x-Q1 Serializer Evaluation Module SNLU224D – SEPTEMBER 2017 – REVISED FEBRUARY 2023
Submit Document Feedback
Copyright © 2023 Texas Instruments Incorporated

1 Introduction
Note
The demo board is not optimized for EMI testing. The demo board was designed for easy accessibility
to device pins with tap points for monitoring or applying signals, additional pads for termination, and
multiple connector options.
Figure 1-1. DS90UB95x-Q1EVM Top View
www.ti.com Introduction
SNLU224D – SEPTEMBER 2017 – REVISED FEBRUARY 2023
Submit Document Feedback
DS90UB95x-Q1 Serializer Evaluation Module 3
Copyright © 2023 Texas Instruments Incorporated

2 Quick Start Guide
The quick start guide is intended to get the DS90UB95x-Q1EVM operational with the minimum amount of
information. See Section 3.5 in the troubleshooting section for in-depth, step-by-step instructions.
2.1 System Requirements
The major components of the DS90UB95x-Q1EVM are:
• DS90UB95x-Q1 Serializer Board
• On-board Power-over-Coax (PoC) interface
• FAKRA connector for digital video, power, and diagnostics
• On-board I2C programming interface
To demonstrate, TI recommends the following (not included):
• DS90UB954-Q1EVM (or variant)
• One DACAR/FAKRA coax cable
• DC power supply for DS90UB954-Q1EVM (or variant) only
• Power supply cables: for example, banana to coax, banana to grabber, and so forth.
• Two male USB-to-mini USB cables
• USB2ANY or an Aardvark I2C/SPI Host Adapter
• Analog LaunchPAD software (download Analog Launch PAD from TI.com (a myTI Login required). Steps for
installation can be found in Section 3.3). This software is not required if an external ECU is used.
2.2 Application Block Diagram
IDx
MIPI CSI-2
HS_GPIO
(SPI)
Signal
Processor
(ISP)
Full HD
Image Sensor
1920x1200
60fps
I2C
1.8 V 1.8 V
MIPI CSI-2
D3+/-
D2+/-
D1+/-
D0+/-
CLK+/-
FPD-Link III
(over Coax or STP)
HS_GPIO
(SPI)
IDx
I2C
DS90UB953
Serializer
0.033 µF 0.033 µF
DOUT0-
DS90UB954
Deserializer
D3+/-
D2+/-
D1+/-
D0+/-
CLK+/-
DOUT0+ RIN0+
RIN0-
0.015 µF
50 Ÿ
0.015 µF
50 Ÿ
Figure 2-1. Typical Application Block Diagram Using DS90UB953-Q1 and DS90UB954-Q1 (or variant)
Quick Start Guide www.ti.com
4DS90UB95x-Q1 Serializer Evaluation Module SNLU224D – SEPTEMBER 2017 – REVISED FEBRUARY 2023
Submit Document Feedback
Copyright © 2023 Texas Instruments Incorporated

2.3 Major Components of DS90UB95x-Q1EVM
Optional Daughter Card Connector
Figure 2-2. DS90UB95x-Q1EVM Major Components
2.4 Demo Instructions for DS90UB95x-Q1EVM
1. Ensure jumpers on J2, J4, and J15 for DS90UB95x-Q1EVM are installed as shown in Figure 2-3
Figure 2-3. DS90UB95x-Q1EVM With Installed Jumpers
www.ti.com Quick Start Guide
SNLU224D – SEPTEMBER 2017 – REVISED FEBRUARY 2023
Submit Document Feedback
DS90UB95x-Q1 Serializer Evaluation Module 5
Copyright © 2023 Texas Instruments Incorporated

2. Ensure jumpers and switches for DS90UB954-Q1EVM (or variant) are configured like shown in Figure 2-4.
See the DS90UB954-Q1EVM User's Guide (SNLU223) for further details.
Figure 2-4. DS90UB954-Q1EVM (or variant) With Jumpers Highlighted
3. Connect the DACAR coax cable with FAKRA connector to RX0p from the DS90UB954-Q1EVM (or variant)
to J16 of the DS90UB95x-Q1EVM
4. Connect a mini USB to J2 on the DS90UB954-Q1EVM (or variant) and J9 on the DS90UB95x-Q1EVM to a
device with Analog LaunchPAD (ALP) software installed
5. Power the DS90UB954-Q1EVM (or variant) with 12 V through J1
6. Open ALP and assign the correct DS90UB953 and DS90UB954 (or variant) profiles to the appropriate USB
IDs
7. The DS90UB95x-Q1EVM and DS90UB954-Q1EVM (or variant) should now be linked and have established
connection. Go to information tab on the DS90UB954 (or variant) device window and confirm that Pass Sts
displays Pass and Linked has the appropriate frequency displayed. Also check if Pass and Lock LEDs are lit
8. Navigate back to the Scripting tab of the DS90UB954 (or variant) ALP profile and run the
953to954_patgen_YUV_1920x1080p-4Lanes-Working.py script to initialize a pattern generation test from
the 953. The script may be found by clicking on the "Run PreDef Script" button. If the DS90UB954-Q1 (or
variant) is not using an I2C address of 0x7A (8-bit form), the script should be modified to use the correct I2C
address. Go back to the information tab of the DS90UB954-Q1 (or variant) and confirm the horizontal and
vertical parameters read 3820 bytes and 1080 lines, respectively.
9. If there are any problems, consult Section 3.5 for an in-depth step-by-step guide to enable the pass and lock
2.5 Use With DS90UB935-Q1
The only modification required to use the DS90UB95x-Q1EVM to evaluate the DS90UB935-Q1 is to exchange
the DS90UB953-Q1 with the DS90UB935-Q1. No additional rework is required.
Quick Start Guide www.ti.com
6DS90UB95x-Q1 Serializer Evaluation Module SNLU224D – SEPTEMBER 2017 – REVISED FEBRUARY 2023
Submit Document Feedback
Copyright © 2023 Texas Instruments Incorporated

3 Troubleshooting
3.1 Default Addresses
The default 9-bit I2C address of DS90UB95xis set to 0x30 (011 0000) using suitable resistor divider on ID[x] pin.
Also, 8-bit I2C address of DS90UB954 (or variant) is set to 0x7A (0111 1010) using suitable resistor dividers on
pins IDX[0] and IDX[1].
3.2 USB2ANY
The USB2ANY is required to work with any interactive GUI over I2C, such as ALP (Analog LaunchPAD).
Download and install ALP from: http://www.ti.com/tool/ALP.
The USB2ANY is shown in Figure 3-1. It is powered through the USB port of computer.
Figure 3-1. USB2ANY
There are two methods to use the USB2ANY to communicate with the 953/954 EVMs. The first method is to
simply connect the USB to Mini-USB cable to the USB port of your computer and the Mini-USB ports on the
EVMs, J9 for the 953 EVM (see Figure 2-2) and J2 on the 954 EVM. If using the first method, skip to Section 3.3.
The second method is to use the pinout of the USB2ANY. Figure 3-2 shows the USB2ANY pinout with the I2C
pins highlighted. Typically, jumper wires are used to connect these to the 953/954 EVMs.
www.ti.com Troubleshooting
SNLU224D – SEPTEMBER 2017 – REVISED FEBRUARY 2023
Submit Document Feedback
DS90UB95x-Q1 Serializer Evaluation Module 7
Copyright © 2023 Texas Instruments Incorporated

Figure 3-2. I2C Pinout of USB2ANY Connector
On the DS90UB954-Q1EVM (or variant), connect the other ends of the corresponding wires to pins 2, 3, and 4 of
J25 labeled SCL, SDA, and GND, respectively.
On the DS90UB95x-Q1EVM, connect the other ends of the corresponding wires to pins 1, 2, and 3 of J5 for 1.8
V, or J6 for 3.3 V labeled SCL, SDA, and GND, respectively. Note that these voltages refer to the pullup voltage
used in I2C communication. As a result, check the mode of the I2C adapter before plugging in to the adapter.
Connecting the Mini USB to USB cable from the port of the USB2ANY to the computer should allow ALP to
communicate with the EVM. However, if the EVMs are configured to have 1.8 V I2C signal levels (see J5 on
the 953 EVM and J16 on the 954 EVM), the USB2ANY must be configured to support the 1.8 V required
by the DS90UB95x-Q1EVM and DS90UB954-Q1EVM (or variant). To do this, the user must navigate to the
USB2ANY.py script and change the code. The path to the file is given below:
SPACER
C:\Program Files (x86)\Texas Instruments\Analog LaunchPAD
v1.56.0010\Drivers\i2c_controllers\usb2any\python
SPACER
Once the usb2any_lib.py script is found, open the script in a text editing program (for example, Notepad,
Wordpad, Notepad++, and so forth) and replace Line 61 from:
SPACER
self.usb2anydll.u2aI2C_Control(self.u2ahandle,1,0,0)
SPACER
To the following:
SPACER
self.usb2anydll.u2aI2C_Control(self.u2ahandle,1,0,1)
self.usb2anydll.u2aPower_WriteControl(self.u2ahandle,1,0)
SPACER
Save the script, close the program, and ALP will now recognize the connection from the board to the USB2ANY.
Troubleshooting www.ti.com
8DS90UB95x-Q1 Serializer Evaluation Module SNLU224D – SEPTEMBER 2017 – REVISED FEBRUARY 2023
Submit Document Feedback
Copyright © 2023 Texas Instruments Incorporated

3.3 ALP Software Setup
Note
The ALP Software Setup example used in this section refers to several FPD-Link parts. Specific
screenshots may not be for the DS90UB954-Q1 or DS90UB953-Q1, however, the process remains
the same for using the DS90UB95x-Q1EVM and DS90UB954-Q1EVM.
3.3.1 System Requirements
Operating System: Windows 7 64-bit
USB: USB2ANY
USB2ANY Firmware Version: 2.5.2.0
USB: Aardvark I2C/SPI host adapter
p/n TP240141
3.3.2 Download Contents
The latest TI Analog LaunchPAD can be downloaded from: http://www.ti.com/tool/alp.
Download and extract the zip file to a temporary location that can be deleted later.
The following installation instructions are for a PC running Windows 7 64-bit Operating System.
3.3.3 Installation of the ALP Software
Execute the ALP Setup Wizard program called ALPF_setup_v_x_x_x.exe that was extracted to a temporary
location on the local drive of your PC.
There are 7 steps to the installation once the setup wizard is started:
1. Select the Next button.
2. Select I accept the agreement and then select the Next button.
3. Select the location to install the ALP software and then select the Next button.
4. Select the location for the start menu shortcut and then select the Next button.
5. There will then be a screen that allows the creation of a desktop icon. After selecting the desired choices
select the Next button.
6. Select the Install button, and the software will then be installed to the selected location.
7. Uncheck Launch Analog LaunchPAD and select the Finish button. The ALP software will start if Launch
Analog LaunchPAD is checked, but it will not be useful until the USB driver is installed and board is attached.
Power the DS90UB95x-Q1 EVM board with a 12-VDC power supply.
3.3.4 Start-Up - Software Description
Make sure all the software has been installed and the hardware is powered on and connected to the PC.
Execute Analog LaunchPAD shortcut from the start menu. The default start menu location is under All Programs
> Texas Instruments > Analog LaunchPAD vx.x.x > Analog LaunchPAD to start MainGUI.exe.
www.ti.com Troubleshooting
SNLU224D – SEPTEMBER 2017 – REVISED FEBRUARY 2023
Submit Document Feedback
DS90UB95x-Q1 Serializer Evaluation Module 9
Copyright © 2023 Texas Instruments Incorporated

Figure 3-3. Launching ALP
The application should come up in the state shown in Figure 3-4. If it does not, see Section 3.4.
Under the Devices tab, click twice on the DS90UB95x to select the device to open the device profile and its
associated tabs. If the incorrect profile is shown, consult Section 3.4.1.
Figure 3-4. Initial ALP Screen
After selecting the DS90UB95x, the following screen shown in Figure 3-5 should appear.
Troubleshooting www.ti.com
10 DS90UB95x-Q1 Serializer Evaluation Module SNLU224D – SEPTEMBER 2017 – REVISED FEBRUARY 2023
Submit Document Feedback
Copyright © 2023 Texas Instruments Incorporated

Figure 3-5. Follow-Up Screen
www.ti.com Troubleshooting
SNLU224D – SEPTEMBER 2017 – REVISED FEBRUARY 2023
Submit Document Feedback
DS90UB95x-Q1 Serializer Evaluation Module 11
Copyright © 2023 Texas Instruments Incorporated

3.3.5 Information Tab
The Information tab is shown in Figure 3-6.
Figure 3-6. ALP Information Tab
Troubleshooting www.ti.com
12 DS90UB95x-Q1 Serializer Evaluation Module SNLU224D – SEPTEMBER 2017 – REVISED FEBRUARY 2023
Submit Document Feedback
Copyright © 2023 Texas Instruments Incorporated

3.3.6 Registers Tab
The Register tab is shown in Figure 3-7.
Figure 3-7. ALP Registers Tab
www.ti.com Troubleshooting
SNLU224D – SEPTEMBER 2017 – REVISED FEBRUARY 2023
Submit Document Feedback
DS90UB95x-Q1 Serializer Evaluation Module 13
Copyright © 2023 Texas Instruments Incorporated

3.3.7 Registers Tab - Address 0x00 Selected
Figure 3-8 shows Address 0x00 selected. Note that the Value: box, , will now show the hex value
of that register.
Figure 3-8. ALP Device ID Selected
Troubleshooting www.ti.com
14 DS90UB95x-Q1 Serializer Evaluation Module SNLU224D – SEPTEMBER 2017 – REVISED FEBRUARY 2023
Submit Document Feedback
Copyright © 2023 Texas Instruments Incorporated

3.3.8 Registers Tab - Address 0x00 Expanded
By double clicking on the Address bar
or a single click on , the expanded Address 0x00 reveals contents by bits. Any register address displayed can
be expanded.
Figure 3-9. ALP Device ID Expanded
Any RW Type register, , can be written into by writing the hex value into the Value: box, or
putting the pointer into the individual register bit(s) box by a left mouse click to put a check mark (indicating a
1) or unchecking to remove the check mark (indicating a 0). Click the Apply button to write to the register, and
refresh to see the new value of the selected (highlighted) register.
Figure 3-10. Writing to Register 0x00 by Checking Bits in ALP
The box toggles on every mouse click.
www.ti.com Troubleshooting
SNLU224D – SEPTEMBER 2017 – REVISED FEBRUARY 2023
Submit Document Feedback
DS90UB95x-Q1 Serializer Evaluation Module 15
Copyright © 2023 Texas Instruments Incorporated

3.3.9 Scripting Tab
Figure 3-11 shows the Scripting tab. The script window provides a full Python scripting environment which can
be for running scripts and interacting with the device in an interactive or automated fashion. Commands may be
written directly into the Scripting tab or may be run from a .py file using the "Run" button. Example scripts may
be found using the "Run PreDef Script" button.
Figure 3-11. ALP Scripting Tab
Troubleshooting www.ti.com
16 DS90UB95x-Q1 Serializer Evaluation Module SNLU224D – SEPTEMBER 2017 – REVISED FEBRUARY 2023
Submit Document Feedback
Copyright © 2023 Texas Instruments Incorporated

Figure 3-12. Pre-Defined Scripts
It is also possible to create custom buttons on the Scripting tab to run a desired script. To do so, click on the
"Setup" button, then say "Add", and select the desired name and script. To make the button appear in future
instances of ALP, click the "Set As Default" button.
www.ti.com Troubleshooting
SNLU224D – SEPTEMBER 2017 – REVISED FEBRUARY 2023
Submit Document Feedback
DS90UB95x-Q1 Serializer Evaluation Module 17
Copyright © 2023 Texas Instruments Incorporated

1
2
3
4
5
Figure 3-13. Custom Button Creation Step 1
6
7
Figure 3-14. Custom Button Creation Step 2
WARNING
Directly interacting with devices either through register modifications or calling device support library
functions can effect the performance and/or functionality of the user interface and may even crash
the ALP Framework application.
3.3.9.1 Example Functions
The following are Python functions commonly used to interact with FPD-Link devices.
Troubleshooting www.ti.com
18 DS90UB95x-Q1 Serializer Evaluation Module SNLU224D – SEPTEMBER 2017 – REVISED FEBRUARY 2023
Submit Document Feedback
Copyright © 2023 Texas Instruments Incorporated

3.3.9.1.1 Local I2C Reads/Writes
These functions will perform reads and writes only for the I2C assigned to board.devAddr, which by default will
be the detected address for the DS90UB954-Q1 (or variant).
board.ReadReg(Register
Address , # of Bytes)
OR board.ReadReg(Register
Address)
I2C Read Command
• Accepts both hex & decimal inputs
• Number of bytes will default to 1 if omitted
• Ex: board.ReadReg(0x00) will return the value in Register 0 for the local
device
board.WriteReg(Register
Address , Data)
I2C Write Command
• Accepts both hex & decimal inputs
• Ex: board.WriteReg(0x01, 0x01) will set Register 0 to have a value of 1
board.devAddr = [I2C Address] Assigns I2C address to be used for board.ReadReg and board.WriteReg
commands
• Accepts both hex & decimal inputs
• Uses the 8-bit form of the I2C address
• Can be used to shorten read/write commands
• Ex: board.devAddress = 0x60 sets the board address to 0x60
3.3.9.1.2 General I2C Reads/Writes:
These I2C commands will work for any I2C address on the local bus and remote devices configured in the Target
ID and Target alias registers of the device. The 8-bit form of I2C addresses should be used.
board.ReadI2C(Device Address,
Register Address , # of Bytes) OR
board.ReadI2C(Device Address,
Register Address)
I2C Read Command
• Accepts both hex & decimal inputs
• Number of bytes will default to 1 if omitted
• Ex: board.ReadI2C(0x60, 0x00) will return the value in Register 0 for
the device with address 0x60 (8-bit form)
board.WriteI2C(Device Address,
Register Address , Data)
I2C Write Command
• Accepts both hex & decimal inputs
• Ex: board.WriteI2C(0x60, 0x01, 0x01) will set Register 1 of the device
with address 0x60 (8-bit form) to have a value of 1
www.ti.com Troubleshooting
SNLU224D – SEPTEMBER 2017 – REVISED FEBRUARY 2023
Submit Document Feedback
DS90UB95x-Q1 Serializer Evaluation Module 19
Copyright © 2023 Texas Instruments Incorporated

3.3.9.1.3 I2C Reads/Writes with Multi-Byte Register Addresses
These I2C commands will work for any I2C address on the local bus and remote devices configured in the Target
ID and Target alias registers of the device. The 8-bit form of I2C addresses should be used.
board.ReadI2C(Device Address,
Register Address Byte 2,[Register
Address Byte 1, # of Bytes])
OR board.ReadI2C(Device Address,
Register Address Byte 2, [Register
Address Byte 1])
I2C Read Command for devices with multi-byte register addresses
• Accepts both hex & decimal inputs
• Number of bytes will default to 1 if omitted
• Ex: board.ReadI2C(0x60, 0x30, [0x00]) will return the value in
Register 0x3000 for the device with address 0x60 (8-bit form)
board.WriteI2C(Device Address,
Register Address Byte 2, [Register
Address Byte 1, Data])
I2C Write Command for devices with multi-byte register addresses
• Accepts both hex & decimal inputs
• Number of bytes will default to 1 if omitted
• • Ex: board.WriteI2C(0x60, 0x30, [0x01, 0x01]) will set Register
0x3000 of the device with address 0x60 (8-bit form) to have a
value of 1
Troubleshooting www.ti.com
20 DS90UB95x-Q1 Serializer Evaluation Module SNLU224D – SEPTEMBER 2017 – REVISED FEBRUARY 2023
Submit Document Feedback
Copyright © 2023 Texas Instruments Incorporated
