PCM1840 Evaluation Module
User's Guide
SBAU345–March 2020
PCM1840 Evaluation Module
This user's guide describes the function and use of the PCM1840EVM. This document includes the
hardware configuration instructions, a quick-start guide, jumper and connector descriptions, schematics,
and printed-circuit board (PCB) layout that demonstrate TI's recommended practices for these devices.
Contents
1 Introduction ................................................................................................................... 3
2 Power Supply................................................................................................................. 3
3 Hardware Configuration..................................................................................................... 3
3.1 PCM1840EVM Inputs .............................................................................................. 5
4 EVM Overview ............................................................................................................... 6
5 Layer Plots.................................................................................................................... 8
6 Schematic and Bill of Materials........................................................................................... 11
6.1 PCM1840EVM Schematic........................................................................................ 11
6.2 PCM1840EVM Bill of Materials.................................................................................. 13
7 Related Documentation.................................................................................................... 15
List of Figures
1 PCM1840EVM Input Architecture ......................................................................................... 5
2 PCM1840EVM Connection for Line Input Application .................................................................. 5
3 PCM1840EVM Connection for the Onboard Microphone Test ........................................................ 6
4 EVM Front Overview ........................................................................................................ 6
5 EVM Back Overview ........................................................................................................ 7
6 Top Layer..................................................................................................................... 8
7 Power Plane 1................................................................................................................ 9
8 Power Plane 2.............................................................................................................. 10
9 Bottom Layer................................................................................................................ 11
10 PCM1840EVM Schematics - Main....................................................................................... 12
11 PCM1840 Schematics - Power........................................................................................... 12

www.ti.com
2SBAU345–March 2020
Submit Documentation Feedback
Copyright © 2020, Texas Instruments Incorporated
PCM1840 Evaluation Module
List of Tables
1 PCM1840 EVM Headers and Jumpers................................................................................... 3
2 PCM1840 Hardware Controllable Settings............................................................................... 4
3 PCM1840EVM Bill of Materials........................................................................................... 13
Trademarks
Burr-Brown is a trademark of Texas Instruments.
All other trademarks are the property of their respective owners.

 
1
MON IOVDD
2
R
V 1 1.188
R
§ ·
 u
¨ ¸
¨ ¸
© ¹
 
3
MON AVDD
4
R
V 1 1.188
R
§ ·
 u
¨ ¸
¨ ¸
© ¹
www.ti.com Introduction
3
SBAU345–March 2020
Submit Documentation Feedback Copyright © 2020, Texas Instruments Incorporated
PCM1840 Evaluation Module
1 Introduction
The PCM1840EVM is an evaluation module (EVM) designed to demonstrate the performance and
functionality of the PCM1840 device. The PCM1840 is a high-performance audio analog-to-digital
converter (ADC) that is configured through logic-level mode selection pins and does not require a digital
interface such as I2C or SPI to configure registers. As such, no software is necessary to interface with the
EVM. The EVM is powered with a single 5-V supply. Access to the converter output is provided on the
audio serial interface in I2S, LJ, or TDM format.
2 Power Supply
The PCM1840EVM can be powered with a single 5-V power supply connected to J6. Onboard low dropout
regulators convert the 5-V supply to the 3.3-V and 1.8-V rails used by the ADC. The analog supply,
AVDD, is fixed at 3.3 V. The digital supply, IOVDD, can be set to either 1.8 V or 3.3 V with J5. It is also
possible to power the ADC directly by removing J9 and J5 and applying a voltage directly to the AVDD
and IOVDD test points. Note that if this is done, it is important to keep J10 populated (or ensure there is a
path between the pins if the supply current is being monitored) as this jumper connects the applied IOVDD
to the mode selection pins and other circuitry that relies on IOVDD. If external supplies are used, there is
an onboard voltage supervisor, U3, that will hold the ADC in shutdown until both AVDD and IOVDD have
reached their respective threshold voltages. The shutdown thresholds for the supply voltages can be
adjusted as shown in Equation 1 and Equation 2. The supervisor can also be removed from the shutdown
logic by depopulating R5. For more information on the reset supervisor, see the TPS37xx Dual-Channel,
Low-Power, High-Accuracy Voltage Detectors Data Sheet.
(1)
(2)
3 Hardware Configuration
The format of the audio data and the operating mode of the ADC are controlled by the following pins:
MD0, MD1, MSZ, FMT0, and FMT1. These signals are referenced to IOVDD and can be set to high (1) or
low (0). If no shunt is installed, then a 10-kΩpulldown resistor will set the pin low so that the ADC remains
in a defined state. Table 1 shows the header numbers and their pin functions and Table 2 shows the
possible modes and output formats. The MSZ pin selects whether the device is a master or a slave on the
audio bus. When MSZ is pulled high, the device is in slave mode and MD1 becomes an input for MCLK. A
shunt connecting J19 to the center pin of J18 will route the MCLK signal provided on J8 to the MD1 pin on
the ADC to allow for easy interfacing with audio measurement equipment.
Table 1. PCM1840 EVM Headers and Jumpers
Designator Function
J1 Differential line, microphone input 1
J2 Differential line, microphone input 2
J3 Differential line, microphone input 3
J4 Differential line, microphone input 4
J5 IOVDD-SYS voltage selection (1.8 V or 3.3 V)
J6 +5-V supply input
J7 Connector to AC-MB
J8 Digital audio serial interface
J9 Connect AVDD to onboard 3.3-V regulator
J10 Connect IOVDD to IOVDD-SYS
J13 MSZ select
J14 Connect MICBIAS to onboard microphone
J15 Microphone OUT+ to ADC IN1P

Hardware Configuration www.ti.com
4SBAU345–March 2020
Submit Documentation Feedback
Copyright © 2020, Texas Instruments Incorporated
PCM1840 Evaluation Module
Table 1. PCM1840 EVM Headers and Jumpers (continued)
Designator Function
J16 Microphone OUT– to ADC IN1M
J17 MDO select
J18 MD1 select
J19 Connect MCLK to MD1
J20 FMT0 select
J21 FMT1 select
Table 2. PCM1840 Hardware Controllable Settings
MD0 Modes
MD0 MSZ (0 = Slave, 1 = Master) MDO Functional Mode
0 0 Linear phase filter
0 1 MCLK = 256 × Fs
1 0 Low latency filter
1 1 MCLK = 512 × Fs
MD1 Modes
MD1 MSZ (0 = Slave, 1 = Master) MD1 Functional Mode
0 0 DRE disabled
0 1 MCLK input
1 0 DRE enabled
1 1 MCLK input
Audio Output Data Format
FMT0 FMT1 Data Format
0 0 4 channel TDM
0 1 2 channel TDM
1 0 2 channel left-justified
1 1 2 channel I2S
All hardware pins are tied low by default, placing the device in slave mode with a linear phase filter, DRE
disabled, and 4-channel TDM audio output.
For more information on the operating modes of the PCM1840 device, see the PCM1840 Quad Channel,
32-Bit, 192-kHz, Burr-Brown™ Audio ADC Data Sheet.

MK1
IN1P IN1M IN2P IN2M IN3P IN3M IN4P IN4M
PCM1840
IN1P IN1M IN2P IN2M IN3P IN3M IN4P IN4M
J16
J15
MICBIAS
J14
www.ti.com Hardware Configuration
5
SBAU345–March 2020
Submit Documentation Feedback Copyright © 2020, Texas Instruments Incorporated
PCM1840 Evaluation Module
3.1 PCM1840EVM Inputs
The PCM1840 device is intended to be driven with differential line inputs or microphone inputs. Each of
the inputs has a 1-µF AC coupling film capacitor. Coupled with the 2.5-kΩinput impedance, this sets the
high pass filter cutoff frequency at approximately 63 Hz. This can be adjusted by replacing the input AC
coupling capacitors on the EVM if necessary. Figure 1 shows the architecture of the inputs to the
evaluation module. The EVM supports a differential full scale input range of 2 VRMS with an AVDD of 3.3 V.
Figure 1. PCM1840EVM Input Architecture
3.1.1 Line Inputs
For the line input configuration, shown in Figure 2, the PCM1840 captures the audio signal provided
through terminals J1 (IN1), J2 (IN2), J3 (IN3), and J4 (IN4). The input accepted in this mode is a
differential, 2 VRMS, full-scale audio signal. Single-ended inputs are not supported by the PCM1840 device
and the inputs should be AC coupled.
Figure 2. PCM1840EVM Connection for Line Input Application

EVM Overview www.ti.com
6SBAU345–March 2020
Submit Documentation Feedback
Copyright © 2020, Texas Instruments Incorporated
PCM1840 Evaluation Module
3.1.2 Onboard Microphone Input
For the onboard microphone input configuration (shown in Figure 3), the PCM1840EVM records the audio
captured from the microphone located on the bottom-left edge of the board. MICBIAS is used to power the
onboard microphone through J14. J15, and J16 must be installed to connect the microphone output to the
ADC inputs. There must not be any connections to J1 during onboard microphone use to preserve the
performance of the microphone.
Figure 3. PCM1840EVM Connection for the Onboard Microphone Test
4 EVM Overview
Figure 4 shows an overview of the system.
Figure 4. EVM Front Overview

www.ti.com EVM Overview
7
SBAU345–March 2020
Submit Documentation Feedback Copyright © 2020, Texas Instruments Incorporated
PCM1840 Evaluation Module
Figure 5. EVM Back Overview

Layer Plots www.ti.com
8SBAU345–March 2020
Submit Documentation Feedback
Copyright © 2020, Texas Instruments Incorporated
PCM1840 Evaluation Module
5 Layer Plots
Figure 6. Top Layer

www.ti.com Layer Plots
9
SBAU345–March 2020
Submit Documentation Feedback Copyright © 2020, Texas Instruments Incorporated
PCM1840 Evaluation Module
Figure 7. Power Plane 1

Layer Plots www.ti.com
10 SBAU345–March 2020
Submit Documentation Feedback
Copyright © 2020, Texas Instruments Incorporated
PCM1840 Evaluation Module
Figure 8. Power Plane 2

www.ti.com Schematic and Bill of Materials
11
SBAU345–March 2020
Submit Documentation Feedback Copyright © 2020, Texas Instruments Incorporated
PCM1840 Evaluation Module
Figure 9. Bottom Layer
6 Schematic and Bill of Materials
6.1 PCM1840EVM Schematic
Figure 10 and Figure 11 show the schematics for the PCM1840EVM.

Schematic and Bill of Materials www.ti.com
12 SBAU345–March 2020
Submit Documentation Feedback
Copyright © 2020, Texas Instruments Incorporated
PCM1840 Evaluation Module
Figure 10. PCM1840EVM Schematics - Main
Figure 11. PCM1840 Schematics - Power

www.ti.com Schematic and Bill of Materials
13
SBAU345–March 2020
Submit Documentation Feedback Copyright © 2020, Texas Instruments Incorporated
PCM1840 Evaluation Module
6.2 PCM1840EVM Bill of Materials
Table 3. PCM1840EVM Bill of Materials
Designator QTY Value Description Package Reference Part Number Manufacturer
!PCB1 1 Printed Circuit Board DC117 Any
C1, C3, C7, C9, C11, C13,
C23, C27, C29, C42 10 0.1 uF CAP, CERM, 0.1 uF, 16 V, ±10%, X7R, 0402 0402 885012205037 Wurth Elektronik
C2 1 1 uF CAP, CERM, 1 uF, 16 V, ±10%, X7R, 0603 0603 885012206052 Wurth Elektronik
C4, C8, C10 3 10 uF CAP, CERM, 10 uF, 10 V, ±20%, X5R, 0603 0603 C1608X5R1A106M080AC TDK
C5 1 1 uF CAP, CERM, 1 uF, 16 V, ±10%, X7R, 0603 0603 EMK107B7105KA-T Taiyo Yuden
C6 1 1 uF CAP, CERM, 1 uF, 16 V, ±10%, X5R, 0402 0402 EMK105BJ105KVHF Taiyo Yuden
C12, C24, C26, C30 4 10 uF CAP, CERM, 10 uF, 16 V, ±20%, X5R, 0603 0603 EMK107BBJ106MA-T Taiyo Yuden
C14, C15, C16, C17, C18,
C19, C20, C21 8 1µF Film Capacitor 12V 10V Acrylic, Metallized 1206 (3216 Metric) 1206 FCA1206A105M-H3 Cornell Dubilier Electronics
C22, C28 2 0.01 uF CAP, CERM, 0.01 uF, 16 V, ±10%, X7R,
0402 0402 520L103KT16T AT Ceramics
D1, D3 2 Green LED, Green, SMD LED_0805 LTST-C170KGKT Lite-On
D2 1 Red LED, Red, SMD 1206 LTST-C150CKT Lite-On
H1, H2, H3, H4 4 Small nylon hex nut, 0.10 thick with a 0.250
outside diameter and a 4-40 threading Hex Nut,4-40 Thread, 250" Head Dia 9605 Keystone
H5, H6, H7, H8 4 Standoff, Hex, Male/Female, 4-40, Nylon, 1/2" Standoff, Hex,
Male/Female, 4-40,
Nylon, 1/2"
4802 Keystone
J1, J2, J3, J4 4 Terminal Block, 3.5mm Pitch, 4 × 1, TH 14 × 8.2 × 6.5mm ED555/4DS On-Shore Technology
J5, J13, J17, J18, J20, J21 6 Header, 100mil, 3 × 1, Gold, TH 3 × 1 Header TSW-103-07-G-S Samtec
J6 1 Terminal Block, 3.5mm Pitch, 2 × 1, TH 7.0 × 8.2 × 6.5mm ED555/2DS On-Shore Technology
J8 1 Header, 100mil, 4 × 2, Gold, TH 4 × 2 Header TSW-104-07-G-D Samtec
J9, J10, J14, J15, J16 5 Header, 100mil, 2 × 1, Gold, TH 2 × 1 Header TSW-102-07-G-S Samtec
J19 1 Header, 100mil, 1pos, Gold, TH Testpoint TSW-101-07-G-S Samtec
MK1 1 Ultra-Low Noise Microphone with Differential
Output, LGA-4 4 × 3mm, LGA ICS-40720 InvenSense
Q1 1 20 V MOSFET, 2-CH, N/P-CH, 20 V, 0.18 A, SOT-
563 SOT-563 SI1035X-T1-GE3 Vishay-Siliconix
Q2 1 50 V MOSFET, N-CH, 50 V, 0.21 A, SOT-323 SOT-323 BSS138W Fairchild Semiconductor
R1, R3, R8, R9, R10, R11,
R12 7 10 kΩRES, 10 k, 5%, 0.1 W, 0603 0603 CRCW060310K0JNEA Vishay-Dale
R2 1 24 kΩRES, 24 k, 5%, 0.1 W, AEC-Q200 Grade 0,
0603 0603 CRCW060324K0JNEA Vishay-Dale

Schematic and Bill of Materials www.ti.com
14 SBAU345–March 2020
Submit Documentation Feedback
Copyright © 2020, Texas Instruments Incorporated
PCM1840 Evaluation Module
Table 3. PCM1840EVM Bill of Materials (continued)
Designator QTY Value Description Package Reference Part Number Manufacturer
R4 1 7.5 kΩRES, 7.5 k, 5%, 0.1 W, AEC-Q200 Grade 0,
0603 0603 CRCW06037K50JNEA Vishay-Dale
R5 1 0 RES, 0, 5%, 0.125 W, 0805 0805 CRCW08050000Z0EA Vishay-Dale
R6 1 10 kΩRES, 10 k, 5%, 0.063 W, 0402 0402 CRCW040210K0JNED Vishay-Dale
R7, R13, R15 3 442 RES, 442, 1%, 0.1 W, AEC-Q200 Grade 0,
0603 0603 CRCW0603442RFKEA Vishay-Dale
R34 1 5.1 kΩRES, 5.1 k, 5%, 0.05 W, 0201 0201 RC0201JR-075K1L Yageo America
SH1, SH2, SH3, SH4, SH5,
SH6, SH7, SH8, SH9, SH10,
SH11
11 1 × 2 Shunt, 100mil, Gold plated, Black Shunt SNT-100-BK-G Samtec
SW1 1 Switch, Tactile, SPST-NO, 0.05A, 12V, SMT Switch, 4.4 × 2 × 2.9 mm TL1015AF160QG E-Switch
TP9, TP10 2 Test Point, Multipurpose, Black, TH Black Multipurpose
Testpoint 5011 Keystone
U1 1 PCM1840IRTWR, RTW0024H (WQFN-24) RTW0024H PCM1840IRTWR Texas Instruments
U2 1 500-mA, Low Quiescent Current, Low-Noise,
High PSRR, Low-Dropout Linear Regulator for
Automotive, DRB0008B (VSON-8)
DRB0008B TPS73533QDRBRQ1 Texas Instruments
U3 1 Low Power, Dual Voltage Detector in Small
uSON package, DRY0006A (USON-6) DRY0006A TPS3780ADRYR Texas Instruments
U4 1 500-mA, Low Quiescent Current, Low-Noise,
High PSRR, Low-Dropout Linear Regulator for
Automotive, DRB0008B (VSON-8)
DRB0008B TPS73518QDRBRQ1 Texas Instruments
FID1, FID2, FID3, FID4, FID5,
FID6 0 Fiducial mark. There is nothing to buy or mount. N/A N/A N/A
J7 0 Connector, Header, High Speed, 20 pairs,
SMT QTE-020-01-X-D-A QTE-020-01-L-D-A Samtec
TP1, TP2, TP3, TP4, TP5,
TP6, TP7, TP8, TP11, TP12,
TP13, TP14, TP15, TP16,
TP17
0 Test Point, Miniature, Red, TH Red Miniature Testpoint 5000 Keystone
TP19, TP20, TP21, TP22,
TP25 0 Test Point, Miniature, Green, TH Green Miniature Testpoint 5116 Keystone

www.ti.com Related Documentation
15
SBAU345–March 2020
Submit Documentation Feedback Copyright © 2020, Texas Instruments Incorporated
PCM1840 Evaluation Module
7 Related Documentation
• Texas Instruments, PCM1840 Quad Channel, 32-Bit, 192-kHz, Burr-Brown™ Audio ADC Data Sheet
• Texas Instruments, TPS37xx Dual-Channel, Low-Power, High-Accuracy Voltage Detectors Data Sheet

STANDARD TERMS FOR EVALUATION MODULES
1. Delivery: TI delivers TI evaluation boards, kits, or modules, including any accompanying demonstration software, components, and/or
documentation which may be provided together or separately (collectively, an “EVM” or “EVMs”) to the User (“User”) in accordance
with the terms set forth herein. User's acceptance of the EVM is expressly subject to the following terms.
1.1 EVMs are intended solely for product or software developers for use in a research and development setting to facilitate feasibility
evaluation, experimentation, or scientific analysis of TI semiconductors products. EVMs have no direct function and are not
finished products. EVMs shall not be directly or indirectly assembled as a part or subassembly in any finished product. For
clarification, any software or software tools provided with the EVM (“Software”) shall not be subject to the terms and conditions
set forth herein but rather shall be subject to the applicable terms that accompany such Software
1.2 EVMs are not intended for consumer or household use. EVMs may not be sold, sublicensed, leased, rented, loaned, assigned,
or otherwise distributed for commercial purposes by Users, in whole or in part, or used in any finished product or production
system.
2Limited Warranty and Related Remedies/Disclaimers:
2.1 These terms do not apply to Software. The warranty, if any, for Software is covered in the applicable Software License
Agreement.
2.2 TI warrants that the TI EVM will conform to TI's published specifications for ninety (90) days after the date TI delivers such EVM
to User. Notwithstanding the foregoing, TI shall not be liable for a nonconforming EVM if (a) the nonconformity was caused by
neglect, misuse or mistreatment by an entity other than TI, including improper installation or testing, or for any EVMs that have
been altered or modified in any way by an entity other than TI, (b) the nonconformity resulted from User's design, specifications
or instructions for such EVMs or improper system design, or (c) User has not paid on time. Testing and other quality control
techniques are used to the extent TI deems necessary. TI does not test all parameters of each EVM.
User's claims against TI under this Section 2 are void if User fails to notify TI of any apparent defects in the EVMs within ten (10)
business days after delivery, or of any hidden defects with ten (10) business days after the defect has been detected.
2.3 TI's sole liability shall be at its option to repair or replace EVMs that fail to conform to the warranty set forth above, or credit
User's account for such EVM. TI's liability under this warranty shall be limited to EVMs that are returned during the warranty
period to the address designated by TI and that are determined by TI not to conform to such warranty. If TI elects to repair or
replace such EVM, TI shall have a reasonable time to repair such EVM or provide replacements. Repaired EVMs shall be
warranted for the remainder of the original warranty period. Replaced EVMs shall be warranted for a new full ninety (90) day
warranty period.
WARNING
Evaluation Kits are intended solely for use by technically qualified,
professional electronics experts who are familiar with the dangers
and application risks associated with handling electrical mechanical
components, systems, and subsystems.
User shall operate the Evaluation Kit within TI’s recommended
guidelines and any applicable legal or environmental requirements
as well as reasonable and customary safeguards. Failure to set up
and/or operate the Evaluation Kit within TI’s recommended
guidelines may result in personal injury or death or property
damage. Proper set up entails following TI’s instructions for
electrical ratings of interface circuits such as input, output and
electrical loads.
NOTE:
EXPOSURE TO ELECTROSTATIC DISCHARGE (ESD) MAY CAUSE DEGREDATION OR FAILURE OF THE EVALUATION
KIT; TI RECOMMENDS STORAGE OF THE EVALUATION KIT IN A PROTECTIVE ESD BAG.

www.ti.com
2
3Regulatory Notices:
3.1 United States
3.1.1 Notice applicable to EVMs not FCC-Approved:
FCC NOTICE: This kit is designed to allow product developers to evaluate electronic components, circuitry, or software
associated with the kit to determine whether to incorporate such items in a finished product and software developers to write
software applications for use with the end product. This kit is not a finished product and when assembled may not be resold or
otherwise marketed unless all required FCC equipment authorizations are first obtained. Operation is subject to the condition
that this product not cause harmful interference to licensed radio stations and that this product accept harmful interference.
Unless the assembled kit is designed to operate under part 15, part 18 or part 95 of this chapter, the operator of the kit must
operate under the authority of an FCC license holder or must secure an experimental authorization under part 5 of this chapter.
3.1.2 For EVMs annotated as FCC – FEDERAL COMMUNICATIONS COMMISSION Part 15 Compliant:
CAUTION
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) this device must accept any interference received, including interference that may cause
undesired operation.
Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to
operate the equipment.
FCC Interference Statement for Class A EVM devices
NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of
the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to
correct the interference at his own expense.
FCC Interference Statement for Class B EVM devices
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of
the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more
of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
3.2 Canada
3.2.1 For EVMs issued with an Industry Canada Certificate of Conformance to RSS-210 or RSS-247
Concerning EVMs Including Radio Transmitters:
This device complies with Industry Canada license-exempt RSSs. Operation is subject to the following two conditions:
(1) this device may not cause interference, and (2) this device must accept any interference, including interference that may
cause undesired operation of the device.
Concernant les EVMs avec appareils radio:
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation
est autorisée aux deux conditions suivantes: (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit
accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement.
Concerning EVMs Including Detachable Antennas:
Under Industry Canada regulations, this radio transmitter may only operate using an antenna of a type and maximum (or lesser)
gain approved for the transmitter by Industry Canada. To reduce potential radio interference to other users, the antenna type
and its gain should be so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more than that necessary for
successful communication. This radio transmitter has been approved by Industry Canada to operate with the antenna types
listed in the user guide with the maximum permissible gain and required antenna impedance for each antenna type indicated.
Antenna types not included in this list, having a gain greater than the maximum gain indicated for that type, are strictly prohibited
for use with this device.

www.ti.com
3
Concernant les EVMs avec antennes détachables
Conformément à la réglementation d'Industrie Canada, le présent émetteur radio peut fonctionner avec une antenne d'un type et
d'un gain maximal (ou inférieur) approuvé pour l'émetteur par Industrie Canada. Dans le but de réduire les risques de brouillage
radioélectrique à l'intention des autres utilisateurs, il faut choisir le type d'antenne et son gain de sorte que la puissance isotrope
rayonnée équivalente (p.i.r.e.) ne dépasse pas l'intensité nécessaire à l'établissement d'une communication satisfaisante. Le
présent émetteur radio a été approuvé par Industrie Canada pour fonctionner avec les types d'antenne énumérés dans le
manuel d’usage et ayant un gain admissible maximal et l'impédance requise pour chaque type d'antenne. Les types d'antenne
non inclus dans cette liste, ou dont le gain est supérieur au gain maximal indiqué, sont strictement interdits pour l'exploitation de
l'émetteur
3.3 Japan
3.3.1 Notice for EVMs delivered in Japan: Please see http://www.tij.co.jp/lsds/ti_ja/general/eStore/notice_01.page 日本国内に
輸入される評価用キット、ボードについては、次のところをご覧ください。
http://www.tij.co.jp/lsds/ti_ja/general/eStore/notice_01.page
3.3.2 Notice for Users of EVMs Considered “Radio Frequency Products” in Japan: EVMs entering Japan may not be certified
by TI as conforming to Technical Regulations of Radio Law of Japan.
If User uses EVMs in Japan, not certified to Technical Regulations of Radio Law of Japan, User is required to follow the
instructions set forth by Radio Law of Japan, which includes, but is not limited to, the instructions below with respect to EVMs
(which for the avoidance of doubt are stated strictly for convenience and should be verified by User):
1. Use EVMs in a shielded room or any other test facility as defined in the notification #173 issued by Ministry of Internal
Affairs and Communications on March 28, 2006, based on Sub-section 1.1 of Article 6 of the Ministry’s Rule for
Enforcement of Radio Law of Japan,
2. Use EVMs only after User obtains the license of Test Radio Station as provided in Radio Law of Japan with respect to
EVMs, or
3. Use of EVMs only after User obtains the Technical Regulations Conformity Certification as provided in Radio Law of Japan
with respect to EVMs. Also, do not transfer EVMs, unless User gives the same notice above to the transferee. Please note
that if User does not follow the instructions above, User will be subject to penalties of Radio Law of Japan.
【無線電波を送信する製品の開発キットをお使いになる際の注意事項】 開発キットの中には技術基準適合証明を受けて
いないものがあります。 技術適合証明を受けていないもののご使用に際しては、電波法遵守のため、以下のいずれかの
措置を取っていただく必要がありますのでご注意ください。
1. 電波法施行規則第6条第1項第1号に基づく平成18年3月28日総務省告示第173号で定められた電波暗室等の試験設備でご使用
いただく。
2. 実験局の免許を取得後ご使用いただく。
3. 技術基準適合証明を取得後ご使用いただく。
なお、本製品は、上記の「ご使用にあたっての注意」を譲渡先、移転先に通知しない限り、譲渡、移転できないものとします。
上記を遵守頂けない場合は、電波法の罰則が適用される可能性があることをご留意ください。 日本テキサス・イ
ンスツルメンツ株式会社
東京都新宿区西新宿６丁目２４番１号
西新宿三井ビル
3.3.3 Notice for EVMs for Power Line Communication: Please see http://www.tij.co.jp/lsds/ti_ja/general/eStore/notice_02.page
電力線搬送波通信についての開発キットをお使いになる際の注意事項については、次のところをご覧ください。http:/
/www.tij.co.jp/lsds/ti_ja/general/eStore/notice_02.page
3.4 European Union
3.4.1 For EVMs subject to EU Directive 2014/30/EU (Electromagnetic Compatibility Directive):
This is a class A product intended for use in environments other than domestic environments that are connected to a
low-voltage power-supply network that supplies buildings used for domestic purposes. In a domestic environment this
product may cause radio interference in which case the user may be required to take adequate measures.

www.ti.com
4
4EVM Use Restrictions and Warnings:
4.1 EVMS ARE NOT FOR USE IN FUNCTIONAL SAFETY AND/OR SAFETY CRITICAL EVALUATIONS, INCLUDING BUT NOT
LIMITED TO EVALUATIONS OF LIFE SUPPORT APPLICATIONS.
4.2 User must read and apply the user guide and other available documentation provided by TI regarding the EVM prior to handling
or using the EVM, including without limitation any warning or restriction notices. The notices contain important safety information
related to, for example, temperatures and voltages.
4.3 Safety-Related Warnings and Restrictions:
4.3.1 User shall operate the EVM within TI’s recommended specifications and environmental considerations stated in the user
guide, other available documentation provided by TI, and any other applicable requirements and employ reasonable and
customary safeguards. Exceeding the specified performance ratings and specifications (including but not limited to input
and output voltage, current, power, and environmental ranges) for the EVM may cause personal injury or death, or
property damage. If there are questions concerning performance ratings and specifications, User should contact a TI
field representative prior to connecting interface electronics including input power and intended loads. Any loads applied
outside of the specified output range may also result in unintended and/or inaccurate operation and/or possible
permanent damage to the EVM and/or interface electronics. Please consult the EVM user guide prior to connecting any
load to the EVM output. If there is uncertainty as to the load specification, please contact a TI field representative.
During normal operation, even with the inputs and outputs kept within the specified allowable ranges, some circuit
components may have elevated case temperatures. These components include but are not limited to linear regulators,
switching transistors, pass transistors, current sense resistors, and heat sinks, which can be identified using the
information in the associated documentation. When working with the EVM, please be aware that the EVM may become
very warm.
4.3.2 EVMs are intended solely for use by technically qualified, professional electronics experts who are familiar with the
dangers and application risks associated with handling electrical mechanical components, systems, and subsystems.
User assumes all responsibility and liability for proper and safe handling and use of the EVM by User or its employees,
affiliates, contractors or designees. User assumes all responsibility and liability to ensure that any interfaces (electronic
and/or mechanical) between the EVM and any human body are designed with suitable isolation and means to safely
limit accessible leakage currents to minimize the risk of electrical shock hazard. User assumes all responsibility and
liability for any improper or unsafe handling or use of the EVM by User or its employees, affiliates, contractors or
designees.
4.4 User assumes all responsibility and liability to determine whether the EVM is subject to any applicable international, federal,
state, or local laws and regulations related to User’s handling and use of the EVM and, if applicable, User assumes all
responsibility and liability for compliance in all respects with such laws and regulations. User assumes all responsibility and
liability for proper disposal and recycling of the EVM consistent with all applicable international, federal, state, and local
requirements.
5. Accuracy of Information: To the extent TI provides information on the availability and function of EVMs, TI attempts to be as accurate
as possible. However, TI does not warrant the accuracy of EVM descriptions, EVM availability or other information on its websites as
accurate, complete, reliable, current, or error-free.
6. Disclaimers:
6.1 EXCEPT AS SET FORTH ABOVE, EVMS AND ANY MATERIALS PROVIDED WITH THE EVM (INCLUDING, BUT NOT
LIMITED TO, REFERENCE DESIGNS AND THE DESIGN OF THE EVM ITSELF) ARE PROVIDED "AS IS" AND "WITH ALL
FAULTS." TI DISCLAIMS ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, REGARDING SUCH ITEMS, INCLUDING BUT
NOT LIMITED TO ANY EPIDEMIC FAILURE WARRANTY OR IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS
FOR A PARTICULAR PURPOSE OR NON-INFRINGEMENT OF ANY THIRD PARTY PATENTS, COPYRIGHTS, TRADE
SECRETS OR OTHER INTELLECTUAL PROPERTY RIGHTS.
6.2 EXCEPT FOR THE LIMITED RIGHT TO USE THE EVM SET FORTH HEREIN, NOTHING IN THESE TERMS SHALL BE
CONSTRUED AS GRANTING OR CONFERRING ANY RIGHTS BY LICENSE, PATENT, OR ANY OTHER INDUSTRIAL OR
INTELLECTUAL PROPERTY RIGHT OF TI, ITS SUPPLIERS/LICENSORS OR ANY OTHER THIRD PARTY, TO USE THE
EVM IN ANY FINISHED END-USER OR READY-TO-USE FINAL PRODUCT, OR FOR ANY INVENTION, DISCOVERY OR
IMPROVEMENT, REGARDLESS OF WHEN MADE, CONCEIVED OR ACQUIRED.
7. USER'S INDEMNITY OBLIGATIONS AND REPRESENTATIONS. USER WILL DEFEND, INDEMNIFY AND HOLD TI, ITS
LICENSORS AND THEIR REPRESENTATIVES HARMLESS FROM AND AGAINST ANY AND ALL CLAIMS, DAMAGES, LOSSES,
EXPENSES, COSTS AND LIABILITIES (COLLECTIVELY, "CLAIMS") ARISING OUT OF OR IN CONNECTION WITH ANY
HANDLING OR USE OF THE EVM THAT IS NOT IN ACCORDANCE WITH THESE TERMS. THIS OBLIGATION SHALL APPLY
WHETHER CLAIMS ARISE UNDER STATUTE, REGULATION, OR THE LAW OF TORT, CONTRACT OR ANY OTHER LEGAL
THEORY, AND EVEN IF THE EVM FAILS TO PERFORM AS DESCRIBED OR EXPECTED.

www.ti.com
5
8. Limitations on Damages and Liability:
8.1 General Limitations. IN NO EVENT SHALL TI BE LIABLE FOR ANY SPECIAL, COLLATERAL, INDIRECT, PUNITIVE,
INCIDENTAL, CONSEQUENTIAL, OR EXEMPLARY DAMAGES IN CONNECTION WITH OR ARISING OUT OF THESE
TERMS OR THE USE OF THE EVMS , REGARDLESS OF WHETHER TI HAS BEEN ADVISED OF THE POSSIBILITY OF
SUCH DAMAGES. EXCLUDED DAMAGES INCLUDE, BUT ARE NOT LIMITED TO, COST OF REMOVAL OR
REINSTALLATION, ANCILLARY COSTS TO THE PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES, RETESTING,
OUTSIDE COMPUTER TIME, LABOR COSTS, LOSS OF GOODWILL, LOSS OF PROFITS, LOSS OF SAVINGS, LOSS OF
USE, LOSS OF DATA, OR BUSINESS INTERRUPTION. NO CLAIM, SUIT OR ACTION SHALL BE BROUGHT AGAINST TI
MORE THAN TWELVE (12) MONTHS AFTER THE EVENT THAT GAVE RISE TO THE CAUSE OF ACTION HAS
OCCURRED.
8.2 Specific Limitations. IN NO EVENT SHALL TI'S AGGREGATE LIABILITY FROM ANY USE OF AN EVM PROVIDED
HEREUNDER, INCLUDING FROM ANY WARRANTY, INDEMITY OR OTHER OBLIGATION ARISING OUT OF OR IN
CONNECTION WITH THESE TERMS, , EXCEED THE TOTAL AMOUNT PAID TO TI BY USER FOR THE PARTICULAR
EVM(S) AT ISSUE DURING THE PRIOR TWELVE (12) MONTHS WITH RESPECT TO WHICH LOSSES OR DAMAGES ARE
CLAIMED. THE EXISTENCE OF MORE THAN ONE CLAIM SHALL NOT ENLARGE OR EXTEND THIS LIMIT.
9. Return Policy. Except as otherwise provided, TI does not offer any refunds, returns, or exchanges. Furthermore, no return of EVM(s)
will be accepted if the package has been opened and no return of the EVM(s) will be accepted if they are damaged or otherwise not in
a resalable condition. If User feels it has been incorrectly charged for the EVM(s) it ordered or that delivery violates the applicable
order, User should contact TI. All refunds will be made in full within thirty (30) working days from the return of the components(s),
excluding any postage or packaging costs.
10. Governing Law: These terms and conditions shall be governed by and interpreted in accordance with the laws of the State of Texas,
without reference to conflict-of-laws principles. User agrees that non-exclusive jurisdiction for any dispute arising out of or relating to
these terms and conditions lies within courts located in the State of Texas and consents to venue in Dallas County, Texas.
Notwithstanding the foregoing, any judgment may be enforced in any United States or foreign court, and TI may seek injunctive relief
in any United States or foreign court.
Mailing Address: Texas Instruments, Post Office Box 655303, Dallas, Texas 75265
Copyright © 2019, Texas Instruments Incorporated
